Progressive Scan
HDMI DVD PLAYER
Instruction manual
DSW-800H
DSW-800H(English) 2008.9.11 9:59 AM ˘`a
Table of Contents
Table of Contents
1
IMPORTANT SAFETY PRECAUTIONS .... 2
FEATURES ............................................. 5
ABOUT DISC ......................................... 6
BEFORE OPERATION............................. 8
PREPARATIONS BEFORE OPERATION. 10
Front Panel ..................................................... 10
Rear Panel ...................................................... 11
LED Display..................................................... 12
Names and Layout of Remote Controls ......... 13
CONNECTIONS ................................... 14
BASIC OPERATIONS............................ 16
Play Discs ....................................................... 16
System Setting................................................ 17
V-Mode .......................................................... 17
Display............................................................ 18
Fast Play ......................................................... 19
Slow Play........................................................ 19
Pause/ Step..................................................... 19
Select Audio Language................................... 20
Select Channels .............................................. 20
PLAYING A DESIRED SCENE............... 21
To skip scenes in a disc................................... 21
Directly moving to a desired title (DVD/VCD) . 21
Playing a disc containing MP3 (or CD) files .... 22
Playing DivX disc on CD-R (W) ....................... 23
Repeat Play .................................................... 24
Repeating a defined period from A to B ........ 24
Select a Subtitle Language ............................. 25
Searching.........................................................25
PLAY DISCS IN VARIOUS WAYS .......... 27
Select Angle.................................................... 27
Zoom Play....................................................... 27
Book Mark...................................................... 28
Program Play (DVD)........................................ 29
Program Play (VCD)........................................ 30
Program Play (CD, MP3, JPEG, MPEG4) ......... 31
FUNCTION SETTING ........................... 32
Menu Setting.................................................. 32
Language........................................................ 34
Video .............................................................. 36
Audio.............................................................. 37
Preference ...................................................... 39
OTHERS............................................... 40
Troubleshooting ............................................. 40
Technical Specifications.................................. 41
DSW-800H(English) 2008.9.11 9:59 AM ˘`1
Important Safety Precautions
Important Safety Precautions
2
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude to
constitute a risk of electric shock.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and servicing
instructions in the literature accompanying the
appliance.
WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE.
CAUTION : TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
IMPORTANT FOR LASER PRODUCTS
• LASER : This Digital Video Disc Player employs a Laser System. To ensure proper use of this
product please read this owner’s manual carefully and retain for future reference. Should
the unit require maintenance, contact an authorized service location - see service
procedure.
Use of control adjustments or the performance of procedures other than those specified
may result in hazardous radiation exposure.
To prevent direct exposure to the laser beam, do not try to open
the enclosure. Visible laser radiation when open and interlocks
defeated.
DO NOT STARE INTO THE BEAM.
• DANGER : Visible laser radiation when open and interlock failed or
defeated. Avoid direct exposure to beam.
• CAUTION : Do not open the top cover. There are no user serviceable parts inside the Unit; leave all
servicing to qualified service personnel.
CLASS 1
LASER PRODUCT
CAUTION: Any changes or modification in construction of this device which are not
expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
ATTENTION: KEEPING THE STATUS OF STOP MORE THAN 5 MINUTES ENTERS SCREEN SAVE MODE. WHEN
THE SCREEN SAVE MODE IS KEPT MORE THAN AN HOUR, THE SET ENTERS STAND-BY MODE.
CAUTION: Apparatus shall not be exposed to dripping or splashing and no objects filled
with liquids, such as vases, shall be placed on the apparatus.
DSW-800H(English) 2008.9.11 9:59 AM ˘`2
Important Safety Precautions
3
This set has been designed and manufactured to assure
personal safety. Improper use can result in electric shock or
fire hazard. The safeguards incorporated in this unit will
protect you if you observe the following procedures for
installation, use and servicing. This unit is fully transistorized
and does not contain any parts that can be repaired by the
user.
1 READ INSTRUCTIONS
All the safety and operating instructions should be read
before the unit is operated.
2 RETAIN INSTRUCTIONS
The safety and operating instructions should be retained
for future reference.
3 HEED WARNINGS
All warnings on the unit and in the operating
instructions should be adhered to.
4 FOLLOW INSTRUCTIONS
All operating and use instructions should be followed.
5 CLEANING
Unplug this unit from the wall outlet before cleaning. Do
not use liquid cleaners or aerosol cleaners. Use a damp
cloth for cleaning.
6 ATTACHMENTS/ACCESSORIES
Do not use attachments unless recommended by the
unit’s manufacturer as they may cause hazards.
Caution :
Apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids,
such as vases, shall be placed on the appratus.
7 WATER AND MOISTURE
Do not use this unit near water- for example, near a bath
tub, wash bowl, kitchen sink or laundry tub, in a wet
basement, or near a swimming pool.
8 PLACEMENT
Do not place this unit on an unstable cart, stand,
tripod, bracket, or table. The unit may fall, causing
serious injury to a child or adult as well as serious
damage to the unit. Use this
unit only with a cart, stand,
tripod, bracket, or table
recommended by the
manufacturer.
8A
A unit and cart combination
should be moved with care. Quick stops, excessive
force, and uneven surfaces may cause the video product
and cart combination to overturn.
9 VENTILATION
Slots and openings in the case are provided for
ventilation to ensure reliable operation of the unit and to
protect it from overheating. These openings must not be
blocked or covered. These openings must not be blocked
by placing the unit on a bed, sofa, rug, or other similar
surface. This unit should never be placed near or over a
radiator or heat radiator. This unit should not be placed
in a built-in installation such as a bookcase or rack
unless proper ventilation is provided or the
manufacturer’s instructions have been adhered to.
10 POWER SOURCES
This unit should be operated only from the type of power
source indicated on the marking label. If you are not sure
of the type of power supply to your home, consult your
video dealer or local power company. For units intended
to operate from battery power, or other sources, refer to
the operating instructions.
11 GROUNDING OR POLARIZATION
This unit is equipped with a polarized alternating current line plug (a plug having one blade wider than
the other). This plug will fit into the power outlet only
one way.
This is a safety feature. If you are unable to insert the
plug fully into the outlet, try reversing the plug. If the
plug still fails to fit, contact your electrician to replace
your obsolete outlet.To prevent electric shock, do not
use this polarized plug with an extension cord,
receptacle, or other outlet unless the blades can be fully
inserted without blade exposure. If you need an
extension cord, use a polarized cord.
12 POWER-CORD PROTECTION
Power-supply cords should be routed so that they are
not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to
cords at plugs and the point where they exit from the
unit. Mains plug is used as the disconnect device, the
disconnect device shall remain readily operable.
13 LIGHTNING
For added protection for this unit during a lightning
storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and
disconnect the antenna or cable system.
PORTABLE CART WARNING
(symbol provided by
RETAC)
DSW-800H(English) 2008.9.11 9:59 AM ˘`3
Important Safety Precautions
4
This will prevent damage to the unit due to lightning and
power line surges.
14 DISC TRAY
Keep your fingers well clear of the disc as it is closing. It
may cause serious personal injury.
15 OVERLOADING
Do not overload wall outlets or extension cords as this
can result in a risk of fire or electric shock.
16 OBJECT AND LIQUID ENTRY
Never press objects of any kind into this unit through
openings as they may touch dangerous voltage points or
“short-out” parts that could result in a fire or electric
shock. Never spill liquid of any kind on the unit.
17 BURDEN
Do not place a heavy object on or step on the product.
The object may fall, causing serious personal injury and
serious damage to the product.
18 DISC
Do not use a cracked, deformed or repaired disc. These
discs are easily broken and may cause serious personal
injury and product malfunction.
19 SERVICING
Do not attempt to service this unit yourself as opening
or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified
service personnel.
20 DAMAGE REQUIRING SERVICE
Unplug this unit from the wall outlet and refer
servicing to qualified service personnel under the
following conditions.
A. When the power-supply cord or plug is damaged.
B. If liquid has been spilled, or objects have fallen into
the unit.
C. If the unit has been exposed to rain or water.
D. If the unit does not operate normally by following the
operating instructions. Adjust only those controls that
are covered by the operating instructions. Improper
adjustment of other controls may result in damage
and will often require extensive work by a qualified
technician to restore the unit to its normal operation.
E. If the product has been dropped or the cabinet has
been damaged.
F. When the unit exhibits a distinct change in
performance-this indicates a need for service.
21 REPLACEMENT PARTS
When replacement parts are required, have the service
technician verify that the replacements he uses have the
same safety characteristics as the original parts. Use of
replacements specified by the unit manufacturer can
prevent fire, electric shock, or other hazards.
22 SAFETY CHECK
Upon completion of any service or repairs to this unit,
ask the service technician to perform safety checks
recommended by the manufacturer to determine that
the unit is in safe operating condition.
23 WALL OR CEILING MOUNTING
The product should be mounted to a wall or ceiling only
as recommended by the manufacturer.
24 HEAT
The product should be situated away from heat sources
such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
FCC NOTICE :
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rule. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio
or television reception; which can be determined by
turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the
following measures:
• Reorientate or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment to an outlet on a circuit
different from that to which the receiver is
connected.
• Consult the dealer or an experience radio/TV
technical for help.
DSW-800H(English) 2008.9.11 9:59 AM ˘`4
5
HDMI
Audio/Video Digital output
support 1080I ( Interlace), 720P (Progressive) and 480P/576P Video out.
OUTSTANDING SOUND QUALITY
Dolby Digital system developed by Dolby Laboratories and DTS
developed by DTS Inc., features high quality surround sound which can be played
in DVD or CD disc at home, to reproduce high quality sound effects.
HIGH DEFINITION
The unit adopts MPEG2 coding format and brings the high horizontal resolution.
UNIQUE FUNCTIONS
Multi-angle and multi-language bring unique trick functions.
Parent lock makes it easy to control the content of discs.
SCREEN
Ordinary screen and wide screen (16:9) are available.
COMPATIBILITY
The unit can play DVD-video discs, and is compatible with CD, CD-G, CD-R, CD-RW,
PIC-CD, MP3, DVD-R, DVD+R, DVD-RW and DVD+RW.
ZOOM
It can enlarge pictures.
MULTI-FUNCTIONS
Fast forward, fast reverse, forward and reverse slow, frame play, repeat play and
program play.
TIME SEARCH
It can search a specific part on a disc, especially good for watching movies.
RESUME PLAY
It can memorize the position where the disc is stopped and resume playback.
VIDEO OUTPUT
Standard video, S-video, HDMI, component (progressive, interlace) video output
mode.
AUDIO OUTPUT
HDMI/ Analog audio output, coaxial digital audio output, can be connected with
the appropriate amplifier to enjoy high-quality sound effects.
Features
Features
DSW-800H(English) 2008.9.11 9:59 AM ˘`5
About Discs
About Discs
6
PRINCIPLES FOR WRITING
This manual mainly introduces how to use buttons on the remote control.
You may operate the unit if the buttons on the unit have the same or similar names
as or to those on the remote control.
TITLE
The images or music of a DVD are divided into some units, among which title is the
biggest one.
When playing a DVD, the movie is the title.
When playing a CD, the combined tracks make up the title.
STRUCTURE OF DVD STRUCTURE OF CD
DISC
TITLE
CHAPTER
DISC
TRACK
PLAYABLE DISCS
DVD-video Region number 4 or Region number ALL
DVD-R/+R DVD video
DVD-RW/+RW DVD video
DVD-ROM DVD video
CD-G Playback audio/ graphic files
CD-DA Digital audio files
CD-R/ CD-RW Digital audio/ MP3/ JPEG format files
CD-DA/JPEG/MP3 Total disc capacity : over 4M, Each file : under 1M
CD-ROM Digital audio/ MP3/ JPEG format files
NONE PLAYABLE DISCS
DVD-video Different region number
DVD-ROM Files for PC application / Data files
CD-ROM Files for PC application / Data files
CD-MP3 Files under windows format
DVD-RAM All format
DSW-800H(English) 2008.9.11 9:59 AM ˘`6
About Discs
7
CHAPTER
It is smaller than title among the units of a DVD. A title is made up of several
chapters , and each chapter has a number for search. But some discs may not
have numbered chapters.
TRACK
In a CD, each track has a number to enable search functions.
REGION MANAGEMENT INFORMATION
This unit is designed and manufactured to respond to the Region Management
information that is recorded on a DVD disc. The region number of this player is
“4”. If the region number described on the DVD discs does not correspond to the
Region number of this player, the player will not play this disc. This player will
play DVD discs made for “ALL” regions. Therefore, this player will play DVD discs
marked with labels containing the region number “4” or “ALL”.
(Region 4) (Region ALL)
4
SCENE
The menu pictures, motion and motionless pictures of a CD can be divided into some
parts, these parts are scenes. Each scene has a number for search.
MACROVISION
This product incorporates copyright protection technology that is protected by
U.S patents and other intellectual property rights. Use of this copyright
protection technology must be authorized by Macrovision, and is intended for
home and other limited viewing uses only unless otherwise authorized by
Macrovision. Reverse engineering or disassembly is prohibited.
DSW-800H(English) 2008.9.11 9:59 AM ˘`7
Before Operation
Before Operation
8
SECURITY
• Before operation, check if the voltage of the unit is in line with the local voltage.
• Hold the plug to disconnect it from the mains outlet. Do not pull the power cord.
• When the plug of the unit is connected to the mains outlet , the unit will be still
connected to AC even if the power is turned off.
• Disconnect the plug as soon as liquid or objects enter the unit. The unit can not be
used until being checked by experts.
• Do not open the cabinet as laser rays employed by the unit may damage eyes. Any
servicing should be done by qualified service personnel.
PLACEMENT
• Put the unit where ventilation is good enough to prevent overheating.
• Never put the unit in direct sunlight or near heat sources.
• Put the unit horizontally, never put any heavy object on the unit.
• To protect the pickup, do not put the unit where there is dust. If there is dust on
the pickup, use a cleaning disc to clean it. Paying particular attention to the
operating instructions of the cleaning disc.
CONDENSATION
Moisture will appear on the pickup lens in the following cases:
• The unit is suddenly moved from a cold place to a warm place.
• The unit is put in a room with a heater, or in cold air from an air-conditioner.
• Using the unit in a humid place. In these cases, the unit can not work. Unload the
disc and leave the unit on for about one hour to evaporate the moisture.
CLEANING
• Use a soft cloth with a little neutral detergent to wipe the cabinet, panel and
controls.
Never use abrasive paper, polishing powder, solvent like alcohol or gasoline.
HANDLING DISC
CLEANING DISC
• To keep the disc clean, do not touch the playsides of the disc.
• Do not attach paper or tape to the disc.
• Keep the disc away from direct sunlight or heat sources.
• Store the disc in a disc case after playback.
• Before playback, wipe the disc outward from the centre with clean cloth.
• Do not use any type of solvent such as thinner, benzine, commercially available
cleaners or antistatic spray.
DSW-800H(English) 2008.9.11 9:59 AM ˘`8
Before Operation
9
CHECK ACCESSORIES
USE REMOTE CONTROL
Check if you have all the accessories after the carton is opened.
1 Open the battery compartment.
2 Insert two AAA batteries, make sure to match "+" and "-" of the batteries to
the marks in the battery compartment.
3 Close the battery compartment.
4 Point the remote control at the remote sensor.
Remote control
AAA batteries
Video/Audio cord
Instruction manual
1. Batteries can last for about 6 months generally. Change the batteries if that does not
work.
2. If the remote control is not used for a long time, remove the batteries to prevent
battery leakage.
-
U
M
-4
+
N
Note:
HDMI-cable
DSW-800H(English) 2008.9.11 9:59 AM ˘`9
Preparations before Operation
Preparations before Operation
10
FRONT PANEL
! STANDBY/ON button
To switch the unit On or Off when connected to AC power outlet.
@ OPEN/CLOSE button
To open or close the disc tray.
# PLAY/ PAUSE button
To play the loaded disc. Press this button to go to the preferred item when the menu
is displayed on the TV screen. Press this button in playback mode, the picture stops.
This machine enters the playback pause mode.
$ STOP
% PREV button
To skip back from the current chapter or track.
^ NEXT button
To skip forward to the next chapter or track.
& DISPLAY
Displays operation status.
* REMOTE SENSOR
Receives a light signal from the remote control.
!
@ # $%^
*
&
DSW-800H(English) 2008.9.11 9:59 AM ˘`10
Preparations before Operation
11
REAR PANEL
! COMPONENT (Y.Pb.Pr)
Connects to TV or monitor equipped with Component input . In order to achieve a
sharper and cleaner picture than when connected via VIDEO OUT (composite video).
@ VIDEO OUT
Connects composite video signal to input AV or PHONO sockets of TV or monitor to
achieve high fidelity colour reproduction.
# POWER SUPPLY SOCKET WIRE
Creates POWER between wall outlet and the unit.
$ AUDIO OUT (L/R TRACK)
Two phono sockets for analogue 2 Channel audio in order to a TV or stereo amplifier.
% DIGITAL AUDIO COAXIAL OUT
Connects digital audio under play mode into an AV amplifier or a receiver equipped with
digital audio decoder for you to enjoy the theatre-quality sound in your home.
^ HDMI OUT
Audio/Video High definition multimedia digital output terminal. Use the HDMI cable,
connect this HDMI output terminal to the HDMI input terminal on your TV for the best
quality picture.
& S-VIDEO OUTPUT
Connects to TV or monitor equipped with S-VIDEO input. In order to achieve a sharper
and cleaner picture than when connected via VIDEO OUT (composite video).
! @
#
$ % ^ &
DSW-800H(English) 2008.9.11 9:59 AM ˘`11
Preparations before Operation
12
LED DISPLAY
! Recognized DISC TYPE indicator
: DVD
@ Recognized DISC TYPE indicator
: VCD
# PLAY indicator
$ PAUSE indicator
% DISC LOAD/PLAY indicator
This indicator is lit up after
recognizing the disc.
^ DVD/CD/MP3 indicator
Indicates the hour.
& DVD/CD/MP3 indicator
Indicates the minutes.
* DVD/CD/MP3 indicator
Indicates the seconds.
( DVD/CD/MP3 indicator
Indicates the title, chapter or track
number.
) REPEAT MODE indicator
: In case you want to play a
chapter, track, title or disc
repeatedly.
1 DVD AUDIO STREAM indicator
: dts digital out
2 Recognized DISC TYPE indicator
: MP3
3 PBC indicator
This indicator is lit up in selecting PBC
ON while this indicator disappears in
selecting PBC OFF.
4 NUMBER/ CHARACTER indicator
Chapter, track number, and time are
displayed in loading DVD/CD disc,
while track number and time are
displayed in loading MP3.
: Tray is opened
: Tray is closed
: Disc is loaded
: There is no disc in tray
5 DVD AUDIO STREAM indicator
Indicates the audio type of the
disc under playing is DOLBY
DIGITAL.
2
4
5
(
3
! #@ %
) 1& *^
$
DSW-800H(English) 2008.9.11 9:59 AM ˘`12
Preparations before Operation
13
NAMES AND LAYOUT OF REMOTE CONTROLS
* After setting the mode by using SETUP menu (for example, NTSC select in NTSC/PAL/AUTO
setup), the setting is kept though you switch the unit off and turn it on.
POWER BUTTON
DISPLAY BUTTON
ANGLE
BUTTON
SETUP
BUTTON
TITLE/PBC BUTTON
UP/DOWN/LEFT/
RIGHT DIRECTION
BUTTON
SEARCH BUTTON
MARK BUTTON
PAUSE BUTTON
STEP BUTTON
AUDIO BUTTON
REPEAT BUTTON
CHANNEL BUTTON
VOLUME “+/-” BUTTON
ONE CHAPTER/TRACK
BACKWARD BUTTON
FAST BACKWARD
SEARCH BUTTON
SUBTITLE BUTTON
A-B REPEAT BUTTON
V-MODE BUTTON
OPEN/CLOSE BUTTON
NUMBER BUTTONS
MENU BUTTON
RETURN BUTTON
STOP BUTTON
SYSTEM BUTTON
INTRO BUTTON
(This button has no function for
this DVD player)
ZOOM BUTTON
PROGRAM BUTTON
ONE CHAPTER/TRACK
FORWARD BUTTON
PLAY/ENTER BUTTON
MUTE BUTTON
3D SURROUND BUTTON
(This button has no function for
this DVD player)
FAST FORWARD
SEARCH BUTTON
SLOW BUTTON
(This button has no
function for this DVD
player)
DSW-800H(English) 2008.9.11 9:59 AM ˘`13
Connections
Connections
14
CONNECTED TO A TV AND AN AUDIO AMPLIFIER
Turn off all equipment before operation.
The unit has many kinds of output modes like A/V output, S-VIDEO output and digital
signal output (COAXIAL). You may select as you need.
Connects either!, @,#+, $+, #+, $+, #+ or $+.
2 Speakers
Amplifier
TV set
@
#$
!
Manufactured under license from Dolby Laboratories."Dolby" and the double-D
symbol are trademarks of Dolby Laboratories. Confidential Unpublished works.
©1992-1997 Dolby Laboratories, Inc. All rights reserved.
Manufactured under license under U.S. Patent #: 5,451,942 and other U.S. and
worldwide patents issued and pending. DTS and DTS Digital Out are registered
trademarks and the DTS logos and Symbol are trademarks of DTS, Inc. © 19962007 DTS, Inc. All Rights Reserved.
DSW-800H(English) 2008.9.11 9:59 AM ˘`14
Connections
15
• When you connect your player to the TV through the HDMI cable, you have to change
the video output mode to HD mode by pressing [V-MODE] button on the remote
control.
• Except HD Mode, the other modes (for example, Interlace, Progressive, S-video mode)
may happen abnormal picture and sound.
• Read Time of HDMI signal may take 10 seconds. (It depends on TV)
Wait a little while, please!
HDMI (High Definition Multimedia Interface) supports both video and audio on a
single digital connection for use with DVD Players, Set-Top Boxes, and other AV
devices. HDMI was developed to provide the technologies of HDCP (High
Definition Contents Protection). HDCP is used to protect digital content
transmitted and received.
HDMI has the capability to support standard, enhanced, or high-definition video
plus standard to multi-channel surround-sound audio, HDMI features include
uncompressed digital video, a bandwidth of up to 5 gigabytes per second, one
connector (instead of several cables and connectors), and communication
between the AV source and AV devices such as DTVs.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks
or registered trademarks of HDMI licensing LLC.
ABOUT HDMI
TV
HDMI cable
(supplied)
DSW-800H(English) 2008.9.11 9:59 AM ˘`15
Basic Operations
Basic Operations
16
PLAY DISCS
Press "POWER" button on the TV and audio
system, Press "TV/VIDEO" button on the TV, select
VIDEO mode (TV).
Select S-Video mode if using an S-VIDEO
connection.
1
Select the correct audio input on the amplifier.
• Each amplifier is different from another, please
refer to the manual for the amplifier. (e.g.,
connect the audio output of the DVD player to
the DVD audio input of an amplifier.)
2
Press "STAND BY/ON" button on the front panel or " " button on the
remote control to turn the unit on.
3
Press "OPEN/CLOSE " button to open the disc tray and insert the disc
with its label upward. Press "OPEN/CLOSE " button again to close
the disc tray. The unit begins to read the disc. The TV screen shows the
DVD menu and title menu.
• When playing a DVD, DVD menus and titles are displayed on TV
screen.
• In the case of CD, the disc plays in order of its track number.
4
Stop playback.
Press .
5
Press to remove the disc.
6
TV/VIDEO
DVD/LD
The Step2 can be
cancelled if you
do not
connect it to the
amplifier.
N
Note:
DSW-800H(English) 2008.9.11 9:59 AM ˘`16
Basic Operations
17
SYSTEM SETTING
V-MODE (WHEN SELECTING INTERLACE, PROGRESSIVE, S-VIDEO or HD mode)
According to the system of the TV to be connected, set the system of the unit to
make it match the TV.
In STOP mode, press SYSTEM button on the remote control, then choose TV TYPE.
SYSTEM
NTSC
PAL
AUTO
• When you press the [SYSTEM] button, the TV screen shows
the information as : “If you want to change, press
[SYSTEM] again.” Press the [SYSTEM] button again, the
video out system changes as follows.
There are variety of ways to connect the DVD player to your TV.
(refer to 14page)
Choose one of the following video output modes by pressing
[V-MODE] button, depending on the connection from DVD
player to your TV.
• Component connection - Progressive mode or Interlace mode
Check whether your TV has the function of progressive before selecting
progressive mode. If your TV does not accept the progressive, you can select
the Interlace mode.
• S-Video connection - S-video mode
• Composite connection - Interlace mode
• HDMI connection - HD mode (For more details, refer to 15page)
When video output mode is not proper for the connection, no picture or no
sound may occur.
V-MODE
DSW-800H(English) 2008.9.11 9:59 AM ˘`17
Basic Operations
18
DISPLAY
Press the “DISPLAY” button when playing a disc, the TV screen shows the
information as :
DISPLAY
DVD
VCD 2.0 00:00:41 00:50:28
Track 1/1
VCD
DVD Video 00:00:35 01:55:28
Title 1/5 Chapter 1/16
Audio 1/2 6Ch Eng
Subtitle Off
Angle 1/1
Remain TimeRunning Time
Remain TimeRunning Time
DSW-800H(English) 2008.9.11 9:59 AM ˘`18
Basic Operations
19
FAST PLAY
When playing disc, you may play it forward fast or reverse it fast to find what you need.
Press to play forward fast. Each
time you press the button, the speed of
picture changes like the right sides.
1
Press to reverse the disc fast.
Each time you press the button, the
speed of picture changes like the
right sides.
2
Press PLAY to play
normally when
playing fast.
The marked FAST
PLAY speed on
owner’s manual
and real fast play
speed can be
different
depending on
which disc you
play.
N
Note:
N
Note:
Press PLAY to
play normally .
Press PLAY to
play normally .
SLOW PLAY
Press "SLOW" button to play slowly.
SLOW
PAUSE/ STEP
Press PAUSE on the remote control to make the playback pause.
Pressing STEP again moves the picture forward frame by frame.
N
Note:
N
Note:
X2
X4
X8
X16
Play
1
2
3
4
5
X2
X4
X8
X16
Play
1
2
3
4
5
DSW-800H(English) 2008.9.11 9:59 AM ˘`19
Basic Operations
20
SELECT AUDIO LANGUAGE
You can choose the language according to your choice when playing mulitlanguage DVD.
Press “AUDIO” button, select different languages.
SELECT CHANNELS (VCD, CD)
You may select the right channel or left channel or stereo from a multi-channel.
Press "CHANNEL" button, the screen show alternately and select the desired
audio channel:
CHANNEL
Mono Left
Mono Right
Stereo
Mix-Mono
You can use channel function when you play the disc, you can choose mono audio output ( left
or right channel ), stereo or mix-mono
N
Note:
1. Different disc has different languages
2. You can press "AUDIO" button to choose the language you want when you play
multi-language DVD discs.
AUDIO
*Attention:
Please select the AUDIO language in SETUP menu to keep the setting!
N
Note:
1/2 6Ch Eng
DSW-800H(English) 2008.9.11 9:59 AM ˘`20
Playing a desired Scene
Playing a desired Scene
21
TO SKIP SCENES IN A DISC
Press √√■to move to the next chapter (or track).
The current chapter (or track) moves to the next chapter (or track).
1
Press ■œœ to move to previous chapter (or track).
The current chapter (or track) moves to the previous chapter (or track) or
first scene of current chapter (or track).
2
DIRECTLY MOVING TO A DESIRED TITLE (DVD, VCD)
Press the [TITLE/PBC] or [MENU] button .
A list of the titles on the disc is displayed.
If using some disc, the menu screen will appear only when the disc has
PBC function and PBC ON is activated.
1
Press the [PLAY] button after pressing the [œ √…†] or number
button to select the desired title.
The selected title now starts playing.
2
Some movie discs may contain multiple titles. If the disc has a movie title menu
recorded on it, the [TITLE/PBC] button can be used to select the movie title. Details of
operation may differ depending on the disc used.
You can select
the desired title
directly by using
number button.
* In the case of PBC play, press RETURN to return to the sub-menu, press
it again to return to the home menu.
N
Note:
DSW-800H(English) 2008.9.11 9:59 AM ˘`21
Playing a desired Scene
22
PLAYING A DISC CONTAINING MP3 (or CD) FILES
When a MP3 disc is loaded,
MP3 menu screen is
displayed automatically
depending on MP3 disc’s
folder structure.
1
Use [œ √…†] button to
select the folder you want
to play, and press the
[PLAY] button.
2
Use [œ √…†] button to select a MP3 file and press the PLAY
button then play will start automatically. When you know the file
number, enter the MP3 file number using the numeric buttons on
the remote control.
3
Press √√■on the remote control to choose next page. Press■œœ
for previous page.
When you know the file number, enter MP3 file number using the
numeric buttons on the remote control.
4
9268-2
AAFALLROAD12
ALL_NITE
AMEILEENDONA
AMFUNKYFLOW
AMPOPPIESDAI
AMPOPPI2
AMPOP
√√
00 : 00 : 26
17/76 /mp3/04 -- -- - - --.MP3
Edit Mode
Program View
Add To Program
Music Playing
This button allows you to see the file lists under the folder.
DSW-800H(English) 2008.9.11 9:59 AM ˘`22
Playing a desired Scene
23
PLAYING DivX DISC ON CD-R (W)
■ DivX refers to a new format of Audio/Video files available for playback
over the internet because of the popularity to download music from DivX
websites on to ones computer.
When a DivX disc is loaded, the DivX menu screen is displayed
automatically depending on DivX disc’s folder structure.
1
Move the cursor to DivX file you want to play and press play
button.
2
On your disc, if there are many subtitles, press the [SUBTITLE]
button for selecting subtitle you want to display.
3
YOUR DVD PLAYER CAN PLAY;
- Picture DivX version: DivX 3.11, 4.x, 5.x, XviD, DivX PRO (Excluding
QPEL and GMC)
- Subtitle file extension : It can support Smi, Srt, Sub, TXT.
- Subtitle Support language: It can display ENGLISH and some languages.
• The player cannot recognize the difference of the filenames which are
made more than 15 characters. It may cause unsuitable or no subtitle.
We recommend to change the file name within 15 characters.
• In order to recognize a DivX subtitle normally, the DivX subtitle language
in Language menu should be set to the corresponding national
language. (refer to “DivX subtitle” in page 34)
N
Note:
DSW-800H(English) 2008.9.11 9:59 AM ˘`23
Playing a desired Scene
24
A-B
Rep A-
Rep A-B
Rep Off
REPEAT PLAY
When play a disc, this function can be used to repeatedly play a title, chapter,
track or disc.
Press "REPEAT" button, the screen shows orderly.
REPEAT
Repeat Chapter
Repeat Title
Repeat Off
➝➝
➝
Repeat Track
Repeat Folder
➝➝
➝
- DVD - - VCD/CD/MP3 -
Repeat Off
• Repeat Chapter : Current chapter will play repeatedly.
• Repeat Title : Current title will play repeatedly.
• Repeat Track : Current track will play repeatedly.
• Repeat Folder : The items in the current directory will play repeatedly.
• Repeat Off : Repeat playback will be cancelled.
For the case of
VCD disc, repeat
playback starts
only in PBC OFF
mode.
N
Note:
You may press A-B to enjoy some parts repeatedly when playing a disc.
REPEATING A DEFINED PERIOD FROM A TO B
Press “A-B” to set a starting point A.
1
Press “A-B” twice to an end point B.
Afterwards, the unit plays from A to B.
2
Press “A-B” three times to remove A-B
repeat.
3
DSW-800H(English) 2008.9.11 9:59 AM ˘`24
Playing a desired Scene
25
SELECT A SUBTITLE LANGUAGE
When play a multi-subtitle DVD, you may select one subtitle to show it on the
screen.
Keep pressing [SUBTITLE] button till the
user’s preferred language appears.
If a DVD disc includes subtitle information, every time
the user presses [SUBTITLE] button, ENGLISH, FRENCH, SPANISH
and others appear one by one.
1
Remove the subtitle.
Press SUBTITLE until the screen shows "Off".
2
SUBTITLE
1. For some discs,
subtitles cannot
be removed.
2. Subtitle
function is only
available for
some discs with
subtitle
recorders.
N
Note:
1/8 Eng
Total Subtitle
Current Subtitle
■ Using the SEARCH button you may play a disc at a desired Title, Chapter
or Time.
Press the [SEARCH] button to select SEARCH mode.
Press … or † button to select title, chapter or time item.
Enter title number, chapter number or time by using numeric buttons directly and
then press PLAY to confirm.
SEARCHING
SEARCHING D
SEARCHING D
VD WITH A TITLE/CHAPTER NUMBER OR A TIME
VD WITH A TITLE/CHAPTER NUMBER OR A TIME
• SEARCH
functionality
depends on
different DVD
disc's format.
Some DVD discs
do not allow
SEARCH
function.
• SEARCH does
NOT function
during Program
playback.
N
Note:
Title - - -
Chapter - - -
Time - - : - - : - -
Search
DSW-800H(English) 2008.9.11 9:59 AM ˘`25
Playing a desired Scene
26
■ Using the SEARCH button you may play a disc at a desired Track or Time.
Press the [SEARCH] button to select SEARCH mode.
Press … or † button to select track or time item.
Enter track number or time by using numeric buttons directly and then press PLAY
to confirm.
SEARCHING VCD& CD WITH A DISC /TRA
SEARCHING VCD& CD WITH A DISC /TRA
CK TIME OR TRA
CK TIME OR TRA
CK NUMBER
CK NUMBER
Track - - -
Time - - : - - : - -
Disc Time - - : - - : - -
Search
■ Using the SEARCH button you may play a MP3 file at a desired Time.
Press the [SEARCH] button to select SEARCH mode.
Enter file time by using numeric buttons directly and then press PLAY to confirm.
SEARCHING MP3 WITH A FILE TIME
SEARCHING MP3 WITH A FILE TIME
Time - - : - - : - -
Search
DSW-800H(English) 2008.9.11 9:59 AM ˘`26
Play discs in various ways
Play discs in various ways
27
SELECT ANGLE
Some discs have images with different screen angles, you may select among
them. For example, when you watch a running train, you may select to watch it
from the front, the left window or the right window without stopping it.
Keep pressing [ANGLE] button till the
preferred angle appears.
ANGLE
Angle 2/4 (select ANGLE2)
Angle 3/4 (select ANGLE3)
Angle 4/4 (select ANGLE4)
Multi Angle
function is
limited to a DVD
disc supporting
multi angle
information.
ZOOM PLAY
This function can be used to enjoy a motion or motionless picture.
Press "ZOOM" button when playing, the
screen shows orderly:
1
Press "UP/DOWN/LEFT/RIGHT“[
œ √…†
]
button to move the enlarged picture.
2
ZOOM
N
Note:
1 2 3 Off
1/4
DSW-800H(English) 2008.9.11 9:59 AM ˘`27
Play discs in various ways
28
If you erase a
book mark
function, press
“RETURN”
button.
BOOK MARK
Storing a marker in the memory
Press MARK during playback mode and press PLAY at the starting
point to be viewed (listened to) again.
Press … or † button to select another book mark item.
1
N
Note:
■ Storing a MARKER in the DVD memory is similar to marking your page in a
book. It allows you to quickly return to any point on the disc.
Recalling/ Clearing a marker
Press MARK during playback. Press …
or
† to select the marker to
be recalled/ cleared.
Press PLAY to recall a marker. Or press RETURN to clear a marker.
Play resumes from the point corresponding to the selected marker,
or the selected marker is cleared.
2
Bookmark 1 - - : - - : - -
Bookmark 2 - - : - - : - -
Bookmark 3 - - : - - : - -
DSW-800H(English) 2008.9.11 9:59 AM ˘`28
Play discs in various ways
29
• Some DVD discs
do not allow
programming.
N
Note:
You may program the title and chapter on a disc and play them in the
programmed order.
• You can clear
all programmed
item by press
PLAY button on
the position of
“Clear All”.
• You can clear
from the latest
programmed
item by press
PLAY button on
the position of
“Clear”.
N
Note:
PROGRAM PLAY (DVD)
Press "PROGRAM" button, the screen shows:
1
Press … or † button to select the desired title number.
Press PLAY. Then chapter screen appears.
You can also select the desired chapter number by using … or
† button. Press PLAY.
2
Program
Title 1
Title 2
Title 3
Title 4
Title 5
Title 6
1
3
5
7
9
11
13
15
2
4
6
8
10
12
14
16
†
Play Clear
Clear all
Program
..
Chapter 1
Chapter 2
Chapter 3
Chapter 4
Chapter 5
1
3
5
7
9
11
13
15
2
4
6
8
10
12
14
16
†
Play Clear
Program
..
Chapter 1
Chapter 2
Chapter 3
Chapter 4
Chapter 5
1 T1C2
3
5
7
9
11
13
15
2 T2C2
4
6
8
10
12
14
16
†
Play Clear
Clear all
The selected title/chapter number will display at the right sides on
the screen.
After the programming is finished, press direction [œ √…† ]
button to select "Play", press "PLAY" button to start playing.
DSW-800H(English) 2008.9.11 9:59 AM ˘`29
Play discs in various ways
30
You may program the track on a disc and play them in the programmed order.
PROGRAM PLAY (VCD)
Press "PROGRAM" button, the screen shows:
1
• Single track
disc can not
be
programmed.
N
Note:
• You can clear all programmed item by press PLAY button on the position of
“Clear All”.
• You can clear from the latest programmed item by press PLAY button on the
position of “Clear”.
N
Note:
Press … or † button to select the desired track number.
Press PLAY.
2
Program
Track 1
Track 2
Track 3
Track 4
Track 5
Track 6
1
3
5
7
9
11
13
15
2
4
6
8
10
12
14
16
†
Play Clear
Clear all
Program
Track 1
Track 2
Track 3
Track 4
Track 5
Track 6
1 T3
3 T1
5
7
9
11
13
15
2 T4
4
6
8
10
12
14
16
†
Play Clear
Clear all
The selected track number will display at the right sides on the
screen.
After the programming is finished, press direction [œ √…† ]
button to select "Play", press "PLAY" button to start playing.
DSW-800H(English) 2008.9.11 9:59 AM ˘`30
Play discs in various ways
31
PROGRAM PLAY (CD, MP3, JPEG, MPEG4)
Cancel PROGRAM
In order to add a file to the
program list, press STOP to stop
the playing file.
Use √ button to select Edit Mode
and press [PLAY] button.
When Edit Mode is selected, 'Edit
Mode' box is already highlighted.
In this case, you don't need to
select Edit mode again.
1
Then press œ button to select the file you want and press [PLAY] button.
2
Press √ button to select “Add To Program”, and press [PLAY] button. Then press
… button to select “Program View” and press [PLAY] button.
3
Use … button to select Edit Mode and press [PLAY] button.
Press œ button to select the file of your choice and press [PLAY] button.
4
9268-2
AAFALLROAD12
ALL_NITE
AMEILEENDONA
AMFUNKYFLOW
AMPOPPIESDAI
AMPOPPI2
AMPOP
17/76 /mp3/04 -- -- - - --.MP3
Edit Mode
Program View
Add To Program
JPEG Preview
AMEILEENDONA
AAFALLROAD12
AMPOPPI2
AMPOPPIESDAI
17/76
Edit Mode
Browser View
Clear program
JPEG Preview
1. Press STOP twice, and press √ button
to select “Edit Mode” and press
[PLAY]. When Edit Mode is selected,
'Edit Mode' box is already highlighted.
In this case, you don't need to select
Edit mode again.
2. Press œ button and
[œ √…† ]
button to select the file you’d like
cancel and press PLAY to confirm your
operation.
First of all, you have to cancel the selection of “Edit Mode” in order
to play the desired file.
C
Caution:
3. Press √ button to select “Clear Program” and press [PLAY] button to confirm your
selection.
4. Press … button to select 'Browser View" and press [Play] button to exit program
screen.
DSW-800H(English) 2008.9.11 9:59 AM ˘`31
Function Setting
Function Setting
32
MENU SETTING
According to the recorded information and external equipment, set the following functions
for DVD to obtain the best playing status. Press "SETUP" button to set the main menu.
OSD language : English
Subtitle : Off
DivX Subtitle :
Western European
Audio : Auto
DVD menu : Auto
TV display : Normal/LB
TV type : NTSC
Screen Saver : On
Smart Picture : Standard
HD Resolution : Auto
Digital Output : LPCM
Night Mode : Off
Down Sampling : Off
Parental Control : 8. Adult
Set Password
Use Default Settings
OSD language
Digital Output
1
SETUP button
2
Play or √button
Language
Video
Audio
Parental
TV display
Parental Control
Enter Password
Normal/PS
Normal/LB
16:9 Wide
✓
Off
LPCM
Bitstream
✓
English
Spanish
✓
DSW-800H(English) 2008.9.11 9:59 AM ˘`32
Function Setting
33
BASIC NAVIGATION
To navigation through the setting on the screen, use the direction [œ √…† ] buttons to
scroll through the list of settings and use “PLAY” button to select the high lighted function.
SETUP MENU
Press the SETUP button to enter the On Screen Display and to exit at any time. In each of
the menus, selecting MAIN PAGE (SETUP menu) will immediately return you to the initial
screen.
Subtitle
Audio
DVD Menu
Night Mode
Off
On
…
or
†
…
or
†
…
or
†
…
or
† …
or
†
DivX subtitle
…
or
†
✓
Down Sampling
Off
On
✓
TV type
NTSC
PAL
Auto
✓
HD Resolution
Auto
480P/576P
720P
1080i
✓
Screen Saver
Smart Picture
…
or
†
…
or
†
…
or
†
…
or
†
Set Password
Enter New Password
1. Kid Safe
2. G
3. PG
4. PG-13
5. PG-R
6. R
7. NC-17
8. Adult
Use Default Settings
Yes No
…
or
†
…
or
†
✓
Off
On
✓
Standard
Bright
Soft
Dynamic
✓
Dynamic
Brightness
Contrast
Tint
Color
0
0
0
0
English
Spanish
Auto
Off
✓
Western European
Central European
✓
English
Spanish
Auto
✓
English
Spanish
Auto
✓
DSW-800H(English) 2008.9.11 9:59 AM ˘`33
Function Setting
34
LANGUAGE
OSD LANG.
When select a language, the screen show this language.
For example, if you select ENGLISH, the OSD is in English.
“OSD” means
“On Screen
Display”.
N
Note:
SUBTITLE
• Selecting Subtitle language.
Please set it as the preferred language. In case the subtitle language is set and
recorded in the DISC, it is automatically played in the set language in every
playing. For example, English is set and recorded as subtitle language in the
DISC, it is played in English.
DivX SUBTITLE (For MP4 files only)
• Selecting DivX Subtitle language.
Please set it as the preferred language. In case the DivX subtitle language is
set and recorded in the DISC, it is automatically played in the set language
in every playing. For example, English is set and recorded as subtitle
language in the DISC, it is played in English.
The default is Western European.
Each DivX subtitle option supports related languages as follows.
• Western European: supports Albanian, Breton, Catalan, Danish, Dutch,
English, Faroese, Finnish, French, Gaelic, German,
Icelandic, Irish, Italian, Norwegian, Portuguese,
Spanish and Swedish.
• Central European: supports Albanian, Croat, Czech, Dutch, English,
German, Hungarian, Irish, Polish, Romanian, Slovak,
Slovene and Sorbian.
DSW-800H(English) 2008.9.11 9:59 AM ˘`34
Function Setting
35
AUDIO
• Selecting an audio language.
Set it as the preferred audio language. In case the audio language is set and
recorded in the DISC, it is automatically played in the set language in every
playing. For example, English is set and recorded as audio language in the
DISC, it is played in English.
DVD MENU
• Selecting DVD Menu language.
Please set it as the preferred DVD MENU language. In case the DVD MENU
language is set and recorded in the DISC, it is automatically played in the set
language in every playing. For example, English is set and recorded as a DVD
MENU language in the DISC, it is played in English.
DSW-800H(English) 2008.9.11 9:59 AM ˘`35
Function Setting
36
VIDEO
TV DISPLAY
NORMAL/PS
This is selected when the unit is
connected with a normal TV.
Wide-screen images are shown on the
screen, but with some parts cut
automatically.
1
1
NORMAL/LB
This is selected when the unit is
connected with a normal TV.
Wide-screen images are shown on screen,
with black belts on the top and bottom.
2
2
16:9 WIDE
This is selected when the unit is
connected with a wide-screen TV.
3
3
TV TYPE
You may select according to the colour system of the TV to be connected.
• Select "NTSC" for a NTSC TV.
• Select "PAL" for a PAL TV.
• Select "AUTO" for a multi-system TV.
SCREEN SAVER
Start the screen saver, the screen saver image appears when the unit stops or
the image is motionless for a few seconds. This saver can keep the screen from
being damaged.
DSW-800H(English) 2008.9.11 9:59 AM ˘`36
Function Setting
37
HD Resolution
The HD Resolution menu enables you to select the desired HD Resolution
used for the video output.
In STOP mode or no disc in the tray, press V-MODE button to select HD
then in SETUP menu to access HD resolution.
There are five Resolution mode.
The default is Auto.
Smart Picture
Select the Picture preset according to your preference. There are 4 options
to select, they are : Standard, Bright, Soft, Dynamic.
• Dynamic - Highlight the Dynamic menu, and press PLAY to confirm. Use
… or † buttons to highlight one of the following options :
Brightness, Contrast, Tint and Color.
Use œ or √ buttons to set the level.
DIGITAL Output
• Bitstream
Select this when the DVD player is connected with a power amplifier through
coaxial port. Please refer to the page 14. when a Dolby Digital DVD, DTS DVD
or MPEG DVD is played, select this, the coaxial port will output in the
corresponding digital format (source code).
• LPCM
Select this when the DVD player is connected with a TV or a power amplifier
through audio cord.
• OFF
No signal is output from the coaxial port.
AUDIO
DSW-800H(English) 2008.9.11 9:59 AM ˘`37
Function Setting
38
Night Mode
Set Night mode to On or Off.
The default is Off.
Down Sampling
Set Down Sampling mode to On or Off.
The default is Off.
DSW-800H(English) 2008.9.11 9:59 AM ˘`38
Function Setting
39
PARENTAL
PARENTAL CONTROL
The Parental Control feature allows you to prevent DVDs from being played
based on their ratings or to have certain discs played with alternative scenes.
You can set the Rating Level from ‘1. Kid Safe’ to ‘8. Adult’.
The content of a disc with lock function is evaluated by grades. You can select
an age grade as your need.
Example: Select “1. Kid Safe”, the scenes of violence inadvisable to children are
not played.
For adults, the screen suggests you enter the code after pressing “PLAY”
button, you can watch if the code is right.
The password is
set by yourself.
The password is
3308 when the
unit is turned on
initially or you
forget the
password.
N
Note:
N
Note:
SET PASSWORD
Select "SET PASSWORD" in Parental menu to setup password.
Press PLAY button, then Enter password screen appears.
Input a password according to the screen.
Use Default Settings
Each function setting returns to the factory initial status if you select “Yes”.
Use Default Settings
Yes No
Set Password
Enter New Password
DSW-800H(English) 2008.9.11 9:59 AM ˘`39
Others
Others
40
TROUBLESHOOTING
If you experience the following problems while using the unit, this troubleshooting
guide can help you.
• NO SOUND
- Check if the unit is connected securely.
- Make sure you operate the TV or amplifier correctly.
• NO IMAGE, IMAGE ROLLS AND NO COLOUR
- Check if the unit is connected securely.
- Make sure you operate the TV correctly.
- Make sure you set the colour system correctly.
• BAD SOUND QUALITY
- Make sure the audio output mode is set correctly.
- Make sure the audio connection between the unit and amplifier is right.
• DISC CAN NOT BE PLAYED
- There is no disc in the unit.
- Insert the disc on the disc tray properly with the label side up.
- Clean the disc.
- Moisture has condensed in the unit.
Remove the disc and leave the unit on for about one hour.
• REMOTE CONTROL DOES NOT WORK
- Remove barriers between the remote control and the unit.
- Replace the batteries with new ones.
- Point the remote control at the remote control sensor of the unit.
• ATTENTION: KEEPING THE STATUS OF STOP MORE THAN 5 MINUTES ENTERS
SCREEN SAVE MODE. WHEN THE SCREEN SAVE MODE IS KEPT MORE
THAN AN HOUR, THE SET ENTERS STAND-BY MODE.
DSW-800H(English) 2008.9.11 9:59 AM ˘`40
Others
41
Notes : Design and specifications in this instruction manual are subjected to change without prior notice to
improve quality and function.
TECHNICAL SPECIFICATIONS
Laser
Video
Frequency response
Signal/noise ratio
output level : 2.0 + 0/-0.2Vrms
(Load impedance : 1.0kΩ)
output level : 0.5 ± 0.1Vp-p
(Load impedance : 75Ω)
output level : 1.0 ± 0.1Vp-p
(Load impedance : 75Ω, imbalance, negative
polarity)
output level : brightness (Luma) 1.0 ± 0.1Vp-p
chromaticity (Color) 0.286 ± 20%
(Load impedance : 75Ω)
Audio/Video Output (480p/576p, 720p, 1080i)
100-240V~ 50Hz/60Hz 12W
430 x 33 x 222 mm
2.23kg / 1.57kg
wavelength 650nm
NTSC/PAL/AUTO
20Hz ~ 20KHz (±1dB)
≥
90dB
≥
85dB ( 1kHz)
≥
80dB ( 1kHz)
Channel separation
Dynamic range
Output
Audio
Output
Video
Analog
Digital
Composite
S-video
Power
HDMI
Component
Body (W x H x D)
Packing
Dimensions
Weight (Gross/ Net)
462 x 85 x 272 mm
Y: 1Vp-p, Pb/Pr: 0.7Vp-p (Load impedance : 75Ω)
DSW-800H(English) 2008.9.11 9:59 AM ˘`41
Loading...
