Daewoo SD-9800D User Manual

English

DVD-VIDEO PLA

YER

INSTRUCTION MANUAL

SD-9800D

- Region code of DVD/Video player is region “2” or ALL. Inserting a disc with another region code, it will not operate. Please only use a disc with region code 2 or ALL.

- is a ‘DO NOT’ mark. If this mark is displayed in operating the product, please wait for a while, then use it. If " DO NOT" mark continues to be displayed in pressing a button after that, it means the button does not function in the currently played disc.

- Press a product button on the REMOTE then use the product.

• DVD operation : [DVD] button

• Video operation : [VCR] button

Please read this manual carefully before connecting your DVD+VCR and operating it for the first time.

Keep the manual in a safe place for future reference.

Product information

Contents

Product Information

Important Safeguards ..................................................... 2

Advantages of This Product Are .... ............................ 5

Read Carefully before Using ......................................... 6

Identification of Controls ...............................................7

Remote Control ................................................................ 9

Installation

Connecting up your player with RF lead ................. 10

Connecting with Other VCR or Camcorder ..............12

Connecting with Audio ................................................ 14

Connecting to a television with Component jack and a

Dolby Digital Amp. ....................................................... 15

Basic Operation

Initial Installation ........................................................... 16

Setting time and date / OSD ON & OFF ................. 18

Output Select .................................................................. 19

DVD Playback ................................................................ 20

VCR Playback ................................................................ 21

Recording ........................................................................ 22

VCR Operation

Tuning in New Stations ................................................ 24

Timer Recording ............................................................ 26

More Functions .............................................................. 28

Connections and Assembling ..................................... 31

DVD Operation

Playing a desired scene ................................................ 33

Confirming the current PLAY mode on screen ....... 37

Selecting an AUDIO language, SUBTITLE language

and 3D AUDIO ...............................................................39

Selecting ZOOM and Multi Angle.............................. 40

About MP3 , JPEG discs ................................................ 41

Displaying menus in a disc........................................... 43

Set-up

Language Setup .............................................................. 44

Video Setup, Audio Setup ............................................ 45

Others Setup ................................................................... 46

The others

About DVD...................................................................... 47

Basic information about VCR and Videotape.......... 49

Before doubting about troubles (VCR)....................... 50

Before doubting about troubles (DVD) ..................... 52

Specifications .................................................................. 53

Important Safeguards

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and servicing instructions in the literature accompanying the appliance.

WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS

APPLIANCE TO RAIN OR MOISTURE.

CAUTION : TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT,

FULLY INSERT.

IMPORTANT FOR LASER PRODUCTS

• LASER :

This Digital Video Disc Player employs a Laser System. To ensure proper use of this product please read this owner’s manual carefully and retain for future reference. Should the unit require maintenance, contact an authorized service location - see service procedure.

Use of control adjustments or the performance of procedures other than those specified may result in hazardous radiation exposure.

To prevent direct exposure to the laser beam, do not try to open the enclosure. Visible laser radiation when open and interlocks defeated. DO NOT STARE INTO THE BEAM.

• DANGER : Visible laser radiation when open and interlock failed or defeated. Avoid direct exposure to beam.

• CAUTION : Do not open the top cover. There are no user serviceable parts inside the Unit; leave all servicing to qualified service personnel.

CLASS 1 LASER PRODUCT

CAUTION: Any changes or modification in construction of this device which are not expressly approved by

the party responsible for compliance could void the user’s authority to operate the equipment.

• Make sure the unit should be placed at least 8cm apart from the other home appliances or the obstacles to get sufficient ventilation.

• This unit shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on this unit.

• Switching it off does not disconnect it from the mains (stand-by). To disconnect it from the mains, you have to unplug it.

This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following procedures for installation, use and servicing. This unit is fully transistorized and does not contain any parts that can be repaired by the user.

1 READ INSTRUCTIONS

All the safety and operating instructions should be read before the unit is operated.

2 RETAIN INSTRUCTIONS

The safety and operating instructions should be retained for future reference.

3 HEED WARNINGS

All warnings on the unit and in the operating instructions should be adhered to.

4 FOLLOW INSTRUCTIONS

All operating and use instructions should be followed.

5 CLEANING

Unplug this unit from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

6 ATTACHMENTS

Do not use attachments unless recommended by the unit’s manufacturer as they may cause hazards.

7 WATER AND MOISTURE

Do not use this unit near water- for example, near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement, or near a swimming pool.

8 ACCESSORIES

Do not place this unit on an unstable cart, stand, tripod, bracket, or table. The unit may fall, causing serious injury to a child or adult as well as serious damage to the unit. Use this unit only with a cart, stand , tripod, bracket, or table recommended by the manufacturer.

A unit and cart combination should be moved

with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to overturn.

9 VENTILATION

Slots and openings in the case are provided for ventilation to ensure reliable operation of the unit and to protect it from overheating. These openings must not be blocked or covered. These openings must not be blocked by placing the unit on a bed, sofa, rug, or other similar surface. This unit should never be placed near or over a radiator or heat radiator. This unit should not be placed in a builtin installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

10 POWER SOURCES

This unit should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your dealer or local power company. For units intended to operate from battery power, or other sources, refer to the operating instructions.

11 GROUNDING OR POLARIZATION

This unit is equipped with a polarized alternating current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug still fails to fit, contact your electrician to replace your obsolete outlet.To prevent electric shock, do not use this polarized plug with an extension cord, receptacle, or other outlet unless the blades can be fully inserted without blade exposure. If you need an extension cord, use a polarized cord.

12 POWER-CORD PROTECTION

Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the unit.

Product information

Important Safeguards

PORTABLE CART WARNING

(symbol provided by RETAC)

Important Safeguards

13 LIGHTNING

For added protection for this unit during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the unit due to lightning and power line surges.

14 DISC TRAY

Keep your fingers well clear of the disc as it is closing. It may cause serious personal injury.

15 OVERLOADING

Do not overload wall outlets of extension cords as this can result in a risk of fire or electric shock.

16 OBJECT AND LIQUID ENTRY

Never push objects of any kind into this unit through openings as they may touch dangerous voltage points or “short-out” parts that could result in a fire or electric shock. Never spill liquid of any kind on the unit.

17 BURDEN

Do not place a heavy object on or step on the product. The object may fall, causing serious personal injury and serious damage to the product.

18 DISC

Do not use a cracked, deformed or repaired disc. These discs are easily broken and may cause serious personal injury and product malfunction.

19 SERVICING

Do not attempt to service this unit yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

20 DAMAGE REQUIRING SERVICE

Unplug this unit from the wall outlet and refer servicing to qualified service personnel under the following conditions. A. When the power-supply cord or plug is

damaged.

B. If liquid has been spilled, or objects have fallen

into the unit. C. If the unit has been exposed to rain or water. D. If the unit does not operate normally by

following the operating instructions. Adjust

only those controls that are covered by the operating instructions. Improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the unit to its normal operation.

E. If the unit has been dropped or the cabinet has

been damaged.

F. When the unit exhibits a distinct change in

performance-this indicates a need for service.

21 REPLACEMENT PARTS

When replacement parts are required, have the service technician verify that the replacements he uses have the same safety characteristics as the original parts. Use of replacements specified by the unit manufacturer can prevent fire, electric shock, or other hazards.

22 SAFETY CHECK

Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks recommended by the manufacturer to determine that the unit is in safe operating condition.

23 WALL OR CEILING MOUNTING

The product should be mounted to a wall or ceiling only as recommended by the manufacturer.

24 HEAT

The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

Product information

Advantages of This Product Are .....

• DVD, VCD, CD, CD-R(MP3), CD-RW, VHS

• Watching DVD for recording broadcast

• Integrated remote control (VCR, DVD)

• VISS function

• Multiplex sound playback/record

• High Sound Quality of 6 head Hi-Fi

• Simple record function

• MP3 file playback function (CD-R disc having records of MP3 files)

• GUI (Graphical User Interface) through OSD (On Screen Display)

By using the [DISPLAY] button on the remote control, information on the DVD/VCD/CD player and disc, can be displayed on the TV screen.

• Screensaver function (DVD)

• 3D sound (3D sound effect using 2 speakers)

• High bit / High sampling with 27MHz / 10bit video encoder

• High bit / High sampling with 96MHz / 24bit Audio D/A Converter

• Coaxial, Optical digital Audio output (PCM, Dolby Digital, dts)

You can enjoy high-level digital audio by connecting with amp embedded with Dolby Digital / dts decoder.

• Built-in Dolby Digital decoder (DVD)

• Analog audio 2-channels output for DOWNMIX (x1)

• Composite video output (x1)

• Slow Forward / Reverse playback (DVD)

• Fast Forward / Reverse playback

• Search of title, chapter, and time in DVD disc, and search of time and track time in VCD and CD

• Various TV aspect (DVD)

4:3 for Pan and Scan, 4:3 for Letter Box, and 16:9 for Wide

• Repeat playback (title, chapter, and part for DVD/ track, disc, and part for VCD/CD)

• Selective Play (DVD/VCD/CD)

You can select and play the desired title / chapter of DVD and track of Video CD/CD in STOP mode.

• 10 languages OSD (On Screen Display) function (DVD)

You can select and display OSD in 10 languages. (E/ F/ S/ G/ I/ D/ R/ C/ H/ P)

• Parental Lock function (DVD)

This function can prevent playback of software that may be unsuitable for children.

• Multi Audio function (DVD)

The audio soundtrack can be heard in up to 8 languages. In the case of SVCD or VCD, it depends on the disc. (The number of audio languages depends on the software.)

• Multi Subtitle function (DVD)

The subtitle can be seem in up to 32 languages. In the case of SVCD or VCD, it depends on the disc. (The number of subtitle languages depends on the software.)

• Multi Angle function (DVD)

This function allows you to choose the viewing angle of scenes which were shot from a number of different angles. (The number of angles depends on the software.)

• Screen zoom function (DVD/VCD)

Read Carefully before Using

Cautions in use of DVD-Video player are described below.

Please read carefully before using a DVD-Video player.

✔ Installation place and handling

• When you place this player near other devices, they may affect poorly together.

•

When you place DVD-Video player and TV in the upper and lower sides, it may cause flickering of pictures or failure (tape is not ejected).

• When you place this player near strong magnetic materials, it may affect image or voice poorly or damage recording.

•

Do not spill volatile liquids like insect spray over the player. Do not leave rubber or plastic products in contact with the player for a long time. They will cause deterioration or paint peel-off.

✔ Not in use

• When the unit is not in use, be sure to remove the disc or tape and turn off the power.

•

If you do not use the unit for a long period, remove batteries in remote control to prevent leakage.

• In case you don’t use the unit for a long time, the unit may not function properly in the future. Turn on and use the player occasionally.

✔ Moving

• Repack the unit as it was originally packed at the factory. Alternatively, pack this product with towel not to be damaged.

• Eject any videotape.

✔ Cleaning

• Dust off dirt in cabinet or control panel part smoothly with a soft cloth.

• For heavy dirt, soak the cloth in a weak detergent solution, wring it well and wipe. Use a dry cloth to wipe it out.

• Follow instructions in using chemical cleaners.

• Do not use any type of solvent such as gasoline or benzene, as they may cause deterioration or paint peel-off.

✔ Checking

• Video is a high precision device. To obtain a clear screen, we recommend regular inspection and maintenance every 1,000 hours of use by technical engineers.

• For checking, contact your dealer or your nearest service center.

✔ Checking and Replacement of Antenna

• Antenna is subject to change in its direction or damage by wind and rain. For clean screen,

contact and consult your nearest service center about checking and replacement.

✔ In recording important screen

• Be sure to record the screen and check whether recording is performed properly. We beg you to understand compensation of recording if recording is not performed by badness of used tape or video.

✔ Copyright

• Do not use your recordings without permission of a copyrighter except personal usage.

✔ Tape and Disc Handling

•

Do not use any tape and disc below. Damage of video head or cut/coiling of tape may cause failure.

- Tape with mold

- Tape or disc stained with juice or attachments

- Tape having breakage connection

- Disassembled tape

- Disc with severe scratch

• Moisture condensation may occur in tape.

Moisture condensation damages the tape. Please use the tape after the moisture condensation is disappeared.

• After use, store tape vertically in a case to

prevent loose.

• Do not store the following places.

- High temperature and humidity

- Subject generation of mold

- Subject to direct sunlight

- Much dirt or dust

- Near strong magnetic materials such as speaker

✔ Instructions in using REMOTE

• Operate remote control within 7m from the unit.

• Do not press 2(two) buttons at the same time.

• Do not light up sending and receiving part of remote control.

• Do not keep in the place with much dust and humidity.

REPEAT

OPEN/CLOSE

DISPLAY

TITLE/PBC

PR +

PR -

INPUT

PREV.

REC

PROGRAM

CLK/CNT

TV/VCR

TRACKING

ANGLE/SPEED

SYSTEM

PLAY/PAUSE

A-B

ZOOM

AUDIO

SUBTITLE

SETUP

CLEAR/3D

ENTER

VCR

DVD

Product information

Identification of Controls

Main body (front panel)

) 1

234

@ #

$ %

POWER (STANDBY/ON) button

Use to power the device on/off if AC power supply is connected.

Place to insert videotape

Disc tray

VIDEO INPUT jack

AUDIO INPUT jack

EJECT button

RECORD button

CHANNEL Up/Down button

(

Operation Display Window

Display operation of device. For more information, see “Operation Display Window” as belows.

)

SELECT button

Use to change DVD mode to VCR mode, and vice versa.

STOP button

Use to stop playing.

REWIND button

Use to rewind currently being played videotape or disc; or to playback back rapidly.

Playback/PAUSE button

Playback videotape or disc. Press this button to pause a screen.

FAST FORWARD button

Use to wind currently being played videotape or disc; or to playback rapidly.

OPEN/CLOSE Tray button

Operation Display Window

Time, Counter and Current Operation

Tray is opened Tray is closed Disc is loaded There is no disc in tray Disc has some error Menu screen is displayed Setup menu is displayed Power is ON Power is OFF

3D Sound Indicator DVD Disc Operation

VCR Operation REC and TIMER REC display

Recording , TIMER Recording , To be Timer-recorded, To be Timer-recorded state ERROR (No Tape or Tape without tab)

dts Disc Indicator

Title This is displayed in VCD and CD disc.

Chapter This is displayed in DVD disc.

Main body (Rear Panel)

Identification of Controls

ANT.IN

ANT. OUT

OUT

AUDIO

VIDEO

COAXIAL

DIGITAL

COMPONENT OUT

AUDIO OUT

OPTICAL

AUDIO OUT

DIGITAL

AUDIO OUT

POWER CORD

It is a jack for supplying power to the unit. Connect to outlet in a wall.

DIGITAL OUTPUT (OPTICAL/COAXIAL) Jack

To enjoy sound quality of theater level in home, connect this jack with amp or unit embedded with digital audio decoder.

A/V OUTPUT Jack

A/V INPUT Jack

AUDIO OUTPUT JACK

COMPONENT OUTPUT Jack

Connection to ANTENNA Cable

Connection to TV

Accessories

REPEAT

OPEN/CLOSE

DISPLAY

TITLE/PBC

PR +

PR -

INPUT

PREV.

REC

PROGRAM

CLK/CNT

TV/VCR

TRACKING

ANGLE/SPEED

SYSTEM

PLAY/PAUSE

A-B

ZOOM

AUDIO

SUBTITLE

SETUP

CLEAR/3D

ENTER

VCR

DVD

remote control 2 Batteries RF cable

Owner’s Manual/

Warranty

• To purchase accessories or not supplied parts additionally, contact your nearest dealer or service center. But, owner’s manual and warranty are not sold additionally.

Product information

Remote Control

REPEAT

OPEN/CLOSE

DISPLAY

TITLE/PBC

PR +

PR -

INPUT

PREV.

REC

PROGRAM

CLK/CNT

TV/VCR

TRACKING

ANGLE/SPEED

SYSTEM

PLAY/PAUSE

A-B

ZOOM

AUDIO

SUBTITLE

SETUP

CLEAR/3D

ENTER

VCR

DVD

@ #

& * (

)

1 2 3 4

7 8 9

“

‘ + = Q q W w E

[DVD]

MENU button

POWER button

[DVD]

TITLE /PBC button (“ PBC” means PlayBack

Control menu.)

[DVD]

OPEN/CLOSE button,

[VCR]

EJECT button

LEFT, RIGHT, UP and DOWN [ ] navigation buttons for on-screen menus. ' PR' for VCR channel selection. See page 16 ' Initial Set-up'

SETUP button

[DVD]

REPEAT Playback button

[DVD]

REPEAT a defined period from A to B button

(

[DVD]

PREVIOUS button (move into a previous

chapter or track)

)

REVERSE SEARCH button

[DVD, VCR]

PROGRAM button

[DVD, VCR]

CLOCK/COUNTER button

[VCR]

TV/VCR button

[VCR]

Record button

[DVD, VCR]

NUMBER button ,

[VCR]

TRACKING -/+

button

VCR SELECT button

DVD SELECT button

[DVD, VCR]

OSD DISPLAY button

[VCR]

INPUT Selection button

ENTER/OK button

“

CLEAR/ 3D button

‘

[DVD]

AUDIO LANGUAGE Select,

[VCR]

AUDIO

Select button

[DVD]

SUBTITLE Select button

[DVD]

NEXT button (Move into a next chapter or

track) ,

[VCR]

Frame Advance button in pause mode

PLAY/PAUSE button

FORWARD SEARCH button

STOP button

[DVD]

Chapter/Title/Time SEARCH button

[DVD]

ZOOM button

[DVD]

ANGLE,

[VCR]

Record SPEED button

Playback video standard selector (only on certain models)

Press the power [ ] button of the remote for about 5 seconds. No buttons of front panel can be operated

now and Lock indicator (“ ”) will be displayed on window display. To release child lock, press any button of the remote control.

Child Lock!!!

Connecting up your player with RF lead

(Option 1) -

How to connect with RF lead

■ Before you start, unplug all the equipment from the mains supply.

Aerial

The type of aerial you should use, depends on local interference and how far you are from the transmitter. You should contact a local retailer if you have any questions about your aerial.

In option (1) you need to tune your television to the player so you can see the picture from the player. When it is on the player generates a signal on UHF transmission channel 52, but this might change after tuning in the stations with 'AUTO-SEARCH' . See the 'Check it out' box on page 16. See your television manual for how to tune in a new channel.

INPUT 1

ANT IN

INPUT 2

DIGITAL

AUDIO OUT

REAR PANEL OF DVD-VIDEO

OUTSIDE ANTENNA OR

WALL ANTENNA OUTLET

REAR PANEL OF TV

RF CABLE

¡ Remove circular cable (RF cable) (surplus cable) plugged in “ANT.IN” jack in rear panel of TV.

Connect the cable to “ANT” jack in rear panel of DVD-Video.

™ Connect TV to DVD-Video. Connect “TV” jack in DVD-Video with “ANT.IN” jack in TV with RF

cable.

OPTICAL

ANT.IN

ANT. OUT

Installation

(Option 2) - How to Connect with Audio/Video jack

■ Before you start, unplug all the equipment from the mains supply.

INPUT 1

ANT IN

INPUT 2

DIGITAL

AUDIO OUT

REAR PANEL OF DVD-VIDEO

OUTSIDE ANTENNA OR

WALL ANTENNA OUTLET

REAR PANEL OF TV

RF CABLE

AUDIO/VIDEO CABLE

£ (If there is AUDIO/VIDEO INPUT jack in TV)

Connect VIDEO OUT jack in DVD-Video to VIDEO IN jack in TV, and AUDIO OUT jack in DVD-Video to AUDIO IN jack in TV with connecting cable of Audio/Video jack.

Select VCR mode by pressing TV/INPUT button in TV, you can view more clear screen and sound than connection with RF cable only.

• VHF: 2 ~12 channels of TV

• UHF: 21~69 channels of TV

• CATV: Broadcasting is transmitted with cable from broadcasting station by contract with the station and consumers. It does not need any antenna.

• In/Out jack in Audio/Video terminal:

- In: A jack used to receive signal required in this unit from other units.

- Out: A jack used to send signal of this unit to other units.

• Connect with Audio/Video terminal, you can enjoy more clear video and audio. (Use INPUT button in this REMOTE to select video mode.)

COMPONENT OUT

AUDIO

VIDEO

OUT

DIGITAL

AUDIO OUT

COAXIAL

OPTICAL

AUDIO OUT

ANT.IN

ANT. OUT

Connecting with Other VCR or Camcorder

How to Connect with Jack in Rear Panel

How to Connect with Jack in Front Panel

INPUT 1

OUT

VIDEO (L) AUDIO (R)

ANT IN

INPUT 2

REAR PANEL OF DVD-VIDEO

FRONT PANEL OF DVD-VIDEO

REAR PANEL OF PLAYBACK VCR(CAMCORDER)

REAR PANEL OF TV

RF CABLE

AUDIO/VIDEO CABLE

INPUT 1

OUT

VIDEO (L) AUDIO (R)

ANT IN

INPUT 2

REAR PANEL OF DVD-VIDEO

REAR PANEL OF PLAYBACK VCR(CAMCORDER)

REAR PANEL OF TV

AUDIO/VIDEO CABLE

RF CABLE

COMPONENT OUT

OUT

DIO

DIGITAL

AUDIO OUT

COAXIAL

DIGITAL

OPTICAL

AUDIO OUT

ANT.IN

ANT. OUT

AUDIO

VIDEO

COMPONENT OUT

OUT

DIGITAL

AUDIO OUT

COAXIAL

DIGITAL

AUDIO OUT

OPTICAL

AUDIO OUT

ANT.IN

ANT. OUT

Installation

How to Copy (Edit) Tape with Other VCR or Camcorder

¡ Connect AUDIO/VIDEO OUT jack in Camcorder(or playback video) to AUDIO/VIDEO IN jack

in rear panel (or front panel) of DVD-Video with connecting cable.

™ Connect “ANT. IN” jack in TV to “TV” jack in DVD-Video with RF cable. £ To record contents of camcorder or playback video with DVD-Video, insert recording tape attached

recording tab in DVD-Video.

¡ Turn on DVD-Video. ™ Press [INPUT] button of remote control and adjust DVD-Video to display “AV” or “AV.F” in TV

screen.

£ Press [PLAY] button in Camcorder or playback video. ¢ Press [REC] button in DVD-Video if you want to record contents of camcorder or playback video. ∞ Press [Pause] button in DVD-Video when unnecessary or undesired scene is displayed in

recording.

(Caution) Recording is released automatically after 5 minutes since pressing [PAUSE] button.

Press [REC] button if you want to record again.

How to Playback Chapter Photographed by Camcorder

¡ Turn DVD-Video on. ™ Press [INPUT] button of remote control and adjust DVD-Video to display “AV” or “AV.F” in TV

screen.

£ Insert tape in camcorder and playback it.

Connecting with Audio

How to Connect with Stereo Unit such as Audio

ANT.IN

ANT. OUT

OUT

AUDIO

VIDEO

COAXIAL

COMPONENT OUT

AUDIO OUT

OPTICAL

DIGITAL

AUDIO OUT

(L) AUDIO (R)

REAR PANEL OF DVD-VIDEOREAR PANEL OF STEREO UNIT

AUDIO CABLE

DIGITAL

AUDIO OUT

¡ Connect Audio jack. Connect AUDIO OUT in rear panel of DVD-Video to IN jack of stereo sound

unit.

™ For Input Select in stereo unit, Select “External Input” connected with DVD-Video. £ Playback DVD disc or Hi-Fi videotape, you can hear sound in speaker of stereo unit.

Installation

Connecting to a television with Component jack and a Dolby Digital Amp.

How to Connect

(NOT SUPPLIED)

ANT.IN

ANT. OUT

OUT

AUDIO

VIDEO

COAXIAL

COMPONENT OUT

AUDIO OUT

OPTICAL

DIGITAL

AUDIO OUT

DIGITAL

AUDIO OUT

(L) AUDIO IN (R)

REAR PANEL OF DVD-VIDEO

DOLBY DIGITAL DECODER-AMPLIFIER TV CONNECTIONS

COMPONENT IN

CONNECTING CABLE

■ Use in COMPONENT In jack attached in TV or amp supporting Dolby Digital.

Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby Laboratories.

Initial Installation

Setting up the player

■ Switch the TV on.

■ You can also start "AUTO SET" in the SETUP "PR PRESET"

➝

"AUTO SET".

■ To tune in new stations (manual tuning) and to enter station names see page 24-25.

SETUP:END

PLEASE WAIT...

CH 25

You should see this picture the first time you switch on the TV and player.

Select the wanted language with PR+ or PR- button. Press OK to confirm.

Press on the remote control and RF52 will be displayed on the front of your player.

Select a free channel on your TV and manual tune the channel until the blue screen as shown in step 2 appears. Refer to the TV manual for more details.

OK for "AUTO SET!".

"AUTO SET" tunes in all the stations you can receive in your country and sorts them in an order common for your country.

• If you don't see the menu picture below after you press the menu button it may be because you don't use a RCA cable and you need to tune the television to the player (see 'Connecting your player through RF lead' on page 10). Normally a new player outputs a signal via the RF lead on transmission channel 52. Search for the menu picture with the channel tuning function of your TV set (see its user manual). Some televisions allow you to key in the transmission channel number in their tuning set-up menu.

• In case there will be interference problems with other transmission channels when the player outputs a signal on transmission channel 52, the AUTO SEARCH process usually recommends an alternative, as in step 4.

• There is a another way of setting RF output channel, if needed please see 'Connections and Assembling on page 31'. It does not apply to models which do not generate the RF output signal.

CHECK IT!

If the clock has not been set, the clock setting screen will appear.

Please see “Setting time and date” on page 18

CLOCK SET

0-9:SETUP (HOUR) </>:CORRECT SETUP:END

TIME - - : - -

DATE - - / - - /- - - -

LANGUAGE SET

ENGLISH

PYCCKNZ

ÔESKY MAGYAR

PR+/-:SELECT OK:CONFIRM SETUP:END

Press the [OK] button to confirm the recommended RF channel.

Should you wish the stations to have the same numbers as those used on the TV, follow the instructions in "Sorting programme locations" on page 25.

Else ... exit the basic installation function and enjoy your player.

Should you wish the stations to have the same numbers as those used on the TV, follow the instructions in "Sorting programme locations" on page 25.

Else ... Press the SETUP button to exit the set-up menu and enjoy your player

PLEASE CHANGE THE TV CH TO 54.

IMPORTANT!

Basic Operation

RF OUTPUT SET

0-9:SELECT(21-69) OK:CONFIRM SETUP:END

CURRENT CH 52 RECOMMENDED CH 54

If other stations are positioned on near the current RF OUTPUT CH, the guide message appears automatically.

The player recommends the optimal RF OUTPUT CH number automatically.

• If the signal from the player is coming into the TV through the RF lead, the picture will disappear when you press OK at step 7. You will need to re-tune your television to the new UHF transmission channel.

MANUAL SET

PR01 P-01 PR08 P-08 PR02 P-02 PR09 P-09 PR03 P-03 PR10 P-10 PR04 P-04 PR11 P-11 PR05 P-05 PR12 ---PR06 P-06 PR13 ---PR07 P-07 PR14 ----

PR+/-:SELECT OK:CONFIRM SETUP:END

Up [PR+], down [PR-], OK and 'confirm'

• Notice the on-screen prompts which the video recorder generates to tell you which button to press. In general

the up and down 'navigation' buttons select or highlight something and the OK button confirms it .

• [PR+] and [PR-] are the same buttons as 'up' and 'down'.

• In the DVD section it is usually the left and right buttons which 'select'.

■ Press [VCR] button on the remote control to change into VCR Mode and follow the procedure

below.

Call the player’s "SETUP", choose "VCR SETUP", then "CLOCK SET".

Move to the position you want to change and type in the new values. Wait a few seconds after typing a one-digit number.

Store with [OK] button and exit with [SETUP] button.

CLOCK SET

0-9:SETUP (HOUR) </>:CORRECT SETUP:END

TIME - - : - -

DATE - - / - - /- - - -

CLOCK SET

0-9:SETUP (HOUR) </>:CORRECT OK:CONFIRM SETUP:END

TIME 06:05

DATE 08/06/2003(SUN)

Setting time and date

OSD ON & OFF

Call the player’s "SETUP".

Choose “VCR SETUP”. And press the [OK] button.

Select “OSD ON/OFF”. If you want OSD OFF mode, select it and press [OK] button to confirm. Then OSD characters are not displayed in the normal picture.

OSD (On Screen Display) ON & OFF

This player is set to “OSD (On Screen Display) ON” mode before shipping and you can change it to OFF mode.

VCR SETUP

CLOCK SET LANGUAGE SET RF OUTPUT SET OSD ON/OFF

PR+/-:SELECT OK:CONFIRM SETUP:END

OSD ON/OFF

ON OFF

PR+/-:SELECT OK:CONFIRM SETUP:END

SETUP

TIMER PROGRAM PR PRESET VCR SETUP TAPE CONTROL

PR+/-:SELECT OK:CONFIRM SETUP:END

Output Select

Press [DVD] button.

If DVD mode is correctly selected, DVD on the operation display window is lit. Then, REMOTE button works as DVD function. Press the [DVD] button, then the mode of DVD-Video Player becomes to the OPERATION mode.

To Select VCR

Press [VCR] button.

If VCR mode is correctly selected, VCR on the operation display window is lit and DVD goes out. Then, REMOTE button works as VCR function. Press the [VCR] button, then it becomes to the VCR OPERATION mode.

To Select Watch Modes or External Input

Press [INPUT] button.

When you press [INPUT] button, BROADCASTING RECEPTION and EXTERNAL INPUT is selected. But, it is not operated in PLAY, REC and DVD mode.

To Select DVD

Basic Operation

DVD Playback

Press [ ] button to power on.

Press [DVD] button of REMOTE to change into DVD mode.

Press [OPEN/CLOSE] button to open the disc tray.

Place a disc firmly on the disc tray, making its label look upward.

Insert the disc and press [OPEN/CLOSE] button to close the tray.

The disc tray is closed and after checking the disc’s condition, Playback or Stop function starts to operate.

To playback it, press [PLAY/PAUSE] button.

• In the case of DVD, DVD menus and titles are displayed on TV screen.

• In the case of S-VCD and VCD2.0 the menus are displayed on TV screen and it is converted into PBC(Playback Control) mode.

• In the case of CD, VCD1.1 and MP3, the disc plays in order of its track numbers.

To stop it, press [ ] button.

For pause, press [PLAY/PAUSE] button in playback mode. If you press this button once more, it starts playback again.

Press [OPEN/CLOSE] button to remove the disc.

REPEAT

OPEN/CLOSE

DISPLAY

TITLE/PBC

PR +

PR -

INPUT

PREV.

REC

PROGRAM

CLK/CNT

TV/VCR

TRACKING

ANGLE/SPEED

SYSTEM

PLAY/PAUSE

A-B

ZOOM

AUDIO

SUBTITLE

SETUP

CLEAR/3D

ENTER

VCR

DVD

Various Playback Methods

■ If you want fast forward (or reverse) playback, press [

√√√√

] or [

œœœœ

]button in Playback mode. You can watch fast playing (reverse ) screen. * This reverse playback can be unavailable for certain DVD. Unavailable for MP3.

■ If you want slow (or reverse) playback, press [

√√√√

] or [

œœœœ

] button in Pause mode.

You can watch the desired screen in the slow forward (reverse) playback.

* For the case of Video CD, this reverse slow playback function is unavailable. The

mark will appear.

■ If you want still picture, press [PAUSE] button in Playback mode. You can watch

the desired screen in Pause status.

Basic Operation

VCR Playback

Press [ ] button to power on.

Press [VCR] button of remote control to change into VCR mode.

Insert the desired tape.

If you want to playback it, press [PLAY/PAUSE] button.

When the operational status is flickering or poor, adjust it with [TRACKING +/-] button.

To stop it, press [ ] button.

For pause, press [PLAY/PAUSE] button in playback mode. If you press this button once more, it starts playback again.

Press [EJECT] button in the front part or [OPEN/CLOSE] button on remote control to remove the tape.

REPEAT

OPEN/CLOSE

DISPLAY

TITLE/PBC

PR +

PR -

INPUT

PREV.

REC

PROGRAM

CLK/CNT

TV/VCR

TRACKING

ANGLE/SPEED

SYSTEM

PLAY/PAUSE

A-B

ZOOM

AUDIO

SUBTITLE

SETUP

CLEAR/3D

ENTER

VCR

DVD

If the product, which has a auto-detector, detects a contaminated head(s), it shows the conditions to notice the contamination on screen.

* In case of the notice

on screen, please rub the heads with a headcleaner followed by “How to use a headcleaner”.

Various Playback Methods

■ If you want fast forward (or reverse) playback, press [

√√√√

] or [

œœœœ

] button in

Playback mode. You can watch fast playing (rewinding) screen.

■ If you want Still picture, press [PLAY/PAUSE] in Playback mode. You can watch

the desired screen in pause status.

■ If you want slow-motion playback, press [

√√√√

] button in Pause mode. You can

watch the desired screen in the slow forward playback.

* NOTE: VCR doesn’t have Slow Reverse Playback function.

■ If you want to watch a series of screens one by one, (FRAME ADVANCE) press

[NEXT

√√√√

❚ ] button in Pause mode. Each time you press this button, the picture

advances one frame.

To Adjust Display

This product includes automatic Tracking function and enables users to enjoy clear picture without an additional operation. Provided that the following problems can be solved by the manual adjustment, which improves display quality. (During automatic display adjustment, “Adjusting Display” are displayed on TV screen.)

- If the screen is poor in Playback mode,

- If noises occur in the upper or lower part of screen in slow playback mode,

- If paused picture vibrates up and down. Use [TRACKING +/-] buttons of remote control to adjust the display suitable for watching.

To Enjoy Another TV Channel or DVD during recording

1 If you want to watch another TV channel during recording with video, press

[TV/VCR] button.

It is available of changing into and watching another TV channel.

2 If you want to playback DVD during recording with video, insert a DVD disc.

Place the desired DVD disc on DVD tray, press [DVD] button to convert OUTPUT into DVD mode and press [PLAY] button. Then, you can watch DVD.

Press [ ] button to power on.

• Press [VCR] button of remote control to change into VCR mode.

Insert a recordable tape.

Insert a tape with recording tab.

With [CHANNEL], [NUMBER] and [INPUT] buttons, select the desired broadcasting channel or external input unit to record.

To Record With VCR

Select the desired speed (SP or LP) with [SPEED] button.

Press [REC] button.

Then, it starts recording.

If you want to pause recording, press [PAUSE] button.

After pressing [PAUSE] button, if the pause status continues for five minutes, the recording is released automatically.

To exit recording, press [STOP] button.

REPEAT

OPEN/CLOSE

DISPLAY

TITLE/PBC

PR +

PR -

INPUT

PREV.

REC

PROGRAM

CLK/CNT

TV/VCR

TRACKING

ANGLE/SPEED

SYSTEM

PLAY/PAUSE

A-B

ZOOM

AUDIO

SUBTITLE

SETUP

CLEAR/3D

ENTER

VCR

DVD

Recording

Basic Operation

Recording

This product incorporates copyright protection technology that is protected by method claims of certain U.S patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

To Copy From DVD To Videotape

1 Insert the desired DVD disc.

When it is a DVD disc with copy protect function, you can’t copy it.

Insert a recordable tape.

2 Press [REC] button during playing of DVD.

DVD plays and VCR starts recording.

3 If you press STOP [ ] button in DVD mode, DVD and VCR will stop at the

same time.

If you press STOP [ ] button in VCR mode, VCR stops to record and DVD continues to play.

One Touch timer Recording (OTR)

■ When your urgent business happens suddenly in watching TV or you want to record the current TV

program for the desired time, follow the procedures below.

1 First, follow the steps 1 to 4 in “Recording With VCR”.

2 Press [REC] button as much as you want. See the “Recording Times Table”

below.

Once continuous recording until you press STOP button Twice recording for 30 mins from current time 3 (times) recording for 1 hour

9 recording for 4 hours

22 returning to the status of Once Press

3 To stop Recording mode, press [STOP] button more than 5 seconds.

Tuning in New Stations

Tuning

■ The TV and player are switched on.

■ To see the picture from your player, press the station button on the TV reserved for player input or

the AV (Audio / Video) button.

To complete the set-up of your video recorder when the auto set has not stored all of the channels or when you wish to store a new channel. Call the video’s "SETUP", choose "PR PRESET".

Select "MANUAL SET".

Choose any unused location number "----" or "P-xx" ...

It's simplest to use the same location number on both the TV and video.

... and confirm.

Set the station you want:

• the programme location number;

• the proper broadcast system for your location (BG/DK)

• the broadcast system you want (Aerial(CH) or Cable(CC)),

• You can directly enter the real channel number with the [0 to 9] buttons, or search by pressing [< / >],

• The fine tuning you can adjust,

• Change or create the station name.

Once you see the station you want, store it.

Tune in further stations (from step 3 onwards) or exit tuning mode.

PR PRESET

AUTO SEARCH MANUAL SET PR ERASE PR ALIGN

PR+/-:SELECT OK:CONFIRM SETUP:END

MANUAL SET

PR01 P-01 PR08 P-08 PR02 P-02 PR09 P-09 PR03 P-03 PR10 P-10 PR04 P-04 PR11 P-11 PR05 P-05 PR12 ---PR06 P-06 PR13 ---PR07 P-07 PR14 ----

PR+/-:SELECT OK:CONFIRM SETUP:END

MANUAL SET

PR+/-: UP/DOWN

</>: SELECT

OK:CONFIRM SETUP:END

PR 04 STANDARD BG RECEPTION AERIAL AUTOSEARCH CH

_ _ FINE TUNING NAME

_ _ _ _

MANUAL SET

PR+/-: UP/DOWN

</>: SELECT

OK:CONFIRM SETUP:END

PR 03 STANDARD BG RECEPTION AERIAL AUTOSEARCH CH 03 FINE TUNING NAME

_ _ _ _

MANUAL SET

PR+/-: UP/DOWN 0/1: CHANGE/CREATE OK:CONFIRM SETUP:END

PR 03 STANDARD BG RECEPTION AERIAL AUTOSEARCH CH

_ _ FINE TUNING NAME

_ _ _ _

Station names

■ If your player is showing no station name or is showing a station name incorrectly, you can correct

this.

Call this menu (just see the previous page), if it isn't displayed.

Select NAME position. Press the [0] button to change the given name. Or press the [1] button to create the station name.

Either select the name from the stored list or you create the station name and enter a 4-digit name. Change the letters with the [PR +/–] buttons, move to the next letter with the [< / >] buttons.

Store and exit.

MANUAL SET

PR+/-:SELECT OK:CONFIRM SETUP:END

PR01 P-01 PR08 P-08 PR02 P-02 PR09 P-09 PR03 P-03 PR10 P-10 PR04 P-04 PR11 P-11 PR05 P-05 PR12 ---PR06 P-06 PR13 ---PR07 P-07 PR14 ----

Sorting programme locations

If the location numbers used for programmes stored in your TV and player are different, you can change them on the player. To do this, move the stations to the right numbers, until they are arranged the way you want.

1 Call the player’s "SETUP",

choose "PR PRESET" then "PR ALIGN".

Select the programme to swap.

Confirm by pressing OK button. Move the station to the desired location number. Confirm by pressing OK button.

Clearing programme locations

1 Call the player’s "SETUP",

choose "PR PRESET" then "PR ERASE".

2 Select the station (location number) you want to clear.

Review the picture by pressing [<] button.

Clear by pressing OK button.

PR ERASE

PR+/-:SELECT

< :PR VIEW

OK:ERASE SETUP:END

PR ALIGN

PR+/-:ALIGN

< :PR VIEW

OK:CONFIRM SETUP:END

PR01 P-01 PR08 P-08 PR02 P-02 PR09 P-09 PR03 P-03 PR10 P-10 PR04 P-04 PR11 P-11 PR05 P-05 PR12 ---PR06 P-06 PR13 ---PR07 P-07 PR14 ----

Tuning in New Stations

VCR Operation

MANUAL SET

PR+/-: UP/DOWN 0/1: CHANGE/CREATE OK:CONFIRM SETUP:END

PR 01 STANDARD BG RECEPTION AERIAL AUTOSEARCH CH01 FINE TUNING NAME

_ _ _ _

MANUAL SET

PR+/-: SELECT CHARACTER

</>: SELECT POSITION

OK:CONFIRM SETUP:END

PR 01 STANDARD BG RECEPTION AERIAL AUTOSEARCH CH

_ _ FINE TUNING NAME O

_ _ _

Timer Recording

Normal timer recording

Call the player’s "SETUP", choose "TIMER PROGRAM". Decide if you want to record "ONCE", "WEEKLY" or "DAILY"... ... and confirm.

Type in one after the other:

• The programme location number;

• the time the broadcast starts,

• the time the broadcast ends,

• the day of the broadcast, if it is not today.

• Select LP if you wish to make a very long recording .

If you wish to make changes: Move to the position you want to change using the [< / >] buttons. Change the setting using the [PR+/- ] or [number] buttons. If all setting are ok, press [< or >], till you see “OK : CONFIRM” in the bottom line. Confirm.

Switch your player off.

• Wait a few seconds after typing a one-digit-number.

• If you have made a mistake, move to the position you want to change using the [< / >] buttons and change the setting.

• If programme timings overlap, the machine will give a warning message. If you don’t adjust the times, the machine will record the first programme completely then continue with the second one.

• If there is no sufficient free space for the recording on the cassette the video switches automatically to “LP” for double recording capacity.

• The recorder will eject cassettes which have the safety tab removed.

PR+/-:SELECT(AV) 0-9 :SETUP(PR) </>:CORRECT SETUP:END

PR -START TIME --:-END TIME --:-START DATE --/-TAPE SPEED SP

TIMER PROGRAM (ONCE)

PR 01 START TIME 18:10 END TIME 20:30 START DATE 20/06(FRI) TAPE SPEED LP

PR+/-:SELECT(AV)

0-9 : SETUP (PR)

</>:CORRECT

OK:CONFIRM SETUP:END

TIMER PROGRAM (ONCE)

HOW OFTEN DO YOU WANT

TO RECORD THIS PROGRAM?

PR+/-:SELECT OK:CONFIRM SETUP:END

ONCE WEEKLY(ONCE A WEEK)

DAILY(MON-FRI) DAILY(MON-SAT) DAILY(MON-SUN)

■ For timer recordings, clock, date, and stations must be set correctly.

■ Load a cassette with its safety tab in place and with sufficient free space for the recording.

■ Press the [VCR] button to assume control of the VCR part.

■

The up [PR+], down [PR-], left [<] and right [>] buttons are illustrated on page 16, 'Initial Set-up and tuning'.

VCR Operation

Timer Recording

Timer Review – changing and erasing

Call the player’s "SETUP", choose "TIMER PROGRAM".

Select the programming to change or erase. If you want to erase this programming press button [0], confirm with OK. If you wish to make changes: Move to the position you want to change using the [< , >] buttons. Change the settings using the [PR +/–] or [number] buttons. If all settings are ok, press [< or >], until you see "OK: CONFIRM" in the bottom line. Confirm changes with [OK]. Exit the menus.

TIMER PROGRAM

PR START END DATE 03 21:20 22:20 14/06

01 18:10 20:30 20/06

-- -- : -- -- : -- -- / --

PR+/-:SELECT OK:CONFIRM SETUP:END

TIMER PROGRAM (ONCE)

PR 03 START TIME 21:20 END TIME 22:20 START DATE 14/06(SAT) TAPE SPEED SP

0 :ERASE

</>:CORRECT SETUP:END

More Functions

Clock / counter display

■ The counter counts in real time from the point you load the cassette. This does not have to be its

beginning! The counter does not count unrecorded parts of the tape.

■ If you rewind beyond the zero position, the counter counts in negative values (e.g. – 0:01:15).

Each time you press [DISPLAY] button, 1x: Time and date+current status ➝Time and date 2x: Counter+current status ➝counter 3x: disappear.

But if you press [CLK/CNT] button, clock and counter on display window will change each other.

• If didn’t wind tape (PLAY, FF, REW,...), it doesn’t appear the tape remain time.

STOP SP PR01 ARD

14:00 08/06 E180 00:48

STEREO ON

Accessing counter zero position

The player will wind to the position 0:00:00 and stop.

Remaining time and cassette length

When you want the player to show the time remaining from the current player tape position (to find out if there is sufficient space for a recording, for example). To ensure the remaining time shown is accurate, select the length of cassette currently loaded by selecting this function until you reach the correct length.

Call the player’s "SETUP", choose "TAPE CONTROL"

• Remaining time display is only possible when the cassette is loaded.

TAPE CONTROL

TAPE REMAIN

E-240 01:27

TAPE REMAIN GO TO ZERO COUNTER RESET INDEX+ INDEX-

E-180 E-240 E-300

PR+/-:SELECT OK:CONFIRM SETUP:END

REW SP GO TO ZERO

0:02:13

Resetting the counter to zero

Reset the counter.

COUNTER RESET

0:00:00

Searching a recorded program with index (VISS)

When you record a program, the VCR places an index mark at the start of the recording. To search fo an index mark

1. Call the player’s "SETUP", choose "TAPE CONTROL"

2. Choose index + to search forward or index - to search backward. The player will locate your index mark and begin playback.

TAPE CONTROL

TAPE REMAIN GO TO ZERO COUNTER RESET INDEX+ INDEX-

PR+/-:SELECT OK:CONFIRM SETUP:END

and ...

Dimmer : Your player dims its display when switched to stand-by mode. Auto power off : Your player switches to stand-by when no tape is played and no station is received for more

than 5 minutes.

VCR Operation

AUTO REPEAT

If you press the [PLAY] button for 5secs during stop or still mode, it goes Auto repeat mode. This player plays repeatedly the tape from the beginning to end parts.

To release this mode, press the [ ] button or mode operation button. (PLAY, FF, REW or STOP)

SETUP languages

Call the player’s "SETUP", choose "VCR SETUP", then "LANGUAGE SET".

Select your language. Confirm.

Child lock

Press the [ ] button for about 5 seconds. No buttons of front panel can be operated now and LOCK INDICATOR (“LOCK”) will be displayed on window display. Keep your remote control in a safe place. To release child lock, press any button of the remote control.

Cassettes

Use only good quality tape cassettes with the VHS logo.

•Keep cassettes away from excessive moisture or dust, magnetic and electrical fields (loud speakers and computer monitors, for example).

•Always wind the tape to the beginning when you have finished. Store with the full spool at the bottom and with the cassette in its cover.

You can protect your precious recordings from being wiped by breaking out the safety tab on the side of the cassette (some cassettes have a slide). Should you wish to re-use the tape after removing the tab, cover the hole with adhesive tape.

PAL

More Functions

LANGUAGE SET

ENGLISH

PYCCKNZ

ÔESKY MAGYAR

PR+/-:SELECT OK:CONFIRM SETUP:END

The Hi-Fi system

■ The player machine records the complete sound signal transmitted by the TV station.

■ On the mono VCR, you will hear the normal mono sound.

In addition to the normal mono sound track of VHS video recorders, your player machine is equipped with a high-quality Hi-Fi sound system.

This means you can enjoy

• films with excellent stereo sound

• films of full-length concerts in high quality stereo

• films with impressive Surround Sound using additional Surround equipment

• films with two dialogue modes (dual, bilingual), usually the original sound track and dubbed sound track

• VHS cassettes with Hi-Fi stereo sound and VHS cassette with normal sound

What you can listen to

During Stop, the player displays what the current station is broadcasting. When you switch to another station or the current station changes the sound mode, your player displays the programme and sound mode on screen (if not, press AUDIO).

• “STEREO” = stereo “BIL I / BIL II ”=bilingual

nothing= monaural sound

During Playback, the player displays what is recorded on the cassette (if not, press AUDIO).

• “Hi-Fi” = stereo/bilingual nothing = monaural sound

STOP SP PR10 EURO

STEREO ON

PLAY SP Hi-Fi

L+R

Choice of sound output

During a stereo performance (playback-”Hi-Fi”/ broadcast

- “STEREO”): Hi-Fi stereo ➝left audio channel only ➝ right channel only ➝ the normal mono sound track of a Hi-Fi cassette

• During broadcasting a bilingual performance : Main language (original sound track) ➝sub-language (dubbed) ➝both main language and sub-language

➝

OFF.

• For mono performances , there is no choice available.

PLAY SP Hi-Fi

L+R HI-Fi LEFT

Hi-Fi

RIGHT Hi-Fi OFF

More Functions

STOP SP PR10 EURO

BIL

BIL I

BIL

I+II

BIL OFF

VCR Operation

Connections and Assembling

To the TV via antenna cable (if you are not using a RCA cable)

■ If you are using a RCA cable, select the AV input on the TV to see the picture from the player.

■ If you are not using a RCA cable, select the button number on the TV reserved for video input to

see the picture from the player.

If you are not using a RCA cable, your player can transmit pictures and sound to the TV via the coax aerial cable. Just tune the TV to the player's transmitting channel (factory set to UHF CH 52). Tune the TV carefully to ensure the best pictures and sound.

Once you have carried out the steps in "Connecting up the player" , switch on your TV. Press the [OK] button of the player’s remote control longer than 5 seconds to call the player´s test picture. Tune the TV to the test picture using the channel pre-set functions of your TV as described in its manual. When you have found the test picture, store it under the button number on your TV for player input. Press the [OK] button of the player’s remote control again longer than 5 seconds to release the test picture.

• If the quality of the test picture transmitted to the TV is poor due to interference caused by a station transmitting on channel 52, you can tune the player to a different transmitting channel. Find a free channel between 21 and 69 on your TV.

Call the player’s "SETUP" choose "VCR SETUP" then "RF OUTPUT SET".

Type in the free channel.

Store and exit.

• If the quality of the test picture transmitted to the TV is poor, fine-tuning on the TV may help (refer to the TV manual).

• Without a scart cable, you will not get stereo sound from a TV capable of stereo sound.

RF OUTPUT SET

0-9:SELECT (21-69) </> :SELECT (BG/DK) OK:CONFIRM SETUP:END

CH 52 SYSTEM BG DK

Connections and Assembling

Assembling

Should you wish to assemble your own film, from camcorder footage for example, use the assembly technique for smooth edit points:

• Move the tape to the position at which the new scene is to be added using the play functions.

• Wind back slightly before the edit point and put the machine into pause using the [PAUSE] button (do not press STOP!).

• Now go directly into record.

For the best results, the source cassette from which you are recording should already be playing back when you start recording.

DVD Operation

Playing a desired scene

To skip scenes in a disc

To move to next chapter (or track), press [

√√❚

NEXT] button.

The current chapter (or track) moves to the next chapter (or track).

Press [

❚œœ

PREV] button.

The current scene moves to the previous chapter (or track) or first scene of current chapter (or track).

Directly moving to a desired title

Press the [TITLE/PBC] or [MENU] button.

A list of the titles on the disc is displayed.

* For the case of VCD disc, menu screen will

appear only when the disc has PBC function and PBC ON is activated.

Press the [ENTER] button or [PLAY] button after pressing the [ ] button to

select the desired title.

The selected title now starts playing.

■

Some movie discs may contain multiple titles. If the disc has a movie title menu recorded on it, the [TITLE/PBC] or [MENU] button can be used to select the movie title. Details of operation may differ depending on the disc used.

* Selecting a title may not be available on certain DVD discs.

Playing a programmed order

While STOP or Playback, press [PROGRAM] button.

While the right figure is appearing, please input desired Title and Chapter number with NUMBER buttons. Press [ENTER] to memorize. Then input next number.

* In case of VCD and CD, please input TRACK

Number.

After completing setting, press [PLAY] button.

Then, titles and chapters (track) are played in the above-programmed order. To exit from Program Play mode, press [PROGRAM] button.

PROGRAM

TITLE CHAPT SEL.

000 1-54

TITLE CHAPT TITLE CHAPT 01 - - - - - 06 - - - - 02 - - - - - 07 - - - - 03 - - - - - 08 - - - - 04 - - - - - 09 - - - - 05 - - - - - 10 - - - - -

PRG.PLAY : PLAY SELECT : ENTER EXIT : PRG.

Playing desired scene

To cancel, move the cursor to the desired parts and press [CLEAR] button.

Repeating a defined period

• CHAPTER : Current chapter will be repeatedly playback.

• TITLE : Current title will be repeatedly playback.

• TRACK : Current track will be repeatedly playback.

• DISC : Current disc will be repeatedly playback.

• RANDOM : Tracks in the disc will be playback in random order.

• FOLDER : Current folder will be repeatedly playback.

• OFF : Repeat playback will be cancelled.

Each time you press [REPEAT] button in playback mode, repeat playback starts as below.

• DVD •

CHAPTER

TITLE

OFF

➝➝

➝

• VCD •

TRACK

DISC

OFF

➝➝

➝

• CD •

TRACK

DISC

RANDOM

➝➝

OFF

➝

• MP3 •

TRACK

FOLDER

RANDOM

➝➝

OFF

➝

Playing desired scene

DVD Operation

Repeating a defined period from A to B

■ You may repeat a defined period from A to B.

A MP3 disc may not be repeated from A to B.

At the point where you want to start the repeat playback, press [A-B] button.

The right figure appears and repeat playback start position (A) is set.

At the point where you want to end the repeat playback, press [A-B] button again.

The repeat playback end position (B) is set and a defined period from A to B is playback repeatedly.

To exit from repeat playback mode, press [A-B] button.

It enters into Normal Playback mode.

A-

A-B

OFF

Searching DVD with a title number, a chapter number or a time

If you want to search with a title number, press [SEARCH] button one time.

It shows current and total title numbers. Please enter the new title number to be searched using the [NUMBER] buttons.

If you want to search with a time, press [SEARCH] button three times.

Please enter the new time to be searched using the [NUMBER] buttons.

In completing entering, please press [ENTER] button.

PLAY starts from the selected position.

If you want to search with a chapter number, press [SEARCH] button twice.

It shows current and total chapter numbers. Please enter the new chapter number to be searched using the [NUMBER] buttons.

001/003

➟

total title number

➟

current title number

001/023

➟

total chapter number

➟

current chapter number

01:03:20

➟

total time

Playing a desired scene

Searching VCD, CD and MP3 with a track or track time

If you want to search with a track number, press [SEARCH] button one time.

In case of PBC OFF, the screen like the right figure appears. It shows current and total track numbers. Please enter the new track number to be searched using the [NUMBER] button.

* If it is PBC ON, pressing track number converts PBC

to OFF mode automatically.

In completing entering, please press [ENTER].

PLAY starts from the selected position.

If you want to search with a track time, press [SEARCH] button twice.

In case of PBC OFF, the screen like the right figure appears. It shows total track time. Please enter the new time to be searched using the [NUMBER] button.

001/013

➟

total track number

➟

current track number

01:03:20

➟

total time

DVD Operation

Confirming the current PLAY mode on screen

Confirming the current DVD disc mode

While in playing, press [DISPLAY] button.

It shows the current disc mode. If you want to change the mode, select the item with up/down cursor and enter the new settings with [number], [<] or [>] button. In completing entering, press [ENTER] button. To exit from Display mode, press [DISPLAY] button again.

Confirming the current SVCD/VCD2.0 disc mode

While in playing, press [DISPLAY] button.

DISPLAY

001/003

001/023 00:01:03 1/3 ENG 1/3 ENG OFF 1/4

➟

channel number at current title / total title number

➟

channel number at current chapter / total chapter number

➟

time elapsed

➟

channel number at current subtitle / total subtitle number / subtitle selected

➟

channel number at current audio language / total audio language number / audio language selected

➟

repeat playback mode

➟

channel number at current angle / total angle number

DISPLAY

001/003

00:10:54 OFF OFF

➟

channel number at current track / total track number

➟

time elapsed

➟

repeat playback mode

➟

PBC mode

Confirming the current PLAY mode on screen

Confirming the current VCD, CD, MP3, JPEG disc mode

While in playing, press [DISPLAY] button.

DISPLAY

001/005

00:07:13 OFF

➟ channel number at current track / total track number ➟ time elapsed ➟ repeat playback mode

DVD Operation

Selecting an audio language

Selecting an AUDIO language, SUBTITLE language and 3D AUDIO

■ The user may select an audio language and subtitle language if a disc includes Multi-language.

Keep pressing [AUDIO] button till the user’s preferred language appears in playback mode.

If DVD disc includes audio information, every time the user presses [AUDIO] button, English (ENG), French (FRE), Spanish (SPA) and others appear one by one.

Selecting a subtitle language

Keep pressing [SUBTITLE] button till the user’s preferred language appears in playback mode.

If a DVD disc includes subtitle information, every time the user presses [SUBTITLE] button, English (ENG), French (FRE), Spanish (SPA), ... and OFF appear one by one.

A certain disc may not support audio select or subtitle select.

Selecting 3D Audio

If you want to adjust Sound Fields, press [3D] button.

Every time the user presses [3D] button, a 3D sound

changes 3D ON ➝3D OFF ➝3D ON .... one by

one.

■ Sound Fields can be set.

01/03 ENG

AUDIO : DOLBY D

➟

current audio type

channel number at current audio language

➟

total audio language number

➟

current audio language

➟

3D ON

3D OFF

01/03 ENG

➟

total subtitle language number

➟

channel number at current subtitle language

➟

current subtitle language

Selecting ZOOM and Multi Angle

Using a zoom function

■ The user can enlarge the current screen about 2 or 4 times.

Keep pressing [ZOOM] button till the preferred zoom appears.

Every time the user presses [ZOOM] button, a zoom magnification changes 2 times (X2)

➝

4 times (X4)

➝

OFF ➝2 times (X2) ➝... one by one. A base point to be enlarged is centre and the point can

be changed with the operation of [ ] button.

Different Angle

■ If a disc includes multi angle information, the user can watch a screen in multi angles. The function is limited

to a DVD disc supporting multi angle information.

Keep pressing [ANGLE] button till the preferred angle appears.

Every time the user presses [ANGLE] button, an angle degrees changes in a consecutive order.

• For the case of SVCD and VCD, only 2 times Zoom is available.

• During 4 time zoom, subtitle language can’t be seen.

X 2 _ _ _ _ _

_ _ _ _ _

X 4 _ _ _ _ _

_ _ _ _ _

01/03

➟

total screen angle numbers

➟

channel number at current screen angle

DVD Operation

Playing a disc containing MP3, JPEG files

About MP3, JPEG discs

This unit will play MP3, JPEG files recorded on CD-R and CD-RW discs.

Turn on your television and select the channel assigned to this DVD player.

Press the DVD open [OPEN/CLOSE] button, the disc tray opens.

Put a disc containing MP3, JPEG files on the disc tray with the label side up.

Press the DVD open [OPEN/CLOSE] button, the disc tray closes.

The unit will take a short while to load the disc and display the directory structure.

The below figure appears.

Select your disc type.

Move the cursor to FILTER by pressing [ ] button.

Keep pressing [ENTER] button till the user’s preferred disc type. Every time the user presses [ENTER] button, disc type changes MIXED ➝MP3 ONLY ➝JPG ONLY ➝MP3 AND JPG ➝MIXED

➝

... one by one.

DISC:

FILTER MIXED REPEAT OFF

00:00 / 00:00

❑

… † œ √ ENTER MENU

DIR--01 DIR--02 DIR--03

➟ ➟

Name of current directory

Location of current cursor

Current disc type selected Current repeat

mode selected

DISC:

DIR--01 DIR--02 DIR--03

FILTER MP3 ONLY REPEAT OFF

00:00 / 00:00

❑

… † œ √ ENTER MENU

Select the repeat playback mode.

Move the cursor to REPEAT by pressing [ ] button.

Keep pressing [ENTER] button till the user’s preferred repeat playback mode. Every time the user presses [ENTER] button, repeat playback mode changes OFF ➝TRACK ➝FOLDER ➝RANDOM

➝

OFF ➝... one by one.

DISC:

DIR--01 DIR--02 DIR--03

FILTER MP3 ONLY REPEAT TRACK

00:00 / 00:00

❑

… † œ √ ENTER MENU

Select the folder.

Move the cursor to desired folder by pressing [ ] button and press [ENTER] button to confirm.

DISC:

DIR--02 DIR--03

FILTER MP3 ONLY REPEAT TRACK

00:00 / 00:00

❑

… † œ √ ENTER MENU

DIR--01

About MP3, JPEG discs

Select the file to listen to (or view).

Move the cursor to desired file which you want to listen to (or view) by pressing [ ] button and press [ENTER] button to confirm. The selected file will be playback.

* To disappear the directory screen, press [MENU] button in

playback or stop mode. Press [MENU] button again to make it appear.

DISC: \DIR--01

FILEOPEN--01 FILEOPEN--02 FILEOPEN--03

FILTER MP3 ONLY REPEAT TRACK

00:00 / 00:00

❑

… † œ √ ENTER MENU

■ Play and Pause

Press the [PLAY/PAUSE] button to switch between play and pause.

■ Search for a track

The [SEARCH] button works on MP3/JPEG discs as well as VCD/CD audio.

* In case [SEARCH] button is pressed in playback mode, folder tree view disappears and search bar is displayed.

■ To stop playback

Press the [STOP ] button.

■ To skip to the next or previous file

• Press the [ NEXT] button of the remote control briefly while playing, to skip ahead to the beginning of the next file. Each time you press the button consecutively, the beginning of the next file is located and played back.

• Press the [ PREV (Previous)] button of the remote control briefly while playing, to skip back to the beginning of the previous file. Each time you press the button consecutively, the beginning of the previous file is located and played back.

The ability of this unit to read MP3 discs is dependent on the followings:

• The Bit Rate must be within 64-256 kbps.

• The maximum number of directories should not exceed 32.

• The maximum depth level of directories should not exceed 4.

•

In case of the file that is recorded with the variable bit rate (VBR) in one file (Example: 54-256kbps) occurrence of the sound breaking may happen during the playback.

• File names should be named using 8 or fewer letters and/or numbers, and must incorporate the “MP3” file extension. EXAMPLE:

********

. MP3 where each *is a letter or number.

• Use only letters and/ or numbers in file names. If you use special characters, the file and/ or folder names may not be displayed correctly on the on-screen display.

The ability of this unit to read JPEG discs is dependent on the following:

• If you press [PLAY] button instead of [ENTER] in JPEG image, sliding show will begin at the current image.

• To stop slide show, press [STOP] button. By pressing [STOP] and [PLAY] button, you can start slide show from the first JPEG image.

Caution

• Don’t use the CD-RW(Rewritable) disc if possible because it can not be played back.

• The CD-R must be recorded with the standard format because it can not be played back according to the recording format.

• The CD-R should be written using the ‘disc at once’ method.

• The disc which is made with ISO 9660 format can be played back.

DVD Operation

To display menus in a disc

■ If a disc includes menus, the user may use them.

Press [MENU] button.

• In case of a DVD disc, it shows menus in the disc. Also they are different according to discs. (“Return” will appear on the OSD with VCD2.0.)

• If it is a VCD2.0, select PBC ON mode by pressing [TITLE/PBC] button.

* CD and VCD1.1 do not support the function.

If it is a DVD disc, move a cursor to a relative item with arrow buttons of [ ] button and select one with [ENTER] button or [PLAY] button.

If it is a VCD 2.0 disc, it shows menus in the disc by pressing [ENTER] button.

Displaying menus in a disc

Language Setup

While STOP or RESUME STOP, press [SETUP] button.

Selecting a OSD language.

Please select a language to be displayed on DVD screen.

Every time the user presses [ENTER] button, OSD LANGUAGE changes ENGLISH

➝

FRANCAIS ➝... one by one.

Selecting Audio language.

Set it as the preferred audio language. In case the audio language is set and recorded in the DISC, it is automatically played in the set language in every playing. For example, English is set and recorded as audio language in the DISC, it is played in English.

Every time the user presses [ENTER] button, AUDIO LANGUAGE changes ENGLISH ➝FRENCH ➝... ➝AUTO one by one.

Selecting Subtitle language.

Please set it as the preferred language. In case the subtitle language is set and recorded in the DISC, it is automatically played in the set language in every playing. For example, English is set and recorded as subtitle language in the DISC, it is played in English.

Every time the user presses [ENTER] button, SUBTITLE LANGUAGE changes ENGLISH ➝FRENCH ➝... ➝OFF one by one.

Selecting Disc Menu language.

Please set it as the preferred DISC MENU language. In case the DISC MENU language is set and recorded in the DISC, it is automatically played in the set language in every playing. For example, English is set and recorded as a DISC MENU language in the DISC, it is played in English.

Every time the user presses [ENTER] button, DISC MENU LANGUAGE changes ENGLISH ➝FRENCH ➝... one by one.

■ A user can set OSD language, Audio, Subtitle and Disc Menu.

In case a disc

does not include setting languages information, the selected language does not appear.

“OSD” means “On Screen Display”.

OSD LANGUAGE

ENGLISH

AUDIO ENGLISH SUBTITLE ENGLISH DISC MENU ENGLISH

LANGUAGE

VIDEO AUDIO OTHERS

MOVE œ √†… SELECT:ENTER EXIT: SETUP

Setup

Audio Setup

Select a Digital Output.

Every time the user presses [ENTER] button, DIGITAL OUT changes BITSTREAM ➝LPCM

➝

BITSTREAM ➝... one by one.

Select a Dynamic Range.

Every time the user presses [ENTER] button, DYNAMIC RANGE changes OFF ➝FULL

➝

OFF ➝... one by one.

• Set “OFF” to view a program in the dynamic range as recorded disc.

• If you hear loud sound softer and soft sound louder, set “FULL”.

■ A user may select audio menu according to a user’s speaker set.

While STOP or Resume STOP, press [SETUP] button.

Video Setup

While STOP or RESUME STOP, press [SETUP] button.

Selecting TV Aspect.

Every time the user presses [ENTER] button, TV ASPECT changes 4:3 LB ➝ 16:9 WIDE

➝

4:3 PS ➝ ... one by one.

■ A user can set up a connected TV condition and screen.

If a user selects “4:3 PS”, the user can watch only a center of the original scene of “16:9”. If a user selects “4:3 LB”, the user can watch the original scene of “16:9”, but the top and bottom of the screen look black color. If a disc size is originally recorded in 4:3, a user cannot watch it in a wide screen though a user sets a size as “16:9 Wide”.

TV ASPECT

4:3 LB

LANGUAGE

VIDEO AUDIO OTHERS

MOVE œ √†… SELECT:ENTER EXIT: SETUP

DIGITAL OUT

BITSTREAM

DYNAMIC RANGE OFF

LANGUAGE

VIDEO AUDIO OTHERS

MOVE œ √†… SELECT:ENTER EXIT: SETUP

DIGITAL OUT BITSTREAM DYNAMIC RANGE

OFF

LANGUAGE

VIDEO AUDIO OTHERS

MOVE œ √†… SELECT:ENTER EXIT: SETUP

Set output conditions to coaxial or optical terminal. You can set following two values of digital output;

• Bitstream: The same signal as audio signal recorded in disc goes to digital audio output terminal.

• LPCM: Decoded audio signal goes to digital output terminal.

Others Setup

Select character display window.

Select "On" to make OSD(On Screen Display) language displayed in screen.

Select screensaver.

If bright scenes continue to be displayed in screen, TV can be damaged. Set the screensaver to "On", the screensaver functions automatically and DVD logo moves continuously if the resume stop, stop, open status is maintained for about 5 minutes.

Select defaults.

If you select defaults, every function set returns to FACTORY Defaults except Parental.

Select Parental.

Press [ENTER] button when the cursor is located in PARENTAL.

When “INPUT PASSWORD” appears on the screen, input the password.

Change the level of Parental.

With right password, you can change the PARENTAL by pressing [ENTER] buttons.

Every time the user presses [ENTER] button, Parental changes 1KIDS ➝2G ➝3PG ➝4PG13

➝

5PG-R ➝ 6R ➝7NC-17 ➝ 8ADULT

one by one.

It consists of 8 levels of parental control, violence, sexual scene, strong sexual scene and others to protect children from watching those scenes.

While STOP or RESUME STOP, press [SETUP] button.

“Parental Lock”

activates only if you set a password and the unit goes into Lock status. When the disc has no parental function even if the disc for adult only, Parental Lock doesn’t activate.

The initial

password is

3308. In case you forget newly-input password, you can use 3308 as a password.

Changing a password.

For the change of a user’s password, please move to “Change Password” and enter new password.

OSD

SCREEN SAVER ON DEFAULTS RESET PARENTAL 8 ADULT

LANGUAGE

VIDEO AUDIO OTHERS

MOVE œ √†… SELECT:ENTER EXIT: SETUP

OSD ON SCREEN SAVER ON DEFAULTS RESET INPUT PASSWORD - - - -

LANGUAGE

VIDEO AUDIO OTHERS

MOVE œ √†… SELECT:ENTER EXIT: SETUP

OSD ON SCREEN SAVER ON DEFAULTS RESET PARENTAL

8 ADULT

CHANGE PASSWORD

- - - -

LANGUAGE

VIDEO AUDIO OTHERS

MOVE œ √†… SELECT:ENTER EXIT: SETUP

The others

About DVD

Playable Disc

• DVD, Video CD(Version 1.1, 2.0), S-VCD and Audio CD

Disc type Playable Restriction

DVD Possible Region number 4 or Region number All

Video CD Possible Version 1.0/1.1/2.0, SVCD/CVD

CD Possible PCM or dts

CD-G Possible Only Audio playback

CD-ROM Possible MP3 File

CD-R Possible Video-CD/CD/CD-ROM (MP3 File) CD-RW Possible Video-CD/CD/CD-ROM (MP3 File) DVD-R Possible DVD Video

DVD-RW Possible DVD Video

DVD+RW Possible DVD Video DVD-ROM Impossible DVD-RAM Impossible

Photo CD Impossible

REGION MANAGEMENT INFORMATION

This unit is designed and manufactured to respond to the Region Management information that is recorded on a DVD disc. The region number of this player is “2”. If the region number described on the DVD discs does not correspond to the Region number of this player, the player will not play this disc. This player will play DVD discs made for “ALL” regions. Therefore, this player will play DVD discs marked with labels containing the region number “2” or “ALL”.

(Region 2) (Region ALL)

ALL

Terms related with DVD

DVD A DVD (abbreviation of Digital Versatile Disc or Digital Video Disc) can include 135 minutes of video

information. And for audio, it can hold up to 8 kinds of languages and 32 kinds of subtitle languages. By using MPEG-2 video compression and digital 3D surround sound, DVD realizes high-defined screen and quality sound like a movie theater.

CDDA A CDDA (abbreviation of Compact disc digital audio) is a music disc that is currently used.

MP3 Audio compression format that enables audio files to be stored and transferred on a computer with a

relatively small file size. It enables you to enjoy CD quality music. (Short for MPEG-1 Layer 3)

PBC This is recorded on a Video CD 2.0, Video CD 3.0, SVCD and CVD. The scenes or information to be

viewed (or listened to) can be selected interactively with the TV monitor by looking at the menu shown on the TV monitor. It stands for PlayBack Control.

CHAPTER It means the information recorded in a DVD. A title in a DVD is divided into many tracks, of

which a track is called as a chapter. A certain scene of a screen can be quickly searched with the chapter number.

TITLE It means the information recorded in a DVD. A DVD can be divided into may titles.

TRACK It means the information recorded in a video CD and audio CD. A disc consists of many a track,

for which a user can search a certain position.

dts Digital Theatre System is a 5.1 -channel surround sound system, which is widely used in movie

theatres around the world. It enables the bit rate to be increased to provide good sound quality. “DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.

Multi Angle Some DVD discs contain the various scenes that have been simultaneously shot from a number of

different angles.

PCM Linear PCM is a signal-recording format used in a CD, while CD is recorded in 44.1kHz/16bit, a

DVD is recorded in 48KHz/16bit up to 96KHz/24bit.

Dolby DigitalDolby Digital enables the delivery of mono through 5.1-channel audio at data rates from 32 kbps

to 640 kbps, thus offering flexibility and economical performance as well as uncompromised sound quality.

Bitstream Digital audio data that is decoded into an analog signal for subsequent output to speakers.

Lt/Rt It indicates L/R of Dolby Digital 2CH Downmix output.

Downmix DOWNMIX is reproducing the proper audio when audio format recorded on a disc differs from

the output audio channel configuration. For example, with just one stereo speaker system you can hear full 5.1 channel audio.

About DVD

Handling Disc

• To keep a disc clean condition, please do not touch a side containing play information.

• Do not attach a bit of paper or sticky tape on it.

• Do not expose a disc to a direct sunlight or electric heating systems.

• After using it, please keep a disc in a case.

Cleaning Disc

• Before using it, please rub it from center toward outside with clean clothes.

• Do not use any type of solvent such as thinner, benzol (benzene), commercial cleaning goods or antistatic sprays.

The others

How to use a head cleaner

• In case of a old or contaminated videotape, screen may not be clean from the contamination of VCR heads. Please remove contaminants using a head-cleaner like below order.

1 Insert a head-cleaner into VCR 2 Press “PLAY” for 5 seconds, and then press “FF” for about 10 seconds.

3 Eject a head-cleaner from VCR

• If the screen is not clean yet, please repeat the above 2 or 3 times more.

• A head-cleaner is not for sale. Please ask it for the nearest agent.

• In case a user ask the removal of contaminants of us, the user should pay extra charges.

PLAY (5secs)

FF (10secs)

Basic information about VCR and Videotape

What is dew condensation symptom?

• If a VCR is moved from a cool place to a warm and damp place or a place facing a direct cool wind from airconditioner...and others, temperature varies sharply, which makes dew on head drums of VCR.

If dew condensation occurs,

1 First, turn it on for one or two hours before using it.

2 Do not use it because it may develop troubles of a VCR or videotape.

Terms related with VCR

AFT Automatic fine tuning, a circuit that automatically adjusts TV reception to optimum condition.

CABLE Cable television.

Index Search A feature of this VCR that automatically records an index each time recording begins. It helps you

locate a particular segment of the tape quickly and easily.

LP Long Play, an intermediate tape recording speed that combines most of the picture/audio quality

obtainable at the standard recording speed with some of the tape economy of Extended Play (EP).

OSD On-screen display of information pertinent to the features of the VCR.

OTR One-touch recording, a feature that allows you to record the program you’re watching by

pressing the REC key. Each press of the key increases the recording time by 30 minutes, up to 10 hours.

RF Radio frequency, the composite audio/video signal supplied to a TV receiver (or other video

component) by an antenna or cable system.

Safety tab The plastic tab at the back of a video tape cassette which, when removed, prevents accidental

erasure of a recording.

SP Standard play, the recording speed to use when the best picture quality is of prime importance

(and when total recording time is not).

Before doubting about troubles (VCR)

• “Power On” does not work.

• It does not work even in “Power On”.

• A videotape is not inputted in.

• On inputting a videotape, the tape is re-ejected.

• A videotape is not ejected.

• A channel on video and a play screen does not appear.

• Noise (screen noise) appears on screen.

• Noise appears on screen after recording.

• While in playing, noise appears.

• Sound and screen are irregular.

• Sound comes out but screen does not appear.

• Screen is irregular and stripes appears.

• "Screen Error" message is displayed in a screen.

• While recording and playing, the top of screen extremely waves.

• A screen is not clear.

• A screen at pause is trembling or slow screen is not clear.

Checks

Symptom

➤ Please check whether a power plug is inserted in an electric outlet. ➤ Please check whether a videotape is inserted in.

➤ Try to insert a plug again. ➤ Please check whether a power plug is inserted in an electric outlet.

➤ Please check whether a videotape is in. ➤ Please check whether a videotape is inserted in a right direction (a

side of transparent window should be on the upside)

➤ Have you inputted a videotape again just after the tape was ejected?

Please try it again after fully ejecting it.

➤

When a videotape forces to be ejected, the tape may not be inputted. In the case, please pull out an outlet, and then push the tape smoothly.

➤ That’s why a safe mode to protect a videotape is operated

automatically. Please pull out the tape and input it again.

➤ In case the product is used for a long time, a videotape may not be

ejected for a film inside may be stretched. In the case, please pull out a power plug for about 10mins and then press “EJECT” button.

➤ Please check your antenna’s connection. ➤ TV channel should be fixed on video channel. ➤

Please check your antenna’s signal whether it may be weak. In case of its weakness, please use a frequency amplifier connected with the device.

➤

Press “TV/VCR” and then let “VCR” is displayed on the display panel.

➤ While in no use of VCR, was it turned on? ➤ While in recording a program, do you watch another channel? ➤ Select TV by pressing [TV/VCR] button on remote control.

➤ While in playing a videotape, there may happen some noise or blot

in the part of the beginning of a videotape or resuming “PAUSE”, which are not breakdown.

➤ Please press “TRACKING” for better screen. Videotape may be

poor. Try to change it to another one.

➤ Please use a head-cleaner to clean VCR heads. VCR heads may be

contaminated.

➤ Since VCR Play signals are not stable like a TV signals, screen may

be unstable or curved while in playing. To fix the problem, please horizontal adjustment.

➤ In case videotape is the one recorded by other products or old one,

stripe may appear on the screen.

➤ Try to adjust the screen by [TRACKING+/-] button ➤ Try to use a head-cleaner.

➤ Try to use a head-cleaner. ➤ Try to adjust the screen by [TRACKING+/-] button.

Before doubting about troubles (VCR)

• Recording a TV program is impossible.

• Once pressing “REC”, a videotape is ejected automatically.

• Timer recording of Cable TV does not work.

• In spite of pressing “CHANNEL”, a channel can not be set.

• While duplicating, screen is not clean and distorted.

• remote control does not work.

• Buttons on remote control do not work.

• VISS index search does not work.

• Cable broadcasting can not be selected.

Checks

Symptom

➤ For recording, you should use videotape with a tab. ➤ Please check whether a channel is fixed on video. If not, you have to

turn it into “TV” by pressing “INPUT” button.

➤ Please check whether the timer recording info is right. ➤ Are RF cables inputted antenna connection terminal correctly? ➤ Does a CH number selected in display section appear? ➤ Please check a tab on a tape whether it is broken or not. (If it was

broken, please scotch-tape it)

➤ Check whether a tape attached with a recording tap is inserted. ➤ Check whether the screen is displayed in VCR Only Channel. Press

[INPUT] button in this remote controller to adjust in "General Broadcast" condition.

➤ Is the rounded line (RF cable) connected in "ANT.IN" terminal? ➤ Is the selected channel number shown in Display? ➤ Is a tab of cassette tape broken? (Please cover a tab hole with

cellophane adhesive tape (Scotch tape).)

➤ Please check whether the clock is right. ➤ Does the display on your video show “

”

(Ready to timer

recording)? Please make it out.

➤ Please check whether the timer recording info is right. ➤ Please check a tab on a tape whether it is broke or not. (If it was

broken, please scotch-tape it)

➤ Was a cable data output code connected correctly? ➤ Were a converter manufacturer setup and output channel right? ➤ Did you enter a password? (Please cancel it.) ➤ Did you turn off your player? (Please turn it on.)

➤ You may not memorize channels. ➤ Please check your channel setting or press a number button.

➤ Some tapes or discs distributed in the market for lending is set to

prevent copy in manufacturing. These tapes cannot be duplicated in a good condition.

➤ Battery may be weak or exhausted. ➤ A receiver of remote control may be different with a sender.

➤ In case a videotape is positioned in the beginning, “VISS REW” and

“REW” do not work.

➤ In case a videotape is positioned in the end, “FF”, “VISS FF”, “PLAY”

and “REC” do not work.

➤ Please check whether another button is pressed. ➤ Are you playing a tape that is not recorded in this recorder? (Try to

record it with the recorder.)

➤ You may start recording it in “REC-PAUSE”. Please start recording it

from stop condition.

➤ Please select “CABLE” not “NETWORK” from the “CHANNEL

SETTING”.

The others

Before doubting about troubles (DVD)

• The recorder does not play.

• No sound comes through.

• A disc is playing but screen does not appear or poor screen appears.

• Sound is irregular

• REMOTE does not work.

• Dolby Digital sound does not work

• “AUDIO” or “SUBTITLE” button does not work.

• “ANGLE” button does not work while a DVD is playing.

• “MENU” does not appear while a DVD is playing.

• The file name of MP3 (CD-R) appears with strange letters.

• Any MP3 (CD-R) file isn’t displayed.

Checks

Symptom

➤ If a DVD is from overseas, it may not be played. Please check a

DVD’s region code whether it has the relative region code 2 or All.

➤ Please check whether a DVD is inserted in a right direction. ➤ If it is a CD-ROM for PC or DVD-ROM, it does not work.

➤ Play mode may be “SLOW” or “PAUSE”(In abnormal speed play,

no sound comes through)

➤ Did you connect the parts in right way? ➤ Please check the operative condition of TV or amplifier. ➤ From SETUP, please check “AUDIO” items.

➤ Did you turn on your TV sets? ➤ Did you connect the parts in right way? ➤ The play may be in “PAUSE”. ➤ A disc may have some contaminants or be damaged. ➤ A disc may be bad one.

➤ Please check the connection with Dolby Digital amplifier. ➤ Please check the plugs are connected with one another tightly. ➤ Some contaminants may be remained in connection terminal.

➤

Please check the degree of remote control, distance or any interruption.

➤ Battery may be weak or exhausted. ➤ When you operate DVD, use it by pressing [DVD] button.

➤

Dolby Digital sound can be worked in the Dolby Digital amplifier only.

➤ Please check “Dolby Digital ” mark on your DVD. ➤ In case of playing it through digital output, while pressing “STOP”,

please check whether “Digital Output” is “Bitstream” by pressing “SETUP”.

➤ Please check the connection is correct. ➤ If a DVD does not include language information, it does not support

the function.

➤

“ANGLE” is supported only in a DVD contains multi angle scenes. Also a user can confirm the support with the “ANGLE” mark on screen.

➤

Please check the degree of remote control, distance or any interruption.

➤

Please check a battery in remote control whether it is exhausted or not.

➤ A DVD may not contain menu information. ➤ The file name of MP3 recognize only the Alphabet (A~Z, a~z),

numbers (0~9) and a special symbol on keyboard (~, !, @, #, $ ....)

and 10 letters can be displayed in maximum.

➤ The letters except above case will be displayed like “----”. ➤ If the surface of disk is injured, the file display and playback can be

impossible.

DVD Audio output standards

Specifications

Disc type

DVD VIDEO-CD CD

Analogue Audio output 48/96KHz sampling 44.1KHz sampling 44.1KHz sampling Digital Audio output 48KHz sampling 44.1KHz sampling 44.1KHz sampling Optical digital audio output 48KHz sampling 44.1KHz sampling 44.1KHz sampling

Output

Power 230V~, 50/60Hz

Consumed electricity 26W

Weight 4.6kg

Dimension (W x H x D) 435mmx93mmx255mm

Operative temperature +5°C~40°C

Installation condition Horizontal / Relative humidity under 80%

Signal type PAL COLOR

Antenna Input/output U/V-mixed: 75Ω unbalanced

VIDEO input 1.0Vp-p (unbalanced, RCA JACK)

AUDIO input -8.8dBm, RCA JACK

VIDEO output (common use of DVD and VCR) VIDEO output terminal, 1.0 Vp-p unbalanced, RCA JACK

VIDEO output (DVD only) Component output (75Ω In load Y: 1.0Vp-p, Pb:0.7Vp-p, Pr:0.7Vp-p)

AUDIO output (common use of DVD and VCR) Audio output terminal (2 kinds): -5.8dBm(VCR), 2Vrms(DVD), RCA JACK

AUDIO output (DVD only) Analogue AUDIO output : 2.0Vrms

Digital audio output (OPTICAL, COAXIAL)

Playable tape Very high dense tapes with VHS marks

Playable disc DVD, VIDEO-CD, CD (12cm), CD (8cm), MP3, CD-R, CD-RW

Tape speed SP: 23.39mm/s, LP: 11.70mm/s

Playtime SP: 3hrs, LP: 6hrs (use of E180tape)

Clock display 24 hrs

Time Recording 8 programs a month

Persistence in power failure 1min

VIDEO S/N (VCR) Over 43dB (Standard recording)

Resolution VCR Over 240 lines (Standard recording)

DVD Over 400 lines (Playback DVD)

AUDIO (VCR) Over 65dB

AUDIO (DVD) 90dB

AUDIO dynamic range 90dB

The others

Daewoo SD-9800D User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
