1. Introduction
1.1. Overview....................................................................
sensorCUE-W is a temperature and daylight sensor for indoor installation compatible with ABB Time
or Element design series. The temperature sensor can be used for temperature monitoring and
heating control. The daylight sensor enables the controller to automatically dim lights when available
daylight is high, or brighten lights when daylight is low in order to maintain a specific light level in the
space. It may be calibrated for daylight sensitivity by programming the controller. The unit is fully
compatible with CUE controllers and the connection is provided via standard CUEwire system bus.
1.2. Models........................................................................
This User Manual describes products itemized in the table below.
Model Product code Description
sensorCUE-W CS0289 Temperature and daylight sensor for indoor installation.
1.3. Features .....................................................................
• Temperature measurement range -20°C to +50°C
• Integrated daylight sensor
• Compatible with Time and Element design series of ABB Switches
• Fully compatible with ipCUE controllers
• Small size
• Easy installation
• System connection by CUEwire
1.4. Programming .............................................................
The sensorCUE is programmed using Cue Director XPL programming tool.
User Manual sensorCUE-W
www.cuesystem.com
Page 4 of 14
2. Description
The case of sensorCUE-W is a small plastic box (83 x 81 x 27 mm) which allows simple installation
into the standard European electrical wall box. The temperature and daylight sensors must not be
covered so that the functionality of sensorCUE-W is ensured. The standard CUEwire is connected via
4-conductor cable, containing the 24 VDC power supply and RS-485 data.
sensorCUE-W front view
Daylight sensor
Temperature sensor
User Manual sensorCUE-W
www.cuesystem.com
Page 5 of 14
3. Connecting
The connection of sensorCUE-W is described in the picture below.
sensorCUE-W rear view
DIP switch for address settings
Pin
1
S1
J2
1432
Signal
1
+24
Power +24 VDC
2
G
Ground
34A+B-RS-485 Data +
RS-485 Data -
CUEwire connector
CUEwire connector
Description
Phoenix 4-pin 3.5 mm
User Manual sensorCUE-W
www.cuesystem.com
Page 6 of 14
4. Addressing
Each unit connected to the CUEwire bus must have its unique address. These addresses for
touchpanels and keyboards are set in configuration and are called „panel addresses“. The same type
of address is set for each sensorCUE-W. Its value must be unique for each unit on the CUEwire bus.
The ADDRESS of the sensorCUE-W is binary coded by DIP switch located on the rear panel.
The ADDRESS can be set in the range 1 to 127. Default ADDRESS is 15.
Switch view Switch nr. Function Address bit’s weight
SW1 ADDRESS bit 0 1
SW2 ADDRESS bit 1 2
SW3 ADDRESS bit 2 4
SW4 ADDRESS bit 3 8
SW5 ADDRESS bit 4 16
SW6 ADDRESS bit 5 32
SW7 ADDRESS bit 6 64
SW8 Not used Not used
ADDRESS SW1 SW2 SW3 SW4 SW5 SW6 SW7
1 ON OFF OFF OFF OFF OFF OFF
2 OFF ON OFF OFF OFF OFF OFF
3 ON ON OFF OFF OFF OFF OFF
4 OFF OFF ON OFF OFF OFF OFF
5 ON OFF ON OFF OFF OFF OFF
6 OFF ON ON OFF OFF OFF OFF
7 ON ON ON OFF OFF OFF OFF
8 OFF OFF OFF ON OFF OFF OFF
9 ON OFF OFF ON OFF OFF OFF
… … … … … … … …
15 ON ON ON ON OFF OFF OFF
… … … … … … … …
126 OFF ON ON ON ON ON ON
127 ON ON ON ON ON ON ON
User Manual sensorCUE-W
www.cuesystem.com
Page 7 of 14
5. Programming
The standard command for reading out the data from sensorCUE-W is:
RemoteVariableGet (reference as Word, paneladdress As Byte) as Word
The reference allows to identify which measured value should be read while the paneladdress
identifies which sensorCUE unit is to answer.
The following reference values are supported:
• Reference = 0 sensorCUE firmware version
• Reference = 1 temperature value
• Reference = 2 lighting level value
Reference = 0 sensorCUE-W firmware version
Response value is in range 0 - 65535
Example: Fw = RemoteVariableGet (0, 34)
This command has assigned the firmware version number of sensorCUE-W (with the address 34) to
the Fw variable.
Reference = 1 temperature value
The temperature is measured with a 12-bit resolution sensor. It covers the measuring range from
+50 °C to -20 °C
The temperature value is encoded into a 16-bit response value acco rding to the following rules:
Response value bit weight
BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
S S S S S 26 25 24 23 22 21 20 2-1 2-2 2-3 2
-4
S means sign.
S=0 for positive and S=1 for negative values.
User Manual sensorCUE-W
www.cuesystem.com
Page 8 of 14
Temperature –Response data relationship:
TEMPERATURE RESPONSE VALUE (binary) RESPONSE VALUE (hex)
+25.0625°C
+10.125°C
+0.5°C
+0°C
-0.5°C
-10.125°C
0000 0001 1001 0001 0191H
0000 0000 1010 0010 00A2H
0000 0000 0000 1000 0008H
0000 0000 0000 0000 0000H
1111 1111 1111 1000 FFF8H
1111 1111 0101 1110 FF5EH
Example: T = RemoteVariableGet (1, 68)
This command has assigned the temperature from sensorCUE-W (with the address 68) to the
T variable.
Reference = 2 the lighting level value
The expected response value range is ( 1 - 30000).
The lowest values mean the highest lighting levels and the highest values mean dark.
The typical expected return values are as follows:
For straight full light the return values are below 100
For bright room the return values are about 700-800
For dark room the return values are about 3500-5000
Example: Light = RemoteVariableGet (2, 47)
This command has assigned the lighting level from sensorCUE-W (with the address 47) to the Light
variable.
User Manual sensorCUE-W
www.cuesystem.com
Page 9 of 14
6. Program module for sensorCUE
For easier programming you can use the module sensorCUE.csm. You can find it on the CUE
Application CD in folder XPL Drivers and Modules. This module is also compatible with sensorCUE-W.
This module has two functions:
Public Function
Integer
GetTemperature returns current temperature measured in 1/10 degrees of Celsius as integer value (it
allows negative values). Returned values are -200 (-20 °C) to 500 (+50 °C). The first parameter is the
panel address of sensorCUE-W, the second parameter is string, where temperature value will be
stored as string (“-20.0” to “+50.0”)
Example:
Declarations:
Public TemperatureInt As Integer
Public TemperatureString As String *10
Program:
TemperatureInt = GetTemperature(38, TemperatureString)
This command has assigned the temperature from sensorCUE-W (with the address 38) to the
TemperatureInt variable. If current temperature is for example +23.5 °C, in TemperatureInt variable
will be value 235. In string TemperatureString will be value “+23.5”.
Public Function GetLight(PanelAddress As Word) As Word
GetLight returns current lighting level as a word value. Returned values are 1 (straight full light) to cca
30000 (dark).
Example:
Declarations:
Public LightLevel As Word
Program:
LightLevel = GetLight(48)
This command has assigned the lighting level from sensorCUE-W (with the address 48) to the
LightLevel variable.
GetTemperature (PanelAddress As Word, ByRef TemperatureAsText As String) As
User Manual sensorCUE-W
www.cuesystem.com
Page 10 of 14
7. Specifications and Mechanical Drawings
Temperature measurement.................Range -20°C to +50°C
Daylight sensing..................................May be calibrated for day / night light level recognition
System connection..............................CUEwire (RS-485)
Power supply.......................................24 VDC (+/- 20%), 1 W
Enclosure.............................................Plastic
Dimensions (WxHxD)..........................83 mm (3.3”) x 81 mm (3.2”) x 27 mm (1.1”)
Weight..................................................0.1kg / 0.2 lb
User Manual sensorCUE-W
www.cuesystem.com
Page 11 of 14
8. Software and Firmware License
END-USER NOTICE AND LICENSE AGREEMENT FROM CUE, a.s.
NOTICE TO END-USER: CAREFULLY READ THE FOLLOWING LEGAL AGREEMENT (THIS "LICENSE").
INSTALLATION OR USE OF THE ENCLOSED CUE, a.s. SOFTWARE PROGRAMS (COLLECTIVELY,
"SOFTWARE") ON YOUR COMPUTER SYSTEMS OR HARDWARE DEVICES CONSTITUTES YOUR
ACCEPTANCE OF THESE TERMS. IF YOU DO NOT AGREE TO THE TERMS OF THIS LICENSE, PROMPTLY
DELETE THE SOFTWARE FROM YOUR COMPUTER SYSTEMS AND HARDWARE DEVICES, DESTROY
ANY COPIES YOU MADE OF THE SOFTWARE OR ANY INSTALLATION MEDIA OF THE SOFTWARE
INCLUDED WITH YOUR SYSTEM, AND DISPOSE OF ALL WRITTEN MATERIALS IN YOUR POSSESSION
REGARDING THE SOFTWARE.
License Grant: CUE grants to You, as an individual, a license to install and use one (1) copy of the Software on
a single computer at a time; provided, however, that You may make copies of the Software solely for Your
development of applications for CUE hardware and demonstration versions of such applications. Any applications
created with the Software may only be used with Cue hardware. Your license to use the Software is conditioned
upon Your compliance with the terms of this License. A License is required for each end-user of the Software. A
license is required for each installation of the Software. You may make one (1) copy of the Software for archival
purposes only. You may use this Software only in connection with CUE hardware. You must have acquired the
Software directly in connection with the purchase of CUE hardware from CUE or from a CUE approved reseller
for this license to be effective. If You have purchased a Site License, You may complete only the number of
installations specified in the License Agreement accompanying the Software.
Copyright: The Software and soft ware built into CUE hardware ("Firm ware") are protected by copyright la w and
international treaty provisions. You acknowledge that no title to the intellectual property in the Software and
Firmware is transferred to You. You further acknowledge that title and ful l ownership rights to the Software and
Firmware will remain the exclusive property of CUE, and You will not acquire any rights to the Software and
Firmware except as expressly set forth in this License. You agree that any copies of the Software will contain the
same proprietary notices which appear on and in the Software.
Prohibited Uses: Without obtaining prior written permission from CUE, You ma y not (a.) use, cop y, modify, alter,
or transfer the Software or documentation except as expressly provided in this License; (b.) translate,
disassemble, decompile, reverse program or otherwise reverse engineer the Software and Firmware; (c.)
sublicense or lease the Software or its documentation (d.) use this Software with any hardware other than
products produced by CUE or in connection with applicat ions being devel oped for CUE hardware; or (e.) use t he
Software in a multi-user, network, or multiple computer environment or in a rental, time sharing or computer
service business. Without prejudice to any other rights, CUE may terminate this License if You fail to comply with
its terms and conditions. In such event, You must immediately destroy all copies of the Software.
No Other Warranties: CUE DOES NOT WARRANT THAT THE SOFTWARE AND FIRMWARE IS ERROR
FREE. CUE DISCLAIMS ALL WARRANTIES WITH RESPECT TO THE SOFTWARE AND FIRMWARE, EITHER
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OF THIRD PARTY RIGHTS. SOME
JURISDICTIONS DO NOT ALLOW THE EXCLUSION OF IMPLIED WARRANTIES OR LIMITATIONS OF HOW
LONG AN IMPLIED WARRANTY MAY LAST, OR THE EXCLUSION OF LIMITATION OF INCIDENTAL
DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WARRANTY
GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM
JURISDICTION TO JURISDICTION.
No Liability for Consequential Damages: IN NO EVENT SHALL CUE BE LIABLE TO YOU FOR ANY
CONSEQUENTIAL, SPECIAL, INCIDENTAL, OR INDIRECT DAMAGES OF ANY KIND ARISING OUT OF THE
PERFORMANCE OR USE OF THE SOFTWARE, EVEN IF CUE HAS BEEN ADVISED OF THE POSSIBILITY
OF SUCH DAMAGES.
Label on Hardware: Use of this hardware and the software programs controlling this hardware is subject to the
terms of the Software and Hardware License Agreements (the “License Agreements”). You should not use the
software and hardware until you have read the License Agreements. By using the software and hardware, you
signify that you have read the Licenses Agreements and accept their terms. The “License Agreement” is available
at www.cuesystem.com.
Trademark Notice: CUE and the CUE logo are trademarks of CUE, a.s. in the United States and in other
countries.
User Manual sensorCUE-W
www.cuesystem.com
Page 12 of 14
Notes
User Manual sensorCUE-W
www.cuesystem.com
Page 13 of 14
Notes
User Manual sensorCUE-W
www.cuesystem.com
Page 14 of 14
Loading...
