Preface
Thank you for placing your trust in this devolo product!
The dLAN 200 AVpro i is a network device that uses power and coaxial cables
which have already been installed in order to provide data communication for
applications such as HDTV streaming, Internet telephony, and fast Internet con
nection. Once it has been installed successfully, the dLAN network behaves like
a conventional LAN. The dLAN
200 Mbps and provides a powerful encryption function with maximum data
security.
About this manual
In this manual, you will learn everything you need to know about your devolo
dLAN
200 AVpro i. You will be shown how to start and configure the
dLAN
200 AV device. In addition, the chapter 'All about the network' contains
practical examples of the use of the dLAN 200 AVpro i.
This documentation was compiled by several members of our staff from a variety
of departments in order to ensure you the best possible support when using your
product.
For further information, please visit www.devolo.com
Our online services (www.devolo.com) are available to you around the clock
should you have any queries or require any further support.
200 AVpro i supports a network speed of up to
-
devolo dLAN 200 AVpro i
|
|
Page 4
|
Package contents
Please ensure that the delivery is complete before beginning with the installation
of your dLAN
dLAN 200 AVpro i
Network cable
Ethernet cable
Coaxial cable
Coaxial adapter
Printed information leaflet
CD containing software and online documentation
devolo AG reserves the right to change the package contents without prior
notice.
Description of the symbols
Here we briefly describe the meaning of the symbols used in this manual.
200 AVpro i:
Very important notice which, if ignored, may lead to damage.
Important notice which should be heeded.
Additional information which is useful to know, but not vital.
devolo dLAN 200 AVpro i
|
|
Page 5
|
Content
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.1 What exactly is dLAN?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.2 What does the dLAN 200 AVpro i have to offer? . . . . . . . . . . . . . 7
2 Connection and Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.1 System requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.2 Connection and display elements . . . . . . . . . . . . . . . . . . . . . . . 10
2.3 Connecting the dLAN 200 AVpro i. . . . . . . . . . . . . . . . . . . . . . . 12
3 devolo dLAN 200 AV software . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.1 Overview of the devolo software . . . . . . . . . . . . . . . . . . . . . . . . 13
3.1.1 devolo dLAN Configuration Wizard . . . . . . . . . . . . . . . 13
3.1.2 devolo Informer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.1.3 devolo EasyShare . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.1.4 devolo EasyClean . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.2 Install the dLAN 200 AV software . . . . . . . . . . . . . . . . . . . . . . . 14
3.3 Configuring the dLAN 200 AV network with the devolo dLAN Confi-
guration Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.4 Overview of the dLAN with the devolo Informer . . . . . . . . . . . . . 16
3.5 Communication in the network using
devolo EasyShare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.5.1 Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.6 Maintain your privacy with devolo EasyClean. . . . . . . . . . . . . . . 20
4 All about the network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.1 Networking and Internet access . . . . . . . . . . . . . . . . . . . . . . . . 22
4.2 Networking a building. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.2.1 Example of networking in a hotel . . . . . . . . . . . . . . . . 23
4.2.2 Example of networking in a hospital . . . . . . . . . . . . . . 24
4.3 Use of coaxial filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
5 Appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
5.1 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
5.2 Important safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
5.3 CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
5.4 Declaration of conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
5.5 Warranty conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
6 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
devolo dLAN 200 AVpro i
|
|
Page 6
Introduction
6
|
1 Introduction
In this chapter, we will provide an overview of the dLAN technology and introduce the dLAN 200 AVpro i briefly.
1.1 What exactly is dLAN?
There is now an exciting new alternative to the familiar cable-based and wireless
technologies, LAN and Wireless LAN: dLAN (direct Local Area Network, i.e. net
worked directly). dLAN uses power or coaxial cables that have already been
installed to enable data communication.
Cost factor and transmission quality
dLAN is an economical and easy-to-use networking technology. Cables no
longer need to be installed, and any socket or coaxial cable outlet can be used
to connect to the network.
With dLAN, additional frequencies are modulated on the power and coaxial circuits. Modulation and demodulation is a well-known and proven method of
data transmission, which has been in use in other applications for a number of
years. Depending on the properties of the circuit and the damping factor, dis
tances of 200 meters can be spanned with the power circuit; over 750 meters is
possible over the coaxial circuit.
In order to transmit data over the power supply grid or the coaxial network, the
dLAN
200 AVpro i is used in conjunction with Standard HomePlug AV. HomePlug AV uses the domestic power or coaxial infrastructure to transmit data,
audio and video in just the same way as the proven HomePlug 1.0 technology.
But HomePlug AV is much faster: with a transmission rate of 200 Mbps and its
"Quality of Service: functions, HomePlug AV technology is ideal for Triple-Play
services, and is thus entirely capable of handling the enormous range of new
online entertainment options.
HomePlug AV and HomePlug 1.0 can be operated together on the same power
network. Data can be exchanged between HomePlug 1.0 networks and HomePlug AV networks via a bridge. One HomePlug 1.0 adapter and one HomePlug
AV adapter simply have to be plugged into adjacent sockets and connected
directly with an Ethernet cable.
-
-
devolo dLAN 200 AVpro i
|
|
Page 7
Introduction
|
Data security and radiation
The dLAN 200 AV devices are protected with 128-bit AES encryption (Advanced
Encryption Standard). This procedure represents reliable protection for your
dLAN network against unauthorized access.
dLAN devices from devolo meet the stringent EU industrial standards and comply with the current standards for electromagnetic radiation.
1.2 What does the dLAN 200 AVpro i have to offer?
Powerful and flexible
The dLAN 200 AVpro i offers a transfer rate of up to 200 Mbps which makes it
ideal for the high requirements of applications, such as HDTV streaming,
Internet telephony and fast Internet.
In particular, the use of dLAN 200 AVpro i offers the following applications and
advantages:
Connection of computers and other network devices to a dLAN network via
power or coaxial circuits
Shared use of network resources
Files and applications
Peripherals such as printers, etc.
Centralized Internet access
Sufficient bandwidth for high-requirement applications such as data, audio,
and video
Provision of digital services such as Internet telephony (Voice over IP – VoIP)
to many points in the building
Integration of multimedia devices such as set-top boxes etc. in the dLAN
network
Reduced requirement for long network cables
Ethernet port with Auto MDI/X for automatic detection of network speed
and contact seizure
Powerful, 128-bit AES encryption to protect transmitted data from unautho-
rized access
Transmission of data over greater distances (200 meters in the power supply
grid, 750 meters or more in the coaxial network)
Cost-effective, reliable solution for "high-speed" communication
7
devolo dLAN 200 AVpro i
|
|
Page 8
8
Introduction
|
Application examples of possible networks can be found in chapter 'All about
the network'.
Simple installation
Connect the dLAN 200 AVpro i to the computer or the network device using
the Ethernet cable provided.
Connect the dLAN 200 AVpro i to the power supply grid using the power
adapter cable provided.
In order to use the power supply grid as the transmission medium:
Set the switch to "Hybrid".
To use the coaxial network as the transmission medium:
Connect the dLAN 200 AVpro i to the coaxial connector with the coaxial
cable provided for this purpose. Set the switch to "Coax".
Install the dLAN 200 AV software for assigning a password.
That's it!
Connections and status displays
The dLAN 200 AVpro i is equipped with an Ethernet port for connection to a
network device and with a coaxial port for connection to a coaxial socket.
The 5 control lamps (LEDs) of your dLAN 200 AVpro i display the connection
status and provide status regarding the function of the data transmission.
devolo dLAN 200 AVpro i
|
|
Page 9
|
2 Connection and Startup
This chapter covers the connectors and display elements of your
dLAN
200 AVpro i and explains how to connect the device.
2.1 System requirements
Operating systems: Windows 2000, Windows XP, Linux, Mac OS X and any
other operating system with TCP/IP support
Ethernet connection
Please note that your computer or other device must feature a network adapter
with an Ethernet port.
To set up a dLAN 200 AVpro i network, you need at least two dLAN 200 AVpro i
devices.
dLAN 200 AVpro i type devices are based on the HomePlug AV standard and
cannot be used in a shared network with adapters, which are based on another
standard than HomePlug. The different encoding methods are not compatible
and cannot occupy the same infrastructure, i.e., if they are operated together on
power and/or coaxial circuits, they interfere with each other, influencing trans
mission of data by either system.
Connection and Startup
9
-
devolo dLAN 200 AVpro i
|
|
Page 10
Connection and Startup
10
|
2.2 Connection and display elements
The dLAN 200 AVpro i features 5 control LEDs as well as an Ethernet, coaxial,
and a power connection:
Power Lit steady when the dLAN 200 AVp ro i is ready for operation;
dLAN Link/Act Lit steady when a connection with the dLAN 200 AVpro i net-
ETH 100/Act Lit steady when a 100 Mbps connection to the Ethernet net-
ETH 10/Act Lit steady when a 10 Mbps connection to the Ethernet network
ETH Col Flashes at a faster rate if the network is experiencing increasing
flashes when the dLAN 200 AVp ro i is in Power Save mode.
work exists; flashes when data is being sent or received via the
power or coaxial circuits.
work exists; flashes when data is being transmitted.
exists; flashes when data is being transmitted.
use.
devolo dLAN 200 AVpro i
|
|
Page 11
Connection and Startup
|
11
ETH This is the connection point on the dLAN 200 AVpro i for con-
Coax Here you connect the dLAN 200 AVpro i to the coaxial connec-
Coax/Hybrid The switch must have been set to "Hybrid" to allow transmis-
AC Here you connect the dLAN 200 AVpro i to the power supply
necting it to a computer or another network device with the
network cable (included).
The Auto-MDI(X) interface in the dLAN 200 AVp ro i automatically detects when a contact is seized and determines the transmission rate of the connected network device.
tor using the coaxial cable supplied.
sion across the power supply grid.
The switch must have been set to "Coax" to allow transmission
across the coaxial network.
using the power cable (included).
If no device that is switched on (e.g. computer) is connected to the Ethernet port,
the dLAN 200 AVpro i switches to Power Save mode after about 20 minutes
(Power LED flashes). In Power Save mode, the dLAN
200 AVpro i cannot be
accessed via the power supply grid or the coaxial network. As soon as the device
that is connected to the Ethernet port is switched on again, your
dLAN
200 AVpro i is available again via the power supply grid or the coaxial
network.
devolo dLAN 200 AVpro i
|
|
Page 12
Connection and Startup
12
|
2.3 Connecting the dLAN 200 AVpro i
In this section, we will show you how to connect and start the
dLAN
200 AVpro i.
햲 Use the included AC adapter cable to connect the dLAN 200 AVpro i to a
power supply grid.
햳 Use the supplied Ethernet cable to connect the dLAN 200 AVpro i to the
Ethernet connector on the computer that is switched on.
햴 Select the transmission medium:
To use the power supply grid as the transmission medium:
The switch on the back of the device must have been set to "Hybrid" to
allow transmission across the power supply grid.
To use the coaxial network as the transmission medium:
Connect the dLAN 200 AVpro i to the coaxial connector with the coaxial
cable provided for this purpose.
The switch on the back of the device must have been set to "Coax" to
allow transmission across the coaxial network.
햵 Continue with the installation of the devolo dLAN 200 AVpro i software. For
more information, refer to the chapter on '
devolo dLAN 200 AV software'.
No drivers are required for running the dLAN 200 AVpro i.
devolo dLAN 200 AVpro i
|
|
Page 13
devolo dLAN 200 AV software
|
3 devolo dLAN 200 AV software
In this chapter, we introduce the devolo software package, including dLAN Configuration Wizard, Informer, EasyShare and EasyClean. We will also provide
instructions for installing the software and configuring your dLAN
network with the help of the dLAN Configuration Wizard.
3.1 Overview of the devolo software
3.1.1 devolo dLAN Configuration Wizard
The dLAN Configuration Wizard is designed to assist you in setting up and modifying your encrypted dLAN 200 AVpro i network. With its help, you can add the
desired dLAN
devices that are on the network can be configured from one central location, i.e.
your workstation. For the encryption, you need the dLAN
IDs (see the bottom of the devices) and assign the network identifier chosen by
you.
The default identifier set by devolo is HomePlugAV (note upper and lower
cases).
200 AVpro i adapters to your network. All dLAN 200 AVpro i
200 AVpro i Security
13
200 AVpro i
3.1.2 devolo Informer
The Informer displays information about all the dLAN 200 AVpro i devices in
your network, such as their MAC addresses and current connection rates.
Only when data is transmitted via the dLAN 200 AVpro i, the connection rates
are displayed in the Informer
The MAC address (Media Access Control) is a serial number, and is unique for
each device. It is hard-coded in each device and cannot be altered. You can find
the MAC address on the bottom of the device.
3.1.3 devolo EasyShare
EasyShare is a file sharing and chat software package for your local network. It
enables the simple exchange of files between local Windows computers. In
addition, the integrated Chat function enables all network subscribers to com
municate directly. EasyShare is extremely user-friendly and easy to operate.
devolo dLAN 200 AVpro i
|
-
|
Page 14
devolo dLAN 200 AV software
14
|
3.1.4 devolo EasyClean
Microsoft Internet Explorer stores files in a cache on your hard drive while you
surf the Internet. With EasyClean, you can determine which of these unwanted
files you would like to delete.
3.2 Install the dLAN 200 AV software
햲 Insert the provided devolo product CD into the CD-ROM drive.
햳 Select 'Install dLAN 200 AV'. Windows launches the wizard. Then, click
Next.
햴 Select 'Standard Installation' to install the complete devolo dLAN 200 AV
software package. Then, click Next.
If you would like to choose the software components to be installed yourself,
select 'Custom Installation'. Then, click Next.
햵 Complete and exit the installation by clicking Finish.
Windows may prompt you to restart your computer once the installation is complete.
햶 When you have successfully completed the installation, select Start Pro-
grams devolo dLAN Configuration Wizard, EasyClean, EasyShare
and Informer to run the software.
3.3 Configuring the dLAN 200 AV network with the devolo dLAN Configuration Wizard
Make sure that the Security IDs for the dLAN 200 AVpro i devices you noted earlier are available for reference. The dLAN Configuration Wizard needs these in
order to configure the network. You can find the Security ID on the bottom of
the device.
햲 Run the dLAN Configuration Wizard by selecting Start Programs
devolo dLAN Configuration Wizard.
햳 Confirm your choice by clicking Next. The dLAN Configuration Wizard will
start the network analysis and will search your network for
dLAN
200 AVpro i devices.
devolo dLAN 200 AVpro i
|
|
Page 15
devolo dLAN 200 AV software
|
15
If a device that has been switched off (e.g. a computer) is connected to the Ethernet port, a dLAN 200 AVpro i device switches to Power Save mode after about
20 minutes. In Power Save mode, the dLAN
200 AVpro i device cannot be
accessed via the power supply grid or the coaxial network. As soon as the device
that is connected to the Ethernet port is switched on again, your
dLAN
200 AVpro i is available again via the power grid or the coaxial network.
햴 In the following dialog box, select a shared identifier for your
dLAN
200 AVpro i network, and click Next to confirm.
The default identifier set by devolo is HomePlugAV (note upper and lower
cases).
햵 The dLAN 200 AVpro i that is connected directly to your computer will be
found automatically. All other dLAN
ually. To do this, enter the Security IDs of the dLAN 200 AVpro is that are to
be combined in a network one after the other, and click on Add. Click Next
to confirm when you have entered all the dLAN
add.
200 AVpro is must be registered man-
200 AVpro is you wish to
햶 To exit the Security setup for your network, click on Finish. All the
dLAN
200 AVpro i adapters that are entered in the list will receive the same
ID. All dLAN
among themselves. Adapters that have been installed on the same power
supply grid or coaxial network, but which use different IDs, cannot commu
200 AVpro i adapters that have the same ID can exchange data
devolo dLAN 200 AVpro i
|
|
-
Page 16
devolo dLAN 200 AV software
16
nicate with each other. This assignment of IDs thus protects your
dLAN
|
200 AV network from unauthorized access.
The configuration of the dLAN 200 AVpro i network can be changed or
upgraded at any time. To do this, simply repeat the steps for configurating as
described above.
3.4 Overview of the dLAN with the devolo Informer
With the Informer you can maintain a constant watch over all dLAN 200 AVpro i
devices in your dLAN
dLAN
200 AVpro i device that is connected directly to the computer and also all
dLAN
200 AV devices that belong to the same dLAN 200 AVpro i network and
can be accessed across it.
200 AV network. The Informer shows the
For example, the Informer shows the dLAN MAC address and the current connection data rate for each individual dLAN 200 AVpro i device. You can change
the name of the marked device with the command Device Rename.
Right-clicking on one of the dLAN 200 AVpro i devices opens a context menu
that contains the following commands:
'Rename' opens a dialog box in which you can assign a new name to the
'Launch dLAN configuration wizard' opens a dialog box in which new
The Informer only shows those dLAN 200 AVpro i devices that are connected to
the power grid or the coaxial network and have been added to your
devolo dLAN 200 AVpro i
|
device.
dLAN
200 AVpro i devices can be added to the dLAN 200 AVpro i network;
the network ID is also assigned in this dialog.
|
Page 17
devolo dLAN 200 AV software
|
dLAN 200 AVpro i network. If a device (e.g. computer) that is connected to the
Ethernet port has been switched off, the dLAN device switches to Power Save
mode after about 20 minutes. dLAN
mode do not appear in the Informer. As soon as the device (e.g. computer) that
is connected to the Ethernet port is switched on again, your dLAN
device can be reached via the power grid or the coaxial network again, and it is
displayed in the Informer.
200 AVpro i devices that are in Power Save
17
200 AVpro i
devolo dLAN 200 AVpro i
|
|
Page 18
devolo dLAN 200 AV software
18
|
3.5 Communication in the network using devolo EasyShare
All users on the local network who have started EasyShare are automatically recognized by the program and listed:
3.5.1 Configuration
The EasyShare software provides two easy wizards, which will guide you quickly
and easily through the configuration process: the first setup wizard, which starts
automatically the first time the program is started, and the sharing wizard,
which allows you to add shared items at any time. The individual functions of
the EasyShare software are described here:
Folder sharing
To share data with others, a EasyShare network user has to make the data available in a shared folder. When a folder is shared, all of its files as well as the files
of all its subdirectories become available to all users on the EasyShare network.
Folders can be shared either by using the initial setup wizard, which opens auto
matically the first time the EasyShare is started, or by using the sharing wizard.
You can open the shar
ing File Add share from the menu.
devolo dLAN 200 AVpro i
|
|
-
ing wizard by clicking the Add share button, or by select-
Page 19
devolo dLAN 200 AV software
|
Options
Every computer has a name. When EasyShare is first installed, you can assign a
new name to your computer or use the default name suggested by the operating
system. Your computer is visible by this name to all EasyShare users.
The computer name can be changed at any time by clicking the Options button
or by selecting Tools Options from the menu.
Refreshing shared folders
To view (newly) shared folders of other EasyShare network users, select File
Refresh from the menu, or Refresh from the context menu (right mouse button).
The contents of all shared folders will appear in the top right-hand window.
Downloading files
To download shared files from other EasyShare network users, select the computer belonging to the user and then mark the shared folder for that user. The
upper-right window then lists all the contents of the folder. From the list, mark
the files and/or folders that you want to download and then select File
Download from the menu, or Download from the context menu (right mouse
button). Choose a target folder on your computer and confirm by clicking OK.
The files are now downloaded to your computer. The status of the download is
displayed in the lower-right window entitled 'Data transfer in process'.
19
Data transfer in process
All 'Data transfer in process' are displayed in the lower right window and disappear from the screen once they are finished.
The 'Name' column indicates the name of the file being downloaded.
The 'Status' column shows the current transfer progress and the transfer
speed.
The 'Host' column shows the computer from which the file is being down-
loaded, or to which it is being uploaded from your computer.
You can cancel the current download by clicking the file and selecting Cancel
from the context menu (right mouse button).
Chatting
The lower left window functions as a chat room, which is visible and accessible
to all EasyShare users on the local network. Users can "chat" by writing mes
sages and clicking Send.
devolo dLAN 200 AVpro i
|
|
-
Page 20
devolo dLAN 200 AV software
20
|
3.6 Maintain your privacy with devolo EasyClean
With EasyClean, you can delete the cached files listed below. Select the checkboxes of the file types you would like to remove, then click Delete.
Cookies—Many websites store small files on your computer, so-called
Temporary Internet files—Temporary files are stored on your hard drive
History files—Internet Explorer records your surfing activity over a period
Stored form information—Internet Explorer stores information that you
devolo dLAN 200 AVpro i
|
cookies. These files may contain personal information such as log-in data,
passwords or credit card numbers.
while you surf the Net. Over time, these files take up a considerable amount
of space.
of days or weeks. This can be practical, but it also takes up space and can
be undesirable in many cases.
enter in forms and can auto-complete this information in the future.
|
Page 21
devolo dLAN 200 AV software
|
Stored passwords—Passwords can also be stored and automatically
inserted together with usernames in subsequent log-in procedures. While
this is convenient, it's also dangerous—especially in connection with bank
transactions. Sensitive information such as this should only be stored locally
in special programs designed for this purpose.
Document history—Internet Explorer maintains lists of open documents
and visited websites. This information is generally no longer needed.
21
Please note that EasyClean only supports Microsoft Internet Explorer.
devolo dLAN 200 AVpro i
|
|
Page 22
All about the network
Coax
Hybrid
Coax
Hybrid
Coax
Hybrid
Coax
Hybrid
Coax
Hybrid
Coax
Hybrid
Coax
Hybrid
Coax
Hybrid
Coax
Hybrid
Coax
Hybrid
22
|
4 All about the network
This chapter presents networking options that will illustrate the advantages of
dLAN
200 AVpro i devices.
The dLAN 200 AVpro i adapters transmit in the frequency band between 2 and
28 MHz. If the adapters are being operated in a coaxial network that is not
exclusively available for data transmission by dLAN
check must be made to determine whether existing television transmission fre
quencies experience interference. If interference does occur, please refer to the
section
“Use of coaxial filters” on page 24.
4.1 Networking and Internet access
dLAN 200 AVpro i adapters are used to connect network devices such as computers, routers, switches, IP telephones, set-top boxes etc. in a network using
the existing power and coaxial cables.
Data transmission over power supply grid
200 AVpro i adapters, a
-
MODEM
ROUTER
H
T
E
l
H
o
T
C
E
t
c
A
/
H
0
T
1
E
t
c
A
/
0
0
1
N
A
L
d
t
c
A
/
k
in
L
r
e
w
o
P
i
o
r
p
V
A
0
0
2
N
A
L
d
H
T
E
l
H
o
T
C
E
t
c
A
/
H
0
T
1
E
t
c
A
/
0
0
1
N
A
L
d
t
c
A
/
k
in
L
r
e
w
o
P
i
o
r
p
V
A
0
0
2
N
A
L
d
ITCH
SW
SWITCH
H
T
E
l
H
o
T
C
E
t
c
A
/
H
0
T
1
E
t
c
A
/
0
0
1
N
A
L
d
t
c
A
/
k
in
L
r
e
w
o
P
i
o
r
p
V
A
0
0
2
N
A
L
d
Data transmission over power and coaxial
network (hybrid)
o
i
d
a
R
V
T
H
T
E
l
o
H
T
C
E
t
c
A
/
H
0
T
1
E
t
c
A
/
0
0
1
N
A
L
d
ct
A
/
k
n
i
L
r
e
w
o
P
i
200 AV pro
AN
dL
H
T
E
l
o
H
T
C
E
t
c
A
/
H
0
T
1
E
t
c
A
/
0
0
1
N
A
L
d
t
c
A
/
k
in
L
r
e
w
o
P
i
ro
V p
A
200
dLAN
SWITCH
H
T
E
l
o
H
T
C
E
t
c
A
/
H
0
T
1
E
t
c
A
/
0
0
1
N
A
L
d
t
c
A
/
k
n
i
L
r
e
w
o
P
0 AV pro i
20
LAN
d
MODEM
ROUTER
o
i
d
a
R
V
T
H
T
E
l
o
H
T
C
E
t
c
A
/
H
0
T
1
E
ct
A
/
0
0
1
N
A
L
d
t
c
A
/
k
n
i
L
r
e
w
o
P
0 AV pro i
20
dLAN
4.2 Networking a building
dLAN 200 AVpro i devices are able to make flexible use of the circuits that are
already present in the rooms. The dLAN
network subscribers over both circuit types even if the conditions within the
devolo dLAN 200 AVpro i
|
|
Data transmission over coaxial network
MODEM
ROUTER
o
i
d
a
R
V
T
H
T
E
t
c
A
/
0
0
1
N
A
L
d
t
c
A
/
k
n
i
L
r
e
w
o
P
i
o
r
p
V
A
0
0
2
N
A
L
d
o
i
d
a
R
V
T
H
T
E
l
H
o
T
C
E
t
c
A
/
0
1
H
T
E
l
H
o
T
C
E
t
c
A
/
H
0
T
1
E
t
c
A
/
0
0
1
N
A
L
d
t
c
A
/
k
n
i
L
r
e
w
o
P
i
o
r
p
V
A
0
0
2
N
A
L
d
SWITCH
200 AVpro i devices can connect all
V
T
SWITCH
o
i
d
a
R
H
T
E
l
H
o
T
C
E
t
c
A
/
H
0
T
1
E
t
c
A
/
0
0
1
N
A
L
d
t
c
A
/
k
in
L
r
e
w
o
P
i
o
r
p
V
A
0
0
2
N
A
L
d
Page 23
All about the network
Coax
Hybrid
Coax
Hybrid
Coax
Hybrid
Coax
Hybrid
Coax
Hybrid
Coax
Hybrid
Coax
Hybrid
|
building change, and for example provide central Internet access to all connected network devices.
H
T
E
l
o
H
T
C
E
t
c
A
/
H
0
T
1
E
t
c
A
/
0
0
N
1
A
L
t
d
c
A
/
k
n
i
L
r
e
w
o
P
ro i
p
V
A
0
20
N
A
L
d
io
d
a
R
V
T
io
d
a
R
V
T
io
d
a
R
V
T
23
H
T
E
l
o
H
T
C
E
t
c
A
/
H
0
T
1
E
t
c
A
/
0
0
N
1
A
L
t
d
c
A
/
k
n
i
L
r
e
w
o
P
i
o
r
p
V
A
0
0
2
N
A
dL
H
T
E
l
o
H
T
C
E
t
c
A
/
H
0
T
1
E
t
c
A
/
0
0
N
1
A
L
t
d
c
A
/
k
n
i
L
r
e
w
o
P
i
ro
p
V
A
0
0
2
N
A
dL
Apartement 3
io
d
a
R
TV
io
d
a
R
V
T
H
T
E
l
o
H
T
C
E
t
c
A
/
H
0
T
1
E
t
c
A
/
0
0
N
1
A
L
t
d
c
A
/
k
n
i
L
r
e
w
o
P
i
ro
p
V
A
0
0
2
N
LA
d
io
d
a
R
TV
io
d
a
R
TV
Apartement 1
io
d
a
R
V
T
A repeater, consisting of two adapters, can be set up so that both circuit types
– power circuit and coaxial circuit – can be used in a data network. To do this,
one dLAN
one dLAN
200 AVpro i adapter for transmitting data over the power circuit, and
200 AVpro i adapter for transmitting over the coaxial circuit are con-
nected directly via an Ethernet cable (see Figure Apartment 3).
4.2.1 Example of networking in a hotel
H
T
E
l
o
H
T
C
E
t
c
A
/
H
0
T
1
E
t
c
A
/
0
0
N
1
A
L
t
d
c
A
/
k
n
i
L
r
e
w
o
P
i
o
r
p
V
A
0
0
2
N
A
dL
Apartement 4
H
T
E
l
o
H
T
C
E
t
c
A
/
H
0
T
1
E
t
c
A
/
0
0
N
1
A
L
t
d
c
A
/
k
n
i
L
r
e
w
o
P
i
ro
p
V
A
0
0
2
N
A
L
d
Apartement 2
Basement
MODEM
ROUTER
H
T
E
l
o
H
T
C
E
t
c
A
/
H
0
T
1
E
t
c
A
/
0
0
N
1
A
L
t
d
c
A
/
k
n
i
L
r
e
w
o
P
i
ro
p
V
A
0
0
2
N
A
L
d
Internet access is becoming increasingly important even for hotel guests – particularly for those traveling on business who want to review their e-mail or distribute presentations in the evening. It has long been commonplace for hotels
to provide televisions in each room, so all the hotel rooms that are of concern
are generally equipped with coaxial connections already. By using the
dLAN
200 AVpro i devices, fast Internet connections can be offered as well as
television in all these rooms with very little effort.
devolo dLAN 200 AVpro i
|
|
Page 24
All about the network
24
|
4.2.2 Example of networking in a hospital
Just as in the hotels, it is becoming more and more important to provide fast
Internet access in hospitals as well, both for the staff and the patients. Since
hospitals also tend to be well served with extensive systems of coaxial circuits,
the dLAN
ing wards, treatment rooms, and the Administrative department for example,
without the need to install completely new network circuits. The enormous
ranges that are possible with coaxial circuits mean that connections can easily
be extended even to include separate buildings, as is often the case with hospi
tals.
200 AVpro i devices can be used to provide more options for network-
4.3 Use of coaxial filters
The transmission frequency of the wanted signal across coaxial circuits is
between 2 and 28 MHz. It can happen that interference is emitted above this
frequency range, which may interfere with the wanted signals of other applica
tions. In this case, it is advisable to use a filter.
It is recommended to use a filter to decouple the dLAN 200 AVpro i signals from
the transfer point of the TV signal. The filter can be accquired from devolo. A fil
ter should be used
when you want to isolate your dLAN 200 AVpro i network from the rest of
the coax infrastructure, or to prevent the dLAN
interfering with other devices that are not included in your network.
when you want to shield your dLAN 200 AVpro i network from interference
by other transmissions in the same frequency range.
when you want to protect your dLAN 200 AVpro i network from interference
by a Docsis modem (or other cable modem)
between the cable modem and the dLAN
For more answers to frequently asked questions (FAQs), please visit our website
at www.devolo.com.
200 AVpro i network.
-
-
-
200 AVpro i signal from
In this case, install a filter
devolo dLAN 200 AVpro i
|
|
Page 25
5 Appendix
5.1 Technical data
dLAN 200 AVpro i
Appendix
|
25
Standards Ethernet specification IEEE 802.3, IEEE 802.3x, IEEE 802.3u
Protocols CSMA/CA, TDMA
Transmission speed up to 200 Mbps
Encoding Asynchronous
Modulation OFDM – 1155 carriers, 1024/256/64- QAM, QPSK, BPSK
Data path Ethernet <-> Power supply grid
Range 200m over the power supply grid
Security 128-bit AES encryption over the power supply grid and the
LEDs Power
dLAN port Euro plug, coaxial connector
Computer port RJ45
Power consumption Max. 5.5 W
Power supply AC 100 – 240 V, 50/60 Hz
Ambient conditions Humidity (non-condensing): 10 - 90%
System requirements Ethernet interface
Operating systems Windows 2000, Windows XP, Linux, Mac OS X and any other
CE conformity CE conformity in accordance with the technical requirements
Construction Plastic; 170 x 107 x 40 mm (Width x Depth x Height)
Warranty 3 years
Auto MDI(X)
HomePlug AV
Ethernet <-> Coaxial network
750m over the coaxial network
coaxial network
dLAN Link/Act
Ethernet 10/Act
Ethernet 100/Act
Ethernet Colision
operating system with TCP/IP support
for all EU countries and Switzerland
devolo dLAN 200 AVpro i
|
|
Page 26
Appendix
26
|
5.2 Important safety instructions
It is essential to have read and understood all safety and operating instructions
before the device is used for the first time; these should then be kept safely for
future reference.
Do not open the dLAN 200 AVpro i. There are no user-serviceable parts
inside the dLAN
Do not attempt to service the product yourself, call on qualified technicians for
assistance with all service tasks! There is a danger of electric shock!
Use the dLAN 200 AVpro i only in a dry location.
Do not insert any objects in the openings in the dLAN 200 AVpro i.
To disconnect the dLAN 200 AVpro i from the power supply grid, pull out
the plug.
Do not expose the dLAN 200 AVpro i to direct sunlight.
Slits and apertures in the case are intended to provide ventilation and must
not be blocked or covered.
The dLAN 200 AVpro i must not be set up in close proximity to a radiator.
The dLAN 200 AVpro i should only be set up in locations where adequate
ventilation is assured in accordance with the manufacturer's instructions.
Disconnect the dLAN 200 AVpro i from the power supply grid before clean-
ing. Never use water, paint thinner, benzene, alcohol or other strong cleaning agents when cleaning the device, as these could damage the case. Only
use a slightly moist soft cloth.
The dLAN 200 AVpro i should be operated exclusively on a public power
supply as described on the rating plate. If you are not sure which kind of
power supply you have at home, contact your dealer or your utility company.
If the equipment is damaged, disconnect the dLAN 200 AVpro i from the
mains and contact your after-sales service representative. Damage is
deemed to have occurred
if the power cable or plug is damaged
if the dLAN 200 AVpro i is sprayed with liquid or if objects have got
inside the device
if the dLAN 200 AVpro i has been exposed to rain or water
if the dLAN 200 AVpro i does not work, despite the fact that all operat-
ing instructions have been followed properly
if the case of the dLAN 200 AVpro i has been damaged.
200 AVpro i.
devolo dLAN 200 AVpro i
|
|
Page 27
5.3 CE conformity
The product conforms to the basic requirements of Directive 1999/5/EC (R&TTE)
and the other relevant provisions of the FTEG (Radio and Telecommunications
Terminal Equipment Act), and is designed for use in the EU and Switzerland.
This product is class A equipment. This equipment may cause interference with
radio waves in home use; if this occurs the operator may be required to take cor
rective action.
Appendix
|
27
-
devolo dLAN 200 AVpro i
|
|
Page 28
Appendix
28
|
5.4 Declaration of conformity
KONFORMITÄTSERKLÄRUNG
DECLARATION OF CONFORMITY
Hersteller: devolo AG
Manufacturer: Sonnenweg 11
52070 Aachen
®®®®
Produkt: devolo dLAN
Product:
Typnummer: MT2077
Type number:
Verwendungszweck: PLC, Coax zu Ethernet Adapter
Intended purpose: PLC, Coax to Ethernet Adapter
Richtlinie: 1999/5/EG (R&TTE)
Directive: 1999/5/EC (R&TTE)
Das Produkt entspricht den grundlegenden Anforderungen und Bestimmungen der
folgenden Normen und Methoden:
The product complies with the essential requirements and provisions of f ollowing standards and methods:
200 AVpro i
Sicherheitsanforderungen: EN 60950-1:2001
Safety requirements:
Immunitätsanforderungen: EN 55024:1998+A1:2001+A2:2003
Immunit y requirements:
Emissionsanforderungen: EN 55022:1998+A1:2000+A2:2003 (Class A)
Emission requirements: und Expert Opinion vom Competent Body EMV
Diese Erklärung wird verantwortlich abgegeben durch:
This declaration is submi tted by:
Aachen, 06. November 2006
Aachen, 6th November 2006 Heiko Harbers
Vorstandsvorsitzender
CEO
devolo dLAN 200 AVpro i
|
and Expert Opinion by Competent Body EMC
|
Page 29
5.5 Warranty conditions
The devolo AG warranty is given to purchasers of devolo products in addition to the warranty conditions provided by law and in accordance with the following conditions:
1 Warranty coverage
a) The warranty covers the equipment delivered and all its parts. Parts will, at devolo's sole dis-
cretion, be replaced or repaired free of charge if, despite proven proper handling and adherence to the operating instructions, these parts became defective due to fabrication and/or
material defects. Alternatively, devolo reserves the right to replace the defective product with
a comparable product with the same specifications and features. Operating manuals and any
supplied software are excluded from the warranty.
b) Material and service charges shall be covered by devolo, but not shipping and handling costs
involved in transport from the buyer to the service station and/or to devolo.
c) Replaced parts become property of devolo.
d) devolo is authorized to carry out technical changes (e.g. firmware updates) beyond repair and
replacement of defective parts in order to bring the equipment up to the current technical state.
This does not result in any additional charge for the customer. A legal claim to this service does
not exist.
2 Warranty period
The warranty period for this devolo product is three years. This period begins at the day of delivery
from the devolo dealer. Warranty services rendered by devolo do not result in an extension of the
warranty period nor do they initiate a new warranty period. The warranty period for installed
replacement parts ends with the warranty period of the device as a whole.
3 Warranty procedure
a) If defects appear during the warranty period, the warranty claims must be made immediately,
at the latest within a period of 7 days.
b) In the case of any externally visible damage arising from transport (e.g. damage to the case),
the person responsible for the transportation and the sender should be informed immediately.
On discovery of damage which is not externally visible, the transport company and devolo are
to be immediately informed in writing, at the latest within 3 days of delivery.
c) Transport to and from the location where the warranty claim is accepted and/or the repaired
device is exchanged, is at the purchaser's own risk and cost.
d) Warranty claims are only valid if a copy of the original purchase receipt is returned with the
device. devolo reserves the right to require the submission of the original purchase receipt.
4 Suspension of the warranty
All warranty claims will be deemed invalid if
a) the label with the serial number has been removed from the device,
b) the device is damaged or destroyed as a result of acts of nature or by environmental influences
(moisture, electric shock, dust, etc.),
c) the device was stored or operated under conditions not in compliance with the technical spec-
ifications,
d) the damage occurred due to incorrect handling, especially due to non-observance of the sys-
tem description and the operating instructions,
e) the device was opened, repaired or modified by persons not authorized by devolo,
f) the device shows any kind of mechanical damage,
g) the warranty claim has not been reported in accordance with 3a) or 3b).
Appendix
|
29
devolo dLAN 200 AVpro i
|
|
Page 30
30
Appendix
|
5Operating mistakes
If it becomes apparent that the reported malfunction of the device has been caused by unsuitable
software, hardware, installation or operation, devolo reserves the right to charge the purchaser for
the resulting testing costs.
6 Additional regulations
a) The above conditions define the complete scope of devolo’s legal liability.
b) The warranty gives no entitlement to additional claims, such as any refund in full or in part.
Compensation claims, regardless of the legal basis, are excluded. This does not apply if e.g.
injury to persons or damage to private property are specifically covered by the product liability
law, or in cases of intentional act or culpable negligence.
c) Claims for compensation of lost profits, indirect or consequential detriments, are excluded.
d) devolo is not liable for lost data or retrieval of lost data in cases of slight and ordinary negli-
gence.
e) In the case that the intentional or culpable negligence of devolo employees has caused a loss
of data, devolo will be liable for those costs typical to the recovery of data where periodic secu-
rity data back-ups have been made.
f) The warranty is valid only for the first purchaser and is not transferable.
g) The court of jurisdiction is located in Aachen, Germany in the case that the purchaser is a mer-
chant. If the purchaser does not have a court of jurisdiction in the Federal Republic of Germany
or if he moves his domicile out of Germany after conclusion of the contract, devolo’s court of
jurisdiction applies. This is also applicable if the purchaser's domicile is not known at the time
of institution of proceedings.
h) The law of the Federal Republic of Germany is applicable. The UN commercial law does not
apply to dealings between devolo and the purchaser.
devolo dLAN 200 AVpro i
|
|
Page 31
6 Troubleshooting
The dLAN 200 AVpro i has been intentionally designed to be as reliable and
easy to operate as possible. This chapter includes a few notes that are designed
to help you locate the possible fault in the event of a malfunction
The Power LED is flashing
햲 The device is in Power Save mode. Check whether the device has an active
Ethernet connection.
The Power LED does not light up
햲 Check that the power cable is connected properly to the power connector
on the device.
햳 Make sure that the device is connected directly to a socket, and that the
socket is live.
햴 Try using a different socket.
The dLAN Link/Act LED does not light up
햲 Make sure that there is not an analog TV amplifier or too many T-splitters
between the dLAN
each other.
200 AVpro i devices that should be communicating with
Troubleshooting
|
31
햳 Try connecting two dLAN 200 AVpro is with a short coaxial cable to carry
out a quick connectivity test.
The Ethernet LED does not light up
햲 Make sure that the dLAN 200 AVpro i is connected to a device with an Eth-
ernet port by an RJ-45 cable, and that both devices are switched on.
Safety instructions
햲 In order to switch the device off completely, pull the power cable out of the
socket.
햳 Never install the devices in a wet location or close to radiators/heat sources.
햴 Never use the device outside.
햵 Do not remove the device case under any circumstances.
devolo dLAN 200 AVpro i
|
|
Loading...
