Condensing
Tumble Dryer
Instruction Book
You must read these instructions prior to using the
appliance and retain them for future reference.
Contents
Safety Advice 3-4
Electrical Requirements 5
Features - Get to know the main parts of your Dryer 6
Where to put your Dryer 7
How to use your Dryer 8
The Controls 9-11
Sorting your laundry 12
Wash Care Labels 13
Items requiring special attention 14
Emptying you Water Container 15
Speedy Iron Programme 16
Guide to Drying Times 17
Caring for your Dryer 18
If something goes wrong 20
Key Contacts Back Cover
Retention of this Instruction Book
This Instruction Book must be kept handy for reference as it contains important details on
the safe and proper use of the appliance.
If you sell or pass the appliance to someone else, or move house and leave it behind, make
sure this Book is also provided so the new owner can become familiar with the appliance
and safety warnings.
2
For your safety
IMPORTANT
Using your Tumble Dryer is easy.
Nevertheless, for your own safety and to get the best results it is important to know your
Dryer by reading right through this handbook before using your dryer for the first time.
NEVER ● Allow children to play with or otherwise interfere with the dryer.
NEVER ● Allow the air inlet at the front of the dryer or the air outlet at the back
to be obstructed.
NEVER ● Switch the machine off leaving a hot load in the drum.
NEVER ● Tumble dry without the Filter, Water Container or Condenser in
position.
NEVER ● Exceed the maximum load capacity recommended or place
dripping wet items in the drum.
NEVER ● Allow lint to collect around the dryer.
NEVER ● Add liquid fabric conditioner to the dryer, use liquid conditioner in the
final rinse of your wash.
NEVER ● Use the dryer for commercial drying, the dryer is only suitable for
domestic use.
NEVER ● Dry Acrylics or synthetics on the high heat setting.
NEVER ● Tumble dry articles that have NOT been well washed in water and
detergent then well rinsed and spun.
NEVER ● Tumble dry articles that have had chemicals used for cleaning.
NEVER ● Dry articles that are contaminated with flammable substances such
as: petrol, oil, paint, hair lacquer, creams, cooking fat or oil.
NEVER ● Tumble dry: rubber, foam rubber, plastic, plastic foam, nappy pants
or liners, polythene or paper.
Large, very bulky items including duvets and sleeping bags.
NEVER ● Attempt to stand on top of your dryer, it is not designed for
such use and you could injure yourself or damage the dryer by such
abuse.
NEVER ● Switch electricity On or Off with wet hands.
IMPORTANT
A CHILD COULD CLIMB INTO OR TAMPER WITH AN UNATTENDED
TUMBLE DRYER.
WHEN THE MACHINE IS NOT IN USE SWITCH OFF, REMOVE THE PLUG
AND CLOSE THE DOOR.
3
For your safety
ALWAYS ● Empty the Water Container after EACH drying cycle.
ALWAYS ● Finish every programme with the cool tumble cycle provided on
the control.
ALWAYS ● Clean the filter, it is essential that the filter is kept clear of fluff
after EACH drying cycle.
ALWAYS ● Ensure Condenser is free of fluff, regular cleaning is recommended.
ALWAYS ● When the dryer is not in use, switch off, remove plug and close the
door.
ALWAYS ● Comply with the specified electrical requirements.
ALWAYS ● Ensure that your dryer is installed correctly and has adequate
ventilation. (see, "Where to put your dryer.")
ALWAYS ● Observe the rules for drying garments:
In particular woollen articles should not be dried in a
tumble dryer unless they are labelled ‘Superwash’,
‘Machine washable’ or have the ‘May be tumble dried’
symbol:
If in any doubt do not dry wool in the machine.
Unlike other materials, the mechanism of wool
shrinkage is irreversible, i.e. it will not stretch back to
the original size and shape.
ALWAYS ● Buy genuine accessories and spares.
CAUTION:
When the dryer is in use avoid touching the
rear of the dryer as it may be hot!
4
Electrical Requirements
WARNING: This appliance must be earthed!
Supply
Changing
the fuse
Moulded plug
Changing
the plug
Rewirable plug
GREEN &
YELLOW TO
EARTH
BLUE TO
CORD
NEUTRAL
CLAMP
REFER TO THE RATING PLATE FOR VOLTAGE AND CURRENT
REQUIREMENTS. (see diagram for location.)
The flexible mains lead is supplied fitted with a BS1363 plug and
with a 13 amp BS1362 fuse.
The plug should be connected to the mains supply via a suitable
switched socket which is accessible after installing your dryer.
If it is necessary to fit a replacement fuse, it must be a 13 amp
ASTA approved to BS1362 type.
WARNING: The plug must not be used without a fuse cover.
If a replacement fuse holder/cover is required, it must be of the
same colour coding or wording as shown on the base of the plug.
Replacements are available from your Spares stockist.
The wires in the mains lead are coloured in accordance with the
following:
GREEN/YELLOW - EARTH
BLUE - NEUTRAL
BROWN - LIVE
If a replacement plug is to be fitted, the appropriate wire must be
connected to the correct terminal,as follows:
Connect:
Green/Yellow to terminal marked Earth or Green or
Blue to terminal marked Neutral or N or Black
Brown to terminal marked Live or L or Red.
13 AMP
FUSE
If the plug being replaced is a non-rewirable type then the cut-off
BROWN
plug must be disposed of safely. DO NOT leave where it can be
TO LIVE
inserted into a socket and create a shock hazard.
Changing the
mains cable
Should the mains lead ever require replacing at any time please
contact your nearest Service Centre. A charge will be made for the
replacement of the mains lead or if you require a longer lead.
The mains lead must only be replaced by a specially prepared
cable obtainable from your Spares Stockist and fitted by a
qualified electrician.
NOTE: IF IN DOUBT ABOUT ANY OF THE ABOVE CONSULT A
QUALIFIED ELECTRICIAN.
5
Features - Get to know the main parts of your dryer
see "The Controls"
Plinth Moulding
(Not fitted to all models)
Fluff filter
CLEAN AFTER
EACH LOAD
Push here to
open door
Air intake
grille
Serial & Model
numbers
NOTE: If your
dryer is new wipe
out the inside of
the drum before
you first use it
to remove any
dust which may
have accumulated
during transit.
Rating Plate
Door
catch
Door latch
6
Condenser
(Keep clear of fluff)
Clean periodically
Water Container
(Empty after Each Load)
Where to put your dryer
Your Tumble Dryer should NOT be located adjacent to a gas hob,
cooker, heater or eye level grill as flames from the burners could
cause damage to your machine.. When the dryer is fitted under a
work surface, allow space for air to exit the rear grille, a 15mm gap
each side of the dryer is recommended. This airflow is essential to
condense the water produced drying the washing, the dryer will not
operate efficiently in an enclosed space or cupboard.
If using your dryer in a small or cold room some condensation could
be experienced.
If you are using this dryer adjacent or stacked on top of a washing
machine SEPARATE mains plugs and sockets must be used for each
appliance. DO NOT use 2-way adaptors or extension leads.
Stack it on your
Washing Machine
DOOR
LATCH
Both your tumble dryer and front loading washing machine are similar in design allowing the tumble dryer to be permanently stacked on
top saving you valuable floor space. A special stacking kit complete
with instructions is available from your retailer or nearest Spares
Centre.
IMPORTANT
Only use genuine stacking kits. When ordering you must state
the model numbers of both your Washing Machine and your
Tumble Dryer. Unsuitable kits may result in a potential hazard
and will invalidate your warranty rights.
HINGE
DOOR
CATCH
Door Reversal
Instructions
HINGE
The door of your Dryer is reversible and can easily be changed .
Exchange diagonally hinge brackets and blanking plugs. Exchange
door latch and catch with their opposite blanking plates. See diagram
above.
7
How to use your dryer
1. Plug in, switch
on electricity.
3. Open the door
by pressing and
releasing the front
panel in the position
shown.
5. Load the dryer
placing the
clothes carefully in
the drum pushing
them well towards
the back and
away from the
door seal. Close
the door.
WARNING: WHEN
SWITCHING ON
OR OFF, PLEASE
ENSURE THAT
YOUR HANDS
ARE DRY
2. Sort your laundry
(see section “Sorting
Your Laundry”)
4. Always check
the following:
6. Select the relevant heat setting
(see section “The
Controls”)
FLUFF FILTER
is clean and in place
WATER CONTAINER
is empty and in place
CONDENSER
is clean and in place
7. Select the
required programme
or drying time. (see
section “The
Controls”)
8. Press the
START switch to
commence the drying programme.
The ‘Cool Tumble’
phase
8
9. When finished
open the door and
take out the laundry. Clean and
replace the fluff filter, and empty the
water container.
About 10 minutes before the programme is completed, the heating
elements will be switched off and the programme enters the final
‘Cool Tumble’ phase. During this phase the fabric is cooled. You
should always allow the dryer to complete this phase.
By opening the door you can check the dryness of the load as often
as you wish and if you want to remove some items before they are
fully dry. (This is particularly useful for a mixed load where you want
to iron some items, but others are to be fully dried.) You will need
to press the start button after closing the door to re-start the
programme. See section ‘The Controls’.
10.Switch off electricity and remove
plug from socket.
WARNING: WHEN
SWITCHING ON
OR OFF, PLEASE
ENSURE THAT
YOUR HANDS
ARE DRY
The Controls - Timed Dry Models
Heat Switch (OUT low heat, IN high heat) Empty Water Light
Start Switch
Setting the Timer
Starting the Dryer
Speedy Iron Cycle
Turn the Timer clockwise to select the required drying time.
The drying time for both heat settings is controlled by the timer. All you
have to do is turn the Timer Control clockwise until the required time
appears in line with the indicator. If you have selected more time than
you require turn the knob clockwise to select the correct time required.
Never wind the timer control anti-clockwise.
The "Guide to Drying Times" section will tell you how much time you
will need for various loads.
THE START BUTTON MUST BE PRESSED TO START ALL
PROGRAMMES.
Press and release the START Drying button to commence a drying
programme. The door must have been securely closed first.
After releasing the start button, it will return to its original position.
NOTE: If the door is opened during a programme, the Dryer
will automatically stop. To continue the programme after
closing the door, the START button must be pressed again.
This is a short programme of approximately 10 minutes to condition
previously dried clothes. See section, "Speedy Iron Programme".
It consists of a period of heating followed by a short cool tumble
period. Select HIGH heat for this programme.
It should not be used on damp loads, as it is NOT a drying
programme.
Selecting the
required Heat
Switch setting
Empty Water Light
To select HIGH heat (Cottons), the Heat Switch must be IN.
To select LOW heat (Acrylics and Synthetics), the Heat Switch must
be OUT. See section, "Guide to Drying Times".
This light will glow when the water container is full.
You should not wait for this light to glow before emptying the
container, but empty it after each load (See section “Emptying the
Water Container”).
NOTE: If the light glows during a programme you must stop the dryer
and empty the water container. If this is not done the timer will advance
to the Cool Tumble phase without drying the load.
The light will take approximately 10 seconds to go out after replacing
the empty container.
9
The Controls - Excel Sensor Dry Models
Heat Switch (OUT low heat, IN high heat) Active / Empty Water Light
Start Switch
Selecting a
programme
Programme
options
Turn the knob in either direction to select the required programme,
until the required selection appears in line with the indicator.
NOTE: The timer knob does NOT move during the programme.
THE START BUTTON MUST BE PRESSED TO START ALL
PROGRAMMES INCLUDING A DELAYED START (DRY LATER)
●
Sensor Drying with delayed start (Dry Later) selected in steps of 1
hour (The knob remains on the Selected position during the
delay and drying sections of the programme, it does not count
down).
●
S-Sensor Drying (Dry Now).
●
Timed drying (30 minutes) for small loads.
●
Speedy Iron programme.
PROGRAMME (Green Light will illuminate).
Selecting the
required heat
switch settings
(i) Sensor Drying
(Dry now)
(ii) Delayed Start
Sensor Drying
(Dry Later)
10
To select HIGH heat (Cottons), the Heat Switch must be IN.
To select LOW heat (Acrylics and Synthetics), the Heat Switch must
be OUT. See section, "Guide to Drying Times".
The Sensor Drying programme will automatically dry most loads to the
dry condition. This eliminates the need to guess the drying times and
saves energy. To select Sensor, turn the knob to position ‘S’. When
the load is dry, the dryer will automatically complete the 10-minute cool
tumble phase.
NOTE:
●
Small loads (less than 1kg) must be dried using Timed drying
programme.
When using a Delay Start Sensor Drying programme, select the
programme with the required number of hours delay. The time set is
the delay before the drying programme is required to start (Maximum
8 hours).
NOTE:
●
The drying programme will start when the delay time selected
has elapsed, but the knob will not move from the position you
set.
●
Ensure that the door is closed and the start button has been
pressed after setting the required delay start programme.
●
If you open the door after pressing the Start button, ie. to add
articles, remember to press the Start button again.
The Controls - Excel Sensor Dry Models (continued)
THE START BUTTON MUST BE PRESSED TO START ALL
PROGRAMMES INCLUDING A DELAYED START (DRY LATER)
(iii) Timed Drying
(iv) Speedy Iron
Cycle
Starting a
Programme
(Green Active
light)
Empty Water light
A short programme of around 30 minutes is provided to dry small loads
of less than 1kg.
To select this programme, turn the knob clockwise until 30 min
appears in line with the indicator. About 10 minutes before the programme is completed, the heating elements are switched off and the
programme enters the final ‘Cool Tumble’ phase.
This is a short programme of approximately 10 minutes to condition
previously dried clothes. See section ‘Speedy Iron Programme’.
It consists of a period of heating followed by a short cool tumble
period (as detailed below).
Select High heat for this programme.
It should not be used on damp loads, as it is NOT a drying
programme.
Press the Start button and the indicator light turns Green to show that
the programme is active. The light goes out when the selector is
returned to position ‘0’, or if the door is opened during the
programme’s duration.
CAUTION:
If the door is opened during the cycle, the dryer stops automatically.
When the door is closed the Start button must be pressed to restart the
programme. The light flashes green to remind you to press the Start
button. The cycle resumes from the point it stopped, if the position of
the knob has not been changed. Otherwise, the dryer starts the new
selection.
The indicator light turns Orange during a drying programme when the
water container is full. When this happens, you must empty the water
container. You should not wait for this light to change colour before
emptying the container, but empty it after each load (see section
‘Emptying the Water Container’).
The programme goes directly to the cool tumble phase and the dryer
stops. The Orange light warns you that the load will not be dried
correctly.
At the end of a drying programme if the container has filled the
indicator light will glow Red. Empty the water container and start the
programme again by pressing the Start button.
The indicator light goes off (or turns Green if a programme is running)
about 10 seconds after the water container has been put back.
The ‘Cool Tumble’
phase
About 10 minutes before the programme is completed, the heating
elements will be switched off, the programme enters the final ‘Cool
Tumble’ phase. During this period, the fabric is cooled. You should
always allow the dryer to complete this phase. By opening the door,
you can check the dryness of the load as often as you wish and if you
want to, remove some items before they are fully dry. (This is
particularly useful for a mixed load when you want to iron some items,
but others to be fully dried). You will need to press the Start button
after closing the door to re-start the programme.
11
Sorting your laundry
1. Always separate laundry into the correct fabric groups before
washing and drying.
2. See that all zips are closed, hooks and eyes are fastened and
belt, strings etc. are tied loosely in bows, you will normally have
done this for each item before the washing stage.
3. It is important to extract as much water as possible from each
item before drying. This saves you time and money.
WARNING: CLOTHES SHOULD NEVER BE LOADED
DRIPPING WET
4. Make sure that the items to be dried are suitable for tumble
drying, or are not of a type requiring ‘special attention’ (see“Wash
Care Labels” section).
Maximum
load size
Typical load
Your dryer will hold a load of 6kg (13lb) dry weight of natural fabrics.
if you are drying items of man-made fibres (synthetic or acrylics), the
maximum load should not exceed 3kg (6.6lb) dry weight.
This difference is that man-made fibres require more space to tumbledry without creasing.
WARNING: DO NOT OVERLOAD AS THIS COULD RESULT IN
REDUCED DRYING PERFORMANCE AND A POSSIBLE FIRE
HAZARD.
To help you estimate how many items it takes to make up a drying
load, the charts below show the approximate weights of some everyday washing items.
Clothes
Blouse Cotton 150g 5oz
Other 100g 3
Dress Cotton 500g 1lb 2oz
Other 350g 12oz
Jeans 700g 1lb 6oz
10 Nappies 1000g 2lb 3oz
Shirt Cotton 300g 10
Other 200g 7oz
T-Shirt 125g 4
1
/2oz
1
/2oz
1
/2oz
Household Items
Duvet cover Cotton 1500g 3lb 5oz
(Double)
Large Tablecloth 700g 1lb 6oz
Small Tablecloth 250g 9oz
Tea Towel 100g 3
Bath Towel 700g 1lb 8oz
Hand Towel 350g 12oz
Double Sheet 500g 1lb 2oz
Single Sheet 350g 12oz
Other 1000g 2lb 3oz
1
/2oz
If you group small cotton or terry-towelling items with a synthetic
fabric load they could be damp at the end of the drying cycle. If this
happens simply give them an additional short period of drying to
finish them off.
12
Wash Care Labels
Most of today’s fabrics can be tumble dried in your Dryer with no
trouble at all, but there are certain fabric finishes which should be
dried away from direct heat.
The majority of garments now have wash-care labels on them, giving
full washing and drying instructions. These should always be
followed carefully especially when you are drying something for the
first time.
Typical symbols are:
May be tumble dried
Do not tumble dry
Or:
Tumble dry at high heat setting
Tumble dry at low heat setting
Items not suitable for tumble drying
• Those containing foam rubber or rubber-like materials or plastic
film (e.g. pillows, cushions, PVC rainwear), or any other articles
which are inflammable or contain inflammable substances (e.g.
towels contaminated with hair lacquer
• Fibreglass (e.g. some types of curtains)
• Items which have been dry cleaned
• Woollens. Woollen items need as much care in drying as they do
in washing. The movement of the tumble-drying action causes the
woollen fibre to shrink and distort.
• Garments with the ITCL Code (see ‘Items Requiring Special
Attention’).
Do not tumble dry.
• Large bulky items e.g. continental quilts, sleeping bags, pillows,
cushions, double blankets and large bedspreads. These expand
when drying and would prevent airflow through the Dryer.
WARNING: THE DRYER IS INTENDED FOR USE ONLY
WHERE WATER SOLUTION IS USED FOR THE CLEANING
PROCESS. MISUSE OF A TUMBLE DRYER MAY CREATE A
FIRE HAZARD.
13
Items requiring special attention
Blankets and
Bedspreads
Permanently
pleated or creased
garments
Starched articles
Fabric conditioner
The drying requirements of blankets and bedspreads will, of course,
vary tremendously according to size and weight. Some, however are
simply too big. if you have difficulty getting them into the Dryer, the
machine will have difficulty drying them properly. Blankets (and
Garments) made from Acrylic fibres (e.g. Acilan, Courtelle, Orion and
Dralon) must be dried with special care on Low heat setting.
Overdrying should be avoided to ensure heat creasing does not
occur.
Your dryer will cope with such clothes very well, but you should
always read the manufacturer’s drying instructions attached to the
garment before you begin.
Starched articles should be dried together in the same load to avoid
the distribution of starch to non-starched items. You should use a
slightly heavier starch solution than you would when drying the items
on the washing line. Make sure that as much of the solution is
removed from the load as possible before placing it in the Dryer.
Remove the items from the dryer as soon as they reach ironing
dampness. If they are overdried the starch will powder, leaving the
fabric limp - which rather defeats the purpose of the exercise!
To make sure all your tumble dried clothes come out really fresh and
soft we recommend you use a liquid fabric conditioner in the final
rinse of your wash. A liquid fabric conditioner restores bounce and
softness and helps eliminate static cling.
Home Dry Cleaning
14
WARNING: ON NO ACCOUNT SHOULD LIQUID FABRIC
CONDITIONER BE ADDED TO THE DRYER ITSELF.
Garments with the ITCL Code may be cleaned using one of the
Home Dry Cleaning Kits available.
The instructions supplied with the Home Dry Cleaning Kit must be
strictly followed.
Emptying the Water Container
Water
Container
Water
Container
Plinth
Moulding
(not fitted to
all models)
To Empty Water
Container
Sink
Empty the water container after EVERY programme.
Failure to do this will result in the water container
becoming full and the load will not dry.
Remove plinth (where fitted) by slightly lifting and sliding to the left.
Pull the container out of the dryer and empty it into a sink (or other
suitable drain).
If your dryer is stacked on top of a Washing Machine, the Tumble
Dryer can be plumbed into the drain by attaching a suitable tube to the
stub at the rear of the dryer, after removing the blanking cap. When
plumbed into a drain the water container does not need to be emptied.
15
Speedy Iron Programme
‘Speedy Iron’ provides a short programme consisting of
approximately 7.5 minutes of heat with an approximately 2.5 minutes
cool tumble period. It is a short conditioning programme that softens
the fibres allowing them to relax making handling and ironing easier
and less time consuming.
When to use
‘Speedy Iron’
Important!
However garments are dried, outside on the line, inside on a radiator,
hung around the home or using a tumble dryer, once dry they usually
get left in the same position/place for a long period of time. This tends
to cause garment fibre stiffness which can make the handling of
garments difficult and therefore the ironing time longer. Garments
dried in any of the ways described above and left will benefit from the
‘Speedy Iron’ programme.
● The ‘Speedy Iron’ cycle is not a drying programme. It has been
designed to condition/soften garments that have already been
dried and left unattended in this state for a period of time.
● All materials do not behave in exactly the same way when heated.
For instance, our testing has shown that materials such as
Tencel® and Acrylics are not relaxed quite as effectively by
applying the ‘Speedy Iron’ cycle as we found on the more
traditional Cottons and Polycottons.
● To obtain the best results from ‘Speedy Iron’ it is important that the
weights recommended below are not exceeded and HIGH heat is
selected. (Heat switch IN).
● For best results We recommend garments should be
removed from the dryer immediately after the ‘Speedy Iron’
programme to be hung, folded neatly or ironed.
When this is not possible the ‘Speedy Iron’ programme
should be repeated.
Recommended weights and materials
Material Maximum load
Cotton and Cotton mixtures 2.5kg
Synthetics
Denim
2kg
2kg
5.5lb
4.4lb
4.4lb
16
Guide to drying times
Please note that the drying times stated below and on appliance
control panel; are a GUIDE only and drying times are affected by:-
The amount of
water remaining
in the clothes
after spinning
The type of
fabric
The quantity of
clothes to be
dried
How dry you
want the
clothes
The heat setting
you have
selected
The temperature
of the room
Bulky items
Items such as towelling retain a lot of water after spinning, also the
suggested wash programme for small items such as T-Shirts may
sometimes incorporate a low spin speed which has the same effect.
Your drying load may contain the same type of fabric but of different
thicknesses. Thinner items will take less time to dry. Some fabrics,
such as those used for jeans are of closer texture than others and
although light when dry will be heavy after washing and spinning.
Single items of clothes or small loads may take disproportionally
longer to dry. It is more energy efficient to dry larger loads.
As it takes longer to fully dry clothes than to have them ready for
ironing, you may wish to remove some clothes when they are slightly
damp, ready for ironing and then continue to dry the remainder until
they are fully dry.
The label on the garment should tell you the correct heat setting to
select. See ‘Wash Care Labels’.
If the room in which the dryer is situated is cold, your clothes will take
longer to dry than if the room is warm.
Some bulky items such as padded jackets can be dried, with care,
and we do advise that you remove these items several times, shake
them and return them to the dryer.
THERE ARE HOWEVER SOME ITEMS THAT WE DO NOT ADVISE
YOU TO DRY. SEE ‘ITEMS NOT SUITABLE FOR TUMBLE DRYING’
ying Guide - approximate drying time in minutes (weights specified are when dry)
Dr
COTTONS SYNTHETICS ACRYLICS
Drying times 800 - 1000rpm in
washing machine
Half
load
1 kg
30 - 40
2 kg
40 - 55
3 kg
55 - 70
Be careful not
to overdry
load
4 kg
70 - 80
5 kg
80 - 90
6 kg
95 - 120
All fabrics contain a little natural moisture even when ‘dry’ and this natural moisture should not be lost if the clothes are to remain soft and
Drying times on reduced
spin in washing machine
Full
1 kg
40 - 50
Half
load
2 kg
50 - 70
Full
load
3 kg
70 - 90
Drying times on
reduced spin in
washing machine
Half
load
1 kg
40 - 60
55 - 75
fluffy.
Clothes that are dried for too long tend to wrinkle and will need more
ironing than usual, giving you extra work that the Dryer was designed
to remove.
Full
load
2 kg
17
Caring for your Dryer
Your Tumble Dryer needs very little attention. The following simple
steps will keep it performing well.
When finished
Switch off electricity and remove plug. Ensure hands are dry.
After each load
Every Week
Every Month
Automatic
Dryers only
Always clean the filter, by rinsing under the tap or using a vacuum
cleaner. Turn the dryer by hand to check that small items like handkerchiefs do not get missed.
Wipe the drum and seal with a damp cloth.
Fluff filter
(Automatic Dryers only)
Condenser
Remove condenser unit and clean any build up of fluff from between
the plates by rinsing it under the tap with cold water. This should be
done with cold water from the rear of the condenser. Refit with the
handle at the front.
Occasionally clean the surface of the stainless steel sensor inside the
drum with vinegar to remove water contaminates. Apply carefully with
a cloth this will maintain the drying performance of the dryer. The
sensor is located between the vanes of the drum towards the front of
the dryer, rotate the drum if necessary to locate it.
Sensor
Ta p
Rear
Front
Cleaning
Do not use
Lubrication
18
Every 6 months vacuum the front air intake grille and Vents at the rear
of the dryer, to remove the build up of fluff, lint or dust.
To remove accumulation of fluff from the door, front of condenser and
filter areas, clean occasionally with a vacuum cleaner.
Abrasive cleaners, scouring agents, acids, chlorine bleach or metal
polish to clean any part of the machine.
Your tumble dryer uses special bearing components. Lubrication by
the user is not necessary and must not be attempted.
We strongly recommend that all appliances are regularly checked for
electrical and mechanical safety.
Spare parts
Please remember your new appliance is a complex piece of
equipment.
‘DIY” repairs or unqualified and untrained service people may put
you in danger, could damage the appliance, and might mean you
lose cover under the Parts Guarantee.
If you do experience a problem with the appliance don’t take risks,
call in our Service Engineer. Our Spare Parts are designed
exclusively to fit your appliance. Do not use them for any other
purpose as you may create a safety hazard.
Disposal of your product
To minimise the risk of injury to children please dispose of your
product carefully and safely.
Remove all doors and lids. Remove the mains cable (where fitted)
by cutting off flush with the appliance and always ensure that no
plug is left in a condition where it could be connected to the
electricity supply.
To help the environment Local Authority instructions should be
followed for the disposal of your product.
This appliance conforms to the following EEC Directives.
Low Voltage Equipment
72/23/EEC
93/68/EEC
Electromagnetic Compatability
89/336/EEC
92/31/EEC
93/68/EEC
19
If something goes wrong
First, don’t panic! There may be nothing wrong at all. Look for your
problem below, then check the things we suggest. More often than
not, this will give you the answer to your problem, and you’ll be able
to carry on without having to telephone your Service Office.
If after this you still cannot get your machine to work, follow the
advice given on the next page.
Problem
‘It won’t start’
‘It is taking a long
time to dry’
Sensor Dry
Programmes
(Excel Models
only)
Check these things first
1. Is the machine plugged in and switched on at the socket?
2. Is the Timer Control set to required time or programme?
3. Is the door securely closed?
4. Has the start button been pressed hard enough? Try pressing the
start button again.
5. Has the fuse blown? (Try plugging in another appliance to check)
6. Have you used an extension lead? Many are not suitable. Try
plugging the dryer directly into a socket to check.
7. Has a delayed start been selected? (Not all models).
1. Have you forgotten to clean the filter? It should be cleaned after
each load.
2. Does the water container need emptying? Is the empty water light
glowing? (Orange or Red on Excel model)
The water container should be emptied after every load.
3. Does the condenser need cleaning? It should be cleaned every
month.
4. Have you selected the correct Heat setting for the type of fabric
you are drying? (IN for High, OUT for low).
5. Have the air intake grille or rear vents of the dryer been
obstructed?
6. Were the clothes ‘excessively wet’ when they were put in?
7. Was the correct time selected?
8. Have you overloaded the dryer?
1. Has the correct programme been selected for the load?
Loads above 1kg - S (Sensor Dry)
Loads less than 1kg use timed dry programme.
Any other
problem
20
2. The indicator light flashed Green? This is a reminder to press the
Start button.
3. The knob does not move/time down during a time delay
programme? This is normal for all programmes, the knob can
only move if you turn it by hand.
Have you re-read this instruction book?
Key Contacts
Service
Creda has the largest appliance manufacturer’s service team in Europe,
trained specialists directly employed by us to ensure your complete
confidence.
Repair Service
UK: 08709 066 066
Republic of Ireland: 1850 302 200
You will be asked for the following information:-
Name, address and postcode.
Telephone number
Model / Serial number of the appliance
Clear and concise details of the query or fault
Place and Date of purchase
(Please keep the receipt as evidence will be required when the engineer calls).
Extended Warranty
To join: UK 08709 088 088
Republic of Ireland: 1850 502 200
Genuine Parts & Accessories
Mail Order Hotline
UK: 08709 077 077
Republic of Ireland: (01) 842 6836
For further product information
All Creda Services are offered as an extra benefit and do not affect your statutory rights.
General Domestic Appliances Limited, Morley Way, Peterborough, PE2 9JB
PRINTED BY SIMLEX.FOUR ASHES,WOLVERHAMPTON. May 2002 Part No.0766200075-01
08701 50 60 70
Loading...
