F.V/Time
2MIN
4MIN
5MIN
6MIN
8MIN
10MIN
15MIN
20MIN
30MIN
45MIN
60MIN
90MIN
1.60V
74.0
50.0
42.2
36.8
29.6
24.9
18.0
14.2
10.3
7.36
5.84
4.21
1.67V
67.3
47.5
40.7
35.8
29.0
24.5
17.8
14.1
10.2
7.34
5.82
4.20
1.70V
64.1
45.9
39.7
35.2
28.6
24.2
17.7
14.0
10.1
7.33
5.81
4.19
1.75V
58.3
42.8
37.5
33.6
27.6
23.5
17.4
13.9
10.0
7.27
5.77
4.17
1.80V
52.6
39.1
34.7
31.2
26.0
22.4
16.8
13.5
9.83
7.12
5.67
4.11
1.85V
46.2
35.4
31.2
28.2
23.8
20.6
15.7
12.7
9.38
6.83
5.45
3.96
F.V/Time
2MIN
4MIN
5MIN
6MIN
8MIN
10MIN
15MIN
20MIN
30MIN
45MIN
60MIN
90MIN
1.60V
737
518
450
399
328
280
207
165
120
86.7
69.0
50.1
1.67V
688
502
438
391
324
277
206
164
119
86.5
68.9
50.0
1.70V
677
492
431
386
320
275
205
163
118
86.3
68.8
49.9
1.75V
633
466
413
372
312
268
202
161
117
85.7
68.4
49.8
1.80V
584
434
388
351
298
257
196
157
116
84.3
67.4
49.2
1.85V
519
397
355
324
276
240
185
150
111
81.3
65.2
47.8
Please refer to the official site for the latest rating confirmation. URL:
www.csb-battery.com
Issued:
180205
Tel: +31(0)180-418-140
Tel: +886-2-2880-5600
Fax: +31(0)180-418-327
Fax: +866-2-2888-3300
Tel: +86-10-5820-5336, 5820-5338
Fax: +86-10-5820-3053
Specification
HR series
HR 1234W
12V 34W
Constant Power Discharge Characteristics Unit: W (25
℃
, 77℉)
Sales Offices
Constant Current Discharge Characteristics Unit: A (25
℃
, 77℉)
Tel: +86-755-8831-6488, 8831-6775
Tel: +86-21-5046-1622, 5046-0833
Tel: +886-2-2880-5600
Fax: +866-2-2888-3300
USA OFFICE
EUROPE (EMEA) OFFICE
TAIPEI OFFICE
Tel: +1-817-244-7777 / 1-(800)3-CSB-USA (272872)
Fax: +86-755-8831-6075
Fax: +86-21-5046-1046
Fax: +1-817-244-4445
SHENZHEN OFFICE (CHINA)
SHANGHAI OFFICE (CHINA)
Valve Regulated Lead Acid Battery
Maintenance-Free Sealed Lead Acid Battery.
Absorbent Glass Mat (AGM) technology for efficient gas recombination of up to 99%.
Design for Standby Power Applications
【Design Life】 【 Float Charging Voltage
Up to 5 Years in Standby Service at 25
Eurobat (20℃) : 3-5 years, Standard Commercial 【Equalization Charging Voltage 】
【 Operating Temperature Range】 14.4 ~ 15.0 VDC/Unit at 25℃ (77℉)
Nominal Operating Temperature : 25℃(77℉)
Discharge : -15℃ ~ 50℃ (5℉~122℉)
Charge: -15℃ ~ 40℃ (5℉~104℉)
Storage: -15℃ ~ 40℃ (5℉~104℉) at higher temperature than 25℃ (77℉).
Design according with IEC 61056-1/2:2012
Nominal Voltage 12V (6 cells per unit)
Nominal Capacity
Weight
Maximum Discharge Current
Internal Resistance
Short Circuit Current
Maximum Charge Current 3.4A
Terminal types F2 -Faston Tab250
Terminal breaking Torque --
Container Material ABS (UL 94-HB) & Flame Retardant (94-V0) available upon request
Dimensions
34W @15min-rate to 1.67V per cell @25℃ (77℉)
Approx. 2.50 Kg (5.51 lbs)
130A (5sec)
Approx. 19.0 mΩ
349A
Length (L) 150.9±2.0 mm 5.94±0.08 inch
Width (W) 64.8±1.0 mm 2.55±0.04 inch
Container Height (h) 94.3±1.0 mm 3.71±0.04 inch
Overall Height (H) 98.6±1.0 mm 3.88±0.04 inch
13.5 ~ 13.8 VDC/Unit at 25℃ (77℉)
【 Self Discharge
Less than 10% after 90 days, can be stored up to 6 months at 25℃ (77℉);
Fully recharging is required before usage, and charged sooner if stored
BUSINESS HEADQUARTERS
Recognized under UL 1989,
and certified by ISO 9001, 14001.
BEIJING OFFICE (CHINA)
Loading...
