Dell 6248, 6248P, 6224, 6224P, 6224F User Manual

Dell™ PowerConnect™ 6224/6224F/6224P/6248/6248P

PowerConnect
6224/6224F/6224P/6248/6248P
Release Notes

Date: May 2010
System Firmware Version 3.2.0.6

Information in this document is subject to change without notice.
© 2003 – 2010 Dell Inc. All rights reserved.

Reproduction in any manner whatsoever without the written permission of Dell Inc is strictly forbidden.

Trademarks used in this text: Dell, the DELL logo and PowerConnect are trademarks of Dell Inc; Intel and Pentium are registered trademarks and
Celeron is a trademark of Intel Corporation; Microsoft and Windows are registered trademarks of Microsoft Corporation.
Other trademarks and trade names may be used in this document to refer to either the entity claiming the marks and names or their products. Dell

Inc disclaims any proprietary interest in trademarks and trade names other than its own. All rights reserved. This document may not, in whole or
in part, be copied, photocopied, reproduced, translated, or reduced to any electronic medium or machine-readable form without the prior written
consent of Dell. Dell reserves the right to make changes without further notices to any products or specifications referred to herein to impr ove
reliability, functionality or design.

Reproduction, adaptation or translation without prior written permission is prohibited, except as allowed under the copyright laws.

Table of Contents

Introduction 1

Global Support 1

Firmware Specifications 1

Hardware Supported 2

Added Functionality in this Release 3

Changed Functionality in this Release 11

Deprecated Commands and Parameters 15

Issues Resolved 17

CLI Reference Manual Updates 21

User’s Guide Updates 24

Known Issues 25

Known Restrictions and Limitations 28

Layer 2 28

Layer 3 29

Management 31

End of Release Notes 32

ii System Firmware Version 3.2.0.6

PowerConnect 6224/6224F/6224P/6248/6248P Release Notes

Introduction

This document provides specific information for the Dell PowerConnect 6200 Series switches, firmware version 3.2.0.6.

It is recommended that this release note be thoroughly reviewed prior to installing or upgrading of this product.

Global Support

For information regarding the latest available firmware, release note revisions, or additional assistance, please visit the
Support Web Site http://support.dell.com/.

Firmware Specifications

Firmware Version Details

Boot PROM Name Version No. Release Date

Not Applicable 3.2.0.6 May 2010

Firmware Upgrade

NOTE: Version 3.2 includes improvements to the firmware management

system. You MUST follow the procedure set forth in the Dell PowerConnect 6200
Series Release 3.2 Upgrade Procedure included in the zip file to update the boot
code AND firmware. Failure to adhere to this procedure may result in your switch
becoming inoperable.

NOTE: The PC6200 switches when stacked require that the same version of

firmware be installed on every switch member.

System Firmware Version 3.2.0.6 Page 1

Firmware Image Name Version No. Release Date

PC6200v3.2.0.6.stk 3.2.0.6 May 2010

Version Numbering Convention

Version number Description

6200 Series

3 2 0 6









Four part version number
Denotes the build number.
Denotes an ad hoc release of the product software.
Denotes a scheduled maintenance release of the product software.
Denotes a major version number.

Supported Firmware Functionality

For more details regarding the functionalities listed, please refer to the Dell™ PowerConnect™ 6200 Series Systems CLI

Reference Guide and the Dell™ PowerConnect™ 6200 Series Configuration Guide

NOTE: OMNM 4.1 will not discover the switches running any

.

version of 3.x.y.z firmware therefore users should upgrade to
version 4.2.

If you use OpenManage Network Manager to deploy firmware,
do not use it to deploy 3.x (or later) firmware to a
PowerConnect 62xx device that is currently running firmware
version 2.x or earlier. Only use the method described in these
Release Notes to upgrade this firmware.

Firmware Downgrade

Downgrading from 3.2.0.6 to a previous release is not supported. Users should save their configuration file to a backup location
before performing this operation.

Hardware Supported

PowerConnect 6224
PowerConnect 6248
PowerConnect 6224F
PowerConnect 6224P
PowerConnect 6248P

2 System Firmware Version 3.2.0.6

PowerConnect 6224/6224F/6224P/6248/6248P Release Notes

Added Functionality in this Release

¾ Non-Stop Forwarding

This feature creates an option to allow the forwarding plane of stack units to continue to forward packets
while the control and management planes restart as a result of a power failure , har dwa re f a ilure, or software
fault on the stack management unit. This type of operation is called non-stop forwarding. When the
management unit fails, only the management switch needs to be restarted.

¾ Configuration of CX-4/Stacking Modules

This feature will allow the stacking and CX-4 plug-in modules to be configured to either role (Ethernet or
Stacking). By default, the module will function according to its module ID. Upon changing the role of a
module, a reboot of the switch will be required for the change to take effect.

¾ Custom Protocol Based VLANs

Prior to the 3.2 release only ARP, IP and IPX are configurable as protocols for protocol-based VLANs.
This has been extended so that any Ethertype may be used.

¾ Port Configuration Show Command

Added support for a single command that shows VLAN, STP, Port Status, and Port Configuration
information etc.

The new command is show interfaces detail {ethernet interface | port-channel port-channel-number}
where

• interface—A valid Ethernet port.

• port-channel-number—A valid port -channel trunk index.

¾ Configurable Message of the Day Banner

The system supports a configurable message of the day banner that displays on the console. This feature is
configurable via the CLI or GUI and supports 1500 characters.

¾ VLAN Name Support with RADIUS Server

This feature is an extension of Dot1x Option 81 feature added in Power Connect Release 2.1 to accept a
VLAN name as an alternative to a number when RADIUS indicates the Tunnel-Private-Group-ID for a
supplicant. Since this option is a string, it can also be used for a VLAN name. In order to support this
feature, VLAN names must be unique.

¾ HTTP Download

Allow users to download files via an HTTP session. All file types which may be downloaded via TFTP are
supported.

System Firmware Version 3.2.0.6 Page 3

¾ Serviceability Tracing Commands

Debug commands provided to enable tracing of various protocols.

¾ Faster Initialization for Stacking Failover

Fast Reinitialization involves improvement in:

• Detection of Management Unit Failure

• Building Card Manager Database

• Application of saved configuration

Performance Improvements (based on Configuration File size) are:

• Default ~ 35%

• Medium ~ 50%

• Large ~80%

The impact is higher on large configuration files versus the smaller ones.

¾ Auto Config

Auto Config is a software feature which provide s for the configuration of a switch automatically when the
device is initialized and no configuration file is found on the switch. Auto Config is accomplished in three
phases:

1. Configuration or assignment of an IP address for the device

2. Assignment of a TFTP server

3. Obtaining a configuratio n file for the device from the TFTP server

¾ DHCP Snooping

DHCP Snooping is a security feature that monitors DHCP messages between a DHCP client and DHCP
server. It filters harmful DHCP messages and builds a bindings database of (MAC address, IP address,
VLAN ID, port) tuples that are specified as authorized. DHCP snooping can be enabled globally and on
specific VLANs. Ports within the VLAN can be configured to be trusted or untrusted. DHCP servers must
be reached through trusted ports.

¾ DHCP L2 Relay

Permits L3 Relay agent functionality in L2 switched networks.

¾ sFlow

sFlow is the standard for monitoring high-speed switched and routed networks. sFlow technology is built
into network equipment and gives complete visibility into network activity, enabling effective management
and control of network resources.

4 System Firmware Version 3.2.0.6

PowerConnect 6224/6224F/6224P/6248/6248P Release Notes

¾ MLD Snooping (RFC2710)

In IPv4, Layer 2 switches can use IGMP Snooping to limit the flooding of multicast traffic by dynamically
configuring Layer 2 interfaces so that multicast traffic is forwarded to only those interfaces associated with
IP multicast address.

In IPv6, MLD snooping performs a similar function. With MLD snooping, IPv6 multicast data is
selectively forwarded to a list of ports intended to receive the data (instead of being flooded to all of the
ports in a VLAN). This list is constructed by snooping IPv6 multicast control pac kets.

¾ MGMD Proxy

The IGMP Proxy component has been extended to include support for MLD Proxy and is now called the
Multicast Group Membership Discovery (MGMD) Proxy. The MGMD Proxy is used to enable the system
to issue MGMD host messages on behalf of hosts that the system discovered through standard MGMD
router interfaces, thus acting as proxy to all its hosts residing on its router interfaces.

¾ Dynamic ARP Inspection

Dynamic ARP Inspection (DAI) is a security feature that rejects invalid and malicious ARP packets. The
feature prevents a class of man-in-the-middle attacks, where an unfriendly station intercepts traffic for other
stations by poisoning the ARP caches of its unsuspecting neighbors. The miscreant sends ARP requests or
responses mapping another station’s IP address to its own MAC address.

¾ Multiple LLDP Neighbors per Interface

This feature allows support for multiple neighbors on a single LLDP interface.

¾ Configurable DSCP for Voice VLAN

Allow the user to configure the voice VLAN DSCP parameter and set the DSCP value. This value is
retrieved by LLDP when the LLDPDU is transmitted (if LLDP has been enabled on the port and the
required TLV is configured for the port).

¾ CDP Interoperability

Allows the ISDP feature to interoperate with Cisco™ devices running CDP.
Industry Standard Discovery Protocol (ISDP) is a proprietary Layer 2 network protocol which inter-

operates with Cisco network equipment and is used to share information between neighboring devices
(routers, bridges, access servers, and switches).

This feature is enabled by default if using phones with CDP enabled, but should be disabled if a
Voice VLAN is manually configured on the port.

¾ SSH/SSL Refresh

The SSH update incorporates the latest security and bug fixes.

System Firmware Version 3.2.0.6 Page 5

¾ RADIUS Enhancements

• The maximum number of RADIUS servers supported has increased from three to 32.

• RADIUS servers with the same name can be used as Backups (RADIUS Authentication and

Accounting servers)

• Simultaneous Transactions to Multiple RADIUS Servers

• RADIUS Accounting – Allows a client the ability to deliver accounting information about a user to an

Accounting server.

¾ IPv6 support for QoS (ACL/DiffServ)

Extends the existing QoS ACL and DiffServ functionality by providing support for IPv6 packet
classification. Ethernet IPv6 packets are distinguished from IPv4 packets by a unique Ethertype value (all
IPv6 classifiers include the Ethertype field).

¾ Auto VoIP

This provides ease of use in configuring VoIP for IP phones on the switch. This is accomplished by
enabling a VoIP profile that a user can select on a per port basis.

¾ Dynamic ACL Management

The number of rules allowed per ACL has been increased to the maximum allowed by the silicon (127
rules). This will allow all available rules to be assigned to a single ACL. However, the user is no longer
guaranteed to be able to apply an ACL if the number of rules is over-subscribed. Refer to the

Guide for details.

¾ SCPv2, SFTP

Adds the ability for the user to securely transfer files to/or from the switch. It makes use of the Secure Copy
Protocol (SCP) and SSH File Transfer Protocol (SFTP). SSH client login is used to establish a secure
connection to the remote server before the file transfer begins.

¾ Captive Portal

This allows administrators to block clients from accessing the network until user verification has been
established or authenticated. Verification can be configured to allow access for both guest and
authenticated users. Authenticated users must be validated against a database of authorized Captive Portal
users before access is granted.

¾ 802.1x MAC Authentication Bypass (MAB)

Provides 802.1x unaware clients controlled access to the network using the device MAC address as an
identifier. This requires that the known and allowable MAC address and corresponding access rights be
pre-populated in the authentication server. MAB only works when the port control mode of the po rt is
MAC-based.

Configuration

6 System Firmware Version 3.2.0.6

PowerConnect 6224/6224F/6224P/6248/6248P Release Notes

¾ Ping/Traceroute Enhancements

New ping options have been added to allow the user to specify the number and size of echo requests and
the interval between echo requests. A ping can now be initiated via SNMP using the MIB defined in RFC

2925.

New traceroute options have been added to allow the user to specify the initial and maximum time to live
(TTL) in probe packets, the maximum number of failures before termination, the number of probes sent for
each TTL, and the size of each probe. A trace route can be initiated in the web and SNMP user interfaces.

¾ Static Reject Routes

Allows the user to configure a static route to discard the packets to a particular destination, thereby forcing
a black-hole routing behavior for a particular set of IP prefixes.

This can be done for the following reasons:

• Prevent a routing loop in the network (default route configured on a router).

• A preventive measure against a DOS attack on a router with unwanted destination addresses.

¾ Clear ARP Cache Management Port

A new CLI command has been added to enable clearing of the ARP table of entries learned from the
management port.

¾ OSPFv2 Point-to-Point Links

OSPF can treat an interface as a point-to-point circuit, even though the physical network is a broadcast
network. This simplifies OSPF operation on the link. OSPF does not elect a designated router for a point­to-point network, and does not generate a network LSA to represent a point-to-point network in the link
state topology. This mode of operation is useful when there are only two routers attached to the link (either
a physical or virtual LAN).

In point-to-point mode, OSPF joins the AllSPFRouters multicast group on the interface and sends all OSPF
packets on the interface to AllSPFRouters. OSPF accepts packets received on point-to-point interfaces even
if the source IP address is not on a local subnet.

¾ OSPVv2/v3 Summary Reject Routes

The area address range advertised by OSPF router at area boundaries as summary route into another area
can lead to routing loops in some situations. This feature can avoid situations where a routing loop can
occur in a network.

¾ OSPF v2/v3 Passive Interfaces

Allows passive interfaces for OSPF implementations.

System Firmware Version 3.2.0.6 Page 7

¾ Granular OSPF v2/v3 Traps

Configure which of the OSPF traps the OSPF Router should generate by enabling or disabling the trap
condition. If a trap condition is enabled and the condition is detected, the OSPF router will send the trap to
all trap receivers.

¾ auto-cost reference bandwidth and bandwidth Commands

Controls how OSPF calculates the default metric for an interface by using the auto-cost command in router
OSPF configuration mode. To assign cost-based only on the interface type, use the no form of this
command.

¾ network area Command

Support is added for the following 2 OSPFv2 CLI commands:

• network ip-address wildcard-mask area areaid

• ip ospf area areaid [ secondaries none ]

¾ OSPF v2/v3 Route Preferences Rework

The following effects are seen with this change:

• Configuration of external route preference that applies to all OSPF external routes (like type1,

type2, nssa-type1, nssa-type2) equally.

• Allows multiple route types to be configured with equal preference values.

• No longer follows the order among OSPF route preferences: intra < inter < external.

• Configuring the route preference of 255 makes the route ineligible to be selected as the best route

to its destination (a route with preference of 255 is never used for forwarding).

• While migrating from previous releases, the preference for the external routes will be set with the

preference value of the type-1 route in the earlier releases.

¾ Opaque LSAs and Detailed Display of OSPF v2 LSAs

Opaque LSAs provide a generalized mechanism to allow for the future extensibility of OSPF. The
information contained in Opaque LSAs may be used directly by OSPF or indirectly by some application
wishing to distribute information throughout the OSPF domain. For example, the OSPF LSA may be used
by routers to distribute IP to link-layer address resolution information.

¾ ICMP Enhancements (RFC4443)

ICMPv6 code is updated to support RFC 4443.

¾ DNSv6 Client

The DNS Client has added support for IPv6 (RFC3596). The transport for communication with a DNS
server can be either IPv6 or IPv4 depending on type of server address.

8 System Firmware Version 3.2.0.6

PowerConnect 6224/6224F/6224P/6248/6248P Release Notes

¾ Configured Tunnels MTU

To comply with RFC 4213, Basic Transition Mechanisms for IPv6 Hosts and Routers, the IPv6 MTU on
configured IPv6 over IPv4 tunnels was changed from 1480 bytes to 1280 bytes.

¾ IPv6 6 to 4 Auto Tunnels

The 6 to 4 tunnels automatically formed IPv4 6 to 4 tunnels for carrying IPv6 traffic. The automatic tunnel
IPv4 destination address is derived from the 6 to 4 IPv6 address of the tunnel next hop. There is support for
a 6 to 4 border router that connects a 6 to 4 site to a 6 to 4 domain. It sends/receives tunneled traffic from
routers in a 6 to 4 domain that includes other 6 to 4 border routers and 6 to 4 relay routers.

¾ VRRP Route Interface Tracking

This extends the capability of the Virtual Router Redundancy Protocol (VRRP) to allow tracking of
specific route/interface IP state within the router that can alter the priority level of a virtual router for a
VRRP group.

The exception to this is, if that VRRP group is the IP address owner, its priority is fixed at 255 and can not
be reduced through tracking process.

¾ ICMP Throttling

This adds configuration options for the transmission of various types of ICMP messages.
This project adds the following configuration options:

• Rate limiting the generation of ICMP error messages.

• Suppression of ICMP echo replies.

• Suppression of ICMP Redirects.

• Suppression of Destination Unreachables.

¾ IP Helper

Provides the ability to enable DHCP relay on specific interfaces, with DHCP server addresses specified
independently on each interface. The ip helper-address commands configure both DHCP and UDP relay.

¾ OSPF Enhancements

A CLI command is added with options to do the following:

• Disable and re-enable OSPF

• Clear the OSPF configuration

• Bounce all or specific OSPF neighbors

• Flush and re-originate all self-originated external LSAs

• Clear OSPF statistics

¾ Support of IPv6 routes in PIM-SM and PIM-DM

Support for IPv6 routes has been added to PIM-SM and PIM-DM.

System Firmware Version 3.2.0.6 Page 9

¾ IPv6 Management Enhancements

Provides the following:

• Dual IPv4/IPv6 operation over the net wo rk po rt

• Static assignment of IPv6 addresses and gateways for the service/network ports

• Ability to ping an IPv6 link-local address over the service/network port

• SNMP traps and queries via the service/network port

¾ Updated IPv4 Multicast Routing Support

The Multicast package code has been extensively re-engineered and furnished with the following:

• PIM-DM advanced to RFC 3973

• PIM-SM advanced to RFC 4601, pim-sm-bsr-05, draft-ietf-pim-mib-v2-03

• DVMRP advanced to draft-ietf-idmr-dvmrp-v3-10.txt, draft-ietf-idmr-dvmrp-mib-11.txt

¾ MLD Snooping Querier

MLD Snooping Querier is an extension to the MLD Snooping feature; it enhances the switch capability to
simulate a MLD router in a Layer 2 network thus removing the need to have a MLD Router in a Layer2
network to collect the Multicast group membership information. The Querier functionality is a small subset
of the MLD Router functionality.

10 System Firmware Version 3.2.0.6

PowerConnect 6224/6224F/6224P/6248/6248P Release Notes

Changed Functionality in this Release

¾ Spanning Tree Update – 802.1Q-2005

Spanning Tree now supports IEEE802.1Q-2005. This version of the IEEE Multiple Spanning Tree Protocol
corrects problems associated with the previous version, provides for faster transition-to-forward ing, and
incorporates new features for a port (restricted role and restricted TCN).

Restricted role - Setting the restricted role parameter for a port causes the DUT not to select that port as a
root for CIST or any MSTI.

Restricted TCN - Setting the restricted TCN parameter causes the port not to propagate topology change
notification. A port configured with this parameter will not flush its MAC address table or send out a
BPDU with a topology change flag set to true when it receives a BPDU with the topology change flag set
to true.

Hello-time - This revision of the standard does not allow the value of hello-time to be modified;
consequently, the hello-time command has been blocked for all CLI.

Loop Guard - The STP Loop Guard feature is an enhancement of the Multiple Spanning Tree Protocol.
STP Loop Guard protects a network from forwarding loops induced by BPDU packet loss. It prevents a
blocked port from erroneously transitioning to the forwarding state when the port stops receiving BPDUs.

The reasons for packet loss are numerous, including heavy traffic, software problems, incorrect
configuration, and unidirectional link failure. When a non-designated port no longer receives BPDUs,
MSTP considers this link as loop free and begins transitioning the link from blocking to forwarding. In
forwarding state, the link may create a loop in the network.

Enabling loop guard prevents such accidental loops. When a port is no longer receiving BPDUs and the
max age timer expires, the port is moved to a “loop-inconsistent blocking state.” In the loop-inconsistent
blocking state, traffic is not forwarded (acting in the same manner as the blocking state). The port remains
in this state until it receives a BPDU and it transitions through the normal spanning tree states based on the
information in the received BPDU. Normal spanning tree states include blocking, listening, learning, and
forwarding.

The “loop-inconsistent blocking state” is a state introduced with the loop guard feature.
This feature is intended for improving network stability and used for preventing STP loops. It is compatible

with CST, RSTP and MST modifications of spanning tree.

Note: Loop Guard should be configured o nly on no n- designated ports. These include ports in alternate or
backup roles. Ports in designated roles should not have loop guard enabled. Ports in designated roles can
forward traffic.

¾ RFC3621 (PoE) MIB Moved

The POWER-ETHERNET-MIB has been moved from its previous location of {fastpath 16} to the standard
location of {mib-2 105}. Any SNMP agents that accessed this MIB on previous releases must be updated to
use the new location.

¾ RFC1612 (DNS Resolver) MIB Moved

The DNS-RESOLVER-MIB has been moved from its previous location of {fastpath 200} to the standard

location of {dns 2}. Any SNMP agents that accessed this MIB on previous releases must be updated to use
the new location

.

System Firmware Version 3.2.0.6 Page 11

¾ ip route Command Changed

The syntax of the ip route command has changed. The metric keyword is no longer accepted as it had no
effect. The new syntax is:

ip route ip addr subnetmask | prefix-length nextHopRtr [ preference ]

¾ distance ospf Command Changed

The distance ospf command has been changed (for both OSPFv2 and OSPFv3) to the industry standard
syntax. The new syntax is:

distance ospf {external | inter-area | intra-area } distance

¾ ip mtu Command Changed (Maximum Value Increased)

The maximum value for the ip mtu command has increased from 1500 to 9202. If not configured, the IP
MTU tracks the interface MTU.

¾ bridge address Command Changed

The following bridge address command optional parameters have been deprecated:

• delete-on-reset

• delete-on-timeout

• secure

¾ port security Command Changed

The following port security command optional parameters have been deprecated:

• forward

• discard-shutdown

¾ Link Dependency Available

The Link Dependency feature which has previously only been available on modular switches is now
available on all switches. The functionality is similar to the capability available on the PCM6220,
PCM8024, and the PCM6348.

This release added an action capability to link-dependency where if a dependant port goes down, as an
action option, the group’s members come up versus also go down. This can be used as a form of link
redundancy as an alternative to using STP.

¾ ISDP Advertise/Display hostname

ISDP can now use the hostname as the Device ID instead of the Serial Number. The user needs to change
the default hostname on the switch and can verify the results via the show isdp

command.

12 System Firmware Version 3.2.0.6

PowerConnect 6224/6224F/6224P/6248/6248P Release Notes

¾ Trap Configuration

In previous versions of the software, configuration of the flags for controlling traps was scattered about in a
number of places.

snmp-server enable traps is now a common command for configuring all trap flags. The legacy
commands are preserved for backward compatibility. Also note that the keyword “trap” has changed to the
plural “traps”.

¾ SNTP Server Priority

The server priority is now available from the show sntp configuration command. Previously it was only
configurable.

¾ GARP Leave Timer

The valid range for the GARP leave timer has been changed to 20-600 centiseconds.

¾ IP Multicast Static Route Configuration

The command for configuring a static IPv4 multicast route has changed to ip mroute. The ip multicast
staticroute command is deprecated.

¾ Support for Long User Names

The show users, show users accounts, and show users login-history commands have changed. The long
parameter has been added to these commands to support long usernames.

¾ Flow Control

Flow Control is enabled by default.
Note: When you upgrade a switch to this release, flow control is automatically enabled. If your previous

configuration had flow control disabled, you must disable flow control after the upgrade to match the
previous configuration.

¾ VLAN Limit Increases

MAC based VLAN limit was increased from 128 to 256.
Subnet based VLAN limit was increased from 64 to 128.

System Firmware Version 3.2.0.6 Page 13

¾ ACL Changes

The following changes apply to ingress and egress ACLs:

Maximum of 100 ACLs

o
o

Maximum rules per ACL are 127

Note: Although the maximum number of ACLs is 100, and the maximum number of rules per ACL is 127,
the system cannot support 100 ACLs that each has 127 rules.

Note: Any given port can support up to 127 rules. These 127 rules can be in a single ACL or in multiple
ACLs that are applied to the interface.

Note: ACL’s can be applied to all Ethernet interfaces.

14 System Firmware Version 3.2.0.6

PowerConnect 6224/6224F/6224P/6248/6248P Release Notes

Deprecated Commands and Parameters

The following CLI commands have been deprecated since the 2.x release.

Title Description
bridge address

ip dhcp filtering

ip multicast staticroute

ip dhcp filtering trust

show ip dhcp filtering

mdix

port security

logging buffered size

rmon table-size history

rmon table-size log

spanning-tree bpdu filtering

MSTP Mode

Interface Configuration mode
Rationale: The following parameters have been deprecated:

• delete-on-reset

• delete-on-timeout

• secure

Global Configuration mode
Rationale: The ip dhcp filtering command has been deprecated. It has

been replaced by the ip dhcp snooping command.

Global Configuration mode
Rationale: The ip multicast staticroute command has been deprecated. It

has been replaced by the ip mroute command.

Interface Configuration mode
Rationale: The ip dhcp filtering trust command has been deprecated. It

has been replaced by the ip dhcp snooping trust command.

Privileged EXEC mode
Rationale: The show ip dhcp filtering command has been deprecated. It

has been replaced by the show ip dhcp snooping command.

Interface Configuration mode
Rationale: The mdix { auto | on } command has been deprecated.

Crossover is always automatically detected on ports.

Interface Configuration mode
Rationale: The following parameters have been deprecated:

• forward

• discard-shutdown

Global Configuration mode
Rationale: The logging buffered size command has been deprecated.

The buffer size is now fixed at 400 entries.

Global Configuration mode
Rationale: The rmon table-size history command has been deprecated.

The RMON history table size is now fixed at 270.

Global Configuration mode
Rationale: The rmon table-size log command has been deprecated. The

RMON log table size is now fixed at 100.

Global Configuration mode
Rationale: The spanning-tree bpdu filtering command has been

deprecated. It has been replaced by the no spanning-tree
bpdu flooding command.

MST mode
Rationale: The abort and show commands in MST Configuration mode

have been deprecated.

System Firmware Version 3.2.0.6 Page 15

Title Description
ip ospf

ip ospf areaid

ip dhcp filtering

ip dhcp filtering

show ip dhcp filtering

Interface Configuration mode
Rationale: The ip ospf command has been deprecated. This functionality

has been replaced by the ip ospf area command.
Interface Configuration mode

Rationale: The ip ospf areaid command has been deprecated. This

Global Configuration mode
Rationale: The ip dhcp filtering command has been deprecated.

Interface Configuration mode
Rationale: The ip dhcp filtering trust command has been deprecated.

Privileged EXEC mode
Rationale: The show ip dhcp filtering command has been deprecated.

functionality has been replaced by the ip ospf area command.

16 System Firmware Version 3.2.0.6

PowerConnect 6224/6224F/6224P/6248/6248P Release Notes

Issues Resolved

The following is a list of issues resolved in the current firmware release.

Description User Impact Resolution

Unable to configure IPv6 host
(4001::2) as an SNMP trap
receiver on the DUT.

WFB: Logging messages show
UTC time only.

Web: Zone config incorrect
with summer time config.

MLD Packets are not snooped,
when sending MLD packets
with Hop-by-Hop header with
Router Alert Option.

Firmware missing no
command to remove switch x
priority x.

Missing RFC1213 MIB-2
SNMP Trap counter.

Member xx changes do not
result in prompt to save
running-config on reload.

Cut-through mode does not
show in running-config.

Asset-tag is not set on stack
members.

GVRP CLI vs. GUI
inconsistency.

Configured non-existing host
cannot be deleted for logging
syslog.

Syslog server CLI description
accepts invalid control
characters

User is not aware that the only IPv4
address is accepted by the command
snmp-server host <ipaddress> and so
may try to give IPV6 address as input.

Logging messages show UTC time
instead of updated time with timezone
offset.

Zone is not correctly populated on the
web page with the summertime taken into
consideration.

PC6200 cannot properly identify IPv6
MLD packets that have the hop-by-hop
option set like other chips such as FP2.

The no switch 2 priority 2 command
does not work. There is no no form for

User could not walk all objects in SNMP
group.

If there is an unsaved member, standby,
or NSF configuration, user is not warned
of the unsaved configuration on issuing
reload.

The user cannot determine how cut­through mode is configured via the show
running-config command.

If a user would run the show system id
on the stack member, the asset tag would
not be displayed.

CLI and Web field names are different
and used reverse to each other.

Configured non-existing host cannot be
deleted for logging syslog.

Validation for syslog description is
different between Web and CLI.

Updated the help string to mention
that IPv4 address is expected as input
for snmp-server host <ipaddress>
CLI command.

Used simAdjustedTimeGet()
function for correcting log messages
time.

Added an object to get the
information on summertime check
and based on this value, populating
the zone in the web page.

Added a new MLD rule to the FFP
which will trap to the CPU IPv6
Membership reports which use the
well known MAC address
33:33:00:00:00:16.

Added the no version of the
command, setting the value to the
default.

Re-enabled objects to provide
support even though the objects
were obsoleted in RFC

Set the unitMgrCfgFile ->
dataChanged flag in the respective
APIs.

Added a comment to the running
config to indicate when the switch is
configured in cut-through mode. The
switch must be rebooted for the cut­through configuration to be
changed.

Process SET_ASSET_TAG event
while in
connected_unit/connected_stby
state.

Make the Web field names similar to
those of CLI such that the
configuration is understood
correctly.

Corrected logic so that only valid
servers could be deleted.

Added validation for syslog
description in CLI to accept control
characters: 'a-z' | 'A-Z' | '0-9' | " " | ' @

' | ' # ' | ' $ ' | ' _ ' | ' - ' | ' . '

System Firmware Version 3.2.0.6 Page 17

Description User Impact Resolution

Bridge multicast forbidden
forward-unregistered causes
L3 Multicast to fail.

Cut-through mode command
help is not clear.

Console logging levels help
does not indicate precedence.

Web Dot1x Authentication Max
Users show units in seconds
vs. # Users.

Web and CLI disagreement on
Dot1x statistics.

ReFormatFlashFileSystem no
available via the boot menu.

Show interfaces advertise
ethernet <unit> <port>
command is not parsed
properly.

Stack port link status mismatch
in CLI and Web interface when
configured for Ethernet.

Web Home > General > Asset
selection does not show
details.

Mirroring port should not send
CDP packets.

Backups with SNMP do not
work correctly.

END command with all upper
case is not understood by CLI.

Trying to add ninth member to
a channel-group shows LACP
assignment in HTTP view.

Switchport protected name
accepts non-alphanumeric
characters.

Description inconsistency
between HTTP and CLI
Administration.

Inconsistent CLI and Web
interface responses for STP
LAG settings.

Ip host parse Some ip host names with numbers and

Flooding in ingress VLAN. Modified the L3 interaction code of

snooping to notify the driver when
snooping is enabled. When
snooping is disabled, the current
operational state of snooping is also
sent to the driver.

For normal command and no command
the help information is the same.

Help content needs to show severity level
of logging.

Incorrect help string added in read-only
page of dot1x, causing user confusion.

Not displaying the MAC address correctly
in the field Last Frames Source in the
web page EAP Statistics.

ReFormatFlashFileSystem cannot be
executed from boot menu.

Show interfaces advertise ethernet <unit>
<port> command is not parsed properly.

To display the correct link status when
configured stack mode is Ethernet in the
Stack Port Summary web page.

Incorrect link for Asset page on General
Index page.

Both mirrored and mirroring ports are
sending CDP packets.

The MIB allows users to backup the
starting configuration to TFTP using
SNMP, but the file is corrupted.

User will not be able to go to root mode
by entering END.

Trying to add ninth member to a channel­group shows LACP assignment in HTTP
view.

Needed to check that protected port name
accepts only alphanumeric characters.

Spaces were not accepted in description
fields through web.

Inconsistent CLI and Web interface
responses for STP LAG settings.

periods are rejected.

Changed the help information

Added the severity levels to the help
strings.

Removed help string for read-only
page of dot1x.

Corrected the problem in the object
handler.

The ReFormatFlashFileSystem
operation is now available via the
boot menu.

Added a check for invalid interface.

Corrected the web page to properly
handle Ethernet and show link
status as up.

Corrected the file name for the
Asset page.

Get probe events, and mark
interface as acquired in ISDP
database. As a result, ISDP does
not participate on this port.

Corrected handling of upload
filetypes and setting local filename
in SNMP.

Use case insensitive comparison.

Corrected the code to enable LACP
after ports are added to lag
successfully.

Enhanced the validation.

Added appropriate validation.

Use the CLI formatting such that
both the CLI and Web are in sync.

Corrected the host name checks.

18 System Firmware Version 3.2.0.6

PowerConnect 6224/6224F/6224P/6248/6248P Release Notes

Description User Impact Resolution

Cannot enter Daylight Saving
Time from Web interface.

In summer time configuration page, in
recursive mode, clock zone field is not
accepting valid range.

In summer time configuration page,
in recursive mode, added
appropriate regular expression in
validation.

Error message when changing
SNTP Server Priority from
Web interface.

Custom Protocol VLAN shows
incorrect VLAN ID.

When priority is set through Web interface
for SNTP Server, and no encryption key is
configured, the system returns an error
message.

VLAN protocol group if configured for
custom protocol using ethertype did not
display the VLAN id in the Switching >

Upon setting the priority to SNTP
server when no encryption key is
configured, the key is now submitted
to the switch.

Made modifications to the Switching
> VLAN > ProtocolGroup web page
in order to resolve the issue.

VLAN > ProtocolGroup web page.

NIM_events prints unknown
characters.

Unknown characters being displayed are
for the interface name.

Properly initialized the variable.

<190> MAY 26 05:57:54 0.0.0.0-3
NIM[99904544]: nim_events.c(603) 367
%% Component NIM generated interface
event Unknown Port Event (39) for
interface ?j?????? (639).

VLAN protocol groups not
visible in GUI.

Cannot select the protocol group on the
Switching > VLAN > ProtocolGroup web

Display the group IDs in the list and
corresponding group name below it.

page.

Second protocol group not
shown in OpenManage GUI.

In protocol-based VLAN Show All page,
configured interfaces were not displayed

Corrected the display of the

interfaces.
properly. Web page affected Switching >
VLAN > Protocol Group Table.

Adding VLAN range issues.

1. When adding a range of VLANs

1. Corrected the error
to VLAN Database from Web
Interface, an error message is

2. Increased the maximum
returned when no name is

entered.

2. VLAN range is limited to 4
characters preventing adding
certain ranges.

Switch gives error message
when entered upper case letter
for interface value.

Custom Protocol-based VLAN
does not display configurable

On the interface ethernet CLI command,
switch gives error message when entering
interface names in upper case letters.

Valid range of supported ethertypes is not
mentioned in CLI help.

String is converted to lower case
before processing.

Add supported range in CLI help.

ethertype value.
Captive Portal login does not

display error message for
invalid credentials.

OpenManage Web UI shows
invalid MAC address (all 0s) in
ARP table.

Captive Portal user can get confused
since the login failure is not reported
correctly.

Configuring Proxy ARP results in the ARP
Table web page displaying the MAC
address as all zeros.

Implemented logic that verifies the
session state.

Corrected the output of the MAC
Address in the ARP Table to be the
same as the Dynamic Address
Table web page.

Unable to authenticate a client
when radius server is given a
name

User authentication does not happen
when there is no default radius server.

The switch was assuming that the
default named radius server will
always be present. Therefore, when
no default named server is present
the switch will attempt to send it to
the next valid radius server.

handling for this scenario.

length to 250 such that a
comma separated VLAN
list can be configured.

System Firmware Version 3.2.0.6 Page 19

Description User Impact Resolution

Changing Radius Timeout from
Web interface inadvertently
changes Priority to same value.

Radius Servers always show
active status.

Interface Configuration web page
would not allow the user to set the
MTU size to zero.

PCs or clients do not authenticate
after reboot and logging back on
(802.1x).

Web Display of Rapid Spanning
Tree only displays first 10 interface
ports

Web Global Portfast applies
Portfast on trunk switchports

IGMP Snooping failing on PC6200
stack of two switches

Changing the Timeout Duration field on the
RADIUS Server Configuration web page would
also change the Priority field to the same value.

The RADIUS Server Status web page was
always displaying the server’s status as active.

Interface Configuration web page restricted the
user to configure the IP MTU from 68-9198.

Windows Vista clients were not getting re­authenticated after the PC rebooted.

The Rapid Spanning Tree Table web page
would only display the first 10, and potential
incorrect interfaces.

Activating global portfast from the Web
Interface applies portfast to trunk interfaces
(Switching>Spanning_Tree>Global_Settings).
When removing portfast globally via the CLI, it
will not remove it from trunks.

Two copies of DLF/Bcast/Unknown unicast
packet will be sent out of the port 1 to 24 if two
PC6248 switches are stacked using both the
stack ports to form stack trunk.

Correct the API to properly set the
RADIUS priority.

Retrieved the server status the same as
the CLI for each row in the web page
display.

Changed the weg page IP MTI field do
allow the following values to be
configured: 0 or 68-9198.

Modified the state machine to move to
connecting state to trigger the sending of
the EAP-REQ packet.

Corrected the web page backend API to
retireve all of the applicable interfaces.

While applying Portfast via the GUI, no
check was present to know what the
switchport access of a particular
interface was hence the portfast was
being applied even on trunk switchports.

Modified the driver layer to ignore this
trunk-id while destroying external trunks.

20 System Firmware Version 3.2.0.6

PowerConnect 6224/6224F/6224P/6248/6248P Release Notes

CLI Reference Manual Updates

Non-Stop Forwarding

Title Description

nsf

no nsf

show nsf Use this command to show the status of non-stop forwarding.

show checkpoint statistics Use this command to display the statistics for the check pointing process.

clear checkpoint statistics Use this command to clear the statistics of the check pointing process.

vlan routing vlanid [index] This command is used to enable routing on a VLAN. Us the “no” form of

nsf [ ietf ] [ planned-only ] Use this command to enable OSPF graceful restart. Use the “no” form of

nsf helper [ planned-only ] Use this command to allow OSPF to act as a helpful neighbor for a

nsf [ietf] helper strict-lsa-checking

no nsf [ietf] helper strict-lsa-checking

nsf [ietf] restart-interval seconds Use this command to configure the length of the grace period on the

show ip ospf This command has been enhanced to lists the values of the configuration

Use this command to enable non-stop forwarding. The “no” form of the
command will disable NSF.

Default: Non-stop forwarding is enabled by default.

Default: Not applicable

Default: Not applicable

Default: Not applicable

the command to disable routing on a VLAN.
Default: Routing is not enabled on any VLANs by default.

this command to disable graceful restart.

• ietf — This keyword is used to distinguish the IETF standard
implementation of graceful restart from other implementations. Since
the IETF implementation is the only one supported, this keyword is
optional

• planned-only — This keyword indicates that OSPF should only

perform a graceful restart when the restart is planned (i.e., when the
restart is a result of the initiate failover command).

Default: Graceful restart is disabled by default.

restarting router. Use the “no” form of this command to prevent OSPF
from acting as a helpful neighbor.

• planned-only — This keyword indicates that OSPF should
only help a restarting router performing a planned restart.

Default: OSPF may act as a helpful neighbor for both planned an
unplanned restarts.

This command is used to require that an OSPF helpful neighbor exit
helper mode whenever a topology change occurs. Use the “no” form of
this command to allow OSPF to continue as a helpful neighbor in spite of
topology changes.

Default: A helpful neighbor exits helper mode upon a topology change.

restarting router. Use the “no” form of this command to revert the grace
period to its default.

• ietf — This keyword is used to distinguish the IETF standard

implementation of graceful restart from other implementations. Since
the IETF implementation is the only one supported, this keyword is
optional.

seconds — The number of seconds that the restarting router asks its

•

neighbors to wait before exiting helper mode. The restarting router
includes the restart interval in its grace LSAs (range 1 – 1800
seconds).

Default: The default restart interval is 120 seconds.

parameters described above and the status parameters defined in the
RFC 4750 MIB.

System Firmware Version 3.2.0.6 Page 21

Title Description

show ip ospf neighbor This command has been enhanced to list the per neighbor graceful restart

Port Configuration Show Command

Title Description
show interfaces detail {ethernet interface | port-

channel port-channel-number}

Custom Protocol Based VLANs

Title Description
vlan protocol group add protocol <groupid>

ethertype <value>
no vlan protocol group add protocol <groupid>

ethertype <value>

vlan protocol group <groupid>
no vlan protocol group <groupid>

vlan protocol group name <groupid>

<groupName>
no vlan protocol group name <groupid>

status described in the RFC 4750 MIB. Possible values for Restart Helper
Status are as follows:

• Helping – This router is acting as a helpful neighbor to this neighbor.

• Not Helping – This router is not a helpful neighbor at this time.

A new single command that shows VLAN, STP, Port status, and Port
Configuration information.

Default: Not applicable

Previously only ARP, IP and IPX are configurable as protocols for
protocol-based VLANs. This has been extended so that any Ethertype
may be used.

• groupid—The protocol-based VLAN group ID, which is
automatically generated when you create a protocol-based VLAN
group with the vlan protocol group command. To see the group
ID associated with the name of a protocol group, use the show
port protocol all command.

• ethertype—The protocol you want to add. The ethertype can be
any valid hexadecimal number in the range 1536 to 65535.

Default: Not applicable
If the user creates multiple vlan protocol groups, deletes one of them, and

then saves the configuration, the older implementation of this command
resulted incorrectly applying the groupids on reload. Hence, the existing
command vlan protocol group <groupname> is updated to vlan
protocol group <groupid> so that groupid is used for both configuration
and script generation.

• groupid—The protocol-based VLAN group ID, to create a protocol­based VLAN group. To see the created protocol groups, use the

show port protocol all command.

Default: Not applicable

This is a new command for assigning a group name to vlan protocol group
id.

• groupid—The protocol-based VLAN group ID, which is
automatically generated when you create a protocol-based VLAN
group with the vlan protocol group command. To see the group
ID associated with the name of a protocol group, use the show
port protocol all command

• groupNa me—The group name you want to add. The group name
can be up to 16 characters length. It can be any valid alpha
numeric characters.

Default: Not applicable

VLAN Name Support with RADIUS Server

Title Description
show dot1x Ethernet interface The command was updated to display the VLAN Id, or name as required.

22 System Firmware Version 3.2.0.6

Default: Not applicable

PowerConnect 6224/6224F/6224P/6248/6248P Release Notes

RADIUS Accounting Servers

Title Description

radius-server host acct

The switches do not support creating accounting server names with the
same name although the CLI Reference Manual and User Guide state
that it is supported.

Default: Not applicable

Spanning Tree

Title Description

no spanning-tree transmit hold-count

The hold-count keyword is not required when resetting the spanning-tree
transmit hold-count.

Default: Not applicable

Stacking/CX-4 Module Configuration

Title Description
stack-port <unit>/<port-type> <port-num>

{ethernet | stack}

This command is used to configure a port on a CX-4 or stacking plug-in
modules as either an ethernet or stack port.

Default: From the factory the ports are all configured as Ethernet ports.
If upgrading from a previous release the modes will be preserved and no
configuration should be necessary.

Configurable Message of the Day Banner

Title Description
banner motd <message>

no banner motd

banner motd acknowledge
no banner motd acknowledge

Controls (enables or disables) the display of message-of-the-day banners.
‘banner motd’ enables the banner, and allows configuration of message­of-the-day banners. Use ‘no banner motd’ to delete the message, and
disable the banner.

Default: Disabled by default.
The user will be required to acknowledge the banner displayed on the

console if ‘banner motd acknowledge’ is executed. The user would have
to type "y" or "n" to continue to the login prompt. If "n" is typed, the
session is terminated and no further communication is allowed on that
session. However, serial connection will not get terminated if user does
not enter ‘y’. Use ‘no’ form of the command to disable banner
acknowledge.

Default: Disabled by default.

Dot1X

Title Description
dot1x timeout guest-vlan-period Use this command in Interface Config Mode to set the number of seconds

that the switch waits before authorizing the client if the client is a dot1x
unaware client.

Default: The switch remains in the quiet state for 90 seconds.
Refer to the

Guide for details.

Dell™ PowerConnect™ 6200 Series Systems CLI Reference

System Firmware Version 3.2.0.6 Page 23

Link Dependency Commands

Title Description
link-dependency group [ action { up | down } ] Use the action command to control the operational state of the group

Multicast

Title Description

ip pimdm mode
ip pimdm query-interval
show ip pimdm interface

User’s Guide Updates

based on the dependent links state.

• up — Causes the group members to change their operational
state to be opposite that of the dependent link.

• down — Causes the group members to change their
operational state to follow that of the dependent link.

Default: Not applicable.

PIM-DM commands not supported in the 3.2 release are documented in
the CLI Reference Manual.

Configuring Dell PowerConnect

Title Description

User’s Guide
Configuration Guide

See: Dell™ PowerConnect™ 6200 Series User’s Guide
See: Dell™ PowerConnect™ 6200 Series Configuration Guide

24 System Firmware Version 3.2.0.6

PowerConnect 6224/6224F/6224P/6248/6248P Release Notes

Known Issues

Summary User Impact Workaround

Non-configuration file
getting loaded to
startup-config through
HTTP.

TACACS operation User cannot enter Privileged EXEC mode

Ping fails with 33% to
100% packet loss

OSPF Dead interval
expires on neighbor,
when the DUT stack
manager restarts with
large configuration.

VLAN configuration is
not successful on
ports after detaching
them from LAG.

Issue with PBVLAN
configuration
migration.

Read/write user is
getting read only
access when
authentication
method is used as
TACACS.

TFTP gives no
reason for file
download failures.

CLI command stack­port config rejection
does not display the
cause.

Banner MOTD: The
switches Console and
Web sessions are
inaccessible until the
user acknowledges
the banner of the day.

DHCP server has
data changed flag set
after booting from
saved config.

When the switch reboots and attempts to
read an invalid start-up configuration file, it
will give up and create a default startup
configuration.

without using the enable command.
Using a Windows 7 client and pinging with a

59900 byte packet will result in packet loss.
In a large stack with an unusually large

configuration, it is possible that during an
unplanned failover, the control plane may
not issue OSPF grace LSAs before the dead
interval expires on neighbors. When this
happens, neighbors report the router down
and other routers in the area recomputed
OSPF routes to avoid the restarting order.

The issue is that any VLAN configuration
applied to a physical port while it is a
member of a LAG will not be applied when
the port leaves the LAG.

The command vlan protocol group expected
a string in earlier versions; now it expects a
number.

The user always gets Read-Only access if
using TACACS as a means for HTTP
authentication, even if the TACACS user is
Read/Write capable.

Generic failure message. None.

If a user enters an invalid interface, a
generic error message will be generated:
ERROR: Invalid input.

The current implementation of the MOTD
acknowledgement results in all user
interface sessions being inaccessible until
the user enters a response or the 30-second
timeout occurs. While the acknowledge
process is pending, it cannot process the
other UI sessions. Once the timeout occurs,
then the MOTD acknowledgement ends the
connection and resumes processing of the
other sessions.

If DHCP server is enabled, then the user
may be prompted to save configuration
changes even though no configuration
changes have been made.

It is recommended that all users keep
backups of their configuration files.

None.

None.

Increase the dead internal timer.

This is not a problem if VLAN configuration
is performed while the port is not a member
of a LAG. If the configuration is saved and
the switch is reset, the configuration is
applied correctly.

The software recognizes if the group name
is alphanumeric, however it will not work
when the name of the group is numeric (for
example 2, 3, etc.)

User can configure the same TACACS user
locally and use LOCAL authentication
method for HTTP. The user will be able to
get access based on this local user access
level (Read-write or Read-only).

None.

Acknowledge the message to avoid the
session timeout.

None.

System Firmware Version 3.2.0.6 Page 25

Summary User Impact Workaround

Bridge multicast
address is shown as
MAC Address format
in show running-
config buffer when it
is configured in IP
format.

Connected spanning
tree root port role not
changed to auto­portfast after
disabling MSTP on
Trunk.

Three commands are
not available at
interface range
Ethernet level, but
are available at
interface.

There is no command
to add protocol vlan
in interface range
mode.

Invalid error port
number displayed on
log message when
VLAN is changed to
forbidden mode from
access mode.

Gratuitous ARP
packets are not being
generated when
management VLAN is
changed with static IP
configuration.

Using interface range
mode not able to
configure protected
ports.

TFTP fails to display
specific error
message when
incorrect filename
was given while
downloading the
code.

Web needs to provide
an option to configure
sFlow sampler / poller
values on range of
interfaces.

If a user configures the bridge multicast
address as an IP address format in VLAN
interface mode, it is displayed in the show
running-config command in MAC address
format.

A port that is a root port will not become auto
edge port if the bridge that the root port is
connected to goes away.

The following commands are not available to
use in interface range Ethernet level: isdp,
lacpa, and protocol.

The user cannot use interface ranges to
configure a protocol VLAN.

When port is changed to forbidden mode
from access mode, the log message below
is generated that reports the wrong port
number.

<187> OCT 12 08:39:03 10.131.6.173-1
DOT1Q[104741168]: dot1q_api.c(525) 2475
%% Port(88)

This log message is correct when a port
from the base unit is selected.

If the user changes the management VLAN,
then management connections must be re­established on the new VLAN. Neighbors
will resolve the switch’s management IP
address on the new VLAN.

Cannot use interface range mode to
configure protected switchports.

If a user attempts to tftp a non-existent file to
the image of the switch, nothing will be
downloaded and there will not be an error
message generated.

User will not be able to select range of
interfaces through web for the Sampler and
Poll Configuration web pages. However,
configuration is not affected as user can
individually select the interfaces and
configure.

None.

This means that the port would flush the
Forwarding Database entries every time that
there is a topology change. This could be
avoided if the link goes down and comes
back up.

Each interface must be configured
individually.

Each protocol VLAN must be configured
individually.

None.

None.

The user must configure each protected port
individually.

None.

User has to select each interface individually
to configure in the Sampler Configuration
and Poll Configuration web pages.

26 System Firmware Version 3.2.0.6

PowerConnect 6224/6224F/6224P/6248/6248P Release Notes

Summary User Impact Workaround

ISDP updates are not
including Voice VLAN
Reply TLV when
Voice VLAN ID on
interface is changed.

PC6200 fails to re­authorize IP phone
upon enabling and
disabling Voice VLAN
authentication.

Upon changing configuration immediately
after getting the VLAN assigned, DUT stops
advertising Voice VLAN reply TLV in its
ISDP updates which causes IP phone to
change its VLAN properties.

Once a phone is configured, enable Voice
VLAN authentication, wait for DHCP
discovery again, and then disable Voice
VLAN authorization. On disabling Voice
VLAN authorization, PC6200 fails to

The administrator can work around this
problem by shutting down the port and
restarting it after the configuration is
changed.

Disconnect and reconnect the phone to the
port, the phone gets authorized.

authorize IP phone based on the received
LLDP packet (with network policy TLV).

When Line or enable
method is used as
login method and
enable authentication
is none, the user is
unable to enter into
Privileged EXEC

If login authentication method is Line or
Enable, and enable authentication is None,
you will always get read-only access
(because there is no user configured for line
or enable authentication). The user will
never get read-write access.

If enable authorization is set to None, ensure
that the login authorization method is at least
TACACS, Radius, or Local. Any
authentication method that requires a user
configuration will ensure that the user will get
proper access based on how the user is
configured.

mode.
Cannot change LAG

mode from Static to

Cannot change LAG mode from Static to
Dynamic via CLI.

The user may change the LACP Mode using
the Graphical User Interface.

Dynamic via CLI.

System Firmware Version 3.2.0.6 Page 27

Known Restrictions and Limitations

Layer 2

802.1AB (LLDP)

Description User Impact

LLDP-MED location and inventory
transmit TLVs have no effect.

QoS

Description User Impact

Traffic permitted by an outbound
ACL on one port can be allowed on
another port.

Ip-dscp-mapping is not working as
per the configured priority Queues on
10G (CX4) ports.

The switch does not support configuring this data so enabling these TLVs
has no effect.

This behavior is a limitation of implementing egress ACLs on an ingress
classifier.

Given a configuration where two outbound ACLs are active on different
ports. Since both ACLs are applied in the 'out' direction, the rules
programmed into the IFP will match on any ingress port. Ultimately, w/ the
implementation of egress ACLs on the ingress classifier, unexpected
behavior occurs if overlapping rules (i.e. a given packet can match multiple
rules) are applied to different ports in the outbound direction.

This is only an issue when forwarding traffic between 10G interfaces on
different switches in a stack. The stack link can only support 12G so if it is
oversubscribed, the effects of the queues are reduced.

802.1X

Description User Impact

Windows Vista® Authentication The Windows Vista® client could fail to authenticate properly when the

option to cache user credentials is selected.
Workaround:

1. In Control Panel Æ Network Connections, right-click on the
desired Local Area Connection and select Properties.

2. In the Properties window, select the Authentication tab.

3. Deselect the checkbox for Cache user information for
subsequent connections to this network.

4. Click OK.

28 System Firmware Version 3.2.0.6

PowerConnect 6224/6224F/6224P/6248/6248P Release Notes

LACP

Description User Impact

LAGs Supported Number of LAGs supported:

• Up to 18 Dynamic LAGs

• 48 Static LAGs

Limitations (stack of 12)

• Long Timeouts

With a minimal CPU load, it takes approximately 1.5 minutes with
16 dynamic LAGs and 15 MSTP instances for the ports to
become active with traffic running.

• Short Timeouts
With a minimal CPU load, it takes approximately 1.5 minutes with

12 dynamic LAGs and 15 MSTP instances for the ports to
become active with traffic running.

VLAN

Description User Impact
vlan association mac command

limitations

The maximum number of MAC-based VLANs is 256.

Layer 3

IP Map

Description User Impact
ip default gateway and ip default

route are for different types of

interfaces. ip default gateway is for
the management interface and ip
default route is for VLAN routing
interfaces.

DiffServ

Description User Impact

Failed to attach diffserv policy to an
interface with mark cos and assign
queue attributes.

Ensure the correct command is used for the interface being configured.

This behavior is a known limitation of the PowerConnect 6200 series
switches.

System Firmware Version 3.2.0.6 Page 29

ICMP

Description User Impact

IPv4 Fragmentation support The switch is not fragmenting the datagram and forwards even when the

IP MTU of the forwarding Interface is set to a lower value (than the
datagram size).

This is a hardware limitation and is working as designed. The HW does
not allow the IP MTU to be configured per VLAN. We can configure the
maximum frame size in HW using the 'mtu' command in interface Ethernet
mode. However, if a packet exceeds the maximum frame size for a port, it
is discarded. If a packet happens to be sent to the software and it exceeds
the IP MTU, then the packet still will not be fragmented. An ICMP error
message is sent to the sender.

ICMP Error message generation

ICMPv6 Packet Too Big The system is not generating Packet Too Big message to the source when

The ICMP Error Message generated by the switch has the fields (TTL)
unmodified instead of sending with a modified value resulted as a part of
forwarding process.

it forwards the packet through an interface vlan with mtu smaller than the
packet being forwarded.

The PowerConnect 6200 Series switches do not have the capability to
enforce IP MTU on VLAN Routing interfaces..

Multicast

Description User Impact

Multicast VLC streams are not
received on VLC client on complex
network topology.

This is not a mainstream problem. DVMRP functionality works fine and
such issues are not seen in 2 or 3 router topologies. This issue is seen
only in complex topologies under high loads in the presence of other
multicast entries upon table full conditions.

30 System Firmware Version 3.2.0.6

PowerConnect 6224/6224F/6224P/6248/6248P Release Notes

Management

CLI

Description User Impact

radius-server mode commands do
not have a "no" form.

SNMP

Description User Impact

Not able to set the value for
dellLanMngInfEnable

dot3StatsAlignmentErrors not
incrementing

agentInventoryStackReplicateSTK
object not working as expected

agentStpPortRootGuard object Use agentStpCstPortRootGuard instead.

None of the commands in radius-server mode support a "no" form except
for the msgauth command. To reset values to the default, delete the
server and add it back.

Management ACLs are always enabled and cannot be disabled.

The value for all ports shows up as 0.

Copies backup image of master to member instead of active image of
master.

Web-based Management

Description User Impact

Traffic Monitoring Chart Rate Display The chart displays a count rather than a rate.
Stacking Ports displayed on the

LLDP, LLDP-MED, and Voice VLAN
configuration pages

Browser-specific issue: On the
VRRP Router Configuration page,
the authentication type is not saved
when using Firefox v2.x.

The interface selections available on the configuration pages contain the
stacking ports which are not applicable.

To configure the authentication type, either upgrade the browser to Firefox

3.x or use the CLI.

System Firmware Version 3.2.0.6 Page 31

Cable Diagnostics

Description User Impact

Cable Length Diagnostic shows
result as 'Unknown' for a port to
which Network is connected.

File Management

Description User Impact

Error displayed on console while
applying configuration for a 48 port
switch to a 24 port switch.

CLI Comment Character The '!' indicates the beginning of a comment. All characters following the '!'

Problem is intermittent and only observable when connected to a D-Link
DES1008.

When applying configuration to ports which do not exist, errors are
generated such that all subsequent commands fail.

User Action: Remove the configuration for the non-existent ports.

will be treated as a comment.

End of Release Notes

32 System Firmware Version 3.2.0.6
