Product datasheet
G6T5/OF 25/CS 1/SKU
Product features and benefits
_
Effective and environment-friendly disinfection without
chemicals
_
High UV-C radiance at 254 nm
_
Low mercury content
_
Long lifetime due to special coating
_
Ozone-free
__
Areas of application
_
Air
_
Water Purification
_
Surface Sterilization
July 26, 2022, 15:49:33 © 2022, OSRAM GmbH. All rights reserved.
HNS 6 W G5 Page 1 of 4
Page 2
Product datasheet
Technical data
General product information
Product Number 23399
Product Name G6T5OF 25/CS 1/SKU
Ordering Abbreviation G6T5/OF 25/CS 1/SKU
Brand Name OSRAM
General Description 6 watt soft glass germicidal lamp
Application Air and water purification, surface disinfection
Product Remark
_
The life ratings of fluorescent lamps are based
on 3 hr. burning cycles under specified
conditions and with ballast meeting ANSI
specifications. If burning cycle is increased,
there will be a corresponding increase in the
average hours life.
_
Germicidal lamps can be operated on
corresponding wattage preheat ballasts.
_
Starter required.
Electrical data
Nominal Wattage 6 W
Nominal Voltage 42 V
__
Current (A) 0.16 A
Light technical data
Average Rated Life 6000 h
Physical attributes
Base Miniature Bipin
Bulb Shape T5
Maximum Overall Length (mm) 226.3 mm
Length l (mm) 212 mm
Diameter d (mm) 16 mm
Distance a (mm) 154 mm
Additional product data
Operating Position Any
Total surface inside 1: appearance (cold) Clear
Lamp Type PREHEAT
July 26, 2022, 15:49:33 © 2022, OSRAM GmbH. All rights reserved.
HNS 6 W G5 Page 2 of 4
Page 3
Product datasheet
Safety advice
To prevent possible serious injury, eyes and skin should not be exposed to direct or reflected ultraviolet light emitted by this
lamp. This lamp is in Risk Group 3 per ANSI/IESNARP-27.3-96. Adequate protection should be provided by clothing, gloves,
opaque materials, and ordinary window glass. Although this lamp will operate in standard fluorescent fixtures, it should not be
used for general lighting applications.
Packaging Information
Product number EAN/UPC Packaging Quantity Outside dimensions l x w x h Gross weight
23399 4008321378330 Sleeve (SKU) 1 8.9 in x 0.7 in x 0.7 in 0.1 lb
23399 4008321378347 Shipping box (Case) 25 9.7 in x 4.7 in x 4.3 in 1.6 lb
The mentioned product code describes the smallest quantity unit which can be ordered. One shipping unit can contain one or
more single products. When placing an order, for the quantity please enter single or multiples of a shipping unit.
Disclaimer
OSRAM does not accept liability for errors, changes and omissions.
__
July 26, 2022, 15:49:33 © 2022, OSRAM GmbH. All rights reserved.
HNS 6 W G5 Page 3 of 4
Page 4
Product datasheet
HNS 6 W G5
PURITEC HNS Linear Lamps |
Product name Lamp group
HNS 6 W G5 QT-ECO 1x4-16/220-240 S
QT-ECO 2x5-11/220-240 S
QTP-D/E 1x10-13
