Datasheet MSC400SMA330B4 Datasheet

MSC400SMA330B4

3300 V, 400 mΩ SiC N-Channel Power MOSFET

Product Overview

The silicon carbide (SiC) power MOSFET product line from Microsemi increases the performance over silicon
MOSFET and silicon IGBT solutions while lowering the total cost of ownership for high-voltage applications. The
MSC400SMA330B4 device is a 3300 V, 400 mΩ SiC MOSFET in a TO-247 4-lead package with a source sense.

Features

The following are key features of the MSC400SMA330B4 device:

• Low capacitances and low gate charge

• Fast switching speed due to low internal gate resistance (ESR)

• Stable operation at high junction temperature, T

• Fast and reliable body diode

• Superior avalanche ruggedness

• RoHS compliant

Benefits

The following are benefits of the MSC400SMA330B4 device:

• High efficiency to enable lighter, more compact system

• Simple to drive and easy to parallel

• Improved thermal capabilities and lower switching losses

• Eliminates the need for external freewheeling diode

• Lower system cost of ownership

Applications

The MSC400SMA330B4 device is designed for the following applications:

• PV inverter, converter, and industrial motor drives

• Smart grid transmission and distribution

• Induction heating and welding

• H/EV powertrain and EV charger

• Power supply and distribution

J(max)

= 150 °C

© 2022 Microchip Technology Inc.

and its subsidiaries

Datasheet

DS00004433A-page 1

1. Device Specifications

This section shows the specifications of the MSC400SMA330B4 device.

1.1 Absolute Maximum Ratings

The following table shows the absolute maximum ratings of the MSC400SMA330B4 device.

Table 1-1. Absolute Maximum Ratings

Symbol Parameter Ratings Unit

MSC400SMA330B4

Device Specifications

V

DSS

I

D

Drain source voltage 3300 V

Continuous drain current at TC = 25 °C 11 A

Continuous drain current at TC = 100 °C 7

I

DM

V

GS

P

D

Pulsed drain current

Gate-source voltage 23 to –10 V

Total power dissipation at TC = 25 °C 131 W

1

27

Linear derating factor 1.05 W/°C

Note: 

1. Repetitive rating: pulse width and case temperature limited by maximum junction temperature.

The following table shows the thermal and mechanical characteristics of the MSC400SMA330B4 device.

Table 1-2. Thermal and Mechanical Characteristics

Symbol Characteristic/Test Conditions Min Typ Max Unit

R

θJC

T

J

T

STG

T

L

Junction-to-case thermal resistance 0.64 0.96 °C/W

Operating junction temperature –55 150 °C

Storage temperature –55 150 °C

Soldering temperature for 10 seconds (1.6

300 °C

mm from case)

Mounting torque, 6-32 or M3 screw 10 lbf-in

Wt Package weight 0.22 oz

1.2 Electrical Performance

The following table shows the static characteristics of the MSC400SMA330B4 device. TJ = 25 °C unless otherwise
specified.

Table 1-3. Static Characteristics

Symbol Characteristic Test Conditions Min Typ Max Unit

V

(BR)DSS

R

DS(on)

© 2022 Microchip Technology Inc.

and its subsidiaries

Drain-source breakdown voltage VGS = 0 V, ID = 100 μA 3300 V

Drain-source on resistance

1.1 N-m

6.2 g

1

VGS = 20 V, ID = 5 A 416 520 mΩ

Datasheet

DS00004433A-page 2

MSC400SMA330B4

Device Specifications

...........continued

Symbol Characteristic Test Conditions Min Typ Max Unit

V

I

DSS

GS(th)

Gate-source threshold voltage VGS = VDS, ID = 1 mA 1.9 2.97 V

Zero gate voltage drain current VDS = 3300 V, VGS = 0 V 100 µA

VDS = 3300 V, VGS = 0 V, TJ =

500

125 °C

I

GSS

Gate-source leakage current VGS = 20 V/–10 V ±100 nA

Note: 

1. Pulse test: pulse width < 380 μs, duty cycle < 2%.

The following table shows the dynamic characteristics of the MSC400SMA330B4 device. TJ = 25 °C unless otherwise
specified.

Table 1-4. Dynamic Characteristics

Symbol Characteristic Test Conditions Min Typ Max Unit

C

C

C

Q

Q

Q

t

d(on)

t

r

t

d(off)

t

f

E

E

iss

rss

oss

g

gs

gd

on

off

Input capacitance VGS = 0 V

Reverse transfer
capacitance

Output capacitance 18

VDD = 2400 V

VAC = 25 mV

ƒ = 200 kHz

Total gate charge VDD = 2600 V

Gate-source charge 10

Gate-drain charge 10

VGS = –5 V/20 V

ID = 5 A

Turn-on delay time VDD = 2310 V

Voltage rise time 8

Turn-off delay time 16

Voltage fall time 20

Turn-on switching energy 750 µJ

Turn-off switching energy 120

VGS = –5 V/20 V

ID = 10 A

R

= 16 Ω

g(ext)

Freewheeling diode =
MSC400SMA330B4 (VGS = –5
V) (reference Fig. 1-17)

579 pF

2

37 nC

16 ns

ESR Gate equivalent series

f = 1 MHz, 25 mV, drain short 3.7 Ω

resistance

The following table shows the body diode characteristics of the MSC400SMA330B4 device. TJ = 25 °C unless
otherwise specified.

Table 1-5. Body Diode Characteristics

Symbol Characteristic Test Conditions Min Typ Max Unit

V

SD

Diode forward voltage ISD = 5 A, VGS = 0 V 4.0 V

ISD = 5 A, VGS = –5 V 4.0

t

rr

Q

rr

I

RRM

© 2022 Microchip Technology Inc.

and its subsidiaries

Reverse recovery time ISD = 10 A, VDD = 2310 V, Drive

Reverse recovery charge 175 nC

Rg = 16 Ω, VGS = –5 V, dl/dt =
–7900 A/μs

14 ns

Reverse recovery current 32 A

Datasheet

DS00004433A-page 3

1.3 Typical Performance Curves

This section shows the typical performance curves of the MSC400SMA330B4 device.

MSC400SMA330B4

Device Specifications

Figure 1-1. Drain Current vs. VDS at T

Figure 1-3. Drain Current vs. VDS at V

J

GS

Figure 1-2. Drain Current vs. VDS at V

Figure 1-4. Drain Current vs. VDS at V

GS

GS

© 2022 Microchip Technology Inc.

and its subsidiaries

Datasheet

DS00004433A-page 4

MSC400SMA330B4

Device Specifications

Figure 1-5. R

Figure 1-7. Capacitance vs. Drain-to-Source Voltage Figure 1-8. ID vs. VDS 3rd Quadrant Conduction

vs. Junction Temperature Figure 1-6. Gate Charge Characteristics

DS(on)

© 2022 Microchip Technology Inc.

and its subsidiaries

Datasheet

DS00004433A-page 5

MSC400SMA330B4

Device Specifications

Figure 1-9. ID vs. VDS 3rd Quadrant Conduction Figure 1-10. Switching Energy Eon vs. V

Figure 1-11. Switching Energy Eoff vs. V

DS

& I

D

Figure 1-12. Switching Energy vs. Rg

DS

& I

D

© 2022 Microchip Technology Inc.

and its subsidiaries

Datasheet

DS00004433A-page 6

MSC400SMA330B4

Device Specifications

Figure 1-13. Switching Energy vs. Temperature Figure 1-14. Threshold Voltage vs. Junction Temp.

Figure 1-15. Forward Safe Operating Area

© 2022 Microchip Technology Inc.

and its subsidiaries

Datasheet

DS00004433A-page 7

Figure 1-16. Maximum Transient Thermal Impedance

MSC400SMA330B4

Device Specifications

The following figure shows the switching waveform diagram of the MSC400SMA330B4 device.

Figure 1-17. Switching Waveform

© 2022 Microchip Technology Inc.

and its subsidiaries

Datasheet

DS00004433A-page 8

2. Package Specification

This section shows the package specification of the MSC400SMA330B4 device.

2.1 Package Outline Drawing

The following figure illustrates the TO-247-4L package outline of the MSC400SMA330B4 device.

Figure 2-1. Package Outline Drawing

MSC400SMA330B4

Package Specification

The following table shows the TO-247-4L dimensions and should be used in conjunction with the package outline
drawing.

Table 2-1. TO-247-4L Dimensions

Symbol Min (mm) Max (mm) Min (in.) Max (in.)

A 4.90 5.17 0.193 0.204

B 1.85 2.11 0.073 0.083

C 2.25 2.51 0.089 0.099

D 0.55 0.68 0.022 0.027

E 5.49 5.74 0.216 0.226

F 3.56 3.66 0.140 0.144

G 6.15 BSC 0.242 BSC

H 20.83 21.08 0.820 0.830

© 2022 Microchip Technology Inc.

and its subsidiaries

Datasheet

DS00004433A-page 9

MSC400SMA330B4

Package Specification

...........continued

Symbol Min (mm) Max (mm) Min (in.) Max (in.)

I 19.81 20.32 0.780 0.800

J 1.07 1.33 0.042 0.052

K 15.77 16.03 0.621 0.631

L 13.89 14.15 0.547 0.557

M 16.25 16.85 0.640 0.663

N 2.00 2.75 0.079 0.108

O 7.10 7.50 0.280 0.295

P 2.87 BSC 0.113 BSC

Q 5.08 BSC 0.200 BSC

R 2.54 BSC 0.100 BSC

Terminal 1 Drain

Terminal 2 Source

Terminal 3 Source sense

Terminal 4 Gate

Terminal 5 Drain

© 2022 Microchip Technology Inc.

and its subsidiaries

Datasheet

DS00004433A-page 10

3. Revision History

Table 3-1. Revision History

Revision Date Description

A 02/2022 Document created.

MSC400SMA330B4

Revision History

© 2022 Microchip Technology Inc.

and its subsidiaries

Datasheet

DS00004433A-page 11

MSC400SMA330B4

The Microchip Website

Microchip provides online support via our website at www.microchip.com/. This website is used to make files and
information easily available to customers. Some of the content available includes:

• Product Support – Data sheets and errata, application notes and sample programs, design resources, user’s
guides and hardware support documents, latest software releases and archived software

• General Technical Support – Frequently Asked Questions (FAQs), technical support requests, online
discussion groups, Microchip design partner program member listing

• Business of Microchip – Product selector and ordering guides, latest Microchip press releases, listing of
seminars and events, listings of Microchip sales offices, distributors and factory representatives

Product Change Notification Service

Microchip’s product change notification service helps keep customers current on Microchip products. Subscribers will
receive email notification whenever there are changes, updates, revisions or errata related to a specified product
family or development tool of interest.

To register, go to www.microchip.com/pcn and follow the registration instructions.

Customer Support

Users of Microchip products can receive assistance through several channels:

• Distributor or Representative

• Local Sales Office

• Embedded Solutions Engineer (ESE)

• Technical Support

Customers should contact their distributor, representative or ESE for support. Local sales offices are also available to
help customers. A listing of sales offices and locations is included in this document.

Technical support is available through the website at: www.microchip.com/support

Microchip Devices Code Protection Feature

Note the following details of the code protection feature on Microchip devices:

• Microchip products meet the specifications contained in their particular Microchip Data Sheet.

• Microchip believes that its family of products is secure when used in the intended manner and under normal
conditions.

• There are dishonest and possibly illegal methods being used in attempts to breach the code protection features
of the Microchip devices. We believe that these methods require using the Microchip products in a manner
outside the operating specifications contained in Microchip’s Data Sheets. Attempts to breach these code
protection features, most likely, cannot be accomplished without violating Microchip’s intellectual property rights.

• Microchip is willing to work with any customer who is concerned about the integrity of its code.

• Neither Microchip nor any other semiconductor manufacturer can guarantee the security of its code. Code
protection does not mean that we are guaranteeing the product is “unbreakable.” Code protection is constantly
evolving. We at Microchip are committed to continuously improving the code protection features of our products.
Attempts to break Microchip’s code protection feature may be a violation of the Digital Millennium Copyright Act.
If such acts allow unauthorized access to your software or other copyrighted work, you may have a right to sue
for relief under that Act.

© 2022 Microchip Technology Inc.

and its subsidiaries

Datasheet

DS00004433A-page 12

MSC400SMA330B4

Legal Notice

Information contained in this publication is provided for the sole purpose of designing with and using Microchip
products. Information regarding device applications and the like is provided only for your convenience and may be
superseded by updates. It is your responsibility to ensure that your application meets with your specifications.

THIS INFORMATION IS PROVIDED BY MICROCHIP “AS IS”. MICROCHIP MAKES NO REPRESENTATIONS
OR WARRANTIES OF ANY KIND WHETHER EXPRESS OR IMPLIED, WRITTEN OR ORAL, STATUTORY
OR OTHERWISE, RELATED TO THE INFORMATION INCLUDING BUT NOT LIMITED TO ANY IMPLIED
WARRANTIES OF NON-INFRINGEMENT, MERCHANTABILITY, AND FITNESS FOR A PARTICULAR PURPOSE
OR WARRANTIES RELATED TO ITS CONDITION, QUALITY, OR PERFORMANCE.

IN NO EVENT WILL MICROCHIP BE LIABLE FOR ANY INDIRECT, SPECIAL, PUNITIVE, INCIDENTAL OR
CONSEQUENTIAL LOSS, DAMAGE, COST OR EXPENSE OF ANY KIND WHATSOEVER RELATED TO THE
INFORMATION OR ITS USE, HOWEVER CAUSED, EVEN IF MICROCHIP HAS BEEN ADVISED OF THE
POSSIBILITY OR THE DAMAGES ARE FORESEEABLE. TO THE FULLEST EXTENT ALLOWED BY LAW,
MICROCHIP'S TOTAL LIABILITY ON ALL CLAIMS IN ANY WAY RELATED TO THE INFORMATION OR ITS USE
WILL NOT EXCEED THE AMOUNT OF FEES, IF ANY, THAT YOU HAVE PAID DIRECTLY TO MICROCHIP FOR
THE INFORMATION. Use of Microchip devices in life support and/or safety applications is entirely at the buyer’s risk,
and the buyer agrees to defend, indemnify and hold harmless Microchip from any and all damages, claims, suits, or
expenses resulting from such use. No licenses are conveyed, implicitly or otherwise, under any Microchip intellectual
property rights unless otherwise stated.

Trademarks

The Microchip name and logo, the Microchip logo, Adaptec, AnyRate, AVR, AVR logo, AVR Freaks, BesTime,
BitCloud, chipKIT, chipKIT logo, CryptoMemory, CryptoRF, dsPIC, FlashFlex, flexPWR, HELDO, IGLOO, JukeBlox,
KeeLoq, Kleer, LANCheck, LinkMD, maXStylus, maXTouch, MediaLB, megaAVR, Microsemi, Microsemi logo,
MOST, MOST logo, MPLAB, OptoLyzer, PackeTime, PIC, picoPower, PICSTART, PIC32 logo, PolarFire, Prochip
Designer, QTouch, SAM-BA, SenGenuity, SpyNIC, SST, SST Logo, SuperFlash, Symmetricom, SyncServer,
Tachyon, TimeSource, tinyAVR, UNI/O, Vectron, and XMEGA are registered trademarks of Microchip Technology
Incorporated in the U.S.A. and other countries.

AgileSwitch, APT, ClockWorks, The Embedded Control Solutions Company, EtherSynch, FlashTec, Hyper Speed
Control, HyperLight Load, IntelliMOS, Libero, motorBench, mTouch, Powermite 3, Precision Edge, ProASIC,
ProASIC Plus, ProASIC Plus logo, Quiet-Wire, SmartFusion, SyncWorld, Temux, TimeCesium, TimeHub, TimePictra,
TimeProvider, WinPath, and ZL are registered trademarks of Microchip Technology Incorporated in the U.S.A.

Adjacent Key Suppression, AKS, Analog-for-the-Digital Age, Any Capacitor, AnyIn, AnyOut, Augmented Switching,
BlueSky, BodyCom, CodeGuard, CryptoAuthentication, CryptoAutomotive, CryptoCompanion, CryptoController,
dsPICDEM, dsPICDEM.net, Dynamic Average Matching, DAM, ECAN, Espresso T1S, EtherGREEN, IdealBridge,
In-Circuit Serial Programming, ICSP, INICnet, Intelligent Paralleling, Inter-Chip Connectivity, JitterBlocker, maxCrypto,
maxView, memBrain, Mindi, MiWi, MPASM, MPF, MPLAB Certified logo, MPLIB, MPLINK, MultiTRAK, NetDetach,
Omniscient Code Generation, PICDEM, PICDEM.net, PICkit, PICtail, PowerSmart, PureSilicon, QMatrix, REAL ICE,
Ripple Blocker, RTAX, RTG4, SAM-ICE, Serial Quad I/O, simpleMAP, SimpliPHY, SmartBuffer, SMART-I.S., storClad,
SQI, SuperSwitcher, SuperSwitcher II, Switchtec, SynchroPHY, Total Endurance, TSHARC, USBCheck, VariSense,
VectorBlox, VeriPHY, ViewSpan, WiperLock, XpressConnect, and ZENA are trademarks of Microchip Technology
Incorporated in the U.S.A. and other countries.

SQTP is a service mark of Microchip Technology Incorporated in the U.S.A.

The Adaptec logo, Frequency on Demand, Silicon Storage Technology, and Symmcom are registered trademarks of
Microchip Technology Inc. in other countries.

GestIC is a registered trademark of Microchip Technology Germany II GmbH & Co. KG, a subsidiary of Microchip
Technology Inc., in other countries.

All other trademarks mentioned herein are property of their respective companies.

©

2022, Microchip Technology Incorporated, Printed in the U.S.A., All Rights Reserved.

ISBN: 978-1-5224-9733-2

© 2022 Microchip Technology Inc.

and its subsidiaries

Datasheet

DS00004433A-page 13

MSC400SMA330B4

Quality Management System

For information regarding Microchip’s Quality Management Systems, please visit www.microchip.com/quality.

© 2022 Microchip Technology Inc.

and its subsidiaries

Datasheet

DS00004433A-page 14

Worldwide Sales and Service

AMERICAS ASIA/PACIFIC ASIA/PACIFIC EUROPE

Corporate Office

2355 West Chandler Blvd.

Chandler, AZ 85224-6199

Tel: [phone]

Fax: [phone]

Technical Support:

www.microchip.com/support

Web Address:

www.microchip.com

Atlanta

Duluth, GA

Tel: [phone]

Fax: [phone]

Austin, TX

Tel: [phone]

Boston

Westborough, MA

Tel: [phone]

Fax: [phone]

Chicago

Itasca, IL

Tel: [phone]

Fax: [phone]

Dallas

Addison, TX

Tel: [phone]

Fax: [phone]

Detroit

Novi, MI

Tel: [phone]

Houston, TX

Tel: [phone]

Indianapolis

Noblesville, IN

Tel: [phone]

Fax: [phone]

Tel: [phone]

Los Angeles

Mission Viejo, CA

Tel: [phone]

Fax: [phone]

Tel: [phone]

Raleigh, NC

Tel: [phone]

New York, NY

Tel: [phone]

San Jose, CA

Tel: [phone]

Tel: [phone]

Canada - Toronto

Tel: [phone]

Fax: [phone]

Australia - Sydney

Tel: [phone]

China - Beijing

Tel: [phone]

China - Chengdu

Tel: [phone]

China - Chongqing

Tel: [phone]

China - Dongguan

Tel: [phone]

China - Guangzhou

Tel: [phone]

China - Hangzhou

Tel: [phone]

China - Hong Kong SAR

Tel: [phone]

China - Nanjing

Tel: [phone]

China - Qingdao

Tel: [phone]

China - Shanghai

Tel: [phone]

China - Shenyang

Tel: [phone]

China - Shenzhen

Tel: [phone]

China - Suzhou

Tel: [phone]

China - Wuhan

Tel: [phone]

China - Xian

Tel: [phone]

China - Xiamen

Tel: [phone]

China - Zhuhai

Tel: [phone]

India - Bangalore

Tel: [phone]

India - New Delhi

Tel: [phone]

India - Pune

Tel: [phone]

Japan - Osaka

Tel: [phone]

Japan - Tokyo

Tel: [phone]

Korea - Daegu

Tel: [phone]

Korea - Seoul

Tel: [phone]

Malaysia - Kuala Lumpur

Tel: [phone]

Malaysia - Penang

Tel: [phone]

Philippines - Manila

Tel: [phone]

Singapore

Tel: [phone]

Taiwan - Hsin Chu

Tel: [phone]

Taiwan - Kaohsiung

Tel: [phone]

Taiwan - Taipei

Tel: [phone]

Thailand - Bangkok

Tel: [phone]

Vietnam - Ho Chi Minh

Tel: [phone]

Austria - Wels

Tel: [phone]

Fax: [phone]

Denmark - Copenhagen

Tel: [phone]

Fax: [phone]

Finland - Espoo

Tel: [phone]

France - Paris

Tel: [phone]

Fax: [phone]

Germany - Garching

Tel: [phone]

Germany - Haan

Tel: [phone]

Germany - Heilbronn

Tel: [phone]

Germany - Karlsruhe

Tel: [phone]

Germany - Munich

Tel: [phone]

Fax: [phone]

Germany - Rosenheim

Tel: [phone]

Israel - Ra’anana

Tel: [phone]

Italy - Milan

Tel: [phone]

Fax: [phone]

Italy - Padova

Tel: [phone]

Netherlands - Drunen

Tel: [phone]

Fax: [phone]

Norway - Trondheim

Tel: [phone]

Poland - Warsaw

Tel: [phone]

Romania - Bucharest

Tel: [phone]

Spain - Madrid

Tel: [phone]

Fax: [phone]

Sweden - Gothenberg

Tel: [phone]

Sweden - Stockholm

Tel: [phone]

UK - Wokingham

Tel: [phone]

Fax: [phone]

© 2022 Microchip Technology Inc.

and its subsidiaries

Datasheet

DS00004433A-page 15
