MAKING MODERN LIVING POSSIBLE
Electrical Installation
Series 90 Pump
3-Position (FNR) Electric Control
powersolutions.danfoss.com
Electrical Installation S90 3-Position (FNR) Electric Control
Revision history Table of revisions
Date Changed Rev
August 2015 Converted to Danfoss layout BA
April 2007 First edition AA
2 11023266 • Rev BA • August 2015
Electrical Installation S90 3-Position (FNR) Electric Control
Contents
Literature references
S90 Pump 3-Position (FNR) Electric Control literature references..................................................................................4
Latest version of technical literature.........................................................................................................................................4
Product overview
Product image................................................................................................................................................................................... 5
Nomenclature....................................................................................................................................................................................5
Theory of operation.........................................................................................................................................................................6
Pump displacement versus electrical signal..................................................................................................................... 6
Hydrostatic drive line power...................................................................................................................................................6
Hydraulic schematics...................................................................................................................................................................... 6
Electrical specifications.................................................................................................................................................................. 7
Electrical installation
Pinout....................................................................................................................................................................................................8
DIN 43650 connector.................................................................................................................................................................8
Pin compatibility...............................................................................................................................................................................8
S90 3-position FNR input/output matrix..................................................................................................................................8
Mating connector.............................................................................................................................................................................9
DIN 43650 connector parts list...............................................................................................................................................9
11023266 • Rev BA • August 2015 3
Electrical Installation S90 3-Position (FNR) Electric Control
Literature references
S90 Pump 3-Position (FNR) Electric Control literature references
Literature title Description Literature number
S90 Axial Pumps Technical Information Complete product electrical
PLUS+1® Compliant S90 FNR Control Function Block User
Manual
Latest version of technical literature
Danfoss product literature is online at: http://powersolutions.danfoss.com/literature/
and mechanical
specifications
Compliant function block
set-up information
520L0603
11022881
4 11023266 • Rev BA • August 2015
9 0
A R C M P J G N F L H T W Y Z K
Electrical Installation
Product overview
Product image
Nomenclature
S90 3-Position (FNR) Electric Control
S90 Pump 3-Position (FNR) Electric Control
M module - FNR control options
Option Description
DC 3-position (FNR) Electric Control, 12 Vdc
DD 3-position (FNR) Electric Control, 24 Vdc
Only certain control options for the Series 90 pump utilize the 3-position (FNR) Electric Control. Please
refer to the pump’s nomenclature to determine if the pump is equipped with the proper option. The
nomenclature can be found on the pump’s nametag.
11023266 • Rev BA • August 2015 5
"0"
Current mA
Displacement
100 %
100 %
W
M5 M4
T
P
X2 X1
Feedback from swashplate
Electrical Installation
Product overview
Theory of operation
S90 3-Position (FNR) Electric Control
The 3-position (FNR) Electric Control uses an electric input signal to switch the pump to a full stroke
position.
Pump displacement versus electrical signal
Hydraulic schematics
Hydrostatic drive line power
Warning
Unintended vehicle or machine movement hazard. The loss of hydrostatic drive line power, in any mode
of operation (forward, neutral, or reverse) may cause the system to lose hydrostatic braking capacity. You
must provide a braking system, redundant to the hydrostatic transmission, sufficient to stop and hold the
vehicle or machine in the event of hydrostatic drive power loss.
3-position electric control
6 11023266 • Rev BA • August 2015
Electrical Installation S90 3-Position (FNR) Electric Control
Product overview
Electrical specifications
S90 3-Position (FNR) electrical specifications
Voltage
Rated power
12V 24V
33 W 33 W
11023266 • Rev BA • August 2015 7
1 2
W
Electrical Installation S90 3-Position (FNR) Electric Control
Electrical installation
Pinout
DIN 43650 connector
Pin location
Pinout
Pin Function
1 PWM signal
2 Ground
Pinout (alternative)
Pin Function
1 Ground
2 PWM signal
Pin compatibility
PLUS+1® module pin type
Pin Function
1,2 DOUT
1,2 DOUT/PVG Power
1, 2 PWMOUT/DOUT/PVG Power supply
1, 2 PWMOUT/DOUT/PVGOUT
1, 2 Power ground
Warning
Unintended vehicle or machine movement hazard. Verify the wiring harness to ensure the correct PLUS
+1® pin is properly connected to each control pin.
S90 3-position FNR input/output matrix
Input shaft rotation
Signal at solenoid
Port A flow
Port B flow
Servo cylinder
Clockwise Counterclockwise
A B A B
Out In In Out
In Out Out In
M5 M4 M5 M4
8 11023266 • Rev BA • August 2015
Electrical Installation S90 3-Position (FNR) Electric Control
Electrical installation
Mating connector
DIN 43650 connector parts list
Description Quantity Ordering Number
DIN 43650 connector 1 Hirschmann 932 106-100
Mating connector kit 1 Danfoss K09129
11023266 • Rev BA • August 2015 9
