Model FF-2
PROJECT
ITEM #
QUANTITY DATE
APPROVAL
FF
Built-in remote ice cream dispensers
Short form specications
The exterior sides and top edge shall be 20-gauge galvanized steel. Exterior bottom to
be 14-gauge galvanized steel.
Inner liner shall be water-tight and constructed of 22-gauge stainless steel with a
1.25" (3.2cm) I.P.S. drain. Opening(s) shall have throat liners constructed of high impact
plastic. Unit to be insulated with foamed-in-place polyurethane insulation with a nonconductive top breaker strip.
Each opening shall have an insulated, stainless steel folding lid with high impact plastic
liner, molded rubber edge and black plastic handles.
Each self-leveling mechanism shall be eld adjustable by adding or removing stainless
steel extension springs in the elevator housing inside the unit. The elevators shall be
connected by removable platform carriers constructed of 18-gauge stainless steel.
(6) anodized aluminum divider trays will be supplied per opening. NOTE: See chart on
back for ice cream storage capacity.
Refrigeration system (provided by others) shall use HFC-404A refrigerant. An expansion valve and copper tubing connection to the remote refrigeration system shall be
provided.
NOTE: Temperature and pressure controls are not provided on remote models.
Optional accessories & modications
• Lid locking device
• Wire baskets
This equipment is intended for storage and/or
display of pre-packaged products only.
The Delfield Company, 980 S. Isabella Rd., Mt. Pleasant, MI 48858, U.S.A. • (800) 733-8821 • Fax (800) 669-0619 • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2002 The Delfield Company. All rights reserved. Printed in U.S.A.
![](/html/85/85fb/85fb1bca0b0c839d7849e4ae0f74d080ea5abec3b4a05ab3c8a12614be474578/bg2.png)
FF
14.50"
36.8cm
26.25"
66.7cm
2.62"
6.7cm
1.87"
4.8cm
REBMUNLEDOM
SNOISNEMIDTUOTUC
)DxL( YTICAPAC
-ESROH
†REWOP DAOLUTB
.PAVE
.PMET
PIHS
THGIEW
4233-FF
"00.12x"57.01)1(
mc3.35xmc3.72)1(
ecnuo-eerht012
spucmaerceci
†4/1 034
21– F
42– C
sbl512
gk89
2-FF
*"00.12x"57.01)2(
*mc3.35xmc3.72)2(
ecnuo-eerht024
spucmaerceci
†3/1 017
41– F
62– C
sbl092
gk231
tuotuchcaeneewteb)mc0.7("57.2seriuqer*
dednemmocereranwohssgnitarrewopesroh;smetsysnoitaregirferetomereriuqersledomFF†
28.00"
71.1cm
26.25"
66.7cm
2.62"
6.7cm
1.87"
4.8cm
2.75"
7.0cm
Built-in remote ice cream dispensers
PLAN VIEW
MODEL FF-3324
ELEVATION VIEW
MODEL FF-3324
PLAN VIEW
MODEL FF-2
ELEVATION VIEW
MODEL FF-2
LID OPENING DETAIL
ALL FF MODELS
CUTOUT ORIENTATION
(PLAN VIEW)
RIGHT END VIEW
ALL FF MODELS
The Delfield Company, 980 S. Isabella Rd., Mt. Pleasant, MI 48858, U.S.A. • (800) 733-8821 • Fax (800) 669-0619 • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2002 The Delfield Company. All rights reserved. Printed in U.S.A.
MSFF 10/01
