DIGIWEIGH DWP-102NS User Manual

DWP-102N

DWP-102NS

DWP-102N(S)

NTEP Weighing Indicator

User’s Guide

PLEASE READ THIS MANUAL VERY CAREFULLY BEFORE
ATTEMPT TO OPERATE THE INSTRUMENT

April 2012

Specifications subject to change without prior notice

CONTENTS

1. INSTALLATION

2. SPECIFICATIONS

3. KEYS, DISPLAY AND CONNECTIONS

4. GETTING STARTED

5. INITIAL SETUP

6. INSTRUCTION FOR USE

7. RS232 DATA OUTPUT

8. BATTERY POWER AND RECHARGING

9. ERROR CODES

10. DAILY CARE AND MAINTENANCE

1. INSTALLATION

Because of metrological legislation, installation/some
metrological parameter settings are limited to be done by
authorized personnel only. Do not attempt to change any of the
built-in metrological parameters. Contact your dealer for more
information and technical assistance.

To ensure performance accuracy, do not use the instrument in
where or when the environment condition falls beyond as those
listed on SPECIFICATIONS.

Do not attempt to open the instrument, no user serviceable
parts inside.

2. SPECIFICATIONS

Housing

DWP-102N plastic housing with s s bracket
DWP-102NS with Stainless steel housing

Power supply

110V 60Hz
built-in rechargeable battery
DWP-102N 6V4AH.
DWP-102NS 6V 1.3AH

Display

6 digits. 1’ LED and 9 status indication

Keys

0-9 numeric and function combined keys
and TARE,ZERO,CE keys

Max input

15mV

ADC

Σ-Δ

Interface

2 ports RS-232 Output

Stabilization time

1 second typical

Operating temperature

5°C -35°C

Load cell drive voltage

5V/ Max 150mA

Other function

Real-time clock
and units conversion of kg ,lb, oz, g

Load cells

8 x 350Ω Load Cells, or
16 x 700Ω Load Cells

Load Cell Connection

Supports 4-wire and 6-wire Load Cell
Connections

2.1 GENERAL SPECIFICATIONS

3. KEYS, DISPLAY AND CONNECTIONS

1.CNT KEY

Press this key to enter counting function
Press this key as next parameter when setting

2. WEIGHT UNIT KEY

Press this key to shift among various weight units.
Press this key as previous parameter when setting

3. WEIGH KEY

Press this key to back weighing status after counting, checking, animal
weighing, percentage function

4. PRINT KEY

Press this key to print the results to a computer or a printer through the
RS-232 output. according to the parameter setting whether accumulate or
not when printing

5.TARE KEY

Press this key to tare off the weight of a container.
Press this key to enter parameter setting when self-checking after power on
Press this key to confirm the parameter option

6. ZERO KEY

Press this key to set weight displayed to zero when an empty scale has
drifted away from a true zero reading.
Cancel or quit from the operations

6. CHECK KEY

Press this key to start check weighing function and to enter value for HI and
LO limit.

7. ANI KEY
Press this key to enter animal weighing function

8.PERCENTAGE KEY

Press this key to enter percentage weighing function

9.PTARE KEY
Press this key to enter pre-set tare value

10.MC KEY

Press this key to recall total stored transactions.

11.CE KEY
Press this key to clear value entered.

12. NUMERIC KEYS

Numeric keys 0 ~ 9 and decimal key.

13.ON/OFF
Power on /off the indicator

14. CHECK SYMBOLS

 HI = Weight reading is higher than the HI limit entered,
 OK = Weight reading is in between than the low and HI limits entered,
 LO = Weight reading is lower than the LO limit entered.


15. TARE INDICATOR

Visible when the tare function is in effect. Weight reading shown is net value

16. STABLE INDICATOR

Visible when weight reading is stable.

17. ZERO INDICATOR

Visible when instrument is at true zero weight status.

18. WEIGHT UNIT

LED indication as below:
kg =”kg” on, lb = “lb” on
oz = both “kg” and “lb” on; g= neither “kg “ nor “lb” on

19. CHARGE INDICATION

Flicker when charging ; invisible when full of charge

RS232
COMPORT 1
(DB9)
comport.

RS232
COMPORT 2
(DB9)

LOAD CELL
CONNECTOR
(5 or 7-Pin).

AC power plug

110V adapter

BACKSIDE INSTRUCTION

DWP102N:

TTL (low-active) is transmitted here(optional). The DB-25 connector of the
external relay board (if ordered) should be plugged in

DWP102NS:

DWP-102NS use water proof joints which need to get through the round
joints and connect onto the PCB
The recommend (from left to right):

1) power plug 2) Com2 RS232

3) Com1 RS232 (RS485 optional) 4) Loadcell

4. GETTING STARTED

In order to obtain an accurate weighing result, the weighing platform,
(hereinafter referred as platform) must be placed on a strong and level
surface. Avoid using the platform and this instrument (hereinafter
collectively referred as scale) in environment where excessive wind flow,
vibration and extreme temperature change exist

General Warning: -

 The instrument is not an explosion proof device.
 The instrument is not a water proof device.
 Do not open the instrument, no user serviceable parts inside.

Always contact your dealer for service.

 The instrument not to be subject to shock, excessive vibration

or extremes of temperature (before or after installation).

4.1 BUILT-IN RECHARGEABLE BATTERY

The instrument is equipped with a built-in rechargeable battery. Before first
time use, recharge it for at least 8 hours to ensure the best battery
performance.

4.2 POWER ADAPTOR

Before plugging in the power adaptor, check and make sure the input
voltage of the adaptor matches with output voltage of the electricity outlet. If
not, contact your dealer immediately.

4.3 CONNECTING OTHER DEVICES1

4.3.1 Connection with Weighing Platform (Load Cell)

Connect this instrument with a weighing platform (load cell) through load
cell connector located at the back according to the below pin assignment
table.
4-wire load cell or junction box is used as default,.6-wire load cell is optional
