Daewoo G1629 User Manual

Product information

1

Contents

Product Information

Important Safeguards ..................................................... 2

Advantages of This Product Are .... ............................ 5

Read Carefully before Using ......................................... 6

Identification of Controls ...............................................7

Remote Control .............................................................. 11

Installation

Connecting up your player with RF lead .................. 12

Connecting with Other VCR or Camcorder ............. 14

Connecting with Audio .................................................16

Connecting to a television with Component jack and a

Dolby Digital Amp. ....................................................... 17

Basic Operation

Initial Installation ........................................................... 18

Setting time and date, OSD ON & OFF ..................... 20

Output Select .................................................................. 21

DVD Playback ................................................................ 22

VCR Playback ................................................................ 23

Recording ........................................................................ 24

VCR Operation

Tuning in New Stations ................................................ 27

Timer Recording ............................................................ 30

More Functions .............................................................. 32

Connections and Copying ...........................................35

DVD Operation

Playing a desired scene ................................................ 37

Confirming the current PLAY mode on screen ....... 41

Selecting an AUDIO language, SUBTITLE language

and 3D AUDIO ...............................................................43

Selecting ZOOM and Multi Angle.............................. 44

About MP3 ,CDDA, JPG and MPG discs .................. 45

Displaying menus in a disc, Progressive Scan Mode

...49

Set-up

Language Setup .............................................................. 50

Video Setup ......................................................................52

Audio Setup..................................................................... 53

Others Setup ................................................................... 54

Other Features

About DVD...................................................................... 56

Basic information about VCR and Videotape.......... 58

Trouble Shooting (VCR)................................................ 59

Trouble Shooting (DVD) .............................................. 61

Specifications .................................................................. 62

Product information

2 3

Important Safeguards

CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.

The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and servicing
instructions in the literature accompanying the
appliance.

WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS

APPLIANCE TO RAIN OR MOISTURE.

CAUTION : TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT,

FULLY INSERT.

IMPORTANT FOR LASER PRODUCTS

• LASER :

This Digital Video Disc Player employs a Laser System. To ensure proper use of this product
please read this instruction manual carefully and retain for future reference. Should the unit
require maintenance, contact an authorized service location - see service procedure.

Use of control adjustments or the performance of procedures other than those specified
may result in hazardous radiation exposure.

To prevent direct exposure to the laser beam, do not try to open the enclosure. Visible laser
radiation when open and interlocks defeated.
DO NOT STARE INTO THE BEAM.

• DANGER :

Visible laser radiation when open and interlock failed or
defeated. Avoid direct exposure to beam.

• CAUTION : Do not open the top cover. There are no user
serviceable parts inside the Unit; leave all servicing to
qualified service personnel.

CLASS 1 LASER PRODUCT
LUOKAN 1 LASERLAITE
KLASS 1 LASERAPPARAT

CAUTION: Any changes or modification in construction of this device which are not expressly approved by

the party responsible for compliance could void the user’s authority to operate the equipment.

• Make sure the unit should be placed at least 8cm apart from the other home appliances or the
obstacles to get sufficient ventilation.

• This unit shall not be exposed to dripping or splashing and no objects filled with liquids, such
as vases, shall be placed on this unit.

• Switching it off does not disconnect it from the mains (stand-by). To disconnect it from the
mains, you have to unplug it.

• The system is not completely disconnected from the mains when the / I button is set to
the position.

Product information

This set has been designed and manufactured to assure
personal safety. Improper use can result in electric
shock or fire hazard. The safeguards incorporated in
this unit will protect you if you observe the following
procedures for installation, use and servicing. This unit
is fully transistorized and does not contain any parts
that can be repaired by the user.

1 READ INSTRUCTIONS

All the safety and operating instructions should be
read before the unit is operated.

2 RETAIN INSTRUCTIONS

The safety and operating instructions should be
retained for future reference.

3 HEED WARNINGS

All warnings on the unit and in the operating
instructions should be adhered to.

4 FOLLOW INSTRUCTIONS

All operating and use instructions should be
followed.

5 CLEANING

Unplug this unit from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.

6 ATTACHMENTS

Do not use attachments unless recommended by
the unit’s manufacturer as they may cause
hazards.

7 WATER AND MOISTURE

Do not use this unit near water- for example, near
a bath tub, wash bowl, kitchen sink or laundry tub,
in a wet basement, or near a swimming pool.

8 ACCESSORIES

Do not place this unit on an
unstable cart, stand, tripod,
bracket, or table. The unit may
fall, causing serious injury to
a child or adult as well as serious damage to the
unit. Use this unit only with a cart, stand , tripod,
bracket, or table recommended by the
manufacturer.

8A

A unit and cart combination should be moved

with care. Quick stops, excessive force, and uneven
surfaces may cause the product and cart
combination to overturn.

9 VENTILATION

Slots and openings in the case are provided for
ventilation to ensure reliable operation of the unit
and to protect it from overheating. These openings
must not be blocked or covered. These openings
must not be blocked by placing the unit on a bed,
sofa, rug, or other similar surface. This unit should
never be placed near or over a radiator or heat
radiator. This unit should not be placed in a built­in installation such as a bookcase or rack unless
proper ventilation is provided or the
manufacturer’s instructions have been adhered to.

10 POWER SOURCES

This unit should be operated only from the type of
power source indicated on the marking label. If
you are not sure of the type of power supply to
your home, consult your dealer or local power
company. For units intended to operate from
battery power, or other sources, refer to the
operating instructions.

11 POWER-CORD PROTECTION

Power-supply cords should be routed so that they
are not likely to be walked on or pinched by items
placed upon or against them, paying particular
attention to cords at plugs, convenience
receptacles, and the point where they exit from the
unit.

12 LIGHTNING

For added protection for this unit during a
lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the
wall outlet and disconnect the antenna or cable
system. This will prevent damage to the unit due
to lightning and power line surges.

13 DISC TRAY

Keep your fingers well clear of the disc as it is
closing. It may cause serious personal injury.

Important Safeguards

PORTABLE CART WARNING

(symbol provided by RETAC)

Product information

4 5

Important Safeguards

14 OVERLOADING

Do not overload wall outlets of extension cords as
this can result in a risk of fire or electric shock.

15 OBJECT AND LIQUID ENTRY

Never push objects of any kind into this unit
through openings as they may touch dangerous
voltage points or “short-out” parts that could
result in a fire or electric shock. Never spill liquid
of any kind on the unit.

16 BURDEN

Do not place a heavy object on or step on the
product. The object may fall, causing serious
personal injury and serious damage to the product.

17 DISC

Do not use a cracked, deformed or repaired disc.
These discs are easily broken and may cause
serious personal injury and product malfunction.

18 SERVICING

Do not attempt to service this unit yourself as
opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.

19 DAMAGE REQUIRING SERVICE

Unplug this unit from the wall outlet and refer
servicing to qualified service personnel under the
following conditions.
A. When the power-supply cord or plug is

damaged.

B. If liquid has been spilled, or objects have fallen

into the unit.
C. If the unit has been exposed to rain or water.
D. If the unit does not operate normally by

following the operating instructions. Adjust

only those controls that are covered by the

operating instructions. Improper adjustment of

other controls may result in damage and will

often require extensive work by a qualified

technician to restore the unit to its normal

operation.
E. If the unit has been dropped or the cabinet has

been damaged.
F. When the unit exhibits a distinct change in

performance-this indicates a need for service.

20 REPLACEMENT PARTS

When replacement parts are required, have the
service technician verify that the replacements he
uses have the same safety characteristics as the
original parts. Use of replacements specified by the
unit manufacturer can prevent fire, electric shock,
or other hazards.

21 SAFETY CHECK

Upon completion of any service or repairs to this
unit, ask the service technician to perform safety
checks recommended by the manufacturer to
determine that the unit is in safe operating
condition.

22 WALL OR CEILING MOUNTING

The product should be mounted to a wall or
ceiling only as recommended by the manufacturer.

23 HEAT

The product should be situated away from heat
sources such as radiators, heat registers, stoves, or
other products (including amplifiers) that produce
heat.

24 To prevent battery electrolyte leakage, which may

result in injury and damage to the unit or other
objects, observe the following precautions:
A. All batteries must be installed with the

proper polarity.
B. Do not mix new with old or used batteries.
C.

Only use batteries of the same type and brand.
D. Remove the batteries when they are not to be

used for a long period time.
E. When the batteries have become discharged,

they must be disposed of in a safe manner

which complies with all applicable laws.

Advantages of This Product Are .....

• DVD, VCD, CD, CD-R(MP3), CD-RW, VHS

• Watching DVD while recording TV
broadcasts

• Integrated remote control (VCR, DVD)

• VISS function

• Multiplex sound playback/record

• High Sound Quality of 6 head Hi-Fi

• Simple record function

• MP3 file playback function (CD-R disc
having records of MP3 files)

• GUI (Graphical User Interface) through
OSD (On Screen Display)

By using the [DISPLAY] button on the remote
control, information on the DVD/VCD/CD
player and disc, can be displayed on the TV
screen.

• Screensaver function (DVD)

• 3D sound (3D sound effect using 2 speakers)

• High bit / High sampling with 27MHz /
10bit video encoder

• High bit / High sampling with 96MHz /
24bit Audio D/A Converter

• Coaxial, Optical digital Audio output (PCM,
Dolby Digital, dts)

You can enjoy high-level digital audio by
connecting with amp embedded with Dolby
Digital / dts decoder.

• Built-in Dolby Digital decoder (DVD)

• Analog audio 2-channels output for
DOWNMIX (x1)

• Composite video output (x1)

• Slow Forward / Reverse playback (DVD)

• Fast Forward / Reverse playback

• Search of title, chapter, and time in DVD
disc, and search of time and track time in
VCD.

• Various TV aspect (DVD)

4:3 for Pan and Scan, 4:3 for Letter Box, and 16:9
for Wide

• Repeat playback (title, chapter, and part for

DVD/ track, disc, and part for VCD/CD)

• Selective Play (DVD/VCD/CD)

You can select and play the desired title / chapter
of DVD and track of Video CD/CD in STOP
mode.

• 6 languages OSD (On Screen Display)
function (DVD)

You can select and display OSD in 6 languages.
(E/ F/ S/ G/ I/ D)

• Parental Lock function (DVD)

This function can prevent playback of software
that may be unsuitable for children.

• Multi Audio function (DVD)

The audio soundtrack can be heard in up to 8
languages. In the case of SVCD or VCD, it
depends on the disc. (The number of audio
languages depends on the software.)

• Multi Subtitle function (DVD)

The subtitle can be seem in up to 32 languages.
In the case of SVCD or VCD, it depends on the
disc. (The number of subtitle languages depends
on the software.)

• Multi Angle function (DVD)

This function allows you to choose the viewing
angle of scenes which were shot from a number
of different angles. (The number of angles
depends on the software.)

• Screen zoom function (DVD/VCD)

Product information

6 7

Read Carefully before Using

Cautions in use of DVD-Video player are described
below.

Please read carefully before using a DVD-Video player.

✔ Installation place and handling

• When you place this player near other devices,
they may affect poorly together.

• When you place DVD-Video player and TV in
the upper and lower sides, it may cause
flickering of pictures or failure (tape is not
ejected).

• When you place this player near strong
magnetic materials, it may affect image or voice
poorly or damage recording.

• Do not spill volatile liquids like insect spray
over the player. Do not leave rubber or plastic
products in contact with the player for a long
time. They will cause deterioration or paint
peel-off.

✔ Not in use

• When the unit is not in use, be sure to remove
the disc or tape and turn off the power.

• If you do not use the unit for a long period,
remove batteries in remote control to prevent
leakage.

• In case you don’t use the unit for a long time,
the unit may not function properly in the
future. Turn on and use the player occasionally.

✔ Moving

• Repack the unit as it was originally packed at
the factory. Alternatively, pack this product
with towel not to be damaged.

• Eject any videotape.

✔ Cleaning

• Dust off dirt in cabinet or control panel part
smoothly with a soft cloth.

• For heavy dirt, soak the cloth in a weak
detergent solution, wring it well and wipe. Use
a dry cloth to wipe it out.

• Follow instructions in using chemical cleaners.

• Do not use any type of solvent such as gasoline
or benzene, as they may cause deterioration or
paint peel-off.

✔ Checking

• Video is a high precision device. To obtain a
clear screen, we recommend regular inspection
and maintenance every 1,000 hours of use by
technical engineers.

• For checking, contact your dealer or your
nearest service center.

✔ Checking and Replacement of Antenna

• Antenna is subject to change in its direction or
damage by wind and rain. For clean screen,
contact and consult your nearest service center
about checking and replacement.

✔ Copyright

• Do not use your recordings without permission
of a copyrighter except personal usage.

✔ Tape and Disc Handling

• Do not use any tape and disc below. Damage
of video head or cut/coiling of tape may cause
failure.

- Tape with mold

- Tape or disc stained with juice or attachments

- Tape having breakage connection

- Disassembled tape

- Disc with severe scratch

• Moisture condensation may occur in tape.

Moisture condensation damages the tape.
Please use the tape after the moisture
condensation is disappeared.

• After use, store tape vertically in a case to

prevent loose.

• Do not store the following places.

- High temperature and humidity

- Subject generation of mold

- Subject to direct sunlight

- Much dirt or dust

- Near strong magnetic materials such as speaker

✔ Video head cleaning

• Video head cleaning is needed when the
playback picture becomes unclear. Use an
equivalent high quality chemical non-abreasive
head cleaning tape or have them cleaned
professionally.

Identification of Controls

!

POWER (STANDBY/ON) button

Use to power the device on/off if AC power supply
is connected.

@

Place to insert videotape

#

Disc tray

$

VIDEO INPUT jack

%

AUDIO INPUT jack

^

EJECT button

&

RECORD button

*

PR -/+ (Programme Down/Up) button

(

Operation Display Window

Display operation of device. For more information,
see “Operation Display Window” (refer to page 8).

)

SELECT button

Use to change DVD mode to VCR mode, and vice
versa.

1

OPEN/CLOSE Tray button

2

REWIND button

Use to rewind currently being played videotape or
disc; or to playback back rapidly.

3

STOP button

Use to stop playing.

4

FAST FORWARD button

Use to wind currently being played videotape or
disc; or to playback rapidly.

5

Playback/PAUSE button

Playback videotape or disc.
Press this button to pause a screen.

Main body (front panel)

!

%

&

*

)1234

5

^

@#

$

(

Product information

8 9

Identification of Controls

Timer Recording Standby

Timer Recording Error

Recording in Progress

Timer Recording in
Progress

Recording Pause

Repeat one chapter

[DVD]

Repeat track

[VCD]

Repeat title

[DVD]

Repeat ALL

[VCD]

Repeat a defined period
from A

[DVD, VCD]

Repeat a defined period
from A to B

[DVD, VCD]

- RECORDING MODE - - REPEAT MODE -

DVD playback

Fast playback

Fast reverse playback

Slow playback

Pause picture

- DVD OPERATION -

VCR playback

Fast forward

Rewinding

Fast playback (CUE)

Fast reverse playback
(REVIEW)

Slow playback

Still picture

Stop

Child Lock

- VCR OPERATION -

Operation Display Window

Identification of Controls

ANT.IN

ANT. OUT

R

L

OUT

IN

AUDIO

VIDEO

R

COAXIAL

L

Y

Pr

Pb

DIGITAL

COMPONENT OUT

AUDIO OUT

OPTICAL

AUDIO OUT

DIGITAL

AUDIO OUT

DVD & VCRDVD

!

POWER CORD

It is a jack for supplying power to the unit.
Connect to outlet in a wall.

@

AUDIO OUTPUT Jack

#

COMPONENT OUTPUT Jack

$

DIGITAL OUTPUT (COAXIAL) Jack

To enjoy sound quality of theater level in home,
connect this jack with amp or unit embedded
with digital audio decoder.

%

DIGITAL OUTPUT (OPTICAL) Jack

To enjoy sound quality of theater level in home,
connect this jack with amp or unit embedded
with digital audio decoder.

^

A/V OUTPUT Jack

&

A/V INPUT Jack

*

Connection to ANTENNA Cable

(

Connection to TV

Main body (Rear Panel)

!

@ # ^ & *

$ % (

Product information

10 11

Identification of Controls

Remote control 2 Batteries RF cable

Instruction

Manual

• To purchase accessories or not supplied parts additionally, contact your nearest dealer or service center.

• Operate remote control within 7m from the unit.

• Do not press 2(two) buttons at the same time.

• Do not light up sending and receiving part of remote control.

• Do not keep in the place with much dust and humidity.

Instructions in using REMOTE

Accessories

Remote Control

!

#

@

$
%

^

&

(

)

2

4
5

7

9

“

#

‘

=

q

w

e

R

r

T

Y

0

+

E

t

y

W

Q

*

3

1

6
8

!

[DVD]

OPEN/CLOSE button,

[VCR]

EJECT button

@

VCR SELECT button

#

[DVD, VCR]

NUMBER button,

[VCR]

TRACKING -/+

button

$

SYSTEM button

[VCR]

`

This button is not available for

this set

[DVD]

Activates Progressive Scan button

%

SETUP button

^

[DVD, VCR]

MOVE/SELECT in OSD,

[VCR]

Channel

Up/Down button

&

[DVD]

TITLE /PBC button

*

[DVD]

AUDIO LANGUAGE Select,

[VCR]

AUDIO Select

button

(

[DVD]

SUBTITLE Select button

)

REVERSE SEARCH button

1

PLAY/PAUSE button

2

[DVD]

PREVIOUS button (move into a previous chapter

or track)

3

[VCR]

Record SPEED button

4

[VCR]

Record button

5

[VCR]

TV/VCR button

6

[DVD]

3D button

7

[VCR]

CM SKIP

8

[VCR]

Replay button

9

POWER button

0

DVD SELECT button

“

[VCR]

INPUT Selection button

‘

CLEAR button

+

[DVD, VCR]

OSD DISPLAY button

=

OK/ENTER button

Q

[DVD]

MENU button

q

[DVD]

Chapter/Title/Time SEARCH button

W

[DVD]

ZOOM button

w

FORWARD SEARCH button

E

STOP button

e

[DVD]

NEXT button (Move into a next chapter or track) ,

[VCR]

Frame Advance button in pause mode

R

[DVD]

REPEAT Playback button

r

[DVD]

REPEAT a defined period from A to B button

T

[DVD]

ANGLE button

t

[DVD]

MARK button

Y

[DVD, VCR]

PROGRAM button

y

[VCR]

LAST CHANNEL button (Return to the previous

TV channel which was being watched.)

Press the power [ ] button of the remote for about
5 seconds. No buttons of front panel can be operated
now and Lock indicator (“ ”) will be
displayed on window display. To release child lock,
press any button of the remote control.

POWER ON

Player will be POWER ON if any button of the
remote control is pressed.

Child Lock !

AAA

AAA

✔

Remote control battery installation

Detach the battery cover on the rear of the
remote control, and insert two AAA
batteries with the + and - ends aligned
correctly.

Two “AAA”
batteries
(supplied).

Installation

12 13

Connecting up your player with RF lead

■ Before you start, unplug all the equipment from the mains supply.

(Option 1) - How to connect with RF lead

■ Before you start, unplug all the equipment from the mains supply.

(Option 2) - How to Connect with Audio/Video jack

Aerial

The type of aerial you should use,
depends on local interference and
how far you are from the
transmitter. You should contact a
local retailer if you have any
questions about your aerial.

In option (1) you need to tune your television to the player so you can see the picture from the player. When
it is on the player generates a signal on UHF transmission channel 36, but this might change after tuning in
the stations with 'AUTO-SEARCH' . See the 'Check it out' box on page 18. See your television manual for
how to tune in a new channel.

INPUT 1

ANT IN

INPUT 2

REAR PANEL OF DVD-VIDEO

OUTSIDE ANTENNA OR

WALL ANTENNA OUTLET

REAR PANEL OF TV

RF CABLE

¡ Remove circular cable (RF cable) (surplus cable) plugged in “ANT.IN” jack in rear panel of TV.

Connect the cable to “ANT” jack in rear panel of DVD-Video.

™ Connect TV to DVD-Video. Connect “TV” jack in DVD-Video with “ANT.IN” jack in TV with RF

cable.

INPUT 1

ANT IN

INPUT 2

REAR PANEL OF DVD-VIDEO

REAR PANEL OF TV

AUDIO/VIDEO CABLE

£ (If there is AUDIO/VIDEO INPUT jack in TV)

Connect VIDEO OUT jack in DVD-Video to VIDEO IN jack in TV, and AUDIO OUT jack in
DVD-Video to AUDIO IN jack in TV with connecting cable of Audio/Video jack.

Select VCR mode by pressing TV/INPUT button in TV, you can view more clear screen and sound
than connection with RF cable only.

• VHF: 1 ~11 channels of TV / • UHF: 21~69 channels of TV

• CATV: Broadcasting is transmitted with cable from broadcasting station by contract with the station and
consumers. It does not need any antenna.

• In/Out jack in Audio/Video terminal:

- In: A jack used to receive signal required in this unit from other units.

- Out: A jack used to send signal of this unit to other units.

• Connect with Audio/Video terminal, you can enjoy more clear video and audio.
(Use INPUT button in this REMOTE to select video mode.)

INPUT 1

OUT

VIDEO (L) AUDIO (R)

ANT IN

INPUT 2

REAR PANEL OF DVD-VIDEO REAR PANEL OF TV

RF CABLE

Installation

14 15

Connecting with Other VCR or Camcorder

How to Connect with Jack in Front Panel

How to Connect with Jack in Rear Panel

INPUT 1

OUT

VIDEO (L) AUDIO (R)

ANT IN

INPUT 2

REAR PANEL OF DVD-VIDEO REAR PANEL OF TV

RF CABLE

¡ Connect AUDIO/VIDEO OUT jack in Camcorder(or playback video) to AUDIO/VIDEO IN jack

in rear panel (or front panel) of DVD-Video with connecting cable.

™ Connect “ANT. IN” jack in TV to “TV” jack in DVD-Video with RF cable.
£ To record contents of camcorder or playback video with DVD-Video, insert recording tape attached

recording tab in DVD-Video.

¡ Turn on DVD-Video.
™ Press [INPUT] button of remote control and adjust DVD-Video to display “AV” or “AV.F” in TV

screen.

£ Press [PLAY] button in Camcorder or playback video.
¢ Press [REC] button in DVD-Video if you want to record contents of camcorder or playback video.
∞ Press [Pause] button in DVD-Video when unnecessary or undesired scene is displayed in

recording.

(Caution) Recording is released automatically after 5 minutes since pressing [PAUSE] button.

Press [REC] button if you want to record again.

¡ Turn DVD-Video on.
™ Press [INPUT] button of remote control and adjust DVD-Video to display “AV” or “AV.F” in TV

screen.

£ Insert tape in camcorder and playback it.

How to Copy(Edit) Tape with Other VCR or Camcorder

How to Playback Chapter Photographed by Camcorder

FRONT PANEL OF DVD-VIDEO

REAR PANEL OF PLAYBACK VCR(CAMCORDER)

Installation

16 17

Connecting with Audio

How to Connect with Stereo Unit such as Audio

Connecting to a television with Component
jack and a Dolby Digital Amp.

How to Connect

(L) AUDIO (R)

REAR PANEL OF DVD-VIDEOREAR PANEL OF STEREO UNIT

DIGITAL

AUDIO OUT

¡ Connect Audio jack. Connect AUDIO OUT in rear panel of DVD-Video to IN jack of stereo sound

unit.

™ For Input Select in stereo unit, Select “External Input” connected with DVD-Video.
£ Playback DVD disc or Hi-Fi videotape, you can hear sound in speaker of stereo unit.

■ Use in COMPONENT In jack attached in TV or amp supporting Dolby Digital.

(NOT SUPPLIED)

(L) AUDIO IN (R)

REAR PANEL OF DVD-VIDEO

DOLBY DIGITAL DECODER-AMPLIFIER

TV CONNECTIONS

COMPONENT IN

CONNECTING CABLE

Manufactured under license from Dolby Laboratories.
"Dolby" and the double-D symbol are trademarks of Dolby Laboratories.

“DTS” and “DTS Digital Out” are trademarks of Digital Theatre Systems, Inc.

Basic Operation

18 19

Initial Installation

Setting up the player

■ Switch the TV on.

■ You can also start "AUTO SEARCH" in the SETUP "PR PRESET"

➝

"AUTO SEARCH".

■ To tune in new stations (manual tuning) and to enter station names see page 27-28.

LANGUAGE SET

ENGLISH
DEUTSCH
ITALIANO
ESPAÑOL
FRANÇAIS
NEDERLANDS

PR+/-:SELECT
OK:CONFIRM SETUP:END

SETUP:END

PLEASE WAIT...

CH 25

You should see this picture the first time you switch on the TV
and player.

Choose your language.

2

Press on the remote control and RF36 will be displayed on
the front of your player.

Select a free channel on your TV and manual tune the channel
until the blue screen as shown in step 2 appears. Refer to the TV
manual for more details.

1

Then choose your country.

3

OK for "AUTO SEARCH!".

"AUTO SEARCH" tunes in all the stations you can receive in your
country.

4

• If you don't see the menu picture below after you press the menu button it may be because you
don't use a RCA cable and you need to tune the television to the player (see 'Connecting your
player through RF lead' on page 12). Normally a new player outputs a signal via the RF lead on
transmission channel 36. Search for the menu picture with the channel tuning function of your TV
set (see its user manual). Some televisions allow you to key in the transmission channel number in
their tuning set-up menu.

• In case there will be interference problems with other transmission channels when the player
outputs a signal on transmission channel 36, the AUTO SEARCH process usually recommends an
alternative, as in step 4.

• There is a another way of setting RF output channel, if needed please see 'Connections and
Assembling on page 35'. It does not apply to models which do not generate the RF output signal.

CHECK IT!

COUNTRY SET

AUSTRALIA
NEW ZEALAND

PR+/-:SELECT
OK:CONFIRM SETUP:END

Press the [OK] button to confirm the recommended RF channel.

Should you wish the stations to have the same numbers as those
used on the TV, follow the instructions in "Sorting programme
locations" on page 28.

Else ...
exit the basic installation function and enjoy your player.

7

Should you wish the stations to have the same numbers as those
used on the TV, follow the instructions in "Sorting programme
locations" on page 28.

Else ...
Press the SETUP button to exit the set-up menu and enjoy your
player

8

PLEASE CHANGE THE TV
CH TO 34.

IMPORTANT!

RF OUTPUT SET

0-9:SELECT(21-69)
OK:CONFIRM SETUP:END

CURRENT CH 36
RECOMMENDED CH 34

If other stations are positioned on near the current RF OUTPUT
CH, the guide message appears automatically.

The player recommends the optimal RF OUTPUT CH number
automatically.

6

If the clock has not been set, the clock setting screen will appear.

Please see “Setting time and date” on page 20.

5

• If the signal from the player is coming into the TV through
the RF lead, the picture will disappear when you press OK
at step 8. You will need to re-tune your television to the new
UHF transmission channel.

MANUAL SET

PR01 P-01 PR08 P-08
PR02 P-02 PR09 P-09
PR03 P-03 PR10 P-10
PR04 P-04 PR11 P-11
PR05 P-05 PR12 ---­PR06 P-06 PR13 ---­PR07 P-07 PR14 ----

PR+/-:SELECT
OK:CONFIRM SETUP:END

Up [PR+], down [PR-], OK and 'confirm'

• Notice the on-screen prompts which the video recorder generates to tell you which button to press. In general

the up and down 'navigation' buttons select or highlight something and the OK button confirms it .

• [PR+] and [PR-] are the same buttons as 'up' and 'down'.

• In the DVD section it is usually the left and right buttons which 'select'.

CLOCK SET

0-9:SETUP (HOUR)

/➝:CORRECT SETUP:END

TIME - - : - -

DATE - - / - - /- - - -

➝

Basic Operation

20 21

OSD ON & OFF

Output Select

Press [DVD] button.

If DVD mode is correctly selected, DVD on the operation display
window is lit. Then, REMOTE button works as DVD function. Press the
[DVD] button, then the mode of DVD-Video Player becomes to the
OPERATION mode.

Press [VCR] button.

If VCR mode is correctly selected, DVD on the operation display
window goes out. Then, REMOTE button works as VCR function. Press
the [VCR] button, then it becomes to the VCR OPERATION mode.

Press [INPUT] button.

When you press [INPUT] button, BROADCASTING RECEPTION and EXTERNAL INPUT is selected. But, it
is not operated in PLAY, REC and DVD mode.

Call the player’s "SETUP".

1

Choose “VCR SETUP”.
And press the [OK] button.

2

Select “OSD ON/OFF”.
If you want OSD OFF mode, select it and press [OK] button to
confirm.
Then OSD characters are not displayed in the normal picture.

3

This player is set to “OSD (On Screen Display) ON” mode before shipping and you can change it
to OFF mode.

VCR SETUP
CLOCK SET
LANGUAGE SET
RF OUTPUT SET
OSD ON/OFF

PR+/-:SELECT
OK:CONFIRM SETUP:END

OSD ON/OFF

ON
OFF

PR+/-:SELECT
OK:CONFIRM SETUP:END

SETUP

TIMER PROGRAM
PR PRESET
VCR SETUP
TAPE CONTROL

PR+/-:SELECT
OK:CONFIRM SETUP:END

To Select DVD

To Select VCR

To Select Watch Modes or External Input

■ Press [VCR] button on the remote control to change into VCR Mode and follow the procedure

below.

Call the player’s "SETUP",
choose "VCR SETUP", then "CLOCK SET".

1

Move to the position you want to change and type in the
new values.
Wait a few seconds after typing a one-digit number.

2

Store with [OK] button and exit with [SETUP] button.

CLOCK SET

0-9:SETUP (HOUR)

/➝:CORRECT SETUP:END

TIME - - : - -

DATE - - / - - /- - - -

CLOCK SET

0-9:SETUP (HOUR)

/➝:CORRECT

OK:CONFIRM SETUP:END

TIME 06:05

DATE 08/08/2004(SUN)

Setting time and date

Setting time and date

➝

➝

Basic Operation

2322

DVD Playback

Press [ ] button to power on.

Press [DVD] button of REMOTE to change into DVD mode.

Press [OPEN/CLOSE] button to open the disc tray.

Place a disc firmly on the disc tray, making its label look upward.

Insert the disc and press [OPEN/CLOSE] button to close the tray.

The disc tray is closed and after checking the disc’s condition, Playback or Stop
function starts to operate.

1

2

3

To playback it, press [PLAY/PAUSE] button.

• In the case of DVD,
DVD menus and titles are displayed on TV screen.

• In the case of S-VCD and VCD2.0
the menus are displayed on TV screen and it is converted into PBC(Playback
Control) mode.

• In the case of CD, VCD1.1 and MP3,
the disc plays.

4

To stop it, press [ ] button.

For pause, press [PLAY/PAUSE] button in playback mode.
If you press this button once more, it starts playback again.

5

Press [OPEN/CLOSE] button to remove the disc.

6

Various Playback Methods

■ If you want fast forward (or reverse) playback, press [

√√√√

] or [

œœœœ

]button in
Playback mode. You can watch fast playing (reverse ) screen.
* This reverse playback can be unavailable for certain DVD.

■ If you want slow (or reverse) playback, press [

√√√√

] or [

œœœœ

] button in Pause mode.

You can watch the desired screen in the slow forward (reverse) playback.

* For the case of Video CD, this reverse slow playback function is unavailable.

The mark will appear.

■ If you want still picture, press [PAUSE] button in Playback mode. You can watch

the desired screen in Pause status.

VCR Playback

Press [ ] button to power on.

Press [VCR] button of remote control to change into VCR mode.

Insert the desired tape.

If you want to playback it, press [PLAY/PAUSE] button.

When the operational status is flickering or poor, adjust it with [TRACKING
+/-] button.

1

2

3

To stop it, press [ ] button.

For pause, press [PLAY/PAUSE] button in playback mode.
If you press this button once more, it starts playback again.

4

Press [EJECT] button in the front part or [OPEN/CLOSE] button on remote
control to remove the tape.

5

If the product, which
has a auto-detector,
detects a contaminated
head(s), it shows the
conditions to notice the
contamination on
screen.

Various Playback Methods

■ If you want fast forward (or reverse) playback, press [

√√√√

] or [

œœœœ

] button in

Playback mode. You can watch fast playing (rewinding) screen.

* NOTE: You might see no color noise band when you fast forward (or reverse)

playback the tape which is recorded in LP mode.

■ If you want Still picture, press [PLAY/PAUSE] in Playback mode. You can watch

the desired screen in pause status.

■ If you want slow-motion playback, press [

√√√√

] button in Pause mode. You can

watch the desired screen in the slow forward playback.

* NOTE: VCR doesn’t have Slow Reverse Playback function.

■ If you want to watch a series of screens one by one, (FRAME ADVANCE) press

[NEXT

√√√√

❚ ] button in Pause mode. Each time you press this button, the picture

advances one frame.

■ If you press [REPLAY] button in playback mode, the player quickly rewinds 15

seconds of the tape and plays it.

■ If you press [CM SKIP] button in playback mode, the player quickly skips 30

seconds of the tape and plays it.

To Adjust Display

This product includes automatic Tracking function and enables users to enjoy clear
picture without an additional operation. Provided that the following problems can be
solved by the manual adjustment, which improves display quality. (During automatic
display adjustment, “Adjusting Display” are displayed on TV screen.)

- If the screen is poor in Playback mode,

- If noises occur in the upper or lower part of screen in slow playback mode,

- If paused picture vibrates up and down.
Use [TRACKING +/-] buttons of remote control to adjust the display suitable for watching.

Basic Operation

24 25

1

1 If you want to playback DVD during recording with video, insert a DVD disc.

Place the desired DVD disc on DVD tray, press [DVD] button to convert OUTPUT
into DVD mode and press [PLAY] button. Then, you can watch DVD.

2

2 If you want to watch a TV channel during DVD recording with video, press

[VCR] button to convert OUTPUT into VCR mode and press [PR+/-] button.

Then , you can watch a TV channel.

Press [ ] button to power on.

• Press [VCR] button of remote control to change into VCR mode.

Insert a recordable tape.

Insert a tape with recording tab.

With [CHANNEL], [NUMBER] and [INPUT] buttons, select the desired
broadcasting channel or external input unit to record.

1

2

3

Select the desired speed (SP or LP) with [SPEED] button.

4

Press [REC] button.

Then, it starts recording.

5

If you want to pause recording, press [PAUSE] button.

After pressing [PAUSE] button, if the pause status continues for five minutes,
the recording is released automatically.

6

To exit recording, press [STOP] button.

7

Recording

To Record With VCR

To Enjoy a TV Channel or DVD during recording

Recording

“This product incorporates copyright protection technology that is protected by
U.S patents and other intellectual property rights.
Use of this copyright protection technology must be authorized by Macrovision,
and is intended for home and other limited viewing uses only unless otherwise
authorized by Macrovision. Reverse engineering or disassembly is prohibited.”

1

1 Insert the desired DVD disc.

When it is a DVD disc with copy protect function, you can’t copy it.

Insert a recordable tape.

2

2 Press [REC] button during playing of DVD.

DVD plays and VCR starts recording.

3

3 If you press STOP [ ] button in DVD mode, DVD and VCR will stop at the

same time.

If you press STOP [ ] button in VCR mode, VCR stops to record and DVD
continues to play.

To Copy From DVD To Videotape

VCR Operation

26 27

Recording

■ When your urgent business happens suddenly in watching TV or you want to record the current TV

program for the desired time, follow the procedures below.

1

1 First, follow the steps 1 to 4 in “Recording With VCR”.

2

2 Press [REC] button as much as you want. See the “Recording Times Table”

below.

Once continuous recording until you press STOP button
Twice recording for 30 mins from current time
3 (times) recording for 1 hour

21 recording for 10 hours
22 returning to the status of Once Press

3

3 To stop Recording mode, press [STOP] button more than 5 seconds.

One Touch timer Recording (OTR)

Tuning in New Stations

■ The TV and player are switched on.

■ To see the picture from your player, press the input or AV (Audio/Video) button on the TV.

To complete the set-up of your video recorder when the
auto set has not stored all of the channels or when you wish
to store a new channel.
Call the video’s "SETUP", choose "PR PRESET".

1

Select "MANUAL SET".

2

Choose any unused location number "----" or "P-xx" ...

It's simplest to use the same location number on both the
TV and video.

... and confirm.

3

Set the station you want:

• the programme location number;

• the broadcast system you want (Aerial(CH) or
Cable(CC)),

• You can directly enter the real channel number with the
[0 to 9] buttons, or search by pressing [

œœ /√√

],

• The fine tuning you can adjust,

• Change or create the station name.

4

Once you see the station you want, store it.

Tune in further stations (from step 3 onwards) or exit
tuning mode.

5

PR PRESET

AUTO SEARCH
MANUAL SET
PR ERASE
PR ALIGN

PR+/-:SELECT
OK:CONFIRM SETUP:END

MANUAL SET

PR+/-: UP/DOWN

/➝: SELECT

OK:CONFIRM SETUP:END

MANUAL SET

PR01 P-01 PR08 P-08
PR02 P-02 PR09 P-09
PR03 P-03 PR10 P-10
PR04 P-04 PR11 P-11
PR05 P-05 PR12 ---­PR06 P-06 PR13 ---­PR07 P-07 PR14 ----

PR+/-:SELECT
OK:CONFIRM SETUP:END

PR 04
RECEPTION AERIAL
AUTOSEARCH CH

_ _
FINE TUNING
NAME

_ _ _ _

MANUAL SET

PR+/-: UP/DOWN

/➝: SELECT

OK:CONFIRM SETUP:END

PR 03
RECEPTION AERIAL
AUTOSEARCH CH 03
FINE TUNING
NAME

_ _ _ _

MANUAL SET

PR+/-: UP/DOWN
0/1: CHANGE/CREATE
OK:CONFIRM SETUP:END

PR 03
RECEPTION AERIAL
AUTOSEARCH CH

_ _
FINE TUNING
NAME

_ _ _ _

Tuning

➝

➝

VCR Operation

28 29

■ If your player is showing no station name or is showing a station name incorrectly, you can correct

this.

Call this menu (just see the previous page),
if it isn't displayed.

Select NAME position.
Press the [0] button to change the given name.
Or press the [1] button to create the station name.

1

Either select the name from the stored list or you
create the station name and enter a 4-digit name.
Change the letters with the [PR +/–] buttons,

move to the next letter with the [

œœ /√√

] buttons.

2

Store and exit.

3

MANUAL SET

PR+/-:SELECT
OK:CONFIRM SETUP:END

PR01 P-01 PR08 P-08
PR02 P-02 PR09 P-09
PR03 P-03 PR10 P-10
PR04 P-04 PR11 P-11
PR05 P-05 PR12 ---­PR06 P-06 PR13 ---­PR07 P-07 PR14 ----

MANUAL SET

PR+/-: UP/DOWN
0/1: CHANGE/CREATE
OK:CONFIRM SETUP:END

PR 01
RECEPTION AERIAL
AUTOSEARCH CH01
FINE TUNING

NAME

_ _ _ _

MANUAL SET

PR+/-: SELECT CHARACTER

/➝: SELECT POSITION

OK:CONFIRM SETUP:END

PR 01

RECEPTION AERIAL

AUTOSEARCH CH

_ _
FINE TUNING
NAME O

_ _ _

If the location numbers used for programmes stored in your TV and player are different, you can change them on
the player. To do this, move the stations to the right numbers, until they are arranged the way you want.

1

1 Call the player’s "SETUP",

choose "PR PRESET" then "PR ALIGN".

2

2 Select the programme to swap.

Confirm by pressing OK button.
Move the station to the desired location number.
Confirm by pressing OK button.

1

1 Call the player’s "SETUP",

choose "PR PRESET" then "PR ERASE".

2

2 Select the station (location number) you want to clear.

Review the picture by pressing [

œœ

] button.

Clear by pressing OK button.

PR ERASE

PR+/-:SELECT

:PR VIEW

OK:ERASE SETUP:END

PR ALIGN

PR+/-:ALIGN

:PR VIEW

OK:CONFIRM SETUP:END

PR01 P-01 PR08 P-08
PR02 P-02 PR09 P-09
PR03 P-03 PR10 P-10
PR04 P-04 PR11 P-11
PR05 P-05 PR12 ---­PR06 P-06 PR13 ---­PR07 P-07 PR14 ----

PR01 P-01 PR08 P-08
PR02 P-02 PR09 P-09
PR03 P-03 PR10 P-10
PR04 P-04 PR11 P-11
PR05 P-05 PR12 ---­PR06 P-06 PR13 ---­PR07 P-07 PR14 ----

Tuning in New Stations Tuning in New Stations

Station names

Sorting programme locations

Clearing programme locations

➝

➝

➝

VCR Operation

30 31

Timer Recording

■ For timer recordings, clock, date, and stations must be set correctly.

■ Load a cassette with its safety tab in place and with sufficient free space for the recording.

Press "SETUP", choose "TIMER PROGRAM". Press OK.
Choose a free programme location. Press OK.
You will be asked if you want to record "ONCE", "WEEKLY"
or "DAILY".

Please decide and confirm with OK.

1

Type in one after the other:

• The programme location number;

• the time the broadcast starts,

• the time the broadcast ends,

• the day of the broadcast, if it is not today.

• Select LP if you wish to make a very long recording .

2

If you wish to make changes:
Move to the position you want to change using the [œœ/

√√

]
buttons. Change the setting using the [PR+/- ] or [number]
buttons.

If all setting are ok, press [œœor √√], till you see “OK :
CONFIRM” in the bottom line.
Confirm.

3

Switch your player off.

• Wait a few seconds after typing a one-digit-number.

• If you have made a mistake, move to the position you want to change using the [

œœ/√√

] buttons

and change the setting.

• If programme timings overlap, the machine will give a warning message. If you don’t adjust
the times, the machine will record the first programme completely then continue with the
second one.

• If there is no sufficient free space for the recording on the cassette the video switches
automatically to “LP” for double recording capacity.

• The recorder will eject cassettes which have the safety tab removed.

• The player will be powered on and record the program at the set time.

• In case the player is powered on after setting of timer recording, the player cannot record in

VCR mode but can record in DVD mode.

PR+/-:SELECT(AV)
0-9 :SETUP(PR)

/➝:CORRECT SETUP:END

PR -­START TIME --:-­END TIME --:-­START DATE --/-­TAPE SPEED SP

TIMER PROGRAM (ONCE)

PR 01
START TIME 18:10
END TIME 20:30
START DATE 22/08(FRI)
TAPE SPEED LP

PR+/-:SELECT(AV)

0-9 : SETUP (PR)

/➝:CORRECT

OK:CONFIRM SETUP:END

TIMER PROGRAM (ONCE)

HOW OFTEN DO YOU WANT
TO RECORD THIS PROGRAM?

PR+/-:SELECT
OK:CONFIRM SETUP:END

ONCE
WEEKLY(ONCE A WEEK)
DAILY(MON-FRI)
DAILY(MON-SAT)
DAILY(MON-SUN)

Normal timer recording

Timer Recording

Call the player’s "SETUP",
choose "TIMER PROGRAM".

1

Select the programming to change or erase, press
OK.
If you want to erase this programming press
button [0].

If you wish to make changes, move to the position
you want to change using the [

œœ

or √√] buttons.

Change the settings using the [PR +/–] buttons.

If all settings are correct, press OK to confirm the
changes. Exit the menu with SETUP.

2

TIMER PROGRAM

PR START END DATE
03 21:20 22:20 16/08

01 18:10 20:30 22/08

-- -- : -- -- : -- -- / --

-- -- : -- -- : -- -- / --

-- -- : -- -- : -- -- / --

-- -- : -- -- : -- -- / --

-- -- : -- -- : -- -- / --

-- -- : -- -- : -- -- / --

PR+/-:SELECT
OK:CONFIRM SETUP:END

TIMER PROGRAM (ONCE)

PR 03
START TIME 21:20
END TIME 22:20
START DATE 16/08(SAT)
TAPE SPEED SP

0 :ERASE

/➝:CORRECT SETUP:END

Timer Review – changing and erasing

➝

➝

➝

VCR Operation

32 33

More Functions

■ The counter counts in real time from the point you load the cassette. This does not have to be its

beginning! The counter does not count unrecorded parts of the tape.

■ If you rewind beyond the zero position, the counter counts in negative values (e.g. – 0:01:15).

Each time you press [DISPLAY] button,
1x: Time and date+current status ➝Time and date
2x: Counter+current status ➝counter
3x: disappear.

• If didn’t wind tape (PLAY, FF, REW,...), it doesn’t appear the tape remain time.

STOP SP PR01 ARD

14:00 10/08 E180 00:48

STEREO ON

V

When you want the player to show the time remaining from the current player tape position (to find out if
there is sufficient space for a recording, for example).
To ensure the remaining time shown is accurate, select the length of cassette currently loaded by selecting
this function until you reach the correct length.

Call the player’s "SETUP",
choose "TAPE CONTROL"

• Remaining time display is
only possible when the
cassette is loaded.

TAPE CONTROL

TAPE REMAIN

E-240 01:27

TAPE REMAIN
GO TO ZERO
COUNTER RESET
INDEX+
INDEX-

E-180
E-240
E-300

PR+/-:SELECT
OK:CONFIRM SETUP:END

PR+/-:SELECT
OK:CONFIRM SETUP:END

When you record a program, the VCR places an index mark at the start of
the recording.

To search for an index mark

1. Press "SETUP", choose "TAPE CONTROL"

2. Choose INDEX + to search forward, or INDEX - to search backward.
The VCR will locate your index mark and will start playing the tape at
the previously set index mark.

TAPE CONTROL

TAPE REMAIN
GO TO ZERO
COUNTER RESET
INDEX+

INDEX­PR+/- :SELECT
OK:CONFIRM SETUP:END

Clock / counter display

Remaining time and cassette length

Searching for a recorded program via index

Reset the counter.

COUNTER RESET

0:00:00

If you press the [PLAY] button for 5secs during stop or still mode, it goes Auto repeat mode. This player plays
repeatedly the tape from the beginning to end parts.

To release this mode, press the [ ] button or mode operation button. (PLAY, FF, REW or STOP)

Call the player’s "SETUP", choose
"VCR SETUP", then "LANGUAGE SET".

Select your language.
Confirm.

LANGUAGE SET

PR+/-:SELECT
OK:CONFIRM SETUP:END

More Functions

ENGLISH
DEUTSCH
ITALIANO
ESPAÑOL
FRANÇAIS
NEDERLANDS

Resetting the counter to zero

AUTO REPEAT

SETUP languages

The player will wind to the position 0:00:00 and stop.

REW SP
GO TO ZERO

0:02:13

Accessing counter zero position

Dimmer : Your player dims its display when switched to stand-by mode.
Auto power off : Your player switches to stand-by when no tape is played and no station is received for more

than 5 minutes.

Press the [ ] button for about 5 seconds.
No buttons of front panel can be operated now and LOCK INDICATOR (“ ”) will be
displayed on window display. Keep your remote control in a safe place.
To release child lock, press any button of the remote control.

Use only good quality tape cassettes with the VHS logo.

•Keep cassettes away from excessive moisture or dust, magnetic and electrical fields
(loud speakers and computer monitors, for example).

•Always wind the tape to the beginning when you have finished. Store with the full
spool at the bottom and with the cassette in its cover.

You can protect your precious recordings from being wiped by breaking out the safety
tab on the side of the cassette (some cassettes have a slide). Should you wish to re-use
the tape after removing the tab, cover the hole with adhesive tape.

PAL

Cassettes

and ...

Child lock

VCR Operation

34 35

More Functions

■ The player machine records the complete sound signal transmitted by the TV station.

■ On the mono VCR, you will hear the normal mono sound.

In addition to the normal mono sound track of VHS video recorders, your player machine is equipped with a
high-quality Hi-Fi sound system.

This means you can enjoy

• films with excellent stereo sound

• films of full-length concerts in high quality stereo

• films with impressive Surround Sound using additional Surround equipment

• films with two dialogue modes (dual, bilingual), usually the original sound track and dubbed sound track

• VHS cassettes with Hi-Fi stereo sound and VHS cassette with normal sound

During Stop, the player displays what the current station is broadcasting. When
you switch to another station or the current station changes the sound mode, your
player displays the programme and sound mode on screen (if not, press AUDIO).

• “STEREO” = stereo
“BIL I / BIL II ”=bilingual

nothing= monaural sound

During Playback, the player displays what is recorded on
the cassette (if not, press AUDIO).

• “Hi-Fi” = stereo/bilingual
nothing = monaural sound

STOP SP PR10 EURO

STEREO ON

PLAY SP Hi-Fi

L+R

During a stereo performance (playback-”Hi-Fi”/ broadcast

- “STEREO”):
Hi-Fi stereo ➝ left audio channel only ➝ right channel
only ➝ the normal mono sound track of a Hi-Fi cassette

• During broadcasting a bilingual performance : Main
language (original sound track) ➝sub-language
(dubbed) ➝both main language and sub-language

➝

OFF.

• For mono performances , there is no choice available.

PLAY SP Hi-Fi

L+R
HI-Fi
LEFT

Hi-Fi

RIGHT
Hi-Fi
OFF

The Hi-Fi system

What you can listen to

Choice of sound output

STOP SP PR10 EURO

BIL

BIL I

II

BIL

I+II

BIL
OFF

Connections and Copying

■ If you are using a RCA cable, select the AV input on the TV to see the picture from the player.

■ If you are not using a RCA cable, select the button number on the TV reserved for video input to

see the picture from the player.

If you are not using a RCA cable, your player can transmit pictures and sound to the TV via the coax aerial
cable. Just tune the TV to the player's transmitting channel (factory set to UHF CH36). Tune the TV carefully to
ensure the best pictures and sound.

Once you have carried out the steps in "Connecting up your player with
RF lead" , switch on your TV.
Press the [ENTER] button of the player’s remote control longer than 5
seconds to call the player´s test picture.
Tune the TV to the test picture using the channel pre-set functions of your
TV as described in its manual.
When you have found the test picture, store it under the button number on
your TV for player input.
Press the [ENTER] button of the player’s remote control again longer than
5 seconds to release the test picture.

1

• If the quality of the test picture transmitted to the TV is poor due to
interference caused by a station transmitting on channel 36, you can tune
the player to a different transmitting channel.

Find a free channel between 21 and 69 on your TV.

Call the player’s "SETUP" choose "VCR SETUP" then "RF OUTPUT SET".

Type in the free channel.

Store and exit.

2

• If the quality of the test picture transmitted to the TV is poor, fine-tuning on the TV may
help (refer to the TV manual).

• Without a RCA cable, you will not get stereo sound from a TV capable of stereo sound.

RF OUTPUT SET

0-9:SELECT (21-69)
OK:CONFIRM SETUP:END

CH 36

To the TV via antenna cable (if you are not using a RCA cable)

36 37

Connections and Copying

Should you wish to assemble your own film, from camcorder footage for example, use the assembly technique
for smooth edit points:

• The symbol is lit in VCR mode and goes out in TV
mode.

• This symbol means the cassette is in.

• This symbol means a timer recording is setting.

For the best results, the source cassette from which
you are recording should already be playing back
when you start recording.

Assembling

To move to next chapter (or track), press [

√√❚

NEXT] button.

The current chapter (or track) moves to the next chapter (or track).

Press [

❚œœ

PREV] button.

The current scene moves to the previous chapter (or track) or first scene of current
chapter (or track).

Press the [TITLE/PBC] or [MENU] button.

A list of the titles on the disc is displayed.

* For the case of VCD disc, menu screen will

appear only when the disc has PBC function
and PBC ON is activated.

1

Press the [ENTER] button or [PLAY] button
after pressing the [

œ √…†

] button to select

the desired title.

For the case of VCD disc, press the [Number]
button.
The selected title now starts playing.

2

■

Some movie discs may contain multiple titles. If the disc has a movie title menu recorded on it, the [TITLE/PBC] or
[MENU] button can be used to select the movie title. Details of operation may differ depending on the disc used.

* Selecting a title may not be available on certain DVD discs.

Playing a desired scene

To skip scenes in a disc

Directly moving to a desired title

DVD Operation

DVD Operation

38 39

■ You may repeat a defined period from A to B.

A MP3 disc may
not be repeated
from A to B.

At the point where you want to start the repeat
playback, press [A-B] button.

The right figure appears and repeat playback start
position (A) is set.

1

At the point where you want to end the repeat
playback, press [A-B] button again.

The repeat playback end position (B) is set and a
defined period from A to B is playback repeatedly.

2

To exit from repeat playback mode, press [A-B]
button.

It enters into Normal Playback mode.

3

• CHAPTER : Current chapter will play repeatedly.

• TITLE : Current title will play repeatedly.

• TRACK : Current track will play repeatedly.

• ALL : Current disc will play repeatedly.

• Repeat one : Current file will play repeatedly.

• Repeat all : All files on the disc will play repeatedly.

• Random : Tracks on the disc will play in random order.

• OFF : Repeat playback will be cancelled.

* For the case of VCD disc, repeat playback starts only in PBC OFF mode.

- DVD -

CHAPTER

TITLE

OFF

➝➝

➝

- VCD -

TRACK

ALL

OFF

➝➝

➝

- CD/MP3 -

Repeat one

Repeat all

Random

➝➝

OFF

➝

➝

Each time you press [REPEAT] button in playback mode, repeat playback starts as below.

A-

A-B

OFF

Playing desired scene

Repeating a defined period

Repeating a defined period from A to B

Playing desired scene

If you want to search with a title number, press
[SEARCH] button one time.

It shows current and total title numbers. Please enter
the new title number to be searched using the
[NUMBER] buttons.

1

If you want to search with a time, press
[SEARCH] button three times.

Please enter the new time to be searched using the
[NUMBER] buttons.

In completing entering, please press [ENTER]
button.

PLAY starts from the selected position.

3

If you want to search with a chapter number,
press [SEARCH] button twice.

It shows current and total chapter numbers.
Please enter the new chapter number to be searched
using the [NUMBER] buttons.

2

001/003

➟

total title
number

➟

current title
number

001/023

➟

total chapter
number

➟

current chapter
number

01:03:20

➟

current time

Searching DVD with a title number, a chapter number or a time

DVD Operation

40 41

Playing desired scene

If you want to search with a track number, press
[SEARCH] button one time.

In case of PBC OFF, the screen like the right figure
appears. It shows current and total track
numbers. Please enter the new track number to
be searched using the [NUMBER] button.

* If it is PBC ON, pressing track number converts PBC

to OFF mode automatically.

1

In completing entering, please press [ENTER].

PLAY starts from the selected position.

3

If you want to search with a track time, press
[SEARCH] button twice.

In case of PBC OFF, the screen like the right figure
appears.
It shows total track time.
Please enter the new time to be searched using the
[NUMBER] button.

2

001/013

➟

total track
number

➟

current track
number

01:03:20

➟

current time

■ Storing a MARKER in the DVD memory is similar to marking your page in a book. It allows you to

quickly return to any point on the disc.

Storing a marker in the memory.

Press [MARK] during play and press [ENTER] at
the starting point to be viewed (listened to) again.

1

Recalling/Clearing a marker

Press [MARK] during playback. Press [œ √] to select the marker to be
recalled/cleared.

Press [PLAY] to recall a marker. Or press [CLEAR] to clear a marker.
Play resumes from the point corresponding to the selected marker, or the

selected marker is cleared.

2

1 - - - - - - - -

Searching VCD with a track or track time

Storing markers in memory to be viewed (listened to) again

Confirming the current PLAY mode on screen

While in playing, press [DISPLAY] button.

It shows the current disc mode.
If you want to change the mode, select the item with up/down (…†) cursor and enter
the new settings with [number], [œ] or [√] button. In completing entering, press
[ENTER] button.
To exit from Display mode, press [DISPLAY] button again.

➟ current title / total title
➟ current chapter / total chapter
➟ time elapsed
➟ subtitle selected / current subtitle / total subtitle
➟ audio language selected / current / total audio language
➟ repeat playback mode
➟ current angle / total angle

001/003

001/023

00:01:03

ENG 01/01

ENG 01/03

OFF

01/01

0-9

Confirming the current DVD disc mode

DVD Operation

42 43

Confirming the current PLAY mode on screen

While in playing, press [DISPLAY] button.

It shows the current disc mode.
If you want to change the mode, select the item with up/down (…†) cursor and enter
the new settings with [number], [œ] or [√] button. In completing entering, press
[ENTER] button.
To exit from Display mode, press [DISPLAY] button again.

It shows the current disc mode.
If you want to change the mode, select the item with up/down (…†) cursor and enter
the new settings with [number], [œ] or [√] button. In completing entering, press
[ENTER] button.

➟ current track / total track number
➟ time elapsed
➟ repeat playback mode
➟ PBC mode

001/003

00:01:03

OFF

ON

➟ disc mode / current playback file name
➟ current track / total track number,

time elapsed / total time, repeat playback mode

MUSIC

■ 000/000 0:00:00 / 0:00:00

\

PROGRAMLIST

max 6
SKY
winamp

_ _ _ _
_ _ _
_ _ _ _ _
_ _ _
_ _ _ _ _

0-9

Confirming the current VCD disc mode

Confirming the current CD, MP3, JPG, MPG disc mode

MUSIC file select

JPG file select

MPG file select

➟
➟
➟

➟ current cursor file name

* For more information, refer to 45-48p.

Selecting an AUDIO language,
SUBTITLE language and 3D AUDIO

■ The user may select an audio language and subtitle language if a disc includes Multi-language.

Keep pressing [AUDIO] button till the user’s preferred language appears in
playback mode.

If DVD disc includes audio information, every time the user presses [AUDIO] button,
English (ENG), French (FRE), Spanish (SPA) and others appear one by one.

Keep pressing [SUBTITLE] button till the user’s preferred language appears in
playback mode.

If a DVD disc includes subtitle information, every time the user presses [SUBTITLE]
button, English (ENG), French (FRE), Spanish (SPA), ... and OFF appear one by one.

A certain disc
may not support audio
select or subtitle select.

ENG 01/03

ENG 01/01

Press [3D].

Every time you press [3D], the 3D sound toggles
between 3D ON › 3D OFF.

■ You can enjoy a virtual 3D sound effect from 2-channel sources.

ON

OFF

Selecting an audio language

Selecting a subtitle language

Selecting 3D Audio

DVD Operation

44 45

Selecting ZOOM and Multi Angle

■ The user can enlarge the current screen about 2 or 4 times.

Keep pressing [ZOOM] button till the preferred zoom appears.

Every time the user presses [ZOOM] button, a zoom magnification changes 2 times (X2)

➝

4 times (X4) ➝OFF ➝2 times (X2) ➝... one by one.
A base point to be enlarged is centre and the point can be changed with the operation of
[

œ √…†

] button.

■ If a disc includes multi angle information, the user can watch a screen in multi angles. The function is limited

to a DVD disc supporting multi angle information.

Keep pressing [ANGLE] button till the preferred
angle appears.

Every time the user presses [ANGLE] button, an angle
degrees changes in a consecutive order.

• During zoom mode,
subtitle language
can’t be seen.

01/01

Using a zoom function

Different Angle

About MP3, CDDA, JPG and MPG discs

This unit will play MP3 or CDDA files recorded on CD-R and CD-RW discs.

Turn on your television and select the channel assigned to this DVD player.

Press the DVD open [OPEN/CLOSE] button, the disc tray opens.

Put a MP3 or CDDA disc on the disc tray with the label side up.

Press the DVD open [OPEN/CLOSE] button, the disc tray closes.

The unit will take a short while to load the disc and display the directory structure.

1

The below figure appears.

2

Select the file to listen to (or view).

Move the cursor to desired file which you
want to listen to (or view) by pressing [

œ

√…†

] button

Press [PLAY] or [ENTER] to start playback.

The selected file will play.

Press [■ ] to stop playback.

4

MUSIC

■ 000/000 0:00:00 / 0:00:00

\

PROGRAMLIST

max 6
SKY
winamp

_ _ _ _
_ _ _
_ _ _ _ _
_ _ _
_ _ _ _ _

Select the folder.

Move the cursor to desired folder by
pressing [

œ √…†

] button and press

[ENTER] button to confirm.

3

MUSIC

■ 000/000 0:00:00 / 0:00:00

\

PROGRAMLIST

max 6
SKY
winamp

_ _ _ _
_ _ _
_ _ _ _ _
_ _ _
_ _ _ _ _

MUSIC > MP3
√ 001/018 0:00:34 / 0:03:59

\max 6\01(musicfamily.i.am) Smooth-

PROGRAMLIST

_ _

1. 01(musicfamily.i

2. 02(musicfamily.i

3. 03(musicfamily.i

4. 04(musicfamily.i

5. 05(musicfamily.i

6. 06(musicfamily.i

7. 07(musicfamily.i

Playing a disc containing MP3 or CDDA files

mp3

mp3
mp3
mp3
mp3
mp3
mp3

* Only MP3 or CDDA file is listed.

x2 x4

DVD Operation

46 47

About MP3, JPG and MPG discsAbout MP3, JPG and MPG discs

You can program playback.

Select the file to program. Then press
[PROGRAM].

The selected file will go into PROGRAM
folder.

Press [PLAY] or [ENTER] in PROGRAM
folder.

If you want to delete all the files in the
PROGRAM folder, select by pressing [

√

†

] and press [ENTER].

If you want to delete one file, press
[CLEAR] button.

6

The ability of this unit to read MP3 discs is dependent on the followings:

• The Bit Rate must be within 64-256 kbps.

• The maximum number of directories should not exceed 32.

• The maximum depth level of directories should not exceed 4.

•

In case that the file is recorded with the variable bit rate (VBR) in one file (Example: 54-256kbps) the
sound breaking may occur during the playback.

• File names should be named using 8 or fewer letters and/or numbers, and must incorporate the
“MP3” file extension. EXAMPLE:

********

. MP3 where each *is a letter or number.

• Use only letters and/ or numbers in file names. If you use special characters, the file and/ or folder
names may not be displayed correctly on the on-screen display.

Caution

• Try to avoid the use the CD-RW(Rewritable) disc if possible because it can not be played back
according to the recording format.

• The CD-R must be recorded with the standard format because it can not be played back according to
the recording format.

• The CD-R should be written using the ‘disc at once’ method.

• The disc which is made with ISO 9660 format can be played back.

Repeat playback mode.

Every time you press [REPEAT], repeat
playback mode changes as follows: Repeat
one ➝ Repeat all ➝ Random ➝ OFF ➝ ...

Or select by pressing [à] and press
[ENTER].

The selected file or folder will be playback
repeatedly.

5

MUSIC > MP3
√ 001/018 0:00:34 / 0:03:59 Repeat one

\max 6\01(musicfamily.i.am) Smooth-

PROGRAM

LIST
_ _

1. 01(musicfamily.i

2. 02(musicfamily.i

3. 03(musicfamily.i

4. 04(musicfamily.i

5. 05(musicfamily.i

6. 06(musicfamily.i

7. 07(musicfamily.i

MUSIC > MP3
√ 001/018 0:00:34 / 0:03:59 REPEAT FILE

\max 6\02(musicfamily.i.am) Lager T

LIST
_ _

1. 01(musicfamily.i

2. 02(musicfamily.i

3. 03(musicfamily.i

4. 04(musicfamily.i

5. 05(musicfamily.i

6. 06(musicfamily.i

7. 07(musicfamily.i

PROGRAM

6. 06(musicfamily.i

2. 02(musicfamily.i

5. 05(musicfamily.i

mp3

mp3
mp3
mp3
mp3
mp3
mp3

mp3
mp3
mp3
mp3
mp3

mp3
mp3

mp3
mp3

mp3

This unit will play JPG files recorded on CD-R and CD-RW discs.

Select the desired folder.

Move the cursor to the desired
folder by pressing […†] and
press [ENTER] to confirm.

1

Slideshow Delay Time set.

Select “ Slideshow &Delay
Time” function. Then press
[ENTER] to adjust the slideshow
delay time from 0FF to 10 seconds.

* Only JPG file is listed.

2

Start the slideshow of file.

If you press [PLAY] or [ENTER]
when a JPG image is selected, a
slideshow will begin automatically
starting from the selected image.

• To stop the slideshow, press
[STOP].

To turn left, press [œ ].
To turn right, press [√].

3

Combination Play set.

Select “ Combination Play”
function.

Then press [ENTER] or [PLAY]
to enter into the playback of total
files.

A combination play will begin.

4

12/134 œ 90° √ 90°■œœ √√■√/ ■■■ DISPLAY

■ ■ ■ ■ ■

To skip to next screen (or file), press [

√√❚

].

To skip to previous screen (or file), press [

❚œœ

].

PICTURE > JPG

■ 000/000 0:00:00 / 0:00:00

\

LIST

DESKTOP
TEMPORAR
TRASH

PREVIEW

PICTURE > JPG

■ 000/000 0:00:00 / 0:00:00


LIST
__

1. BAK001

2. BAK002

3. BAK003

4. BAK004

5. BAK005

6. BAK006

7. BAK007

PREVIEW

PICTURE > JPG

■ 000/000 0:00:00 / 0:00:00


LIST
__

1. BAK001

2. BAK002

3. BAK003

4. BAK004

5. BAK005

6. BAK006

7. BAK007

PREVIEW

Playing a disc containing JPG (PHOTO) files

jpg
jpg
jpg
jpg
jpg
jpg
jpg

jpg
jpg

jpg
jpg
jpg
jpg
jpg

DVD Operation

48 49

About MP3, JPG and MPG discs

This unit will play MPG files recorded on CD-R and CD-RW discs.

Select the desired folder.

Move the cursor to the desired
folder by pressing […†] and
press [ENTER] to confirm.

1

Select the desired MPG file.

Move the cursor to the desired
MPG file. Then press [ENTER] or
[PLAY] button to playback.

* Only MPG file is listed.

2

Start the playback of MPG file.

If you press [ENTER] or [PLAY]
button, selected MPG file starts
playback.

3

MOVIE

■ 0/00 0:00:00 / 0:00:00

\

LIST

DESKTOP
MOVIE
TEMPORAR
TRASH

PREVIEW

MOVIE

■ 0/00 0:00:00 / 0:00:00

\MOVIE\320\BAK001.MPG

LIST
__

1. BAK001

2. BAK002

3. BAK003

4. BAK004

5. BAK005

6. BAK006

7. BAK007

PREVIEW

Playing a disc containing MPG (MOVIE) files

mpg
mpg
mpg
mpg
mpg
mpg
mpg

■ ■ ■ ■ ■

➟ current track / total track number
➟ time elapsed
➟ repeat playback mode

001/003

00:01:03

OFF

0-9

• To stop the playback, press [STOP].

• To skip to next movie (or file), press [

√√❚].

• To skip to previous movie (or file), press [❚œœ

].

• To view fast forward playback, press [√√].

• To view fast reverse playback, press [œœ].

If you press [DISPLAY] button,

it

shows the current disc mode.

■ If a disc includes menus, the user may use them.

Press [MENU] button.

• In case of a DVD disc, it shows menus in the disc. Also they are different

according to discs.

• If it is a VCD2.0, select PBC ON mode by pressing [TITLE/PBC] button.

* CD and VCD1.1 do not support the function.

1

If it is a DVD disc, move a cursor to a relative item with arrow buttons of [

œ

√…†

] button and select one with [ENTER] button or [PLAY] button.

2

To display menus in a disc

Displaying menus in a disc

Selecting SCAN MODE

Progressive Scan Mode

While in DISC STOP mode, press the [SYSTEM] button .

Each time you press [SYSTEM] button, the SCAN MODE changes as follows:
INTERLACED › PROGRESSIVE › INTERLACED › PROGRESSIVE.

* If SCAN MODE is set to “INTERLACED”, connect Y/Pb/Pr on the

DVD+VCR to the INTERLACED input on your TV.

If SCAN MODE is set to “PROGRESSIVE”, connect Y/Pb/Pr on the
DVD+VCR to the PROGRESSIVE SCAN input on your TV.

DVD Operation

50 51

Language Setup

While STOP or RESUME STOP, press [SETUP]
button.

1

Selecting a OSD language.

Select a OSD language to be displayed on DVD
menus with [ENTER].

2

Selecting Audio language.

Set your preferred audio language with
[ENTER]. If the audio language is set and
recorded on the DISC, it is automatically played
in the set language every time it is played.

OTHERS - - - - : Another language can be
selected. You can input 4-digit language code.

Refer to the language codes on next page. Press [CLEAR] if an
incorrect language code is entered.

3

Selecting Subtitle language.

Set your preferred subtitle with [ENTER]. If the
subtitle language is set and recorded on the
DISC, it is automatically played in the set
language every time it is played.

OTHERS - - - - : Another language can be
selected. You can input 4-digit language code.

Refer to the language codes on next page. Press [CLEAR]
if an incorrect language code is entered.

4

■ A user can set OSD language, Audio, Subtitle and Disc Menu.

In case a disc

does not include
setting languages
information, the
selected language does
not appear.

“OSD” means
“On Screen Display”.

OSD
AUDIO
SUBTITLE
DISC MENU

ENGLISH
AUTO
OFF
AUTO

OSD
AUDIO
SUBTITLE
DISC MENU

ENGLISH ✓
FRENCH
SPANISH
GERMAN
ITALIAN
PORTUGUESE
SWEDISH
DUTCH

OSD
AUDIO
SUBTITLE
DISC MENU

FRENCH
SPANISH
GERMAN
ITALIAN
PORTUGUESE
SWEDISH
DUTCH
AUTO ✓

OSD
AUDIO
SUBTITLE
DISC MENU

SPANISH
GERMAN
ITALIAN
PORTUGUESE
SWEDISH
DUTCH
AUTO ✓
OTHERS - - - -

OSD
AUDIO
SUBTITLE
DISC MENU

FRENCH
SPANISH
GERMAN
ITALIAN
PORTUGUESE
SWEDISH
DUTCH
OFF ✓

OSD
AUDIO
SUBTITLE
DISC MENU

SPANISH
GERMAN
ITALIAN
PORTUGUESE
SWEDISH
DUTCH
OFF ✓
OTHERS - - - -

Selecting Disc Menu language.

Set your preferred DISC MENU language with
[ENTER]. If the DISC MENU language is set and
recorded on the DISC, it is automatically played
in the set language every time it is played.

OTHERS - - - - : Another language can be
selected. You can input 4-digit language code.

Refer to the language codes. Press [CLEAR] if an
incorrect language code is entered.

5

Language Setup

OSD
AUDIO
SUBTITLE
DISC MENU

FRENCH
SPANISH
GERMAN
ITALIAN
PORTUGUESE
SWEDISH
DUTCH
AUTO ✓

OSD
AUDIO
SUBTITLE
DISC MENU

SPANISH
GERMAN
ITALIAN
PORTUGUESE
SWEDISH
DUTCH
AUTO ✓
OTHERS - - - -

Enter the appropriate code number for the initial settings “AUDIO”, “SUBTITLE”
and/or “DISC MENU”.

Code Language Code Language Code Language Code Language Code Language

6565 Afar 6983 Spanish 7473 Yiddish 7789 Burmese 8385 Sundanese
6566 Abkhazian 6984 Estonian 7487 Javanese 7865 Nauru 8386 Swedish
6570 Afrikaans 6985 Basque 7565 Georgian 7869 Nepali 8387 Swahili
6577 Ameharic 7065 Persian 7575 Kazakh 7876 Dutch 8465 Tamil
6582 Arabic 7073 Finnish 7576 Greenlandic 7879 Norwegian 8469 Telugu
6583 Assamese 7074 Fiji 7577 Cambodian 7982 Oriya 8471 Tajik
6588 Aymara 7079 Faroese 7578 Kannada 8065 Panjabi 8472 Thai
6590 Azerbaijani 7082 French 7579 Korean 8076 Polish 8473 Tigrinya
6665 Bashkir 7089 Frisian 7583 Kashmiri 8083 Pashto, Pushto 8475 Turkmen
6669 Byelorussian 7165 Irish 7585 Kurdish 8084 Portuguese 8476 Tagalog
6671 Bulgarian 7168 Scots Gaelic 7589 Kirghiz 8185 Quechua 8479 Tonga
6672 Bihari 7176 Galician 7665 Latin 8277 Rhaeto-Romance 8482 Turkish
6678 Bengali;Bangla 7178 Guarani 7678 Lingala 8279 Romanian 8484 Tatar
6679 Tibetan 7185 Gujarati 7679 Laothian 8285 Russian 8487 Twi
6682 Breton 7265 Hausa 7684 Lithuanian 8365 Sansrit 8575 Ukrainian
6765 Catalan 7273 Hindi 7686 Latvian, Lettish 8368 Sindhi 8582 Urdu
6779 Corsican 7282 Croatian 7771 Malagasy 8372 Serbo-Croatian 8590 Uzbek
6783 Czech 7285 Hungarian 7773 Maori 8373 Singhalese 8673 Vietnamese
6789 Welsh 7289 Armenian 7775 Macedonian 8375 Slovak 8679 Volapük
6865 Danish 7365 Interlingua 7776 Malayalam 8376 Slovenian 8779 Wolof
6869 German 7378 Indonesian 7778 Mongolian 8377 Samoan 8872 Xhosa
6890 Bhutani 7383 Icelandic 7779 Moldavian 8378 Shona 8979 Yoruba
6976 Greek 7384 Italian 7782 Marathi 8379 Somali 9072 Chinese
6978 English 7387 Hebrew 7783 Malay 8381 Albanian 9085 Zulu
6979 Esperanto 7465 Japanese 7784 Maltese 8382 Serbian

Table of language and Their Abbreviations

Setup

52 53

Video Setup

While STOP or RESUME STOP, press
[SETUP] button.

Selecting TV Aspect.

Set your preferred TV ASPECT ratio with
[ENTER] button.

2

1

■ A user can set up a connected TV condition and screen.

If a user selects “4:3 PS”, the user can watch
only a center of the original scene of “16:9”. If a
user selects “4:3 LB”, the user can watch the
original scene of “16:9”, but the top and bottom
of the screen look black color.
If a disc size is originally recorded in 4:3, a user
cannot watch it in a wide screen though a user
sets a size as “16:9 Wide”.

TV ASPECT
SCAN MODE

4:3 LB
INTERLACED

TV ASPECT
SCAN MODE

4:3 LB

✓

4:3 PS
16:9 WIDE

Selecting SCAN MODE.

You may set SCAN MODE to INTERLACED or
PROGRESSIVE.

3

* If SCAN MODE is set to “INTERLACED”,
connect Y/Pb/Pr on the DVD+VCR to the
INTERLACED input on your TV.
If SCAN MODE is set to “PROGRESSIVE”,
connect Y/Pb/Pr on the DVD+VCR to the
PROGRESSIVE SCAN input on your TV.

TV ASPECT
SCAN MODE

INTERLACED

✓

PROGRESSIVE

Audio Setup

Select a Digital Output.

Set audio output to coaxial or optical. You
can set the outgoing digital signal to
BITSTREAM or LPCM:

2

Select a Dynamic Range.

You can set the Dynamic Range as follows:

• Off : You can hear the sound as it was
originally recorded on the disc.

• Full : You can hear loud sounds softer
and soft sounds louder.

3

■ A user may select audio menu according to a user’s speaker set.

While STOP or Resume STOP, press
[SETUP] button.

1

• BITSTREAM : The raw audio signal

recorded on the disc goes to the digital
audio output.

• LPCM : The decoded audio signal goes

to the digital audio output.

DIGITAL OUT
DYNAMIC RANGE

BITSTREAM
OFF

DIGITAL OUT
DYNAMIC RANGE

BITSTREAM

✓

LPCM

DIGITAL OUT
DYNAMIC RANGE

FULL
OFF

✓

Setup

54 55

Others Setup

Select character display window.

Select "On" to make OSD (On Screen Display)
language displayed in screen.

2

Select screensaver.

If bright scenes continue to be displayed in
screen, TV can be damaged. Set the screensaver
to "On", the screensaver functions automatically
and DVD logo moves continuously if the resume
stop, stop, open status is maintained for about 5
minutes.

3

Restoring DEFAULTS.

If you press [ENTER] when the cursor
highlights RESET, “Are you sure?” message
will appear. Confirm with [OK].

This feature resets every function to its
original Factory Defaults except the Parental
Control settings.

4

Select Parental.

Press [√] button when the cursor is located in
PARENTAL.

When “INPUT PASSWORD” appears on the
screen, input the password.

Change Parental Rating level.

Once you have entered the correct
password, you can change the PARENTAL
rating by pressing […†]. And confirm it
with [ENTER].

These 8 levels of parental control, protect
children from watching violence, sexual
scenes and other objectionable material.

5

While STOP or RESUME STOP, press [SETUP]
button.

1

OSD
SCREEN SAVER
DEFAULTS
PARENTAL
PASSWORD

ON
ON
RESET
8 ADULT

OSD
SCREEN SAVER
DEFAULTS
PARENTAL
PASSWORD

ON

✓

OFF

OSD
SCREEN SAVER
DEFAULTS
PARENTAL
PASSWORD

ON

✓

OFF

OSD
SCREEN SAVER
DEFAULTS
PARENTAL
PASSWORD

RESET

Are you sure?

OK CANCEL

OSD
SCREEN SAVER
DEFAULTS
PARENTAL
PASSWORD

1 KIDS
2 G
3 PG
4 PG-13
5 PG-R
6 R
7 NC-17
8 ADULT

✓

OSD
SCREEN SAVER
DEFAULTS
PARENTAL
PASSWORD

1 KIDS
2 G
3 PG
4 PG-13
5 PG-R
6 R
7 NC-17
8 ADULT

✓

Changing a password.

To change your password, move the cursor
to “PASSWORD” and press [√].

Enter a current password.

Then enter a new password and press
[ENTER].

Confirm a new password.

Now your password is changed.

6

Others Setup

OSD
SCREEN SAVER
DEFAULTS
PARENTAL
PASSWORD

INPUT PASSWORD

- - - -

OK CANCEL

OSD
SCREEN SAVER
DEFAULTS
PARENTAL
PASSWORD

INPUT PASSWORD

- - - -

OSD
SCREEN SAVER
DEFAULTS
PARENTAL
PASSWORD

CONFIRM PASSWORD

- - - -

OSD
SCREEN SAVER
DEFAULTS
PARENTAL
PASSWORD

CHANGE OK

“Parental Lock” activates only if you set a password and the unit goes into Lock status. When the
disc has no parental function even if the disc is for adult only, Parental Lock doesn’t activate.

The initial password is 3308. In case you forget newly-input password, you can use 3308 as a
password.

Setup

56 57

About DVD

• DVD, Video CD(Version 1.1, 2.0), S-VCD and Audio CD

Disc type Playable Restriction

DVD Possible Region number 4 or Region number All

Video CD Possible Version 1.0/1.1/2.0, SVCD

CD Possible PCM or dts

CD-ROM Possible MP3 File

CD-R Possible Video-CD/CD/CD-ROM (MP3 File)

CD-RW Possible Video-CD/CD/CD-ROM (MP3 File)

DVD-R Possible DVD Video
DVD-RW Possible DVD Video
DVD+RW Possible DVD Video

DVD-ROM Impossible
DVD-RAM Impossible

Photo CD Possible except KODAC CD

REGION MANAGEMENT INFORMATION

This unit is designed and manufactured to respond to the Region Management information that is
recorded on a DVD disc. The region number of this player is “4”. If the region number described on the
DVD discs does not correspond to the Region number of this player, the player will not play this disc.
This player will play DVD discs made for “ALL” regions. Therefore, this player will play DVD discs
marked with labels containing the region number “4” or “ALL”.

(Region 4) (Region ALL)

4

ALL

Playable Disc

• You should record the file with standard format.

• Playback of some discs such as CD-R, CD-RW, DVD-R, DVD-RW, or DVD+RW may be impossible according to its record status.

Terms related with DVD

DVD A DVD (abbreviation of Digital Versatile Disc or Digital Video Disc) can include 135 minutes of video

information. And for audio, it can hold up to 8 kinds of languages and 32 kinds of subtitle languages. By
using MPEG-2 video compression and digital 3D surround sound, DVD realizes high-defined screen and
quality sound like a movie theater.

CDDA A CDDA (abbreviation of Compact disc digital audio) is a music disc that is currently used.

MP3 Audio compression format that enables audio files to be stored and transferred on a computer with a

relatively small file size. It enables you to enjoy CD quality music. (Short for MPEG-1 Layer 3)

About DVD

PBC This is recorded on a Video CD 2.0, Video CD 3.0 and SVCD. The scenes or information to be viewed (or

listened to) can be selected interactively with the TV monitor by looking at the menu shown on the TV
monitor. It stands for PlayBack Control.

CHAPTER It means the information recorded in a DVD. A title in a DVD is divided into many tracks, of which a

track is called as a chapter. A certain scene of a screen can be quickly searched with the chapter
number.

TITLE It means the information recorded in a DVD. A DVD can be divided into may titles.

TRACK It means the information recorded in a video CD and audio CD. A disc consists of many a track, for

which a user can search a certain position.

dts Digital Theatre System is a 5.1 -channel surround sound system, which is widely used in movie

theatres around the world. It enables the bit rate to be increased to provide good sound quality. “DTS”
and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.

Multi Angle Some DVD discs contain the various scenes that have been simultaneously shot from a number of

different angles.

PCM Linear PCM is a signal-recording format used in a CD, while CD is recorded in 44.1kHz/16bit, a DVD

is recorded in 48KHz/16bit up to 96KHz/24bit.

Dolby DigitalDolby Digital enables the delivery of mono through 5.1-channel audio at data rates from 32 kbps to 640

kbps, thus offering flexibility and economical performance as well as uncompromised sound quality.

Bitstream Digital audio data that is decoded into an analog signal for subsequent output to speakers.

Lt/Rt It indicates L/R of Dolby Digital 2CH Downmix output.

Downmix DOWNMIX is reproducing the proper audio when audio format recorded on a disc differs from the

output audio channel configuration. For example, with just one stereo speaker system you can hear
full 5.1 channel audio.

• To keep a disc clean condition, please do not touch a side containing play
information.

• Do not attach a bit of paper or sticky tape on it.

• Do not expose a disc to a direct sunlight or electric heating systems.

• After using it, please keep a disc in a case.

• Before using it, please rub it from center toward outside with clean clothes.

• Do not use any type of solvent such as thinner, benzol (benzene), commercial cleaning
goods or antistatic sprays.

Handling Disc

Cleaning Disc

Other Features

58 59

Basic information about VCR and Videotape

• If a VCR is moved from a cool place to a warm and damp place or a place facing a direct cool wind from air­conditioner...and others, temperature varies sharply, which makes dew on head drums of VCR.

If dew condensation occurs,

1 First, turn it on for one or two hours before using it.

2 Do not use it because it may develop troubles of a VCR or videotape.

AFT Automatic fine tuning, a circuit that automatically adjusts TV reception to optimum condition.

CABLE Cable television.

Index Search A feature of this VCR that automatically records an index each time recording begins. It helps you

locate a particular segment of the tape quickly and easily.

LP Long Play, an intermediate tape recording speed that combines most of the picture/audio quality

obtainable at the standard recording speed with some of the tape economy of Extended Play (EP).

OSD On-screen display of information pertinent to the features of the VCR.

OTR One-touch recording, a feature that allows you to record the program you’re watching by

pressing the REC key. Each press of the key increases the recording time by 30 minutes, up to 10
hours.

RF Radio frequency, the composite audio/video signal supplied to a TV receiver (or other video

component) by an antenna or cable system.

Safety tab The plastic tab at the back of a video tape cassette which, when removed, prevents accidental

erasure of a recording.

SP Standard play, the recording speed to use when the best picture quality is of prime importance

(and when total recording time is not).

Terms related with VCR

What is dew condensation symptom?

Trouble Shooting (VCR)

• “Power On” does not work.

• It does not work even in “Power On”.

• A videotape is not inputted in.

• On inputting a videotape, the tape is
re-ejected.

• A videotape is not ejected.

• A channel on video and a play screen
does not appear.

• Noise (screen noise) appears on
screen.

• Noise appears on screen after
recording.

• While in playing, noise appears.

• Sound and screen are irregular.

• Sound comes out but screen does not
appear.

• Screen is irregular and stripes appears.

• "Screen Error" message is displayed
in a screen.

• While recording and playing, the top
of screen extremely waves.

• A screen is not clear.

• A screen at pause is trembling or
slow screen is not clear.

Checks

Symptom

➤ Please check whether a power plug is inserted in an electric outlet.
➤ Please check whether a videotape is inserted in.

➤ Try to insert a plug again.
➤ Please check whether a power plug is inserted in an electric outlet.

➤ Please check whether a videotape is in.
➤ Please check whether a videotape is inserted in a right direction (a

side of transparent window should be on the upside)

➤ Have you inputted a videotape again just after the tape was ejected?

Please try it again after fully ejecting it.

➤

When a videotape forces to be ejected, the tape may not be inputted. In
the case, please pull out an outlet, and then push the tape smoothly.

➤ That’s why a safe mode to protect a videotape is operated

automatically. Please pull out the tape and input it again.

➤ In case the product is used for a long time, a videotape may not be

ejected for a film inside may be stretched. In the case, please pull out
a power plug for about 10mins and then press “EJECT” button.

➤ Please check your antenna’s connection.
➤ TV channel should be fixed on video channel.
➤

Please check your antenna’s signal whether it may be weak. In case of its
weakness, please use a frequency amplifier connected with the device.

➤

Press “TV/VCR” and then let “VCR” is displayed on the display panel.

➤ While in no use of VCR, was it turned on?
➤ While in recording a program, do you watch another channel?
➤ Select TV by pressing [TV/VCR] button on remote control.

➤ While in playing a videotape, there may happen some noise or blot

in the part of the beginning of a videotape or resuming “PAUSE”,
which are not breakdown.

➤ Please press “TRACKING” for better screen. Videotape may be

poor. Try to change it to another one.

➤ Please use a head-cleaner to clean VCR heads. VCR heads may be

contaminated.

➤ Since VCR Play signals are not stable like a TV signals, screen may

be unstable or curved while in playing. To fix the problem, please
horizontal adjustment.

➤ In case videotape is the one recorded by other products or old one,

stripe may appear on the screen.

➤ Try to adjust the screen by [TRACKING+/-] button
➤ Try to use a head-cleaner.

➤ Try to use a head-cleaner.
➤ Try to adjust the screen by [TRACKING+/-] button.

Other Features

6160

Trouble Shooting (VCR)

• Recording a TV program is
impossible.

• Once pressing “REC”, a videotape is
ejected automatically.

• Timer recording of Cable TV does
not work.

• In spite of pressing “CHANNEL”, a
channel can not be set.

• While duplicating, screen is not
clean and distorted.

• remote control does not work.

• Buttons on remote control do not
work.

• VISS index search does not work.

• Cable broadcasting can not be
selected.

Checks

Symptom

➤ For recording, you should use videotape with a tab.
➤ Please check whether a channel is fixed on video. If not, you have to

turn it into “TV” by pressing “INPUT” button.

➤ Please check whether the timer recording info is right.
➤ Are RF cables inputted antenna connection terminal correctly?
➤ Does a CH number selected in display section appear?
➤ Please check a tab on a tape whether it is broken or not. (If it was

broken, please scotch-tape it)

➤ Check whether a tape attached with a recording tap is inserted.
➤ Check whether the screen is displayed in VCR Only Channel. Press

[INPUT] button in this remote controller to adjust in "General
Broadcast" condition.

➤ Is the rounded line (RF cable) connected in "ANT.IN" terminal?
➤ Is the selected channel number shown in Display?
➤ Is a tab of cassette tape broken? (Please cover a tab hole with

cellophane adhesive tape (Scotch tape).)

➤ Please check whether the clock is right.
➤ Does the display on your video show “

”

(Ready to timer

recording)? Please make it out.

➤ Please check whether the timer recording info is right.
➤ Please check a tab on a tape whether it is broke or not. (If it was

broken, please scotch-tape it)

➤ Was a cable data output code connected correctly?
➤ Were a converter manufacturer setup and output channel right?
➤ Did you enter a password? (Please cancel it.)
➤ Did you turn off your player? (Please turn it on.)

➤ You may not memorize channels.
➤ Please check your channel setting or press a number button.

➤ Some tapes or discs distributed in the market for lending is set to

prevent copy in manufacturing. These tapes cannot be duplicated in
a good condition.

➤ Battery may be weak or exhausted.
➤ A receiver of remote control may be different with a sender.

➤ In case a videotape is positioned in the beginning, “VISS REW” and

“REW” do not work.

➤ In case a videotape is positioned in the end, “FF”, “VISS FF”, “PLAY”

and “REC” do not work.

➤ Please check whether another button is pressed.
➤ Are you playing a tape that is not recorded in this recorder? (Try to

record it with the recorder.)

➤ You may start recording it in “REC-PAUSE”. Please start recording it

from stop condition.

➤ Please select “CABLE” not “NETWORK” from the “CHANNEL

SETTING”.

Trouble Shooting (DVD)

• The recorder does not play.

• No sound comes through.

• A disc is playing but screen does not
appear or poor screen appears.

• Sound is irregular

• REMOTE does not work.

• Dolby Digital sound does not work

• “AUDIO” or “SUBTITLE” button
does not work.

• “ANGLE” button does not work
while a DVD is playing.

• “MENU” does not appear while a
DVD is playing.

• The file name of MP3 (CD-R) appears
with strange letters.

• Any MP3 (CD-R) file isn’t displayed.

Checks

Symptom

➤ If a DVD is from overseas, it may not be played. Please check a

DVD’s region code whether it has the relative region code 4 or All.

➤ Please check whether a DVD is inserted in a right direction.
➤ If it is a CD-ROM for PC or DVD-ROM, it does not work.

➤ Play mode may be “SLOW” or “PAUSE”(In abnormal speed play,

no sound comes through)

➤ Did you connect the parts in right way?
➤ Please check the operative condition of TV or amplifier.
➤ From SETUP, please check “AUDIO” items.

➤ Did you turn on your TV sets?
➤ Did you connect the parts in right way?
➤ The play may be in “PAUSE”.
➤ A disc may have some contaminants or be damaged.
➤ A disc may be bad one.

➤ Please check the connection with Dolby Digital amplifier.
➤ Please check the plugs are connected with one another tightly.
➤ Some contaminants may be remained in connection terminal.

➤

Please check the degree of remote control, distance or any interruption.

➤ Battery may be weak or exhausted.
➤ When you operate DVD, use it by pressing [DVD] button.

➤

Dolby Digital sound can be worked in the Dolby Digital amplifier only.

➤ Please check “Dolby Digital ” mark on your DVD.
➤ In case of playing it through digital output, while pressing “STOP”,

please check whether “Digital Output” is “Bitstream” by pressing
“SETUP”.

➤ Please check the connection is correct.
➤ If a DVD does not include language information, it does not support

the function.

➤

“ANGLE” is supported only in a DVD contains multi angle scenes. Also
a user can confirm the support with the “ANGLE” mark on screen.

➤

Please check the degree of remote control, distance or any interruption.

➤

Please check a battery in remote control whether it is exhausted or not.

➤ A DVD may not contain menu information.
➤ The file name of MP3 recognize only the Alphabet (A~Z, a~z),

numbers (0~9) and a special symbol on keyboard (~, !, @, #, $ ....)

and 10 letters can be displayed in maximum.

➤ The letters except above case will be displayed like “----”.
➤ If the surface of disk is injured, the file display and playback can be

impossible.

62

Specifications

Disc type

DVD VIDEO-CD CD

Analogue Audio output 48/96KHz sampling 44.1KHz sampling 44.1KHz sampling
Digital Audio output 48KHz sampling 44.1KHz sampling 44.1KHz sampling
Optical digital audio output 48KHz sampling 44.1KHz sampling 44.1KHz sampling

Output

Power 200-240V~, 50/60Hz

Consumed electricity 22W

Weight 4.6kg

Dimension (W x H x D)

435mmx93mmx255mm(Without Foot), 435mmx98mmx255mm(With Foot)

Operative temperature +5°C~40°C

Installation condition Horizontal / Relative humidity under 80%

Laser output 5mW (continuous wave max.)

Wave length 635nm (DVD), 730nm (CD)

Signal type PAL COLOR

Antenna Input/output U/V-mixed: 75Ω unbalanced

VIDEO input 1.0Vp-p (unbalanced, RCA JACK)

AUDIO input -8.8dBm, RCA JACK

VIDEO output

(common use of DVD and VCR)

VIDEO output terminal, 1.0 Vp-p unbalanced, RCA JACK

VIDEO output (DVD only)

Component output (75Ω In load Y: 1.0Vp-p, Pb:0.7Vp-p, Pr:0.7Vp-p)

AUDIO output

(common use of DVD and VCR) Audio output terminal (2 kinds): -5.8dBm(VCR), 2Vrms(DVD), RCA JACK

AUDIO output (DVD only) Analogue AUDIO output : 2.0Vrms

Digital audio output (OPTICAL, COAXIAL)

Playable tape Very high dense tapes with VHS marks

Playable disc DVD, VIDEO-CD, CD (12cm), CD (8cm), MP3, CD-R, CD-RW

Tape speed SP: 23.39mm/s, LP: 11.70mm/s

Playtime SP: 3hrs, LP: 6hrs (use of E180tape)

Clock display 24 hrs

Time Recording 8 programs a month

Persistence in power failure 1min

VIDEO S/N (VCR) Over 43dB(Standard recording)

Resolution VCR Over 240 lines (Standard recording)

DVD Over 400 lines (Playback DVD)

AUDIO (VCR) Over 65dB

AUDIO (DVD) 90dB

AUDIO dynamic range 90dB

DVD Audio output standards

◆Region code of DVD/Video player for home is 4 or ALL. In inserting a disc with other region code, it does not operate. Please only

use a disc with region code 4 or ALL.

◆ is a ‘Prohibition’ mark. If this mark is displayed in operating the product, please wait for a while, then use it.

If " Prohibition" mark continues to be displayed in pressing a button after that, it means the button does not function in
the currently played disc.

◆Press a product button on the remote control then use the product.

• DVD operation : [DVD] button

• Video operation : [VCR] button

G1629

Owner’s Manual
