The moment keeps going
Jackie on holidays
- Great ocean road, Melbourne
7" Disco Series
Bringing memories to life!
Product User Manual (Model No's: DF-F7010b, DF-F7011s & DF-F7012t)
Precautions
Do not subject the device to severe impact
Do not use the device in extreme hot or cold, dusty or damp
conditions. Do not expose it to direct sunshine.
Keep the device away from water or other liquids. In the event
that water or other liquids enter the device, power off the
product immediately, and clean the device with soft cloth.
Do not use a chemical solution to clean the device in order to
avoid corrosion. Clean it with a dry cloth.
We are not responsible for the damages or lost data caused by
malfunction, misusing, repairing the device or battery
replacement
Do not attempt to disassemble, repair or modify the product, or
it will void the warranty
To prevent overheating, never block vents on the back of the
digital photo frame
This manual is subject to change without prior notification.
Functions or display of the actual product may be different
from what is described in this manual. Please refer to the
actual product.
Clean the LCD Screen
Do not apply cleaning liquid to the LCD screen. The screen
may be easily scratched or broken. Wipe the screen with a soft,
non-abrasive cloth.
2
TABLE OF CONTENTS
1 PRODUCT OVERVIEW...................................................... 4
2 FEATURES & SPECIFICATIONS ....................................... 4
3 PACKAGE CONTENTS ...................................................... 4
4 BUTTONS & PORTS .......................................................... 5
5 REMOTE CONTROL ......................................................... 6
6 GETTING STARTED .......................................................... 7
7 TURN THE SCREEN ON or OFF ....................................... 7
8 MAIN MENU....................................................................... 8
9 MODE SELECTION ........................................................... 8
10 MEMORY DEVICE MENU ................................ .................. 8
11 THUMBNAIL VIEW................................ ............................. 9
12 CALENDAR........................................................................ 9
13 SETTINGS MENU ............................................................ 10
14 TROUBLESHOOTING ..................................................... 13
15 TECHNICAL SPECIFICATIONS ....................................... 14
3
1 PRODUCT OVERVIEW
7" Digital Photo Frame
Changeable Frames
Remote Control
Power Adaptor
Warranty Card
Operating Guide
The DigiFrame 7inch “Disco Series” Digital Photo Frame enables you
to view your photos on its high-resolution LCD screen. Simply insert
a USB flash drive or SD memory card into the appropriate slot
located on the back of the frame and your pictures will be displayed
on the screen.
2 FEATURES & SPECIFICATIONS
7inch TFT Digital LCD screen
Screen Resolution - 800 x 480 pixels
Aspect Ratio – 16:9
View Photos, Listen to Music and Watch Videos files
Changeable Frames INCLUDED
Supports: SD / MMC / MS & XD memory cards
USB Flash Drive Support
Automatic Photo Slideshow
Multi Languages
Split Screen Function
Picture Preview, Zoom and Rotate Functions
Calendar with Time Clock and Alarms
3 PACKAGE CONTENTS
4
1 UP Move cursor Up
2 DOWN Move cursor Down
3 LEFT Move cursor Left / Previous
4 RIGHT Move cursor Right / Next
5 STOP EXIT and move “BACK” through
menu options
6 MENU Display Menu options
7 ENTER Confirm Sections
8 MEMORY CARD SLOT SD / MMC / MS / XD
9 EARPHONE Connect to earphones (not supplied)
10 MIN-USB Connect to Mini USB
11 USB port Connect to a USB flash drive
12 DC IN port Connect to the AC adaptor
13 ON/OFF Power On / Off switch
14 UNIT STAND
4 BUTTONS & PORTS
5
5 REMOTE CONTROL
Key
Function
Mute – No Sound
Turn Power On or Off (on screen)
To Play Photo files
MUSIC
To Listen to Music files
MOVIE
To View Movie files
Play or Pause files
EXIT
Move back through Menu options
UP
Move cursor up / Rotate Anticlockwise
DOWN
Move cursor down / Rotate Clockwise
LEFT/ PREVIOUS
Move cursor left / Show previous photo
RIGHT/ NEXT
Move cursor right / Show next photo
ENTER
Confirm a selection
SETUP
Enter or Exit main menu
CALENDAR
Display the calendar / clock
VOL + and VOL -
Adjust Volume levels up or down
Forward
Backward
Previous
Next
6
6 GETTING STARTED
Step 1: Adjust the stand outwards so the unit will rest in position
Step 2: Connect the device to a wall outlet and switch Power On
using the switch located near the USB port
Step 3: Insert a USB flash drive into the USB port or a memory
card into the card slot.
Memory cards should be inserted with the sticker facing toward you
7 TURN THE SCREEN ON or OFF
When you do not want to view the photos momentarily, you can
press the button on your remote control to turn off the
screen for power saving. To turn on the screen, press the
button on the remote control again. To completely power
down the unit, use the switch located on the back of the unit
near the USB port.
7
8 MAIN MENU
Select from the following
Menu options:
* Slideshow – Play Photos and Music together
* Movie Select & Play Video files (MPEG1/2/4, AVI, DIVX)
* Photos Select & Play Photo files (JPEG)
* Music Select & Play Music files (MP3 & WMA)
*Calendar Access Calendar & Clock
9 MODE SELECTION
Press the LEFT / RIGHT buttons to choose the desired mode.
Use the “ENTER” button to confirm all selections.
Press EXIT / STOP to move backwards through the sub menus
10 MEMORY DEVICE MENU
After mode selection, use the
LEFT / RIGHT buttons to select
the desired Media Storage
Device (location of desired files)
To select press “ENTER”
(NOTE: “Favourite” drive contains system files only)
Previous/Next
Press the LEFT button to display the previous photo.
Press the RIGHT button to display the next photo.
8
11 THUMBNAIL VIEW
Slide Show
Current Time
Press the “ARROW Buttons”
to select photo from the
thumbnail view. Press the
“ENTER” button to confirm
and start viewing the photos.
12 CALENDAR
Your DigiFrame can also be used as a tabletop calendar with time
and an alarm clock.
To enter the calendar view mode, navigate to “CALENDAR” from the
main menu and then press the “ENTER” button to confirm. The
calendar & clock page will also display your photos in a slide show.
Press the LEFT, RIGHT, UP and DOWN button to select the date.
Press the “ENTER” button to confirm your selections
Press the EXIT/STOP button to return to the main menu.
9
13 SETTINGS MENU
Press the “Setup” key on the remote control (or Menu button on the
unit) and a popup menu will appear (invalid during Auto slideshow
and whilst in CALENDAR mode)
Use UP and DOWN keys to select the desired settings and use the
“ENTER” button to enter the sub menu settings.
Use the “ARROW Keys” to navigate and adjust and then press the
“ENTER” button to confirm the settings changes.
Press EXIT to move backwards through the menus and return to the
Main Menu.
1. Image Size
Select this option to set the view mode of the screen.
Three options - Auto Fit, Optimal and Full
2. Slide Show Effects
Select this option to set the transition effect of the slide show.
3. Slide Show Interval
Set the interval time between slides. From 1 second to 3 hours
(Default time is 7 seconds – large files may take longer to load)
4. Split Slide Show
Turn On/Off split screen slide show (4 photos will display at once)
5. Music play mode
Single Repeat, Circular, No Repeat and Single mode options
10
6. Start Slideshow
7. Rotate
Use “ENTER” key to rotate the picture clockwise from 90° - 360° (in
slideshow mode, press STOP/PAUSE first) – Available in full screen
display.
8. ZOOM
Use “ENTER” key to zoom in on the picture up to 10X. When the
photo is enlarged, you can press the “ARROW Keys” to roam on the
photo. When the picture zooms to 10X, press “ENTER” to restore
the picture to original size - Available in full screen display.
9. Save Picture
Available in picture playback mode
10. Reset Settings
Select this option to restore the system settings to the default factory
settings.
11. Languages
Select this option to set the Menu Language. If the wrong language
is selected by accident - Choose the 11th option from the top (this is
the Languages option) From Top to bottom they are
1. English 5. Spanish
2. French 5. Portuguese
3. Italian 6.
4. German 8. Dutch
11
12. Brightness – Contrast – Color & Tint
Use these options to adjust the image display properties
13. Alarm
To enable the alarm,
(1) Press SETUP button to select “SetTime/Set Alarm” and then
press the “ENTER” button to confirm.
(2) Press UP and DOWN button to select “Set Alarm”.
(3) Press the LEFT and RIGHT button to select “OFF” and then
press the UP / DOWN button to change “OFF” to “ON”.
(4) Press the LEFT and RIGHT button to select among the time
setting items – hour, minute, second. Press the UP and DOWN
button to set the time item.
(5) press the “ENTER” to confirm the alarm time. The alarm
should ring at the specified time every day.
NOTE: The frame must be on for the alarm to go off
16. Time
To setup and Save the Time and Date Settings
(1) Press the UP and DOWN buttons to select among the time
setting items – Year, Month, Day, Hour, Minute, Second.
(2) Use the LEFT and RIGHT buttons to adjust
(3) Then move down to “Save Time” to confirm these settings
12
14 TROUBLESHOOTING
The digital photo frame will
not power on.
Make sure that the AC adapter is
connected securely to the frame and
the power source.
Remote control does not
work
Ensure that a working battery is
inserted
The images can not be
displayed.
Make sure the image file is in a
supported format
The image is distorted or
blurred.
Resolution of the image is too low.
Try using a file with a higher
resolution.
The device responds very
slowly to commands.
There are too many files on the
memory device.
13
15 TECHNICAL SPECIFICATIONS
Item
Description
Display
7.0-inch TFT LCD screen
LCD Resolution
800 x 480
Photo Formats
JPEG
Music Formats
MP3, WMA
Video Formats
MPEG1/2/4, AVI, DIVX
Supports Memory Card
SD / MMC / MS / XD
USB Interface
USB 2.0 Host (High Speed)
Other
Calendar, Clock and Alarm
Supports Languages
English / French / Italian / German
Spanish & Portuguese
Memory Card Capacity
Up to 8GB
USB Flash Drive
Up to 8GB
Power Supply
AC Adapter, Input 100 ~ 240V,
DC 12V 1A
Storage Temp*
-20% ~ +55%
Ambient Temp*
0℃ ~ +55%
Operation Humidity*
20% ~ 80%
Storage Humidity*
20% ~ 80%
14
We hope you enjoy your DigiFrame
and all your special memories.
For additional hints & tips - visit us at www.digiframe.com.au
For Repairs & Service please contact CUSTOMER SERVICE on 1300 559 881
or email support@digiframe.com.au
