Danby DCR044B1BM, DCR044B1WM, DCR044B1SLM User Manual

OWNER’S MANUAL MANUEL DU PROPRIÉTAIRE MANUAL DEL PROPIETARIO

COMPACT REFRIGERATOR

Owner’s Manual...............................1 - 7

RÉFRIGÉRATEUR COMPACT

Manuel du propriétaire...................8 - 14

REFRIGERADOR COMPACTO

Manual del propietario.................15 - 21

MODEL * MODÈLE * MODELO

DCR044B1WM DCR044B1BM DCR044B1SLM DCR044B1WM-6 DCR044B1BM-6 DCR044B1SLM-6

www.Danby.com

Danby Products Limited, Guelph, Ontario Canada N1H 6Z9

Danby Products Inc., Findlay, Ohio US A 45840

2019.07.22

Welcome

Welcome to the Danby family. We are proud of our quality products and we believe in dependable service. We suggest that you read this owner’s manual before plugging in your new appliance as it contains important operation information, safety information, troubleshooting and maintenance tips to ensure the reliability and longevity of your appliance.

Visit www.Danby.com to access self service tools, FAQs and much more. For additional assistance call 1-800-263-2629.

Note the information below; you will need this information to obtain service under warranty. You must provide the original purchase receipt to validate your warranty and receive service.

Model Number: _________________________________________________

Serial Number: _________________________________________________

Date of Purchase: _______________________________________________

Need Help?

Before you call for service, here are a few things you can do to help us serve you better.

Read this owner’s manual:

It contains instructions to help you use and maintain your appliance properly.

If you receive a damaged appliance:

Immediately contact the retailer or builder that sold you the appliance.

Save time and money:

Check the troubleshooting section at the end of this manual before calling. This section will help you solve common problems that may occur.

1-800-26- Danby

(1-800-263-2629)

Important Safety Information

READ AND FOLLOW ALL SAFETY INSTRUCTIONS

SAFETY REQUIREMENTS

DANGER: Risk of ﬁ re or explosion. Flammable

refrigerant used. Do not puncture refrigerant tubing.

• Do not use mechanical devices to defrost refrigerator.

• Ensure that servicing is done by factory authorized service personnel, to minimize product damage or safety issues.

• If the power supply cord is damaged, it must be replaced by the manufacturer, its service agent or similar qualiﬁ ed person in order to avoid hazard.

• Consult repair manual or owner’s guide before attempting to service this product. All safety precautions must be followed.

• Dispose of properly in accordance with federal or local regulations.

• Follow handling instructions carefully.

• Do not store explosive substances such as aerosol cans with a ﬂ ammable propellant in this appliance.

WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.

WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.

WARNING: Do not damage the refrigerant circuit. WARNING: Do not use electrical appliances inside

the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.

CAUTION: Children should be supervised to ensure that they do not play with the appliance.

SAFETY REQUIREMENTS

This appliance is not intended for use by persons (including children) whose physical, sensory or mental capabilities may be different or reduced, or who lack experience or knowledge, unless such persons receive supervision or training to operate the appliance by a person responsible for their safety.

This appliance is intended to be used in household and similar applications such as:

• Staff kitchen areas in shops, ofﬁ ces and other working environments;

• Farm houses and by clients in hotels, motels and other residential type environments;

• Bed and breakfast type environments;

• Catering and similar non-retail applications.

GROUNDING INSTRUCTIONS

This appliance must be grounded. Grounding reduces the risk of electrical shock by providing an escape wire for the electrical current.

This appliance has a cord that has a grounding wire with a 3-prong plug. The power cord must be plugged into an outlet that is properly grounded. If the outlet is a 2-prong wall outlet, it must be replaced with a properly grounded 3-prong wall outlet. The serial rating plate indicates the voltage and frequency the appliance is designed for.

WARNING - Improper use of the grounding plug can result in a risk of electric shock. Consult a qualiﬁ ed electrician or service agent if the grounding instructions are not completely understood, or if doubt exists as to whether the appliance is properly grounded.

DANGER: Risk of child entrapment. Before throwing away an old appliance:

• Remove the door or lid.

• Leave shelves in place so that children may not easily climb inside.

DANGER: Do not add a lock to the door or lid. This can cause child entrapment and harm.

SAVE THESE INSTRUCTIONS!

Do not connect your appliance to extension cords or together with another appliance in the same wall outlet. Do not splice the power cord.

Do not under any circumstances cut or remove the third ground prong from the power cord. Do not use extension cords or ungrounded (two prongs) adapters.

INSTALLATION INSTRUCTIONS OPERATING INSTRUCTIONS

LOCATION

• Two people should be used when moving the appliance.

• Remove interior and exterior packaging prior to installation. Wipe the outside of the appliance with a soft, dry cloth and the inside with a lukewarm wet cloth.

• Place the appliance on a ﬂ oor that is strong enough to support it when it is fully loaded.

• Do not place the appliance in direct sunlight or near sources of heat, such as a stove or heater, as this can increase electrical consumption. Extreme cold ambient temperatures may also cause the appliance to perform improperly.

• Do not use the appliance near water, for example in a wet basement or near a sink.

• This appliance is intended for household use only. It is not designed for outside installation, including anywhere that is not temperature controlled (garages, porches, vehicles, etc.).

• Before connecting the appliance to a power source, let it stand upright for approximately 6 hours. This will reduce the possibility of a malfunction in the cooling system from handling during transportation.

TEMPERATURE SELECTION

The temperature of the appliance can be adjusted by turning the thermostat dial in the interior compartment.

• Higher numbers indicate the coldest setting.

• Lower numbers indicate the warmest setting.

• The “0” position will turn off the cooling function.

Internal temperature of the appliance can vary based on ambient temperature, the quantity of items stored and how frequently the door is opened.

INTERIOR LIGHT

The interior light bulb can be replaced if it burns out. Ensure that the appliance is unplugged before replacing the light bulb.

1. Remove the screw that secures the light cover.

2. Remove the light cover by squeezing the tabs at the top and bottom of the light cover and pulling outward.

3. Make sure the light bulb is cool before removing it.

4. Replace the light bulb with a 10 watt bulb that is the same shape and size.

5. Replace the light bulb cover and the securing screw.

• This appliance is 49 cm (19.3 inches) wide by 81 cm (31.9 inches) high by 49 cm (19.3 inches) deep.

• Allow 12.7 cm (5 inches) of space between the back, sides and top of the appliance and all adjacent walls.

• This appliance is intended for free-standing installation only and is not intended to be built into a cabinet or counter. Building in this appliance can cause it to malfunction.

LEVELING INSTRUCTIONS

There is an adjustable leg on the bottom of the appliance that can be turned up or down to ensure that the appliance is level.

1. Turn the leveling leg counter-clockwise as far as it will go, until the top of the foot is touching the bottom of the chassis.

2. Slowly turn the leveling leg clockwise until the appliance is level.

OPERATING INSTRUCTIONS

DOOR REVERSAL INSTRUCTIONS

If the appliance is placed on its back or side for any length of time during this process, it must be allowed to remain upright for 6 hours before plugging it in to avoid damage to the internal components.

1. Remove the upper hinge cover and the upper hinge from the top right side of the cabinet. Remove the screw hole cover from the top left side of the cabinet.

2. Remove the hinge hole cover from the top left side of the door and install it on the top right hand side of the door. Remove the door from the cabinet.

3. Remove the adjustable foot from the bottom left side of the cabinet. Remove the lower hinge from the bottom right side of the cabinet.

4. Unscrew the hinge pin and remove it from the hinge.

5. Flip over the lower hinge.

6. Reinstall the hinge pin.

7. Install the lower hinge on the bottom left side of the cabinet. Install the adjustable foot on the lower right side of the cabinet. Install the door on the cabinet.

8. Install the upper hinge on the top left side of the cabinet. Install the screw hole cover on the top right side of the cabinet.

Note: Ensure that the top of the door is level with the top of the cabinet and that the rubber gasket is making a good seal with the cabinet all the way around before tightening the screws on the upper hinge.

CARE & MAINTENANCE

CLEANING

Ensure the appliance is unplugged before cleaning.

• To clean the inside of the appliance, use a soft cloth and a solution of a tablespoon of baking soda to one quart of water or a mild soap solution or some mild detergent.

• Wash removable shelves in a mild detergent solution, then dry and wipe with a soft cloth.

• Clean the outside with a soft, damp cloth and some mild detergent.

• It is important to keep the area clean where the door seals against the cabinet. Clean this area with a soapy cloth. Rinse with a damp cloth and let dry.

Note: Do not use cleaners containing ammonia or alcohol on the appliance. Ammonia or alcohol can damage the appearance of the appliance. Never use any commercial or abrasive cleaners or sharp objects on any part of the appliance.

POWER FAILURE

Most power failures are corrected within a few hours and should not affect the temperature of your appliance if you minimize the number of times the door is opened. If the power is going to be off for a longer period of time, take the proper steps to protect your contents.

Note: Wait 3 to 5 minutes before attempting to restart the refrigerator if operation has been interrupted.

MOVING

• Make sure the appliance is empty.

• Secure the shelves with tape.

• Secure the door with tape.

• Turn the adjustable foot up to the base to avoid damage.

• Protect the outside of the appliance with a blanket or similar item.

• Be sure the appliance stays in the upright position during transportation.

• If the appliance is placed on its back or side during transportation, upon reaching the destination, allow it to remain upright for 6 hours before plugging in to avoid damage to internal components.

DEFROSTING INSTRUCTIONS

This appliance is equipped with a manual defrost system. Defrosting should be activated any time the ice build up inside the freezer compartment reaches 6 mm (1/4”) thick.

• Remove all food from the appliance.

• Unplug the appliance and leave it unplugged until all ice has melted.

• Remember to protect your ﬂ oors or counters during the defrosting process by putting towels or a pan under the appliance in case of leaking.

• Leaving the refrigerator door partially open can help the defrosting process. You must remember to close the door before plugging the appliance back in.

• Ensure that the drip tray is under the evaporator to collect melted water.

VACATION

• Short vacations: Leave the appliance operating

during vacations of less than three weeks.

• Long vacations: If the appliance will not be used

for several months, remove all items and turn off the appliance. Clean and dry the interior thoroughly. To prevent odor and mold growth, leave the door open slightly, blocking it open if necessary.

Important: Never use sharp or pointed instruments to remove ice from the freezer compartment. The freezer compartment contains refrigerated gas lines. If these lines are accidentally pierced it will render the refrigerator inoperable and void the manufacturer’s warranty. Do not allow the refrigerator to continue operation if the freezer compartment is pierced.

DISPOSAL

This appliance may not be treated as regular household waste, it should be taken to the appropriate waste collection point for recycling of electrical components. For information on local waste collection points, contact your local waste removal agency or government ofﬁ ce.

TROUBLESHOOTING

Danby Consumer Care: 1-800-263-2629

Hours of operation:

Monday to Thursday 8:30 am - 6:00 pm Eastern Standard Time Friday 8:30 am - 4:00 pm Eastern Standard Time

Information in this manual is subject to change without notice.

PROBLEM POSSIBLE CAUSE

No power • A fuse may be blown or the circuit breaker

tripped.

• Plug not fully inserted into the wall outlet.

Internal temperature not cold enough • Temperature setting is too warm.

• Door is not shut properly or opened excessively.

• Recently added a large quantity of warm food to the cabinet.

• Close proximity to heat source or direct sunlight.

• Ambient temperature or humidity is very high.

Appliance runs continuously • Temperature setting is too cold.

• Door not shut properly or opened excessively.

• Recently added a large quantity of warm food to the cabinet.

• Close proximity to heat source or direct sunlight.

• Ambient temperature or humidity is very high.

Popping, crackling or gurgling noises • These noises are normal. As the compressor

turns on, metal parts undergo expansion and contraction causing popping or crackling noises. As the coolant moves through the system it changes from a liquid to a gas and back again which can cause gurgling noises.

LIMITED “IN HOME” WARRANTY

LIMITED IN-HOME APPLIANCE WARRANTY

This quality product is warranted to be free from manufacturer’s defects in material and workmanship, provided that the unit is used under the normal operating

This quality product is warranted to be free from manufacturer’s defects in material and workmanship, provided that the unit is used

conditions intended by the manufacturer.

under the normal operating conditions intended by the manufacturer.

This warranty is available only to the person to whom the unit was originally sold by Danby Products Limited (Canada) or Danby Products Inc. (U.S.A.) (hereafter

This warranty is available only to the person to whom the unit was originally sold by Danby Products Limited (Canada) or Danby

“Danby”) or by an authorized distributor of Danby, and is non-transferable.

Products Inc. (U.S.A.) (hereafter “Danby”) or by an authorized distributor of Danby, and is non-transferable.

TERMS OF WARRANTY

Plastic parts are warranted for thirty (30) days from the date of purchase, with no extensions provided.

Plastic parts, are warranted for thirty (30) days only from purchase date, with no extensions provided.

First 12 months

First Year

To obtain service

To obtain Service

Boundaries of in-home service

During the ﬁrst twelve (12) months, any functional parts of this product found to be defective, will be repaired or replaced, at warrantor’s option, at no charge to the original purchaser.

During the rst twelve (12) months, any functional parts of this product found to be defective, will be repaired or replaced, at warrantor’s option, at no charge to the ORIGINAL purchaser.

Contact the dealer where the unit was purchased, or contact the nearest authorized Danby service depot, where service must be performed by a qualiﬁed service technician. If service is performed on the unit by anyone other

Danby reserves the right to limit the boundaries of “In Home Service” to the proximity of an Authorized Service Depot. Any app liance

than an authorized service depot, all obligations of Danby under this warranty shall be void.

requiring service outside the limited boundaries of “In Home Service” , it will be the consumer’s responsibility to transport the appliance (at their own expense) to the original retailer (point of purchase) or a service depot for repair. See “Boundaries of In Home Serv ice” below.

Danby reserves the right to limit the boundaries of “In Home Service” to the proximity of an authorized service

Contact your dealer from whom your unit was purchased, or contact your nearest authorized Danby service depot, where service

depot. Any appliance requiring service outside the limited boundaries of “In Home Service”, will be the consumer’s

must be performed by a qualied service technician.

responsibility to transport at their own expense to the original point of purchase or a service depot for repair. If the

If service is performed on the units by anyone other than an authorized service depot, or the unit is used for commercial appli cation, all

appliance is installed in a location that is 100 kilometers (62 miles) or more from the nearest service center, it must

obligations of Danby under this warranty shall be void.

be delivered to the nearest authorized Danby Service Depot by the purchaser.

TERMS OF WARRANTY

Boundaries of In Home Service

If the appliance is installed in a location that is 100 kilometers (62 miles) or more from the nearest service center your unit must be

Transportation charges to and from the service location are not protected by this warranty and are the

delivered to the nearest authorized Danby Service Depot, as service must only be performed by a technician qualied and certif ied for

responsibility of the purchaser.

warranty service by Danby. Transportation charges to and from the service location are not protected by this warranty and are t he

Nothing within this warranty shall imply that Danby will be responsible or liable for any spoilage or damage to food or other contents of this appliance, whether due to any defect of the appliance, or its use, whether proper or improper.

responsibility of the purchaser.

Nothing within this warranty shall imply that Danby will be responsible or liable for any spoilage or damage to food or other c ontents of this appliance, whether due to any defect of the appliance, or its use, whether proper or improper.

Save as herein provided, by Danby, there are no other warranties, conditions, representations or guarantees, express or implied, made or intended by Danby or its authorized distributors and all other warranties, conditions, representations or guarantees, including any warranties, conditions, representations or guarantees under any Sale of Goods Act or like legislation or statute is hereby expressly

Save as herein provided, Danby, there are no other warranties, conditions, representations or guarantees, express or implied, m ade or intended by Danby or its

excluded. Save as herein provided, Danby shall not be responsible for any damages to persons or property, including the unit itself,

authorized distributors and all other warranties, conditions, representations or guarantees, including any warranties, conditio ns, representations or guarantees

howsoever caused or any consequential damages arising from the malfunction of the unit and by the purchase of the unit, the

under any Sale of Goods Act or like legislation or statue is hereby expressly excluded. Save as herein provided, Danby shall no t be responsible for any damages

purchaser does hereby agree to indemnify and hold harmless Danby from any claim for damages to persons or property caused by

to persons or property, including the unit itself, howsoever caused or any consequential damages arising from the malfunction o f the unit and by the purchase of

the unit.

the unit, the purchaser does hereby agree to indemnify and hold harmless Danby from any claim for damages to persons or propert y caused by the unit.

No warranty or insurance herein contained or set out shall apply when damage or repair is caused by any of the following:

1) Power failure.

2) Damage in transit or when moving the appliance.

1) Power failure.

3) Improper power supply such as low voltage, defective house wiring or inadequate fuses.

2) Damage in transit or when moving the appliance.

4) Accident, alteration, abuse or misuse of the appliance such as inadequate air circulation in the room or abnormal operating

3) Improper power supply such as low voltage, defective house wiring or inadequate fuses.

conditions (ie. extremely high or low room temperature).

4) Accident, alteration, abuse or misuse of the appliance such as inadequate air circulation in the room or abnormal operating con ditions

5) Use for commercial or industrial purposes (ie. If the appliance is not installed in a domestic residence).

6) Fire, water damage, theft, war, riot, hostility, acts of God such as hurricanes, ﬂoods etc.

7) Service calls resulting in customer education.

8) Improper Installation (ie. Building-in of a free standing appliance or using an appliance outdoors that is not approved for outdoor application, including but not limited to: garages, patios, porches or anywhere that is not properly insulated or climate controlled).

Proof of purchase date will be required for warranty claims; retain bills of sale. In the event that warranty service is required, present

Proof of purchase date will be required for warranty claims; so, please retain bills of sale. In the event warranty service is required, present this document to our

the proof of purchase to our authorized service depot.

AUTHORIZED SERVICE DEPOT.

(extremely high or low room temperature).

5) Use for commercial or industrial purposes (ie. If the appliance is not installed in a domestic residence).

6) Fire, water damage, theft, war, riot, hostility, acts of God such as hurricanes, oods etc.

7) Service calls resulting in customer education.

8) Improper Installation (ie. Building-in of a free standing appliance or using an appliance outdoors that is not approved for out door application).

EXCLUSIONS

GENERAL PROVISIONS

Danby Products Limited

PO Box 1778, Guelph, Ontario, Canada N1H 6Z9

Telephone: (519) 837-0920 FAX: (519) 837-0449

Warranty Service

In-home

In Home

1-800-263-2629

04/17

04/09

Danby Products Inc.

PO Box 669, Findlay, Ohio, U.S.A. 45840

Telephone: (419) 425-8627 FAX: (419) 425-8629

PO Box 669, Findlay, Ohio, U.S.A. 45840

Telephone: (419) 425-8627 FAX: (419) 425-8629

Danby Products Inc.

+ 16 hidden pages
