CPC1017N Units

Load Voltage 60 V
Load Current 100 mA
Max R

ON

16 Ω

Current to operate 1.0 mA

Part # Description

CPC1017N 4 Pin SOP (100/tube)
CPC1017NTR 4 Pin SOP (2,000/reel)

www.clare.com

DS-CPC1017N-R0A.1

CPC1017N

4 Pin SOP OptoMOS®Relays

1

Applications

Features

Description

Approvals

Ordering Information

Pin Configuration

Switching Characteristics of

Normally Open (Form A) Devices

CONTROL

LOAD

10ms

10%

10%

90%

+

T

ON

T

OFF

+

+

• Design for use in security systems complying with

EN50130-4

• Only 1mA of LED curent required to operate

• Small 4 Pin SOP Package

• TTL/CMOS Compatible input

• No Moving Parts

• High Reliability

• Arc-Free With No Snubbing Circuits

• 1500V

RMS

Input/Output Isolation/2100V AC peak

• No EMI/RFI Generation

• Immune to radiated EM fields

• SMD Pick & Place, Wave Solderable

• Tape & Reel Version Available

• Security

• Passive Infrared Detectors (PIR)

• Data Signalling

• Sensor Circuitry

• Instrumentation

• Multiplexers

• Data Acquisition

• Electronic Switching

• I/O Subsystems

• Meters (Watt-Hour, Water, Gas)

• Medical Equipment—Patient/Equipment Isolation

• Aerospace

• Industrial Controls

The CPC1017N is a miniature 1-Form-A solid state
relay in a 4 pin SOP package that employs optically
coupled MOSFET technology to provide 1500V of
input to output isolation. The super efficient MOSFET
switches and photovoltaic die use Clare’s patented
OptoMOS architecture. The optically coupled input is
controlled by a highly efficient GaAIAs infrared LED.
The CPC1017N uses Clare’s state-of-the-art double
molded vertical construction packaging to produce
the world’s smallest relay. The CPC1017N offers
board space savings of at least 20% over the com­petitor’s larger 4 pin SOP relay. It boasts the indus­tries’ lowest input current to operate in its class.

• UL Recognized Component

• BSI Certified to EN60950

1

2

3

4

+ Control

– Control

Load

Load

CPC1017N Pinout

PRELIMINARY

Parameter Conditions Symbol Min Typ Max Units

Output Characteristics @ 25°C

Load Voltage (Peak) IL=1µAVL-- 60V
Load Current (Continuous)

AC Peak

1

IF=10mA I

L

- - 100 mA

Peak Load Current 10ms I

LPK

- - 350 mA

On-Resistance

2

IL=100mA R

ON

-- 16Ω

Off-State Leakage Current VL=60V I

LEAK

-- 1µA

Switching Speeds

Tur n- On IF=5mA, VL=10V T

ON

-- 10ms

Turn-Off IF=5mA, VL=10V T

OFF

-10ms

Output Capacitance 50V; f=1MHz C

OUT

-25 -pF

Capacitance

Input to Output - - - 1 - pF

Input Characteristics @ 25°C

Input Control Current

3

IL=150mA I

F

1- 50mA

Input Dropout Current - I

F

0.3 0.9 - mA

Input Voltage Drop IF=5mA V

F

0.9 1.2 1.4 V

Reverse Input Voltage - V

R

-- 5V

Reverse Input Current V

R

=5V I

R

- - 10 µA

1

Load current derates linearly from 100mA @ 25oC to 80mA @ 80oC.

2

Measurement taken within 1 second of on time.

3

For applications requiring high temperature operation (greater than 60oC) an LED drive current of 3mA is recommended.

www.clare.com

2

CPC1017N

R0A.1

Absolute Maximum Ratings are stress ratings. Stresses in
excess of these ratings can cause permanent damage to
the device. Functional operation of the device at these or
any other conditions beyond those indicated in the opera­tional sections of this data sheet is not implied. Exposure of
the device to the absolute maximum ratings for an extend­ed period may degrade the device and effect its reliability.

Absolute Maximum Ratings (@ 25˚ C)

Parameter Min Typ Max Units

Input Power Dissipation - - 70 mW
Input Control Current - - 50 mA
Peak (10ms) - - 1 A
Reverse Input Voltage - - 5 V
Total Power Dissipation - - 4001mW
Isolation Voltage Input

to Output(AC Peak test voltage) 2100 - - V

peak

Operational Temperature -40 - +85°C
Storage Temperature -40 - +125°C
Soldering Temperature - - +220

°

C

(10 Seconds Max.)

1

Derate Linearly 3.33 mw /oC

Electrical Characteristics

CPC1017N

www.clare.com

3

R0A.1

PRELIMINARY

CPC1017N

Typical LED Forward Voltage Drop

vs. Temperature

Temperature ( C)

LED Forward Voltage Drop (V)

1.8

1.6

1.4

1.2

1.0

0.8

-40 -20 0 20 40 60 80 120100

50mA

10mA
5mA

o

CPC1017N

Typical Turn-Off vs. Temperature

(Load Current = 50mA)

Temperature ( C)

Turn-Off (ms)

-40

1.000

0.900

0.800

0.700

0.600

0.500

0.400

0.300

0.200

0.100
0

-20 0 20 40 60 80 100

o

I =5mA

F

I =2mA

F

CPC1017N

Typical Turn-On vs. Temperature

(Load Current = 50mA)

Temperature ( C)

Turn-On (ms)

-40

5.000

4.500

4.000

3.500

3.000

2.500

2.000

1.500

1.000

0.500
0

-20 0 20 40 60 80 100

o

I =5mA

F

I =2mA

F

CPC1017N

Typical Leakage vs. Temperature

(Measured across Pins 3 & 4) IL = max rated

Temperature ( C)

Leakage (µA)

-40

0.016

0.014

0.012

0.010

0.008

0.006

0.004

0.002

0

-20 0 20 40 60 80 100

o

CPC1017N

Typical Load Current vs. Temperature

Temperature ( C)

Load Current (mA)

180

160

140

120

100

80

60

40

20

0

-40 -20 0 20 40 60 80 120100

I =2mA

F

o

I =5mA

F

CPC1017N

Typical Turn-Off Time

(Ambient Temperature = 25 C)

(Load Current = 100mA; IF = 5mA)

0.26 0.30 0.34 0.380.360.320.28

Turn-Off (ms)

Device Count (N)

25

20

15

10

5

0

o

CPC1017N

Typical Turn-On Time

(Ambient Temperature = 25 C)

(Load Current = 100mA; IF = 5mA)

1.0 1.2 1.4 1.61.1 1.3 1.5

Turn-On (ms)

Device Count (N)

25

20

15

10

5

0

o

CPC1017N

Typical IF for Switch Dropout

(Ambient Temperature = 25 C)

(Load Current = 100mA)

25

20

15

10

5

0

0.35 0.45 0.550.30 0.40 0.50 0.60

LED Current (mA)

Device Count (N)

o

CPC1017N

Typical On-Resistance Distribution

(Ambient Temperature = 25 C)

(Load Current = 100mA)

35

30

25

20

15

10

5

0

On-Resistance (Ω)

Device Count (N)

o

6.8

6.9 7.17.0 7.47.2

7.3

CPC1017N

Typical LED Forward Voltage Drop

(Ambient Temperature = 25 C)

IF = 5mADC

35

30

25

20

15

10

5

0

1.17 1.19 1.21 1.23 1.25

LED Forward Voltage Drop (V)

Device Count (N)

o

PERFORMANCE DATA*

CPC1017N

Typical IF for Switch Operation

(Ambient Temperature = 25 C)

(Load Current = 100mA)

0.35 0.45 0.550.30 0.40 0.50 0.60

LED Current (mA)

Device Count (N)

25

20

15

10

5

0

o

CPC1017N

Typical Turn-Off vs. Temperature

(Load Current = 50mA)

Temperature ( C)

Turn-Off (ms)

-40

1.000

0.900

0.800

0.700

0.600

0.500

0.400

0.300

0.200

0.100
0

-20 0 20 40 60 80 100

o

I =5mA

F

I =2mA

F

* The Performance data shown in the graphs above is typical of device performance. For guaranteed parameters not indicated in the written specifications, please contact our application
department.

www.clare.com

4

CPC1017N

R0A.1

PRELIMINARY

CPC1017N

Typical On-Resistance vs. Temperature

(Load Current = 50mA; IF = 5mA)

Temperature ( C)

On-Resistance ( )

-40

60

50

40

30

20

10

0

-20 0 20 40 60 80 100

o

CPC1017N

Typical Turn-Off vs. LED Forward Current

(Load Current = 100mA)

LED Forward Current (mA)

Turn-Off (ms)

0

5 1015202530354045

0.7

0.6

0.5

0.4

0.3

0.2

0.1

0

50

CPC1017N

Typical Turn-On vs. LED Forward Current

(Load Current = 100mA; IF=5mA)

LED Forward Current (mA)

Turn-On (ms)

0

5 1015202530354045

3.0

2.7

2.4

2.1

1.8

1.5

1.2

0.9

0.6

0.3
0

50

PERFORMANCE DATA*

* The Performance data shown in the graphs above is typical of device performance. For guaranteed parameters not indicated in the written specifications, please contact our application
department.

CPC1017N

Typical IF for Switch Operation

vs. Temperature

(Load Current = 50mA)

Temperature ( C)

LED Current (mA)

-40

3.000

2.500

2.000

1.500

1.000

0.500

0

-20 0 20 40 60 80 100

o

CPC1017N

Typical Load Current vs. Load Voltage

(Ambient Temperature = 25 C)

IF = 5mA

Load Voltage (V)

Load Current (mA)

150

100

50

0

-50

-100

-150

-3 -2 -1 0 1 2 3

o

CPC1017N

Energy Rating Curve

Time

Load Current (A)

10µs

1.0

0.9

0.8

0.7

0.6

0.5

0.4

0.3

0.2

0.1
0

1ms100µs 100ms

1s

10ms 10s 100s

CPC1017N

www.clare.com

5

R0A.1

PRELIMINARY

.20 ± .025

(.008 ± .001)

2.54 TYP.

(.100 TYP.)

2.16 MAX.
(.085)

1.02 ± .025

(.040 ± .001)

3.81 ± .08

(.150 ± .003)

6.096 ± .102
(.240 ± .004)

.38 x 45¼

(.015 x 45¼ )

.38 TYP.

(.015 TYP.)

4.09 ± 0.20

(0.161 ± 0.008)

.432 ± .127

(.017 ± .005)

Dimensions

mm

(inches)

MECHANICAL DIMENSIONS

4 Pin SOIC Narrow (“N” Suffix)

PC Board Pattern (Top View)

2.54 ± 0.127

(0.100 ± 0.005)

5.66 ± 0.14

(0.223 ± 0.005)

1.448

(0.057)

0.889

(0.035)

4.70 0.15

3.0 R

1.50

1.60

A

A

8.00

2.00 .05

+

_

4.00 .10

+

_

1.5 dia

5.50 .10

+

_

12.00

1.75

.30

.3 R MAX

TYP

2.30 0.15

SECTION A-A

Tape and Reel Packaging for 4 pin SOIC package

330.2 DiA
(13.00")

Top Cover

Tape Thickness

0.102 MAX
(0.004)

3.8

TYP

+

_

4.2
+

_

2.7 0.15

+

_

Embossment

Embossed

Carrier

6.50

0.15

+

_
