Danfoss 087H3241, ECL Comfort 110, Danfoss Link Installation Manual

Danfoss

87H1434.10

Application example · Applikationseksempel · Applikationexempel · Applikationsbeispiel

ECL Comfort 110, DLG, Danfoss Link™ CC

^

^

Danfoss

87H1435.10

?



ECL 110 http://heating.danfoss.com

Danfoss Link™ Gateway http://heating.danfoss.com

Danfoss Link™ CC http://heating.danfoss.com

Danfoss Living Connect® http://homeowners.danfoss.com/products/smartheating/#/

ECL Comfort 110

DLG

© Danfoss | 2017.03

VI.JM.C3.6K | 1

Danfoss Link™ Gateway (DLG) (code no. 087H3241)
ECL Comfort 110
Danfoss Link™

Installation Guide

Mounting · Montering · Montering · Befestigung

DLG

2

1

Danfoss

87H1436.10

2

1

1

Danfoss

87H1437.10

ECL Comfort 110, DLG, Danfoss Link™ CC

Danfoss

87H1438.11

Mk III v. 3.2.0 +

Danfoss

87H1444.10

ECL 110

?



http://heating.danfoss.com



Documentation



VIKTG

Danfoss
Link™ CC

?



http://heating.danfoss.com



Documentation



VISGL

Danfoss
Living
Connect®

?



http://heating.danfoss.com



Documentation



VIIDH

Installation Guide, DLG / ECL 110 / Danfoss Link™

2 | © Danfoss | 2017.03

VI.JM.C3.6K

Electrical connection · El-tilslutning · Elektrisk anslutning · Elektrischer Anschluss

ECL Comfort 110

Gnd

D+

D-

Danfoss

87H1439.10

?



http://heating.danfoss.com



Documentation



VIKTG

DLG

Data / Daten

DLG

8 - 24 V d.c.

220 - 240 V a.c.,
50 Hz

0,9 W

0 - 45° C

868,42 MHz

0 - 30 m

Max. 1 mW

IP class 20

Dim. 80 x 80 x 30 mm

Danfoss

87H1440.10

Installation Guide, DLG / ECL 110 / Danfoss Link™

© Danfoss | 2017.03 | 3

VI.JM.C3.6K
