READ THESE INSTRUCTIONS CAREFULLY BEFORE
INSTALLATION. KEEP THIS MANUAL IN A HANDY PLACE
FOR FUTURE REFERENCE.
IMPROPER INSTALLATION OR ATTACHMENT OF EQUIP­MENT OR ACCESSORIES COULD RESULT IN ELECTRIC
SHOCK, SHORT-CIRCUIT, LEAKS, FIRE OR OTHER
DAMAGE TO THE EQUIPMENT. BE SURE ONLY TO USE
ACCESSORIES MADE BY DAIKIN WHICH ARE SPECIFIC­ALLY DESIGNED FOR USE WITH THE EQUIPMENT AND
HAVE THEM INSTALLED BY A PROFESSIONAL.
IF UNSURE OF INSTALLATION PROCEDURES OR USE,
ALWAYS CONTACT YOUR DAIKIN DEALER FOR ADVICE
AND INFORMATION.

Installation manual

Installation

• For installation of the indoor unit(s), refer to the indoor unit
installation manual.

• This outdoor unit requires the pipe branching kit (optional)
when used as the outdoor unit for the simultaneous operation
system. Refer to catalogues for details.

• Never operate the unit without the thermistor (R3T), burning
of the compressor may result.

• When closing the service panels, take care that the tightening
torque does not exceed 4.1Nm.

Accessories

Check if the following accessories (gas pipes) are included with
your unit.

Handling

The units are packed in a wooden crate and attached on a
wooden pallet.
At delivery, the package should be checked and any damage
should be reported immediately to the carrier claims agent.
When handling the unit, take into account the following:

1

BEFORE INSTALLATION

Precautions

For R407C units only

• The new refrigerant requires strict cautions for keeping the
system clean, dry and tight.

a. Clean and dry.

Foreign materials (including mineral oils or moisture) should
be prevented from getting mixed into the system.

b. Tight.

Read the chapter ‘Precautions on refrigerant piping’ carefully
and follow these procedures correctly.
Since design pressure is 3.3MPa or 33bar (for R22 units

3.0MPA or 30bar), pipes of larger wall thickness may be
required.

• Since R407C is a mixed refrigerant, the required additional
refrigerant must be charged in its liquid state. (If the
refrigerant is in state of gas, its composition changes and the
system will not work properly).

• The connected indoor units must be indoor units designed
exclusively for R407C. If indoor units for R22 are connected,
normal operation cannot be assured.

2

Fragile, handle the unit with care.

1.
Keep the unit upright in order to avoid compressor

damage.

2. Lift the unit preferably with a crane and 2 belts (1) of at least

8m long.

3. When lifting the unit with a crane, always use protectors (2)

to prevent belt damage and pay attention to the position of the
unit’s centre of gravity.

4. Bring the unit as close to its final installation position in its

original package to prevent damage during transport.

1

SELECTING INSTALLATION SITE

PRECAUTIONS ON INSTALLATION

1. Select an installation site where the following conditions are
satisfied and that meets with your customer’s approval.

• Places which are well-ventilated.

• Places where the unit does not bother next-door neighbours.

• Safe places which can withstand the unit’s weight and

vibration and where the unit can be installed level.

• Places where there is no possibility of flammable gas or

product leak.

• Places where servicing space can be well ensured.

• Places where the indoor and outdoor units’ piping and

wiring lengths come within the allowable ranges.

• Places where water leaking from the unit cannot cause

damage to the location (e.g. in case of a blocked drain
pipe).

Precautions

• Do not install or operate the unit in rooms mentioned below.
a. Where mineral oil like cutting oil is present.
b. Where the air contains high levels of salt such as that near

the ocean.

c. Where sulphurous gas is present such as that in areas of

hot spring.
d. Where voltage fluctuates a lot such as that in factories.
e. In vehicles or vessels.
f. Where high concentrations of oil vapour or spray are

present such as that in kitchens.
g. Where machines generating electromagnetic waves are

present.
h. Where acidic or alkaline vapour is present.

2. Prepare a water drainage channel around the foundation, to
drain waste water from around the unit.

• Check the strength and level of the installation ground so that
the unit will not cause any operating vibration or noise after
installation.

• Unpacking and placing the unit
a) Remove the wooden crate from the unit.
b) Remove the 4 screws fixing the unit to the pallet.
c) The unit must be installed on a solid longitudinal founda-

tion (steelbeam frame or concrete). Maximum height of the
foundation is 150mm.

d) Lift the unit from the pallet and place it on its installation

position.

• In accordance with the foundation drawing in the figure, fix the
unit securely by means of the foundation bolts. (Prepare four
sets of M12 foundation bolts, nuts and washers each which
are available on the market.)

• It is best to screw in the foundation bolts until their length are
20mm from the foundation surface.

INSTALLATION SERVICING SPACE

Refer to figure 1 for the required dimensions (mm). Choose one
of the 2 possibilities.

3. If you install the unit on a frame, please install a waterproof
plate within 150mm of the underside of the unit in order to
prevent the invasion of water from the lower direction.

4. When installing the unit in a place frequently exposed to
snow, pay special attention to the following:

• Elevate the foundation as high as possible.

• Remove the rear suction grille to prevent snow from accu-

mulating on the rear fins.

5. If you install the unit on a building frame, please install a
waterproof plate (within 150mm of the underside of the unit)
in order to avoid the drainwater dripping. (See figure).

2

REFRIGERANT PIPE SIZE AND ALLOWABLE PIPE LENGTH

All field piping must be installed by a licensed refrigeration
technician and must comply with relevant local and
national regulations.

1. Refrigerant pipe size
a) Pair system: see figure 2

Refrigerant pipe size

Gas pipe Liquid pipe

R(Y)(P)200

R(Y)(P)250

ø 28.6 x t1.15

b) Simultaneous operation system

• Twin and triple operation system (twin: see figure 3, triple: see
figure 4)

The pipes between the outdoor unit and the branch (L1) should
have the same size as the outdoor connections. The pipes
between the branch and the indoor units (L2~L4) should have the
same size as the indoor connections. Branch: see marking ‘■■’ on
figures 3~4.

• Double twin operation system: see figure 5

The pipes between the outdoor unit and the branch (L1) should
have the same size as the outdoor connections. The pipes
between the branch and the indoor units (L4~L7) should have the
same size as the indoor connections. Branch: see marking ‘■■’ on
figure 5.

For branch pipes L2 and L3: see table below for the branch pipe
sizes.

Branch pipe size

Gas pipe

R(Y)(P)200,250

ø 19.1 x t1.00

2. Allowable pipe length

See the table below concerning lengths and heights. Refer to
figures 2~5. Assume that the longest line in the figure corres­ponds with the actual longest pipe, and the highest unit in the
figure corresponds with the actual highest unit.

ø 12.7 x t0.90

ø 15.9 x t0.95

L2, L3

Liquid pipe

ø 9.5 x t0.80

PRECAUTIONS ON REFRIGERANT PIPING

When a heat pump outdoor unit is installed below the indoor unit,
the following can occur:

- when the unit stops, oil will return to the discharge side of the
compressor. When starting the unit, this can cause liquid (oil)
hammer.

- the oil circulation will decrease

To solve these phenomena, provide oil traps in the gas pipe every
15m if the level difference (H) is more than 15m. See figure 6.

A outdoor unit
B indoor unit
C gas pipe
D liquid pipe
E oil trap

Note: if the outdoor unit is installed above the indoor unit, oil

traps are not necessary.

Connecting the refrigerant piping

For R407C units:

Use R407C only when adding refrigerant
Installation tools:
Make sure to use installation tools (gauge manifold
charge hose, etc.) that are exclusively used for R407C
installations to withstand the pressure and to prevent
foreign materials (e.g. mineral oils and moisture) from
mixing into the system. Vacuum pump (use a 2-stage
vacuum pump with a non-return valve):

Make sure the pump oil does not flow oppositely into the
system while the pump is not working.

Use a vacuum pump which can evacuate to -100.7kPa
(5Torr, -755mmHg).

Installation of refrigerant piping is possible as front connection,
side connection and bottom connection.

Maximum allowable piping length
(Parenthesized figure represents
equivalent length)

Maximum total one-way pipe length

Maximum branch pipe length

Maximum difference between branch
lengths

Maximum difference between each
1st branch
Maximum difference between each
2nd branch
Maximum height between indoor and
outdoor

Maximum height between indoors

Pair
Twin / Triple
Double twin
Twin
Triple
Double twin
Twin / Triple
Double Twin
Twin
Triple
Double Twin

Double Twin

Double Twin

All

Twin / Triple /
Double Twin

L1
L1+L2
L1+L2+L4
L1+L2+L3
L1+L2+L3+L4
L1+L2+L3+L4+L5+L6+L7
L2
L2+L4
L2-L3
L2-L4
(L2+L4)-(L3+L7)

L2-L3

L4-L5, L6-L7

H1

H2

50 m (70 m)

60 m

20 m

10 m

10 m

10 m

30 m

0.5 m

The minimal piping length should be 7.5m. If installation is
performed with less field piping, the system will be overcharged
(abnormal HP, etc.). If the distance between indoor and outdoor
unit is less than 7.5 m, please make sure that the piping length
is ≥ 7.5 m by additional bending of the pipes.

3

1. Flange

2. Flare nut

3. Gas side (attached pipe)

4. Liquid side

5. Brazing

6. Knock out hole

Remarks:

Front connection:

• Make sure to close the piping intake hole again after
installation work.

Bottom Connection:

• Remove the knock out hole by drilling the 2 concave recesses
with a Ø 6mm drill (see figure). Afterwards, paint the edges to
avoid rusting.

A Knock out hole
B Drill
C Concave recess

• Liquid side:
Provide a liquid side pipe (field supply), and
connect it to the stop valve. Take care not to
allow it to touch the gas side pipe.

±100mm

• Gas side:
Cut the gas side accessory pipe and make connection using
an elbow (field supply).

A = cutting position

A

±167mm

Precautions for connecting pipes

When the outdoor unit is installed above the indoor unit the
following can occur:

1. The condensated water on the stop valve can move to the
indoor unit. To avoid this, please cover the stop valve with
sealing material.

2. If the temperature is higher than 30°C and the humidity is
higher than RH 80%, then the thickness of the sealing
materials should be at least 20mm in order to avoid
condensation on the surface of the sealing.

• Please refer to the table for the dimensions for processing
flares and for the tightening torques. (Too much tightening will
end up in splitting of the flare.)

• When connecting the flare nut, coat the flare both inside and
outside with refrigerant oil (R22), ether or ester oil (R407C)
and initially tighten by hand before tightening firmly.

• Make sure to flow nitrogen gas through the pipe when
brazing.

A dimensions for

processing flares (mm)

12.0 ~ 12.4

15.4 ~ 15.8Ø 12.7

18.6 ~ 19.0

22.9 ~ 23.3

±0.5

90°

45°

±2

A

R=0.4~0.8

Ø 9.5

Ø 15.9

Ø 19.1

Flare nut tightening torquePiping size Flare shape

3270~3990 N•cm
(333~407 kgf•cm)
4950~6030 N•cm
(504~616 kgf•cm)
6180~7540 N•cm
(630~770 kgf•cm)

9720~11860 N•cm

(989.8~1208 kgf•cm)

Application of refrigerant oil
(for R407C ether or ester oil should be used)

Operating stop valve: refer to figure 7

To open:

1. Remove the cap (1) and turn the shaft (2) counterclockwise
with hexagon socket screw keys.

2. Turn it all the way until the shaft stops.

3. Tighten the cap firmly.

To close:

1. Remove the cap and turn the shaft clockwise.

2. Tighten the shaft firmly until it reaches the sealed area (4) of
the body.

3. Tighten the cap firmly.

Note

- Refer to the table for stop valve tightening torques.

- Be sure to use both a spanner and a torque wrench when
connecting or disconnecting pipes to or from the unit.

- Use a charging hose with push rod when using the service
port (5).

- Check for refrigerant gas leakage after tightening the cap.

- Make sure to keep the valve open during operation.

Stop valve tightening torques

R(Y)(P)200 R(Y)(P)250

Service port (5)

Valve cap (1)

Liquid pipe

Gas pipe

980~1470 N•cm (100~150 kgf•cm)

1960~2450 N•cm 2940~3430 N•cm
(200~250 kgf.cm) (300~350 kgf.cm)

3920~4410 N•cm (400~450 kgf.cm)

• Take measures against contamination when installing pipes.
Prevent foreign materials like moisture and other impurities
from mixing into the system.

Place Installation period

Outdoor unit

Indoor

More than a month Pinch the pipe

Less than a month

Regardless of the period

Protection method

Pinch or tape the pipe

Great caution is needed when passing copper tubes through
walls.

In case of simultaneous operation system

• Upward and downward piping should be performed at the
main piping line.

• Use branch piping kit (optional) for branching refrigerant
pipes.

Precautions to be taken. (For details, refer to the manual
attached to branch piping kit.)

*1.Install the branch pipes horizontally (Maximum inclination:

20 degrees or less)

*2.Length of branch pipe to the indoor unit should be as short

as possible.

*3.Try to keep lengths of both branch pipes to the indoor unit

equal.

4

EVACUATING

CHARGING REFRIGERANT

The units were checked for leaks by the manufacturer.

The refrigerant lines fitted in site are to be checked for leaks by
the fitter.

Confirm that the valves are firmly closed before pressure test or
vacuuming.

Do not purge the air with refrigerants. Use a vacuum
pump to vacuum the installation. No additional refrigerant
is provided for air purging.

Air tight test and vacuum drying (take special care for
R407C units): refer to figure 11

A Pair system
B Simultaneous operation system
1 Pressure gauge
2 Nitrogen
3 Refrigerant
4 Weighing machine
5 Vacuum pump
6 Stop valve
7 Main pipe
8 Branched pipes
9 Pipe branching kit (optional)

• Air tight test: make sure to use nitrogen gas. Pressurize the
liquid and gas pipes to 3.3MPa (do not pressurize more than

3.3MPa). If the pressure drops, check where the nitrogen
comes from.

• Vacuum drying: use a vacuum pump which can evacuate to

-100.7kPa (5Torr, -755mmHg).

This unit requires additional charging of refrigerant according to
the length of pipe connected at the site. Concerning R407C
refrigerant: charge the refrigerant to the liquid pipe in its liquid
state. Since R407C is a mixed refrigerant, its composition
changes if charged in a state of gas and normal system operation
would no longer be assured.
Concerning L1~L7 (see tables below), refer to figures 2~5.

1. Additional charging of refrigerant

• The R22 cooling units (R200/R250) do not require any
additional charging of refrigerant.

• The R22 heatpump units (RY200/RY250) and the R407C
units (R(Y)P200 / R(Y)P250) require additional charging of
refrigerant, according to the length of pipe connected at the
site.

Find the correct amount of additional refrigerant to charge ‘G’
(kg) using one of the following formulas.

If G<0: no addition is required.

Pair system: refer to figure 2

L1 (m) one way length of liquid pipe

R407C R22

R(P)200 G = (L1-30) x 0.06 G= 0
R(P)250 G = (L1-30) x 0.09 G= 0
RY(P)200 G = (L1-30) x 0.10 G= (L1-7.5) x 0.03
RY(P)250 G = (L1-30) x 0.14 G= (L1-7.5) x 0.05

1. Evacuate the system from the liquid and gas pipes by
using a vacuum pump for more than 2 hours and bring the
system to -100.7kPa. After keeping the system under that
condition for more than one hour, check if the vacuum
gauge rises or not. If it rises, the system may either contain
moisture inside or have leaks.

2. Following should be executed if there is a possibility of
moisture remaining in the pipe (if piping work is carried out
during the raining season or over a long period of time,
rainwater may enter the pipe during work).
After evacuating the system for 2 hours, pressurize the
system to 0.05MPa (vacuum break) with nitrogen gas and
evacuate the system again using the vacuum pump for
1 hour to -100.7kPa (vacuum drying). If the system cannot
be evacuated to -100.7kPa within 2 hours, repeat the
operation of vacuum break and vacuum drying.
Then after leaving the system in vacuum for 1 hour,
confirm that the vacuum gauge does not rise.

Leak test

1. Evacuate the pipes and check vacuum. (No pressure increase
for 1 minute.)

2. Break the vacuum with a minimum of 2 bar of nitrogen.

3. Conduct leak test by applying soap water, etc. to the connect­ing part of the pipes.

4. Discharge Nitrogen.

5. Evacuate and check vacuum again.

6. Open the stop valve and inject the refrigerant into the refrig­erant pipe and into the indoor unit.

7. Leak test must satisfy EN 378-2.

Simultaneous operation system
(Twin, Triple, Double Twin: refer to figures 2~5)

- L1 (m) one way length of main liquid pipe

- L2~L7 (m) one way length of branched liquid pipes

R407C:

RP200 G = (L1-30) x 0.06 + L2 x A + L3 x A + L4 x A + L5 x A + L6 x A + L7 x A
RP250 G = (L1-30) x 0.09 + L2 x A + L3 x A + L4 x A + L5 x A + L6 x A + L7 x A
RYP200 G = (L1-30) x 0.10 + L2 x A + L3 x A + L4 x A + L5 x A + L6 x A + L7 x A
RYP250 G = (L1-30) x 0.14 + L2 x A + L3 x A + L4 x A + L5 x A + L6 x A + L7 x A

RP200,250 Ø 9.5 0.03 kg/m

RYP200,250

Branched pipe A

Ø 6.4 0.03 kg/m
Ø 9.5 0.05 kg/m

R22:

R200 G = 0
R250 G = 0
RY200 G = (L1-7.5) x 0.03 + L2 x A + L3 x A + L4 x A + L5 x A + L6 x A + L7 x A
RY250 G = (L1-7.5) x 0.05 + L2 x A + L3 x A + L4 x A + L5 x A + L6 x A + L7 x A

Branched pipe A

RY200,250

Ø 6.4 0.005 kg/m
Ø 9.5 0.015 kg/m

5

2. Complete charging of the refrigerant

When the entire refrigerant pipe length is within 30 meters (for
R407C) and 7.5 meters (for R22), charge the refrigerant in
accordance with the amount mentioned in the nameplate, and
when the pipe length exceeds 30 meters (for R407C) and

7.5 meters (for R22), the charging amount mentioned in the
nameplate and that required for additional charging are to be
totalled as the net charging amount.

3. Precaution for pumping-down operation

The outdoor unit is equipped with a low-pressure switch to
protect the compressor. Take the following steps to perform
the pumping-down operation.

Caution

Never short-circuit the low-pressure switch in this operation.
In order to avoid electric shock, please put the insulation sheet
as follows. (See figure 9).

1 Switch box
2 PCB
3 Pump down button
4 Insulation sheet
5 Tape

1. Start the fan operation with the remote controller.
Confirm that stop valves both on the liquid and gas side are
open.

2. Push the pumping-down button on the PC board of the
outdoor unit during more than 5 seconds.
Compressor and outdoor fan will start operation automatically.
If step 2 is performed before step 1, then the indoor fan may
automatically start running. Please pay attention to this.

ELECTRICAL WIRING WORK

• All wiring must be performed by an authorized electrician.

• All components procured on the site and all electric construct-

ion should comply with the applicable local and national codes.

• Be sure to use a dedicated power circuit.

• Do not share a common source with other equipment.

• Fix cables so that cables do not make contact with the pipes

(especially on high pressure side).

• Make sure to connect power supply cables in normal phase.
If connected in reverse phase, the remote controller of indoor
unit indicates “U1” and the equipment cannot operate.
Change any two of the three power supply cables (L1, L2, L3)
to correct phase.
If the contact in the magnetic switch should be forcibly turned
on while the equipment is inoperative, the compressor will
burn out. Never try to forcibly turn on the contact.

• Never squeeze bundled cables into a unit.

• When cables are routed from the unit, a protection sleeve for

the conduits (PG-insertions) can be inserted at the installation
hole. (Refer to figure 8)

A Inside
B Outside
1 Wire
2 Bush
3 Nut
4 Frame
5 Hose

• Follow the electric wiring diagram for electrical wiring works.

• Grounding resistance should be according to national

regulations.

3. Continue operation for 2 min. until operation condition
stabilizes.

4. Close the stop valve on the liquid side securely. (See
“Operating stop valve”.)
Insecure closing of the valve may result in burning of the
compressor.

5. When the low-pressure switch is activated, the unit stops
working. At this time, close the stop valve on the gas side.

This is the end of pumping-down operation. After pumping-down
operation, the remote controller can show the following pattern:

•“U4”

• blank screen

• indoor fan operates for about 30 sec.

even when ON button on the remote controller is pressed, and it
will not operate. Turn off the main power supply switch and turn
it on again in need of operation.

Wiring of power supply and the units

Refer to the installation manual attached to the indoor unit for
wiring of indoor units, etc.
Attach an earth leak detector and fuse to the power supply line.
(See figure 10).

I Pair
II Twin
III Triple
IV Double Twin
M Master
S Slave
1 Earth leak detector
2 Fuse
3 Remote controller

Power supply

Field fuseModel

R(Y)(P)200 25A H05VV-U5G H05VV-U4G2.5

R(Y)(P)250 32A H05VV-U5G H05VV-U4G2.5

Wire type

(*)

Size

Wiring size must

comply with the
applicable local

and national code

* Only in protected pipes, use HO7RN-F when protected pipes

are not used.

Wire type of wiring

between the units

6

TEST OPERATION

For the test run procedure, refer to the indoor unit installation
manual.

DISPOSAL REQUIREMENTS

Dismantling of the unit, treatment of the refrigerant, oil and
eventual other parts, should be done in accordance with the
relevant local and national regulations.

WIRING DIAGRAM

L :LIVE

:FIELD WIRING

N :NEUTRAL

:TERMINAL
:CONNECTOR
:WIRE CLAMP

:PROTECTIVE EARTH (SCREW)

BLK :BLACK
BLU :BLUE
ORG :ORANGE
RED :RED
WHT :WHITE
YLW :YELLOW

:DO NOT OPERATE THE UNIT BY SHORT-

CIRCUITING S1LP

:USE COPPER CONDUCTORS ONLY

L1 .....................................RED

L2 .....................................WHITE

L3 .....................................BLACK

N .......................................BLUE

A1P,A2P ........................... PRINTED CIRCUIT BOARD

BS1 ...................................PUSH BUTTON (FORCED DEFROST - PUMP

DOWN)

C1R,C2R ...........................CAPACITOR (M1F-M2F)

DS1 .................................. SELECTOR SWITCH (DEFROST)

F1C ...................................OVER-CURRENT RELAY

F1U,F2U ............................FUSE (250V,10A)

F3U ...................................FIELD FUSE

J1HC .................................CRANKCASE HEATER

K1M .................................. MAGNETIC CONTACTOR (M1C)

M1C .................................. MOTOR (COMPRESSOR)

M1F,M2F .......................... MOTOR (FAN)

PRC .................................. PHASE REVERSE CIRCUIT

Q1L,Q2L ........................... THERMO SWITCH (M1F-M2F)

Q3E ...................................EARTH LEAK DETECTOR

R1T ...................................THERMISTOR (AIR)

R2T ...................................THERMISTOR (COIL)

RC .................................... SIGNAL RECEIVER CIRCUIT

RyC ...................................MAGNETIC RELAY (K1M)

RyF1 .................................MAGNETIC RELAY (M1F)

RyF2 .................................MAGNETIC RELAY (M2F)

RyS ...................................MAGNETIC RELAY (Y1R)

S1LP .................................PRESSURE SWITCH (LOW)

S1PH ................................ PRESSURE SWITCH (HIGH)

SD .................................... SAFETY DEVICES INPUT

TC .....................................SIGNAL TRANSMISSION CIRCUIT

X1M .................................. TERMINAL STRIP

Y1R .................................. 4-WAY VALVE

FOR R22 ONLY

H1P .................................. LIGHT EMITTING DIODE (GREEN)

H2P,H3P ...........................LIGHT EMITTING DIODE (RED)

Q3L ................................... THERMO SWITCH (M1C)

S2PH ................................ CONTROL PRESSURE SWITCH (HIGH)

SS1 ................................... SELECTOR SWITCH (EMERGENCY)

T1R ................................... TRANSFORMER (230V/16V)

FOR R407C ONLY

A3P ................................... PRINTED CIRCUIT BOARD

DS2 .................................. SELECTOR SWITCH (VARIOUS: SEE PCB)

DS3 .................................. SELECTOR SWITCH (EMERGENCY)

HAP .................................. LIGHT EMITTING DIODE (GREEN)

H1P,H2P ...........................LIGHT EMITTING DIODE (RED)

R3T ................................... THERMISTOR (DISCHARGE)

RyCH ................................ MAGNETIC RELAY (J1HC)

RyR .................................. MAGNETIC RELAY (Y1S)

T1R ................................... TRANSFORMER (230V/20.1V)

Y1E ...................................EXPANSION VALVE

Y1S ................................... SOLENOID VALVE

7

Zandvoordestraat 300, B-8400 Oostende, Belgium 4PW10932-1A
