1. Introduction
2
CLP 675 / CLP D 675 pumps are made according
to API 675 3
rd
edition.
CLP 675 / CLP D 675pumps are specic designed
for various chemicals, liquids, additives and other
hard-to-handle uids in production systems,
placed in subsea, onshore and oshore
applications.
Danfoss CLP pumps are based on the axial piston
principle oering long life and high eciency in
the demanding oil and gas industry. The Danfoss
CLP pumps have a light and compact design,
resulting in one of the smallest footprints on the
market.
All parts are designed to provide long service life,
i.e. long service life with a constantly high
eciency and minimum of service required.
Lubrication of the moving parts in the pumps is
This datasheet covers CLP 675-005-017,
CLP D 675-005-017 / CLP 675-025-058 /
CLP D 675-025-058 / CLP 675-085-152 /
CLP D 675-085-152 pumps
521B1388 / DKCFN.PD.014.1H.02 / 09.2015
provided by the uid itself. No oil lubrication is
thus required.
The pumps are xed displacement pumps in
which the ow is proportional to the number of
revolutions of the input shaft and the pump
displacement, regardless of any counterpressure.
The pump design ensures a minimal acceleration
loss, low pulsation and high eciency.
If magnetic drive is required, please
contact Danfoss High Pressure Pumps
sales organization for further information.
In the next pages all pumps will be named as
CLP.
The CLP pumps are made in AISI 316, whereas the
CLP D are made in Super Duplex / Duplex.
Data sheet CLP 675 / CLP D 675-005-017 / 025-058 / 085-152
Below sectional drawing is a conceptual example of a CLP 675 / CLP D 675 pump
1: Cover for shaft seal
2: Shaft seal
3: Port ange
4: Port plate
5: Valve plate
6: Retainer plate
7: Swash plate
8: End ange
9: Spring
10: Piston
11: Cylinder barrel
12: Housing with bearing:
521B1388 / DKCFN.PD.014.1H.02 / 09.2015
3
Data sheet CLP 675 / CLP D 675-005-017 / 025-058 / 085-152
2. Benets
• High reliability:
• Constructed to provide maximum
reliability.
• Designed for a wide range of corrosive,
volatile and other hard-to-handle
uids.
• All parts are made of high-grade
materials.
• Minimum service required:
• Generates insignicant pulsations in
the discharge line.
• No oil lubrication is required.
• Long service life and easy maintenance.
• Low energy costs:
• The highly ecient axial piston pump
design provides the lowest energy
consumption of any comparable on the
market.
• Zero risk of lubricant contamination:
• Oil lubricants are replaced with the
pumped medium so there is no
contamination risk from the pump.
3. Application examples • Dehydration / glycol pumping
• Transfer pumps
• Produced uid injection
• Wash uid system
• Chemical / technical processes
• Fluid make up pump
• Easy installation:
• One of the smallest, lightest and most
compact designs available in the
market.
• Pump can be installed horizontally or
vertically.
• In most cases no pulsation dampeners
are necessary due to extremely low
pulsations.
• Powered by electric motors or
combustion engines.
• Certied quality:
• ATEX available on request.
• CE available.
• Type approval available on request.
• Design verication available on
request.
• The pump is designed according to
API 675 3
rd
edition.
• Gas sweetening – “Amine”
• Fluid and glycol hydraulic uid
• Subsea
• Closed and open drain pump
• Seal ush pump
4
521B1388 / DKCFN.PD.014.1H.02 / 09.2015
Data sheet CLP 675 / CLP D 675-005-017 / 025-058 / 085-152
4. Technical data
4.1 CLP 675- 005- 017
Pump size CLP 675-005 CLP 675- 008 CL P 675-010 C LP 675 -015 CL P 675 -017
Geometric
displacement
Pressure
1)
Min. continuous
outlet pressure
Max. continuous
inlet pressure [MASP]
Max. continuous
outlet pressure [MAWP]
3)
Speed
Min. speed
Max. speed
7)
5)
cm³/rev 2.00 3.20 4.07 5.30 6.30
in³/rev 0.12 0.20 0.25 0. 32 0.38
barg 20 20 20 20 20
psig 290 290 290 290 290
barg 10 10 10 10 10
2)
psig 145 145 145 145 145
barg 172 172 17 2 172 157
6)
psig 2494 2494 2494 2494 2277
rpm 700 700 700 700 700
rpm 3600 3600 3600 3600 3600
Typical ow at 80 barg - Flow curves available in section 5
150 0 rpm l/min 2.70 4. 32 5.50 7.45 8.86
3000 rpm l/min 5.64 9.02 11. 49 15. 47 18.40
1800 rpm gpm 0.87 1.39 1.76 2.38 2.83
3600 rpm gpm 1.80 2.88 3.67 4.94 5.87
Typical motor size at 80 barg
150 0 rpm kW 50Hz 0.75 1.10 1.10 1.50 2.20
1800 rpm hp 60Hz 0.75 1.50 1.50 3.00 3.00
3000 rpm kW 50Hz 1.10 1.50 2.20 3.00 3.00
3600 rpm hp 60Hz 1.50 3.00 3.00 5.00 5.00
o
Media temperature
Ambient temperature
Sound pressure level
Weight
C 95 95 95 95 95
o
F 203 203 203 203 203
o
C 60 60 60 60 60
o
F 140 140 14 0 140 140
4)
dB(A) 73 73 73 75 75
kg 6 6 6 6 15
lbs 13 13 13 13 13
1)
For lower and higher continuous pressure please contact Danfoss High Pressure Pumps.
2)
NPIPr - see section 5.
3)
For lower or higher continuous speed please contact Danfoss High Pressure Pumps.
4)
According to ISO 3744 : 2010.
5)
Over 3000 rpm, the pump operation is referred to as “high end performance”, max. outlet
pressure is limited to 140 bar. Recommended inspection intervals are detailed in section 8.
6)
Over 160 barg, the pump operation is referred to as “high end perfomance” and recommended
inspection intervals are detailed in section 8.
7)
Minimum speed is 1000 rpm when pumping DI water
521B1388 / DKCFN.PD.014.1H.02 / 09.2015
5
Data sheet CLP 675 / CLP D 675-005-017 / 025-058 / 085-152
4.2 CLP D 675-005-017
Pump size CLP D 675-005 CLP D 675-008 CLP D 675-010 CLP D 675-015 CLP D 675-017
Geometric
displacement
Pressure
1)
Min. continuous
outlet pressure
Max. continuous
inlet pressure [MASP]
Max. continuous
outlet pressure [MAWP]
3)
Speed
Min. speed
Max. speed
7)
5)
Typical ow at 80 barg - Flow curves available in section 5
150 0 rpm l/min 2.70 4. 32 5.50 7.45 8.86
3000 rpm l/min 5.64 9.02 11. 49 15. 47 18.40
1800 rpm gpm 0.87 1.39 1.76 2.38 2.83
3600 rpm gpm 1.80 2.88 3.67 4.94 5.87
Typical motor size at 80 barg
150 0 rpm kW 50Hz 0.75 1.10 1.10 1.50 2.20
1800 rpm hp 60Hz 0.75 1.50 1.50 3.00 3.00
3000 rpm kW 50Hz 1.10 1.50 2.20 3.00 3.00
3600 rpm hp 60Hz 1.50 3.00 3.00 5.00 5.00
Media temperature
Ambient temperature
Sound pressure level
Weight
cm³/rev 2.00 3.20 4.07 5.30 6.30
in³/rev 0.12 0.20 0.25 0. 32 0.38
barg 20 20 20 20 20
psig 290 290 290 290 290
barg 10 10 10 10 10
2)
psig 145 145 145 145 145
barg 250 220 199 179 157
6)
psig 3625 3190 2886 2596 2277
rpm 700 700 700 700 700
rpm 3600 3600 3600 3600 3600
o
C 95 95 95 95 95
o
F 203 203 203 203 203
o
C 60 60 60 60 60
o
F 140 140 14 0 140 140
4)
dB(A) 73 73 73 75 75
kg 6 6 6 6 15
lbs 13 13 13 13 13
1)
For lower and higher continuous pressure please contact Danfoss High Pressure Pumps.
2)
NPIPr - see section 5.
3)
For lower or higher continuous speed please contact Danfoss High Pressure Pumps.
4)
According to ISO 3744 : 2010.
5)
Over 3000 rpm, the pump operation is referred to as “high end performance”, max. outlet
pressure is limited to 140 bar. Recommended inspection intervals are detailed in section 8.
6)
Over 160 barg, the pump operation is referred to as “high end perfomance” and recommended
inspection intervals are detailed in section 8.
7)
Minimum speed is 1000 rpm when pumping DI water
6
521B1388 / DKCFN.PD.014.1H.02 / 09.2015
Data sheet CLP 675 / CLP D 675-005-017 / 025-058 / 085-152
4.3 CLP 675-025-058
Pump size CLP 675-025 CLP 675-035 CLP 675-042 CLP 675-050 CLP 675-058
Geometric
displacement
Pressure
1)
Min. continuous
outlet pressure
Max. continuous
inlet pressure [MASP]
Max. continuous
outlet pressure [MAWP]
3)
Speed
Min. speed rpm 700 700 700 700 700
Max. speed
5)
Typical ow at 80 barg - Flow curves available in section 5
150 0 rpm l/min 12.00 16.09 20.86 24.43 28.69
3000 rpm l/min 26 .11 34.30 43.84 50.98 59.50
1800 rpm gpm 3.91 5.21 6.73 7. 86 9.21
3600 rpm gpm 8.39 10.98 14.01 16.27 18.97
Typical motor size at 80 barg
150 0 rpm kW 50Hz 3 3 4 5.5 5.5
1800 rpm hp 60Hz 5 5 7.5 7. 5 10
3000 rpm kW 50Hz 5.5 7.5 7.5 11 11
3600 rpm hp 60Hz 7.5 10 15 15 20
Media temperature
Ambient temperature
Sound pressure level
Weight
cm³/rev 9.41 12.14 15 .32 17.7 0 20.54
in³/rev 0.57 0. 74 0.93 1.08 1.25
barg 20 20 20 20 20
psig 290 290 290 290 290
barg 10 10 10 10 10
2)
psig 145 145 145 145 145
barg 175 175 175 171 157
6)
psig 2538 2538 2538 2480 2277
rpm 3600 3600 3600 3600 3600
o
C 95 95 95 95 95
o
F 203 203 203 203 203
o
C 60 60 60 60 60
o
F 140 140 14 0 140 140
4)
dB(A) 79 79 79 79 79
kg 16 16 16 16 16
lbs 35 35 35 35 35
1)
For lower and higher continuous pressure please contact Danfoss High Pressure Pumps.
2)
NPIPr - see section 5.
3)
For lower or higher continuous speed please contact Danfoss High Pressure Pumps.
4)
According to ISO 3744 : 2010.
5)
Over 3000 rpm, the pump operation is referred to as “high end performance”, max. outlet
pressure is limited to 140 bar. Recommended inspection intervals are detailed in section 8.
6)
Over 160 barg, the pump operation is referred to as “high end perfomance” and recommended
inspection intervals are detailed in section 8.
521B1388 / DKCFN.PD.014.1H.02 / 09.2015
7
Data sheet CLP 675 / CLP D 675-005-017 / 025-058 / 085-152
4.4 CLP D 675-025-058
Pump size CLP D 675-025 CLP D 675-035 CLP D 675-042 CLP D 675-050 CLP D 675-058
Geometric
displacement
Pressure
1)
Min. continuous
outlet pressure
Max. continuous
inlet pressure [MASP]
Max. continuous
outlet pressure [MAWP]
3)
Speed
2)
6)
Min. speed rpm 700 700 700 700 700
Max. speed
5)
Typical ow at 80 barg - Flow curves available in section 5
150 0 rpm l/min 12. 00 16.09 20.86 24.43 28.69
3000 rpm l/min 26 .11 34.30 43.84 50.98 59.50
1800 rpm gpm 3.91 5.21 6.73 7.8 6 9.21
3600 rpm gpm 8.39 10.98 14.01 16.27 18.97
Typical motor size at 80 barg
150 0 rpm kW 50Hz 3 3 4 5.5 5.5
1800 rpm hp 60Hz 5 5 7. 5 7. 5 10
3000 rpm kW 50Hz 5.5 7. 5 7. 5 11 11
3600 rpm hp 60Hz 7.5 10 15 15 20
Media temperature
Ambient temperature
Sound pressure level
4)
Weight
cm³/rev 9.41 12.14 15. 32 17.70 20.54
in³/rev 0.57 0 .74 0.93 1.08 1.25
barg 20 20 20 20 20
psig 290 290 290 290 290
barg 10 10 10 10 10
psig 145 145 145 145 145
barg 230 205 186 171 157
psig 3335 2973 2697 2480 2277
rpm 3600 3600 3600 3600 3600
o
C 95 95 95 95 95
o
F 203 203 203 203 203
o
C 60 60 60 60 60
o
F 140 14 0 140 14 0 140
dB(A) 79 79 79 79 79
kg 16 16 16 16 16
lbs 35 35 35 35 35
1)
For lower and higher continuous pressure please contact Danfoss High Pressure Pumps.
2)
NPIPr - see section 5.
3)
For lower or higher continuous speed please contact Danfoss High Pressure Pumps.
4)
According to ISO 3744 : 2010.
5)
Over 3000 rpm, the pump operation is referred to as “high end performance”, max. outlet
pressure is limited to 140 bar. Recommended inspection intervals are detailed in section 8.
6)
Over 160 barg, the pump operation is referred to as “high end perfomance” and recommended
inspection intervals are detailed in section 8.
8
521B1388 / DKCFN.PD.014.1H.02 / 09.2015
Loading...
