Digiview
Atomic Projection
Alarm Clock
(PCR102W)
USER'S MANUAL
DIGIVIEW PCR102W MANUAL (English)
SIZE: W65 X H105 (mm)
BY EMILY TSOI 08/07/05
TABLE OF CONTENTS |
|
INTRODUCTION |
|
|
|
Thank you for selecting the Digiview Atomic Projection |
|
INTRODUCTION |
3 |
Alarm Clock. This device delivers precise time keeping |
|
ABOUT HIDEKI ELECTRONICS |
3 |
and can project the current time onto the wall or ceiling. |
|
In this package you will find: |
|||
PRODUCT OVERVIEW |
3 |
• One Atomic Projection Clock |
|
WWVB RADIO CONTROLLED TIME |
7 |
• One AC/DC Adapter |
|
GETTING STARTED |
8 |
• One User Manual |
|
Please keep this manual handy as you use your new |
|||
BATTERY INSTALLATION |
8 |
item. It contains practical step-by-step instructions, |
|
ATOMIC CLOCK |
8 |
as well as technical specifications and precautions |
|
you should know. |
|||
CALENDAR AND CLOCK |
8 |
||
ABOUT HIDEKI ELECTRONICS |
|||
PROJECTION |
9 |
||
MANUAL SETTINGS |
9 |
Visit our website (www.digiviewtime.com) to learn |
|
more about a wide range of Hideki Electronics |
|||
SNOOZE |
12 |
products such as precise projection time pieces, |
|
PRECAUTIONS |
14 |
environmental products and weather monitoring |
|
devices. The website also includes important information |
|||
SPECIFICATIONS |
14 |
about an extended warranty program and other useful |
|
STANDARD WARRANTY |
15 |
facts. |
|
|
|||
INFORMATION |
|
PRODUCT OVERVIEW |
|
|
|
FEATURES |
|
|
|
* Precise time and date set via RF signals from the |
|
|
|
US Atomic Clock |
|
|
|
* Current time image projected onto the ceiling or |
|
|
|
wall |
|
|
|
* 180° projected image flip |
|
|
|
* Calendar displaying date with month and day of the |
|
|
|
week in English, Spanish or French |
|
|
|
* User-selectable 12 or 24 hour time format |
|
|
|
* Dual crescendo alarm with programmable snooze |
|
|
|
* LED backlight |
|
2 |
|
3 |
|
|
|
|
FRONT VIEW
A. ATOMIC CLOCK WITH THREE LINE DISPLAY CALENDAR AND US TIME ZONE MAP
H
|
MIC |
TO |
|
A |
|
CLOCK
MODE
B
A C
1 |
D |
G |
E |
2 |
F
4
B. PROJECTOR
* Projects current time onto the wall or ceiling
C. MODE BUTTON
*Allows toggling between Alarm One and Alarm Two display modes
*Allows setting the date and time manually
D. UP (+) BUTTON
*Increases all function parameters
*Activates US Time Zone selection mode
*Enables Atomic Time signal search when used simultaneously with DOWN (–) button.
Press to select 12 or 24 hour time format.
E. DOWN (–) BUTTON
*Decreases all function parameters
*Sets the language for the day of the week
*Enables Atomic Time signal search when used simultaneously with UP (+) button.
F. 1 AND 2 BUTTONS
*Activate or deactivate Alarm One and Alarm Two
*Set the time for Alarm One and Alarm Two
G. “CONTINUE PROJECTION” SWITCH
*Allows continuous projection of the current time onto the wall or ceiling
H. SNOOZE/LIGHT BUTTON
* Activates LED backlight and snooze feature
5
REAR VIEW
I. BATTERY COMPARTMENT
*Accommodates 2 (two) UM-3 or AA 1.5V alkaline batteries.
BOTTOM VIEW
J. FLIP BUTTON
*Allows to flip the projected image 180°
K. AC/DC ADAPTER CONNECTION
*Allows to connect AC/DC adapter
FLIP
DC 3V
6
WWVB RADIO CONTROLLED TIME
The NIST (National Institute of Standards and Technology) radio station (WWVB) is located in Ft. Collins, Colorado. It transmits an exact time signal continuously throughout the most of the continental United States at 60 KHz frequency. The Travel Alarm Clock can receive this WWVB signal through the internal antenna from up to 2,000 miles away. Due to the nature of the Earth’s ionosphere, reception can be limited during the daylight hours. The radio controlled clock will search for an alternate station that receives the atomic time signal from the NIST Atomic clock in Boulder, Colorado.
The WWVB tower icon on the unit’s display will flash indicating a radio signal reception from the WWVB station. If the tower icon is not fully lit, or if the time and date are not set automatically, please consider the following:
*During night-time hours, atmospheric disturbances are typically less severe and radio signal reception may improve. A single daily reception is sufficient enough to keep the clock accuracy within 1 second.
*Make sure the unit is positioned at 8 feet (2 meters) distance from any interference source such as a TV, computer monitor, microwave, etc.
*Within concrete wall rooms such as basements or office buildings, the received signal may be weakened. Always place the Travel Alarm Clock near the window for better reception.
7
