PowerScan™ PD9530
Quick Reference Guide
Industrial Corded Handheld
Area Imager Bar Code Reader
Datalogic ADC Inc.
959 Terry Street
Eugene, OR 97402
USA
Telephone: (541) 683-5700
Fax: (541) 345-7140
©2013-2016 Datalogic ADC Inc.
An Unpublished Work - All rights reserved. No part of the contents of this documentation or the procedures described
therein may be reproduced or transmitted in any form or by
any means without prior written permission of Datalogic ADC,
Inc. or its subsidiaries or affiliates ("Datalogic" or “Datalogic
ADC”). Owners of Datalogic products are hereby granted a
non-exclusive, revocable license to reproduce and transmit
this documentation for the purchaser's own internal business
purposes. Purchaser shall not remove or alter any proprietary
notices, including copyright notices, contained in this documentation and shall ensure that all notices appear on any
reproductions of the documentation.
Should future revisions of this manual be published, you can
acquire printed versions by contacting your Datalogic representative. Electronic versions may either be downloadable
from the Datalogic website (www.datalogic.com) or provided
on appropriate media. If you visit our website and would like
to make comments or suggestions about this or other Datalogic publications, please let us know via the "Contact Datalogic" page.
Datalogic has taken reasonable measures to provide information in this manual that is complete and accurate, however,
Datalogic reserves the right to change any specification at any
time without prior notice.
Datalogic and the Datalogic logo are registered trademarks of
Datalogic S.p.A. in many countries, including the U.S.A. and
the E.U. PowerScan is a registered trademark of Datalogic
ADC Inc. in many countries, including the U.S.A. and the E.U.
All other brand and product names may be trademarks of
their respective owners.
See www.patents.datalogic.com for patent list.
Disclaimer
Patents
See the Regulatory Addendum included with
your product for additional regulatory, safety
and legal information.
Table of Contents
END USER SOFTWARE LICENSE AGREEMENT (EULA) ............. iii
Software Product Policy ............................................................vii
Description ....................................................................................1
General Features .................................................................. 1
Setting Up the Reader .................................................................2
Connecting the Cable ........................................................... 3
Using the PowerScan™ PD9530 ..................................................4
Selecting the Interface Type .......................................................5
Interface Selection ............................................................... 5
Configuring the Interface ........................................... 5
Scancode Tables.......................................................... 8
Keyboard Interface ..................................................... 8
Country Mode.............................................................. 9
Caps Lock State......................................................... 13
Numlock..................................................................... 14
Programming ..............................................................................14
Using Programming Bar Codes ........................................ 14
Configure Other Settings ................................................... 15
Resetting Product Defaults ..............................................15
Reading Parameters ..................................................................16
Good Read Green Spot Duration ...................................... 16
Operating Modes ........................................................................17
Scan Mode .......................................................................... 17
Motion Aiming Control ...................................................... 18
Pick Mode ............................................................................ 19
Multiple Label Reading ...................................................... 19
Technical Specifications ............................................................20
LED and Beeper Indications ......................................................23
Error Codes .................................................................................26
Cleaning .......................................................................................27
Datalogic ADC Limited Factory
Warranty .....................................................................................28
Ergonomic Recommendations .................................................30
Services and Support .................................................................31
Quick Reference Guide i
NOTES
ii PowerScan™ PD9530
DATALOGIC IP TECH S.R.L.
END USER SOFTWARE LICENSE AGREEMENT (EULA)
FOR THE POWERSCAN™ 9500
Notice to End User: There are two types of software covered by this END USER
LICENSE AGREEMENT ("EULA"): (1) The Datalogic Product you have acquired contains embedded software ("Embedded Software") which is integral to the Product's
operation; and (2) Optional Application Software provided to you on an optional
basis ("Application Software"). Embedded Software and Application Software are
collectively referred to as "Software" and are subject to the terms and conditions
contained in this EULA. Software is provided only for use with, and for authorized
end users of, the Datalogic PowerScan™ 95XX ("Product"). Portions of the Embedded Software include or operate with Open Source software or libraries ("Open
Source"). Use of Open Source is subject to the Open Source licenses entitled "PowerScan_95XX.zip" available at the following website: http://www.datalogic.com/
software_lan_sb2783_1.html.
This EULA (End User Software License Agreement) ("EULA” or "Agreement") is a
legally binding agreement governing the licensing of the Software and Documentation by Datalogic IP Tech S.r.l. and its subsidiaries and affiliates ("Datalogic") to
the entity or person who has purchased or otherwise acquired a Datalogic Product
("End User"). For purposes of this Agreement, any software that is not Embedded
Software or Application Software is software associated with a separate end-user
license agreement is licensed to you under the terms of that license agreement.
Datalogic and End User hereby agree as follows:
1. Definitions
1.1 "Affiliate" means a business entity currently existing or later acquired that is
controlled by, or is under common control with Datalogic S.p.A.
1.2 "Documentation" means materials such as user's guides, program reference
guides, quick reference guides, manuals, or similar materials associated with
or related to the Datalogic Product, whether in printed, "online", or other form.
1.3 "Proprietary Information" means: (a) source code, object code, software, documentation, and any related internal design, system design, data base design,
algorithms, technology, technical data or information, implementation techniques, and trade secrets related to the Software, (b) any other trade secrets
marked appropriately or identified as proprietary or confidential, and (c) any
information that End User, under the circumstances, should recognize as confidential. Proprietary Information does not include any information that the
receiving party can establish was (1) in the public domain, (2) already in the
receiving party's possession or rightfully known prior to receipt, (3) rightfully
learned from a third party not in violation of any other's proprietary rights, or
(4) independently developed without access to Proprietary Information.
1.4 "Datalogic Product" means the Datalogic Powerscan™ series scanner product,
including all embedded Software in and all Documentation related to such
product, which has been purchased or otherwise acquired by End User,
whether obtained directly or indirectly from Datalogic.
1.5 "Software" means any software or computer programs of Datalogic or its third
party licensors in machine readable form which is embedded in the Datalogic
Product, whether obtained directly or indirectly from Datalogic, including any
replacement, update, upgrade, enhancement or modification.
2. Scope Of License Granted
2.1 Datalogic grants to End User a personal non-exclusive, non-transferable, perpetual license to use the Software, solely on the Datalogic Product in which it
is embedded ("designated Datalogic Product"), in machine-readable form only,
solely for End User's internal business purposes. This Agreement does not
convey ownership of the Software to End User. Title to the Software shall be
and remain with Datalogic or the third party from whom Datalogic has
obtained a licensed right. As used in this Agreement, the term "purchase" or
its equivalents when applied to the Software shall mean "acquire under
license." End User is not entitled to receipt or use of the source code to any
Software.
2.2 End User shall not copy, modify, decompile, disassemble, reverse engineer, or
otherwise reproduce or remanufacture the Software, whether modified or
unmodified, nor sell, assign, sublicense, distribute, lend, rent, give, or otherwise
transfer the Software to any other person or organization, for purposes other
than as expressly provided in this Agreement, without Datalogic's prior written
consent.
Quick Reference Guide iii
3. Transfers, Support
3.1 Any copying, installing, reproduction, remanufacture, reverse engineering,
electronic transfer, or other use of the Software on other than the designated
Datalogic Product will be a material breach of this Agreement. However, Datalogic may elect not to terminate this Agreement or the granted licenses, but
instead may elect to notify End User that End User is deemed to have ordered
and accepted a license for each breaching use. End User shall pay Datalogic
the applicable list price for such licenses as of the date of such breach.
3.2 End User shall not sell, assign, sublicense, distribute, lend, rent, give, or otherwise transfer the Datalogic Product to any third party unless such third party
agrees with Datalogic in writing to be bound by the terms and conditions of
this Agreement. Any such transfer of the Datalogic Product absent such
agreement shall be null and void.
3.3 End User may obtain support for Soft ware from Datalogic at Datalogic's standard support fees and under Datalogic's standard support terms and conditions in effect at the time the support is requested.
4. Intellectual Property
End User acknowledges that the Software comprises valuable trade secrets of
Datalogic or Datalogic's third party licensors and that the Software is protected by
United States copyright law and trade secret law, and by all applicable international intellectual property laws and treaty provisions . The license set forth in this
Agreement does not transfer to End User any ownership of Datalogic's or its third
party licensors' copyrights, patents, trademarks, service marks, trade secrets, or
other intellectual property rights and End User shall have no right to commence
any legal actions to obtain such rights. End User shall not remove, modify, or take
any other action that would obscure any copyright, trademark, patent marking, or
other intellectual property notices contained in or on the Datalogic Product.
5. Proprietary Information
5.1 End User acknowledges that Proprietary Information is the confidential, proprietary, and trade secret property of Datalogic and Datalogic's third party
licensors and End User acquires no right or interest in any Proprietary Information.
5.2 End User shall not disclose, provide, or otherwise make available the Proprietary Information of Datalogic or its third party licensors to any person other
than End User's authorized employees or agents who are under confidentiality
agreement, and End User shall not use the Proprietary Information other than
in conjunction with use of the Datalogic Product exclusively for End User's
internal business purposes. End User shall take steps to protect the Proprietary Information no less securely than if it were End User's own intellectual
property.
5.3 The provisions of this Proprietary Information Section shall survive and continue for five (5) years after the termination of this Agreement.
6. Limited Warranty
6.1 Datalogic warrants that, under normal use and operation, the Datalogic Product will conform substantially to the applicable Documentation for the period
specified in the Documentation. During this period, for all reproducible nonconformities for which Datalogic has been given written notice, Datalogic will
use commercially reasonable efforts to remedy nonconformities verified by
Datalogic. End User agrees to supply Datalogic with all reasonably requested
information and assistance necessary to help Datalogic in remedying such
nonconformities. For all defects reported to Datalogic within the warranty
period, Datalogic's liability is limited to providing End User with one copy of
corrections or responding to End User's problem reports according to Datalogic's standard assistance practices. Datalogic does not warrant that the
product will meet End User's requirements or that use of the product will be
uninterrupted or error free, or that Datalogic's remedial efforts will correct any
nonconformance. This limited warranty does not cover any product that have
been subjected to damage or abuse, whether intentionally, accidentally, or by
neglect, or to unauthorized repair or unauthorized installation, and shall be
void if End User modifies the product, uses the product in any manner other
than as established in the Documentation, or if End User breaches any of the
provisions of this Agreement.
6.2 EXCEPT AAS PROVIDED IN THIS AGREEMENT, THE DATALOGIC PRODUCT IS
PROVIDED "AS IS" AND DATALOGIC MAKES NO WARRANTIES OF ANY KIND,
EXPRESS OR IMPLIED, WRITTEN OR ORAL, WITH RESPECT TO THE PRODUCT,
AND SPECIFICALLY DISCLAIMS THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULA R PURPOSE.
iv PowerScan™ PD9530
7. Infringement
7.1 Datalogic will defend End User against any claim in a lawsuit that the Datalogic Product furnished hereunder directly infringe a United States patent or
copyright of a third party and Datalogic will pay any damages finally awarded
against End User by a court of competent jurisdiction that are attributable to
such claim or will pay End User's part of any settlement that is attributable to
such claim, provided, that 1) End User notifies Datalogic promptly in writing of
the claim, 2) Datalogic controls the defense or settlement of the claim, and 3)
End User cooperates fully with Datalogic in such defense or settlement. All
notices of a claim should be sent to Datalogic IP Tech S.r.l., Legal & IP Department, Via San Vitalino 13, 40012 Calderara di Reno (Bologna), Italy.
7.2 In the defense or settlement of any such claim, Datalogic may, at its option, 1)
procure for End User the right to continue using the Datalogic Product, 2)
modify the Datalogic Product so that it becomes non-infringing, 3) replace the
Datalogic Product with an equivalent product not subject to such claim, or 4)
provide End User an opportunity to return the Datalogic Product and receive a
refund of the purchase price paid, less a reasonable allowance for use.
7.3 Datalogic shall have no liability to End User for claims of infringement based
upon 1) the use of any Datalogic Product in combination with any product
which Datalogic has not either furnished or authorized for use with such Datalogic Product 2) the use of any Datalogic Product designed, manufactured, or
modified to the specifications of End User, or 3) End User's modification of the
Datalogic Product without written authorization from Datalogic.
7.4 THE FOREGOING STATES DATALOGIC'S COMPLETE AND ENTIRE OBLIGATION
CONCERNING CLAIMS OF PATENT, COPYRIGHT, OR OTHER INTELLECTUAL
PROPERTY INFRINGEMENT, CANCELS AND SUPERCEDES ANY PRIOR AGREEMENTS, WHETHER ORAL OR WRITTEN, BETWEEN THE PARTIES CONCERNING
SUCH CLAIMS, AND WILL NOT BE MODIFIED OR AMENDED BY ANY PAST, CONTEMPORANEOUS, OR FUTURE AGREEMENTS OR DEALINGS BETWEEN THE
PARTIES, WHETHER ORAL OR WRITTEN, EXCEPT AS SET FORTH IN A FUTURE
WRITING SIGNED BY BOTH PARTIES.
8. Limitation Of Liability
EXCEPT AS PROVIDED IN SECTION 7, DATALOGIC SHALL NOT BE LIABLE FOR ANY
CLAIMS AGAINST END USER BY ANY OTHER PARTY. IN NO EVENT SHALL DATALOGIC'S LIABILITY FOR DAMAGES, IF ANY, WHETHER BASED UPON CONTRACT,
TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY, STRICT LIABILITY, WARRANTY, OR ANY OTHER BASIS, EXCEED THE PRICE OR FEE PAID BY END USER FOR
THE DATALOGIC PRODUCT. UNDER NO CIRCUMSTANCES SHALL DATALOGIC BE
LIABLE TO END USER OR ANY THIRD PARTY FOR LOST PROFITS, LOST DATA,
INTERRUPTION OF BUSINESS OR SERVICE, OR FOR ANY OTHER SPECIAL, CONSEQUENTIAL, CONTINGENT, INDIRECT, INCIDENTAL, PUNITIVE, EXEMPLARY, OR
OTHER SIMILAR DAMAGES, EVEN IF DATALOGIC HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
9. Government Restricted Rights; International Use
9.1 Use, duplication, or disclosure of the Software by the U.S. Government is subject to the restrictions for computer software developed at private expense as
set forth in the U.S. Federal Acquisition Regulations at FAR 52.227-14(g), or
52.227-19 or in the Rights in Technical Data and Computer Software clause at
DFARS 252.227-7013(c)(1)(ii), whichever is applicable.
9.2 If End User is using the Datalogic Product outside of the United States, End
User must comply with the applicable local laws of the country in which the
Datalogic Product is used, with U.S. export control laws, and with the English
language version of this Agreement. The provisions of the "United Nations
Convention on International Sale of Goods" shall not apply to this Agreement.
10. Termination
10.1Either party may terminate this Agreement or any license granted under this
Agreement at any time upon written notice if the other party breaches any
provision of this Agreement.
10.2Upon termination of this Agreement, End User immediately shall cease using
any nonembedded software and shall return to Datalogic or destroy all nonembedded software covered by this Agreement, and shall furnish Datalogic
with a certificate of compliance with this provision signed by an officer or
authorized representative of End User. For embedded software, End User
agrees to sign a waiver prepared by Datalogic concerning further use of the
embedded Software. End User's resumed or continued use of the embedded
Software after termination shall constitute End User's agreement to be bound
by the terms and conditions of this Agreement for such use.
Quick Reference Guide v
11. General Provisions
11.1 Entire Agreement; Amendment. This document contains the entire agreement between the parties relating to the licensing of the Software and supersedes all prior or contemporaneous agreements, written or oral, between the
parties concerning the licensing of the Software. This Agreement may not be
changed, amended, or modified except by written document signed by Datalogic.
11.2 Notice. All notices required or authorized under this Agreement shall be given
in writing, and shall be effective when received, with evidence of receipt.
Notices to Datalogic shall be sent to the attention of Datalogic IP Tech S.r.l.,
Legal & IP Department, Via San Vitalino 13, 40012 Calderara di Reno (Bologna),
Italy or such other address as may be specified by Datalogic in writing.
11.3 Waiver. A party's failure to enforce any of the terms and conditions of this
Agreement shall not prevent the party's later enforcement of such terms and
conditions.
11.4 Governing Law; Venue: Both parties agree to the application of the laws of the
country in which End User obtained the license to govern, interpret, and
enforce all of End User’s and Datalogic’s respective rights, duties, and obligations arising from, or relating in any manner to, the subject matter of this
Agreement, without regard to conflict of law principles. The United Nations
Convention on Contracts for the International Sale of Goods does not apply.
All rights, duties, and obligations are subject to the courts of the country in
which End User obtained the license. For licenses granted by Licensee who
operates in the countries specified below, the following terms applies.
For Americas.
This Agreement is governed by the laws of the State of Oregon. This Agreement and the rights of the parties hereunder shall be governed by and construed in accordance with the laws of the State of Oregon U.S.A, without
regard to the rules governing conflicts of law. The state or federal courts of the
State of Oregon located in either Multnomah or Lane counties shall have
exclusive jurisdiction over all matters regarding this Agreement, except that
Datalogic shall have the right, at its absolute discretion, to initiate proceedings
in the courts of any other state, country, or territory in which End User resides,
or in which any of End User's assets are located. In the event an action is
brought to enforce the terms and conditions of this Agreement, the prevailing
party shall be entitled to reasonable attorneys’ fees, both at trial and on
appeal.
For Europe, Middle East and Africa
This Agreement is governed by the laws of Italy. This Agreement and the
rights of the parties hereunder shall be governed by and construed in accordance with the laws of Italy, without regard to the rules governing conflicts of
law. Italian Court of Bologna shall have exclusive jurisdiction over all matters
regarding this Agreement, except that Datalogic shall have the right, at its
absolute discretion, to initiate proceedings in the courts of any other state,
country, or territory in which End User resides, or in which any of End User's
assets are located. In the event an action is brought to enforce the terms and
conditions of this Agreement, the prevailing party shall be entitled to reasonable attorneys’ fees, both at trial and on appeal.
For Asia- Pacific Countries
This Agreement is governed by the laws of the State of Hong Kong. This
Agreement and the rights of the parties hereunder shall be governed by and
construed in accordance with the laws of the State of Hong Kong without
regard to the rules governing conflicts of law. The Court of Hong Kong shall
have exclusive jurisdiction over all matters regarding this Agreement, except
that Datalogic shall have the right, at its absolute discretion, to initiate proceedings in the courts of any other state, country, or territory in which End
User resides, or in which any of End User's assets are located. In the event an
action is brought to enforce the terms and conditions of this Agreement, the
prevailing party shall be entitled to reasonable attorneys’ fees, both at trial
and on appeal.
11.5 Attorneys' Fees. In the event an action is brought to enforce the terms and
conditions of this Agreement, the prevailing party shall be entitled to reasonable attorneys' fees, both at trial and on appeal.
- END -
vi PowerScan™ PD9530
Software Product Policy
Software Product Policy
Datalogic reserves the right to ship its products with the
latest version of software/firmware available. This provides our customers with the very latest in Datalogic software technology.
The only exception to this policy is when the buyer has a
signed contract with Datalogic that clearly defines the
terms and conditions for making software/firmware
changes in products shipped to the buyer.
To arrange for a Software Maintenance and Support
Agreement please contact your Datalogic sales person.
Quick Reference Guide vii
Software Product Policy
NOTES
viii PowerScan™ PD9530
PowerScan™ PD9530
Description
The PowerScan™ 9530 is a feature-rich and rugged area
imager reader. It is offered in several different models to
better fit the different needs of each customer.
The table below shows the unique features of each model:
Model P/N Optical feature
PD9530 Standard optic, standard and low density codes
PD9530-HP
PD9530-HPE
PD9530-DPM
General Features
Omni-directional
Operating
Decoding
Formatting and
Concatenating
Autofocus optic, High, standard and low density
codes, wide angle
Autofocus optic, High, standard and low density
codes, wide angle
High Density optic, high and medium density
codes, DPM (laser, ink jet and dot peen)
To read a symbol or capture an image, you
simply aim the reader and pull the trigger.
Since the PowerScan™ PD9530 is a powerful
omni-directional reader, the orientation of the
symbol is not important.
Thanks to powerful algorithms, PowerScan™
PD9530 reliably decodes all major 1D (linear)
barcodes, 2D stacked codes (such as PDF417),
2D matrix symbols (such as DataMatrix), postal
codes (such as POSTNET, PLANET). The data
stream — acquired from decoding a symbol —
is rapidly sent to the host. The reader is immediately available to read another symbol.
The string of a decoded code may be processed according to either a simple or
advanced data formatting and be concatenated.
Quick Reference Guide 1
Setting Up the Reader
PowerScan™ PD9530 can also function as a
Imaging
Autoscanning
Flash Memory
USA Driver License
Parsing
camera by capturing entire images or image
portions of labels, signatures, and other
items.
An autoscan command causes the reader to
scan continuously and to monitor the central
zone of its reading area.
Flash technology allows you to upgrade the
PowerScan™ PD9530 reader as new symbologies are supported or as improved decoding
algorithms become available.
The reader can be set up to select and output
a subset of data elements from USA Driver
License PDF417 barcodes. This feature can be
enabled using either Datalogic Aladdin™ or
the barcodes in the USA Driver License Parsing Quick Reference Guide (QRG), available on
the Datalogic website.
Setting Up the Reader
Follow the steps below to connect and get your reader up
and communicating with its host.
1. Connect the Cable to the reader and the Host,
shown on page 3.
2. Configure the Interface (see page 5).
3. Configure the Reader starting on page 15
(optional, depends on settings needed)
Connect the PowerScan by plugging directly into the host
device as shown. The power can also be supplied through
an external power supply via the Interface Cable supplied
with a power jack.
2 PowerScan™ PD9530
Setting Up the Reader
A
B
C
D
FRONT>>
1
2
3
6
4
5
7
Connecting the Cable
A. Rubber gasket
B. Cable Holder
C. Cover
D. Connector Holder
1. Slip the cable through
the Cover.
2. Push the Rubber Gasket onto the Cable
Holder.
3. Push the Cable Holder
and gasket into the
handle. Ensure that
the “Front” marking
on the Cable Holder is
facing out, with the
arrow pointing
towards the front of
the scanner.
4. Insert the end of the
5. Push the Cover along
6. Insert the cable
7. Insert and tighten the
Quick Reference Guide 3
cable into the socket
of the Cable Holder.
the cable towards the
reader, and hook it
over the yellow
“tooth” on the back of
the handle.
through the Connector
Holder, and push it up
into the Cover.
screw to affix the
cable assembly to the
reader handle.
Using the PowerScan™ PD9530
Using the PowerScan™ PD9530
The PowerScan™ PD9530 normally functions by capturing
and decoding bar codes. The reader is equipped with an
internal Motionix™ motion-sensing function which activates the aiming system on device motion. The intelligent
aiming system indicates the field of view which should be
positioned over the bar code:
Table 1. Aiming System
Model P/N Aimer pattern
PD9530 /
PD9530-DPM
PD9530-HP /
PD9530-HPE
The field of view indicated by the aiming system will be
smaller when the reader is closer to the bar code and
larger when it is farther from the code. Symbologies with
smaller bars or elements (mil size) should be read closer
to the unit. Symbologies with larger bars or elements (mil
size) should be read farther from the unit.
If the entire bar code is within the aiming field, you will get
a good read. Successful reading is signaled by an audible
tone plus a good-read green spot LED indicator.
Reference the PowerScan PD9530 Product Reference
Guide (PRG) for more information about this feature and
other programmable settings.
4 PowerScan™ PD9530
Selecting the Interface Type
Selecting the Interface Type
Upon completing the physical connection between the
reader and its host, proceed directly to Interface Selection
below for information and programming for the interface
type the reader is connected to (for example: RS-232, Keyboard Wedge, USB, etc.) and scan the appropriate bar code
to select your system’s correct interface type.
Interface Selection
All models are multi-interface and support RS-232, USB
and Keyboard Wedge.
Information and programming options for each interface
type are provided in this section. For defaults and additional information associated with each interface, proceed
to the corresponding chapter in the PowerScan PD9530
PRG.
Configuring the Interface
Scan the appropriate programming bar code to selects the
interface type for your system.
Unlike some other programming features and
options, interface selections require that you
scan only one programming bar code label. DO
NOT scan an ENTER/EXIT bar code prior to
NOTE
scanning an interface selection bar code.
Some interfaces require the scanner to start in
the disabled state when powered up. If additional scanner configuration is desired while in
this state, pull the trigger and hold for 5 seconds. The scanner will change to a state that
allows programming with bar codes.
Quick Reference Guide 5
Selecting the Interface Type
RS-232
RS-232 standard interface
RS-232 Wincor-Nixdorf
RS-232 for use with OPOS/UPOS/JavaPOS
RS-232
RS232-WN
RS-232 OPOS
USB
USB Com to simulate RS-232 standard interface
USB-COM
6 PowerScan™ PD9530
a
Selecting the Interface Type
USB (continued)
USB-OEM
(can be used for OPOS/UPOS/JavaPOS)
USB-OEM
a. Download the correct USB Com driver from www.datalogic.com
USB Keyboard with standard key encoding
USB-KBD
USB Keyboard with alternate key encoding
USB-KBD-ALT
USB Keyboard for Apple computers
USB-KBD-APPLE
Quick Reference Guide 7
Selecting the Interface Type
Keyboard Interface
KEYBOARD WEDGE
IBM AT or PS/2 PCs
Standard Key Encoding
KBD-AT
IBM AT or PS/2 PCs
Standard Key Encoding without external keyboard
KBD-AT-NK
IBM AT or PS/2 PCs
w/Alternate Key
KBD-AT-ALT
IBM AT or PS/2 PCs
Alternate Key Encoding without external keyboard
KBD-AT-ALT-NK
Scancode Tables
Reference the PowerScan PD9530 PRG for information
about control character emulation for keyboard interfaces.
8 PowerScan™ PD9530
Selecting the Interface Type
Country Mode
This feature specifies the country/language supported by
the keyboard. This option is usable only with USB-KBD
and Keyboard Wedge interface without the "Alternate
Key" mode.
COUNTRY MODE
ENTER/EXIT PROGRAMMING MODE
Country Mode = U.S.
Country Mode = Belgium
Country Mode = Britain
Country Mode = Croatia*
*
Supports only the interfaces listed in the Country Mode feature description
Quick Reference Guide 9
Selecting the Interface Type
$CKBCO13(CR)
COUNTRY MODE (continued)
Country Mode = Czech*
Country Mode = Denmark*
Country Mode = France
Country Mode = French Canadian*
Country Mode = Germany
Country Mode = Hungary*
*
Supports only the interfaces listed in the Country Mode feature description
10 PowerScan™ PD9530
COUNTRY MODE (continued)
Country Mode = Italy
Country Mode = Japanese 106-key*
Country Mode = Lithuanian*
Selecting the Interface Type
Country Mode = Norway*
Country Mode = Poland*
Country Mode = Portugal*
*
Supports only the interfaces listed in the Country Mode feature description
Quick Reference Guide 11
Selecting the Interface Type
COUNTRY MODE (continued)
Country Mode = Romania*
Country Mode = Spain
Country Mode = Sweden
Country Mode = Slovakia*
Country Mode = Switzerland*
*Supports only the interfaces listed in the Country Mode feature
description
12 PowerScan™ PD9530
Selecting the Interface Type
Caps Lock State
This option specifies the format in which the reader sends
character data. This applies to keyboard wedge interfaces.
This does not apply when an alternate key encoding keyboard is selected.
ENTER/EXIT PROGRAMMING MODE
Caps Lock State = Caps Lock OFF
Caps Lock State = Caps Lock ON
Caps Lock State = AUTO Caps Lock Enable
Quick Reference Guide 13
Programming
Numlock
This option specifies the setting of the Numbers Lock
(Numlock) key while in keyboard wedge interface. This
only applies to alternate key encoding interfaces. It does
not apply to USB keyboard.
ENTER/EXIT PROGRAMMING MODE
Numlock = Numlock key unchanged
Numlock = Numlock key toggled
Programming
The reader is factory-configured with a set of standard
default features. After scanning the interface bar code
from the Interfaces section, select other options and customize your reader through use of the programming bar
codes available in the PowerScan PD9530. Check the corresponding features section for your interface, and also
the Data Editing and Symbologies chapters of the PRG.
Using Programming Bar Codes
This manual contains bar codes which allow you to reconfigure your reader. Some programming bar code labels,
14 PowerScan™ PD9530
Programming
Reset Default Settings
like the "Reset Default Settings" on page 15, require only
the scan of that single label to enact the change.
Other bar codes require the reader to be placed in Programming Mode prior to scanning them. Scan an ENTER/
EXIT bar code once to enter Programming Mode; scan the
desired parameter settings; scan the ENTER/EXIT bar
code again to accept your changes, which exits Programming Mode and returns the reader to normal operation.
Configure Other Settings
Additional programming bar codes are available in the
PRG to allow for customizing programming features. If
your installation requires different programming than the
standard factory default settings, refer to the PRG.
Resetting Product Defaults
If you aren’t sure what programming options are in your
reader, or you’ve changed some options and want your
custom factory settings restored, scan the bar code below
to reset the reader to its initial configuration. Reference
the PRG for other options, and a listing of standard factory
settings.
Factory defaults are based on the interface
type. Be sure your reader is configured for the
correct interface before scanning this label.
See "Selecting the Interface Type" on page 5
NOTE
for more information.
Quick Reference Guide 15
Reading Parameters
Reading Parameters
Move the reader toward the target and center the aiming
pattern and illumination system to capture and decode
the image. See Using the PowerScan™ PD9530 on page 4
for more information.
The aiming system will briefly switch off after the acquisition time, and if no code is decoded will switch on again
before the next acquisition. The illuminator will remain on
until the symbol is decoded.
As you read code symbols, adjust the distance at which
you are holding the reader.
Good Read Green Spot Duration
Successful reading can be signaled by a good read green
spot. Use the bar codes that follow to specify the duration
of the good read pointer beam after a good read.
ENTER/EXIT PROGRAMMING MODE
Disabled
Medium (500 ms)
16 PowerScan™ PD9530
Short (300 ms)
Long (800 ms)
Operating Modes
Operating Modes
Scan Mode
The imager can be set to operate in one of several scanning modes. See the PRG for more information and settings for any of the options:
Trigger Single (Default) —
cal handheld reader operation. Motion Sense is active and
if the scanner detects motion the aiming pattern is turned
on. When the trigger is pulled, illumination is turned on
and the scanner attempts to read a label. Scanning is activated until one of the following occurs:
• the programmable “maximum scan on time”
has elapsed
• a label has been read
• the trigger is released
Trigger Pulse Multiple —
is pulled and continues after the trigger is released, until
the trigger is pulled again or until the programmable
“maximum scan on time”
does not disable scanning. Double Read Timeout
vents undesired multiple reads while in this mode.
Trigger Hold Multiple —
ning starts and the product scans until the trigger is
released or “maximum scan on time”
ing a label does not disable scanning. Double Read Time-
1
out
prevents undesired multiple reads in this mode.
Always On —
The illuminator is always ON and the reader
is always ready for code reading. Double Read Timeout
prevents undesired multiple reads.
Flashing —
The reader illuminator flashes on and off
regardless of the trigger status. Code reading takes place
only during the Flash On
prevents undesired multiple reads.
Stand Mode —
The scanner looks for changes within its
field-of-view. The Aiming Pattern is always on to show
the optimum reading area. If a predefined amount of
movement is detected, the red illumination switches on.
Scanning continues until a label is read or "maximum scan
on time" is reached.
1. See the Product Reference Guide (PRG) for these an d other programmable
features
2. Controlled by Flash On Time and Flash Off Time. Use the PRG to program these
options.
This mode is associated with typi-
Scanning begins when the trigger
1
has elapsed. Reading a label
1
pre-
When the trigger is pulled, scan-
1
has elapsed. Read-
2
time. Double Read Timeout1
1
1
Quick Reference Guide 17
Operating Modes
Scan Mode (continued)
ENTER/EXIT PROGRAMMING MODE
Scan Mode = Trigger Single
Scan Mode = Trigger Hold Mul-
Scan Mode = Always On
tiple
Scan Mode = Trigger Pulse
Multiple
Scan Mode = Flashing
Scan Mode = Stand Mode
Motion Aiming Control
This feature configures the ability of the scanner to
Enable/Disable the Aiming system when motion is
detected (Motionix™ motion-sensing technology). Scan
the Enter/Exit Programming bar code above, then either
of the barcodes below.
Motion Aiming Control =
Enable
18 PowerScan™ PD9530
Motion Aiming Control = Dis-
able
Operating Modes
Pick Mode
Specifies the ability of the reader to decode labels only
when they are close to the center of the aiming pattern.
Pick Mode is a Decoding and Transmission process where
bar codes that are not within the configurable distance
from the center of the aiming pattern are not acknowledged or transmitted to the host. It is active only while the
scanner is in Trigger Single mode. If the scanner switches
to a different Read Mode, Pick Mode is automatically disabled.
This feature is not compatible with Multiple
Labels Reading in a Volume. See the PRG for
more information.
NOTE
ENTER/EXIT PROGRAMMING MODE
PIck Mode = Disable
Pick Mode = Enable
Multiple Label Reading
The reader offers a number of options for multiple label
reading. See the PRG or software configuration tool for
descriptions of these features and programming labels.
Quick Reference Guide 19
Technical Specifications
Technical Specifications
The following table contains Physical and Performance
Characteristics, User Environment and Regulatory information.
Item Description
Physical Characteristics
Height: 212 mm
Dimensions
Length: 110 mm
Width: 74 mm
Weight (without
cable)
Electrical Characteristics
Voltage & Current
Input Voltage
Input Current
Operating (typi-
Operating (max): 475mA
Idle/Standby
(typical)
330 gr (without cable)
PD9530/
PD9530HP
5 VDC +/-
5%
335mA
cal):
180mA 60mA @ 10V 120mA
PD9530HPE
10 to 30 VDC 5 VDC +/-5%
135mA @
10V
300mA @
10V
PD9530DPM
350mA
480mA
20 PowerScan™ PD9530
Performance Characteristics
Light Source LED
Roll (Tilt) Tolerance ± 180°
Pitch Tolerance ± 40°
Technical Specifications
Skew (Yaw) Tolerance
Print Contrast
Minimum
Resolution
Depth of Field (Typical)
Symbology
Code 39
EAN 13 13 mils: 4-48 cm 13 mils: 3-60 cm
PDF-417 10 mils: 2-25 cm 10 mils: 2-30 cm
± 40°
15% minimum
reflectance
PD9530
Max resolution 1D 4
mils
Max resolution 2D
7.5 mils
a
Standard
Model:
4 mils: 6-17 cm
20 mils: 4-55 cm
40 mils: 4-85 cm
PD9530-HP /
PD9530-HPE
1D 2.5 mil
2D 4 mil
High
Performance:
2.5 mils: 2-6 cm
20 mils: 3-70 cm
40 mils: 3-110 cm
DataMatrix
a. 13 mils DOF based on EAN. All other 1D codes are Code 39. All labels grade A,300 lux ambient light, 20°C,
label inclination 10°
Quick Reference Guide 21
7.5 mils: 7-14 cm
10 mils: 4-18 cm
4mil: 2-6 cm
10mil: 2-20 cm
Technical Specifications
Decode Capability
1D Bar Codes
GS1 Databar linear codes, UPC/EAN (A,E,13,8), UPC/EAN with P2/
P5 Addons, UPC/EAN Coupons, ISBN, Code128, EAN128, ISBT128,
Code39, Code39 Full ASCII, Code39 CIP, Code 32, Codabar, Interleaved 2 of 5, IATA, Industrial 2 of 5, Standard 2 of 5, Code11, MSI,
Plessey, Code 93, Follet 2/5
2D / Stacked Codes
DataMatrix, MaxiCode and QR Codes(QR, Micro QR and Multiple
QR codes), Aztec
- Postal codes including:
Australian Post, China Post, Japanese Post, KIX Post, Planet Code,
Postnet, Royal Mail Code(RM45CC), IMB
- stacked codes including EAN/JAN Composites; GS1 Databar
Composites, GS1 Databar Expanded Stacked; GS1 DataBar
Stacked; GS1 DataBar Stacked Omnidirectional; MacroPDF; Micro
PDF417; PDF417; UPC A/E Composites, French CIP13, Grid
Matrix(Chinese) code
RS-232, Keyboard Wedge, and USB.
Interfaces Supported
See page 5 for a listing of available interface options.
User Environment
Operating Temperature
-4° to 122° F (-20° - +50° C )
Storage Temperature -40° to 158° F (-40° to 70° C)
Humidity 0 to 95% non-condensing
Drop Specifications
Ambient Light
Immunity
Scanner withstands >50 times 6.5' (2 m)
drops to concrete
100,000 Lux
Contaminants:
Spray/rain,
IP65
Dust/particulates
ESD Level 20 KV
22 PowerScan™ PD9530
Beeper/Speaker >= 80 dB @ 10 cm
Regulatory
LED and Beeper Indications
Electrical Safety
EMI/RFI
Laser Class Safety
UL 60950, CSA C22.2 No. 60950, IEC 60950
North America (FCC) : Part 15 Class B; Canada ( IC) : ICES003 Class B; Russia ( Gost); European Union EMC Direct ive;
VCCI-Japan; Korean KCC; Taiwan EMC (BSMI); Australia
(ACMA); Mexico (NOM Nyce)
IEC Class 2
Radiation 1 mW Avg., Emitted wavelength 650 nm, 12ms
pulse, Beam Divergence 8.4 deg x 8.1 deg (“plus” pattern)
LED and Beeper Indications
The reader’s beeper sounds and its LED illuminates to
indicate various functions or errors on the reader. An
optional “Green Spot” also performs useful functions. The
following tables list these indications. One exception to
the behaviors listed in the tables is that the reader’s functions are programmable, and so may or may not be turned
on. For example, certain indications such as the power-up
beep can be disabled using programming bar code labels.
Indicator Description LED Beeper
Reader beeps
four times at
highest frequency and volume upon
power-up.
The reader will
beep once at
current frequency, volume,
mono/bi-tonal
setting and
duration upon a
successful label
scan.
Power-up
Beep
Good Read
Beep
The reader is in
the process of
powering-up.
A label has been
successfully
scanned by the
reader.
N/A
LED behavior
for this indication is configurable via the
feature “Good
Read: When to
Indicate”
(see the PRG for
information.)
Quick Reference Guide 23
LED and Beeper Indications
Indicator Description LED Beeper
a
Reader sounds
one error beep
at highest volume.
Reader 'chirps'
six times at the
highest frequency and current volume.
N/A
N/A
ROM Failure
Limited Scanning Label
Read
Reader Active
Mode
Reader
Disabled
There is an error
in the reader's
software/programming
Indicates that a
host connection
is not established.
The reader is
active and ready
to scan.
The reader has
been disabled by
the host.
Flashes
N/A
The LED is lit
steadily
The LED blinks
continuously
Upon successful read of a
label, the soft-
a
Green Spot
flashes
momentarily
ware shall turn
the green spot
on for the time
N/A N/A
specified by the
configured
value.
Image Capture
a
Except when in sleep mode or when a Good Read LED Duration
When ready to
capture image
Blue light
flashes 2 times
when updating
N/A
other than 00 is selected
24 PowerScan™ PD9530
LED and Beeper Indications
Programming Mode
when the reader is in Programming Mode
-
The following indications ONLY occur
.
INDICATION DESCRIPTION LED BEEPER
Label Programming
Mode Entry
A valid programming label has
been scanned.
LED blinks
continuously
Reader sounds
four low frequency beeps.
Reader sounds
Label Programming
Mode Rejection of Label
A label has been
rejected.
N/A
three times at
lowest fre-
quency and
current vol-
ume.
In cases where
Label Programming
Mode Acceptance of Partial Label
multiple labels
must be scanned
to program one
feature, this indication acknowledges
each portion as it is
successfully
N/A
Reader sounds
one short beep
at highest fre-
quency and
current vol-
ume.
scanned.
Label Programming
Mode Acceptance of Programming
Label Programming
Mode Cancel
Item Entry
Configuration
option(s) have been
successfully programmed via labels
and the reader has
exited Programming Mode.
Cancel label has
been scanned.
N/A
N/A
Reader sounds
one high fre-
quency beep
and 4 low fre-
quency beeps
followed by
reset beeps.
Reader sounds
two times at
low frequency
and current
volume.
Quick Reference Guide 25
Error Codes
Error Codes
Upon startup, if the reader sounds a long tone, this means
the reader has not passed its automatic Selftest and has
entered FRU (Field Replaceable Unit) isolation mode. If the
reader is reset, the sequence will be repeated. Press and
release the trigger to hear the FRU indication code.
The following table describes the LED flashes/beep codes
associated with an error found.
Number
of LED
Flashes/
Beeps
1 Configuration
Error
Corrective
Action
2 Interface PCB
6 Digital PCB
11 Imager
Contact Helpdesk for
assistance
26 PowerScan™ PD9530
Cleaning
Cleaning
Exterior surfaces and scan windows exposed to spills,
smudges or debris require periodic cleaning to ensure
best performance during scanning.
Use a soft, dry cloth to clean the product. If the product is
very soiled, clean it with a soft cloth moistened with a
diluted non-aggressive cleaning solution or diluted ethyl
alcohol.
Do not use abrasive or aggressive cleansing
agents or abrasive pads to clean scan windows or plastics.
CAUTION
Quick Reference Guide 27
Do not spray or pour liquids directly onto the
unit.
Datalogic ADC Limited Factory Warranty
Datalogic ADC Limited Factory
Warranty
Warranty Coverage
Datalogic warrants to Customer that Datalogic's products will be
free from defects in materials and workmanship for a period of
one year from product shipment. Datalogic (“Datalogic”) hardware products are warranted against defects in material and
workmanship under normal and proper use. The liability of Datalogic under this warranty is limited to furnishing the labor and
parts necessary to remedy any defect covered by this warranty
and restore the product to its normal operating condition. Repair
or replacement of product during the warranty does not extend
the original warranty term. Products are sold on the basis of
specifications applicable at the time of manufacture and Datalogic has no obligation to modify or update products once sold.
If Datalogic determines that a product has defects in material or
workmanship, Datalogic shall, at its sole option repair or replace
the product without additional charge for parts and labor, or credit or refund the defective products duly returned to Datalogic. To
perform repairs, Datalogic may use new or reconditioned parts,
components, subassemblies or products that have been tested
as meeting applicable specifications for equivalent new material
and products. Customer will allow Datalogic to scrap all parts removed from the repaired product. The warranty period shall extend from the date of shipment from Datalogic for the duration
published by Datalogic for the product at the time of purchase
(Warranty period). Datalogic warrants repaired hardware devices
against defects in workmanship and materials on the repaired
assembly for a 90 day period starting from the date of shipment
of the repaired product from Datalogic or until the expiration of
the original warranty period, whichever is longer. Datalogic does
not guarantee, and it is not responsible for, the maintenance of,
damage to, or loss of configurations, data, and applications on the
repaired units and at its sole discretion can return the units in the
“factory default” configuration or with any software or firmware
update available at the time of the repair (other than the firmware or software installed during the manufacture of the product). Customer accepts responsibility to maintain a back up copy
of its software and data.
Warranty Claims Process
In order to obtain service under the Factory Warranty, Customer
must notify Datalogic of the claimed defect before the expiration
of the applicable Warranty period and obtain from Datalogic a return authorization number (RMA) for return of the product to a
designated Datalogic service center. If Datalogic determines Customer’s claim is valid, Datalogic will repair or replace product
without additional charge for parts and labor. Customer shall be
responsible for packaging and shipping the product to the designated Datalogic service center, with shipping charges prepaid.
Datalogic shall pay for the return of the product to Customer if
the shipment is to a location within the country in which the Da-
28 PowerScan™ PD9530
Datalogic ADC Limited Factory Warranty
talogic service center is located. Customer shall be responsible
for paying all shipping charges, duties, taxes, and any other
charges for products returned to any other locations. Failure to
follow the applicable RMA policy, may result in a processing fee.
Customer shall be responsible for return shipment expenses for
products which Datalogic, at its sole discretion, determines are
not defective or eligible for warranty repair.
Warranty Exclusions
The Datalogic Factory Warranty shall not apply to:
(i) any product which has been damaged, modified, altered,
repaired or upgraded by other than Datalogic service personnel or its authorized representatives;
(ii) any claimed defect, failure or damage which Datalogic
determines was caused by faulty operations, improper
use, abuse, misuse, wear and tear, negligence, improper
storage or use of parts or accessories not approved or
supplied by Datalogic;
(iii) any claimed defect or damage caused by the use of prod-
uct with any other instrument, equipment or apparatus;
(iv) any claimed defect or damage caused by the failure to
provide proper maintenance, including but not limited to
cleaning the upper window in accordance with product
manual;
(v) any defect or damage caused by natural or man-made
disaster such as but not limited to fire, water damage,
floods, other natural disasters, vandalism or abusive
events that would cause internal and external component damage or destruction of the whole unit, consumable items;
(vi) any damage or malfunctioning caused by non-restoring
action as for example firmware or software upgrades,
software or hardware reconfigurations etc.;
(vii) the replacement of upper window/cartridge due to
scratching, stains or other degradation and/or
(viii) any consumable or equivalent (e.g., cables, power supply,
batteries, keypads, touch screen, triggers etc.).
No Assignment
Customer may not assign or otherwise transfer its rights or obligations under this warranty except to a purchaser or transferee
of product. No attempted assignment or transfer in violation of
this provision shall be valid or binding upon Datalogic.
DATALOGIC'S LIMITED WARRANTY IS IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, ORAL OR WRITTEN, STATUTORY OR OTHERWISE, INCLUDING, WITHOUT LIMITATION, ANY
IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE, OR NONINFRINGEMENT. DATALOGIC
SHALL NOT BE LIABLE FOR ANY DAMAGES SUSTAINED BY CUSTOMER ARISING FROM DELAYS IN THE REPLACEMENT OR REPAIR OF PRODUCTS UNDER THE ABOVE. THE REMEDY SET
FORTH IN THIS WARRANTY STATEMENT IS THE CUSTOMER’S
Quick Reference Guide 29
Ergonomic Recommendations
SOLE AND EXCLUSIVE REMEDY FOR WARRANTY CLAIMS. UNDER
NO CIRCUMSTANCES WILL DATALOGIC BE LIABLE TO CUSTOMER
OR ANY THIRD PARTY FOR ANY LOST PROFITS, OR ANY INCIDENTAL, CONSEQUENTIAL IN-DIRECT, SPECIAL OR CONTINGENT
DAMAGES REGARDLESS OF WHETHER DATALOGIC HAD ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.
Risk of Loss
Customer shall bear risk of loss or damage for product in transit
to Datalogic. Datalogic shall assume risk of loss or damage for
product in Datalogic’s possession. In the absence of specific written instructions for the return of product to Customer, Datalogic
will select the carrier, but Datalogic shall not thereby assume any
liability in connection with the return shipment.
Ergonomic Recommendations
In order to avoid or minimize the potential risk
of ergonomic injury follow the recommenda-
CAUTION
tions below. Consult with your local Health &
Safety Manager to ensure that you are adhering to your company’s safety programs to prevent employee injury.
• Reduce or eliminate repetitive motion
• Maintain a natural position
• Reduce or eliminate excessive force
• Keep objects that are used frequently within easy
reach
• Perform tasks at correct heights
• Reduce or eliminate vibration
• Reduce or eliminate direct pressure
• Provide adjustable workstations
• Provide adequate clearance
• Provide a suitable working environment
• Improve work procedures.
30 PowerScan™ PD9530
Services and Support
Services and Support
Datalogic provides several services as well as technical support through its website. Log on to
click on the links indicated for further information.
Products
Search through the links to arrive at your product page where
you can download specific
including:
• Datalogic Aladdin™, a multi-platform utility program
that allows device configuration using a PC. It provides RS-232 interface configuration as well as
configuration bar code printing.
Service & Support
• Technical Support - Product documentation and
programming guides and Technical Support
Department in the world
• Service Programs - Warranty Extensions and Main-
tenance Agreements
• Repair Services - Flat Rate Repairs and Return
Material Authorization (RMA) Repairs
• Downloads – Manuals & Documentation, Data
Sheets, Product Catalogues, etc.
www.datalogic.com and
Manuals and Software & Utilities,
Contact Us
• Information Request Form and Sales & Service
Network
Quick Reference Guide 31
Services and Support
NOTES
32 PowerScan™ PD9530
NOTES
Services and Support
Quick Reference Guide 33
www.datalogic.com
©2013-2016 Datalogic ADC Inc.• All rights reserved.
Datalogic and the Datalogic logo are registered trademarks
of Datalogic S.p.A. in many countries, including the U.S.A.
and the E.U. PowerScan is a registered trademark of
Datalogic ADC Inc. in many countries, including the U.S.A.
and the E.U.
Datalogic ADC Inc.
959 Terry Street | Eugene |OR 97402 | USA
Telephone: (1) 541-683-5700
820077714 (Rev C) January 2016
|
Fax: (1) 541-345-7140
