CUE CRS DemoSet User Manual

Cue ReseRvation system Demo set

User Manual

10.10.2011

Cue Reservation System Demo Set

overview

Cue Reservation System Demo Set includes all necessary equipment for CRS functionality demonstration.

It is fully programmed and congured.

CRS is based on connection to Microsoft Exchange server. This server is located in CUE company and it is available throw Internet connection. For proper demonstration it is necessary to have network with working DHCP server and Internet connection.

PC with Microsoft Internet Explorer is necessary for demonstration and it is not part of demo set.

Microsoft Exchange server is not part of Demo set and it is available via Outlook Web Access on https://193.86.3.66/owa. We recommend to use Microsoft Internet Explorer 8 or higher. For more details how to use Web Outlook see chapter Exchange Web Interface.

All devices have to be connected regarding instructions on in chapter Connection Diagram and Installation Steps.

Demo set touch panels are congured for two rooms BOARDROOM 1 and BOARDROOM 2.

Microsoft Exchange Server is congured for totally 5 rooms (BOARDROOM 1 to 5) and all these rooms are

displayed on room overview monitor.

Box Contents

1. ipCUE-omega incl. power supply

2. 2x touchCUE-8X02 incl. PoE Adapter

3. Router Asus WL-520GU incl. power supply

4. 1x LCD monitor Samsung EX1920W incl. power supply cable

5. 6x Cat5 Straight Cable, 2 m, blue color

6. 1x Cat5 Straight Cable, 5 m, red color

7. 1x DVI cable

8. Power extension with surge protection

9. User Guide

10. CD including User Guide in PDF format

11. Carrying Case

www.cuesystem.com support@cuesystem.com

User Manual

Page 3

ConneCtion Diagram

Cue Reservation System Demo Set

PC for Microsoft Exchange Access

Router

192.168.10.1

230 VAC 230 VAC

PoE Adapter

Company Network with DHCP

enabled and Internet Access

230 VAC

PoE Adapter

230 VAC

WAN

Ethernet

DVI

ipCUE-omega

192.168.10.10

230 VAC

BOARDROOM 2

touchCUE-8X02

192.168.10.11

touchCUE-8X02

192.168.10.12

installation steps

1. Don’t connect any power supply.

2. Connect Router WAN port to your network with Internet access. Network has to be DHCP enabled.

3. Connect ipCUE-omega CUEnet(LAN) port to the router output LAN1.

4. Connect both touch panels touchCUE-8X02 to the router outputs LAN2 and LAN3 using PoE Adapters.

5. Connect PC for Microsoft Exchange Access to router output LAN4. Ethernet card on PC has to be DHCP enabled.

Room Overview DisplayBOARDROOM 1

6. Connect ipCUE-omega HDMI/DVI output to LCD display using cable HDMI to DVI.

7. Connect power supplies using following order

• Router

• Touch panels and LCD monitor

• ipCUE-omega

8. Wait approx. 1 to 2 minutes for system initialization, connection to the Microsoft Exchange server and data download.

www.cuesystem.com support@cuesystem.com

User Manual

Page 4

room User interfaCe

Basic Navigation

Screen Now displayes events for current day.

Cue Reservation System Demo Set

This Tab activates screen Events

This area contains events (appointments) for current day. Use arrows

for time scrolling.

This button allows to create reservation using screen Reserve Now.

Screen Events displays events for any selected date.

Click event for more event details.

Screen Event Details

This Tab activates screen Now.

This area contains events (appointments) for day selected by date

picker. Use arrows for time scrolling.

Selected day Date picker

Current day

www.cuesystem.com support@cuesystem.com

User Manual

Page 5

Reserve Now

Screen Reserve Now

Cue Reservation System Demo Set

Set event start time

Set event end time

Set event sensitivity*

Cancel reservation

Keyboard allows to input Subject

Conrm reservation

Screen Now displays new event.

Set event subject (description name)

* If meeting is marked as PRIVATE, title PRIVATE MEETING” is displayed instead of real event subject.

All details of this event will be hidden.

www.cuesystem.com support@cuesystem.com

User Manual

Page 6

Cue Reservation System Demo Set

exChange weB interfaCe

• Run Internet Explorer on PC for Microsoft Exchange Access.

• Go to https://193.86.3.66/owa.

• Don’t worry to click Continue to this website (not recommended). It is standard feature of trial

version of Microsoft Exchange server which is used for demonstration. If any time this window

appears, click Continue to this website (not recommended).

• Be patient and wait for response.

• Login to Web Access

Check Private Computer

Fill User name: cueuser and Password: reservation.1

Use this selection

(private computer)

• Go to Calendar section using menu on the left side.

Fill cueuser

Fill reservation.1

Step 1: Click the arrow

Step 2: Select Appointment. If certicate trouble window is displayed, click Continue to this website (not recommended).

www.cuesystem.com support@cuesystem.com

User Manual

Page 7

Cue Reservation System Demo Set

• Create new Appointment: Select Menu - New - Appointment

• Fill the appointment subject and time

Step 3: Select room in scheduling

assistant

Step 1: Fill Subject

Step 2: Set Start time and End time

• Select room and conrm appointment as described on the picture below. More rooms can be selected

in one step.

Step 1: Click arrow

Step 2: Select Add all recent rooms

Step 4: Conrm

Step 3: Select room where ap-

pointment will be held. Boardroom1 or Boardroom2 will be displayed on touch panels, other rooms are displayed only on room overview monitor.

www.cuesystem.com support@cuesystem.com

User Manual

Page 8

Cue Reservation System Demo Set

• New appointment will be displayed on the touch panel BOARDROOM 1. By the same way you can create appointment for BOARDROOM 2. All new appointments are displayed on room overview LCD monitor too.

www.cuesystem.com support@cuesystem.com

User Manual

Page 9

Cue Reservation System Demo Set

troUBleshooting

Data not available displayed on room overview display

• Check Internet access of the router. You can use PC for Microsoft Exchange Access connected to the router.

• Check all Ethernet data cables.

• Switch off and on ipCUE-omega.

Lost CUEnet displayed on touch panel

• Check all Ethernet data cables.

• Switch off and on ipCUE-omega.

How to check local Ethernet functionality

• Start Web Browser on PC for Microsoft Exchange Access connected to the router.

• Enter address 192.168.10.10 for ipCUE-omega Admin Web.

• Enter address 192.168.10.11 for Boardroom 1 touch panel Admin Web.

• Enter address 192.168.10.12 for Boardroom 2 touch panel Admin Web.

• If all Admin Web pages are accessible the local network is OK.

Time problem

• If room overview display or touch panels show wrong time or date, set proper time zone using Admin Web of ipCUE-omega and touch panels.

• NTP server (Internet clock) in ipCUE-omega and in touch panels is switched on. In case of troubles

switch off Internet clock and set date and time manually.

DHCP not available on Company Network

• Open admin web pages of the router on 192.168.10.1, login: admin, password: admin.

• Go to WAN Section and set WAN port IP address manually to meet the requirements of company

network.

sUpport

In case of troubles please contact

• Richard Milek, richard.milek@cuesystem.com

• Jakub Zelenka, jakub.zelenka@cuesystem.com

www.cuesystem.com support@cuesystem.com
