NATURAL GAS LOG

VENTED DECORATIVE APPLIANCES

OWNER’S OPERATION AND INSTALLATION MANUAL

RGA 2-72

APPROVED

TESTED AND

LISTED BY

WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury, or loss of life.

— Do not store or use gasoline or other flammable

vapors and liquids in the vicinity of this or any other appliance.

— WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electrical switch; do not use any phone in your building.

• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the fire department.

— Installation and service must be performed by

a qualified installer, service agency, or the gas supplier.

RADCO Burner Models CVSR18, CVSR24, CPVSR18, CPVSR24, CVDR18, CVDR24, and CVDR30

WARNING: Improper installation, adjustment, alteration, service, or maintenance can cause injury or property damage. Refer to this manual for correct installation and operational procedures. For assistance or additional information consult a qualified installer, service agency, or the gas supplier.

WARNING: This appliance is for installation only in a solidfuel burning masonry or UL127 factory-built fireplace, constructed of noncombustible material, and connected to a working flue. (See page 7 for minimum flue opening.)

WARNING: This is a gas-fired appliance. It uses air (oxygen) from the room in which it is installed. Provisions for adequate combustion and ventilation air must be provided. Refer to

This appliance may be installed in an aftermarket* manufactured (mobile) home, where not prohibited by state or local codes.

* Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer

Air for Combustion and Ventilation

Save this manual for future reference.

section on page 4 of this manual.

RADCO BURNERS

FOR VENTED NATURAL GAS LOGS

SAFETY INFORMATION

WARNINGS

WARNING ICON G 001

WARNING: Keep flue open

when operating unit.

IMPORTANT: Read this owner’s manual carefully and completely before trying to assemble, operate, or service this log set. Improper use of this log set can cause serious injury or death from burns, fire, explosion, electrical shock, and carbon monoxide poisoning.

DANGER: Carbon monoxide

poisoning may lead to death!

Carbon Monoxide Poisoning: Early

signs of carbon monoxide poisoning resemble the flu, with headaches, dizziness, or nausea. If you have these signs, the log set may not be working properly. Get fresh air at once! Have log set serviced. Some people are more affected by carbon monoxide than others. These include pregnant women, people with heart or lung disease or anemia, those under the influence of alcohol, and those at high altitudes.

Natural Gas: Natural gas is odorless. An odor-making agent is added to the gas. The odor helps you detect a gas leak. However, the odor added to the gas can fade. Gas may be present even though no odor exists.

Make certain you read and understand all Warnings. Keep this manual for reference. It is your guide to safe and proper operation of this log set.

WARNING: Any change to this log set or its controls can be dangerous.

1. This appliance, as supplied, is only for use with the type of gas indicated on the rating plate. This appliance is convertible for use with propane/LP, using the GA9000 or GA9100 pilot kit.

2. If you smell gas

• shut off gas supply

• do not try to light any appliance

• do not touch any electrical switch; do not use any phone in your building

• immediately call your gas supplier from a neighbor’s phone. F ollow the gas supplier’s instructions

• if you cannot reach your gas supplier , call the fire department

3. Never install the log set

• in a recreational vehicle

• where curtains, furniture, clothing, or other flammable objects are less than 42 inches from the front, top, or sides of the log set

• in high traffic areas

• in windy or drafty areas

4. Before installing in a solid fuel burning fireplace, the chimney flue and firebox must be cleaned of soot, creosote, ashes and loose paint by a qualified chimney cleaner. Creosote will ignite if highly heated. Inspect chimney flue for damage.

5. Y ou must operate this log set with a fireplace screen in place. Make sure fireplace screen is closed before running log set.

6. This log set is designed to be smokeless. If logs ever appear to smoke, turn off appliance and call a qualified service person. eration, slight smoking could occur due to log curing and the burning of manufacturing residues. You may wish to add more ventalation by opening a window .

7. To reduce the creation of soot, follow the instructions in Cleaning and Main- tenance, page 20.

8. Do not allow fans to blow directly into the fireplace. Avoid any drafts that alter burner flame patterns. Ceiling fans can create drafts that alter burner flame patterns. Altered burner patterns can increase sooting.

9. Do not use a blower insert, heat exchanger insert or other accessory not approved for use with this log set.

10. This log set needs fresh, outside air ventilation to run properly. See Air for Combustion and Ventilation, pages 4 through 6.

Note:

During initial op-

11. Do not run log set

• where flammable liquids or vapors are used or stored

• under dusty conditions

12. Do not burn solid fuel in the fireplace after installing the log set. Do not use this log set to cook food or burn paper or other objects.

13. Log set becomes v ery hot when in use. Keep children and adults away from hot surface to avoid burns or clothing ignition. Log set will remain hot for a time after shut-down. Allow surface to cool before touching.

14. Carefully supervise young children when they are in the room with log set.

15. Do not use appliance if any part has been exposed to or under water . Immediately call a qualified service technician to inspect the room appliance and to replace any part of the control system (if using GA9000 or GA9100) and any gas control which has been under water.

16. To help prevent breakage, new logs must be broken-in (see Curing logs page 12).

17. Turn log set off and let cool before servicing, installing, or repairing. Only a qualified service person should install, service, or repair log set.

901048

OWNER’S MANUAL

PRODUCT IDENTIFICATION

Grate Steps

Grate

Burner Pan

Burner Clamp

Burner Manifold

Figure 1 - Product Identification (VVDR24 Shown)

Serial Number ________________________________________ Log Set Model ________________________________________

LOCAL CODES

Install and use log set with care. Follow all local codes. In the absence of local codes, use the latest edition of The National Fuel Gas Code ANS Z223.1, also known as NFPA 54*.

*Available from: American National Standards Institute, Inc.

1430 Broadway

New York, NY 10018

National Fire Protection Association, Inc.

Batterymarch Park

Quincy, MA 02269

UNPACKING

CAUTION: Do not remove the metal data plates from the burner pan. The d ata plates contain important product information.

1. Remove logs, hearth kit, pan materials, and hardware from carton.

2. Remove all protective packaging applied to logs and base for shipment.

3. Check all items for any shipping damage. If damaged, promptly inform dealer where you bought the product.

Burner Inlet Fitting

OPTIONAL PRODUCT FEATURES

ON/OFF SAFETY VALVE/ PILOT KIT AND PROPANE/LP CONVERSION

An optional valve/safety pilot kit with a piezo ignitor is available for this appliance. This system requires no matches, batteries, or other sources to light. You must use this optional system for LP conversion. See Ac- cessories, page 20.

REMOTE CONTROL READY (MILLIVOLT) SAFETY VALVE/ PILOT KIT

An optional millivolt valve/safety pilot kit with a piezo ignitor is available for this appliance. This system requires no matches, batteries, or other sources to light. This system may be connected to a wall switch or hand-held wireless remote control. See Ac- cessories, page 20.

REMOTE CONTROL ACCESSORIES

There is an optional hand-held ON/OFF remote control that can be purchased separately for this log set. You must use the millivolt valve/safety pilot kit to use remote accessories with this appliance. See Acces- sories, page 20.

901048

RADCO BURNERS

FOR VENTED NATURAL GAS LOGS

AIR FOR COMBUSTION AND VENTILATION

WARNING: This appliance shall not be installed in a confined space or unusually tight construction unless provisions are provided for adequate combustion and ventilation air. Read the following instructions to insure proper fresh air for this and other fuel-burning appliances in your home.

Today’s homes are built more energy efficient than ever. New materials, increased insulation, and new construction methods help reduce heat loss in homes. Home owners weather strip and caulk around windows and doors to keep the cold air out and the warm air in. During heating months, home owners want their homes as airtight as possible.

While it is good to make your home energy efficient, your home needs to breathe. Fresh air must enter your home. All fuel-burning appliances need fresh air for proper combustion and ventilation.

Exhaust fans, fireplaces, clothes dryers, and fuel burning appliances draw air from the house to operate. You must provide adequate fresh air for these appliances. This will insure proper venting of vented fuelburning appliances.

PROVIDING ADEQUATE VENTILATION

The following are excerpts from National Fuel Gas Code. NFPA 54/ANS Z223.1, Section 5.3, Air for Combustion and Ventilation.

All spaces in homes fall into one of the three following ventilation classifications:

1. Unusually Tight Construction

2. Unconfined Space

3. Confined Space The information on pages 4 through 6 will

help you classify your space and provide adequate ventilation.

Unusually Tight Construction

The air that leaks around doors and windows may provide enough fresh air for combustion and ventilation. However, in buildings of unusually tight construction, you must provide additional fresh air.

Unusually tight construction is defined as construction where:

a. walls and ceilings exposed to the

outside atmosphere have a continuous water vapor retarder with a rating of one perm (6x10 per pa-sec-m2) or less with openings gasketed or sealed

b. weather stripping has been

added on openable windows and doors

c. caulking or sealants are applied

to areas such as joints around window and door frames, between sole plates and floors, between wall-ceiling joints, between wall panels, at penetrations for plumbing, electrical, and gas lines, and at other openings.

If your home meets all of the three criteria above, you must provide additional fresh air. See

From Outdoors

If your home does not meet all of the three criteria above, proceed to

termining Fresh-Air Flow For Log Set Location

and

Ventilation Air

, page 6.

, page 5.

and

-11

De-

Confined and Unconfined Space

The National Fuel Gas Code (ANS Z223.1, 1992 Section 5.3) defines a confined space

as a space whose volume is less than 50 cubic feet per 1,000 Btu per hour (4.8 m3 per kw) of the aggregate input rating of all appliances installed in that space and an unconfined space as a space whose volume is not less than 50 cubic feet per 1,000 Btu per hour (4.8 m3 per kw) of the aggregate input rating of all appliances installed in that space. Rooms communicating directly with the space in which the appliances are installed*, through openings not furnished with doors, are considered a part of the unconfined space.

This log set shall not be installed in a confined space or unusually tight construction unless provisions are provided for adequate combustion and ventilation air.

* Adjoining rooms are communicating only if there are doorless passageways or ventilation grills between them.

901048

OWNER’S MANUAL

AIR FOR COMBUSTION AND VENTILATION

Continued

DETERMINING FRESH-AIR FLOW FOR APPLIANCE LOCATION

Determining if You Have a Confined or Unconfined Space

Use this work sheet to determine if you have a confined or unconfined space. Space: Includes the room in which you will install appliance plus any adjoining rooms with doorless passageways or ventilation grills

between the rooms.

1. Determine the volume of the space (length x width x height). Length x Width x Height = _________________cu. ft. (volume of space)

Example:

If additional ventilation to adjoining room is supplied with grills or openings, add the volume of these rooms to the total volume of the space.

2. Divide the space volume by 50 cubic feet to determine the maximum Btu/Hr the space can support.

_____________ (volume of space) ÷ 50 cu. ft. = (maximum Btu/Hr the space can support)

Example:

3. Add the Btu/Hr of all fuel burning appliances in the space. Gas fireplace logs _____________ Btu/Hr

Gas water heater* _____________ Btu/Hr Gas furnace _____________ Btu/Hr Vented gas heater _____________ Btu/Hr Vent-free heater _____________ Btu/Hr Other gas appliances* + _____________ Btu/Hr Total = _____________ Btu/Hr

* Do not include direct-vent gas appliances. Direct-vent draws combustion air from the outdoors and vents to the outdoors.

4. Compare the maximum Btu/Hr the space can support with the actual amount of Btu/Hr used.

_____________ Btu/Hr (maximum the space can support) _____________ Btu/Hr (actual amount of Btu/Hr used)

Example:

The space in the above example is a confined space because the actual Btu/Hr used is more than the maximum Btu/Hr the space can support. You must provide additional fresh air. Your options are as follows:

A. Rework worksheet, adding the space of an adjoining room. If the extra space provides an unconfined space, remove door to adjoin-

ing room or add ventilation grills between rooms. See Ventilation Air From Inside Building, page 6.

B. Vent room directly to the outdoors. See Ventilation Air From Outdoors, page 6. C. Install a lower Btu/Hr heater, if lower Btu/Hr size makes room unconfined.

If the actual Btu/Hr used is less than the maximum Btu/Hr the space can support, the space is an unconfined space. You will need no additional fresh air ventilation.

Space size 20 ft. (length) x 16 ft. (width) x 8 ft. (ceiling height) = 2560 cu. ft. (volume of space)

2560 cu. ft. (volume of space) ÷ 50 cu. ft. = 51.2 or 51,200 (maximum Btu/Hr the space can support)

Example:

Gas water heater 40,000 Btu/Hr Gas fireplace logs + 55,000 Btu/Hr Total = 95,000 Btu/Hr

51,200 Btu/Hr (maximum the space can support) 95,000 Btu/Hr (actual amount of Btu/Hr used)

WARNING: If the area in which the appliance may be operated is smaller than that defined as an unconfined space or if the building is of unusually tight construction, provide adequate combustion and ventilation air by one of the methods described in the

901048

National Fuel Gas Code, ANS Z223.1, 1992, Section 5.3

or applicable local codes.

Continued

RADCO BURNERS

FOR VENTED NATURAL GAS LOGS

AIR FOR COMBUSTION AND VENTILATION

Continued

VENTILATION AIR

Ventilation Air From Inside Building

This fresh air would come from an adjoining unconfined space. When ventilating to an adjoining unconfined space, you must provide two permanent openings: one within 12" of the ceiling and one within 12" of the floor on the wall connecting the two spaces (see options 1 and 2, Figure 2). You can also remove door into adjoining room (see option 3, Figure 2). Follow the National Fuel

Gas Code NFPA 54/ANS Z223.1, Section

5.3, Air for Combustion and Ventilation for

required size of ventilation grills or ducts.

WARNING: Rework worksheet, adding the space of the adjoining unconfined space. The combined spaces must have enough fresh air to supply all appliances in both spaces.

Ventilation Air From Outdoors

Provide extra fresh air by using ventilation grills or ducts. You must provide two permanent openings: one within 12" of the ceiling and one within 12" of the floor. Connect these items directly to the outdoors or spaces open to the outdoors. These spaces include attics and crawl spaces.

IMPORTANT:

inlet or outlet air into attic if attic has a thermostat-controlled power vent. Heated air entering the attic will activate the power vent.

Do not provide openings for

Ventilation

Grills

Into Adjoining

Room,

Option 1

Figure 2 - Ventilation Air from Inside Building

Remove Door into Adjoining

Room, Option

12"

Outlet Air

Ventilation Grills

Into Adjoining Room,

Ventilated Attic

Outlet Air

Inlet Air

Figure 3 - Ventilation Air from Outdoors

Crawl Space

12"

Option 2

To Attic

Crawl

Space

Ventilated

901048

OWNER’S MANUAL

INSTALLATION

CAUTION: Do not remove the metal data plates attached to the burner pan. The data plates contain important warranty information.

WARNING: Before installing in a solid fuel burning fireplace, the chimney flue and firebox must be cleaned of soot, creosote, ashes and loose paint by a qualified chimney cleaner. Creosote will ignite if highly heated. A dirty chimney flue may create and distribute soot within the house. Inspect chimney flue for damage.

NOTICE: Installation, service, and repair of this appliance must be performed by a qualified installer, service agency, company or gas supplier experienced with this type of gas appliance. Only factory authorized components listed in these instructions may be used in accordance with the manufacturer’s instructions and all codes and requirements of the authority having jurisdiction. Any modifications to this kit, or use of unauthorized components or accessory items will void the manufacturer’s warranty, and may result in a hazardous condition.

FLUE OPENING SPECIFICATIONS

Note:

This vented appliance must be in-

stalled only in a solid-fuel burning fireplace with a working flue and constructed of noncombustible material.

The charts in Figure 4 indicate technical information regarding the installation of your gas log set. Please make sure that all of the specifications shown are applicable before installation is attempted.

The fireplace must include a working flue and venting system with the minimum openings shown in the Figure 4.

Btu Input

MODEL DESCRIPTION

CVSR18 18" Single Burner 50,000 40,000 8" dia. CPVSR18 18" Single Burner 50,000 40,000 8" dia. CVSR24 24" Single Burner 60,000 50,000 8" dia. CPVSR24 24" Single Burner 60,000 50,000 8" dia. CVDR18 18" Dual Burner 55,000 45,000 8" dia. CVDR24 24" Dual Burner 65,000 55,000 8" dia. CVDR30 30" Dual Burner 70,000 60,000 8" dia.

MINIMUM FIREBOX SIZES

LOG FRONT BACK SIZE WIDTH* WIDTH** DEPTH HEIGHT

18" 28" 16" 14" 18" 24" 29 3/4" 17" 15 1/2" 18" 30" 36" 27" 18" 18"

*Add 6" if safety valve/pilot is used **At depth indicated

FUEL INLET PRESSURE

SPECIFICATIONS ("W.C.)

Min. Max. NG 5.5 10.5 LP 11 13

Figure 4 - Technical Information Charts

CHECK GAS TYPE

Use only natural gas. If your gas supply is not natural gas, you must install ON/OFF Safety Valve/Pilot Kit (see Accessories, page 20). Call dealer where you bought log set.

If the fireplace does not have a gas supply shut-off valve, one must be installed.

Natural Gas

VENTING SPECIFICATIONS FOR INSTALLATION

The fireplace chimney flue and vent must be drafting properly. To check the vent for proper drafting: Light a tightly rolled newspaper on one end and place it at the inside front edge of the fireplace. Observe the smoke and be sure the vent is properly drawing it up the chimney. If the smoke spills out into the room, extinguish the flame and remove any obstruction until proper venting is achieved.

The chimney flue must remain open a minimum of 3" at all times during the operation of this log set.

Btu Input

Propane Gas

BURNER ORIFICE

LOG NATURAL PROPANE/LP SIZE IN. NUM. IN. NUM.

18" .1285 30 .076 48 24" .144 27 .086 44 30" .154 23 .089 43

Minimum

Vent Opening

Continued

901048

RADCO BURNERS

FOR VENTED NATURAL GAS LOGS

INSTALLATION

Continued

INSTALLING DAMPER CLAMP

Secure the damper stop clamp provided to the leading edge of the damper as shown in Figure 5. If for any reason this clamp doesn't work on your fireplace, another suitable clamp or permanent stop must be installed, or the damper blade must be cut or removed.

Damper Clamp

Damper

Masonry Fireplace

Damper Clamp

Figure 5 - Attaching Damper Clamp

Manufactured Fireplace

CONNECTING TO GAS SUPPLY

Damper

CAUTION: Use only new, black iron or steel pipe. Internally-tinned copper tubing may be used in certain areas. Check your local codes. Use pipe of 1/2" diameter or greater to allow proper gas volume to log set. If pipe is too small, undue loss of pressure will occur.

Installation must include a manual shutoff valve, union, and plugged 1/8" NPT tap. Locate NPT tap within reach for test gauge hook up. NPT tap must be upstream from log set (see Figure 6).

Apply pipe joint sealant lightly to male threads. This will prevent excess sealant from going into pipe. Excess sealant in pipe could result in a clogged burner injector.

CAUTION: Use pipe joint sealant that is resistant to liquid petroleum (LP) gas.

Install sediment trap in supply line as shown in Figure 6. Locate sediment trap where it is within reach for cleaning. Locate sediment trap where trapped matter is not likely to freeze. A sediment trap traps moisture and contaminants. This keeps them from going into log set controls. If sediment trap is not installed or is installed wrong, log set may not run properly.

Approved Flexible Gas Hose (if allowed by local codes)

CHECKING GAS CONNECTIONS

WARNING: Test all gas piping and connections for leaks after installing or servicing. Correct all leaks at once.

WARNING: Never use an open flame to check for a leak. Apply a mixture of liquid soap and water to all joints. Bubbles forming show a leak. Correct all leaks at once.

Pressure Testing Gas Supply Piping System

Test Pressures In Excess Of 1/2 PSIG

1. Disconnect log set and its individual manual shutoff valve from gas supply piping system.

2. Cap off open end of gas pipe where manual shutoff valve was connected.

3. Pressurize supply piping system by either using compressed air or opening main gas valve located on or near gas meter.

4. Check all joints of gas supply piping system. Apply mixture of liquid soap and water to gas joints. Bubbles forming show a leak.

5. Correct all leaks at once.

6. Reconnect log set and manual shutoff valve to gas supply . Check reconnected fittings for leaks.

WARNING: A qualified service person must connect log set to gas supply. Follow all local codes.

Installation Items Needed

Before installing log set, make sure you have the items listed below.

• piping (check local codes)

• sealant (resistant to LP gas)

• manual shutoff valve

• test gauge connection

• adjustable (crescent) wrench or pliers

• sediment trap

• tee joint

• pipe wrench

A.G.A. Design-Certified Manual Shutoff Valve With 1/8" NPT Tap*

3" Minimum

Cap

Pipe Nipple

Figure 9 - Gas Connection

* Purchase the optional A.G.A. design-certified manual shutoff valve from your dealer. See Accessories, page 20.

** Minimum inlet pressure for purpose of input adjustment.

Sediment Trap

From Gas Meter (5" W.C.** to 10.5" W.C. Pressure)

Tee Joint

901048

OWNER’S MANUAL

INSTALLATION

Continued

Test Pressures Equal To or Less Than 1/2 PSIG

1. Close manual shutoff valve (see Figure 7).

2. Pressurize supply piping system by either using compressed air or opening main gas valve located on or near gas meter.

3. Check all joints from gas meter to manual shutoff valv e (see Figure 7). Apply mixture of liquid soap and water to gas joints. Bubbles forming show a leak.

4. Correct all leaks at once.

Manual Shutoff Valve

Gas Meter

Figure 7 - Checking Gas Joints

HEARTH KIT ASSEMBLY AND INSTALLATION

Kit Assembly

Note:

The following instructions apply to both standard single bar burners, as well as dual flame “U” style burners. Be sure all pipe threaded connections are tight, and have thread compound to prevent leaks.

1. Determine which side the gas line will

be coming into the fireplace.

2. Using a hammer and screw driver, re-

move knock-out plug from the side of the pan that corresponds to the gas line (see Figure 8).

Knock-Out Plugs

Burner Pan Assembly (Facing Front of Fireplace)

Figure 8 - Knock-Out Plug Locations

3. Unscrew burner inlet fitting from burner manifold (see Figure 9).

4. Place burner manifold in pan with threaded opening facing open knockout plug.

5. Using thread sealant (resistant to the action of propane/LP gas) on larger end of fitting, screw the burner inlet fitting through hole and into burner manifold. Tighten using a wrench. If using propane/LP gas, see Propane/LP Gas Conversion, page 10.

6. Using burner clamp, screw , and nut provided, assemble clamp to pan (“U” style burners only). This will hold the b urner manifold in place.

7. If using optional GA9050 series kit, go to Optional GA9050 Series On/Off Safety V alve/Pilot Kit section for installation instructions. If using optional GA9150 series kit, follow instructions included with kit for installation and operation.

Nut

Burner Manifold

Burner Clamp

Burner Pan

Screw

Figure 9 - Installing Burner

Burner Inlet Fitting

Installation and Gas Connection

1. Place the burner pan assembly in the center of the fireplace floor . Make sure the front of pan faces forward.

2. Thread the gas supply fitting to the fireplace gas supply pipe. Use thread sealant.

3. Install adapter fitting onto the burner inlet fitting using thread sealant on male threads of burner inlet fitting (see Figure 10).

4. Install the gas connector tube to the gas supply fitting. Carefully shape tube to attach to adapter fitting.

Gas Connector Tube

Burner Pan Assembly (Facing Front of Fireplace)

Figure 10 - Connecting Gas to Appliance

Adapter Fitting

OPTIONAL GA9050 SERIES ON/OFF SAFETY VALVE/ PILOT KIT ASSEMBLY

For additional convenience and safety, or for propane/LP conversion, an optional ON/ OFF safety valve/pilot kit is available. See Accessories, page 20.

WARNING: You must use a ON/OFF safety valve/pilot kit for propane/LP conversion.

Natural Gas Installation

1. Thread the gas control valve onto the burner inlet fitting (see Figure 11). Use thread sealant on the male threads of the burner inlet fitting. Hold the burner inlet fitting with a wrench to prevent overtightening the connection to the burner. Make sure the control rod is facing the front (see Figure 11).

Gas Control Valve

Burner Pan Assembly

Figure 11 - Installing Gas Control Valve

Burner Inlet Fitting

Control Rod

Continued

901048

RADCO BURNERS

FOR VENTED NATURAL GAS LOGS

INSTALLATION

Continued

2. Attach the pilot gas line to the pilot outlet of the gas control valve and tighten. Connect the thermocouple to the rear of the gas control valve. See Figure 12. Do not overtighten. If using propane/LP gas, see Changing Pilot Orifice, page 11.

3. Install the inlet fitting into the inlet opening of the gas control valve (see Figure 13). Use thread sealant on the male pipe threads.

4. Place the burner pan assembly in the center of the fireplace floor . Make sure the front of pan faces forward.

5. Thread the gas supply fitting to the fireplace gas supply pipe. Adjust to most convenient position.

Install the gas connector tube to the gas supply fitting. C arefully shape tube to attach to adapter fitting.

7. Test for leaks following instructions under Testing Burner for Leaks, page 11.

Retighten and adjust the location of the gas control as necessary. The gas control should be level, with the control rod to the front.

9. Install cover to burner pan using screws provided.

10. Install thermocouple, pilot, and ignitor onto valve cov er as shown in Figure 14. Use the provided screws.

11. Push the control rod extension onto the “D” shaped control rod through the center hole in the cover.

12.

Install the position decal and control knob making sure to align the marks with the correct stop positions of the gas control. Pilot position will allow the knob to push in about 1/2". Align the decals in the pilot position.

Thermocouple and Line

Pilot and Line

Gas Control Valve

Figure 12 - Gas Control Valve with Thermocouple and Pilot

Gas Connector Tube

Gas Control Valve

Figure 13 - Installing Inlet Fitting and Gas Connector Tube

Ignitor

Control Knob

Figure 14 - Installing Cover, Control Knob, and Piezo Ignitor

Inlet Opening

Screw

Control Rod Extension

Gas Inlet Fitting

Thermocouple

Pilot

Valve Cover

Piezo Ignitor

Propane/LP Gas Conversion

To convert to propane/LP gas, the burner inlet fitting and pilot orifice must be replaced. The propane/LP burner inlet fitting is supplied with the orifice installed for a 24" log set. If you have an 18" or 30" set, you must change this orifice also. See Figure 1, page 3 for product identification.

Burner Inlet Fitting

1. Remove the burner inlet fitting from the burner pan assembly . DO NOT remo ve the orifice from this fitting. The propane/LP burner inlet fitting is included in the hardware kit (see Figure 15).

2. Be sure to use the correct orifice for your appliance. The hardware kit included with this appliance contains two orifices with a cone-like shape. If you have an 18" set, the orifice for the burner inlet fitting is red; for a 30" set, it is black. If you have a 24" log set, the orifice is already installed inside the fitting.

3. For an 18" or 30" set, use a 10mm socket or nut driver to remove the orifice from the propane/LP burner inlet fitting. Choose the correct orifice for your log set size and install in place of the orifice you just removed.

4. Using thread sealant (resistant to the action of propane/LP gas) on larger end of fitting, screw the burner inlet fitting through hole and into burner manifold. Tighten using a wrench.

5 . Follow steps 1 through 12 under Natu-

ral Gas Installation, pages 9 and 10.

Injector for Natural Gas

NATURAL

GAS

FITTING

Figure 15 - Burner Inlet Fittings with Injectors

Figure 16 - Remove Burner Inlet Fitting

Injector for Propane/LP Gas

PROPANE/

LP GAS

FITTING

Burner Inlet Fitting for Natural Gas

Changing Pilot Orifice

The pilot is provided with a natural gas orifice installed. For propane/LP gas you must remove it and replace it with an propane/LP orifice. The hardware kit contains an propane/LP orifice with a red stripe for converting the pilot.

1. Gently loosen and remove the pilot line connection from the bracket (see Figure 17, page 11).

901048

OWNER’S MANUAL

INSTALLATION

Continued

2. Replace the injector (see Figure 17) with the propane/LP pilot injector with the red stripe.

3. Replace and tighten the pilot line to the bracket.

4. Continue with step 3 under Natural Gas Installation, page 10.

Pilot Injector

Figure 17 - Installing Propane/LP Pilot Orifice

TESTING BURNER FOR LEAKS

1. Generously apply soapy solution to all connections.

WARNING: Never check for

gas leaks with open flame.

2. Light the burner with the shut-off v alve no more than half open and holding a match slightly in front of the pan (see Lighting Instructions, page 12).

3. Inspect all connections for bubbles, raw gas odor, or flame from any area other than the burner (leaks). If leaks are detected, shut off the gas valve immediately. Tighten, or reassemble the loose connection(s) using pipe joint compound until burner system is leak free.

4. When the burner is tested and leak free, observe the individual tongues of flame on the burner . includes more ports on the outside of the bar. Make sure that all ports are clear and producing flame evenly across the burner . If any ports appear blocked, clear them by removing the burner manifold and reaming the ports with a modified paper clip or other suitable tool.

5. When finished testing, turn the gas shutoff valve OFF to extinguish all flames.

Note:

The burner design

ADDING PAN MATERIAL

1. Open the bag of Ash Bed Material (ver miculite) and spread it evenly across the burner pan to the top. You may overflow the front and sides of the pan to cover the entire pan and connecting hardware. Do not cover GA9050 series or GA9150 series valve.

2. Open the glowing embers and evenly cover the Ash Bed Material (vermiculite) in the burner pan.

INSTALLING THE GRATE AND LOGS

1. Place the grate over the burner pan where the two outer horizontal supports on the grate fit into the two pan positioning notches in the rear vertical edge of the pan.

2. Slide the two rear log grate steps over the two outer horizontal supports on the grate as shown in Figure 18 (Not Included with Oxford Oak Models).

3. Place the back log on the grate onto the grate steps (see Figure 19). If assembling Oxford Oak models, place log on the back of the grate bars (see Figure 19).

4. Place the front log(s) on the grate and slide forward against the front bars on the grate (see Figure 19).

5. Place the smaller top logs onto the bottom logs (see Figure 20). Leave as much open space between logs as possible to minimize flame impingement and sooting. they are handled roughly or if hit together while being placed.

Grate

Figure 18 - Installing Grate (Pan Material Not Shown)

Note:

Logs may chip if

Grate Steps

Oxford Oak Logs

Amherst Oak Logs

Berkshire Split Oak Logs

Figure 19 - Installing Front and Back Logs (Number and style of your logs may vary)

Figure 20 - Placement of Top Logs (Berkshire Split Oak Logs Shown)

901048

RADCO BURNERS

FOR VENTED NATURAL GAS LOGS

OPERATING APPLIANCE

FOR YOUR SAFETY

READ BEFORE

LIGHTING

WARNING: Keep flue open

when operating unit.

WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life.

BEFORE LIGHTING smell all around the appliance area for gas. Be sure to smell next to the floor because some gas is heavier than air and will settle on the floor.

WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electric switch; do not use any phone in your building.

• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

• If you cannot reach y our gas supplier, call the fire department.

LIGHTING

INSTRUCTIONS

1. STOP! Read the safety information,

above.

2. Turn the gas shut-off valve to OFF.

3. Wait f ive (5) minutes to clear out any

gas. If you then smell gas STOP! F ollow the safety information above. If you don't smell gas, go on to the next step.

4. Light a match and lay it on top of

the pan material about 2" from the end of the supply side of the pan

5. Slowly turn the gas shut-off valve ON

until the burner ignites. If the bur ner doesn’t ignite within 10 seconds with the match burning, turn the shut-off valve OFF and repeat steps 1 through 4 again.

GAS SHUT-OFF

VALVE OPERATION

Flame Adjustment

1. Adjust the flame ON/OFF by turning the gas shut-off valve counterclockwise to open or clockwise to close, as necessary.

Shutting Off Appliance

1. Turn gas shut-off valve clockwise

to the OFF position.

CURING LOGS

During the 2-3 hour appliance break-in period, you may detect an odor from the appliance as the various paints and compounds used in the manufacturing of this log set cure. This is a normal and temporary situation that is not cause for alarm. However, you may want to provide extra ventilation to the room during this time.

To ensure proper curing of the logs:

• Ignite a 2" flame and maintain it for 1

hour .

• Burn the logs in consecutive 1 hour pe-

riods raising the flame an additional 2" to full flame height for a total of three hours.

OPERATING

INSTRUCTIONS FOR

GA9000

Note:

Operation instructions for GA9100 Remote Ready Valve/Pilot Kit will be included with the Kit.

1. STOP! Read the safety information,

column one this page.

2. Make sure manual shutoff valve is

fully open.

3. Press in and turn control knob clock-

wise to the OFF position.

4. Wait f ive (5) minutes to clear out an y

gas. Then smell for gas ar ound log set and near floor. If you smell gas, STOP! See Safety information, page 2 and Air For Combustion And Ventila- tion, pages 4 through 6. If you don’t smell gas, go to the next step.

5. T ur n control knob counterclockwise to the PILOT position and

press in. Keep control knob pressed in for five (5) seconds.

Note:

You ma y be running this log set for the first time after hooking up to gas supply . If so, the contr ol knob may need to be pressed in for 30 seconds. This will allow air to bleed from the gas system.

• If control knob does not pop up

when released, contact a qualified service person or gas supplier for repairs.

6. With control knob pressed in, push down and release ignitor button. This will light pilot. The pilot is attached to the rear of the front burner. If needed, keep pressing ignitor button until pilot lights.

Note:

If pilot does not stay lit, contact a qualified service person or gas supplier for repairs. Until repair s are made, light pilot with match.

7. Keep control knob pressed in for 30 seconds after lighting pilot. After 30 seconds, release control knob.

Note:

If pilot goes out, repeat steps

3 through 7.

8. T urn contr ol knob counterclockwise

to the ON position. Burner should light. If burner does not light, call a qualified service person.

Ignitor

Figure 21 - Ignitor and Control Knob

Pilot

Figure 22 - Thermocouple and Pilot

Control Knob

Pilot

FROM "PILOT" POSITION

SLIGHT PUSH TO

TURN OFF

PULL PUSH

TURN OFF

PULL PUSH

SLIGHT PUSH TO

FROM "PILOT" POSITION

ON OFF

OFF

Off

FROM "PILOT" POSITION

SLIGHT PUSH TO

PULL PUSH

TURN OFF

Thermocouple

OFF

901048

OPERATING APPLIANCE

Continued

TO TURN OFF GAS

TO APPLIANCE

Shutting Off Appliance

1. T urn control knob clockwise to the PILOT position.

2. Press in and turn control clockwise

to the OFF position.

Shutting Off Burner Only (pilot stays lit)

Turn control knob clockwise to the PILOT position.

OWNER’S MANUAL

TROUBLESHOOTING

Note:

For additional help, visit DESA

International’s technical service web site at www.desatech.com.

Note:

All troubleshooting items are listed in

order of operation.

OBSERVED PROBLEM

Log set is smoking/sooting excessively (

Note:

It is natural and unavoidable for vented gas log sets to produce moderate levels of carbon (soot) where flames contact the logs. This is especially true with propane/LP gas.)

Burner is excessively noisy (

Note:

The movement and combustion of gas will create low, unavoidable levels of noise.)

WARNING: Turn off log set and let cool before servicing. Only a qualified service person should service and repair log set.

CAUTION: Never use a wire, needle, or similar object to clean ODS/pilot. This can damage ODS/ pilot unit.

POSSIBLE CAUSE REMEDY

1. Poor fuel quality

2. Fireplace venting system not drafting properly

3. Excessive flame impingement or bloc kage

4. Improper fuel/air mixture

5. Excessive gas supply/pressure

1. Passage of air/gas across irregular surfaces

1. Contact local natural or propane/LP gas company

2. Adjust damper wide open and/or have fireplace and venting professionally cleaned and checked

3. Separate the logs to allow more flame passage

4. Remove any foreign items from the flame pattern and/or check for proper orifice sizing

5. Preheat flue in very cold weather

1. Relieve any tight bends or kinks in gas supply line

Burner flame is too low or too high

901048

1. Incorrect gas supply or pressure

2. Blocked burner orifice or burner manifold ports

3. Improper burner orifice size

www.desatech.com

1. Check for proper gas supply pressure

2. Free burner orifice and manifold ports of any burrs, paint, or other blockage

3. Verify proper burner orifice sizing (see Figure 4, page 7)

Continued

RADCO BURNERS

FOR VENTED NATURAL GAS LOGS

TROUBLESHOOTING

Continued

WARNING: If you smell gas

• Shut off gas supply.

• Do not try to light any appliance.

• Do not touch any electrical switch; do not use any phone in your building.

• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the fire department.

IMPORTANT:

Cleaning supplies, paint, paint remover, cigarette smoke, cements and glues, new carpet or textiles, etc., create fumes. These fumes may mix with combustion air and create odors. These odors will disappear over time.

OBSERVED PROBLEM

Log Set produces a clicking/ticking noise just after burner is lit or shut off

Log Set produces unwanted odors

Gas odor even when control knob is in OFF position

Gas odor during combustion

Operating log set where impurities in air exist may create odors.

POSSIBLE CAUSE

1. Metal expanding while heating or contracting while cooling

1. Log Set burning vapors from paint, hair spray, glues, cleaners, chemicals, new carpet, etc. (See ment above)

2. Gas leak. See W arning statement at

top of page

1. Gas leak. See W arning statement at top of page

2. Control valve defective

1. Gas leak. See W arning statement at

top of page

IMPORTANT

state-

REMEDY

1. This is common with most log sets. If noise is excessive, contact qualif ied service person

1. Open flue to maximum. Stop using odor causing products while log set is running

2. Locate and correct all leaks (see Check- ing Gas Connections, page 8)

1. Locate and correct all leaks (see Check- ing Gas Connections, page 8)

2. Replace control valve

2. Locate and correct all leaks (see Check- ing Gas Connections, page 8)

www.desatech.com

901048

TROUBLESHOOTING

Continued

OWNER’S MANUAL

OBSERVED PROBLEM

When ignitor button is pressed, there is no spark at pilot (GA9000 Only)

When ignitor button is pressed, there is spark at pilot but no ignition (GA9000 Only)

Pilot lights but flame goes out when control knob is released (GA9000 Only)

POSSIBLE CAUSE

1. Ignitor electrode not connected to ignitor cable

2. Ignitor cable pinched or wet

3. Bad ground on piezo ignitor

4. Broken ignitor cable

5. Bad piezo ignitor

6. Ignitor electrode broken

7. Ignitor electrode positioned wrong

1. Gas supply turned off or manual shutof f valve closed

2. Control knob not in PILOT position

3. Control knob not pressed in while in PILOT position

4. Air in gas lines when installed

5. Pilot adjustment screw closed

6. Pilot is clogged

7. Low gas pressure

1. Control knob not fully pressed in

2. Control knob not pressed in long enough

3. Manual shutoff valve not fully open

4. Pilot flame not touching thermocouple, which allows thermocouple to cool, causing pilot flame to go out. This problem could be caused by one or both of the following: A) Low gas pressure B) Dirty or partially clogged pilot

5. Thermocouple connection loose at control valve

6. Thermocouple damaged

7. Control valve damaged

REMEDY

1. Reconnect ignitor cable

2. Free ignitor cable if pinched by any metal or tubing. Keep ignitor cable dry

3. Scrape away paint on bracket for better contact with ground on piezo ignitor

4. Replace ignitor cable

5. Replace piezo ignitor

6. Replace electrode

7. Reposition electrode

1. Turn on gas supply or open manual shutoff valve

2. Turn control knob to PILOT position

3. Press in control knob while in PILOT position

4. Continue holding down control knob. Repeat igniting operation until air is removed

5. Adjust pilot flame for approximately 2" blue flame

6. Clean pilot (see Cleaning and Mainte- nance, page 20) or replace pilot assembly

7. Replace gas control

1. Press in control knob fully

2. After pilot lights, keep control knob pressed in 30 seconds

3. Fully open manual shut-off valve

4. A) Contact local natural gas company B) Clean pilot (see Cleaning and Mainte-

nance, page 20) or replace pilot assembly

5. Hand tighten until snug, then tighten 1/4 turn more

6. Replace thermocouple

7. Replace control valve

Burner does not light after pilot is lit (GA9000 Only)

Delayed ignition burner (GA9000 Only)

901048

1. Burner orifice clogged

2. Inlet gas pressure is too low

3. Burner orifice diameter is too small

4. Thermocouple leads disconnected or improperly connected

1. Pilot flame needs adjusting

2. Wrong pilot orifice

www.desatech.com

1. Clean burner orifice

2. Contact local natural or propane/LP gas company

3. Replace burner orifice

4. Reconnect leads

1. Adjust pilot flame for approximately 2" blue flame

2. Replace pilot orifice set

RADCO BURNERS

FOR VENTED NATURAL GAS LOGS

ILLUSTRATED PARTS BREAKDOWN

RADCO BURNER MODELS CVSR18, CVSR24, CPVSR18, AND CPVSR24

Oxford Round Oak Logs

Amherst Round Oak Logs

901048

OWNER’S MANUAL

PARTS LIST

This list contains replaceable parts used in your log set. When ordering parts, follow the instructions listed under Replacement Parts on page 20 of this manual.

RADCO BURNER MODELS CVSR18, CVSR24, CPVSR18, AND CPVSR24

KEY PART NUMBER FOR NO. CVSR18 CVSR24 CPVSR18 CPVSR24 DESCRIPTION QTY.

1 901058-01 901058-01 901058-01 901058-01 Brass 3/8 FLR x 1/2 FPT Adapter 1 2 901059-01 901059-01 901059-01 901059-01 Brass 3/8 FLR x 3/8 FPT Adapter 1 3 901066-01 901066-01 901066-01 901066-01 Brass Air Mixer - Natural Gas 1 4 901064-02 901064-03 901064-02 901064-03 Natural Gas Injector 1 5 901208-01 901208-02 901208-01 901208-02 Burner Manifold 1 6 901136-01 901136-02 901137-01 901137-02 Burner Pan 1 7 901242-01 901242-01 901242-01 901242-01 Damper Clamp - Std. Assembly 1 8 101628-01 101628-01 101628-01 101628-01 Gas Line - 10" Flex 1 9 — — 901431-01 901431-01 Grate Steps 2 10 901243-01 901243-02 901246-01 901246-02 Log Grate 1 11 901635-01 901636-01 — — Bottom Front Log 1 12 901625-01 901626-01 — — Bottom Rear Log 1 13 901545-01 901545-01 — — CPR12/CP Top Log 1 14 — 901546-01 — — CPR13S/CP Top Log 1 15 901541-01 901541-01 — — CPR13/CP Top Log 1 16 901547-01 901547-01 — — CPR14/CP Top Log 1 17 — — 901641-01 901642-01 Bottom Front Log 1 18 — — 901625-02 901626-02 Bottom Rear Log 1 19 — — 901580-04 — VR11/CH Top Log 1 20 — — 901555-01 901555-01 CHR10/CH Top Log 1 21 — — 901550-01 901550-01 CHR11/CH Top Log 1 22 — — 901551-01 901551-01 CHR13/CH Top Log 1 23 — — 901556-01 901556-01 CHR13Y/CH Top Log 1

PARTS AVAILABLE — NOT SHOWN

901156-01 901156-01 901156-01 901156-01 .125# Bag Embers 1 901155-01 901155-01 901155-01 901155-01 1.5# Bag Ash Bed Material

(Vermiculite) 1 901036-01 901036-01 901036-01 901036-01 Aluminum Rating Plate-Radco Gen. 1 901265-01 901265-01 901265-01 901265-01 Instruction Manual - V/G RGA 2-72 1

901048

RADCO BURNERS

FOR VENTED NATURAL GAS LOGS

ILLUSTRATED PARTS BREAKDOWN

RADCO BURNER MODELS CVDR18, CVDR24, AND CVDR30

Berkshire Split Oak Logs

901048

OWNER’S MANUAL

PARTS LIST

This list contains replaceable parts used in your log set. When ordering parts, follow the instructions listed under Replacement Parts on page 20 of this manual.

RADCO BURNER MODELS CVDR18, CVDR24, AND CVDR30

KEY PART NUMBER FOR NO. CVDR18 CVDR24 CVDR30 DESCRIPTION QTY.

1 901058-01 901058-01 901058-01 Brass 3/8 FLR x 1/2 FPT Adapter 1 2 901059-01 901059-01 901059-01 Brass 3/8 FLR x 3/8 FPT Adapter 1 3 901066-01 901066-01 901066-01 Brass Air Mixer - Natural Gas 1 4 901064-02 901064-03 901064-04 Natural Gas Injector 1 5 901209-01 901209-02 901209-03 Burner Manifold 1 6 901137-01 901137-02 901137-03 Burner Pan 1 7 901242-01 901242-01 901242-01 Damper Clamp - Std. Assembly 1 8 101628-01 101628-01 101628-01 Gas Line - 10" Flex 1 9 901430-01 901430-01 901431-01 Grate Steps 2 10 901246-01 901246-02 901246-03 Log Grate 1 11 901681-01 901681-01 901681-01 Burner Strap 1 12 901078-01 901078-01 901078-01 Nut #8/32 1 13 901076-01 901076-01 901076-01 Screw #8/32 x 3/8 1 14 901645-01 901646-01 901647-01 Bottom Front Log 1 15 901528-01 901566-01 901567-01 Bottom Rear Log 1 16 901591-03 901591-03 901591-03 VCR11/CC Top Log 1 17 901587-03 901587-03 901587-03 VCR9/CC Top Log 1 18 — 901551-02 901551-02 CHR13/CC Top Log 1 19 901527-03 901527-03 901527-03 CS12/CC Top Log 1 20 901541-03 901541-03 901541-03 CPR13/CC Top Log 1 21 — — 901528-01 CS16/CC Top Log 1

901048

PARTS AVAILABLE — NOT SHOWN

901156-01 901156-01 901156-01 .125# Bag Embers 1 901155-01 901155-01 901155-01 1.5# Bag Ash Bed Material

(Vermiculite) 1 901036-01 901036-01 901036-01 Aluminum Rating Plate-Radco Gen. 1 901265-01 901265-01 901265-01 Instruction Manual - V/G RGA 2-72 1

RADCO BURNERS

FOR VENTED NATURAL GAS LOGS

CLEANING AND MAINTENANCE

• Keep the area around the log set clean and clear of debris.

• Occasionally, you may use a soft bristle brush to clean logs.

• Once every year a qualified agency or certified chimney sweep should examine and clean the venting system of the fireplace.

REPLACEMENT PARTS

Note:

Use only original replacement parts. This will protect your warranty coverage for parts replaced under warranty.

PARTS UNDER WARRANTY

Contact authorized dealers of this product or Parts Central (see page 21). If they can’t supply original replacement part(s), call DESA International’s Technical Service Department at 1-800-DESA LOG (1-800-337-2564).

When calling DESA International, have ready

• your name

• your address

• model and serial numbers of your fireplace

• how fireplace was malfunctioning

• type of gas used (propane/LP or natural

gas)

• purchase date Usually, we will ask you to return the defec-

tive part to the factory.

PARTS NOT UNDER WARRANTY

Contact authorized dealers of this product or Parts Central (see page 21). If they can’t supply original replacement part(s), call DESA International’s Parts Department at 1-800-972-7879 for referral information.

When calling DESA International, have ready

• model number of your fireplace

• the replacement part number

ACCESSORIES

Purchase these fireplace accessories from your local dealer. If they can not supply these accessories, call DESA International’s Sales Department at 1-800-432-2382 for information. You can also write to the address listed on the back page of this manual.

MANUAL SHUTOFF VALVE GA5010

For all models. Manual shutoff valve with 1/8" NPT tap. Fits 1/2" NPT pipe.

RECEIVER AND HANDHELD REMOTE CONTROL KIT - GHRC Series

For all models. Allows the gas log set to be turned on and off by using a hand-held remote control. Valve/Pilot Kit GA9100 must be used with this remote.

ON/OFF SAFETY VALVE/ PILOT KIT - GA9050-1

(Not Shown)

For all models. Required for Propane/LP installation.

REMOTE READY VALVE/ PILOT KIT - GA9150-1

(Not Shown)

For all models.

INDIVIDUAL ROUND LOG GA9450

(Not Shown)

For all models. Use when more logs are desired. Carton of 6

INDIVIDUAL SPLIT LOG GA9550

(Not Shown)

For all models. Carton of 6.

PINE CONES - GA9650

(Not Shown)

For all models. Use for additional decoration only. Carton of 6 Boxes (3 pine cones per box).

ASH BED MATERIAL (Vermiculite) - GA9750

(Not Shown)

For all models. Carton of 6.

GLOWING EMBERS - GA9950

(Not Shown)

For all models. Use for firebox decoration only.

SILICA SAND - GA9850

(Not Shown)

For all models. Use for firebox decoration only. Carton of 6.

LAVA ROCK - GA6067

(Not Shown)

For all models. Use for firebox decoration only.

901048

ACCESSORIES

Continued

DECORATIVE ASH BED CONTROL COVER - CDABK

(Not Shown)

An attractive way to cover control knob and piezo ignitor.

18" ORNAMENTAL GRATE ENHANCER - GA9350

(Not Shown)

For 18" models only. Additional decoration for front grate.

24" ORNAMENTAL GRATE ENHANCER - GA9360

(Not Shown)

For 24" models only. Additional decoration for front grate.

OWNER’S MANUAL

30" ORNAMENTAL GRATE ENHANCER - GA9370

(Not Shown)

For 30" models only. Additional decoration for front grate.

PARTS CENTRALS

Baltimore Electric

1348 Dixwell Avenue Hamden, CT 06514 1-800-397-7553 203-248-7553 Parts Department

Portable Heater Parts

342 N. County Rd. 400 E. Valparaiso, IN 46383 All States 219-462-7441 1-800-362-6951 Parts Department

FBD

1349 Adams St. Bowling Green, KY 42103 502-846-1199 1-800-654-8534 Fax: 1-800-846-0090

Four Flags Power Products

1115 Stateline Road Niles, MI 49120 616-684-2697 1-800-268-4983 Parts Only

Master Parts Distributor

1251 Mound Ave. NW Grand Rapids , MI 49504-2672 616-791-0505 1-800-446-1446 Fax: 1-616-791-8270 Parts Department

Washer Equipment Co.

1715 Main Street Kansas City, MO 64108-2195 KS, MO, AR 816-842-3911 Parts Department

These Parts Centrals are privately-owned businesses. They have agreed to support our customer’s needs by providing original replacement parts and accessories.

East Coast Energy Products

707 Broadway W. Long Branch, NJ 07764 732-870-8809 1-800-755-8809 Parts Department

Tarantin Tank Co.

P.O. Box 6129 Freehold, NJ 07728 908-780-9340 1-800-922-0724 Parts Department

Dayton Hardware

P.O. Box 275 North Dayton Station Dayton, OH 45404 All States 513-258-3721 OH 1-800-762-3426 Parts Department

Halco Enterprises

208 Carter Drive, Unit 21 West Chester, PA 19382-4500 610-430-7717 1-800-368-0803 Parts Department

LaPorte’s Parts and Service

2444 North 5th Street Hartsville, SC 29550-7704 803-332-0191 Parts Department

Cans Unlimited, Inc.

P.O. Box 645 Taylor, SC 29687 All States 803-879-3009 1-800-845-5301 Parts Department

Heater and Fireplace Store

1922 N. Route 9 Cape May Court, NJ 08210-1110 609-624-0678 Parts Department

901048

RADCO BURNERS

FOR VENTED NATURAL GAS LOGS

NOTES

_______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________

901048

OWNER’S MANUAL

NOTES

901048

WARRANTY INFORMATION

KEEP THIS WARRANTY

Model Serial No. Date Purchased

Always specify model and serial numbers when communicating with the factory. We reserve the right to amend these specifications at any time without notice. The only warranty applicable is our standard written

warranty. We make no other warranty, expressed or implied.

LIMITED WARRANTY

VANGUARD VENTED GAS LOGS

DESA International warrants this product to be free from defects on burner system for three (3) years and logs for a lifetime from the date of first purchase, provided that the product has been properly installed, operated and maintained in accordance with all applicable instructions. To make a claim under this warranty the Bill of Sale or cancelled check must be presented.

This warranty is extended only to the original retail purchaser. This warranty covers the cost of part(s) required to restore this log set to proper operating condition and an allowance for labor when provided by a DESA Authorized Service Center. Warranty part(s) MUST be obtained through authorized dealers of this product and/or DESA International who will provide original factory replacement parts. Failure to use original factory replacement parts voids this warranty. The log set MUST be installed by a qualified installer in accordance with all local codes and instructions furnished with the unit.

This warranty does not apply to parts that are not in original condition because of normal wear and tear, or parts that fail or become damaged as a result of misuse, accidents, lack of proper maintenance or defects caused by improper installation. Travel, diagnostic cost, labor, transportation and any and all such other costs related to repairing a defective log set will be the responsibility of the owner.

TO THE FULL EXTENT ALLOWED BY THE LAW OF THE JURISDICTION THAT GOVERNS THE SALE OF THE PRODUCT; THIS EXPRESS WARRANTY EXCLUDES ANY AND ALL OTHER EXPRESSED WARRANTIES AND LIMITS THE DURATION OF ANY AND ALL IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE TO THREE (3) YEARS ON BURNER SYSTEM AND A LIFETIME ON LOGS FROM THE DATE OF FIRST PURCHASE; AND DESA INTERNATIONAL’S LIABILITY IS HEREBY LIMITED TO THE PURCHASE PRICE OF THE PRODUCT AND DESA INTERNATIONAL SHALL NOT BE LIABLE FOR ANY OTHER DAMAGES WHATSOEVER INCLUDING INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES.

Some states do not allow a limitation on how long an implied warranty lasts or an exclusion or limitation of incidental or consequential damages, so the above limitation on implied warranties, or exclusion or limitation on damages may not apply to you.

This warranty gives you specific legal rights, and you may also have other rights that vary from state to state. For information about this warranty write:

INTERNATIONAL

2701 Industrial Drive P.O. Box 90004 Bowling Green, KY 42102-9004

www.desatech.com

901048 01

NOT A UPC

901048-01 Rev. A 07/99

Desa CVDR30, CVDR24, CPVSR18, CVSR18, CVDR18 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
