HDL20/32-M-A/E-S
3243 North California Avenue, Chicago, IL 60618
HEADLINER POPCORN MACHINE
SERVICE MANUAL
120/208 - 240 Volt,
Single and Three Phase, 60 Hz
230 Volt,
Single Phase, 50 Hz
400 Volt, 3N~,
Three Phase, 50 Hz
100/200 Volt,
Single Phase, 50 & 60 Hz
READ
instructions before servicing this popcorn machine
Created on 4/28/2000 8:55:00 AM BEGIN SERIAL NO. 00000000
and UNDERSTAND these servicing, and safety
04/00
HDL20/32-A/E-S
SAFETY FIRST
The information in this manual is essential for the safe installation and
maintenance of your Cretors popcorn machine. The manual must be read
and understood before installing, or maintaining this equipment, or
equivalent training must be provided.
"The employer shall instruct each employee in the recognition and avoidance
of unsafe conditions and the regulations applicable to his work environment
to control or eliminate any hazards or other exposure to illness or injury".
Ref.: 29 CFR 1926.20 (b)(4)(a)(2)
It is understood that safety rules within individual companies vary. If a
conflict exists between the safety procedures contained in this manual and
the rules of a using company, the more stringent rule should take precedence.
04/00
BEGIN SERIAL NO. 00000000
HDL20/32-A/E-S
I INTRODUCTION
This manual is filled with time-saving and money-saving information regarding your Cretors
popcorn machine. There is nothing, however, more important than the safety aids and warnings
that are found throughout this document. The Safety Alert Symbol is used to identify topics of
primary safety concern wherever they appear. Furthermore, a separate section has been included
which deals exclusively with operation and accident prevention.
If, after reviewing this manual, anything is unclear or technical problems are encountered, contact
the dealer from whom you purchased your machine for assistance and if there are any additional
questions, feel free to contact our Customer Service Department at the address and/or phone
number listed on the front and back covers of this manual. Always have the model and serial
number of your machine available to assist in obtaining the correct information.
ELECTRICAL SPECIFICATIONS: Headliner Models are available in any of the following
Electrical configurations:
120/208 - 240 Volt, Single, 60 Hz
230 Volt, Single Phase, 50 Hz
400 Volt, 3N~, Three Phase, 50 Hz
100/200 Volt, Single Phase, 50 & 60 Hz
SPECIFICATIONS:
MODEL HDL20CP HEADLINER 20 OZ. ELECTRIC COUNTER MODEL
Capacity: 20 oz. All-Steel Kettle, 400 one-ounce servings per hour
Electrical: 5600 watts,
Dimensions: 28"D x 36"W x 47" H - - - - 71 cm D x 91 cm W x 119 cm H
Net Weight: 250 lbs. (113 kg.)
MODEL HDL32CP HEADLINER 32 OZ. ELECTRIC COUNTER MODEL
Capacity: 32 oz. All-Steel Kettle 640 one-ounce servings per hour
Electrical: 6600 watts
Dimensions: 28"D x 36"W x 47" H - - - - 71 cm D x 91 cm W x 119 cm H
Net Weight: 250 lbs. (113 kg.)
MODEL HDL20FP HEADLINER 20 OZ. ELECTRIC FLOOR MODEL
Capacity: 20 oz. All-Steel Kettle 400 one-ounce servings per hour
Electrical: 5600 watts
Dimensions: 28"D x 36"W x 74"H - - - - 71 cm D x 91 cm W x 188 cm H
Net Weight: 370 lbs. (168 kg.)
MODEL HDL32FP HEADLINER 32 OZ. ELECTRIC FLOOR MODEL
Capacity: 32 oz. All-Steel Kettle 640 one-ounce servings per hour
BEGIN SERIAL NO. 00000000
04/00
HDL20/32-A/E-S
Electrical: 6600 watts
Dimensions: 28"D x 36"W x 74"H - - - - 71 cm D x 91 cm W x 188 cm H
Net Weight: 380 lbs. (168 kg.)
I SAFETY ALERT SYMBOL
The symbol shown below is used to call your attention to instructions concerning your personal
safety and the safety of others. Watch this symbol. It points out important safety precautions. It
means "ATTENTION! Become Alert! Your personal safety is involved!" Read the message that
follows and be alert to the risk of personal injury or death.
III PURPOSE OF MANUAL
This instruction manual is intended to familiarize owners with the servicing
and safety procedures associated with your Cretors popcorn machine.
This manual should be kept available to maintenance personnel.
04/00
BEGIN SERIAL NO. 00000000
HDL20/32-A/E-S
IV INSTALLATION INSTRUCTIONS
1. Location
Choose a location for your Cretors popcorn machine to maximize the ease of operation and
maintenance procedures. Check your local building and fire codes for location restrictions.
2. Power Supply
A. Check the nameplate to determine the required power supply.
Connect your popcorn popper only to the correct power source. Failure to do so may
result in personal injury or death and may damage your popper.
B. C. Cretors and Company recommends dedicated circuits for the Headliner model
popcorn machine. The Headliner model poppers require a dedicated circuit to avoid
voltage drop in the supply wiring. Check your local electrical codes regarding fuse or
circuit breaker requirements.
Make certain your popcorn machine is properly grounded. Failure to do so may result
in damage to your equipment or present a shock hazard.
3. Connecting Machine to Power Supply
A. Make certain that power supply circuit breakers are in the ‘OFF’ position.
B. Push the plug completely into the receptacle. If the cord has a twist lock plug be sure to
turn to lock in position.
C. If the supply cord is damaged, it must be replaced by Cretors’, or by a Cretors’ approved
service agent, or a similarly qualified person in order to avoid a hazard.
4. Pump Installation
Refer to the Service Manual supplied with the pump to be installed in the machine.
5. Counter Model Installation
The Counter Model Headliners have 4” legs which must be attached at the time of
installation. The legs are required to comply with Sanitation Standards.
A person who has not read and understood all service and safety instructions
is not qualified to service the machine.
04/00
BEGIN SERIAL NO. 00000000
HDL20/32-A/E-S
V SERVICE INSTRUCTIONS
In the case of improper operation, qualified personnel only should perform the
following diagnostic checks, and, if necessary, corresponding adjustments and repairs.
Many of the following procedures present an electrical shock hazard and can cause
serious injury or death.
A. Perform work only on de-energized circuits. Failure to do so may lead to electrical
shock resulting in personal injury or death.
1. Parts
When ordering parts, refer to the attached parts diagram. Always supply the serial number,
model number, and voltage of your popcorn machine.
If the supply cord is damaged, it must be replaced by Cretors’, or by a Cretors’ approved
service agent, or a similarly qualified person in order to avoid a hazard.
2. Kettle Temperature Control
THERMOSTAT OPERATION
A. The thermostat is installed as a safety device to prevent overheating of the kettle if the
machine should be left unattended momentarily while in operation. The operation of
the thermostat is indicated by the kettle indicator light which is located in the ceiling of
the cabinet. The indicator light should stay on for most of the popping cycle. The
indicator light should go off 10-20 seconds before the corn finishes popping and the
kettle is dumped. If the indicator light goes out 30 seconds or more before the corn
finishes popping, the thermostat may be too low and be in need of adjustment.
CAUTION If the corn has dried out, it may not finish popping at normal
temperatures and the light may appear to go out early. DO NOT ADJUST KETTLE
TEMPERATURE BASED ON POOR QUALITY CORN.
B. If set too high (over 500°F 260
o
C), the thermostat can cause a serious fire hazard.
C. Repair part thermostats shipped from the factory have been factory adjusted to
switch off the current to the heating elements when the kettle temperature reaches
410° F (210
thermostat must be checked after installation to confirm correct operation. To adjust
the thermostat, perform the following operations:
04/00
o
C). The factory setting should prove satisfactory; however, each
BEGIN SERIAL NO. 00000000
HDL20/32-A/E-S
THERMOSTAT ADJUSTMENT
A. Locate the plugged thermostat adjustment hole on the side of the kettle retainer and
remove the plug.
B. Turn on the kettle heat.
C. Locate pyrometer over thermostat.
D. Set temperature so that the power to heat elements is cut off at the correct temperature.
KETTLE
20 OZ. 420º F. (215º C) 385º F. (193º C)
32 OZ. 420º F. (215º C) 385º F. (193º C)
E. To adjust thermostat, insert a flat blade screwdriver into the slotted adjustment screw
and turn COUNTER - CLOCKWISE to raise the temperature or CLOCKWISE to lower
the temperature.
F. Do not adjust more than one-quarter turn at a time. One full turn of the adjustment
screw equals approximately 110° (43
G. Do not screw the adjusting screw all the way in or out! This will render the
thermostat inoperable and the kettle heat will increase to a dangerous level and
could possibly cause a "flash fire" if oil is put into the pan.
H. If no pyrometer is available, the thermostat may be adjusted by observing the operation
of the indicator light as described in the Thermostat Operation section. Adjust the
thermostat so that the kettle heat is turned off 10 to 20 seconds before the corn finishes
popping and the kettle is dumped
CAUTIONIf the corn has dried out, it may not finish popping at normal temperature,
and the light may appear to go out early. DO NOT ADJUST KETTLE TEMPERATURE
BASED ON POOR QUALITY CORN.
CAUTION Do not adjust the temperature so high that the pan smokes at the end of
the popping cycle. If set too high (over 500°F or 260oC), the kettle can become a
serious fire hazard.
I. Your final setting should allow the indicator light to cycle off 10 to 20 seconds prior to
dumping the kettle.
J. Observe two or three cycles of correct operation to be certain everything is working
correctly.
SALTED CORN SUGAR CORN
o
C) Fahrenheit.
04/00
BEGIN SERIAL NO. 00000000
