Cub Cadet CC30 User Manual
Illustrated Parts Manual
Printed In USA
Model CC30 Mini Rider
CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
Form No. 769-09489
November 12, 2013
To The Owner
Thank You
Thank you for purchasing a Cub Cadet Lawn Tractor. It was
carefully engineered to provide excellent performance when
properly operated and maintained.
All information in this manual is relative to the most recent
product information available at the time of printing. Please be
aware that this Illustrated Part’s Manual may cover a range of
product specifications for various models.
Table of Contents
Frame & Fender ....................................................... 4
Drive System ............................................................ 6
Seat, Fuel Tank & Electrical ..................................... 8
Front End Steering ..................................................10
Pedal Controls ........................................................12
Deck Lift ..................................................................13
Components listed and/or illustrated in this manual may not be
applicable to all models. We reserve the right to change product
specifications, designs and equipment without notice and
without incurring obligation.
Throughout this manual, all references to right (RH) and left (LH)
are observed from the operating position.
30” Deck ..................................................................14
Engine Accessories MTD P90 .................................16
Wiring Harness Schematic ....................................17
Labels ......................................................................18
Engine Model 4P90JUA ......................................... 20
Engine Model 4P90JUB ......................................... 34
Record Product Information
To ease in ordering replacement parts, please locate the model
plate on the equipment and record the information in the
provided area to the right. You can locate the model plate by
looking beneath the seat.
Model NuMber
Serial NuMber
Painted Parts
When ordering painted service parts, a four digit color suffix must be added to the part number (e.g. 783-XXXXX-0637).
Please refer to the table below for current color codes:
0637 Black
4021 Yellow (Cub Cadet)
0499 Beige (Cub Cadet)
0685 Blue (Cub Cadet)
0691 Black Jack (Cub Cadet Commercial)
2
This page intentionally left blank.
Frame & Fender
19
18
15
25
18
14
23
20
16
24
4
21
1
8
10
14
22
9
17
17
8
12
8
11
5
28
8
7
13
3
4
27
29
2
6
9
4
26
8
Frame & Fender
Ref.
No.
1 710-05073 Screw, 1/4-20 x .500
2 710 -0 4187A Screw, 1/4-15 x 0.50
3 731- 08753A Running Board Plug
4 738-04184A Shoulder Screw, .368 X.113: 1/4-20
5 68 3 - 05015 Frame Assembly
6 683- 05019 Column Assembly
7 710 -06194 Hex Washer Screw, 5/16-18 x .75
8 710 -1652 Tap Screw, 1/4-20, .625
9 912-0 42 9 Hex Locknut, 5/16-18
10 783 - 07168 Seat Pivot Bracket
11 783-08197 Seat Pan
12 783-08260 Deck Lift Index Bracket
13 931- 05041 Column Cover
14 710 - 0448 4 Tap Screw, 5/16-18, .750
15 710 - 0924 Machine Screw, 1/4-20, 0.750
16 710 -1241 Hex Screw, 1/4-15, 1.000
17 710-30 08 Hex Head Screw, 5/16-18, .75
18 728-0199 Rivet, .3125
19 731- 0912 9A Rear Cover
20 731-09185 Top Rear Drive Cover
21 931-10151 Fender
22 735-05006 Bumper, .62 Dia. x .50
23 749-04932 Rear Cover Support Tube
24 783-07208 Hitch Plate
25 731- 0939 9 Steering Column Cap
26 683- 04767 Bumper Assembly
27 731-08884A Trim Running Board, LH
28 731-08885A Trim Running Board, RH
29 931- 09591 Running Board
Part No. Description
5
Drive System
13
26
22
14
37
30
9
34
29
32
3
21
23
8
45
20
24
12
16
7
35
39
31
33
15
40
42
19
28
2
34
38
44
6
43
41
25
36
5
17
18
1
10
48
4
50
49
6
47
46
11
11
27
Drive System
Ref.
No.
1 918-05056A Transmission Assembly
2 647-04262C Shift Handle Assembly
3 683-04768A Drive Assembly Idler
4 710-05339 Screw, 5/16-24 x .750
5 710-044 84 Tap Screw, 5/16-18, .750
6 710-0599 Tap Scew, 1/4-20, 0.500
7 710-06016 Screw, 3/8-16 x 1.375
8 710-0623 Tap Screw, 3/8-16, 0.750
9 710-1026 Screw, 1/4-20 x 1.750
10 710 -1266 Hex Cap Screw, 5/16-18 x 3.5, Gr5
11 710 -1652 Tap Screw, 1/4-20 x .625
12 710 -0560 Screw, Carriage: 3/8-16 x 1.75”
13 711- 06141 Adjustable Ferrule, 1/4-20 X 1.00
14 712- 04063 Flange Locknut, 5/16-18
15 712- 04 0 65 Flange Lock Nut, 3/8-16
16 712- 070 0 Flange Nut, 9/16-18
17 914-0209 Internal Cotter Pin, .125 Dia.
18 714-04040 Bow-Tie Cotter Pin
19 718 - 04407 Pulley Hub, 5/8 Spline
20 720-04028 Shift Knob
21 732-0459C Extension Spring, .94 Dia. X 6.74 Lg.
22 732-04934 Extension Spring, .97 OD X 6.18
23 738-0372B Shoulder Spacer, 1.00 X .38 X .38
24 738 - 05016 Shoulder Screw, .368 x .75, 1/4-20
25 738-05019 Shoulder Screw, .560 x .165, 5/16-18
Part No. Description
Ref.
No.
26 747-05593 Shift Rod
27 747- 06126 Deck Belt Keeper, 30"
28 948-0334 Spacer
29 750-04456 Spacer, .260 X .372 X 1.420
30 750-05563 Spacer, .385 x .625 x .500
31 954-05040 V-Belt, 5L:35.25
32 954 -04331 V-Belt, 5L:35.28
33 756 - 04224 Flat Idler Pulley, 2.75 OD
34 756-04325 V-Type Idler Pulley, 3.06
35 756 - 04464 V-Type Pulley, 6.56
36 783- 07248 Rear Idler Arm Bracket
37 783-08131 Transaxle Mounting Bracket
38 956 - 04015A Variable Speed Pulley Assembly
39 710 - 0627 Hex Head Lock Screw, 5/16-24:.750
40 710- 0778 Tap Screw, 1/4-20:1.500
41 718 -04261 Bearing Cup
42 736-0362 Flat Washer, .330x1.250x.060
43 941- 0600 Ball Bearing, 17 X 40 X 12
44 783- 08210 Variable Bracket
45 634 -0139 Complete Wheel Assembly
46 734-04641 Tire, 16 x 6.5 x 8 Sq. Shldr.
47 6 3 4 -0 4174 Rim Assembly, 8.0 x 5.38
48 934- 0255 Air Valve
49 731-2290A Hub Cap
50 736-0430 Flat Washer, .35 x 1.59 x .062
Part No. Description
7
Seat, Fuel Tank & Electrical
8
7
21
24
23
29
26
16
15
28
27
6
5
14
34
33
31
18
20
11
10
12
31
19
32
32
30
2
3
4
1
25
22
8
17
13
17
13
9
17
13
17
13
Seat, Fuel Tank & Electrical
Ref.
No.
1 710- 0607 Tap Screw, 5/16-18, 0.500
2 720- 04009A Knob, 3/8-16, .875
3 712- 04 0 63 Flange Lock Nut, 5/16-18
4 732-04905 Seat Spring
5 938 -0140 Shldr Spacer, .435 X .178-5/16 X .56
6 935 - 0199A Rubber Bumper, .63 Dia
7 757- 05019 Seat
8 783-07213A Seat Pivot Bracket
9 710- 0227 Screw, #8
10 710 -044 84 Tap Screw, 5/16-18, .750
11 710-1652 Tap Screw, 1/4-20, .625
12 925 -0 6119 Key Switch
13 725-04363 Interlock Switch
14 925- 05013 Seat Switch
15 72 5 -16 43 Switch Spring
16 926- 0320 Insulator Plate
17 738-0 42 37A Shoulder Screw, #10-32, .500
18 747- 06131A Battery Rod
19 747- 06148 Battery Hold Down Bracket
20 625-05000 Key, A ssembly
21 683-04754 PTO Handle Assembly
22 710- 04683A Tap Screw, 3/8-16, 1.000
23 720-04049A Handle Grip, 3/8
24 750 -0526 Spacer, .380 ID x .50 OD x .265
25 951-04366B Fuel Tank, 1-3 Gal.
26 751-12089 -28 Hose Vent, 3/16 EPA
27 735 -04081 Rubber Grommet
28 751-12 118 Rollover Valve
29 951-12179 B Fuel Cap
30 925-1707D Battery, 155 CCA
31 7 38 -1132 Screw, Shoulder, .250 x .150
32 712-0271 Nut, Sems, 1/4-20
33 712- 0 4064 Flange Lock Nut, 1/4-20
34 725-04439 Solienoid, 12v
— 925-0 6042 Wiring Harness (Not Shown)
Part No. Description
9
Front End Steering
28
18
7
27
3
17
15
4
10
6
16
30
19
5
14
21
21
14
21
21
12
1
5
9
29
26
25
12
20
13
8
11
23
24
10
12
8
22
12
2
29
9
30
10
Front End Steering
Ref.
No.
1 683- 04726 Front Axle Assembly, RH
2 683- 04727 Front Axle Assembly, LH
3 683 - 0 4761 Upper Tube Assembly
4 683-04762 Lower Tube Assembly
5 714 -0162 Cotter Pin, 5/32 x 1.25
6 738-05000 Shoulder Screw, .375 x .148 x 1/4-20
7 710 - 0643 Hex Head Screw, 5/16-18:1.00
8 710 - 0703 Carriage Screw, 1/4-20, .75
9 731-2290A Hub Cap
10 712 - 0406 4 Flange Lock Nut, 1/4-20
11 712 - 04063 Flange Lock Nut, 5/16-18
12 714-04040 Bow-Tie Cotter Pin, 72
13 717-1554 Steering Pinion Gear
14 726 -0341 Push Cap, 3/4
15 7 26 - 04127 Snap Butt
16 731-08690 Lower Steering Collar
17 731- 08691 Upper Steering Collar
18 736-0242 Bevel Washer, .340X.872X.060
19 7 38- 0 4537A Steering Shaft, .625 OD X 18.03
20 741- 04542A Hex Flange Bearing, 5/8
21 741- 0660A Flange Bearing, .760 X .941 X 1.0
22 747-05514 Steering Rod, LH
23 747-05585 Steering Rod, RH
24 747- 06027 Front Tie Rod
25 783-06988A Steering Rack Plate
26 783-07239A Lower Steering Bearing
27 631- 040 08A Steering Wheel, Soft Grip
28 731-04039 No Sprig Cap
29 634-04726-0931 Complete Wheel Assembly
30 736- 04228A Washer, .781 x 1.59
Part No. Description
11
Pedal Controls
14
23
18
13
16
17
11
2
5
8
8
9
1
6
10
7
12
15
22
20
3
19
4
4
8
21
21
Ref.
No.
1 68 3 - 05017 Brake Pedal Assembly
2 910- 0224 Screw, #10-16:0.500
3 710- 0376 Hex Head Scerw, 5/16-18:1.00
4 710- 044 84 Tap Screw, 5/16-18:.750
5 936-0264 Flat Washer, .330 x .630 x .064
6 711- 0610 3 Ferrule 3/8-24 X .375 Dia.
7 712- 04 0 63 Flange Lock Nut, 5/16-18
8 714-04040 Bow-Tie Cotter Pin, 72
9 726 -0214 Push Cap, 5/8
10 731-08656A Speed Control Cover
11 731-08743B Speed Lever, 6-SPEED
12 732- 04937 Shift Spring
Part No. Description
12
Ref.
No.
13 747- 06033A Brake Rod
14 732-0716D Extension Spring, .59 OD x 4.00 LG
15 735-04279 Foot Pad, 2.5" LG.
16 738-04184A Shoulder Screw, .368 X.113, 1/4-20
17 741- 0356A Steering Col. Bearing, .880 ID X 1.36
18 747- 05506 Variable Speed Control Rod
19 747- 06015 Speed Selector Control Rod
20 748 -02 3 4 Shoulder Spacer
21 783-05940 Pedal Strap Support Bracket, 5/8
22 783-08116A Speed Latch Bracket
23 717- 077 2B Brake lever Bracket
Part No. Description
19
21
Deck Lift
6
14
3
3
15
11
1
12
13
18
15
5
11
12
15
17
2
12
4
16
8
9
10
20
7
Ref.
No.
1 683-05060 Lift Assembly Shaft
2 683-04757 Front Hanger Bracket Assembly
3 710- 044 84 Tap Screw, 5/16-18, .750
4 710- 0514 Hex Head Screw, 3/8-16, 1.00
5 710- 0642 Tap Screw, 1/4-20, 0.750
6 710- 0778 Screw, 1/4-20, 1.50
7 710-1652 Tap Screw, 1/4-20 X .625
8 711- 05 6 9 0 Ferrule, .50 X .50
9 712- 04 0 65 Flange Lock Nut, 3/8-16
10 712- 05046 Hex Lock Nut, 1/2-13
11 714-04040 Bow-Tie Cotter Pin, 72
Part No. Description
Ref.
No.
12 714-04043 Bow-Tie Cotter Pin, 91
13 720 -0311 Grip Handle, 1/2
14 732-04692 Extension Spring, .85 OD X 5.915 LG
15 936-0300 Flat Washer, .406 X .875 X .059
16 938-0347 Shoulder Spacer, .625 ID X .169
17 74 7- 05511 Lift Link Rod
18 747- 05576 Deck Lift Rod
19 750-0566A Spacer, .260 x .375 x 1.030 LG
20 783- 07129 Front Deck Mounting Bracket
21 936 -0463 Flat Washer, .250 x .630 x .052
Part No. Description
13
30” Deck
1
15
3
41
42
42
39
40
41
43
17
22
30
2
27
12
26
1
14
23
4
20
46
45
19
9
25
44
14
21
29
11
18
24
10
13
16
31
38
35
34
33
34
36
32
36
6
5
8
32
37
15
28
7
14
30” Deck
Ref. Part Number Description
1 918-04822A Spindle Pulley Assembly, 6.3 DIA
2 631-05024 Deck Belt Cover
3 647-05028 Idler Rod Assembly
4 983-05034 PTO Brake Assembly Bracket
5 983-05039A Deck, 30” w/ Nozzle
6 710-0347 Hex Cap Screw, 3/8-16 x 1.75
7 710-1260A Tap Screw, 5/16-18, .750
8 710-0514 Hex Head Screw, 3/8-16, 1.00
9 710-0528 Hex Cap Screw, 5/16-18 x 1.25
10 710 -059 9 Tap Scew, 1/4-20, 0.500
11 710-1026 Tap Screw, 1/4-20, 1.750
12 710-1315 Tap Screw, 3/8-16, 1.250
13 712- 0 4063 Flange Lock Nut, 5/16-18
14 712- 0 4 0 65 Flange Lock Nut, 3/8-16
15 712 - 0417A Flange Nut, 5/8-18
16 732-05045 PTO Torsion Spring
17 732- 05046 Brake Torsion Spring
18 732-0583 Compression Spring, .625 x 4.0
19 736-0362 Flat Washer, .330x1.250x.060
20 736-3040 Flat Washer, .406 x 1.920 x .060
21 938-0347 Shoulder Spacer, .625 ID X .169
22 738-04184A Shoulder Screw, .368 X.113: 1/4-20
23 738 - 05021 Shoulder Spacer, .173 x .625 x .563
Ref. Part Number Description
24 738-05022 Shoulder Spacer, .134 x .500 x .438
25 750- 04456 Spacer, .260 X .372 X 1.420 LG
26 954- 05001 V-Type Belt, 43.5 LG
27 756-04224 Flat Idler Pulley, 2.75 OD
28 783-08047A Deck Spindle Support Bracket
29 783- 0 812 8 Lower Floating Idler Bracket
30 783-08226 Upper Floating Idler Bracket
31 946 -04802A PTO Cable
32 710 - 04998 Carriage Screw, 5/16-18, 1.00
33 720 -0 4122 Wing Knob, 5/16-18
34 726-0201 Speed Nut, .3125 ID
35 731-10267 Chute Deector
36 736-0242 Bevel Washer, .340X.872X.060
37 942-04385 Cutting Blade, 30.00" 3-IN-1
38 731- 09312 Mulch Plug
39 936- 0351 Shim Washer, .760X1.500X.030
40 738-1186A Spindle Shaft, 6.11 LG.
41 941- 0919A Ball Bearing, .787ID X 1.85 ODX.551
42 750 -04936 Spacer, .792 X 1.060 X 1.860 LG
43 95 6 -1227 Deck Pulley, 6.3 DIA
44 921-04041 Water Nozzle Adapter
45 731-074 87 Deck Wash Nozzle
46 738 -04278 Shoulder Screw, 1/4-20 x 0.500
15
Loading...
