Product User Manual (Model No's: DF-F1048b, F1049r & F1050s)
1.
Welcome!
Congratulations on your purchase of a DigiFrame! We understand how
special memories of your loved ones and moments that you encounter
through your journey are. Now they can be treasured in high quality
digital form.
Your DigiFrame is designed to bring your digital photos out of your
computer and into your life! It is packed with great features (like movies
& functions) to help you get the most out of your special moments.
Jess & Chris
- Friends forever
2.
What’s inside
Introduction 3
Main Features 3
Getting Started 4
Package Contents 4
Installing your unit 5
Operation 6
Controls 7
Using your Remote Control 8
Inserting Memory Cards 9
Main menu 10
Viewing Pictures 11
Watching video 13
Listening to MP3 music 17
File Management 19
Playing a slideshow with music 19
Copying and Deleting Files 21
Using the SETUP option 22
Technical Support / FAQ 24-25
Troubleshooting 26
Cleaning the LCD screen 27
Maintenance and Precaution 27
Specications 28
3.
Introduction
Before operating the unit, please read this manual thoroughly, and retain it for future reference.
This manual will help you use many of the exciting and useful features that will make your Digiframe
viewing more enjoyable.
This Digiframe lets you view digital pictures directly from your camera’s memory cards.
You will be able to create a slideshow using multiple transition effects or display one picture at a time.
No computer, digital camera or Internet connection is required.
Main Features
This Digital Picture Frame is compatible with the following popular memory card formats: Compact Flash®, SD™, XD (m),
Multimedia Card™, and Memory Stick®.It can also read les stored on a USB Flash drive using the USB host port.
Displays digital pictures (JPEG) without a computer.
•
Simply insert a compatible memory card into the Digital Picture Frame to show photos, play MP3 music or supported video les.
•
Compatible memory cards include Secure Digital Card (SD), Multimedia Card (MMC), Memory Stick (MS), XD Cards & Compact Flash
•
•
Able to read les located on a USB Flash drive.
Instantly plays MP3 music with the integrated speakers.
•
Instantly plays MPEG1*, MPEG2* & MPEG 4 les stored on supported memory cards*.
•
Supports up to 12 Mega Pixels image les (JPEG format).
•
Compatible with most digital cameras’ stored JPEG images and motion JPEG les.
•
Includes a credit card style remote control.
•
Automatic slide show with multiple transition effects.
•
Plays slide show with MP3 music in the background.
•
User-friendly on-screen display lets you access all controls easily.
•
*Video les may not play properly if stored on a low speed card.
Package Contents
4.
4. Remote Control
2. USB Cable
3. AC Adapter1. Digiframe
Bringing memories to life!
Product user manual for 10.4 & 15” Models
5. User Manual
5.
Installing your unit
Open the packaging and carefully remove the protective foam and the protective, plastic sleeve from the unit.
•
•
Install the Digital Picture Frame stand into the back of the unit; Carefully align the stand in either the landscape or portrait
orientation and gently press on the middle of the stand until it is fully inserted.
Plug in the AC power adapter into power outlet and the other end into the unit.
•
•
Place all of the media you wish to show on the DigiFrame onto your memory card of choice and place it into the provided slot,
making sure that it is in the correct way.
Turn the DigiFrame ON via the ON/OFF switch.
•
My favorite ower
- Grandad gardening
Operation
This Digital Frame is really easy to operate:
6.
1. Remove memory card from camera:
2. Insert memory card into the frame
and ensure it is inserted correctly:
3. The slideshow will start automatically:
7. 8.
Controls & Slots
1.
2.
3.
4.
Mini USB Port
CF Card
1. AUTO 2. MENU 3. PREVIOUS
4. NEXT
SD / MS / MMC / XD Card
Power
5. POWER
5.
Using your remote control
The following table briey describes the remote control functions.
BUTTON DESCRIPTION
On/Off Switch your Digiframe on/off
Card selection Select your memory card
VOL - Decrease volume
VOL + Increase Volume
Slideshow Start slideshow
Music Display music les
Photo Choose which photo les to display
Rotate Rotate the current picture
Mute Mute volume
Zoom Zoom In on the current picture
Play/Pause and display OSD menu
Stop
Setup Open the menu to changing settings
Arrows Navigate on screen
9.
Inserting Memory Cards
The Digital Picture Frame is compatible with the following memory cards:
Secure Digital Card (SD)
•
Multimedia Card (MMC)
•
Memory Stick
•
Compact Flash (CF) Card
•
XD (m) Picture Cards
•
Insert your memory card. Do not force. If you are not able to easily insert the memory card completely, you may have
inserted it the wrong way.
Note:
The Digital Picture Frame will ONLY recognise digital pictures stored in JPEG format. Digital pictures stored in other
formats will be ignored by the device.
Make sure you have at least one picture stored on the memory card. The frame will not function properly without a
stored picture.
You can also use a USB ash drive in the exact same way as you would use a memory card. Simply copy les on to the
ash drive and insert it in the USB Host plug.
Main Menu
Upon turning on the Digital Picture Frame, you will go straight to the MENU screen. To set the Auto Start feature Choose the
SETUP screen. Use the left/right arrow to go to the “Set up”. Press PLAY button to enter the options screen. Use the Up / down
arrows to choose your auto start option. Press the “Card selection” button to show the following menu:
Use the left and right arrows to move inside the menu and then press “PLAY”
to continue.
Note: In all menus, pressing the “Card selection” button will bring you back to
the main menu.
10.
Function Description
Nand Play les in internal memory
Calendar Display calendar, clock, alarm
Setup Set system menu
SD/MMC/MS/XD Play les on SD/MMC/MS/XD memory card
CF Play les on CF memory card
USB Play les on USB ash drive
Dan gets the ball
- Age 15, striker
11. 12.
Viewing Pictures
When correspondent card is removed from card slot.
VIEWING PICTURES
Make sure you have at least one picture on your memory card or your
USB ash drive. When this is done:
Select the desired ash media on main menu. (SD/XD/CF/MS/USB/
•
NAND-Internal Memory)
Select the “PHOTO” option from the menu and press “PLAY”
•
A Photo thumbnail will appear. User UP/DOWN/LEFT/RIGHT arrows to
•
move the highlight. If the highlighted is a folder, press PLAY to enter the
folder.
Relaxing in the park
- Brenda, mother of 2
Viewing Pictures
Otherwise press PLAY to enter the full screen
•
photo (pause mode) and press PLAY to enter into
slideshow mode.
Once a slideshow is playing or a picture is being
•
shown, press the PLAY button. The following menu
will appear:
13.
Viewing Pictures
Previous
Play previous picture in the picture list.
Play or Pause
Play or pause the current slideshow.
Next
Play next picture in the picture list.
Rotate
Use the rotate function to change the picture orientation
between either portrait or landscape.
Stop
Stop slideshow and return to photo thumbnail.
Zoom
Increase the size of the picture by 2/4/8/16/1 times.
Watching Video
14.
The Digital Picture Frame supports the following video formats:
Motion JPEG (AVI): video format used by
•
most digital cameras MPEG-I
MPEG-2
•
•
MPEG 4
Make sure you have at least one video on your memory card or your USB
ash drive. When this is done:
•
Select the desired ash media on main menu. (SD/XD/CF/MS/USB/
NAND-Internal Memory)
Select the “MOVIE” option from the menu and press “PLAY”
•
A list of all movie les will be listed on the left side of the screen. The right side consists of the movie preview window and
information display of the current movie. Use Up/Down arrows to select the movie and press PLAY to play.
15.
Watching Video
Once a movie is playing, press the PLAY button on the remote control.
The following menu will appear:
Watching Video
16.
Fast Forward
Play forward the movie by 2/3/4 times speed.
Play or Pause
Play or Pause the movie.
Fast Backward
Play backward the movie by 2/3/4 times speed.
Next
Play next movie in the play list.
Stop
Stop the movie and return to the play list.
Previous
Play previous movie in the play list.
Zoom
Increase the size of the picture by 2/3/4/1 times.
Listening to MP3 Music Files
Make sure you have at least one MP3 le on your memory card or your USB ash drive. When this is done:
Select the desired ash media on main menu. (SD/XD/CF/MS/USB/NAND-Internal Memory)
•
Select the “MUSIC” option from the menu and press “PLAY”
•
17.
Listening to MP3 Music
A list of music les will be listed on the left side of the screen. The right
side consists of the frequency chart and information status bar. The song
information area is below the status bar. Use Up/Down arrows to select the
music le and press PLAY to play.
Press VOL+ to increase the volume or VOL- to decrease the volume.
•
Press PLAY /PAUSE button on remote control to play or pause the
•
music le.
Press STOP button on the remote control to return to the card menu.
•
Pictures with Music Background
Playing a slideshow with music
Ensure you have at least one picture on your memory card or your USB ash drive. Additionally, you
must have one MP3 le saved on the same selected memory card/USB/Internal Memory.
When this is done:
Select the desired ash media on main menu. (SD/XD/CF/MS/USB/NAND-Internal Memory).
•
Select the “FILE” option from the menu and press “PLAY”.
•
A list of all les on the selected memory card or internal
•
memory will be listed on the left side of the screen. The right
side consists of the le information. Use Up/Down arrows to
select a picture le and press PLAY to enter a full screen photo
(pause mode). Press Slideshow button on the remote control, an
audio slideshow will begin automatically.
18.
19.
Pictures with Music Background
Once an audio-slideshow is playing, press the PLAY button.
•
The following menu will appear:
Previous
Play previous picture in the picture list.
Play or Pause
Play or pause the current slideshow.
Next
Play next picture in the picture list.
Rotate
Use the rotate function to change the picture orientation
to either portrait or landscape.
Stop
Stop slideshow and return to photo thumbnail.
Zoom
Increase the size of the picture by 2/4/8/16/1 times.
File Management
VOL
Press VOL+ or VOL- on remote control to increase or decrease the
volume
Copying and Deleting Files
Copy and delete les on your memory card, USB drive or internal
memory.
Copy
Select the desired ash media on main menu. (SD/XD/CF/MS/USB/
•
NAND-Internal Memory)
•
Select the “FILE” option from the menu and press “PLAY”.
A list of available les will be displayed. Use the up and down
•
arrows to highlight your desired le and press the RIGHT ARROW to
highlight the desired le. Repeat for all les that you want to copy.
20.
Press the “SETUP” button to display the Copy and Delete menu.
•
Select Copy function and Press “PLAY” button to display the C:/ and
D:/ menu.
Use Up/Down arrows to select the le destination folder.
•
Press Right button to conrm.
21.
Copying & deleting les
Press PLAY to start copying the le.
•
Press the STOP button to bring you back to the Copy and
•
Delete menu.
Delete
Select the desired ash media on main menu. (SD/XD/CF/MS/USB/NAND-Internal Memory)
•
Select the “FILE” option from the menu and press “PLAY”.
•
A list of available les will be displayed. Use the UP/DOWN arrows to highlight your required le and press
•
the RIGHT arrow to highlight the desired le. Repeat for all les that you want to copy.
Press the “SETUP” button to display the Copy and Delete menu. Select Delete function and press PLAY. File
•
will be deleted.
Pressing the STOP button will bring you back to the Copy and Delete menu.
•
Using the set-up option
Upon turning on the Digiframe, you will go straight to the MENU screen. Press the “SETUP” button to display the Setup menu on
the remote control. The following options can be changed by using the “SETUP” option from the main menu:
Function Description
Language English, French, Spanish, German, Italian
Slideshow time Slideshow duration: 3s/5s/15s/1mins/15mins/1hr
Slideshow mode Off, Random, Fading, Bottom to top, Top to bottom, Left to right, Right to left, Door close,
Door open, Hori cross, Verti cross
Music Repeat
Mode
Movie Repeat
Mode
Display mode Normal, Wide,
Time Year/Month/Date/Time setup
Alarm Alarm Time/Alarm Music/Alarm On/off setup
Default Recover the factory default setup
Repeat one , Repeat all, Repeat off
Repeat one, Repeat all, Repeat off
22.
NOTE: When entering into the “setup” menu, you can only use the remote controller for operation.
Then set the system function. The OSD button can not be used to operate your Digiframe.
23.
Using the set-up option
Calendar/Clock Display
Upon turning on the Digiframe, you will go straight to the MENU screen. If you select Calendar/Clock and press PLAY, you will go to
Calendar/Clock screen. If the Alarm is turned on, it will also show the alarm time. A picture slideshow will begin at the
picture preview window at the right part of the screen.
Technical Support
Frequently asked questions
1) Q: Can I use touch-enabled technology for my Digiframe?
A: The LCD screen does not support touch-enabled technology. Please use the buttons or remote control to control the Digiframe.
2) Q: If I keep showing the same photo for a long time, will it damage the LCD screen?
A: No. The Digiframe can display the same photo continuously for a long period time. But it is recommended not to show
the same picture continuously for more than 1 month.
3) Q: How do I store music les?
A: First, use a personal computer and popular audio editing software to convert your music to MP3 format. The Digiframe
will only play MP3 les so All Windows Media Player™ and/or iTunes™ les will have to be converted rst. You can use a
card reader or your digital camera to transfer those les to your memory card.
4) Q: Does the Digiframe have built-in memory?
A: Yes. The Digital Picture Frame has built-in memory to store your les.
24.
5) Q: What is the maximum picture size?
A: Your Digiframe is able to display pictures up to 12 Mega Pixels.
6) Q: What is the best picture resolution displayed on the screen?
A: The frame’s best resolution is 800×600.
25.
Technical Support
7) Q: How come the Digiframe does not show some of my photos?
A: The Digiframe is designed to show photos following the same camera industry standards format as digital
cameras. This format is a JPEG format. Images, such as web images, scanned images, or photos in RAW format, are not stored
according to camera industry standards and therefore cannot be displayed correctly on the Digiframe. Please use
your PC applications to convert such images into standard JPEG format before viewing them on the Digital Picture Frame.
Troubleshooting
Symptom Cause Corrective Actions
Digiframe doesn’t power on
No Start-up screen Memory card is not inserted correctly. Make sure there is at least one supported photo
Video doesn’t play properly Slow Memory Card Make sure you use a high-speed memory card to
Small video size on the screen Low Video Resolution Most digital cameras take video in 320x240 or
The POWER connector to the unit is not
securely inserted.
Make sure you connect the AC adapter to the
frame properly. When you connect the AC
adapter to the frame and power up the unit, even
without a memory card, you should see a opening
screen. If you don’t see the opening screen, check
if the power is connected to the Digiframe and
make sure it is securely attached.
le on the memory card.
• Compatible Photo format: Compatible Photo
format: JPEG
• Compatible Music format: MP3
• Compatible Video format: Motion JPEG (AVI),
MPEG1, MPEG2, MPEG4.
play video les.
lower resolution. The best supported resolution
of a photo or video is 640x480. Use the Zoom
button on the remote control to enlarge it.
26.
27.
Maintenance & Precaution
Maintenance and Precaution
The Digiframe is for indoor use only.
•
To reduce the risk of re or electric shock; do not expose this appliance to rain or moisture.
•
Do not block the ventilation holes on the back of the Digiframe at any time.
•
Keep your Digiframe out of sunlight. Direct sunlight may cause damage.
•
•
Do not open the case of the Digiframe. There is a risk of electric shock, and there are no user serviceable parts
inside. Opening the case will void your warranty.
Do not use the Digiframe if conditions could allow condensation to occur, or damage may result.
•
Your Digiframe is a complicated electronic device and cannot withstand shock from drops.
•
Cleaning the LCD screen
Treat the screen gently. The screen on the Digiframe is protected with glass and can be scratched or broken.
•
•
If ngerprints or dust make the LCD screen dirty, we recommend using a soft, non-abrasive cloth such as a camera lens
cleaning cloth to clean the LCD screen.
•
If you use an LCD Cleaning Kit sold on the market, apply the cleaning liquid to the cloth. Do not apply the liquid directly to
your LCD screen.
We hope you enjoy your
Digiframe!
28.
Bringing memories to life!
For additional hints & tips - visit us at www.digiframe.com.au
For Repairs & Service please contact CUSTOMER SERVICE on 1300 559 881
or email support@digiframe.com.au
Loading...
