DATA SH EET

Product specification
File under Integrated Circuits, IC02

2000 Feb 04

INTEGRATED CIRCUITS

SAA4992H

Field and line rate converter with
noise reduction

2000 Feb 04 2

Philips Semiconductors Product specification

Field and line rate converter with noise
reduction

SAA4992H

CONTENTS

1 FEATURES
2 GENERAL DESCRIPTION
3 QUICK REFERENCE DATA
4 ORDERING INFORMATION
5 BLOCK DIAGRAMS
6 PINNING
7 FUNCTIONAL DESCRIPTION
8 CONTROL REGISTER DESCRIPTION
9 LIMITING VALUES
10 THERMAL CHARACTERISTICS
11 CHARACTERISTICS
12 PACKAGE OUTLINE
13 SOLDERING

13.1 Introduction to soldering surface mount
packages

13.2 Reflow soldering

13.3 Wave soldering

13.4 Manual soldering

13.5 Suitability of surface mount IC packages for
wave and reflow soldering methods

14 DEFINITIONS
15 LIFE SUPPORT APPLICATIONS

2000 Feb 04 3

Philips Semiconductors Product specification

Field and line rate converter with noise
reduction

SAA4992H

1 FEATURES

• Upconversion of all 1fH film and video standards up to

292 active input lines per field

• 100/120 Hz 2 : 1, 50/60 Hz 1 : 1 and 100/120 Hz 1 : 1

output formats

• 4:1:1, 4:2:2 and 4 : 2 : 2 Differential Pulse Code

Modulation (DPCM) input colour formats; 4 :1:1 and
4:2:2 output colour formats

• Full 8-bit accuracy

• Scalable performance by applying 1, 2 or 3 external

field memories

• Improved recursive de-interlacing

• Film (25 Hz, 30 Hz) upconversion to 100/120

movement phases per second

• Variable vertical sharpness enhancement

• Motion compensated 3D dynamic noise reduction

• High quality vertical zoom

• 2 Mbaud serial interface (SNERT).

2 GENERAL DESCRIPTION

The SAA4992H is a completely digital monolithic
integrated circuit which can be used for field and line rate
conversion of all global TV standards.

It features improved‘Natural Motion’ performance and full
film upconversion for all 50 and 60 Hz film material.

It can be configured to emulate the SAA4990H as well as
the SAA4991WP. For demonstration purposes a split
screen mode to show the Dynamic Noise Reduction
(DNR) function and a colour vector overlay is available.

The SAA4992H supports a Boundary Scan Test (BST)
circuit in accordance with IEEE 1149.

3 QUICK REFERENCE DATA

4 ORDERING INFORMATION

SYMBOL PARAMETER MIN. TYP. MAX. UNIT

V

DD

supply voltage 3.0 3.3 3.6 V

I

DD

supply current − 400 550 mA

f

CLK

operating clock frequency − 32 33.3 MHz

T

amb

ambient temperature 0 − 70 °C

TYPE

NUMBER

PACKAGE

NAME DESCRIPTION VERSION

SAA4992H QFP160 plastic quad flat package; 160 leads (lead length 1.6 mm);

body 28 × 28 × 3.4 mm; high stand-off height

SOT322-2

2000 Feb 04 4

Philips Semiconductors Product specification

Field and line rate converter with noise

reduction

SAA4992H

This text is here in white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here in

_white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here inThis text is here in

white to forcelandscapepages to be rotated correctly when browsing through the pdf in the Acrobat reader. white to force landscape pages to be ...

5 BLOCK DIAGRAMS

n

dbook, full pagewidth

MHB645

COMPRESS

DYNAMIC

NOISE

REDUCTION

MUX

SPM TPM ESM

MUX

FIELD MEMORY 2

YB7 to YB0
151, 152,

154 to 159

YC0 to YC7
2 to 9

DECOMPRESS

SAA4992H

61 to 68

45 to 52

YF7 to YF0

YG7 to YG0

YA0 to YA7

MPR
LEFT

UPCONVERSION

DE-INTERLACER

SNERT

INTERFACE

MOTION ESTIMATOR

MPR

RIGHT

82 to 89

27

SNCL

26

SNDA

25

SNRST

BST/TEST

35

vectors

vectors

TCK

34

TDO

33

TDI

32

TMS

31

TRST

30

TEST

79

CLK32

CONTROL

SEQUENCER

FIELD MEMORY 3

YD7 to YD0
111, 112,

114 to 119

YE0 to YE7
122 to 129

VERTICAL

ZOOM

VERTICAL

PEAKING

Fig.1 Block diagram of the luminance part.

The solid lines represent pixel data; the broken lines represent controls.

2000 Feb 04 5

Philips Semiconductors Product specification

Field and line rate converter with noise

reduction

SAA4992H

This text is here in white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here in

_white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here inThis text is here in

white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader. white to force landscape pages to be ...

d

book, full pagewidth

MHB646

COMPRESS/

FORMAT

UVB3 to UVB0
147 to 150

UVC0 to UVC3
10 to 13

DECOMPRESS/

REFORMAT

DNR

MPR
LEFT

DECOMPRESS/

REFORMAT

FORMAT

SAA4992H

70 to 77

37 to 44

UVA0 to UVA7

91 to 98

vectors

UPCONVERSION

MPR

RIGHT

VERTICAL

ZOOM

UVD3 to UVD0
107 to 110

UVE0 to UVE3

130 to 133

FIELD MEMORY 2 FIELD MEMORY 3

UVF7 to YVF0

UVG7 to YVG0

Fig.2 Block diagram of the chrominance part.

The solid lines represent pixel data; the broken lines represent controls.

2000 Feb 04 6

Philips Semiconductors Product specification

Field and line rate converter with noise
reduction

SAA4992H

6 PINNING

SYMBOL PIN TYPE DESCRIPTION

(1)(2)

V

SSE

1 ground ground of output pads
YC0 2 input bus C luminance input from field memory 2 bit 0 (LSB)
YC1 3 input bus C luminance input from field memory 2 bit 1
YC2 4 input bus C luminance input from field memory 2 bit 2
YC3 5 input bus C luminance input from field memory 2 bit 3
YC4 6 input bus C luminance input from field memory 2 bit 4
YC5 7 input bus C luminance input from field memory 2 bit 5
YC6 8 input bus C luminance input from field memory 2 bit 6
YC7 9 input bus C luminance input from field memory 2 bit 7 (MSB)
UVC0 10 input bus C chrominance input from field memory 2 bit 0 (LSB)
UVC1 11 input bus C chrominance input from field memory 2 bit 1
UVC2 12 input bus C chrominance input from field memory 2 bit 2
UVC3 13 input bus C chrominance input from field memory 2 bit 3 (MSB)
REC 14 output read enable output for busC
V

SSE

15 ground ground of output pads

V

DDE

16 supply supply voltage of output pads

V

SSI

17 ground core ground

V

DDI

18 supply core supply voltage

JUMP0 19 input configuration pin 0; will be stored in register 0B3 e.g. to indicate presence of 3rd field

memory; should be connected to ground or to V

DDI

via pull-up resistor; note 3

JUMP1 20 input configuration pin 1; will be stored in register 0B5 e.g. to indicate presence of 16-bit

1st field memory for full 4:2:2; should be connected to ground or to V

DDI

via

pull-up resistor; note 3

V

DDE

21 supply supply voltage of output pads

V

DDI

22 supply core supply voltage

V

SSI

23 ground core ground
RAMTST1 24 input test pin 1 for internal RAM testing; connect to ground for normal operation
SNRST 25 input SNERT bus reset
SNDA 26 I/O SNERT bus data
SNCL 27 input SNERT bus clock
V

SSE

28 ground ground of output pads
RAMTST2 29 input test pin 2 for internal RAM testing; connect to ground for normal operation
TEST 30 input test mode input; if not used it has to be connected to ground
TRST 31 input boundary scan test: reset input signal; if not used it has to be connected to ground via

pull-down resistor; note 3

TMS 32 input boundary scan test: test mode select; if not used it has to be connected to V

DDI

via

pull-up resistor; note 3

TDI 33 input boundary scan test: data input signal; if not used it has to be connected to V

DDI

via

pull-up resistor; note 3

TDO 34 output boundary scan test: data output signal

2000 Feb 04 7

Philips Semiconductors Product specification

Field and line rate converter with noise
reduction

SAA4992H

TCK 35 input boundary scan test: clock input signal; if not used it has to be connected to V

DDI

via

pull-up resistor; note 3

V

SSE

36 ground ground of output pads
UVA0 37 input bus A chrominance input from field memory 1 bit 0 (LSB)
UVA1 38 input bus A chrominance input from field memory 1 bit 1
UVA2 39 input bus A chrominance input from field memory 1 bit 2
UVA3 40 input bus A chrominance input from field memory 1 bit 3
UVA4 41 input bus A chrominance input from field memory 1 bit 4
UVA5 42 input bus A chrominance input from field memory 1 bit 5
UVA6 43 input bus A chrominance input from field memory 1 bit 6
UVA7 44 input bus A chrominance input from field memory 1 bit 7 (MSB)
YA0 45 input bus A luminance input from field memory 1 bit 0 (LSB)
YA1 46 input bus A luminance input from field memory 1 bit 1
YA2 47 input bus A luminance input from field memory 1 bit 2
YA3 48 input bus A luminance input from field memory 1 bit 3
YA4 49 input bus A luminance input from field memory 1 bit 4
YA5 50 input bus A luminance input from field memory 1 bit 5
YA6 51 input bus A luminance input from field memory 1 bit 6
YA7 52 input bus A luminance input from field memory 1 bit 7 (MSB)
REA 53 output read enable output for bus A
V

SSE

54 ground ground of output pads
V

SSI

55 ground core ground
V

DDI

56 supply core supply voltage
V

DDI

57 supply core supply voltage
V

SSI

58 ground core ground
V

SSE

59 ground ground of output pads
REF 60 input read enable input for bus F and G
YF7 61 output bus F luminance output bit 7 (MSB)
YF6 62 output bus F luminance output bit 6
YF5 63 output bus F luminance output bit 5
YF4 64 output bus F luminance output bit 4
YF3 65 output bus F luminance output bit 3
YF2 66 output bus F luminance output bit 2
YF1 67 output bus F luminance output bit 1
YF0 68 output bus F luminance output bit 0 (LSB)
V

DDE

69 supply supply voltage of output pads
UVF7 70 output bus F chrominance output bit 7 (MSB)
UVF6 71 output bus F chrominance output bit 6
UVF5 72 output bus F chrominance output bit 5
UVF4 73 output bus F chrominance output bit 4
UVF3 74 output bus F chrominance output bit 3

SYMBOL PIN TYPE DESCRIPTION

(1)(2)

2000 Feb 04 8

Philips Semiconductors Product specification

Field and line rate converter with noise
reduction

SAA4992H

UVF2 75 output bus F chrominance output bit 2
UVF1 76 output bus F chrominance output bit 1
UVF0 77 output bus F chrominance output bit 0 (LSB)
V

SSE

78 ground ground of output pads
CLK32 79 input system clock input
V

SSI

80 ground core ground
V

SSE

81 ground ground of output pads
YG7 82 output bus G luminance output bit 7 (MSB)
YG6 83 output bus G luminance output bit 6
YG5 84 output bus G luminance output bit 5
YG4 85 output bus G luminance output bit 4
YG3 86 output bus G luminance output bit 3
YG2 87 output bus G luminance output bit 2
YG1 88 output bus G luminance output bit 1
YG0 89 output bus G luminance output bit 0 (LSB)
V

DDE

90 supply supply voltage of output pads
UVG7 91 output bus G chrominance output bit 7 (MSB)
UVG6 92 output bus G chrominance output bit 6
UVG5 93 output bus G chrominance output bit 5
UVG4 94 output bus G chrominance output bit 4
UVG3 95 output bus G chrominance output bit 3
UVG2 96 output bus G chrominance output bit 2
UVG1 97 output bus G chrominance output bit 1
UVG0 98 output bus G chrominance output bit 0 (LSB)
V

SSE

99 ground ground of output pads
V

SSI

100 ground core ground

V

DDI

101 supply core supply voltage

V

DDE

102 supply supply voltage of output pads

V

DDI

103 supply core supply voltage

V

SSI

104 ground core ground

V

SSE

105 ground ground of output pads
WED 106 output write enable output for bus D
UVD3 107 output bus D chrominance output to field memory 3 bit 3 (MSB)
UVD2 108 output bus D chrominance output to field memory 3 bit 2
UVD1 109 output bus D chrominance output to field memory 3 bit 1
UVD0 110 output bus D chrominance output to field memory 3 bit 0 (LSB)
YD7 111 output bus D luminance output to field memory 3 bit 7 (MSB)
YD6 112 output bus D luminance output to field memory 3 bit 6
V

DDE

113 supply supply voltage of output pads
YD5 114 output bus D luminance output to field memory 3 bit 5
YD4 115 output bus D luminance output to field memory 3 bit 4

SYMBOL PIN TYPE DESCRIPTION

(1)(2)

2000 Feb 04 9

Philips Semiconductors Product specification

Field and line rate converter with noise
reduction

SAA4992H

YD3 116 output bus D luminance output to field memory 3 bit 3
YD2 117 output bus D luminance output to field memory 3 bit 2
YD1 118 output bus D luminance output to field memory 3 bit 1
YD0 119 output bus D luminance output to field memory 3 bit 0 (LSB)
V

SSE

120 ground ground of output pads
V

SSE

121 ground ground of output pads
YE0 122 input bus E luminance input from field memory 3 bit 0 (LSB)
YE1 123 input bus E luminance input from field memory 3 bit 1
YE2 124 input bus E luminance input from field memory 3 bit 2
YE3 125 input bus E luminance input from field memory 3 bit 3
YE4 126 input bus E luminance input from field memory 3 bit 4
YE5 127 input bus E luminance input from field memory 3 bit 5
YE6 128 input bus E luminance input from field memory 3 bit 6
YE7 129 input bus E luminance input from field memory 3 bit 7 (MSB)
UVE0 130 input bus E chrominance input from field memory 3 bit 0 (LSB)
UVE1 131 input bus E chrominance input from field memory 3 bit 1
UVE2 132 input bus E chrominance input from field memory 3 bit 2
UVE3 133 input bus E chrominance input from field memory 3 bit 3 (MSB)
REE 134 output read enable output for bus E
V

SSE

135 ground ground of output pads
n.c. 136 − not connected
V

SSI

137 ground core ground
V

DDI

138 supply core supply voltage
n.c. 139 − not connected
n.c. 140 − not connected
V

DDE

141 supply supply voltage of output pads
V

DDI

142 supply core supply voltage
V

SSI

143 ground core ground
n.c. 144 − not connected
V

SSE

145 ground ground of output pads
WEB 146 output write enable output for bus B
UVB3 147 output bus B chrominance output to field memory 2 bit 3 (MSB)
UVB2 148 output bus B chrominance output to field memory 2 bit 2
UVB1 149 output bus B chrominance output to field memory 2 bit 1
UVB0 150 output bus B chrominance output to field memory 2 bit 0 (LSB)
YB7 151 output bus B luminance output to field memory 2 bit 7 (MSB)
YB6 152 output bus B luminance output to field memory 2 bit 6
V

DDE

153 supply supply voltage of output pads
YB5 154 output bus B luminance output to field memory 2 bit 5
YB4 155 output bus B luminance output to field memory 2 bit 4
YB3 156 output bus B luminance output to field memory 2 bit 3

SYMBOL PIN TYPE DESCRIPTION

(1)(2)

2000 Feb 04 10

Philips Semiconductors Product specification

Field and line rate converter with noise
reduction

SAA4992H

Notes

1. Not used input pins (e.g. bus E) should be connected to ground.

2. Because of the noisy characteristic of the output pad supply it is recommended not to connect the core supply and
the output pad supply directly at the device. The output pad supply should be buffered as close as possible to the
device.

3. The external pull-up resistor should be 47 kΩ.

YB2 157 output bus B luminance output to field memory 2 bit 2
YB1 158 output bus B luminance output to field memory 2 bit 1
YB0 159 output bus B luminance output to field memory 2 bit 0 (LSB)
V

SSE

160 ground ground of output pads

SYMBOL PIN TYPE DESCRIPTION

(1)(2)

2000 Feb 04 11

Philips Semiconductors Product specification

Field and line rate converter with noise
reduction

SAA4992H

handbook, full pagewidth

MHB647

SAA4992H

1
2
3
4
5
6
7
8

9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40

120
119
118
117
116
115
114
113
112
111
110
109
108
107
106
105
104
103
102
101
100

99
98
97
96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81

V

SSE

YD0
YD1
YD2
YD3
YD4
YD5

V

DDE

YD6
YD7
UVD0
UVD1
UVD2
UVD3
WED

V

SSE

V

SSI

V

DDI

V

DDE

V

DDI

V

SSI

V

SSE

UVG0
UVG1
UVG2
UVG3
UVG4
UVG5
UVG6
UVG7

V

DDE

YG0
YG1
YG2
YG3
YG4
YG5
YG6
YG7

V

SSE

V

SSE
YC0

YC1
YC2
YC3
YC4
YC5
YC6

YC7
UVC0
UVC1
UVC2
UVC3

REC
V

SSE
V

DDE

V

SSI

V

DDI

JUMP0
JUMP1

V

DDE

V

DDI

V

SSI

RAMTST1

SNRST

SNDA
SNCL

V

SSE

RAMTST2

TEST

TRST

TMS

TDI
TDO
TCK

V

SSE

UVA0
UVA1
UVA2
UVA3

V

SSE

YB0

YB1

YB2

YB3

YB4

YB5

V

DDE

YB6

YB7

UVB0

UVB1

UVB2

UVB3

WEB

V

SSE

n.c.

V

SSIVDDI

V

DDE

n.c.

n.c.

V

DDIVSSI

n.c.

V

SSE

REE

UVE3

UVE2

UVE1

UVE0

YE7

YE6

YE5

YE4

YE3

YE2

YE1

YE0

V

SSE

UVA4

UVA5

UVA6

UVA7

YA0

YA1

YA2

YA3

YA4

YA5

YA6

YA7

REA

V

SSE

V

SSI

V

DDIVDDI

V

SSI

V

SSE

REF

YF7

YF6

YF5

YF4

YF3

YF2

YF1

YF0

V

DDE

UFV7

UFV6

UFV5

UFV4

UFV3

UFV2

UFV1

UFV0

V

SSE

CLK32

V

SSI

160

159

158

157

156

155

154

153

152

151

150

149

148

147

146

145

144

143

142

141

140

139

138

137

136

135

134

133

132

131

130

129

128

127

126

125

124

123

122

121

414243444546474849505152535455565758596061626364656667686970717273747576777879

80

Fig.3 Pin configuration.

2000 Feb 04 12

Philips Semiconductors Product specification

Field and line rate converter with noise
reduction

SAA4992H

7 FUNCTIONAL DESCRIPTION

The FAL (fal_top) module builds the functional top level of
theSAA4992H.It connects the luminance data path (KER,
kernel), the chrominance data path (COL, colour) and the
luminance (de)compression (YDP, Y-DPCM) with
SAA4992H inputs and outputs as well as controlling logic
(LSE, line sequencer; SNE, SNERT interface). Outside of
fal_top there are only the pad cells, boundary scan test
cells, the boundary scan test controller, the clock tree, the
test enable tree and the input port registers.

Figure 4 shows a simplified block diagram of fal_top. It
displays the flow of pixel data (solid lines) and controls
(broken lines) between the modules inside.

Basic functionality of the modules in fal_top is as follows:

• KER (kernel): Y (luminance) data path

• COL (colour): UV (chrominance) data path

• YDP (Y-DPCM): compression (and decompression) of

luminance output (and input) data by Differential Pulse
Code Modulation (DPCM)

• LSE (line sequencer): generate line frequent control
signals

• SNE: Synchronous No parity Eight bit Reception and
Transmission (SNERT) interface to a microcontroller.

The SNERT interface operates in a slave receive and
transmit mode for communication with a microprocessor,
which resides on peripheral circuits (e.g. SAA4978H)
together with a SNERT master. The SNERT interface
transforms serial data from the microprocessor (via the
SNERT bus) into parallel data to be written into the
SAA4992Hs write registers and parallel data from
SAA4992Hsreadregisters into serial data to be sent to the
microprocessor. The SNERT bus consists of 3 signals:

1. SNCL: used as serial clock signal, generated by the

master

2. SNDA: used as bidirectional data line

3. SNRST: used as a reset signal, generated by the

microprocessor to indicate the start of a transmission.

The processing of a video field begins on the rising edge
of the RE_F input signal. As indicated in Fig.4, the
SAA4992H expects its inputs and generates its outputs at
the following clock cycles after RE_F (see Table 1).

Table 1 Clock cycle references

There is an algorithmic delay of 3 lines between input and
output data. Therefore, the main data output on the
F and G bus begins while the fourth input line is read.
Writing to the B and D bus starts one input line later.
The read and write enable signals RE_A, WE_B, RE_C,
WE_D and RE_E can be shifted by control registers
REaShift, WEbdShift and REceShift, which are
implemented in the line sequencer.

The fal_top module itself reads the following control
register bits(addresses):

• NrofFMs (017)

• MatrixOn (026)

• MemComp and MemDecom (026).

NrofFMs and MatrixOn are used to enable the D and G
output bus, respectively. MemComp and MemDecom are
connected to YDP to control luminance data compression
and decompression. These control register signals are not
displayed in Fig.4. Further information on the control
registers is given in Chapter 8.

SIGNAL LATENCY

RE_F 0
RE_C and

RE_E

63 cycles + REceShift

YC, YE, UVC
and UVE

63 cycles

RE_A 94 cycles + REaShift
YA and UVA 94 cycles
YF, YG, UVF

and UVG

148 cycles + 3 input lines

WE_B and
WE_D

160 cycles + 4 input lines + WEbdShift

YB, YD, UVB
and UVD

160 cycles + 4 input lines

2000 Feb 04 13

Philips Semiconductors Product specification

Field and line rate converter with noise
reduction

SAA4992H

handbook, full pagewidth

MHB648

COL

external field memories

160
cycles

UVB,
UVD

KER

63
cycles

RE_C,
RE_W

160
cycles

fal_top

WE_B,
WE_D

YDP

160
cycles

YB,
YD

63
cycles

UVC,
UVE

UVF, UVG
148 cycles

RE_F
0 cycles

RE_A

94 cycles

UVA

94 cycles

SNDA

YA

94 cycles

YF, YG
148 cycles

63
cycles

YC,
YE

LSESNE

Fig.4 Block diagram of fal_top.

The solid lines represent pixel data; the broken lines represent controls.

2000 Feb 04 14

Philips Semiconductors Product specification

Field and line rate converter with noise

reduction

SAA4992H

This text is here in white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here in

_white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here inThis text is here in

white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader. white to force landscape pages to be ...

8 CONTROL REGISTER DESCRIPTION

NAME

SNERT

ADDRESS

HEX

READ/

WRITE

(1)

76543210 DESCRIPTION

(2)

DNR/peaking/colour
Kstep10 010 write; S

Kstep0 XXXXset LUT value: k =1⁄16 if difference below (0to15)
Kstep1 X X X X set LUT value: k =

1

⁄8 if difference below (0to15)

Kstep32 011 write; S

Kstep2 XXXXset LUT value: k =2⁄8 if difference below (0 to 30 in multiples of 2)
Kstep3 X X X X set LUT value: k =

3

⁄8 if difference below (0 to 30 in multiples of 2)

Kstep54 012 write; S

Kstep4 XXXXset LUT value: k =4⁄8 if difference below (0 to 60 in multiples of 4)
Kstep5 X X X X set LUT value: k =

5

⁄8 if difference below (0 to 60 in multiples of 4)

Kstep76 013 write; S

Kstep6 XXXXset LUT value: k =6⁄8 if difference below (0, 8, 16, 24, 32, 40, 48, 56,

64, 72, 80, 88, 96, 104, 112 or 120)

Kstep7 X X X X set LUT value: k =

7

⁄8 if difference below (0, 8, 16, 24, 32, 40, 48, 56,

64, 72, 80, 88, 96, 104, 112 or 120)

Gain_fix_y 014 write; S

FixvalY XXXXset fixed Y value; used when FixY = 1 or in left part of split screen

(0,1⁄16to14⁄16or16⁄16)

GainY X X X set gain in difference signal for adaptive DNRY (

1

⁄8,1⁄4,1⁄2, 1, 2 or 4)

FixY X select fixed Y (adaptive or fixed) (full screen)

Gain_fix_uv 015 write; S

FixvalUV XXXXset fixed UV value; used when FixUV = 1 or in left part of split screen

(0,

1

⁄16to14⁄16or16⁄16)

GainUV X X X set gain in difference signal for adaptive DNR UV (

1

⁄8,1⁄4,1⁄2, 1, 2 or 4)

FixUV X select fixed UV (adaptive or fixed) (full screen)

Peak_Vcomp 016 write; S

VecComp X X X set degree of horizontal vector compensation in Y DNR:

(0,

1

⁄8,2⁄8,3⁄8,4⁄8,5⁄8,6⁄8or7⁄8) of the vector

PeakCoef X X X X set vertical peaking level: (0, +2, +3.5, +5, +6, x, x, x, x, x, x, x, x,

−12, −6or−2.5)dB

2000 Feb 04 15

Philips Semiconductors Product specification

Field and line rate converter with noise

reduction

SAA4992H

This text is here in white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here in

_white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here inThis text is here in

white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader. white to force landscape pages to be ...

DNR_Colour_mode 017 write; S

ColourIn X X select colour input format: (4:1:1, 4:2:2, 4:2:2DPCM or

4:2:2)
ColourOut X select colour output format: (4:1:1or4:2:2)
NrofFMs X set number of field memories connected: (1 or 2/3)
ColOvl X select vector overlay on colour output: (vector overlay or colour

from video path)
SlaveUVtoY X slave UV noise reduction to K factor of Y: (separate or slaved)
DnrSplit X select split screen mode for DNR: (normal or split screen)
DnrHpon X switch DNR high-pass on (DNR only active on low frequent spectrum:

(all through DNR or high bypassed)

Vertical zoom
Zoom1 018 write; F

ZoomSt98 X X zoom line step bits 9 and 8; line step = vertical distance between

successive output lines; usable range = 0 to 2 frame lines;

resolution

1

⁄

256

frame line

ZoomPo98 X X zoom start position bits 9 and 8; start position = verticalposition of the

top display line; usable range = 1 to 3 frame lines; resolution

1

⁄

256

frame line

Zoom2 019 write; F

ZoomSt70 X XXXXXXXzoom line step bits 7 to 0 (see above)

Zoom3 01A write; F

ZoomPo70 X XXXXXXXzoom start position bits 7 to 0 (see above)

Zoom4 01B write; F

ZoomEnVal XXXXzoom run in value= number of lines without zoom active

(0to15lines)
ZoomDiVal X X X X zoom run out value = number of lines without zoom active

(−8to+7lines)

NAME

SNERT

ADDRESS

HEX

READ/

WRITE

(1)

76543210 DESCRIPTION

(2)

2000 Feb 04 16

Philips Semiconductors Product specification

Field and line rate converter with noise

reduction

SAA4992H

This text is here in white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here in

_white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here inThis text is here in

white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader. white to force landscape pages to be ...

De-interlacer
Proscan1 01C write; S

KlfLim XXXXlimitation of recursion factor in calculation of original line positions:

(1to16); 1 limits to almost full recursion, 16 limits to no recursion
KlfOfs X X X X The transfer curve of the de-interlacing filter coefficient is determined

by the difference (Diff) between a line in the input field and the

counterpart in the previous field shifted over the estimated motion

vector.KlfOfs determines the bias of the transfer curvefor the original

input line, such that coefficient = KlfOfs + F(Diff), where the function F

is calculated in the SAA4992H. The bias can take a value in the range

(0to15), representing decreasing filter strength.

Proscan2 01D write; S

PlfLim XXXXlimitation of recursion factor in calculation of interpolated line

positions: (1to16); 1 limits to almost full recursion, 16 limits to no

recursion
PlfOfs X X X X see KlfOfs; this offset applies to interpolated lines

Proscan3 01E write; S

PeakLim XXXXMaximumthat the peaked pixel is allowed to deviate from originalpixel

value: deviation (0 to 30 in steps of 2). Above this deviation, the

peaked pixel is clipped to (original pixel + or − PeakLim).
PenInd X X X X index to PenMed table (−256, −128, −64, −32, −16, −8, −4, 0, 4, 8, 16,

24, 32, 64, 128 or 255); penalty for applying (vertical/temporal)

median, in favour of applying vertical average within new field

NAME

SNERT

ADDRESS

HEX

READ/

WRITE

(1)

76543210 DESCRIPTION

(2)

2000 Feb 04 17

Philips Semiconductors Product specification

Field and line rate converter with noise

reduction

SAA4992H

This text is here in white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here in

_white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here inThis text is here in

white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader. white to force landscape pages to be ...

Proscan4 01F write; F

PlfThr X X X Multiplier threshold at which to switch the lower limit of the filter

coefficient for interpolated lines. Above this threshold, the differences

corresponding to the two neighbouring lines are used as clipping

parameters, below this threshold, the interpolated line difference is

used as clipping level. This parameter can be used to optimize the

de-interlacing quality in slowly moving edges; it is not likely to have

effect if PlfLim is high.
ProDiv X X Scaling factor to control the strength of the filtering for the interpolated

lines. A value 0 means no scaling (normal filtering), while 3 means

scaling by factor 8 (very strong filtering). This parameter can be used

to adjust the de-interlacing to varying levelof noise in the input picture;

use higher scaling for higher noise.
UseVec X Enables use of estimated vectors to shift pixels from previous frame to

the current time (null vector or estimated vectors). It is best

switched to ‘null vector’, if vectors are unreliable.
KplOff X disable all recursion in calculating pixels for frame memory (recursive

or non recursive); to be trueSAA4991WP and digital scan emulation

modes

General
NrBlks 020 write; S

NrBlks XXXXXXnumber of blocks in active video (6to53, corresponds to

96 to 848 pixels), to be set as

1

⁄16 (number of active pixels per

line + 15); take remarks on TotalPxDiv8 into consideration
TotalLnsAct98 X X total number of output lines (bits 9 and 8)

TotalLnsAct70 021 write; S X XXXXXXXtotal number of output lines (bits 7 to 0)
TotalPxDiv8 022 write; S X XXXXXXXTotal number of pixels per line divided-by-8 (80 to 128, corresponds to

640 to 1024 pixels). The horizontal blanking interval is calculated as

TotalPxDiv8 − 2 × NrBlks and has to be in the range from 12 to 124

(corresponds to 96 to 992 pixels). Conclusion: TotalPxDiv8 has to be

set to 12 + 2 × NrBlks < TotalPxDiv8< 124 + 2 × NrBlks and NrBlks

has to be set to

REaShift 023 write; S X X X shift of REa signal in number of pixels (0, +1, +2, +3, −4, −3, −2or−1)

NAME

SNERT

ADDRESS

HEX

READ/

WRITE

(1)

76543210 DESCRIPTION

(2)

TotalPxDiv8 124–

2

------------------------------------------------

NrBlks

TotalPxDiv8 12–

2

-------------------------------------------- -

<<

2000 Feb 04 18

Philips Semiconductors Product specification

Field and line rate converter with noise

reduction

SAA4992H

This text is here in white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here in

_white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here inThis text is here in

white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader. white to force landscape pages to be ...

WEbdREceShift 024 write; S

WEbdShift X X X shift of WEb and WEd signal in number of pixels

(0, +1, +2, +3, −4, −3, −2or−1)
REceShift X X X shift of REc and REe signal in number of pixels

(0, +1, +2, +3, −4, −3, −2or−1)

POR 025 write; S X power-on reset command, to be set high temporarily during start-up

(normal or reset); note 3

Mode control
Control1 026 write; F

EstMode X Set estimator mode; 0 = line alternating use of left and right estimator:

use in progressive scan except with vertical compress. 1 = field

alternating use of left and right estimator: use in field doubling and

progressive scan with vertical compress.
FilmMode X set film mode; 0 = video camera mode; 1 = film mode
UpcMode X X select upconversion quality; 00 = full, 01 = economy (DPCM),

10 = SAA4991WP, 11 = SAA4990H
MatrixOn X set matrix output mode; 1 = double output, disabling vertical peaking;

0 = normal single output mode
EmbraceOn X Master enable for embrace mode (off or on); SwapMpr in control2

should be at ‘swap’ position to really cross-switch FM1 and FM3 field

outputs. Should be set to logic 0 except in film mode and FM3 is

present, or in SAA4991WP film mode and MemComp bit is active.
MemComp X set memory compression (luminance DPCM) (off or on)
MemDecom X set memory decompression (luminance DPCM) (off or on)

NAME

SNERT

ADDRESS

HEX

READ/

WRITE

(1)

76543210 DESCRIPTION

(2)

2000 Feb 04 19

Philips Semiconductors Product specification

Field and line rate converter with noise

reduction

SAA4992H

This text is here in white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here in

_white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here inThis text is here in

white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader. white to force landscape pages to be ...

Control2 027 write; F

QQcurr X Quincunx phase of current field (in TPM) (phase0 or phase1); this

needs to toggle each time a new field comes from FM1. In phase0 the

estimator operates on a checker-board pattern that starts with the left

upper block; in phase1 the other blocks are estimated.
QQprev X quincunx phase of previous field (in TPM) (phase0 or phase1); this is

the value of QQcur during the last estimate written into the temporal

prediction memory
FldStat X Field status (same input field or new input field); reflects whether

the output of FM1 is a new or a repeated field. This bit will toggle field

by field in field doubling mode and is continuously HIGH in progressive

output mode.
FieldWeYUV X enable writing FM2 and FM3 for both luminance and chrominance

(recirculation of data for luminance alone can be controlled with

OrigFmEnY and IntpFmEnY in Control3) (off or on)
OddFM1 X odd input field (even or odd), this is to be set equal to the detected

field interlace for the field that comes out of FM1
SwapMpr X Swap multi port RAMs (normal or swap); this bit needs to be set to

get real frame data at the temporal position from FM1. If swapped, the

current field (FM1) will be stored in the right line memory tree, while

the original lines from the stored frame (FM2/3) are stored in the left

memory tree. Should be set only in film mode if FM3 is present;

EmbraceOn must be set as well.
VecOffs X X Set vertical vector offset (0, +1, − or −1) frame lines; vertical offset of

the right line memory tree with respect to the left line memory tree.

A higher offset value means: on the right memory tree access to less

delayed video lines is taken; in interlaced video operation, the vertical

offset will be −1 with an odd field on the left side and +1 with an even

field on the left. With non-interlaced input, vertical offset should be

constantly 0. In film mode, vertical offset is dynamically switched

between +1, 0 and −1.

NAME

SNERT

ADDRESS

HEX

READ/

WRITE

(1)

76543210 DESCRIPTION

(2)

2000 Feb 04 20

Philips Semiconductors Product specification

Field and line rate converter with noise

reduction

SAA4992H

This text is here in white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here in

_white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here inThis text is here in

white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader. white to force landscape pages to be ...

Control3 028 write; F

OddLeft X interlace (even or odd) phase of the field which is written to the left

line memory tree (left MPRAM)
OrigFmEnY X enables writing luminance from de-interlacer in original field memory

(FM2), otherwise recirculation of luminance that is just read from FM2

(recirculate or update)
IntpFmEnY X enables writing luminance from de-interlacer in interpolated field

memory (FM3), otherwise recirculation of luminance that is just read

from FM3 (recirculate or update)
FillTPM X Enables writing in temporal prediction memory (keep or update);

FillTPM should be set to ‘keep’ in SAA4991WP/film mode, in those

output fields where FM1 and FM2 contain the same motion phase.

FillTPM should be set to ‘update’ in all other situations.
VertOffsDNR X X Set vertical vector offset of DNR (0, +1, − or −1) frame lines; vertical

offset of the right line memory tree with respect to the left line memory

tree, before the swap action. A higher offset value means: on the right

memory tree access to less delayed video lines is taken; in interlaced

video operation, the vertical offset will be −1 with an odd field on the

left side and +1 with an even field on the left. With non-interlaced

input, verticaloffset should be constantly logic 0; in film mode, vertical

offset is dynamically switched between +1, 0 and −1. It should be

noted that the signal OddFM1 is used to determine this offset.

Upconversion
Upconv1 029 write; F

UpcShFac XXXXXXtemporal interpolation factor used in luminance upconverter; value

ranges from 0 (for current field position) to 32 (for previous field

position)

Upconv2 02A write

YVecClip S XXXvalueused for coringthe vertical vector component before application

in the upconverter; range: 0 to 3.5 in steps of 0.5 line; should remain

at logic 0 in normal operation
RollBack F X XXXX roll back factor ranging from 0 (use 0% of estimated vectors) to 16

(use 100% of estimated vectors)

NAME

SNERT

ADDRESS

HEX

READ/

WRITE

(1)

76543210 DESCRIPTION

(2)

2000 Feb 04 21

Philips Semiconductors Product specification

Field and line rate converter with noise

reduction

SAA4992H

This text is here in white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here in

_white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here inThis text is here in

white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader. white to force landscape pages to be ...

Upconv3 02B write; S

MelzLfbm X SAA4991WP type local fallback method instead of more robust local

fallback (complex or SAA4991WP type fallback)
Melzmemc X SAA4991WP film mode memory control (normal or SAA4991WP

type); should be set in SAA4991WP film mode to ensure that only

original lines are selected as output when UpcShFac is 0 or 32
MelDeint X use (as in SAA4991WP) horizontal motion compensated median for

upconverter de-interlacing (normal or SAA4991WP type

de-interlacing)
MixCtrl X X X Upconverter sensitivity:

0to3: smoothness dependent weighting between vector shifted

pixels and static pixels. 0 = sensitive to unsmoothness for taking more

of the static pixels ‘conservative’, up to 3 = hardly sensitive to

unsmoothness for taking more of static pixels ‘confident in vector

shifting’.

4to7: static weighting between vector shifted pixels and static pixels.

4 = take most of vector shifted pixels ‘confident in vector shifting’, up to

7 = take most of the static pixels ‘conservative’.

UpcColShiFac 0C4 write; F XXXXXXtemporal interpolation factor used in chrominance upconverter; value

ranges from 0 (for current field position) to 32 (for previous field

position)

Motion estimator
Motest1 02C write; S

PenOdd X X X additional penalty on vector candidates with odd vertical component

(0, 8, 16, 32, 64, 128, 256 or 511)
SpcThr X X X Active when EstMode = 0; replace the spatial prediction of one

estimator (left or right) by that of the other if the match error of the

former exceeds that of the latter by more than (0, 8, 16, 32, 64, 128,

256 or 511). A higher threshold means the two estimators are very

independent.
BmsThr X X Active when EstMode = 0; select as estimated vector the output of the

right estimator unless its match error exceeds that of the left estimator

by more than (0, 8, 16 or 32). This parameter should normally be set

to logic 0.

NAME

SNERT

ADDRESS

HEX

READ/

WRITE

(1)

76543210 DESCRIPTION

(2)

2000 Feb 04 22

Philips Semiconductors Product specification

Field and line rate converter with noise

reduction

SAA4992H

This text is here in white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here in

_white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here inThis text is here in

white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader. white to force landscape pages to be ...

Motest2 02D write; S

TavLow X If the difference between the current vector and the previous one in

the same spatial location is within a small window, then the two

vectors are averaged to improve temporal consistency. TavLow is the

lower threshold of this window (1or2).
TavUpp X X see above; TavUpp is the upper threshold (0, 4, 8 or 16)
MedEns X X scaling factor to reduce all sizes of update vectors in the ensemble

with medium sized vector templates (1,

1

⁄2,1⁄4or1⁄8)

LarEns X X scaling factor to reduce all sizes of update vectors in the ensemble

with large sized vector templates (1,

1

⁄2,1⁄4or1⁄8)

Motest3 02E write; F

MotShiFac XXXXXXMotion estimator shift factor, being the temporal position used in the

estimator at which the matching is done; value 32 for matching at

previous field position down to 0 for matching at current field position.

Keeping MotShiFac equal to UpShiFac in the next upconverted output

field estimates for minimum matching errors (minimum Halo’s).

MotShiFac at value 16 gives the largest natural vector range (twice as

large as with value 0 or 32). Going above the range with

MotShiFac ≠ 16 is dealt with in SAA4992H by shifting towards 16, but

for the horizontal and vertical component separately (consequence is

that vector candidates tend to rotate towards the diagonal directions).

NAME

SNERT

ADDRESS

HEX

READ/

WRITE

(1)

76543210 DESCRIPTION

(2)

2000 Feb 04 23

Philips Semiconductors Product specification

Field and line rate converter with noise

reduction

SAA4992H

This text is here in white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here in

_white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here inThis text is here in

white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader. white to force landscape pages to be ...

Motest4 02F write; S

PenRng X Penalty for vectors estimated on the first row and the first column (if

left estimator is used) or the right column (if right estimator is used),

whenever the spatial prediction candidate is selected (16 or 64).

For noisy pictures, this register could be set to logic 1 to improve

border processing in the estimator.
CndSet X choice of candidate set (left or right) for which data (Candidate1 to

Candidate8) is written in this field (becomes active in next field); see

note 3
ErrThr X X X threshold on block match error for considering a block to be bad

(16, 32, 64, 128, 256, 512, 1024 or 2032)
ErrHbl X X number of horizontally adjacent blocks that have to be all bad before

considering an occurrence of a burst error (1, 2, 4 or 8) (counting of

burst errors is read out with BlockErrCnt, address 0A8)
TstMod X to be kept to logic 1 for normal operation

Candidate1 090 write; S

Candidat1 X X X selection Candidate1 (SpatLeft, SpatRight, TemporalRight,

TemporalLeft, TemporalCentre, Null, Panzoom or Max)
Update1 X X update for Candidate1 (zero update, medium update, large update

or zero update)
Penalty1 X X X penalty for Candidate1 (0, 8, 16, 32, 64, 128, 256 or 511)

Candidate2 091 write; S

Candidat2 X X X selection Candidate2 (SpatLeft, SpatRight, TemporalRight,

TemporalLeft, TemporalCentre, Null, Panzoom or Max)
Update2 X X update for Candidate2 (zero update, medium update, large update

or zero update)
Penalty2 X X X penalty for Candidate2 (0, 8, 16, 32, 64, 128, 256 or 511)

Candidate3 092 write; S

Candidat3 X X X selection Candidate3 (SpatLeft, SpatRight, TemporalRight,

TemporalLeft, TemporalCentre, Null, Panzoom or Max)
Update3 X X update for Candidate3 (zero update, medium update, large update

or zero update)
Penalty3 X X X penalty for Candidate3 (0, 8, 16, 32, 64, 128, 256 or 511)

NAME

SNERT

ADDRESS

HEX

READ/

WRITE

(1)

76543210 DESCRIPTION

(2)

2000 Feb 04 24

Philips Semiconductors Product specification

Field and line rate converter with noise

reduction

SAA4992H

This text is here in white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here in

_white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here inThis text is here in

white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader. white to force landscape pages to be ...

Candidate4 093 write; S

Candidat4 X X X selection Candidate4 (SpatLeft, SpatRight, TemporalRight,

TemporalLeft, TemporalCentre, Null, Panzoom or Max)
Update4 X X update for Candidate4 (zero update, medium update, large update

or zero update)
Penalty4 X X X penalty for Candidate4 (0, 8, 16, 32, 64, 128, 256 or 511)

Candidate5 094 write; S

Candidat5 X X X selection Candidate5 (SpatLeft, SpatRight, TemporalRight,

TemporalLeft, TemporalCentre, Null, Panzoom or Max)
Update5 X X update for Candidate5 (zero update, medium update, large update

or zero update)
Penalty5 X X X penalty for Candidate5 (0, 8, 16, 32, 64, 128, 256 or 511)

Candidate6 095 write; S

Candidat6 X X X selection Candidate6 (SpatLeft, SpatRight, TemporalRight,

TemporalLeft, TemporalCentre, Null, Panzoom or Max)
Update6 X X update for Candidate6 (zero update, medium update, large update

or zero update)
Penalty6 X X X penalty for Candidate6 (0, 8, 16, 32, 64, 128, 256 or 511)

Candidate7 096 write; S

Candidat7 X X X selection Candidate7 (SpatLeft, SpatRight, TemporalRight,

TemporalLeft, TemporalCentre, Null, Panzoom or Max)
Update7 X X update for Candidate7 (zero update, medium update, large update

or zero update)
Penalty7 X X X penalty for Candidate7 (0, 8, 16, 32, 64, 128, 256 or 511)

Candidate8 097 write; S

Candidat8 X X X selection Candidate8 (SpatLeft, SpatRight, TemporalRight,

TemporalLeft, TemporalCentre, Null, Panzoom or Max)
Update8 X X update for Candidate8 (zero update, medium update, large update

or zero update)
Penalty8 X X X penalty for Candidate8 (0, 8, 16, 32, 64, 128, 256 or 511)

PZpositionLeftUppX 098 write; S XXXXXXXposition of LeftUpp measurement point for pan-zoom calculations

(resolution: 16 pixels)

NAME

SNERT

ADDRESS

HEX

READ/

WRITE

(1)

76543210 DESCRIPTION

(2)

2000 Feb 04 25

Philips Semiconductors Product specification

Field and line rate converter with noise

reduction

SAA4992H

This text is here in white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here in

_white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here inThis text is here in

white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader. white to force landscape pages to be ...

PZpositionLeftUppY 099 write; S XXXXXXXYposition of LeftUpp measurement point for pan-zoom calculations

(resolution: 4 lines)

PZpositionRightLowX 09A write; S XXXXXXXposition of RightLow measurement point for pan-zoom calculations

(resolution: 16 pixels)

PZpositionRightLowY 09B write; S XXXXXXXYposition of RightLow measurement point for pan-zoom calculations

(resolution: 4 lines)

PZvectorStartX 09C write; F X XXXXXXXXstart value of pan-zoom vectors
PZvectorDeltaX 09D write; F X XXXXXXXXdelta value of pan-zoom vectors
PZvectorStartY 09E write; F X XXXXXXXYstart value of pan-zoom vectors
PZvectorDeltaY 09F write; F X XXXXXXXYdelta value of pan-zoom vectors

Read data; note 3
GlobalMSEmsb 0A0 read; F X XXXXXXXGlobal Mean Square Error (MSE) = summation within a field period of

squared differences in comparing vector shifted video from frame

memory (FM2/3) with new field input (FM1) in those lines coinciding

with new field lines. The window for the measurement is kept at

40 pixels horizontal and 20 field lines vertical from the border of the

video. Measurements is only done in fields where the de-interlacer is

active, otherwise reading is zero. In field doubling mode, MSE is zero

at the end of every new input field.

GlobalMSElsb 0A1 read; F X XXXXXXX

GlobalMTImsb 0A2 read; F X XXXXXXXGlobal Motion Trajectory Inconsistency (MTI) = summation within a

field period of squared differences comparing shifted video from frame

memory (FM2/3 output) with filtered data that is rewritten to the frame

memory (FM2/3 input) in those lines coinciding with new field lines.

The window for the measurement is kept at 40 pixels horizontal and

20 field lines vertical from the border of the video. Measurement is

done only in fields where de-interlacer is active, otherwise reading is

zero; in field doubling mode, MTI is zero at the end of every new input

field.

GlobalMTIlsb 0A3 read; F X XXXXXXX

GlobalACTmsb 0A4 read; F X XXXXXXXglobal activity (ACT) = summation over a field period of the horizontal

plus the vertical components of the vectors of all blocks

GlobalACTlsb 0A5 read; F X XXXXXXX
VectTempCons 0A6 read; F X XXXXXXXVector temporal consistency = summation over a field period of

absolute differences of horizontal plus vertical components of vectors

newly estimated for each block compared with those vectors

estimated in the previous run at the same spatial block position.

It should be noted that a lower figure implies better consistency.

NAME

SNERT

ADDRESS

HEX

READ/

WRITE

(1)

76543210 DESCRIPTION

(2)

2000 Feb 04 26

Philips Semiconductors Product specification

Field and line rate converter with noise

reduction

SAA4992H

This text is here in white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here in

_white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here inThis text is here in

white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader. white to force landscape pages to be ...

VectSpatCons 0A7 read; F X XXXXXXXVector spatial consistency = summation overa field periodof absolute

differencesof horizontal and vertical components of vectorscompared

with those of the neighbour blocks (L, R, U and D); in the comparison,

all vector data is used from the previous estimator run. It should be

noted that a lower figure implies better consistency

BlockErrCnt 0A8 read; F X XXXXXXXburst error count (number of burst errors)
LeastErrSum 0A9 read; F X XXXXXXXleast error sum (summation over a field period of the smallest match

error that the estimator has found for each block: indicates reliability of

the estimation process)

YvecRangeErrCntmsb 0AA read; F X XXXXXXXYvector range error count (number of vectors that have a vertical

component that is out of range for upconversion at the chosen

temporal position) (15 to 8)

YvecRangeErrCntlsb 0AB read; F X XXXXXXXYvector range error count (7 to 0)
RefLineCountPrev 0AC read; F X XXXXXXXread out of (number of input (run-) lines − 40) used in previous field
RefLineCountNew 0AD write; F X XXXXXXXWrite of [number of input (run-) lines − 40] to be used in new field

(actual maximum number of input lines in normal operation: 292;

register value 252). Nominally this is to be set as an exact copy of the

value read from RefLineCountPrev before a new field starts. In case

the effective number of input (run-) lines has increased,

RefLineCountNew should, for one field, be set to 255. This will occur

e.g. with decreasing vertical zoom magnification or changing from

525 lines video standard to 625 lines standard. If this is not done, a

deadlock will occur with too few lines processed correctly by the

motion estimator.

PanZoomVec0-X 0B0 read; F X XXXXXXXpan-zoom vector0 (8-bit X value)
PanZoomVec0-Y 0B1 read

FalconIdent S 0 SAA4992H identification: fixed bit, reading this bit as zero means

SAA4992H is present
PanZoomVec0-Y F XXXXXXXpan-zoom vector 0 (7-bit Y value)

PanZoomVec1-X 0B2 read; F X XXXXXXXpan-zoom vector1 (8-bit X value)
PanZoomVec1-Y 0B3 read

StatusJump0 S X read out of configuration pin JUMP0
PanZoomVec1-Y F XXXXXXXpan-zoom vector 1 (7-bit Y value)

PanZoomVec2-X 0B4 read; F X XXXXXXXpan-zoom vector2 (8-bit X value)

NAME

SNERT

ADDRESS

HEX

READ/

WRITE

(1)

76543210 DESCRIPTION

(2)

2000 Feb 04 27

Philips Semiconductors Product specification

Field and line rate converter with noise

reduction

SAA4992H

This text is here in white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here in

_white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here inThis text is here in

white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader. white to force landscape pages to be ...

Notes

1. S means semi static, used at initialization or mode changes; F means field frequent, in general updated in each display field.

2. Selectable items are marked bold.

3. Almost all of the R(ead) and W(rite) registers of SAA4992H are double buffered. The Write registers are latched by a signal called New_field.
New_field gets set, when RE_f rises after RSTR (New_field is effectively at the start of active video). The Read registers are latched by a signal
called Reg_upd. Reg_upd gets set, when half the number of active pixels of the fourth line of vertical blanking have entered the SAA4992H
(Reg_upd will effectively be active 3 and a halve lines after the RE_a, RE_c and RE_e have ended). The only exceptional registers, which are not
double buffered, are:

a) Write register 025: power_on_reset
b) Write register 02F, bit 1: CndSet
c) Read register 0B0 to 0BF, 0AE and 0AF: pan_zoom_vectors, including FalconIdent (= 0), jump0 and jump1.

PanZoomVec2-Y 0B5 read

StatusJump1 S X read out of configuration pin JUMP1
PanZoomVec2-Y F XXXXXXXpan-zoom vector 2 (7-bit Y value)

PanZoomVec3-X 0B6 read; F X XXXXXXXpan-zoom vector2 (8-bit X value)
PanZoomVec3-Y 0B7 read; F XXXXXXXpan-zoom vector 3 (7-bit Y value)
PanZoomVec4-X 0B8 read; F X XXXXXXXpan-zoom vector4 (8-bit X value)
PanZoomVec4-Y 0B9 read; F XXXXXXXpan-zoom vector 4 (7-bit Y value)
PanZoomVec5-X 0BA read; F X XXXXXXXpan-zoom vector5 (8-bit X value)
PanZoomVec5-Y 0BB read; F XXXXXXXpan-zoom vector 5 (7-bit Y value)
PanZoomVec6-X 0BC read; F X XXXXXXXpan-zoom vector 6 (8-bit X value)
PanZoomVec6-Y 0BD read; F XXXXXXXpan-zoom vector 6 (7-bit Y value)
PanZoomVec7-X 0BE read; F X XXXXXXXpan-zoom vector7 (8-bit X value)
PanZoomVec7-Y 0BF read; F XXXXXXXpan-zoom vector 7 (7-bit Y value)
PanZoomVec8-X 0AE read; F X XXXXXXXpan-zoom vector8 (8-bit X value)
PanZoomVec8-Y 0AF read; F XXXXXXXpan-zoom vector 8 (7-bit Y value)
EggSliceRgtMSB 0C0 read; F X XXXXXXXresult of right pixels egg-slice detector (15 to 8)
EggSliceRgtLSB 0C1 read; F X XXXXXXXresult of right pixels egg-slice detector (7 to 0)
EggSliceMixMSB 0C2 read; F X XXXXXXXresult of mixed pixels egg-slice detector (15to 8)
EggSliceMixLSB 0C3 read; F X XXXXXXXresult of mixed pixels egg-slice detector (7 to 0)

NAME

SNERT

ADDRESS

HEX

READ/

WRITE

(1)

76543210 DESCRIPTION

(2)

2000 Feb 04 28

Philips Semiconductors Product specification

Field and line rate converter with noise
reduction

SAA4992H

9 LIMITING VALUES

In accordance with the Absolute Maximum Rating System (IEC 134).

10 THERMAL CHARACTERISTICS

11 CHARACTERISTICS

V

DD

= 3.0 to 3.6 V; T

amb

= 0 to 70 °C; unless otherwise specified.

SYMBOL PARAMETER MIN. MAX. UNIT

V

DD

supply voltage −0.5 +3.6 V

I

DD

supply current − 600 mA

I

o

output current − 2.0 mA

V

i

input voltage for all I/O pins −0.5 +3.6 V

T

stg

storage temperature −55 +150 °C

T

j

junction temperature 0 125 °C

SYMBOL PARAMETER CONDITIONS VALUE UNIT

R

th(j-a)

thermal resistance from junction to ambient in free air 27 K/W

R

th(j-c)

thermal resistance from junction to case 2.9 K/W

SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT

General

V

DD

supply voltage 3.0 3.3 3.6 V

I

DD

supply current − 400 550 mA

V

OH

HIGH-level output voltage 2.4 −−V

V

OL

LOW-level output voltage −−0.4 V

V

IH

HIGH-level input voltage 2.0 − 3.6 V

V

IL

LOW-level input voltage 0 − 0.8 V

I

OL

LOW-level output current −−2mA

C

o(L)

output load capacitance −−50 pF

C

i

input capacitance −−8pF

I

LI

input leakage current −−1µA
Outputs; note 1; see Fig.5
I

OZ

output current in 3-state mode −0.5 < Vo< 3.6 −−1µA
t

d(o)

output delay time −−21 ns
t

h(o)

output hold time 4 −−ns
SR slew rate 300 − 700 mV/ns

Inputs; note 2; see Fig.5
t

su(i)

input set-up time 8 −−ns
t

h(i)

input hold time 2 −−ns

2000 Feb 04 29

Philips Semiconductors Product specification

Field and line rate converter with noise
reduction

SAA4992H

Notes

1. Timing characteristics are measured with CL= 15 pF; IOL= 2 mA; RL=2kΩ.

2. All inputs except SNERT, CLK32 and BST.

Input CLK32; see Fig.5
t

r

rise time −−4ns
t

f

fall time −−4ns
δ duty factor 40 − 60 %
T

cy

cycle time 30 − 39 ns
SNERT interface; see Fig.7
t

SNRSTH

SNRST pulse HIGH time 500 −−ns
t

d(SNRST-SNCL

) delay SNRST pulse to SNCL LOW time 200 −−ns

T

cy(SNCL)

SNCL cycle time 0.5 − 1 µs
t

su(i)(SNCL)

input set-up time to SNCL 53 −−ns
t

h(i)(SNCL)

input hold time to SNCL 10 −−ns
t

h(o)

output hold time 30 −−ns
t

d(o)

output delay time −−330 ns
t

o(en)

output enable time 210 −−ns
BST interface; see Fig.6
T

cy(BST)

BST cycle time − 1 −µs
t

su(i)(BST)

input set-up time 3 −−ns
t

h(i)(BST)

input hold time 6 −−ns
t

h(o)(BST)

output hold time 4 −−ns
t

d(o)(BST)

output delay time −−30 ns

SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT

2000 Feb 04 30

Philips Semiconductors Product specification

Field and line rate converter with noise
reduction

SAA4992H

handbook, full pagewidth

MHB175

data

valid

data transition

period

OUTPUT

DATA

CLOCK

90%

10%

90%

10%

1.5 V

t

h(o)

t

d(o)

t

f

t

r

INPUT

DATA

t

h(i)

t

su(i)

Fig.5 Data input/output timing diagram.

handbook, full pagewidth

MHB649

TDO

TCK

t

h(o)(BST)

t

d(o)(BST)

T

cy(BST)

TDI, TMS

t

h(i)(BST)

t

su(i)(BST)

Fig.6 Boundary scan test interface timing diagram.

2000 Feb 04 31

Philips Semiconductors Product specification

Field and line rate converter with noise
reduction

SAA4992H

handbook, full pagewidth

MHB650

SNCL

SNDA

write sequence:

a0 a1 a2 a3 a4 a5 a6 a7 w0 w1 w2 w3 w4 w5 w6 w7

t

su(i)(SNCL)

t

h(i)(SNCL)

t

o(en)

t

d(o)

t

h(o)

t

d(o)

SNDA
driven by
master

read sequence:

SNDA
driven by
master

read sequence:

SNCL

SNDA

write sequence:

a0

50%

50% 50%

a7 w0 w1

a1 a2 a3 a4 a5 a6 a7

r0 r1 r2 r3 r4 r5 r6 r7

SNDA
driven by
SAA4992H

SNDA
driven by
SAA4992H

r0 r1

a6

a6

a7

Fig.7 SNERT interface timing diagram.

2000 Feb 04 32

Philips Semiconductors Product specification

Field and line rate converter with noise
reduction

SAA4992H

Table 2 YUV formats; note 1

Notes

1. Index X refers to different I/O buses:
a) X = A: input from 1st field memory
b) X = B: output to 2nd field memory
c) X = C: input from 2nd field memory
d) X = D: output to 3rd field memory
e) X = E: input from 3rd field memory
f) X = F: main output
g) X = G: 2nd output for matrix purposes.
The first index digit defines the sample number, the second defines the bit number.

2. X = don’t care or not available.

I/O PIN

(1)

4:1:1 FORMAT

(2)

4 : 2 : 2 FORMAT

4:2:2 DPCM

FORMAT

(2)

YX7 Y07 Y17 Y27 Y37 Y07 Y17 Y07 Y17
YX6 Y06 Y16 Y26 Y36 Y06 Y16 Y06 Y16
YX5 Y05 Y15 Y25 Y35 Y05 Y15 Y05 Y15
YX4 Y04 Y14 Y24 Y34 Y04 Y14 Y04 Y14
YX3 Y03 Y13 Y23 Y33 Y03 Y13 Y03 Y13
YX2 Y02 Y12 Y22 Y32 Y02 Y12 Y02 Y12
YX1 Y01 Y11 Y21 Y31 Y01 Y11 Y01 Y11

YX0 Y00 Y10 Y20 Y30 Y00 Y10 Y00 Y10
UVX7 U07 U05 U03 U01 U07 V07 UC03 VC03
UVX6 U06 U04 U02 U00 U06 V06 UC02 VC02
UVX5 V07 V05 V03 V01 U05 V05 UC01 VC01
UVX4 V06 V04 V02 V00 U04 V04 UC00 VC00
UVX3 X X X X U03 V03 X X
UVX2 X X X X U02 V02 X X
UVX1 X X X X U01 V01 X X
UVX0 X X X X U00 V00 X X

2000 Feb 04 33

Philips Semiconductors Product specification

Field and line rate converter with noise
reduction

SAA4992H

12 PACKAGE OUTLINE

UNIT A1A2A3bpcE

(1) (1) (1)

eH

E

LL

p

Zywv θ

REFERENCES

OUTLINE
VERSION

EUROPEAN

PROJECTION

ISSUE DATE

IEC JEDEC EIAJ

mm

0.50

0.25

3.60

3.20

0.25

0.38

0.22

0.23

0.13

28.1

27.9

0.65 0.31.6

1.5

1.1

7
0

o
o

0.13 0.1

DIMENSIONS (mm are the original dimensions)

Note

1. Plastic or metal protrusions of 0.25 mm maximum per side are not included.

1.03

0.73

SOT322-2 135E12 MS-022

99-11-03
00-01-19

D

(1)

28.1

27.9

H

D

31.45

30.95

31.45

30.95

E

Z

1.5

1.1

D

pin 1 index

b

p

e

θ

E

A

1

A

L

p

detail X

L

(A )

3

B

40

c

D

H

b

p

E

H

A

2

v M

B

D

Z

D

A

Z

E

e

v M

A

X

1

160

121

120

81

80

41

y

w M

w M

0 5 10 mm

scale

SOT322-2

160 leads (lead length 1.6 mm); body 28 x 28 x 3.4 mm; high stand-off height

QFP160: plastic quad flat package;

A

max.

4.07

2000 Feb 04 34

Philips Semiconductors Product specification

Field and line rate converter with noise
reduction

SAA4992H

13 SOLDERING

13.1 Introduction to soldering surface mount
packages

Thistextgivesaverybriefinsighttoa complex technology.
A more in-depth account of soldering ICs can be found in
our

“Data Handbook IC26; Integrated Circuit Packages”

(document order number 9398 652 90011).
There is no soldering method that is ideal for all surface

mount IC packages. Wave soldering is not always suitable
for surface mount ICs, or for printed-circuit boards with
high population densities. In these situations reflow
soldering is often used.

13.2 Reflow soldering

Reflow soldering requires solder paste (a suspension of
fine solder particles, flux and binding agent) to be applied
totheprinted-circuit board by screen printing, stencilling or
pressure-syringe dispensing before package placement.

Several methods exist for reflowing; for example,
infrared/convection heating in a conveyor type oven.
Throughput times (preheating, soldering and cooling) vary
between 100 and 200 seconds depending on heating
method.

Typical reflow peak temperatures range from
215 to 250 °C. The top-surface temperature of the
packages should preferable be kept below 230 °C.

13.3 Wave soldering

Conventional single wave soldering is not recommended
forsurfacemountdevices(SMDs)orprinted-circuitboards
with a high component density, as solder bridging and
non-wetting can present major problems.

To overcome these problems the double-wave soldering
method was specifically developed.

If wave soldering is used the following conditions must be
observed for optimal results:

• Use a double-wave soldering method comprising a
turbulent wave with high upward pressure followed by a
smooth laminar wave.

• For packages with leads on two sides and a pitch (e):
– larger than or equal to 1.27 mm, the footprint

longitudinal axis is preferred to be parallel to the
transport direction of the printed-circuit board;

– smaller than 1.27 mm, the footprint longitudinal axis

must be parallel to the transport direction of the
printed-circuit board.

The footprint must incorporate solder thieves at the
downstream end.

• Forpackageswithleadsonfoursides,thefootprintmust
be placed at a 45° angle to the transport direction of the
printed-circuit board. The footprint must incorporate
solder thieves downstream and at the side corners.

During placement and before soldering, the package must
be fixed with a droplet of adhesive. The adhesive can be
applied by screen printing, pin transfer or syringe
dispensing. The package can be soldered after the
adhesive is cured.

Typical dwell time is 4 seconds at 250 °C.
A mildly-activated flux will eliminate the need for removal
of corrosive residues in most applications.

13.4 Manual soldering

Fix the component by first soldering two
diagonally-opposite end leads. Use a low voltage (24 V or
less) soldering iron applied to the flat part of the lead.
Contact time must be limited to 10 seconds at up to
300 °C.

When using a dedicated tool, all other leads can be
soldered in one operation within 2 to 5 seconds between
270 and 320 °C.

2000 Feb 04 35

Philips Semiconductors Product specification

Field and line rate converter with noise
reduction

SAA4992H

13.5 Suitability of surface mount IC packages for wave and reflow soldering methods

Notes

1. All surface mount (SMD) packages are moisture sensitive. Depending upon the moisture content, the maximum
temperature (with respect to time) and body size of the package, there is a risk that internal or external package
cracks may occur due to vaporization of the moisture in them (the so called popcorn effect). For details, refer to the
Drypack information in the

“Data Handbook IC26; Integrated Circuit Packages; Section: Packing Methods”

.

2. These packages are not suitable for wave soldering as a solder joint between the printed-circuit board and heatsink
(at bottom version) can not be achieved, and as solder may stick to the heatsink (on top version).

3. If wave soldering is considered, then the package must be placed at a 45° angle to the solder wave direction.
The package footprint must incorporate solder thieves downstream and at the side corners.

4. Wave soldering is only suitable for LQFP, TQFP and QFP packages with a pitch (e) equal to or larger than 0.8 mm;
it is definitely not suitable for packages with a pitch (e) equal to or smaller than 0.65 mm.

5. Wave soldering is only suitable for SSOP and TSSOP packages with a pitch (e) equal to or larger than 0.65 mm; it is
definitely not suitable for packages with a pitch (e) equal to or smaller than 0.5 mm.

14 DEFINITIONS

15 LIFE SUPPORT APPLICATIONS

These products are not designed for use in life support appliances, devices, or systems where malfunction of these
products can reasonably be expected to result in personal injury. Philips customers using or selling these products for
use in such applications do so at their own risk and agree to fully indemnify Philips for any damages resulting from such
improper use or sale.

PACKAGE

SOLDERING METHOD

WAVE REFLOW

(1)

BGA, SQFP not suitable suitable
HLQFP, HSQFP, HSOP, HTQFP, HTSSOP, SMS not suitable

(2)

suitable

PLCC

(3)

, SO, SOJ suitable suitable

LQFP, QFP, TQFP not recommended

(3)(4)

suitable

SSOP, TSSOP, VSO not recommended

(5)

suitable

Data sheet status

Objective specification This data sheet contains target or goal specifications for product development.
Preliminary specification This data sheet contains preliminary data; supplementary data may be published later.
Product specification This data sheet contains final product specifications.

Limiting values

Limiting values given are in accordance with the Absolute Maximum Rating System (IEC 134). Stress above one or
more of the limiting values may cause permanent damage to the device. These are stress ratings only and operation
of the device at these or at any other conditions above those given in the Characteristics sections of the specification
is not implied. Exposure to limiting values for extended periods may affect device reliability.

Application information

Where application information is given, it is advisory and does not form part of the specification.

© Philips Electronics N.V. SCA
All rights are reserved. Reproduction in whole or in part is prohibited without the prior written consent of the copyright owner.

The information presented in this document does not form part of any quotation or contract, is believed to be accurate and reliable and may be changed
without notice. No liability will be accepted by the publisher for any consequence of its use. Publication thereof does not convey nor imply any license
under patent- or other industrial or intellectual property rights.

Internet: http://www.semiconductors.philips.com

2000

69

Philips Semiconductors – a w orldwide compan y

For all other countries apply to: Philips Semiconductors,

International Marketing & Sales Communications, Building BE-p, P.O. Box 218,
5600 MD EINDHOVEN, The Netherlands, Fax. [phone]

Argentina: see South America
Australia: 3 Figtree Drive, HOMEBUSH, NSW 2140,

Tel. [phone], Fax. [phone]
Austria: Computerstr. 6, A-1101 WIEN, P.O. Box 213,

Tel. [phone], Fax. [phone]
Belarus: Hotel Minsk Business Center, Bld. 3, r. 1211, Volodarski Str. 6,

220050 MINSK, Tel. [phone], Fax. [phone]

Belgium: see The Netherlands
Brazil: see South America
Bulgaria: Philips Bulgaria Ltd., Energoproject, 15th floor,

51 James Bourchier Blvd., 1407 SOFIA,
Tel. [phone], Fax. [phone]

Canada: PHILIPS SEMICONDUCTORS/COMPONENTS,
Tel. [phone], Fax. [phone]

China/Hong Kong: 501 Hong Kong Industrial Technology Centre,
72 Tat Chee Avenue, Kowloon Tong, HONG KONG,
Tel. [phone], Fax. [phone]

Colombia: see South America
Czech Republic: see Austria
Denmark: Sydhavnsgade 23, 1780 COPENHAGEN V,

Tel. [phone], Fax. [phone]
Finland: Sinikalliontie 3, FIN-02630 ESPOO,

Tel. [phone], Fax. [phone]
France: 51 Rue Carnot, BP317, 92156 SURESNES Cedex,

Tel. [phone], Fax. [phone]
Germany: Hammerbrookstraße 69, D-20097 HAMBURG,

Tel. [phone], Fax. [phone]

Hungary: see Austria
India: Philips INDIA Ltd, Band Box Building, 2nd floor,

254-D, Dr. Annie Besant Road, Worli, MUMBAI 400 025,
Tel. [phone], Fax. [phone]

Indonesia: PT PhilipsDevelopment Corporation, Semiconductors Division,
Gedung Philips, Jl. Buncit Raya Kav.99-100, JAKARTA 12510,
Tel. [phone] ext. 2501, Fax. [phone]

Ireland: Newstead, Clonskeagh, DUBLIN 14,
Tel. [phone], Fax. [phone]

Israel: RAPAC Electronics, 7 Kehilat Saloniki St, PO Box 18053,
TEL AVIV 61180, Tel. [phone], Fax. [phone]

Italy: PHILIPS SEMICONDUCTORS, Via Casati, 23 - 20052 MONZA (MI),
Tel. [phone], Fax [phone]

Japan: Philips Bldg 13-37, Kohnan 2-chome, Minato-ku,
TOKYO 108-8507, Tel. [phone], Fax. [phone]

Korea: Philips House, 260-199 Itaewon-dong, Yongsan-ku, SEOUL,
Tel. [phone], Fax. [phone]

Malaysia: No. 76 Jalan Universiti, 46200 PETALING JAYA, SELANGOR,
Tel. [phone], Fax. [phone]

Mexico: 5900 Gateway East, Suite 200, EL PASO, TEXAS 79905,
Tel. [phone], Fax [phone]

Middle East: see Italy

Netherlands: Postbus 90050, 5600 PB EINDHOVEN, Bldg. VB,

Tel. [phone], Fax. [phone]
New Zealand: 2 Wagener Place, C.P.O. Box 1041, AUCKLAND,

Tel. [phone], Fax. [phone]
Norway: Box 1, Manglerud 0612, OSLO,

Tel. [phone], Fax. [phone]

Pakistan: see Singapore
Philippines: Philips Semiconductors Philippines Inc.,

106 Valero St. Salcedo Village, P.O. Box 2108 MCC, MAKATI,
Metro MANILA, Tel. [phone], Fax. [phone]

Poland: Al.Jerozolimskie 195 B, 02-222 WARSAW,
Tel. [phone], Fax. [phone]

Portugal: see Spain
Romania: see Italy
Russia: Philips Russia, Ul. Usatcheva 35A, 119048 MOSCOW,

Tel. [phone], Fax. [phone]
Singapore: Lorong 1, Toa Payoh, SINGAPORE 319762,

Tel. [phone], Fax. [phone]

Slovakia: see Austria
Slovenia: see Italy
South Africa: S.A. PHILIPS Pty Ltd., 195-215 Main Road Martindale,

2092 JOHANNESBURG, P.O. Box 58088 Newville 2114,
Tel. [phone], Fax. [phone]

South America: Al. Vicente Pinzon, 173, 6th floor,
04547-130 SÃO PAULO, SP, Brazil,
Tel. [phone], Fax. [phone]

Spain: Balmes 22, 08007 BARCELONA,
Tel. [phone], Fax. [phone]

Sweden: Kottbygatan 7, Akalla, S-16485 STOCKHOLM,
Tel. [phone], Fax. [phone]

Switzerland: Allmendstrasse 140, CH-8027 ZÜRICH,
Tel. [phone] Fax. [phone]

Taiwan: Philips Semiconductors, 6F, No. 96, Chien Kuo N. Rd., Sec. 1,
TAIPEI, Taiwan Tel. [phone], Fax. [phone]

Thailand: PHILIPS ELECTRONICS (THAILAND) Ltd.,
209/2 Sanpavuth-Bangna Road Prakanong, BANGKOK 10260,
Tel. [phone], Fax. [phone]

Turkey: Yukari Dudullu, Org. San. Blg., 2.Cad. Nr. 28 81260 Umraniye,
ISTANBUL, Tel. [phone], Fax. [phone]

Ukraine: PHILIPS UKRAINE, 4 Patrice Lumumba str., Building B, Floor 7,
252042 KIEV, Tel. [phone], Fax. [phone]

United Kingdom: Philips Semiconductors Ltd., 276 Bath Road, Hayes,
MIDDLESEX UB3 5BX, Tel. [phone], Fax. [phone]

United States: 811 East Arques Avenue, SUNNYVALE, CA 94088-3409,
Tel. [phone], Fax. [phone]

Uruguay: see South America
Vietnam: see Singapore
Yugoslavia: PHILIPS, Trg N. Pasica 5/v, 11000 BEOGRAD,

Tel. [phone], Fax.[phone]

Printed in The Netherlands 753504/01/pp36 Date of release:2000 Feb 04 Document order number: 9397 750 06587
