Dell P17E User Manual

Inspiron 17/17R
Owner’s Manual
Computer model: Inspiron 3721/5721
Regulatory model: P17E
Regulatory type: P17E001
Notes, Cautions, and Warnings
NOTE: A NOTE indicates important information that helps you make better
CAUTION: A CAUTION indicates potential damage to hardware or loss of
data if instructions are not followed.
WARNING: A WARNING indicates a potential for property damage,
personal injury, or death.
____________________
© 2012 Dell Inc.
â„¢
Trademarks used in this text: Dell Microsoft trademarks of Microsoft Corporation in the United States and/or other countries; Bluetooth is a registered trademark owned by Bluetooth SIG, Inc. and is used by Dell under license.
2012 - 12 Rev. A00
®
, Windows®, and the Windows start button logo are either trademarks or registered
, the DELL logo, and Inspironâ„¢ are trademarks of Dell Inc.;
®
Contents
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Turn Off Your Computer and Connected Devices. . . . . 9
Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . 10
Recommended Tools. . . . . . . . . . . . . . . . . . . . . . . 10
After Working Inside Your Computer . . . . . . . . . . 11
Removing the Battery . . . . . . . . . . . . . . . . . . . . . . 12
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Replacing the Battery . . . . . . . . . . . . . . . . . . . . . . 13
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Removing the Optical Drive . . . . . . . . . . . . . . . . . 14
Prerequisites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Replacing the Optical Drive . . . . . . . . . . . . . . . . . 16
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Removing the Keyboard . . . . . . . . . . . . . . . . . . . . 17
Prerequisites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Replacing the Keyboard . . . . . . . . . . . . . . . . . . . . 19
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Removing the Base Cover . . . . . . . . . . . . . . . . . . . 20
Prerequisites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Contents | 3
Replacing the Base Cover . . . . . . . . . . . . . . . . . . . 21
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Removing the Memory Module(s). . . . . . . . . . . . . 22
Prerequisites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Replacing the Memory Module(s). . . . . . . . . . . . . 23
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Removing the Hard Drive . . . . . . . . . . . . . . . . . . . 24
Prerequisites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Replacing the Hard Drive. . . . . . . . . . . . . . . . . . . . 27
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Removing the Coin-Cell Battery. . . . . . . . . . . . . . 28
Prerequisites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Replacing the Coin-Cell Battery . . . . . . . . . . . . . . 29
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Removing the Palm-Rest. . . . . . . . . . . . . . . . . . . . 30
Prerequisites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Replacing the Palm-Rest . . . . . . . . . . . . . . . . . . . . 33
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
4 | Contents
Removing the Wireless Mini-Card . . . . . . . . . . . . 34
Prerequisites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Replacing the Wireless Mini-Card . . . . . . . . . . . . 36
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Removing the I/O Board . . . . . . . . . . . . . . . . . . . . 37
Prerequisites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Replacing the I/O Board . . . . . . . . . . . . . . . . . . . . 38
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Removing the System Board . . . . . . . . . . . . . . . . . 39
Prerequisites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Replacing the System Board . . . . . . . . . . . . . . . . . 43
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Removing the Fan . . . . . . . . . . . . . . . . . . . . . . . . . 45
Prerequisites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Replacing the Fan. . . . . . . . . . . . . . . . . . . . . . . . . . 47
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Removing the Cooling Assembly . . . . . . . . . . . . . 48
Prerequisites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Contents | 5
Replacing the Cooling Assembly . . . . . . . . . . . . . 50
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Removing the Hard-Drive Interposer Board . . . . 51
Prerequisites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Replacing the Hard-Drive Interposer Board . . . . 53
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Removing the Speakers . . . . . . . . . . . . . . . . . . . . . 54
Prerequisites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Replacing the Speakers . . . . . . . . . . . . . . . . . . . . . 56
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Removing the Display Assembly . . . . . . . . . . . . . . 57
Prerequisites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Replacing the Display Assembly . . . . . . . . . . . . . . 59
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Removing the Display Bezel . . . . . . . . . . . . . . . . . 60
Prerequisites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Replacing the Display Bezel . . . . . . . . . . . . . . . . . 62
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
6 | Contents
Removing the Display Hinges . . . . . . . . . . . . . . . . 63
Prerequisites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Replacing the Display Hinges . . . . . . . . . . . . . . . . 65
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Removing the Display Panel . . . . . . . . . . . . . . . . . 66
Prerequisites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Replacing the Display Panel . . . . . . . . . . . . . . . . . 69
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Removing the Camera Module . . . . . . . . . . . . . . . 70
Prerequisites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Replacing the Camera Module . . . . . . . . . . . . . . . 72
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Removing the Power-Adapter Port . . . . . . . . . . . 73
Prerequisites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Replacing the Power-Adapter Port . . . . . . . . . . . 75
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Postrequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Flashing the BIOS . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Contents | 7
8 | Contents

Before You Begin

Turn Off Your Computer and Connected Devices

CAUTION: To avoid losing data, save and close all open files and exit all open
programs before you turn off your computer.
1 Save and close all open files and exit all open programs. 2 Shut down your computer.
Windows 8:
a Point your mouse pointer to the upper-right or lower-right corner of the
screen to open the Charms sidebar.
b In the Charms sidebar, click Settings→ Power→ Shut down.
Windows 7:
Click Start and click Shut down.
Microsoft Windows shuts down and then the computer turns off.
NOTE: If you are using a different operating system, see the documentation
of your operating system for shut-down instructions.
3 Disconnect your computer and all attached devices from their electrical outlets.
4 Disconnect all telephone cables, network cables, and attached devices from your
computer.
5 After you unplug all the cables from the computer, press and hold the power
button for 5 seconds to ground the system board.
Before You Begin | 9

Safety Instructions

Use the following safety guidelines to protect your computer from potential damage and ensure your personal safety.
WARNING: Before working inside your computer, read the safety information
that shipped with your computer. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.
WARNING: Disconnect all power sources before opening the computer cover or
panels. After you finish working inside the computer, replace all covers, panels, and screws before connecting to the power source.
CAUTION: To avoid damaging the computer, ensure that the work surface is flat
and clean.
CAUTION: To avoid damaging the components and cards, handle them by their
edges and avoid touching pins and contacts.
CAUTION: Only a certified service technician is authorized to remove the
computer cover and access any of the components inside the computer. See the safety instructions for complete information about safety precautions, working inside your computer, and protecting against electrostatic discharge.
CAUTION: Before touching anything inside your computer, ground yourself by
touching an unpainted metal surface, such as the metal at the back of the computer. While you work, periodically touch an unpainted metal surface to dissipate static electricity, which could harm internal components.
CAUTION: When you disconnect a cable, pull on its connector or on its pull-tab,
not on the cable itself. Some cables have connectors with locking tabs or thumb-screws that you must disengage before disconnecting the cable. When disconnecting cables, keep them evenly aligned to avoid bending any connector pins. When connecting cables, ensure that the connectors and ports are correctly oriented and aligned.
CAUTION: To disconnect a network cable, first unplug the cable from your
computer and then unplug the cable from the network device.
CAUTION: Press and eject any installed card from the media-card reader.

Recommended Tools

The procedures in this document may require the following tools:
• Phillips screwdriver
• Plastic scribe
10 | Before You Begin

After Working Inside Your Computer

After you complete the replacement procedures, ensure the following:
• Replace all screws and ensure that no stray screws remain inside your computer.
• Connect any external devices, cables, cards, and any other part(s) you removed
before working on your computer.
• Connect your computer and all attached devices to their electrical outlets.
CAUTION: Before turning on your computer, replace all screws and ensure
that no stray screws remain inside the computer. Failure to do so may damage your computer.
After Working Inside Your Computer | 11

Removing the Battery

1
2
WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Procedure

1 Close the display and turn the computer over.
2 Slide the battery latches to the unlock position. You hear a click when the battery is
unlocked.
3 Lift and remove the battery off the computer base.
1 battery latches (2) 2 battery
12 | Removing the Battery

Replacing the Battery

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Procedure

Align the tabs on the battery with the slots on the battery bay and snap the battery into place.
Replacing the Battery | 13

Removing the Optical Drive

1
2
WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Prerequisites

Remove the battery. See "Removing the Battery" on page 12.

Procedure

1 Remove the screw that secures the optical-drive assembly to the computer base.
2 Using your fingertips, slide the optical-drive assembly out of the optical-drive bay.
1 optical-drive assembly 2 screw
14 | Removing the Optical Drive
3 Remove the screw that secures the optical-drive bracket to the
3
2
4
1
optical-drive assembly and remove the optical-drive bracket.
4 Carefully pull the optical-drive bezel and remove it from the optical drive.
1 optical-drive bezel 2 optical drive
3 optical-drive bracket 4 screw
Removing the Optical Drive | 15

Replacing the Optical Drive

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Procedure

1 Align the tabs on the optical-drive bezel with the slots on the optical drive and snap
the optical-drive bezel into place.
2 Align the screw hole on the optical-drive bracket with the screw hole on
the optical-drive assembly and replace the screw that secures the optical-drive bracket to the optical-drive assembly.
3 Slide the optical-drive assembly into the optical-drive bay and ensure that the
screw hole on the optical-drive bracket aligns with the screw hole on computer base.
4 Replace the screw that secures the optical-drive assembly to the computer base.

Postrequisites

Replace the battery. See "Replacing the Battery" on page 13.
16 | Replacing the Optical Drive

Removing the Keyboard

11
2
3
WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Prerequisites

Remove the battery. See "Removing the Battery" on page 12.

Procedure

1 Open the display as far as possible.
2 Using a plastic scribe, pry the keyboard from the tabs on the palm-rest.
1 tabs (4) 2 plastic scribe
3keyboard
Removing the Keyboard | 17
3 Turn the keyboard over and place it on the palm-rest.
1
2
3
4
4 Lift the connector latch and disconnect the keyboard cable from the
keyboard-cable connector.
5 Lift the keyboard off the palm-rest.
1 keyboard cable 2 connector latch
3 keyboard 4 palm-rest
18 | Removing the Keyboard

Replacing the Keyboard

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Procedure

1 Slide the keyboard cable into the keyboard-cable connector and press down on the
connector latch to secure the cable.
2 Slide the tabs at the bottom of the keyboard into the slots on the palm-rest and
place the keyboard on the palm-rest.
3 Gently press around the edges of the keyboard to secure the keyboard under the
tabs on the palm-rest.
4 Replace the screws that secure the keyboard to the computer base.

Postrequisites

Replace the battery. See "Replacing the Battery" on page 13.
Replacing the Keyboard | 19

Removing the Base Cover

1
2
WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Prerequisites

Remove the battery. See "Removing the Battery" on page 12.

Procedure

1 Loosen the captive screws that secure the base cover to the computer base.
2 Using your fingertips, lift the base cover out of the slots on the computer base.
1 captive screws (2) 2 base cover
20 | Removing the Base Cover

Replacing the Base Cover

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Procedure

1 Slide the tabs on the base cover into the slots on the computer base and snap the
base cover into place.
2 Tighten the captive screws that secure the base cover to the computer base.

Postrequisites

Replace the battery. See "Replacing the Battery" on page 13.
Replacing the Base Cover | 21

Removing the Memory Module(s)

1
3
2
WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Prerequisites

1 Remove the battery. See "Removing the Battery" on page 12.
2 Remove the base cover. See "Removing the Base Cover" on page 20.

Procedure

1 Use your fingertips to carefully spread apart the securing-clips on each end of the
memory-module connector until the memory module pops up.
2 Remove the memory module from the memory-module connector.
1 securing-clips (2) 2 memory-module connector
3memory module
22 | Removing the Memory Module(s)

Replacing the Memory Module(s)

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Procedure

1 Align the notch on the memory module with the tab on the
memory-module connector.
2 Slide the memory module firmly, at a 45-degree angle into the connector,
and press the memory module down until it clicks into place.
NOTE: If you do not hear the click, remove the memory module and reinstall it.

Postrequisites

1 Replace the base cover. See "Replacing the Base Cover" on page 21.
2 Replace the battery. See "Replacing the Battery" on page 13.
Replacing the Memory Module(s) | 23

Removing the Hard Drive

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.
CAUTION: To avoid data loss, do not remove the hard drive while the computer is
in Sleep or On state.
CAUTION: Hard drives are extremely fragile. Exercise care when handling the
hard drive.

Prerequisites

1 Remove the battery. See "Removing the Battery" on page 12.
2 Remove the base cover. See "Removing the Base Cover" on page 20.
24 | Removing the Hard Drive

Procedure

1
2
3
1 Remove the screws that secure the hard-drive assembly to the computer base.
2 Using the pull tab, slide the hard-drive assembly towards the side of the computer
to disconnect the hard-drive assembly from the system board.
3 Using the pull tab, lift the hard-drive assembly off the computer base.
1 pull-tab 2 hard-drive assembly
3screws (3)
Removing the Hard Drive | 25
4 Remove the screws that secure the hard-drive bracket to the hard drive.
1
2
3
5 Using the pull-tab, lift the hard-drive bracket off the hard drive.
1 screws (4) 2 hard-drive bracket
3 hard drive
26 | Removing the Hard Drive

Replacing the Hard Drive

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.
CAUTION: Hard drives are extremely fragile. Exercise care when handling the
hard drive.

Procedure

1 Align the screw holes on the hard-drive bracket with the screw holes on
the hard drive.
2 Replace the screws that secure the hard-drive bracket to the hard drive. 3 Place the hard-drive assembly in the hard-drive bay. 4 Slide the hard-drive assembly towards the connector to connect the hard-drive
assembly to the system board.
5 Replace the screws that secure the hard-drive assembly to the computer base.

Postrequisites

1 Replace the base cover. See "Replacing the Base Cover" on page 21.
2 Replace the battery. See "Replacing the Battery" on page 13.
Replacing the Hard Drive | 27

Removing the Coin-Cell Battery

1
2
3
WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.
CAUTION: Removing the coin-cell battery resets the BIOS settings to default.
It is recommended that you note the BIOS settings before removing the coin-cell battery.

Prerequisites

1 Remove the battery. See "Removing the Battery" on page 12.
2 Remove the base cover. See "Removing the Base Cover" on page 20.

Procedure

Using a plastic scribe, gently pry out the coin-cell battery out of the battery socket on the system board.
1 plastic scribe 2 coin-cell battery
3 battery socket
28 | Removing the Coin-Cell Battery

Replacing the Coin-Cell Battery

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.
WARNING: The battery may explode if installed incorrectly. Replace the battery
only with the same or equivalent type. Discard used batteries according to the manufacturer’s instructions.

Procedure

With the positive-side facing up, snap the coin-cell battery into the battery socket on the system board.

Postrequisites

1 Replace the base cover. See "Replacing the Base Cover" on page 21.
2 Replace the battery. See "Replacing the Battery" on page 13.
Replacing the Coin-Cell Battery | 29

Removing the Palm-Rest

1
WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Prerequisites

1 Remove the battery. See "Removing the Battery" on page 12. 2 Remove the base cover. See "Removing the Base Cover" on page 20. 3 Remove the keyboard. See "Removing the Keyboard" on page 17.

Procedure

1 Remove the screws that secure the palm-rest to the computer base.
1screws (12)
30 | Removing the Palm-Rest
2 Turn the computer over and open the display as far as possible.
1
2
3
4
3 Lift the connector latches and, using the pull-tabs, disconnect the power-button
cable and touchpad cable from the system board.
1 power-button cable 2 connector latches (2)
3 pull-tab 4 touchpad cable
Removing the Palm-Rest | 31
4 Remove the screws that secure the palm-rest to the computer base.
1
2
3
5 Using a plastic scribe, gently lift and release the tabs on the palm-rest from the slots
on the computer base.
CAUTION: Separate the palm-rest from the display assembly carefully to avoid
damage to the display assembly.
6 Lift the palm-rest off the computer base.
1 screws (5) 2 palm-rest
3plastic scribe
32 | Removing the Palm-Rest

Replacing the Palm-Rest

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Procedure

1 Align the palm-rest to the computer base. 2 Press down on the edges of the palm-rest to snap it into place. 3 Replace the screws that secure the palm-rest to the computer base. 4 Slide the touchpad cable and the power-button cable into the system-board
connectors and press down on the connector latches to secure the cables.
5 Close the display and turn the computer over. 6 Replace the screws that secure the palm-rest to the computer base.

Postrequisites

1 Replace the keyboard. See "Replacing the Keyboard" on page 19. 2 Replace the base cover. See "Replacing the Base Cover" on page 21. 3 Replace the battery. See "Replacing the Battery" on page 13.
Replacing the Palm-Rest | 33

Removing the Wireless Mini-Card

1
3
2
WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Prerequisites

1 Remove the battery. See "Removing the Battery" on page 12. 2 Remove the base cover. See "Removing the Base Cover" on page 20. 3 Remove the keyboard. See "Removing the Keyboard" on page 17. 4 Remove the palm-rest. See "Removing the Palm-Rest" on page 30.

Procedure

1 Disconnect the antenna cables from the wireless mini-card. 2 Remove the screw that secures the wireless mini-card to the system board.
1 screw 2 antenna cables (2)
3 wireless mini-card
34 | Removing the Wireless Mini-Card
3 Slide and remove the wireless mini-card out of the mini-card connector.
1
2
1 wireless mini-card 2 mini-card connector
Removing the Wireless Mini-Card | 35

Replacing the Wireless Mini-Card

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Procedure

CAUTION: To avoid damage to the wireless mini-card, ensure that no cables are
placed under the wireless mini-card.
1 Align the notch on the wireless mini-card with the tab on the mini-card connector. 2 Insert the wireless mini-card at a 45-degree angle into the mini-card connector. 3 Press the other end of the wireless mini-card down and replace the screw that
secures the wireless mini-card to the system board.
4 Connect the antenna cables to the wireless mini-card.
The following table provides the antenna cable color schemes for the wireless
mini-card supported by your computer.
Connectors on the wireless mini-card Antenna cable color schemes
WLAN + Bluetooth (2 cables)
Main WLAN + Bluetooth (white triangle)
Auxiliary WLAN + Bluetooth (black triangle)
white
black

Postrequisites

1 Replace the palm-rest. See "Replacing the Palm-Rest" on page 33. 2 Replace the keyboard. See "Replacing the Keyboard" on page 19. 3 Replace the base cover. See "Replacing the Base Cover" on page 21. 4 Replace the battery. See "Replacing the Battery" on page 13.
36 | Replacing the Wireless Mini-Card

Removing the I/O Board

1 23
4
5
WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Prerequisites

1 Remove the battery. See "Removing the Battery" on page 12. 2 Remove the base cover. See "Removing the Base Cover" on page 20. 3 Remove the keyboard. See "Removing the Keyboard" on page 17. 4 Remove the palm-rest. See "Removing the Palm-Rest" on page 30.

Procedure

1 Remove the screw that secures the I/O board to the computer base. 2 Lift the connector latch and, using the pull-tab, disconnect the I/O-board cable
from the system board.
3 Peel the I/O board cable from the computer base. 4 Lift the I/O board along with its cable off the computer base.
1 connector latch 2 pull-tab
3 I/O board cable 4 screw
5I/O board
Removing the I/O Board | 37

Replacing the I/O Board

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Procedure

1 Use the alignment posts on the computer base to place the I/O board in position. 2 Replace the screw that secures the I/O board to the computer base. 3 Adhere the I/O board cable to the computer base. 4 Slide the I/O-board cable into the I/O-board-cable connector and press down on
the connector latch to secure the cable.

Postrequisites

1 Replace the palm-rest. See "Replacing the Palm-Rest" on page 33. 2 Replace the keyboard. See "Replacing the Keyboard" on page 19. 3 Replace the base cover. See "Replacing the Base Cover" on page 21. 4 Replace the battery. See "Replacing the Battery" on page 13.
38 | Replacing the I/O Board

Removing the System Board

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.
NOTE: Your computer’s Service Tag is stored in the system board. You must enter
the Service Tag in system setup after you replace the system board.
NOTE: Before disconnecting the cables from the system board, note the location
of the connectors so that you can reconnect them correctly after you replace the system board.

Prerequisites

1 Remove the battery. See "Removing the Battery" on page 12. 2 Follow the instructions from step 1 to step 2 in "Removing the Optical Drive" on
page 14.
3 Remove the base cover. See "Removing the Base Cover" on page 20. 4 Remove the memory module(s). See "Removing the Memory Module(s)" on
page 22.
5 Remove the coin-cell battery. See "Removing the Coin-Cell Battery" on page 28. 6 Follow the instructions from step 1 to step 3 in "Removing the Hard Drive" on
page 24.
7 Remove the keyboard. See "Removing the Keyboard" on page 17. 8 Remove the palm-rest. See "Removing the Palm-Rest" on page 30. 9 Remove the wireless Mini-Card. See "Removing the Wireless Mini-Card" on
page 34.
Removing the System Board | 39

Procedure

1
3
2
1 Disconnect the power-adapter-port cable and the speaker cable from the
system board.
2 Peel the mylar sleeve from the system board.
1 power-adapter-port cable 2 speaker cable
3mylar sleeve
40 | Removing the System Board
3 Peel the tape that secures the display cable to the system board and disconnect the
2
3
4
5
1
display cable from the system board.
4 Lift the connector latch and, using the pull-tab, disconnect the I/O-board cable
from the system board.
1 Display cable 2 tape
3 I/O-board cable 4 pull-tab
5 connector latch
Removing the System Board | 41
5 Remove the screws that secure the system board to the computer base.
1
2
6 Lift the system board at an angle and release the system-board ports from the slots
on the computer base.
7 Lift the system-board assembly off the computer base. 8 Remove the hard-drive interposer board. See "Removing the Hard-Drive Interposer
Board" on page 51
1 screws (5) 2 system board
9 Turn the system board over.
10 Remove the fan. See "Removing the Fan" on page 45.
11 Remove the cooling assembly. See "Removing the Cooling Assembly" on page 48.
42 | Removing the System Board

Replacing the System Board

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.
NOTE: Your computer’s Service Tag is stored in the system board. You must enter
the Service Tag in the system setup after you replace the system board.

Procedure

1 Replace the cooling assembly. See "Replacing the Cooling Assembly" on page 50. 2 Replace the fan. See "Replacing the Fan" on page 47. 3 Turn the system board over. 4 Replace the hard-drive interposer board. See "Replacing the Hard-Drive Interposer
Board" on page 53.
5 Ease the system-board ports into the slots on the computer base and align the
screw holes on the system board with the screw holes on the computer base.
6 Replace the screw that secures the system board to the computer base. 7 Adhere the mylar sleeve to the system board. 8 Connect the display cable to the system board and adhere the tape to the
system board.
9 Slide the I/O-board cable into the I/O-board cable connector and press down on
the connector latch to secure the cable.
10 Connect the power-adapter-port cable and the speaker cable to the
system board.
Replacing the System Board | 43

Postrequisites

1 Replace the wireless Mini-Card. See "Replacing the Wireless Mini-Card" on page 36. 2 Replace the palm-rest. See "Replacing the Palm-Rest" on page 33. 3 Replace the keyboard. See "Replacing the Keyboard" on page 19. 4 Follow the instructions from step 3 to step 5 in "Replacing the Hard Drive" on
page 27.
5 Replace the coin-cell battery. See "Replacing the Coin-Cell Battery" on page 29. 6 Replace the memory module(s). See "Replacing the Memory Module(s)" on page 23. 7 Replace the base cover. See "Replacing the Base Cover" on page 21. 8 Follow the instructions from step 3 to step 4 in "Replacing the Optical Drive" on
page 16.
9 Replace the battery. See "Replacing the Battery" on page 13.
44 | Replacing the System Board

Removing the Fan

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Prerequisites

1 Remove the battery. See "Removing the Battery" on page 12. 2 Follow the instructions from step 1 to step 2 in "Removing the Optical Drive" on
page 14.
3 Follow the instructions from step 1 to step 3 in "Removing the Hard Drive" on
page 24.
4 Remove the base cover. See "Removing the Base Cover" on page 20. 5 Remove the keyboard. See "Removing the Keyboard" on page 17. 6 Remove the palm-rest. See "Removing the Palm-Rest" on page 30. 7 Follow the instructions from step 3 to step 9 in "Removing the System Board" on
page 39.
Removing the Fan | 45

Procedure

1
2
3
1 Disconnect the fan cable from the system board. 2 Remove the screw that secures the fan to the system board. 3 Lift the fan along with the cable, off the computer base.
1fan cable 2screw
3fan
46 | Removing the Fan

Replacing the Fan

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Procedure

1 Place the fan on the computer base and replace the screw that secures the fan to
the computer base.
2 Connect the fan cable to the system board.

Postrequisites

1 Follow the instructions from step 3 to step 10 in "Replacing the System Board" on
page 43.
2 Replace the palm-rest. See "Replacing the Palm-Rest" on page 33. 3 Replace the keyboard. See "Replacing the Keyboard" on page 19. 4 Replace the base cover. See "Replacing the Base Cover" on page 21. 5 Follow the instructions from step 3 to step 4 in "Replacing the Optical Drive" on
page 16.
6 Follow the instructions from step 3 to step 5 in "Replacing the Hard Drive" on
page 27.
7 Replace the battery. See "Replacing the Battery" on page 13.
Replacing the Fan | 47

Removing the Cooling Assembly

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Prerequisites

1 Remove the battery. See "Removing the Battery" on page 12. 2 Follow the instructions from step 1 to step 2 in "Removing the Optical Drive" on
page 14.
3 Follow the instructions from step 1 to step 3 in "Removing the Hard Drive" on
page 24.
4 Remove the base cover. See "Removing the Base Cover" on page 20. 5 Remove the keyboard. See "Removing the Keyboard" on page 17. 6 Remove the palm-rest. See "Removing the Palm-Rest" on page 30. 7 Follow the instructions from step 3 to step 9 in "Removing the System Board" on
page 39.
48 | Removing the Cooling Assembly

Procedure

2
1
1 In sequential order (indicated on the heat-sink), remove the screws that secure the
cooling assembly to the system board.
2 Lift the cooling assembly off the system board.
1 cooling assembly 2 screws (6)
Removing the Cooling Assembly | 49

Replacing the Cooling Assembly

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Procedure

1 Clean the grease from the bottom of the cooling assembly and reapply it. 2 Align the screw holes on the cooling assembly with the screw holes on the
system board.
3 In sequential order (indicated on the heat-sink), replace the screws that secure the
cooling assembly to the system board

Postrequisites

1 Follow the instructions from step 3 to step 10 in "Replacing the System Board" on
page 43.
2 Replace the palm-rest. See "Replacing the Palm-Rest" on page 33. 3 Replace the keyboard. See "Replacing the Keyboard" on page 19. 4 Replace the base cover. See "Replacing the Base Cover" on page 21. 5 Follow the instructions from step 3 to step 4 in "Replacing the Optical Drive" on
page 16.
6 Follow the instructions from step 3 to step 5 in "Replacing the Hard Drive" on
page 27.
7 Replace the battery. See "Replacing the Battery" on page 13.
50 | Replacing the Cooling Assembly

Removing the Hard-Drive Interposer Board

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Prerequisites

1 Remove the battery. See "Removing the Battery" on page 12. 2 Follow the instructions from step 1 to step 2 in "Removing the Optical Drive" on
page 14.
3 Follow the instructions from step 1 to step 3 in "Removing the Hard Drive" on
page 24.
4 Remove the base cover. See "Removing the Base Cover" on page 20. 5 Remove the keyboard. See "Removing the Keyboard" on page 17. 6 Remove the palm-rest. See "Removing the Palm-Rest" on page 30. 7 Follow the instructions from step 3 to step 9 in "Removing the System Board" on
page 39.
Removing the Hard-Drive Interposer Board | 51

Procedure

1
2
1 Remove the screws that secure the hard-drive interposer board to the
system board.
2 Disconnect the hard-drive interposer board from the system board.
1 screws (2) 2 hard-drive interposer board
52 | Removing the Hard-Drive Interposer Board

Replacing the Hard-Drive Interposer Board

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Procedure

1 Connect the hard-drive interposer board to the system board. 2 Replace screws that secure the hard-drive interposer board to the system board.

Postrequisites

1 Follow the instructions from step 3 to step 10 in "Replacing the System Board" on
page 43.
2 Replace the palm-rest. See "Replacing the Palm-Rest" on page 33. 3 Replace the keyboard. See "Replacing the Keyboard" on page 19. 4 Replace the base cover. See "Replacing the Base Cover" on page 21. 5 Follow the instructions from step 3 to step 4 in "Replacing the Optical Drive" on
page 16.
6 Follow the instructions from step 3 to step 5 in "Replacing the Hard Drive" on
page 27.
7 Replace the battery. See "Replacing the Battery" on page 13.
Replacing the Hard-Drive Interposer Board | 53

Removing the Speakers

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Prerequisites

1 Remove the battery. See "Removing the Battery" on page 12. 2 Follow the instructions from step 1 to step 2 in "Removing the Optical Drive" on
page 14.
3 Follow the instructions from step 1 to step 3 in "Removing the Hard Drive" on
page 24.
4 Remove the base cover. See "Removing the Base Cover" on page 20. 5 Remove the keyboard. See "Removing the Keyboard" on page 17. 6 Remove the palm-rest. See "Removing the Palm-Rest" on page 30. 7 Follow the instructions from step 3 to step 7 in "Removing the System Board" on
page 39.
54 | Removing the Speakers

Procedure

1
2
3
1 Remove the screws that secure the speakers to the computer base. 2 Note the speaker-cable routing and remove the cable from its routing guides. 3 Lift the speakers, along with the speaker cable, off the computer base.
1 screws (4) 2 speaker cable
3speakers (2)
Removing the Speakers | 55

Replacing the Speakers

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Procedure

1 Using the alignment posts on the computer base, place the speakers in position. 2 Route the speakers cable through the routing guides on the computer base. 3 Replace the screws that secure the speakers to the computer base.

Postrequisites

1 Follow the instructions from step 3 to step 10 in "Replacing the System Board" on
page 43.
2 Replace the palm-rest. See "Replacing the Palm-Rest" on page 33. 3 Replace the keyboard. See "Replacing the Keyboard" on page 19. 4 Replace the base cover. See "Replacing the Base Cover" on page 21. 5 Follow the instructions from step 3 to step 4 in "Replacing the Optical Drive" on
page 16.
6 Follow the instructions from step 3 to step 5 in "Replacing the Hard Drive" on
page 27.
7 Replace the battery. See "Replacing the Battery" on page 13.
56 | Replacing the Speakers

Removing the Display Assembly

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Prerequisites

1 Remove the battery. See "Removing the Battery" on page 12. 2 Follow the instructions from step 1 to step 2 in "Removing the Optical Drive" on
page 14.
3 Follow the instructions from step 1 to step 3 in "Removing the Hard Drive" on
page 24.
4 Remove the base cover. See "Removing the Base Cover" on page 20. 5 Remove the keyboard. See "Removing the Keyboard" on page 17. 6 Remove the palm-rest. See "Removing the Palm-Rest" on page 30. 7 Follow the instructions from step 3 to step 7 in "Removing the System Board" on
page 39.
Removing the Display Assembly | 57

Procedure

1
2
3
1 Note the antenna cable routing and remove the cable from its routing guides. 2 Remove the screws that secure the display assembly to the computer base. 3 Lift the display assembly off the computer base.
1 display assembly 2 screws (9)
3routing guides
58 | Removing the Display Assembly

Replacing the Display Assembly

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Procedure

1 Place the display assembly on the computer base and align the screw holes on the
display assembly with the screw holes on the computer base.
2 Replace the screws that secure the display assembly to the computer base. 3 Route the antenna cable through the routing guides on the computer base.

Postrequisites

1 Follow the instructions from step 3 to step 10 in "Replacing the System Board" on
page 43.
2 Replace the palm-rest. See "Replacing the Palm-Rest" on page 33. 3 Replace the keyboard. See "Replacing the Keyboard" on page 19. 4 Replace the base cover. See "Replacing the Base Cover" on page 21. 5 Follow the instructions from step 3 to step 4 in "Replacing the Optical Drive" on
page 16.
6 Follow the instructions from step 3 to step 5 in "Replacing the Hard Drive" on
page 27.
7 Replace the battery. See "Replacing the Battery" on page 13.
Replacing the Display Assembly | 59

Removing the Display Bezel

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Prerequisites

1 Remove the battery. See "Removing the Battery" on page 12. 2 Follow the instructions from step 1 to step 2 in "Removing the Optical Drive" on
page 14.
3 Follow the instructions from step 1 to step 3 in "Removing the Hard Drive" on
page 24.
4 Remove the base cover. See "Removing the Base Cover" on page 20. 5 Remove the keyboard. See "Removing the Keyboard" on page 17. 6 Remove the palm-rest. See "Removing the Palm-Rest" on page 30. 7 Follow the instructions from step 3 to step 7 in "Removing the System Board" on
page 39.
8 Remove the display assembly. See "Removing the Display Assembly" on page 57.
60 | Removing the Display Bezel

Procedure

1
1 Using your fingertips, carefully pry up the inside edge of the display bezel. 2 Remove the display bezel off the display back-cover.
1 display bezel
Removing the Display Bezel | 61

Replacing the Display Bezel

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Procedure

Align the display bezel with the display back-cover, and gently snap the display bezel into place.

Postrequisites

1 Replace the display assembly. See "Replacing the Display Assembly" on page 59. 2 Follow the instructions from step 3 to step 10 in "Replacing the System Board" on
page 43.
3 Replace the palm-rest. See "Replacing the Palm-Rest" on page 33. 4 Replace the keyboard. See "Replacing the Keyboard" on page 19. 5 Replace the base cover. See "Replacing the Base Cover" on page 21. 6 Follow the instructions from step 3 to step 4 in "Replacing the Optical Drive" on
page 16.
7 Follow the instructions from step 3 to step 5 in "Replacing the Hard Drive" on
page 27.
8 Replace the battery. See "Replacing the Battery" on page 13.
62 | Replacing the Display Bezel

Removing the Display Hinges

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Prerequisites

1 Remove the battery. See "Removing the Battery" on page 12. 2 Follow the instructions from step 1 to step 2 in "Removing the Optical Drive" on
page 14.
3 Follow the instructions from step 1 to step 3 in "Removing the Hard Drive" on
page 24.
4 Remove the base cover. See "Removing the Base Cover" on page 20. 5 Remove the keyboard. See "Removing the Keyboard" on page 17. 6 Remove the palm-rest. See "Removing the Palm-Rest" on page 30. 7 Follow the instructions from step 3 to step 7 in "Removing the System Board" on
page 39.
8 Remove the display assembly. See "Removing the Display Assembly" on page 57. 9 Remove the display bezel. See "Removing the Display Bezel" on page 60.
Removing the Display Hinges | 63

Procedure

1
2
3
1 Remove the screws that secure the display hinges to the display back-cover. 2 Lift the display hinges off the display back-cover.
1 screws (2) 2 display hinges (2)
3 display back-cover
64 | Removing the Display Hinges

Replacing the Display Hinges

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Procedure

1 Align the screw holes on the display hinges with the screw holes on
the display back-cover.
2 Replace the screws that secure the display hinges to the display back-cover.

Postrequisites

1 Replace the display bezel. See "Replacing the Display Bezel" on page 62. 2 Replace the display assembly. See "Replacing the Display Assembly" on page 59. 3 Follow the instructions from step 3 to step 10 in "Replacing the System Board" on
page 43.
4 Replace the palm-rest. See "Replacing the Palm-Rest" on page 33. 5 Replace the keyboard. See "Replacing the Keyboard" on page 19. 6 Replace the base cover. See "Replacing the Base Cover" on page 21. 7 Follow the instructions from step 3 to step 4 in "Replacing the Optical Drive" on
page 16.
8 Follow the instructions from step 1 to step 3 in "Removing the Hard Drive" on
page 24.
9 Replace the battery. See "Replacing the Battery" on page 13.
Replacing the Display Hinges | 65

Removing the Display Panel

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Prerequisites

1 Remove the battery. See "Removing the Battery" on page 12. 2 Follow the instructions from step 1 to step 2 in "Removing the Optical Drive" on
page 14.
3 Follow the instructions from step 1 to step 3 in "Removing the Hard Drive" on
page 24.
4 Remove the base cover. See "Removing the Base Cover" on page 20. 5 Remove the memory module(s). See "Removing the Memory Module(s)" on
page 22.
6 Remove the keyboard. See "Removing the Keyboard" on page 17. 7 Remove the palm-rest. See "Removing the Palm-Rest" on page 30. 8 Follow the instructions from step 3 to step 7 in "Removing the System Board" on
page 39.
9 Remove the display assembly. See "Removing the Display Assembly" on page 57.
10 Remove the display bezel. See "Removing the Display Bezel" on page 60.
11 Remove the display hinges. See "Removing the Display Hinges" on page 63.
66 | Removing the Display Panel

Procedure

1
22
3
1 Remove the screws that secure the display panel to the display back-cover. 2 Gently lift the display panel and turn it over.
1 display back-cover 2 display panel
3screws (12)
Removing the Display Panel | 67
3 Peel the tape adhered over the display cable.
1
2
4 Disconnect the display cable from the display-panel cable connector.
1 tape 2 display cable
68 | Removing the Display Panel

Replacing the Display Panel

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Procedure

1 Connect the display cable to the display-panel connector. 2 Adhere the tape that secures the display cable. 3 Gently place the display panel on the display back cover and align the screw holes
on the display panel with the screw holes on the display back-cover.
4 Replace the screws that secure the display panel to the display back-cover.

Postrequisites

1 Replace the display hinges. See "Replacing the Display Hinges" on page 65. 2 Replace the display bezel. See "Replacing the Display Bezel" on page 62. 3 Replace the display assembly. See "Replacing the Display Assembly" on page 59. 4 Follow the instructions from step 3 to step 10 in "Replacing the System Board" on
page 43.
5 Replace the palm-rest. See "Replacing the Palm-Rest" on page 33. 6 Replace the keyboard. See "Replacing the Keyboard" on page 19. 7 Replace the memory module(s). See "Replacing the Memory Module(s)" on page 23. 8 Replace the base cover. See "Replacing the Base Cover" on page 21. 9 Follow the instructions from step 3 to step 4 in "Replacing the Optical Drive" on
page 16.
10 Follow the instructions from step 3 to step 5 in "Replacing the Hard Drive" on
page 27.
11 Replace the battery. See "Replacing the Battery" on page 13.
Replacing the Display Panel | 69

Removing the Camera Module

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Prerequisites

1 Remove the battery. See "Removing the Battery" on page 12. 2 Follow the instructions from step 1 to step 2 in "Removing the Optical Drive" on
page 14.
3 Follow the instructions from step 1 to step 3 in "Removing the Hard Drive" on
page 24.
4 Remove the base cover. See "Removing the Base Cover" on page 20. 5 Remove the memory module(s). See "Removing the Memory Module(s)" on
page 22.
6 Remove the keyboard. See "Removing the Keyboard" on page 17. 7 Remove the palm-rest. See "Removing the Palm-Rest" on page 30. 8 Follow the instructions from step 3 to step 7 in "Removing the System Board" on
page 39.
9 Remove the display assembly. See "Removing the Display Assembly" on page 57.
10 Remove the display bezel. See "Removing the Display Bezel" on page 60.
70 | Removing the Camera Module

Procedure

1
2
3
1 Disconnect the camera cable from the camera module. 2 Remove the screw that secures the camera module to the display back-cover. 3 Lift camera module off the display back-cover.
1 screw 2 camera module
3camera cable
Removing the Camera Module | 71

Replacing the Camera Module

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Procedure

1 Use the alignment posts on the display back-cover to place the camera module in
position.
2 Replace the screw that secures the camera module to the display back-cover. 3 Connect the camera cable to the camera-module connector.

Postrequisites

1 Replace the display bezel. See "Replacing the Display Bezel" on page 62. 2 Replace the display assembly. See "Replacing the Display Assembly" on page 59. 3 Follow the instructions from step 3 to step 10 in "Replacing the System Board" on
page 43.
4 Replace the palm-rest. See "Replacing the Palm-Rest" on page 33. 5 Replace the keyboard. See "Replacing the Keyboard" on page 19. 6 Replace the memory module(s). See "Replacing the Memory Module(s)" on page 23. 7 Replace the base cover. See "Replacing the Base Cover" on page 21. 8 Follow the instructions from step 3 to step 4 in "Replacing the Optical Drive" on
page 16.
9 Follow the instructions from step 3 to step 5 in "Replacing the Hard Drive" on
page 27.
10 Replace the battery. See "Replacing the Battery" on page 13.
72 | Replacing the Camera Module

Removing the Power-Adapter Port

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Prerequisites

1 Remove the battery. See "Removing the Battery" on page 12. 2 Follow the instructions from step 1 to step 2 in "Removing the Optical Drive" on
page 14.
3 Follow the instructions from step 1 to step 3 in "Removing the Hard Drive" on
page 24.
4 Remove the base cover. See "Removing the Base Cover" on page 20. 5 Remove the memory module(s). See "Removing the Memory Module(s)" on
page 22.
6 Remove the keyboard. See "Removing the Keyboard" on page 17. 7 Remove the palm-rest. See "Removing the Palm-Rest" on page 30. 8 Follow the instructions from step 3 to step 7 in "Removing the System Board" on
page 39.
9 Remove the display assembly. See "Removing the Display Assembly" on page 57.
Removing the Power-Adapter Port | 73

Procedure

131
2
1 Note the routing of the power-adapter-port cable and remove the
power-adapter-port cable from the routing guides on the computer base.
2 Lift the power-adapter port, along with its cable, off the computer base.
1 power-adapter port cable 2 routing guides
3 power-adapter port
74 | Removing the Power-Adapter Port

Replacing the Power-Adapter Port

WARNING: Before working inside your computer, read the safety information that
shipped with your computer and follow the steps in "Before You Begin" on page 9. After working inside your computer, follow the instructions in "After Working Inside Your Computer" on page 11. For additional safety best practices information, see the Regulatory Compliance Homepage at dell.com/regulatory_compliance.

Procedure

1 Slide the power-adapter port into position. 2 Route the power-adapter-port cable through the routing guides on the
computer base.

Postrequisites

1 Replace the display assembly. See "Replacing the Display Assembly" on page 59. 2 Follow the instructions from step 3 to step 10 in "Replacing the System Board" on
page 43.
3 Replace the palm-rest. See "Replacing the Palm-Rest" on page 33. 4 Replace the keyboard. See "Replacing the Keyboard" on page 19. 5 Replace the base cover. See "Replacing the Base Cover" on page 21. 6 Follow the instructions from step 3 to step 4 in "Replacing the Optical Drive" on
page 16.
7 Follow the instructions from step 3 to step 5 in "Replacing the Hard Drive" on
page 27.
8 Replace the battery. See "Replacing the Battery" on page 13.
Replacing the Power-Adapter Port | 75

Flashing the BIOS

The BIOS may require flashing when an update is available or when replacing the system board. To flash the BIOS:
1 Turn on the computer. 2 Go to dell.com/support. 3 Click Start Here under Support for Home Users. 4 If you have your computer's Service Tag, type your computer's Service Tag and
click Submit. If you do not have your computer's service tag, click Detect Service Tag to allow
automatic detection of your computer's service tag.
NOTE: If the Service Tag cannot be detected automatically, select your
product under the product categories.
5 Click Drivers & Downloads tab. 6 In the Operating System drop-down, select the operating system installed on
your computer.
7 Click BIOS. 8 Click Download File to download the latest version of the BIOS for your computer. 9 On the next page, select Single-file download and click Continue.
10 Save the file and once the download is complete, navigate to the folder where you
saved the BIOS update file.
11 Double-click the BIOS update file icon and follow the instructions on the screen.
76 | Flashing the BIOS
