Dash DAP001 User Manual

unprocess your food

rapidpeeler.com

rapid

peeler

instruction manual & recipe guide

MODEL DAP001

PAGE TITLE

TABLE OF CONTENTS

DASH GO RAPID PEELER

Important Safeguards .......................................... 4-5

Parts & Features ................................................. 6-7

Using Your Rapid Peeler....................................... 8-9

Changing the Peeler Blades ............................. 10-11

Maintenance ....................................................... 12

Operating Your Peeler ...................................... 13-14

Recipes .......................................................... 15-29

Customer Support ................................................ 30

Warranty .............................................................. 31

2 3

IMPORTANT SAFEGUARDSIMPORTANT SAFEGUARDS

PLEASE READ AND SAVE THIS INSTRUCTION AND CARE MANUAL

When using electrical appliances, basic safety precautions should be followed, including:

• Read all instructions.

• Remove all bags and packaging from

appliance before use.

• Make sure the appliance is thoroughly

cleaned before using.

• This appliance is not intended for use

by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge unless they are provided with supervision and instruction concerning use of the appliance by a person responsible for their safety.

• This appliance is intended for

household use only.

• Avoid contact with moving parts.

To reduce the risk of injury to persons and/or damage to the appliance, do not put your hands, hair, clothing or other objects near the Peeler Blade during use.

• Do not use appliance outdoors or for

commercial purposes.

• Do not leave the appliance unattended

when in use.

• Always make sure the voltage used is

consistent with the nominal voltage of the Rapid Peeler.

• Do not remove any parts while

appliance is in use.

• When using any extension cords, make

sure the electrical rating of the wire is compatible with the Peeler.

• Do not operate any appliance with a

damaged cord or plug.

• If appliance malfunctions, discontinue

use until problem is resolved.

• Do not place appliance on or near a hot

gas burner, hot electric burner, or in a heated oven.

• Refrain from using attachments that are

not recommended by the appliance manufacturer, as this may result in re, electric shock or personal injury.

• Handle the Peeler Blades with care as

they are sharp and can cause injury.

• StoreBound shall not accept liability for

damages caused by improper use of the appliance.

• Do not use the appliance if any of the

parts are damaged.

• Improper use of the Rapid Peeler

can result in property damage or even in personal injury.

• Children should be supervised to

ensure that they do not play with the appliance.

• For maintenance other than cleaning,

please contact StoreBound directly at 1-800-898-6970 from 7AM – 7PM PST Monday – Friday or by email at support@storebound.com.

• Never immerse the Motor Base in water

or any other liquid; instead, wipe down with a damp cloth.

• All components included with the

Peeler are compatible with this product only. Do not use these parts on other similar products.

• Always be sure to turn off the appliance

prior to assembly, disassembly, cleaning and storage.

SAVE THESE INSTRUCTIONS

FCC CAUTION: Any changes or

modications not expressly approved by

the party responsible for compliance could void the user’s authority to operate this equipment.

FCC Warning Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

4 5

PARTS & FEATURESPARTS & FEATURES

1. Support Rod

2. Clamping Arm

3. Peeling Arm

4. Height Adjustment Lever

5. On/Off Button

6. Blade Release

7. Blade Holder

8. Rotating Prong

9. Motor Base

10. Blade Storage Compartment

11. Battery Compartment (Batteries not included )

12. Power Port

13. Power Adapter

14. Paring Tool

15. Peeler Blades

+ +

6 7

USING YOUR RAPID PEELERUSING YOUR RAPID PEELER

Clean the Rapid Peeler and all of its components prior to assembly and use. Do not touch the Peeler Blade as it is sharp and can cause injury.

1. Set the Rapid Peeler on a clean and stable surface.

Check that the On/Off Button is in the “Off” position. Insert 4 AA batteries into the Battery Compartment located at the bottom of the Peeler or connect the Power Adapter.

2. Center your fruit or vegetable on the Rotating Prong and

gently press down so that it remains rmly in place.

3. Lower the Clamping Arm onto the fruit or vegetable,

inserting the spike into the food just enough to lock it into place.

4. Using the Height Adjustment Lever, position the Peeling

Arm above the fruit. Do not touch the Peeler Blade as it is sharp and can cause injury.

5. Turn on the Rapid Peeler by pressing the On/Off

Button. Allow the Peeler to peel the skin into one clean, continuous curl. Once the Peeling Arm reaches the bottom of the fruit, the Rapid Peeler will automatically stop. When the Peeling Arm is lifted, the Peeler will re-start automatically. This saves time when making zucchini spaghetti or spiraling.

6. Lift up the Clamping Arm and remove your peeled fruit

or vegetable from the Rotating Prong.

ATTENTION: When the Peeling Arm is lifted, the Peeler will re-start automatically. To turn the Electric Peeler off completely, simply raise the Peeling Arm and press the On/Off button.

8 9

CHANGING THE PEELER BLADES CHANGING THE PEELER BLADES

The Peeler Blades are designed for clean and easy peeling. When the Blade skips, jams or becomes excessively clogged, it may be necessary to replace it with one of the included replacement blades.

1. Make sure the Rapid Peeler is turned off. Turn the Peeler upside

down and open the Blade Storage Compartment located in the Motor Base. Take out one of the extra Peeler Blades.

2. Remove the Blade Holder from the Peeling Arm by pinching

the Blade Release and sliding the Holder away from the Support Rod.

3. Detach the used Peeler Blade by sliding it, blade rst, off of the

Blade holder.

Note: Always make sure to turn off the Rapid Peeler prior to touching or removing the Peeler Blade. When handling the Blade, never touch the blade itself; instead hold it by the red base.

4. Lay the grey Blade Holder and the red Peeler Blade as shown.

The small hooks in the Blade Holder should point up.

5. Line up the new Peeler Blade with the ridges on the Blade

Holder, then slide the Blade onto the Holder until it rmly clicks

into place. Make sure the Blade is securely attached to the Blade Holder before proceeding.

6. To reattach the Blade Holder, slide it back into the slot at the

end of the Peeling Arm.

10 11
