Denon DCM-27, DCM-390 User Manual

CD AUTO CHANGER

DCM-390/290
DCM-27

OPERATING INSTRUCTIONS
MODE D’EMPLOI
INSTRUCCIONES DE FUNCIONAMIENTO

ESPAÑOLENGLISH FRANCAIS

FIGURE A

EXAMPLE OF ANTENNA GROUNDING

AS PER NATIONAL
ELECTRICAL CODE

ANTENNA
LEAD IN
WIRE

GROUND
CLAMP

ELECTRIC
SERVICE
EQUIPMENT

ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)

GROUNDING CONDUCTORS
(NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)

NEC - NATIONAL ELECTRICAL CODE

2 SAFETY PRECAUTIONS

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.

The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the presence
of uninsulated “dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude to constitute a
risk of electric shock t persons.

The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the appliance.

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

LABELS (for U.S.A. model only)

THIS PRODUCT COMPLIES WITH DHHS RULES 21CFR
SUBCHAPTER J APPLICABLE AT DATE OF MANUFACTURE.

CAUTION:
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT
IN HAZARDOUS RADIATION EXPOSURE.
THE COMPACT DISC PLAYER SHOULD NOT BE ADJUSTED OR
REPAIRED BY ANYONE EXCEPT PROPERLY QUALIFIED SERVICE
PERSONNEL.

CERTIFICATION

SAFETY INSTRUCTIONS

1. Read Instructions – All the safety and operating instructions should be read
before the product is operated.

2. Retain Instructions – The safety and operating instructions should be
retained for future reference.

3. Heed Warnings – All warnings on the product and in the operating
instructions should be adhered to.

4. Follow Instructions – All operating and use instructions should be followed.

5. Cleaning – Unplug this product from the wall outlet before cleaning. Do not
use liquid cleaners or aerosol cleaners.

6. Attachments – Do not use attachments not recommended by the product
manufacturer as they may cause hazards.

7. Water and Moisture – Do not use this product near water – for example,
near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement;
or near a swimming pool; and the like.

8. Accessories – Do not place this product on an unstable cart, stand, tripod,
bracket, or table. The product may fall, causing serious injury to a child or
adult, and serious damage to the product. Use only with a cart, stand,
tripod, bracket, or table recommended by the manufacturer, or sold with
the product. Any
mounting of the product should follow the
manufacturer’s instructions, and should use a
mounting accessory recommended by the
manufacturer.

9. A product and cart combination should be moved
with care. Quick stops, excessive force, and
uneven surfaces may cause the product and cart
combination to overturn.

10. Ventilation – Slots and openings in the cabinet are provided for ventilation
and to ensure reliable operation of the product and to protect it from
overheating, and these openings must not be blocked or covered. The
openings should never be blocked by placing the product on a bed, sofa,
rug, or other similar surface. This product should not be placed in a built-in
installation such as a bookcase or rack unless proper ventilation is provided
or the manufacturer’s instructions have been adhered to.

11. Power Sources – This product should be operated only from the type of
power source indicated on the marking label. If you are not sure of the type
of power supply to your home, consult your product dealer or local power
company. For products intended to operate from battery power, or other
sources, refer to the operating instructions.

12. Grounding or Polarization – This product may be equipped with a polarized
alternating-current line plug (a plug having one blade wider than the other).
This plug will fit into the power outlet only one way. This is a safety feature.
If you are unable to insert the plug fully into the outlet, try reversing the
plug. If the plug should still fail to fit, contact your electrician to replace
your obsolete outlet. Do not defeat the safety purpose of the polarized
plug.

I

13. Power-Cord Protection – Power-supply cords should be routed so that they
are not likely to be walked on or pinched by items placed upon or against
them, paying particular attention to cords at plugs, convenience
receptacles, and the point where they exit from the product.

15. Outdoor Antenna Grounding – If an outside antenna or cable system is
connected to the product, be sure the antenna or cable system is grounded
so as to provide some protection against voltage surges and built-up static
charges. Article 810 of the National Electrical Code, ANSI/NFPA 70,
provides information with regard to proper grounding of the mast and
supporting structure, grounding of the lead-in wire to an antenna discharge
unit, size of grounding conductors, location of antenna-discharge unit,
connection to grounding electrodes, and requirements for the grounding
electrode. See Figure A.

16. Lightning – For added protection for this product during a lightning storm,
or when it is left unattended and unused for long periods of time, unplug it
from the wall outlet and disconnect the antenna or cable system. This will
prevent damage to the product due to lightning and power-line surges.

17. Power Lines – An outside antenna system should not be located in the
vicinity of overhead power lines or other electric light or power circuits, or
where it can fall into such power lines or circuits. When installing an
outside antenna system, extreme care should be taken to keep from
touching such power lines or circuits as contact with them might be fatal.

18. Overloading – Do not overload wall outlets, extension cords, or integral
convenience receptacles as this can result in a risk of fire or electric shock.

19. Object and Liquid Entry – Never push objects of any kind into this product
through openings as they may touch dangerous voltage points or short-out
parts that could result in a fire or electric shock. Never spill liquid of any
kind on the product.

20. Servicing – Do not attempt to service this product yourself as opening or
removing covers may expose you to dangerous voltage or other hazards.
Refer all servicing to qualified service personnel.

21. Damage Requiring Service – Unplug this product from the wall outlet and
refer servicing to qualified service personnel under the following
conditions:
a) When the power-supply cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the operating

instructions. Adjust only those controls that are covered by the
operating instructions as an improper adjustment of other controls may
result in damage and will often require extensive work by a qualified

technician to restore the product to its normal operation,
e) If the product has been dropped or damaged in any way, and
f) When the product exhibits a distinct change in performance – this

indicates a need for service.

22. Replacement Parts – When replacement parts are required, be sure the
service technician has used replacement parts specified by the
manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock, or other
hazards.

23. Safety Check – Upon completion of any service or repairs to this product,
ask the service technician to perform safety checks to determine that the
product is in proper operating condition.

24. Wall or Ceiling Mounting – The product should be mounted to a wall or
ceiling only as recommended by the manufacturer.

25. Heat – The product should be situated away from heat sources such as
radiators, heat registers, stoves, or other products (including amplifiers)
that produce heat.

ENGLISHFRANCAISESPAÑOL

FCC INFORMATION (For US customers)

1. PRODUCT

This product complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this product may not cause harmful
interference, and (2) this product must accept any interference received,
including interference that may cause undesired operation.

2. IMPORTANT NOTICE: DO NOT MODIFY THIS PRODUCT

This product, when installed as indicated in the instructions contained in this
manual, meets FCC requirements. Modification not expressly approved by
DENON may void your authority, granted by the FCC, to use the product.

3. NOTE

This product has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This product generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
product does cause harmful interference to radio or television reception,
which can be determined by turning the product OFF and ON, the user is
encouraged to try to correct the interference by one or more of the
following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the product into an outlet on a circuit different from that to
which the receiver is connected.

• Consult the local retailer authorized to distribute this type of product or
an experienced radio/TV technician for help.

This Class B apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003
du Canada.

Copyrights / Droits d’auteur / Derechos de Autor

It is prohibited by law to reproduce, broadcast, rent or play discs in public

2

without the consent of the copyright holder.
La reproduction, la diffusion, la location, le prêt ou la lecture publique de ces

2

disques sont interdits sans le consentement du détenteur des droits
d’auteur.

De acuerdo con las leyes está prohibido reproducir, emitir, alquilar o

2

interpretar discos en público sin la autorización del propietario de los
derechos de autor.

2 NOTE ON USE / OBSERVATIONS RELATIVES A L’UTILISATION / NOTAS SOBRE EL USO

• Keep the apparatus free from moisture, water, and

•Avoid high temperatures.
Allow for sufficient heat dispersion when installed
in a rack.

• Eviter des températures élevées
Tenir compte d’une dispersion de chaleur
suffisante lors de l’installation sur une étagère.

• Evite altas temperaturas
Permite la suficiente dispersión del calor cuando
está instalado en la consola.

• Handle the power cord carefully.
Hold the plug when unplugging the cord.

• Manipuler le cordon d’alimentation avec
précaution.
Tenir la prise lors du débranchement du cordon.

• Maneje el cordón de energía con cuidado.
Sostenga el enchufe cuando desconecte el cordón
de energía.

dust.

•Protéger l’appareil contre l’humidité, l’eau et
lapoussière.

• Mantenga el equipo libre de humedad, agua y
polvo.

• Unplug the power cord when not using the
apparatus for long periods of time.

• Débrancher le cordon d’alimentation lorsque
l’appareil n’est pas utilisé pendant de longues
périodes.

• Desconecte el cordón de energía cuando no utilice
el equipo por mucho tiempo.

* (For apparatuses with ventilation holes)

• Do not obstruct the ventilation holes.

• Ne pas obstruer les trous d’aération.

• No obstruya los orificios de ventilación.

• Do not let foreign objects into the apparatus.

• Ne pas laisser des objets étrangers dans l’appareil.

• No deje objetos extraños dentro del equipo.

• Do not let insecticides, benzene, and thinner come
in contact with the apparatus.

• Ne pas mettre en contact des insecticides, du
benzène et un diluant avec l’appareil.

• No permita el contacto de insecticidas, gasolina y
diluyentes con el equipo.

• Never disassemble or modify the apparatus in any
way.

• Ne jamais démonter ou modifier l’appareil d’une
manière ou d’une autre.

• Nunca desarme o modifique el equipo de ninguna
manera.

II

ENGLISH

rt y

e

Getting Started

Thank you for purchasing this DENON CD Player. Please read the operation instructions thoroughly in order to acquaint yourself with the CD
player and achieve maximum satisfaction from it.
Be sure to keep these instructions for future reference, should any questions or problems arise.

Getting Started
Accessories······················································································1

Before using ················································································1, 2
About discs

About the remote control unit

Part names and functions

Connections
Cable indications ············································································6

Analog connections········································································6
Digital connections·········································································6
Connecting the power supply cord ··············································6

Contents

Discs usable on this set·································································2
Before playing MP3 or WMA (Windows Media® Audio) files ······2
Holding discs··················································································2
Loading discs ·················································································2
Cautions on loading discs ······························································3
Cautions on handling······································································3
Cautions on storing discs·······························································3
Cleaning discs ················································································3

Inserting the batteries····································································3
Operating range of the remote control unit···································3

Front panel ·····················································································4
Display····························································································4
Rear panel ······················································································5
Remote control unit ·······································································5

Operation
Turning the power on·····································································7

Opening and closing the drawer and loading a disc ··················7
Starting playback············································································8
To stop playback·············································································8
Various playback functions

Playing the desired disc and desired track [Direct play] ················8
To move to the next disc during playback ·····································8
To pause playback··········································································8
Automatic search ···········································································8
Manual search················································································9
Programmed play ···········································································9
Random play ················································································10
Repeat play ··················································································10
Other functions ············································································10

Troubleshooting············································································

Specifications················································································

11

12

Accessories

Check that the following parts are attached in addition to the main
unit:

q Operating instructions .............................................................1

w Service station list....................................................................1

e Remote control unit (RC-1033) ................................................1

r R03/AAA batteries ...................................................................2

t Pin-plug cable (Cable length: Approx. 39-3/8 ft 1 m) ...............1

y Power supply cord (Cable length: Approx. 78-47/64 ft 2 m) ...1

Getting Started

Before using

• Remove two shipping screws.

At the bottom of the player there are
two red shipping screws for use when
the player is transported. Before using
the player, turn these screws
counterclockwise and remove them.
If the shipping screws are still in place
and the power is turned on, the disc tray
will not open. If this happens, turn off the power, unplug the power
supply cord from the power outlet and remove the shipping screws.
Retain these screws as they will be needed when the player is
transported.
Before transporting the player, take out the discs, close the disc tray,
turn off the power after “0 000 00:00” is displayed and unplug the
power supply cord from the power outlet. Then install the shipping
screws by turning them clockwise. Be sure to fasten them securely.

• Handle the power supply cord carefully.

Do not damage or deform the power supply cord. If it is damaged or
deformed, it may cause electric shock or malfunction when used.
When disconnecting the power supply cord from the wall outlet,
hold the plug and do not pull on the cable.

• Do not open the top cover.

In order to prevent electric shock, do not open the top cover.
If problems occur, contact your DENON dealer.

• Do not place anything inside.

Prevent metal objects from entering the CD player and avoid spilling
liquids on it.
Electric shock or malfunction may result.

• Cautions on moving.

First, if a disc is loaded, eject it, then turn off the power, unplug the
power supply cord from the power outlet and disconnect the
connection cables with other devices.

• Cautions on using mobile phones.

Using a mobile phone near this unit may result in noise. If so, move
the mobile phone away from this unit when using it.

• Store these instructions in a safe place.

After reading, store this instructions along with the warranty card in
a safe place.

• Note that the illustrations in these instructions may differ from
the actual unit for explanation purposes.

1

ENGLISH

ENGLISH

Getting Started Getting Started

NOTE:

• This CD player uses a semiconductor laser. To ensure stable

operation, it is recommended to use the set indoors at a
temperature of 5°C (41°F) ~ 35°C (95°F).

About discs

Discs usable on this set

Music CDs

q

Discs with the mark at the right can be used on
this set.
Note however that discs with special shapes
(heart-shaped discs, octagonal discs, etc.) cannot
be played. Do not attempt to play them, as doing
so could damage the set.

CD-R/CD-RW

w

• Some discs and some recording formats may not be playable.

• Non-finalized discs cannot be played.

Finalization:

Finalization is the process that makes recorded CD-R/CD-RW discs
playable on compatible players.

Before playing MP3 or WMA (Windows Media

®

Audio) files

There are many music distribution sites on the Internet allowing you
to download music files in MP3 or WMA format. The music (files)
downloaded from such sites can be stored on CD-R or CD-RW discs
and played on the this CD player.

“Windows Media” and “Windows” are registered trademarks or
trademarks in the United States and other countries of the Microsoft
Corporation of the United States.

According to copyright laws, recordings you have made
should only be used for your personal enjoyment and must
not be used in other ways without the consent of the
copyright holder.

NOTE:

• This CD player is compatible with “MPEG-1 Audio Layer-3”
standards (sampling frequency of 44.1 and 48 kHz). It is not
compatible with “MPEG-2 Audio Layer-3”, “MPEG-2.5 Audio
Layer-3”, MP1 or MP2 standards.

• The signals are output with a sampling frequency of 44.1 kHz.

• When writing MP3 files on a CD-R or CD-RW disc, set the writing
software’s format to “ISO9660 Level 1”. The files may not play
properly if they are recorded in other formats. Also note that with
some writing software it is not possible to record in ISO9660
format. If so, use a different program allowing you to record in
ISO9660 format.

•With MP3 files, the higher the bit rate, the better the sound
quality. The compatible bit rate range is 32 to 320 kbps for MP3
files, 64 to 160 kbps for WMA files. We recommend using MP3
files with bit rates of 128 kbps or greater on the this CD player.

• Be sure to add the extensions “.MP3” or “.WMA” to MP3 or
WMA files, respectively. Files with extensions other than
“.MP3” or “.WMA” or files without extensions cannot be
played. (On Macintosh computers, MP3 files can be played by
giving the extension “.MP3” after the file name consisting up a
maximum of 8 alphanumeric characters and storing the files on a
CD-R or CD-RW disc.)

• This CD player is not compatible with packet write software or
playlists.

• The time may not be displayed properly when searching or
pausing during variable bit rate playback.

• The time display cannot be switched “TOTAL REMAIN” using
the TIME button on the remote control unit.

NOTE:

• Multisession and CD-R/CD-RW discs that have not been
completely written can be played, but we recommend using
discs closed after a maximum of 10 sessions or discs that have
been completed.

• The maximum number of files and folders playable is 512 (total
of the number of folders and files). The maximum number of
folders is 256.

• Copyright-protected WMA files cannot be played. (“– – : – –” is
displayed. Use the 8/6 or 7/9 button on the main
unit (the 8 or 9 button on the remote control unit) to select
a different file.)

Holding discs

Do not touch the signal surface.

Loading discs

• Set the disc with the labeled side facing up.

• Make sure the disc tray is fully open when inserting the disc.

• Place the discs flatly, 12 cm discs in the outer tray guide (Figure 1),
8 cm discs in the inner tray guide (Figure 2).

Figure 1

Outer tray guide

12 cm discs

• Place 8 cm discs in the inner tray guide without using an adapter.

• “0 000 00:00” is displayed if no disc is loaded, if a disc that cannot
be played is loaded or if the disc is loaded upside-down.

Figure 2

Inner tray guide

8 cm discs

2

ENGLISH

ENGLISH

Getting Started Getting Started

• Only load one disc per tray at a time. Loading two or more discs per

• Do not use cracked or warped discs or discs that have been repaired

• Do not use discs on which the sticky part of cellophane tape or

• Do not get fingerprints, oil or dirt on discs.

•Take special care not to scratch discs when removing them from

• Do not bend or heat discs.

• Do not enlarge the hole at the center.

•Do not write on the labeled (printed) surface with ball-point pens,

•Water droplets may form on discs if they are moved suddenly from

• Be sure to remove discs after using them.

• Be sure to store discs in their cases to protect them from dust,

• Do not store discs in the following places:

Cautions on loading discs

tray can damage the set or scratch the discs.

with adhesive, etc.

labels is exposed or on which there are traces of where labels have
been removed. Such discs could get caught inside the player and
damage it.

Cautions on handling

their cases.

pencils, etc., or stick new labels on discs.

a cold place (outdoors for example) to a warm place, but do not try
to dry them off using a hairdryer, etc.

Cautions on storing discs

scratches, warping, etc.

1. Places exposed to direct sunlight for long periods of time

2. Dusty or humid places

3. Places exposed to heat from heating appliances, etc.

Cleaning discs

• If there are fingerprints or dirt on discs, wipe them off before using
the disc. If not the sound quality could be reduced and the sound
may be broken.

• Use a commercially available disc cleaning set or a soft cloth to clean
discs.

Gently wipe the disc from the
inside towards the outside.

NOTE:

• Do not use record spray, antistatic agents, or benzene, thinner or

other solvents.

Do not wipe with a circular motion.

About the remote control unit

Inserting the batteries

q Remove the remote control

unit’s rear cover.

w Set two R03/AAA batteries in

the battery compartment in
the indicated direction.

Notes on batteries:

• Replace the batteries with new ones if the set does not operate
even when the remote control unit is operated nearby the unit.
(The attached batteries are only for verifying operation.)

• When inserting the batteries, be sure to do so in the proper
direction, following the “<” and “>” marks in the battery
compartment.

•To prevent damage or leakage of battery fluid:

• Do not use a new battery together with an old one.

•Do not use two different types of batteries.

• Do not short-circuit, disassemble, heat or dispose of batteries

in flames.

• If the battery fluid should leak, carefully wipe the fluid off the
inside of the battery compartment and insert new batteries.

• Remove the batteries from the remote if it will not be in use for
long periods.

Operating range of the remote control unit

• Point the remote control unit at the remote sensor when operating
it.

• The remote control unit can be used from a distance of up to about
8 meters, at a horizontal angle of up to 30° with respect to the
sensor.

30°

30°

e Put the rear cover back on.

Approx. 8 m

NOTE:

• It may be difficult to operate the remote control unit if the remote

sensor is exposed to direct sunlight or strong artificial light.

3

ENGLISH

Getting Started Getting Started

!5

!3 !2 !1

!4

!0oiuytr

w

e

q

Part names and functions

For buttons not explained here, see the page indicated in parentheses ( ).

Front panel

DCM-390

DISC SKIP button

!1

Each time this button is pressed, the carousel
will rotate in a clockwise direction to the next
tray position. This allows for loading or
unloading of discs.
This button is also used to select the next disc,
in the normal play continuously.

OPEN/CLOSE button (5)

!2

•Press this button when opening.

• The drawer is opened toward the front.

•Press the button again to close the drawer.

Loading Drawer

!3

Discs can be loaded and unloaded when this
drawer is open. Do not force the drawer closed
by hand.

PHONES jack

!4

For private listening, you can connect your
headphones (commercially available)to this
jack.

Disc Trays (1 ~ 5)

!5

One disc per tray can be loaded.

Display

e

POWER switch

q

•Press once to turn the power on.

• If a disc is loaded when the power is turned on,
playback starts automatically.

Remote control sensor

w

This sensor receives the infrared light
transmitted from the wireless remote control
unit.

Display

e

REPEAT button

r

Press this button for repeated playback. The
“REPEAT” indicator appears on the display.
Three types of repeat modes are available.(
page 10)

RANDOM button

t

Press this button to begin random play.

Automatic/Manual Search Reverse button

y

(8/6)

•Press this button to return the pickup to the
beginning of the present track. Press again to
return to other tracks.

• Keep on pressing this button for more than 0.5
seconds during playback for fast reverse
search.

Automatic/Manual Search Forward button

u

(7/9)

•Press this button to move the pickup forward to
the beginning of the next track. Press again to
move ahead to other tracks.

• Keep on pressing this button for more than 0.5
seconds during playback for fast forward
search.

Stop button (2)

i

Press this button to stop playback.

Pause button (3)

o

Press this button to stop play temporarily.

Play button (1 PLAY)

!0

Press this button to play a disc.

q

Disc indicator

q

Play indicator

w

Pause indicator

e

Playing disc indicator

r

• HDCD indicator (DCM-390 only)

w

t Playing mode indicator

•

•“Windows Media®”, “Windows®”are a trademarks of Microsoft Corporation, Inc.

®

, HDCD®, High Definition Compatible Digital®and Microsoft®are either registered
trademarks or trademarks of Microsoft Corporation, Inc. in the United States and/or other countries.
HDCD system manufactured under license from Microsoft Corporation, Inc. This product is covered
by one or more of the following: In the USA: 5,479,168, 5,638,074, 5,640,161, 5,808,574, 5,838,274,
5,854,600, 5,864,311, 5,872,531, and in Australia: 669114. Other patents pending.

r

t

o!0 i u y

20-track music calender

y

Time indicator

u

Time display mode indicator

i

Track number indicator

o

Remote control signal receive indicator

!0

ENGLISH

4

ENGLISH

ENGLISH

Getting Started Getting Started

Rear panel

Remote control unit

DCM-390 only

q er tuyw

q RS-232C terminal (DCM-390 only)

This is a terminal for future system expansion.

w LINE OUT terminal

Connect these to the amplifier’s input terminal.

e REMOTE CONTROL jack

(ROOM TO ROOM IN)

This is the input connector for wired remote
control.
Consult your DENON dealer if you wish to use
this connector.

r REMOTE CONTROL jack

(ROOM TO ROOM OUT)

This is the output connector for wired remote
control.
Consult your DENON dealer if you wish to use
this connector.

t COAXIAL terminal

This terminal outputs digital data.
Connect using a 75 Ω/ohms coaxial cable
(commercially available) intended for digital
audio connections.

y OPTICAL terminal

Digital data is output in optical form from this
terminal.
Connect using an optical fiber cable
(commercially available).

u AC inlet

Connect to an AC power supply using the
included power supply cord.

Number buttons
(0 ~ 9, +10)

····················

(8, 9)

DIRECT button

···············································

PROGRAM button

···············································

DISC SELECT button

···············································

RANDOM button

············································

REPEAT button

············································

DISPLAY button

············································

Pause button (3)

···············································

Skip buttons
(8, 9)

························

(9)

(9)

(8)

(10)

(10)

(10)

(8)

(8)

OPEN/CLOSE button

··········································

(7, 8)

CLEAR button

···············································

CALL button

···············································

DISC SKIP (+/–) buttons

··········································

(7, 8)

A-B button

············································

TIME button

·················

(2, 5)

Switches the time display

Elapsed time of currently
playing track

Remaining time of
currently playing track

Remaining time of all
remaining tracks

(9)

(9)

(10)

Search buttons
(6, 7)

··························

(9)

···································

Stop button (2)

Play button (1)

··········································

• If the automatic search forward button (9), automatic search reverse button (8) or +10 button are
held in, the function of these button will be repeated.

5

ENGLISH

(8, 9, 10)

(7, 8)

Connections

R

L

R

L

B

C

OPTICAL

IN

COAXIAL

IN

NOTE:

• Do not plug in the power supply cord until all connections have been completed.

• When making connections, also refer to the operating instructions of the other components.

• Be sure to connect the left and right channels properly (left with left, right with right).

• Making connections with the power turned on could result in noise or damage the speakers.

• Bunching the power supply cords and connection cables together could result in humming or noise.

Cable indications

Connect using the connection cables shown below.

Signal directionAudio cable

Analog connections (Stereo)

A

(White)

(Red)

Digital connections (Coaxial)

B

Pin-plug cable

Audio signal

OUT IN

ENGLISH

Connections

Digital connections

CD recorder etc.

• Digital signals are output from optical terminal and coaxial terminal with parallel.

¢ When connecting the OPTICAL digital output connector with an optical

transmission cable (commercially available)

(Orange)

Coaxial cable (75 Ω/ohms pin-plug cable)

Digital connections (Optical)

C

Optical fiber cable

Analog connections

Use the included pin-plug cable to connect the left (L) and right (R) output terminal (LINE OUT) of the CD
Player to the CD, AUX or TAPE PLAY left (L) and right (R) input terminal of the amplifier.

Stereo amplifier

A

L

R

L

R

AUDIO IN

L

R

ENGLISH

Protective cap

Match the
shapes

Remove the protective cap, match the shapes then
insert firmly all the way in.

Connecting the power supply cord

6

• Store the protective cap in a safe place so as not
to lose it, and use it when not using the terminal.

AC outlet

AC 120 V, 60 Hz

NOTE:

• Insert the plugs securely. Incomplete connections
will result in the generation of noise.

• Do not unplug the power supply cord while the
set is operating.

ENGLISH

3

2

[NUMBER]

(0~9, +10)

[DISC SELECT]

[9]

1

[8]

5

DISC SKIP

<POWER>

5

DISC SKIP

12

<7/9>

<

8/6

>

3

Operation

Turning the power on

<

Press

• When a disc is loaded, playback starts automatically.

• If no disc is loaded “0 000 00:00” is displayed.

POWER

>

.

¢ To turn off the power:

Press <POWER>again.

NOTE:

•To turn off the power while a disc is playing, be sure to press 2
to stop playback before turning off the power.

Opening and closing the drawer and loading a
disc

Press 5.

1

• Make sure the drawer is completely open.

Hold the disc by the edges and place it on the disc tray. (Do not
touch the signal surface, i.e., the glossy side.)

Operation

NOTE:

•The player will not operate properly and the disc may even be
damaged if it is not set correctly.

• If your finger should get caught in the drawer when it closes,
press 5.

• Do not place any foreign objects on the disc tray, and do not
place more than one disc on the tray at a time. Otherwise
malfunction may occur.

• Do not push in the disc tray manually when the power is off as
this may cause malfunction and damage the CD player.

• Do not touch the carousel while it is turning. Also, do not turn the
carousel by hand when it is stopped. Doing so could damage it.

• Do not insert disc where indicated by arrow.
This could damage the internal mechanism in the unit.

LABEL SIDE
UP WARD

About the button names in this explanation

<>: Buttons on the main unit
[]: Buttons on the remote control unit

Button name only :

Buttons on the main unit and remote control unit

Set the disc properly in the tray according to its size.

2

• Set 8 cm discs in the center hole.

• Set 12 cm discs in the outer hole.

Press DISC SKIP.

3

The carousel turns and a disc can be loaded in the another disc
tray.
When the drawer is opened during the play mode, it is possible
to load and unload discs in all of the disc trays other than the one
whose disc is currently playing.

Press 5 again.

4

7

ENGLISH

ENGLISH

1st disc 2nd disc

4th disc5th disc

3rd disc

Operation Operation

Starting playback

Press 1.

• The drawer closes and the disc just loaded is played.

• Playback starts.

If

5 is pressed while a disc is playing, playback continues, but the

drawer opens and four discs can be replaced. The disc that can
be replaced switches when DISC SKIP is pressed.
Playback stops automatically after the last track on the disc has
been played.

To stop playback

Press 2 during playback.

• Playback stops.

Various playback functions

Playing the desired disc and desired track
[Direct play]

Press [DISC SELECT].

1

Use [NUMBER] (1 to 5) to select the disc.

2

Use [NUMBER] (0 ~ 9, +10) to select the track.

3

Example: To play the 4th track on the 3rd disc:

Press [DISC SELECT] [3] [4].

Example: To play the 12th track on the 5th disc:

Press [DISC SELECT] [5] [+10] [2].

Playback begins from the number of the disc and

4

track selected.

To move to the next disc during playback

To pause playback

Use this function to stop playback temporarily, and later resume
playback from that point.

Press 3 during playback.

• Playback pauses.

¢ To resume playback:

Press 1.

Automatic search

¢ Moving ahead to the beginning of the next track

(file):

Press [9] or

• The pickup will advance to the beginning of the next track and
playback will continue. Pressing the button several times will
forward the pickup the corresponding number tracks.

Normal playback resumes when you release your finger from the
button.

<

7/9

>

during playback.

Press DISC SKIP.

1

The carousel in the drawer turns and the disc on the next tray is
played.

• When [DISC SKIP–] on the remote control unit is pressed, the
carousel turns in the opposite direction and the previous disc is
played.

¢ Moving back to the beginning of the current track

(file):

Press [8] or

• The pickup will advance to the beginning of the next track and
playback will continue. Pressing the button several times will
forward the pickup the corresponding number tracks.

<

8/6

>

during playback.

8

ENGLISH

ENGLISH

[NUMBER]

(0~9, +10)

[DISC SELECT]

[DISPLAY]

[DIRECT]

RANDOM

REPEAT

[7]

[6]

[

A-B

]

[

CALL

]

[

CLEAR

]

[

PROGRAM

]

5

1

1

<7/9>

<

8/6

>

5

RANDOMREPEAT

Operation Operation

Manual search

Programmed play

Use this function to skip forward or backward while listening to the
sound.

¢ Searching forward:

Press [7] or press and hold

<

7/9

>

during

playback.

•“ ”is displayed if the end of the last track is reached during
manual searching. If this happens, use [6] or <8/6> to
turn the display off.

¢ Searching backward:

Press [6] or press and hold

<

8/6

>

during

playback.

•“ ” is displayed if the beginning of the first track is reached
during manual searching. If this happens, use [7] or

<7/9> to turn the display off.

NOTE:

• The sound may be interrupted momentarily when resuming
normal playback from the manual search mode. This is not a
malfunction.

You can play certain tracks on the loaded discs in any order.
Up to 32 tracks can be set in a program.

Press [PROGRAM].

1

• The “PROGRAM” indicator lights.

Press [DISC SELECT], [NUMBER] to select the disc to

2

be programmed.

Example: To program the 3rd track on the 2nd disc and the 12 track

on the 5th disc:
Press [PROGRAM] [DISC SELECT] [2] [3], [DISC SELECT] [5]
[+10] [2].

Press 1.

3

• The tracks are played in the programmed order.

¢ Checking the programmed tracks:

Press [CALL].
The tracks are displayed in the programmed order each time the
button is pressed.

¢ Clearing tracks from the program:

Press [CLEAR] while the track you want to clear is displayed during
the “Checking the programmed tracks” operation above.

Button name only :

About the button names in this explanation

<>: Buttons on the main unit
[]: Buttons on the remote control unit

Buttons on the main unit and remote control unit

¢ Stopping programmed playback:

Press [DIRECT] or press 5 to open the disc tray.

•Tracks on a disc not loaded can also be programmed, but if you try
to play that disc, the microprocessor detects that it is not loaded and
the following disc is played automatically.

• When programming, do not program a track number which is not
recorded on the disc. If such a number is programmed by mistake,
the player ignore the program.

•For programmed playback, the remaining time for the program is
only displayed when the programmed tracks are all on the same
disc.
“– – : – –” is displayed when tracks on more than one disc are
programmed.

• In the case that the total playing time of programmed tracks
becomes more than 99:59, “– – : – –” is displayed.

9

ENGLISH
