DEA PASS User Manual

COD.

EN

OTHER CHARACTERISTICS

644031 PASSNET/L

IN COMPLIANCE

WITH STANDARDS

4 and 5 mt

slow

•

NET230N •

- Speed adjustment during normal cycle and slow down in opening
and closing

- Motor controlled by encoder and obstacle detection

- Possibility to lock the programming to prevent tampering

COD.

EN

OTHER CHARACTERISTICS

644020 PASS24NET/V

IN COMPLIANCE

WITH STANDARDS

3 mt fast

• •

NET24N •

- Speed adjustment during normal cycle and slow down in
opening and closing

- Motor control by encoder

- Possibility to lock the programming to prevent tampering

644022 PASS24NET/VR

IN COMPLIANCE

WITH STANDARDS

4 mt fast

• •

NET24N •

644021 PASS24NET/L

IN COMPLIANCE

WITH STANDARDS

4 and 5 mt slow

• •

NET24N •

NET230N

230V a.c. barriers with control board for residential use

230V a.c. barriers without control board for residential use to install 2 opposite barriers

24V a.c. barriers without control board for semi-intensive use to install 2 opposite barriers

Electromechanical barrier

PASS

NET24N

24V d.c. barriers with control board for semi-intensive use

All models have: flashing lights, boom, boom holder and foundation plate not included (see on page 102) - stainless steel version: available on demand
Warning: Proper functioning of this model is guaranted with perfect balance of the spring and adjustment of slow down

All models have: flashing lights, boom, boom holder and foundation plate not included (see on page 102) - stainless steel version: available on demand
Warning: Proper functioning of this model is guaranted with perfect balance of the spring and adjustment of slow down

COD. OTHER CHARACTERISTICS

644003 PASS/SL 4 and 5 mt slow

•

• - To be combined with PASSNET/L

COD. OTHER CHARACTERISTICS

644012 PASS24/SV 3 mt fast

• •

• - To be combined with PASS24NET/V

644019 PASS24/SVR 4 mt fast

• •

• - To be combined with PASS24NET/VR

644013 PASS24/SL 4 and 5 mt slow

• •

• - To be combined with PASS24NET/L

TECHNICAL INFO

PASSNET/L

PASS/SL

PASS24NET/V

PASS24/SV

PASS24NET/L

PASS24/SL

PASS24NET/VR

Motor power supply (V)

230 AC ± 10 % (50/60 Hz)

24 DC

24 DC

24 DC

Maximum power absorption (W)

320

105

105

105

Type of boom

Refer to "Boom Length" table of instructions manual

Duty cycle (cycles/hours)

80

290

140

240

N. max cycles in 24h.

400

1150

700

960

Built-in capacitor (μF)

8//

/

Operating temperature (°C)

-20 ÷ 50

-20 ÷ 50

-20 ÷ 50

-20 ÷ 50

Motor thermal protection (°C)

150//

/

90° Opening time (s)

7,3

2,262,8

Weight with packing (Kg)

424141

41

Protection degree

IP34

IP34

IP34

IP34

IN COMPLIANCE

WITH STANDARDS

100

Cod. 649160

Art. BSF

Bracket for Linear photocells

Cod. 672580

Art. TR2

Remote control

Black version art. TR2N also
available (page 118)

Cod. 381744

Art. OMPASS

Boom holder for DEA rectangular
booms art. PASS3 and PASS4

Cod. 649180

Art. CLED230

Flashing light circuit, 230V,
to be installed under the cover
or into barriers cabinet

EXAMPLE OF A TYPICAL INSTALLATION

ELECTRICAL DIAGRAM

A

4x1 mm² (230V) o 3x1,5 mm² (24V )

4x0,5 mm²

2 x 0,5 mm² - RG58

2x0,5 mm²

3x0,5 mm²

229322

Max 5000

1162

803

76

Cod. 668010

Art. 127

Warning sign

Cod. 321810

Art. GSOFTP

Safety rubber profile for STOP and PASS,
EDPM S65, 24 mt.

DIMENSIONS

BARRIERS

deasy stem.co m

101

1

Cod. 644030

Art. PASSNET/V

Electromechanical barrier
(without foundation plate)

Cod. 662044

Art. LINEAR

Pair of adjustable photocells (180°)
with possibility of syncronized operating.
Range 20 Mt

3

5

Cod. 664000

Art. PILLY/60

Pair of aluminium columns for photocells,
height 55 cm.

4

Cod. 649140

Art. PASS3

DEA rectangular painted boom mm.
300x65x38, with fluorescent red
stickers art. 1012

2

1

Cod. 649073

Art. PASS/B

Foundation plate

1

3

2

5

4

Cod. 381744

Art. OMPASS

Boom holder for DEA rectangular

booms art. PASS3 and PASS4

Cod. 649141

Art. PASS4

DEA rectangular painted boom mm.

4000x65x38, with fluorescent red

stickers art. 1012

Cod. 649140

Art. PASS3

DEA rectangular painted boom mm.

300x65x38, with fluorescent red

stickers art. 1012

Cod. 649240

Art. PASS5

DEA rectangular painted lightweight boom mm.

5000x80x40, without fluorescent stickers.

To be used with PASSNET/L, PASS/SL,

PASS24NET/L, PASS24/SL ONLY

Cod. 649000

Art. 1006

Mobile boom support

Cod. 667061

Art. LOOP 230/1

Loop detector, 1 channel

Cod. 649073

Art. PASS/B

Foundation plate

Cod. 649180

Art. CLED230

Flashing light circuit, 230V,
to be installed under the cover
or into barriers cabinet

Cod. 649250

Art. OMPASS5

Boom holder for DEA rectangular

booms art. PASS5

Cod. 649020

Art. 1010

Adjustable fixed boom support

Cod. 667071

Art. LOOP 230/2

Loop detector, 2 channels

Cod. 321810

Art. GSOFTP

Safety rubber profile for STOP and PASS,
EDPM S65, 24 mt.

Cod. 649172

Art. LEDPASS

Led Strip + Feeder for booms PASS3 and
PASS4 (4 mt. long)

Cod. 381741

Art. OMPASS60

Boom holder for commercial
rectangular booms 60x30mm

Cod. 649021

Art. 1010/M

Adjustable fixed boom
support with magnet

Cod. 681030

Art. SMF230/2

Lamp traffic light with red-green lights

Cod. 101004

Art. 1012

Fluorescent red stickers

SPECIFIC ACCESSORIES

Cod. 649181

Art. CLED24

Flashing light circuit, 24V,
to be installed under the cover
or into barriers cabinet

Not compatible with other accessories or with the front plastic cover of the boom holder

Cod. 672590

Art. TR4

Remote control

Black version art. TR4N also available
(page 118)

Cod. 681060

Art. COVER

Vandal-proof aluminium cover for
art. LINEAR and LINEAR/B

Cod. 663060

Art. KYO

Aluminium vandal-proof
keyswitch, flush mounted.

Cod. 663030

Art. 102LUX

Keyswitch with two contacts, flush
mounted. Supplied with 2 keys.

Cod. 664020

Art. PILLY/base

Pair of fixing plates for columns
to be cemented.

Cod. 649200

Art. BAT/PASS

Batteries set for PASS barriers complete
with 2 x 4,5Ah batteries, fixing plates
and connecting cables

Cod. 677600

Art. NET230N

Universal digital control board for 1 or 2
operators, 230V, with or without magnetic
encoder

Cod. 662044

Art. LINEAR

Pair of adjustable photocells (180°)
with possibility of syncronized operating.
Range 20 Mt

Cod. 649160

Art. BSF

Bracket for Linear photocells

Cod. 663280

Art. DIGIRAD

Wireless keypad

Cod. 664000

Art. PILLY/60

Pair of aluminium columns for photocells,
height 55 cm.

Cod. 672580

Art. TR2

Remote control

Black version art. TR2N also available
(page 118)

Cod. 662043

Art. LINEAR/B

Pair of adjustable photocells (180°)
with tx supplied by a LiOn battery.
Range 7/15 Mt

Cod. 663270

Art. DIGINET

Hardwired keypad for BUS connections
to MASTER devices of range DE@NET
(NET24N, NET230N, MASTERNET)

Cod. 664010

Art. PILLY/120

Pair of aluminium columns for photocells,
height 100 cm.

OTHER ACCESSORIES

Cod. 678251

Art. NET24N

Universal digital control board for 1 or 2
operators, 24V, with or without magnetic
encoder
