Page 1
B e fore Putting Into Use
I m p o rt a n t
• B e fore connecting the appliance to the power supply, let it stand for about 2
h o u r s, which will reduce a possibility of malfunctions in the cooling system due
to tra n s p o rt handling.
• Clean the appliance, and be thorough, especially in the interior (See Cleaning
and Maintenance).
Instructions for Use
These instruction for use are intended for the user. They describe the appliance
and its correct and safe use.
Tips for Energy Sav i n g s
• Try not to open the door too often, especially when the weather is wet and hot.
Once you open the door, mind to close it as soon as possibl e.
• E ve ry now and then check if the appliance is sufficiently ventilated (adequate
air circulation behind the appliance).
• Set thermostat from higher to lower settings as soon as possible (depends on
h ow loaded the appliance is).
• B e fore loading the appliance with packages of fresh fo o d s, make sure they are
cooled to ambient tempera t u r e.
• Ice and frost layer increase energy consumption, so do clean the appliance as
soon as the layer is 1/8” thick .
• D a n ger or Warning: Risk of child entrapment.
• Child entrapment and suffocation are not problems of the past. Ju n ked or
abandoned appliances are still dangerous. . . even if they will “just sit in the
g a rage a few day s.”
•
B e fore you throw aw ay your old refrigerator or freeze r :
L e ave the shelves in place so that children may not easily climb inside.
•
If you have bought this appliance to replace an old one equipped with a lock that
cannot be opened from inside (lock, bolt), make sure that the lock is broke n .
This will make it impossible for children to lock themselves inside the appliance
and suffo c a t e.
• The appliance must be correctly connected to the power supply. (See: How to
i n s t a l l )
• Do not touch the cooled surfaces while the appliance opera t e s, especially not
with wet hands, because the skin may stick to the cold surfa c e s.
• Do not freeze bottles containing liquid, such as mineral wa t e r, sparkling wine,
b e e r, cola etc., because liquid expands during freezing and the glass bottle is
ve ry likely to ex p l o d e.
• If the food has strange smell or color, throw it away, because it is ve ry like l y
that it is spoiled and therefore dangerous to eat.
• Disconnect the appliance from the power supply before repairing it (only a
qualified technician should repair it).
• Do not defrost the appliance with other electric devices (hair dryer etc.) and
n ever scrape the ice or frost layer with sharp tools.
Ta ke off the doors.
• The rating plate is inside the appliance or outside on the rear wa l l .
Page 2
NAMES OF THE PA RT S
Defrost the refri g e rator when the frost accumulated on the eva p o rator is about
5mm (1/5inch) thick .
Set the thermostat dial to “OFF”. Remove frozen or peri s h a ble fo o d s. Insert dri p
t ray below the freezer compartment only for defrosting (as shown below ) .
Defrosting usually takes a few hours. To defrost quickly remove all foods from
the refri g e rator and leave the door open.
N ever use a knife or other metal instrument
to scrape ice/frost from the eva p o r a t o r. A f t e r
defrosting, empty water from drip tray and return
the themostat dial to the desired position.
N OT E : Wait 3-5 minutes before restarting if you unplug the refri g e ra t o r.
The unit may fail to operate properly if restarted too quick l y.
H OW TO OPERAT E
S t a rting your new Refrige r a t o r
1. Clean the refri g e rator thoroughly. Wipe the outside with a soft dry cloth, the
i n t e rior with a damp cloth.
2. I n s e rt the power supply cord into the socke t .
3. Tu rn the thermostat dial to “7”. Close the door and let the refri g e ra t o r
o p e rate for 15-20 minu t e s.
Temperature contro l
To control the internal tempera t u r e, adjust
the thermostat dial. The dial is nu m b e r e d
from 1-7.
Number 1 is the wa rmest setting, number 7
the coldest.
The dial may be set any place on the scale.
It does not have to be set exactly on a
nu m b e r. To make ice cubes in the freeze r
c o m p a rtment, adjust the thermostat to the
coldest setting.
! Fr e e ze r
@ D rain Pa n
# Control Box
$ Plastic Coated Shelf
% Magnetic Door Seal
^ Ice Cube Tray
& R a ck
* Bottle Rack
H ow to defro s t
Page 3
H OW TO OPERAT E
1. R e m ove the hinge cover on the right top
of the cabinet.
2. R e m ove the two screws (using a ra t c h e t
tool with a 8MM socket) that hold the top
hinge to the cabinet. Keep these screw s
for later use.
3. Lift the top hinge straight up to free the pin
from the socket on the top of the door.
4. Lift the door and place it on a padded
s u r face to prevent scratching it.
5. R e m ove the plug buttons from the upper
left holes as illustrated and tra n s fer them
to the uncovered holes at the right side.
Be sure to press the plug buttons firm l y
into the holes.
6. L ay the cabinet on its side down on the
f l o o r. Remove the two screws that hold
the bottom hinge to the cabinet using a
10MM socket. Keep these screws and
washers for later use.
CHANGING THE REVERSIBLE DOOR
C l e a n e rs : N ever use harsh, abra s i ve cleaners, heavy-duty cleaners, or solve n t s
on any surfa c e.
E x t e r i o r : Wipe with damp, sudsy cloth, rinse and dry. For stubb o rn stains and
for periodic waxing, use silicon wa x .
F r e e ze r : When refri g e rator needs defrosting turn thermostat dial to “OFF”. Do
not use sharp instruments to scrape off ice/frost.
R e f r i geration Section: Wash shelves and other remova ble parts in wa rm sudsy
wa t e r, rinse and dry. Wash interior with baking soda solution (3 Ta blespoons to 1
Liter of water) or wa rm sudsy wa t e r, rinse and dry.
M agnetic Door Seals:Wash with wa rm sudsy wa t e r.
The Finishing To u ch :Replace all parts and return thermostat dial to desired
s e t t i n g .
H OW TO INSTA L L
Install refri g e rator in a convenient location away from extreme heat and cold.
A l l ow sufficient clearance between the refri g e rator and side wall so the door
will open without obstruction. Refri g e rator is not designed for recessed
i n s t a l l a t i o n .
Select a space with strong level floor.
A l l ow 5 inches of space between the
r e f ri g e ra t o r ’s side and the wa l l .
This refri g e rator has been built with the door hinges on the ri g h t .
If you wish to change the opening direction, fo l l ow the instruction below :
• Unplug the refri g e rator from its electrical outlet.
• Empty eve rything in the refri g e ra t o r, including shelve s, food, etc.
P OWER CORD REPLAC E M E N T
If the refri g e ra t o r ’s power cord is damaged, have it replaced by a qualified
repair agent.
Page 4
W H AT TO DO. . .
7. I n s e rt the bottom hinge at the left side
using the two screws previously remove d
in step 6.
N OT E : Do not tighten screw s.
8. Stand the cabinet.
9. Replace the door making sure the bottom
s o cket enters the bottom hinge pin.
Be sure washers are in place.
10. While holding the door in the closed
position, secure the top hinge at the left
side using the two screws prev i o u s l y
r e m oved at the beginning in step 2.
Do not tighten the screws until the top of
the door is leveled with the top cabinet.
11. Replace the hinge cove r.
When the fridge is not in use for a pro l o n ged period:
• R e m ove the power plug from the power point.
• R e m ove all contents from the fri d g e.
• D ry the interior and leave the door open for a few day s.
When you wish to move the fridge :
• Secure all mova ble parts and contents.
( Pa ckage them separately if necessary. )
• Tra n s p o rt the fridge only in an upright position. In any other position yo u
m ay damage the compressor.
B e fore calling serv i c e, please fo l l ow the checklist below.
This may save you an ex p e n s i ve service call.
If the refrigerator seems too warm inside:
• C h e ck that the door has not been opened too frequently or for too long.
• C h e ck that the interior circulation is not obstructed by having too many
goods stored. (The fridge is ove rl o a d e d )
• Did you store anything hot. without first cooling it to room tempera t u r e ?
• Is there sufficient clearance around all sides and above the fri d g e ?
12. Tools required:
-8MM & 10MM socke t - ra t c h e t .
-Putty knife or thin-blade screw d ri ve r.
If the fridge starts making any unusual noises:
• Is it wo bbling? Re-level it and check if it now operates norm a l l y.
• H ave any objects fallen behind the fridge? If so, remove them and check if
o p e ration is now norm a l .
• Are any containers inside the fridge vibrating or resonating? If so, rearra n g e
them then check to see if operation has returned to norm a l .
WA R N I N G-Improper use of the grounding plug can result in a risk of electri c
s h o ck. If it is necessary to use an extension cord, use only a 3-wire ex t e n s i o n
cord that has a 3-blade grounding plug and a 3-slot receptacle that will
accept the plug on the appliance. The marked rating of the extension cord
should be AC 1 1 5 - 1 2 0 V, 10A, or more. If a grounding adapter is used, make
sure the receptacle box is fully gr o u n d e d .
Page 5
90 Day Limited Wa rra n t y
O R
INSTRUCTION MANUAL
Avanti Products will rep l a c e, without ch a rge, any product, wh i ch proves to be
d e fe c t ive in mat e rial or wo rkmanship under normal use within 90 days from date of
p u rch a s e. This wa rranty does not include cabinet or cosmetic damages of any kind.
Avanti Products will not be liable for any food loss, or incidental or consequential
d a m ages that may arise connection with its wa rranted pro d u c t .
R E F R I G E R AT
This wa rranty is void outside the Continental United Stat e s .
Model No.: 2 7 1
CONSUMER INFORMATION SERVICE:
IF YOU NEED ASSISTANCE, CALL TOLL FREE
FROM ANYWHERE IN THE UNITED STATES
( 8 0 0 ) 2 2 0 - 5 5 7 0
Before use, please read this manual carefully.
Always remove the drain pan while this refrigerator is running.
Removing the drain pan will enhance the cooling power and save your electric cost.
