Instructions for use
Mode d’emploi
Gebrauchsanleitung
Istruzioni per l’uso
Gebruiksaanwijzingen
Instrucciones para el uso
Instruções para a utilização
Odhgive" crhvsh"
IRONING SYSTEM WITH PRESSURIZED BOILER
SYSTEME DE REPASSAGE AVEC CHAUDIERE SOUS PRESSION
BÜGELSTATION MIT DRUCK-DAMPFKAMMER
SISTEMA STIRANTE CON CALDAIA IN PRESSIONE
STRIJKSYSTEEM MET VERWARMINGSELEMENT ONDER DRUK
SISTEMA PARA PLANCHAR CON CALDERA BAJO PRESION
SISTEMA PARA PASSAR ROUPAS COM CALDEIRA PRESSURIZADA
ATMOSYSTHMAMELEBHTAUPOPIESH
INTRO 3-06-2002 16:51 Pagina 1
A) If your appliance comes fitted with a plug, it will incorporate a 13
Amp fuse. If it does not fit your socket, the plug should be cut off
from the mains lead, and an appropriate plug fitted, as below.
WARNING: Very carefully dispose of the cut off plug after removing the fuse: do not insert in a 13 Amp socket elsewhere in the
house as this could cause a shock hazard.
With alternative plugs not incorporating a fuse, the circuit must
be protected by a 15 Amp fuse.
If the plug is a moulded-on type, the fuse cover must be re-fitted
when changing the fuse using a 13 Amp Asta approved fuse to
BS 1362. In the event of losing the fuse cover, the plug must NOT
be used until a replacement fuse cover can be obtained from your
nearest electrical dealer. The colour of the correct replacement
fuse cover is that as marked on the base of the plug.
B) If your appliance is not fitted with a plug, please follow the
instructions provided below:
WARNING - THIS APPLIANCE MUST BE EARTHED
IMPORTANT
The wires in the mains lead are coloured in accordance with the following code:
Green and yellow: Earth
Blue: Neutral
Brown: Live
As the colours of the wires in the mains lead may not correspond
with the coloured markings identifying the terminals in your plug, proceed as follows:
The green and yellow wire must be connected to the terminal in the
plug marked with the letter E or the earth symbol or coloured
green or green and yellow.
The blue wire must be connected to the terminal marked with the letter
N or coloured black.
The brown wire must be connected to the terminal marked with the letter L or coloured red.
ELECTRICAL CONNECTION (UK ONLY)
GB F D I NL E P GR
Acetate,
acrylic,
nylon,
polyester,
rayon
Acétate,
acrylique,
nylon,
polyester,
rayonne
Acetat,
Acrylsstoffe
Nylon,
Polyester,
Rayon
Acetato,
acrilico,
nylon,
poliestere,
rayon
Acetaat,
acryl,
nylon,
polyester,
rayon
Acetato,
acrílico,
nylon,
poliéster,
rayón
Acetato,
acrílico,
nylon,
poliester,
rayon
S>>>unqetikav,
Akrulikav,
Navilon,
Poluevster,
Raigiovn
Wool,
cotto, fine
linen
Laine,
coton, lin
fin
Wolle,
Baumwolle,
feines
Leinen
Lana,
cotone, lino
fino
Wol,
katoen, fijn
linnen
Lana,
algodón,
lino fino
Lã,
algodão,
linho fino
Mavllina,
bambakerav
Lepta linav
Cotton,
linen,
starched,
clothes
Coton, lin,
tissus
humectés
amidonnés
Baumwolle,
Leinen,
gestärkte
Stoffe
Coton, lino,
tessuti
inamidati
Katoen,
linnen,
gestijfde
stoffe
Algodón,
lino, tejidos
almidonados
Algodão,
linho,
tecidos com
goma
Bambakerav,
Linav,
Bregmevna
ufavsmata
Silk Soie Seide Seta Zijde Seda Seda
Metaxwtav
•
••
••
•••
FIG. 3
FIG. 2
FIG. 1
