Digi-Frame Photo Scanner User Manual
Photo Scanner
User Guide
1
What’s in the Box
Check the package for the following items. If there are any items missing
or damaged, please contact your place of purchase immediately.
Scanner
AC Power Adapter
CD containing User Guide
Scan To PC software (on CD)
Calibration Card
Roller Cleaning Tool
Sensor Cleaning Swab
2 x Plastic Sheaths
USB Cable
Supported Memory Cards
SD / SDHC / MMC
PC System Requirements
Operating system:
Windows XP, Vista, Windows 7 (32 / 64 bit or later version)
USB Port Supported:
USB 2.0 port
10MB free hard disk space for the Scan To PC Manager software
2
Table of Contents
1. Introduction ....................................................................................3
2. Scanner Overview .........................................................................4
3. Installation & Operation .............................................................5
3.1 Initial Setup ..........................................................5
3.2 Power on the Scanner.............................................6
3.3 Scan an Original ....................................................7
3.4 Power off the Scanner.............................................8
4. Connecting to a Computer .......................................................10
4.1 How to connect to a computer................................ 10
4.2 Disconnecting the scanner from a computer............. 11
5. Scanning To PC Manager ..........................................................12
5.1 Starting the Scan To PC Utility............................... 12
5.2 Uninstalling the Scan To PC Manager ...................... 13
6. Maintenance ..................................................................................14
6.1 Cleaning the Roller ............................................... 14
6.2 Calibrating the scanner ......................................... 15
6.3 Cleaning the Image Sensor.................................... 16
7. Troubleshooting ...........................................................................17
7.1 Frequently asked Questions ................................... 17
8. Specifications................................................................................18
3
1. Introduction
Congratulations on your purchase of a DigiFrame Photo Scanner.
Now you can scan and store your printed photos directly to your
memory card or USB Stick without connecting to any computer.
Simply insert a memory card or USB into the scanner, and power it
on. When the scanner is ready, feed your printed photo into the
scanner and your images will be stored in the memory card or USB. If
you want to store your photos directly into your computer, just plug in
a USB cable and/or use the supplied Scan To PC utility.
Before you install and operate the product, please take a few minutes
to read through this manual. It provides proper instructions for you to
install, operate and maintain the product.
4
2. Scanner Overview
Name Function/ Description
1 Power Button Press to power on or off.
2 Custom Button Press the button to start cleaning the roller.
3 Guide Lever
Slide the guide lever to adjust for various sized
originals to ensure the proper alignment.
4 Indicator light Indicates the operating status of the scanner.
5 Feeding Slot Insert an original to begin scanning.
6 Power connector For connecting to the supplied power adapter.
7 Mini USB connector For connecting to a computer via a USB cable.
8 Flash disk slot For inserting a USB Stick.
9 Memory card slot For inserting a memory card.
5
3. Installation & Operation
Precautions
Keep the product out of direct sunlight. Direct exposure to the
sun or excessive heat may cause damage to the unit.
Do not install the product in a humid or dusty place.
Be sure to use the proper AC power source.
Place the product securely on an even, flat surface. Tilted or
uneven surfaces may cause mechanical or paper-feeding
problems.
Retain the product box and packing materials for shipping
purposes.
3.1 Initial Setup
1. Connect the plug on the power adapter cable to the power
connector on the scanner.
2. Plug the power adapter into a power outlet.
3. Insert a memory card into the memory card slot or a USB into the
USB slot.
