Usermanual
4
Contents
02 CONTEnTS
03 INFORmaTION
04 FRONTPAnelOVErVIEW
04 RearPAnelOVErVIEW
06 GetTIngstarted/setUP
08 NetWOrk
09setTIngs
10InternetradiOpOrtal
12InternetradiOmode
15MUsiCplayermode
17FM/AUXSetTIngs
19SPecIFICatIOns
2
4
Information
Congratulationsonyournewradio.
Pleasetakeamomenttoreadthismanual.
Enjoy
Safetyinstructions
Pleasestorethisinstructionmanualforfuture reference.
•Placetheunitonasolidsurface
•DonotexposeScansonicR4tohigh humidity,directsunlight,dirt,heavyvibration orextremetemperatures.
•Donotopenthecabinet.Onlyqualified techniciansareallowedtocleanthis Scansonicradiosinternalparts.
•Ifserviceorrepairisrequired,thismustalso bedonebequalifiedtechnicians.
•Useadusteroraslightlydamp,softand non-fluffyragtocleanthecabinet.Donot usecorrosiveorstrongcleaningagents.
•Makesurenoliquidsormoisturepenetrates theradioduringthecleaning.Unplugthe radiobeforecleaningit.
Unplugtheradioinfollowingcases:
•Foreignobjectsorliquidshaspenetrated theradio
•Theradiocannotbeoperatedproperly.
•Thecabinethasbedamaged.
•Themainsplugorthemainscableis defective.
•Iftheradioisnottobeusedforalongtime.
Disclaimer
Despiteourbesteffortswecannotguaranteethatthetechnicaldataindicatedarecorrect,complete andupdated.We,Scansonic,reservetherighttomaketechnicalchangeswithoutnotice.
3
4
Front panel
02 |
03 |
04 |
05 |
06 |
07 |
08
09
01 |
14 |
13 |
12 |
11 |
10 |
Rear panel
15 16 17 18 19 20 21 22
4
4
01 Display |
OLeddisplayisshowingallinformationontheradio |
02 Speaker |
3”fullrangeloudspeaker |
03 Alarm |
alarmcontrolandsettings |
04 Snooze |
Presstosnooze5minutes |
05 Sleep |
sleeptimercontrolandsettings |
06 Mode |
PresstoselectInternet,MusicPlayer,FMradioorAUXinput |
07 Back |
Presstoentermainmenuorcomebacktoprevioussubmenu |
08 Preset1-3 |
Pressandholdforsettingstationaspreset1 |
09 Menu |
Gotoradiomenu |
10 Selectionknob |
Turnclockwisetoscrolltonextitem,turncounterclockwisetoscrollto |
|
previousitem.Pressbrieflytoconfirmselection.InFMmode,turnclock |
|
wisetotunedownandturncounterclockwisetotuneup.Pressand |
|
holdforautotune. |
11 Power/dimmer |
Pressandholdtoturnonorswitchoffradio.Todimthelightinthe |
|
displaypressbutton,thereare7steps. |
12 Info |
eachtimeyoupressInfo,anothersetofinformationisdisplayed,cyc |
|
lingthroughname/description,genre/location,reliability,codec/sampling |
|
rate,playbackbufferandtoday’sdate. |
13 Volume- |
Presstodecreasevolume |
14 Volume+ |
Presstoincreasethevolume |
15 Keylock |
kensingtonlocktopreventfromtheft |
16 Ethernetconnection |
ConnectEthernetcable(RJ45)tothisinputforwiredinternetconnection. |
17Auxin |
Connectastereoormonoaudiosource(likeiPod,MP3-player,TVor |
|
CD-player)tothisstereoinput.Use3,5mmjacktoconnectdevicesto |
|
theradio. |
18 Lineout |
Thisradiocanbeusedasaseparatestereotunerbyconnectingittoan |
|
stereoamplifier.Use3,5mmjacktoconnecttheradiotoamplifier |
19 Headphones |
Connectaseparatestereoheadsettothisinputtolistentotheradiowith |
|
headset.Insertingaheadsetwillturnoffthemainspeaker |
20 12vDC |
UsethisinputtotheScansonicR4DCpowersupply |
21Antenna |
Theradiocomeswithatelescopeantenna.ToimproveFMreception, |
|
adjusttheantennaforbestreception.Thetelescopeantennacanbe |
|
detachedwiththetoolincludedinthegiftboxsoacoaxialantennacable |
|
oroutdoorantennacanbeconnectedtothisconnector |
20 Porttube |
Bassreflexporttubeforbettersoundquality |
5
4
Getting started / setup
AlthoughtheScansonicR4issophisticated,gettingstartedissimple.ToplayFMradio,allyouneedisa
powersource(a100-240Vmainssupply).
ForMusicPlayermode,youneedeitheraUSBstickwithmusicfilesorawired/wirelessEthernet networkandaUPnPmusicserver(e.g.aPC).
ForInternet-connectedmodessuchasInternetradioorPandora,youalsoneedabroadbandInternet connection.
01 PlaceScansonicR4onasuitableshelfortableandplugitintoapoweroutlet.
02 Toreceivebroadcastradio(FM),extendthetelescopicantenna.
03 PressandholdStandbytopoweron.
SETUPWIZARD
WhenScansonicR4isstartedforthefirsttime,itrunsthroughasetupwizardtoconfiguresettingsfor date/timeandnetwork.Oncethishasfinished,thesystemisreadytouseinmostmodes.
Note:Tochangethesesettingslater,selectMenu>Systemsettings>.
Torunthesetupwizardagain,selectMenu>Systemsettings>
Setupwizard.
SelectYestostartthesetupwizard.
Note:Ifyouwanttouseawirednetwork,bypassthesetupwizard.
IfyouchooseNo,thenextscreenasksifyouwouldliketorunthe
wizardnexttimeScansonicR4isstarted.Thesystemthenstartswithoutconfiguringtime/dateand networksettingsandenterstheMainMenu.
Note:Ifpowerisremovedwhilethewizardisinprogress,thewizardwillrunagainnexttimeScansonic
R4isstarted.
12/24hourdisplay
Tochangebetween12and24hourdisplay,selectSet12/24hourandthenselectyourpreference.
6
