DB Technologies FM-10 User Manual

Series

FLEXSYS FM8
FLEXSYS FM10
FLEXSYS FM12

Digital Active Speakers & Monitors

Series

FM

Active Monitors

FLEXSYS FM8

PACK

Active Coaxial Stage Monitors

A revolution in live sound reinforcement, the Flexsys FM Series
comprises a range oftailored monitoring solutions featuring innovative
technologies.

Housed in compact multifunctional enclosures, these units raise the bar
for intelligibility, definition, and ease of use. They are the discerning
user’s first choice when nothing less than the best on-stage
monitoring will do.

Remarkably resistant to feedback

These newly developed coaxial speakers deliver extraordinary sound
quality that defies the compact design of their housings.

Engineered for precise directivity and uniform throw patterns, they
provide the same satisfying audio experience at every listening position,
with far greater resistance to feedback.

Technical Data

Speaker Type: 2-Way Active Coax ial Stage Monitor

Acoustical data
Frequenc y Response [+/- 3dB]: 77 - 20.0 00 Hz

Max SPL: 117 dB
HF: 1 “
Type HF: compression driver
Horn: CD Horn
LF: 8”

Amplifier

Amp Technology: Digipack™
Amp Class: Class D
Power PRG: 200 W
Peak Power: 400 W

Processor

Controller: DSP 24bit/48kHz
System Presets: 8 presets
Limiter: Dual Active Peak, RMS, Thermal

Mechanics

Housing: Multiplex with H.E.T coating, reinforced
Housing Design: Multifunct ional, Low Profile
Angles Up: 2 monitor angles °
Width: 28 0 mm (11.2 in)
Height: 290 mm (11.6 in)
Depth: 410 mm (16.4 in)
Weight: 9.8 kg (21.61 lbs)

DSP with eight presets for easy
adaptation to varying requirements

FM Series monitors feature a powerful DSP that offers a crossover,
digital multiband limiters, phase correction, and eight variable presets
that serve to adapt the monitor to the varying demands of vocalists,
instrumentalists, and audio playback applications.
