FLEXSYS F8

Technical Data

Speaker Type: 2-Way Active Speaker

Acoustical data
Frequenc y Response [-10dB]: 75 - 20.000 Hz

Frequenc y Response [+/- 3dB]: 90 - 19.000 Hz
Max SPL: 121 dB
HF: 1 “
Type HF: Neodymium compression driver
Directiv ity: 9 0/40 x 60 °
Horn: Asymmetr ical CD Horn
L F : 8 ”

Amplifier

Amp Technology: Digipro®
Amp Class: Class D
Power PRG: 40 0 W
Peak Power: 800 W

Processor

Controller: DSP 24bit/48kHz
System Presets: Flat, Processed
Limiter: Dual Active Peak, RMS, Thermal
Crossover Frequency LF- HF: 2100 Hz
Slope MF-HF: 24 dB/Octave

Mechanics

Housing: Multiplex
Angles Up: Monitor use 40 °
Width: 260 mm (10.4 in)
Height: 4 20 mm (16.8 in)
Depth: 260 mm (10.4 in)
Weight: 9.5 kg (20.9 lbs)

Speaker Type: 2-Way Active Speaker

Acoustical data
Frequenc y Response [-10dB]: 70 - 20.000 Hz

Frequenc y Response [+/- 3dB]: 80 - 19.000 Hz
Max SPL: 125 dB
HF: 1 “
Type HF: Neodymium compression driver
Directiv ity: 90/40 x 6 0 °
Horn: Asymmetrical CD Horn
LF: 10”

Amplifier

Amp Technology: Digipro®
Amp Class: Class D
Power PRG: 40 0 W
Peak Power: 800 W

Processor

Controller: DSP 24bit/48kHz
System Presets: Flat, Processed
Limiter: Dual Active Peak, RMS, Thermal
Crossover Frequency LF- HF: 2050 Hz
Slope MF-HF: 24 dB/Octave

Mechanics

Housing: Multiplex
Angles Up: Monitor use 40 °
Width: 30 0 mm (11.8 in)
Height: 4 80 mm (18.9 in)
Depth: 300 mm (11.8 in)
Weight: 12 kg (26.46 lbs)

FLEXSYS F10

Technical Data
