DV-K821DZ-RG/J _cover 00.11.10 4:36 PM ˘ ` 1
GB
English
Instruction manual
Hi-Fi Video cassette VQ857D
DV-K821DZ-RG/J(GB) 00.11.10 4:37 PM ˘ ` b
W OR T H
k n o w i n g
Please keep the video machine's guarantee card and receipt safe for warranty purposes.
Precautions
Read carefully through this manual to familiarize yourself with this high-quality video cassette recorder.
Make sure the rating of your household electricity supply matches that shown on the back of the video cassette recorder.
Refer to this chapter and the "Initial installation" chapter to help you install and adjust your video cassette recorder.
Do not ...
... expose the video cassette recorder to high levels of humidity and heat, to avoid the risk of fire and electric shock.
... open the video cassette recorder. Have a qualified technician carry out repairs.
... connect the video cassette recorder to the power supply if you have just moved it from a cold to warm environment. This can result in condensation inside the recorder and cause serious damage to the machine and cassettes. Wait around two hours to allow it to reach room temperature.
Make sure ...
... the recorder is placed on a steady, flat surface.
... you place the recorder where there is good ventilation all around.
... you clean the recorder only with a soft, lint-free cloth; do not use aggressive or alcohol-based cleaning agents.
... you disconnect the power supply if the recorder appears to be working incorrectly, is making an unusual sound, has a strange smell, has smoke emitting from it or liquids have got inside it. Have a qualified technician check the recorder.
... you disconnect the power supply and aerial if you will not be using the recorder for a long period or during a thunderstorm.
For your own safety!
There are no components in this video cassette recorder you can service or repair yourself.
Do not open the case of the video cassette recorder. Only allow qualified personnel to repair or service your set.
This video cassette recorder is designed for continuous operation. Switching it off does not disconnect it from the mains (stand-by). To disconnect it from the mains, you have to unplug it.
Recording any copyright protected material may infringe a copyright.
DV-K821DZ-RG/J(GB) 00.11.10 4:37 PM ˘ ` 1
W O R T H
Before doing anything with the machine, please read the chapter "Initial installation".
k n o w i n g
Contents
Controls |
|
The remote control unit .................................................................................... |
2 |
The machine, On screen display ...................................................................... |
3 |
Initial installation |
|
Connecting up the video cassette recorder, Fitting the remote control’s |
|
batteries ........................................................................................................... |
4 |
Setting up the video cassette recorder ........................................................... |
5 |
Playing cassettes |
|
Playing back ....................................................................................................... |
6 |
Still, Variable picture search, Variable slow motion, |
|
Accessing new recordings (index scan), CM Skip ........................................... |
7 |
Recording cassettes |
|
Simple recording .............................................................................................. |
8 |
One touch recording (OTR) ............................................................................... |
9 |
More functions |
|
Normal timer recording .................................................................................. |
10 |
Timer Review – changing and erasing, Setting time and date ..................... |
11 |
Clock/Counter display, Remaining time and Cassette length, |
|
Accessing counter zero position, Resetting the counter to zero ................. |
12 |
Menu languages, Child lock, Cassettes, and ... ............................................ |
13 |
The Hi-Fi system, What you can listen to........................................................ |
14 |
Choice of sound output .................................................................................... |
15 |
Tuning new stations |
|
Tuning ............................................................................................................. |
16 |
Station names ................................................................................................ |
17 |
Sorting programme locations, Clearing programme locations ...................... |
18 |
Connections and copying |
|
To the TV via antenna cable (if you are not using a RCA cable) ................... |
19 |
Copying, Assembling ...................................................................................... |
20 |
Appendix |
|
Brief instruction for experienced users .................................................... |
21/22 |
Before you ask a specialist ............................................................................ |
23 |
Index, Technical data ..................................................................................... |
24 |
On the following pages, the pictures show the buttons you press on the remote control to perform the function, and what you should see in the On Screen Display or machine display (if present).
1
DV-K821DZ-RG/J(GB) 00.11.10 4:38 PM ˘ ` 2
C O N T
R O L S
The remote control is the principle means of control, but the main playback and record functions are also available on the front of the machine.
Press any button to turn on the power.
The remote control unit
power on/off
max. 7 m.
30° 30°
TV/VCR
AV
A
number buttons to select programmes (stations) or to type in numbers
this button is not available for this set
a button for selecting input sources for recording: TV stations – input sockets
clock/counter on-screen display
|
|
|
Q.S |
1 |
2 |
3 |
TV/VCR |
4 |
5 |
6 |
AV |
A.D |
7 |
8 |
9 |
30 |
|
|
|
|
30 |
0 |
A.D |
Q.S |
this button is not available for this set
this button is not available for this set
CM skip button to cue the tape for 30 seconds
pause (record), still (playback)
playback start
playback stop
EJECT
SP/LP |
PR + MENU |
rewinding/fast forwarding a cassette from stop, or picture search backwards/forwards from playback mode
PAL/SEC |
OK |
|
the record or OTR button |
|
(One Touch Recording means: each time you press the |
||
|
|
|
|
– INDEX + |
PR – |
A.SEL |
button recording is extended by 30 minutes) |
|
|||
|
|
|
EJECT |
|
|
|
to eject the cassette |
SP/LP |
a button that doubles the maximum recording time for very |
|
long recordings |
|
the variable slow motion button |
PR + MENU |
|
The buttons to use are marked on the following pages.
OK
PR –
– INDEX +
PAL/SEC
A.SEL
the menu controls, programme (station) selection (PR +/–)
to search the beginnings of records (index)
this button is not available for this set
to select the sound output (if available)
2
DV-K821DZ-RG/J(GB) 00.11.10 4:38 PM ˘ ` 3
Press any button to turn on the power.
The machine
C O N T R O L S
standby/on
playback stop and ejecting the cassette
front input sockets for connecting a camcorder (left/right channels)
programme (station) selection
recording or OTR
(One Touch Recording means: each time you press the button recording is extended by 30 minutes)
rewinding / fast forwarding a cassette from Stop, or picture search backwards / forwards from playback mode.
playback start
On screen display
MAIN MENU |
|
VCR SETUP |
||
Timer Program |
|
|
|
|
PR Preset |
|
|
|
|
VCR Setup |
|
* |
16:9 Set |
|
Tape Control |
|
|
||
|
|
|
||
PR+/-:select |
|
example |
PR+/-:select |
|
OK:confirm |
MENU:end |
|
OK:confirm |
MENU:end |
MENU The video’s menu system
gives you easy-to- understand access to the less used functions such as tuning to stations, clock setting and more.
“Tape Control” Menu appears only when a tape is in the VCR.
PR –
2x
OK
The menus show you which button to press for the next step.
REW SP |
PR04 EURO |
|
STEREO ON |
In addition, some other functions appear on screen temporarily.
|
|
* Though the ”16:9 Set” is displayed on the screen, this function is not available for this set. |
3 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
DV-K821DZ-RG/J(GB) 00.11.10 4:38 PM ˘ ` 4
I n i t i a l
INSTALLATION
Place your video
horizontally on a flat, steady base so that air can circulate around it for ventilation.
away from humidity and heat, magnetic fields, such as those from loudspeakers etc., and with no heavy objects placed on top.
Connecting up the video cassette recorder
Switch off all components when connecting or disconnecting cables.
1 |
2 |
3 |
TV/VCR |
4 |
5 |
6 |
AV |
7 |
8 |
9 |
|
30 |
0 |
A.D |
Q.S |
EJECT
SP/LP |
PR + MENU |
PAL/SEC |
OK |
– INDEX + PR – A.SEL
|
|
OUT |
AC 230 V~ , |
|
|
50 Hz |
|
Unplug the aerial cable from your TV and plug it into the |
|
"ANT. IN" socket of the video.
Plug the short coaxial cable provided into the "ANT.OUT" socket of the video and the aerial socket of the TV.
Plug a RCA cable into the "RCA” socket of the video and the AV socket on the TV if available.
This connection will provide best picture and sound quality. Ask your dealer for an appropriate cable if you do not have one.
Without a RCA cable, you need to follow the steps described under "If you are not using a RCA cable" (right page and page 19).
Make sure the rating of the household mains supply matches the rating shown on the back of the video.
Now plug in the mains lead. The display of the video should now light.
Plug a phone cable into “Audio L, R” jack on the rear panel and into the Audio jack on any audio amplifier, if needed.
Fitting the remote control's batteries
The buttons to use are marked on the following pages.
1.5 V (AAA)
Fit the batteries the pictures
Protect your environment by returning used batteries to your dealer. Since batteries contain toxic substances they require special disposal methods.
Make sure the batteries are always of the same type and age, and remove them from the remote control if you are not using it for a long period.
4
DV-K821DZ-RG/J(GB) 00.11.10 4:38 PM ˘ ` 5
Switch the TV on.
You can also start "Auto Search" in the menu "PR Preset" "Auto Search".
To tune in new stations (manual tuning) and to enter station names see page 16-18.
Setting up the video cassette recorder
I n i t i a l
INSTALLATION
PR –
OK
OK
OK
MENU
LANGUAGE SET |
|
|
English |
|
You should see this picture the first |
Deutsch |
|
|
Italiano |
|
time you switch on the TV and video. |
Español |
|
|
Français |
|
|
Nederlands |
|
|
PYCCK |
|
Choose your language. |
SVENSKA |
|
|
PR+/-:select |
|
|
OK:confirm |
MENU:end |
|
Auto Search!
OK:confirm MENU:end
AUTO SEARCH
PR03
V-L - - - - - - - -- - - - - -
76%
MENU:end
AUTO SEARCH
Please wait...
CLOCK SET
Time - - : - -
Date - - / - - / - - - -
0-9:setup(hour)
/
:correct MENU:end
OK for "Auto Search!".
"AUTO SEARCH" tunes in all the stations you can receive in
your country and ...
... sorts them in an order common for your country.
Then type in the current time and date.
MANUAL SET |
Should you wish the stations to have the same numbers as |
|
PR01 P-01 |
PR08 P-08 |
those used on the TV, follow the instructions in "Sorting |
PR02 P-02 |
PR09 P-09 |
|
PR03 P-03 |
PR10 P-10 |
programme locations" on page 18. |
PR04 P-04 |
PR11 P-11 |
Else ... |
PR05 P-05 |
PR12 ---- |
|
PR06 P-06 |
PR13 ---- |
exit the basic installation function and enjoy your |
PR07 P-07 |
PR14 ---- |
|
PR+/-:select |
|
video cassette recorder. |
OK:confirm |
MENU:end |
If you don´t see this picture, because you don´t use a RCA cable, search this picture now (CH 52) with the station tuning functions of your TV set (see its user manual).
In case of interference problems on CH 52, type in an other transmission channel between 21 and 69 using the number buttons.
5
DV-K821DZ-RG/J(GB) 00.11.10 4:38 PM ˘ ` 6
P L AY I N G
c a s s e t t e s
Your TV and your video cassette recorder are switched on.
To see the picture from your video, press the station button on the TV reserved for video input or the AV (Audio/Video) button.
Playing back
|
Load the cassette by pushing |
|
it smoothly and squarely into |
|
the cassette bay, with its |
VHS |
windows pointing up. |
1 |
2 |
3 |
TV/VCR |
4 |
5 |
6 |
AV |
7 |
8 |
9 |
30 |
0 |
A.D |
Q.S |
|
|
|
L R |
A.SEL |
PLAY |
SP |
Hi-Fi |
|
|
|
L+R |
VCR
L R
Start playback.
If you hear an unintelligible, mixed sound output (bilingual sound), select one of the sound options.
Stop playback.
EJECT VCR
EJECT
SP/LP |
PR + MENU |
PAL/SEC |
OK |
– INDEX + |
PR – |
A.SEL |
L R
VCR
L R
VCR
L R
Eject the cassette.
Fast forward or rewind the cassette from stop.
When you load a protected cassette (e.g. pre-recorded film, see page 13) playback starts automatically.
PLAY switches back to normal playback.
During still, slow or search, you don’t hear the sound.
If the still picture is jittering, you can steady it by using the PR +/– buttons.
You can reduce horizontal interference stripes resulting from inaccurate tracking (when playing tapes of poor quality or recorded on other machines) by using the PR +/– buttons during playback.
After approx. 5 minutes in still, the cassette plays back automatically.
NTSC PLAYBACK on PAL TV ; If you playback the tapes, which have been recorded on NTSC color system, on this VCR, you can watch the pictures on a PAL TV.
Clock / Counter / Remaining time – page 12.
Auto Head Cleaning
This VCR has Auto Head Cleaner. The video head will be cleaned automatically whenever loading or unloading the tape.
6
DV-K821DZ-RG/J(GB) 00.11.10 4:38 PM ˘ ` 7
Still
Variable picture search
VCR +
VCR -
P L AY I N G
c a s s
e t t e s
Still picture from playback.
Each press of the button advances the picture one frame.
“PLAY” blinks during still.
PLAY switches back to normal playback.
Starting from playback you can control search speed in 2 steps either forwards ( ) or backwards (
). Press repeatedly.
PLAY switches back to normal playback.
Variable slow motion
VCR
Starting from playback you can control slow motion speed in 6 steps (1/15, 1/10, 1/5, 1/30, 1/25, 1/20, 1/15, ...). Press repeatedly.
PLAY switches back to normal playback.
Accessing new recordings (index scan)
Access the beginning of recordings in the middle of the tape using the Index + / – function.
The video cassette recorder automatically sets an electronic marker (index) at the beginning of each recording. It is these markers which the Index + / – function detects.
|
FF |
SP |
– INDEX + |
INDEX 01 |
|
|
|
|
|
0:11:09 |
Select INDEX + or INDEX – to search forwards or backwards.
The video will now wind to the beginning of the first recording, play it for about 6 seconds then wind on to the next one.
When you see the recording you want, press PLAY.
CM Skip
30 |
If you press [CM Skip] button on the remote control, tape advances for 30 |
|
|
|
seconds segment. |
7
