Tumble Dryer

Instruction Book

TCS3

You must read these instructions prior to using the appliance and retain them for future reference

Instruction booklet

TUMBLE DRYER

Contents

GB



Installation, 2

Door reversal instructions

Where to put your dryer

Ventilation

Water drain

Electrical connection

Before you start using your dryer

Dryer description, 3

The front

The back

Control panel

Start and programmes, 4

Choosing a programme

Laundry, 5-6

Sorting your laundry

Wash care labels

Special clothing items

Drying times

Warnings and Suggestions, 7

General safety

Disposal

Saving energy and respecting the environment

Maintenance and Care, 8

Switching off the electricity

Cleaning the filter after each cycle

Empty the water container after each cycle

Check the drum after each cycle

Cleaning the condenser unit

Cleaning the dryer

Troubleshooting, 9

Service, 10

Spare parts

1

Installation

GB

! Keep this instruction booklet on hand in order to refer to it when necessary. Take it with you when you move, and should you sell this appliance or pass it on to another party, make sure that this booklet is supplied along with the dryer so that the new owner may be informed about warnings and suggestions on how the dryer works.

! Read these instructions carefully; the following pages contain important information on installation and suggestions on how the appliance works.

Door Reversal Instructions





Hinge



Door catch















Door latch











































Hinge

The door of your dryer is reversible and can easily be changed. Exchange diagonally hinge brackets and blanking screws. Exchange door latch and catch with their opposite blanking plates (see diagram above).

Where to put your dryer

Place your dryer at a distance from gas ranges, stoves, heaters, or cook tops because flames can damage the appliance.

If you are going to install the appliance under a work counter, be sure to leave a 10mm space between the top and any other objects on or above the machine and a 15mm space between the sides and lateral furnishings or walls. This is to ensure proper air circulation. Make sure that the back vents are not obstructed.

Ventilation

When the dryer is in use, there has to be adequate ventilation. Make sure you put your dryer in an environment that is not damp and has proper air circulation throughout. Airflow around the dryer is essential to condense the water produced during the washing, the dryer will not operate efficiently in an enclosed space or cupboard.

! If using the dryer in a small or cold room some condensation could be experienced.

Water drain

If your dryer is installed next to a drain the water can be plumbed into this drain. This does away with the need to empty the water container. Simply remove the top hose from its top fitting at the rear of the dryer and plumb the hose provided to the drain.

Electrical connections

Make sure of the following before you insert the plug into the the electrical socket:

The socket must be grounded.

The socket must be able to sustain the machines maximum power, which is indicated on the rating label (see Dryer Description).

Power voltage must be within the values indicated on the rating label (see Dryer Description).

The socket must be compatible with the dryers plug.

Should this not be the case, replace the plug or the socket.

!The dryer must not be installed outdoors, even if the space is sheltered. It can be very dangerous if it is exposed to rain or storms.

!Once installed, the dryers electrical wire and plug must be within easy reach.

!Do not use extension cords.

!The power cord must not be bent or squashed.

!The power cord supplied is fitted with a BS1363 plug and a 13 amp BS1362 fuse. If you need to replace the fuse, use only those rated at 13 amp (13A) and ASTA approved to BS1362.

Moulded plug

! The plug must not be used without the fuse cover in place.

If a replacement fuse holder/cover is required, it must be of the same colour coding or wording as shown on the base of the plug.

Replacements are available from authorised dealers.

Changing the plug

The wires in the power cord are coloured in accordance with the following:

Green and Yellow (Earth) wire to terminal

marked ‘E’, symbol









,









or coloured green and



13A ASTA approved

yellow.















fuse to BS1362.

Blue (Neutral) wire to





terminal marked ‘N’ or



Brown (Live) wire to

coloured black.



terminal marked ‘L’ or

Cord clamp



coloured red.









!If the plug being replaced is a non-rewirabletype, then thecut-offplug must be disposed of safely. DO NOT leave it where it can be inserted into a socket and create a shock hazard.

!The power supply cord should be checked periodically and replaced by a cord specially prepared for this dryer and fitted only by authorised technicians (see Service). New or longer power cords are supplied at an extra charge by authorised dealers.

!The manufacturer denies any responsibility should any of these rules not be followed.

!If in doubt about any of the above consult a qualified electrician.

Before you start using your dryer

Once you have installed your dryer and before you use it, clean the inside of the drum to remove any dust that could have accumulated during transport.

2

Dryer Description

To open the door

Press and release the front panel in position shown

The features

Water container Rating plate

Door

Model & Serial numbers

Door catch

Air intake grille

Condenser cover handle

Filter

(Pull to open)



Control panel

Empty Water

HEAT





ALARM



Indicator





Light

Button





Button















































Drying Guide

The START button begins drying a selected programme (see Start and Programmes).

The HEAT button selects drying temperature (see Start and Programmes).

Out: HIGH Heat

In: GENTLE (LOW) Heat

The ALARM buzzer signals the end of a drying cycle. Out: buzzer ON

In: buzzer OFF

PROGRAMMES







START







Knob







Button





The Drying Guide allows you to consult a user friendly table of fabric types and load capacities.

The Empty Water light signals that the water container is full and must be emptied. The light will take a few seconds to go out after replacing the empty water container, the dryer must be running for this to happen.

The PROGRAMMES knob sets the programme: rotate until the indicator is pointing to the programme you want to select (see Start and Programmes).

GB

Installation



Description







Programmes

and Start





Laundry







Suggestions

and Warnings





Care

Maintenance



and





Troubleshooting







Service







3

Start and Programmes

Choosing a programme

GB

1.Plug the dryer into the electrical socket.

2.Sort your laundry according to fabric type (see Laundry).

3.Open the door and make sure the filter is clean and in place and the water container is empty and in place (see Maintenance).

4.Load the machine and make sure items are not in the way of the door seal. Close the door.

5.Choose a drying programme by checking the Programmes table (see Programmes) as well as the indications for the type of fabric (see Laundry).

-Set the temperature with the HEAT button.

-Select a programme or drying time by rotating the PROGRAMME knob.

6.If you wish the buzzer to sound at the end of the programme, press the ALARM button.

7.Press the START button to begin.

During the drying programme, you can check on your laundry and take out items that are dry while others continue drying. When you close the door again, press the START button in order to resume drying.

8.About 10 minutes before the programme is completed, it enters the final COOL TUMBLE phase (fabrics are cooled), which should always be allowed to complete.

9.Open the door, take the laundry out, clean the filter and replace it. Empty the water container and replace it (see Maintenance).

10.Unplug the dryer.

Water container and empty water light

If you have plumbed your dryer to a drain this light can be ignored, as there is no need to empty the water container.

When this light is on (not flashing) it reminds you to empty the water container.

If the water container fills during a programme, the light flashes and the dryer does the Cool Tumble phase (see Programmes). You must empty the water container and restart the dryer or the clothes will not dry. Afterre-startingthe dryer the light will take a few seconds to go out.

To avoid this always empty the water container each time you use the dryer (see Maintenance).

4

Start and Programmes

Programmes

Programme

What it does...

How to set it...

Note:













Dries your clothes, ready for

1.

Position the PROGRAMMES knob

Options available:



putting away.



on

.

Alarm, High or Low Heat

Cupboard dry



2.

Select High or Gentle Heat.







3.

Select Alarm option, if required.

! Do not dry Synthetics or





4.

Press the START button.





Acrylics on High Heat





















(see Laundry).













Brief programme

1.

Position the PROGRAMMES knob

Options available:

Speedy Iron

(approximately 10 minutes)



on

.

Alarm

that softens fibres of clothing

2.

Select High Heat.





3.

Select Alarm option, if required.

! This is not a drying



that is ready for ironing.



4.

Press the START button.





programme (see below).





















Timed Drying

For drying small loads (less than

1.

Position the PROGRAMME knob

Options available:

(140, 120, 110,

1kg) or if you prefer to use a



on the desired time: 140, 120, 110,

Alarm, High or Low Heat

100, 90, 80, 70,

timed programme.



100, 90, 80, 70, 60, 50, 40, 30 or



60, 50, 40, 30 or



20.



! Do not dry Synthetics or

20 minutes)



2.

Select High or Gentle Heat.

Should be used if you prefer a

Acrylics on High Heat





3.

Select Alarm option if required.



damper result than Cupboard

(see Laundry).



4.

Press the START button.



dry.















eg. a damper result suitable for







Consult suggested drying



ironing.







times (see Laundry).











The last 10 minutes of











these programmes is the











Cool Tumble phase (see











below).









Cool Tumble

Brief programme

1. Position the PROGRAMME knob

Options available:



(approximately 10 minutes)



on .



Alarm



that cools fibres of clothing.

2. Select Alarm option, if required.





3. Press the START button.





















Speedy Iron











‘Speedy Iron’ is a short 10 minute programme (8 minutes of heat followed by a 2 minute cool tumble period) which fluffs the fibres of clothing that have been left in the same position/location for an extended period of time. The cycle relaxes the fibres and makes them easier to iron and fold.

! ‘Speedy Iron’ isnot a drying programme and should not be used for wet articles of clothing.

For best results:

1.Do not load more than the maximum capacity. These numbers refer to the dry weight:

Fabric

Maximum load

Cotton and Cotton mixtures

2.5kg

Synthetics

2kg

Denim

2kg

2.Unload the dryer immediately after the end of the drying programme, hang, fold or iron the articles and put them away in the closet. Should this not be possible repeat the programme.

The ‘Speedy Iron’ effect varies from one fabric to the next. It works well on traditional fabrics like Cotton or Cotton mix, and less well on acrylic fibres and on materials such as Tencel®.

GB

Installation







Description







Programmes

and Start





Laundry







Suggestions

and Warnings





Care

Maintenance



and





Troubleshooting







Service







5

Laundry

Sorting your laundry

GB

Check symbols on clothing labels to make sure that the articles can be tumble dried.

Sort laundry by fabric type.

Empty pockets and check buttons.

Close zippers and hooks and tie loose belts and strings.

Wring out each item in order to eliminate as much excess water as possible.

! Do not load dripping wet clothes into the dryer.

Maximum load size

Do not load more than maximum capacity.

These numbers refer to dry weight:

Natural fibres: 6kg max (13lb)

Synthetic fibres: 3kg max (6.6lb)

! DO NOT overload the dryer as this could result in reduced drying performance.

Typical load

Clothes

Blouse

Cotton

150g

5oz



Other

100g

3oz

Dress

Cotton

500g

1lb 2oz



Other

350g

12oz









Jeans



700g

1lb 6oz









10 nappies



1000g

2lb 3oz









Shirt

Cotton

300g

10oz



Other

200g

7oz

T-Shirt



125g

4oz

















Household Items







Duvet cover

Cotton

1500g

3lb 5oz

(Double)

Other

1000g

2lb3oz









Large Tablecloth



700g

1lb 6oz









Small Tablecloth



250g

9oz









Tea Towel



100g

3oz









Bath Towel



700g

1lb 6oz









Hand Towel



350g

12oz









Double Sheet



500g

1lb 2oz









Single Sheet



350g

12oz









At the end of a drying cycle, cottons could still be damp if you grouped cottons and synthetics together. If this happens simply give them an additional short period of drying.

Wash Care Labels

Look at the labels on your garments, especially when tumble drying for the first time. The following symbols are the most common:

May be tumble dried

Do not tumble dry

Tumble dry at high heat setting

Tumble dry at low heat setting

Items not suitable for tumble drying

Articles that containing rubber or rubber-likematerials or plastic film (pillows, cushions, or PVC rainwear), any other flammable articles or objects that contain flammable substances (towels soiled with hair spray).

Glass fibres (certain types of draperies)

Items which have been dry cleaned

Items with the ITCL Code (see Special clothing items). These can be cleaned with specialat-home

dry cleaning products. Follow instructions carefully.

Large bulky items (quilts, sleeping bags, pillows, cushions, large bedspreads etc). These expand when drying and would prevent airflow through the dryer.

6

Laundry

Special clothing items

Blankets and Bedspreads: acrylic items (Acilan, Courtelle, Orion, Dralon) must be driedwith special care on LOW heat setting. Avoid drying for a long period of time.

Pleated or creased garments: read the manufacturer’s drying instructions on the garment.

Starched articles: do not dry these with nonstarched items. Make sure that as much of the starch solution is removed from the load as possible before placing it in the dryer. Do notover-dry:the starch will become powdery and leave your clothing limp, which defeats the purpose of starch.

Drying times

The table below presents APPROXIMATE drying times in minutes. Weights refer to dry garments:

Cottons /

High (full) Heat

Drying times 800-1000rpmin washing machine





Half Load





Full Load













1kg

2kg

3kg

4kg

5kg

6kg













30-40

40-55

55-70

70-80

80-90

95-120













Synthetics

Low (gentle) Heat

Drying times on reduced spin in washing machine



Half Load

Full Load







1kg

2kg

3kg







40-50

50-70

70-90







Acrylics /

Low (gentle) Heat

Drying times on reduced spin in washing machine



Half Load

Full Load









1kg

2kg







40-60

55-75







Times are approximate and can vary depending upon:

Amount of water retained in clothes after spin cycle: towels and delicates retain a lot of water.

Fabrics: items that are the same type of fabric but different textures and thicknesses may not have the same drying time.

Quantity of laundry: single items or small loads may take longer to dry.

Dryness: If you are going to iron some of your clothes, they can be taken out while still a bit damp. Others can be left longer if you need them to be completely dry.

Heat setting.

Room temperature: if the room where the dryer is located is cold, it will take longer for the dryer to dry your clothes.

Bulk: some bulky items can be tumble dried with care. We suggest that you remove these items several times, shake them out, and return them to the dryer until finished.

! Do notover-dryyour clothes.

All fabrics contain a little natural moisture, which keeps them soft and fluffy.

GB

Installation







Description







Programmes

and Start





Laundry







Suggestions

and Warnings





Care

Maintenance



and





Troubleshooting







Service







7

8

Warnings and Suggestions

GB

! The appliance has been designed and built according to international safety standards.

These warnings are given for safety reasons and must be read carefully.

This appliance conforms to the following EEC Directives:

-72/23/EEC and 93/68/EEC (Low Voltage Equipment)

-89/336/EEC, 92/31/EEC and 93/68/EEC (Electromagnetic Compatibility)

General safety

This tumble dryer has been designed for home, and not professional use.

This dryer must be used by adults, and the instructions in this booklet should be followed carefully.

Do not touch the appliance while barefoot or with wet hands or feet.

Unplug the machine by pulling on the plug, not the cord.

Children must not be in proximity of the dryer when in use. After using the dryer, turn it off and unplug it. Keep the door closed to make sure that children do not use it as a toy.

The appliance must be installed correctly and have proper ventilation. The air intake at the front of the dryer and rear vent behind the dryer should never be obstructed (see Installation).

Never use the dryer on carpeting where the pile height would prevent air from entering the dryer from the base.

Check to see if the dryer is empty before loading it.

The back of the dryer could become very hot. Never touch it while in use.

Do not use the dryer unless the filter, water container and condenser are securely in place (see Maintenance).

Do not use liquid fabric softeners in the dryer, add it to the final rinse of your wash.

Do not overload the dryer (see Laundry for maximum loads).

Do not load items that are dripping wet.

Tumble dry items only if they have been washed with detergent and water, rinsed and been through the spin cycle. It is a fire hazard to dry items that HAVE NOT been washed with water.

Carefully check all instructions on clothing labels (see Laundry).

Do not dry garments that have been treated with chemical products.

Never dry articles that are contaminated with flammable substances (petrol, oil, paint, hair spray, creams, cooking fat or oils).

Do not tumble dry rubber, foam rubber, plastic, plastic foam, nappy pants or liners, polythene or paper.

Do not tumble dry large, very bulky items.

Do not tumble dry acrylic fibres at high temperatures.

Complete each programme with its Cool Tumble Phase.

Do not turn off the dryer when there are still warm items inside.

Clean the filter after each use (see Maintenance).

Empty the water container after each use (see Maintenance).

Clean the condenser unit after regular intervals (see Maintenance).

Do not allow lint to collect around the dryer.

Never climb on top of the dryer. It could result in damage.

Always follow electrical standards and requirements (see Installation).

Always buy original spare parts and accessories (see Service).

Disposal

Disposing of the packaging material: follow local regulations, so the packaging can be recycled.

Disposal of your old dryer: cut the power cord and remove the door before disposing of an old dryer.

Saving energy and respecting the environment

Wring out items to eliminate excess water before tumble drying (if you use a washing machine first, select a high spin cycle). Doing this will save time and energy during drying.

Always dry full loads - you save energy: single items or small loads take longer to dry.

Clean the filter after each use to contain energy consumption costs (see Maintenance).

Maintenance and Care

Switching off the electricity

! Unplug your dryer when not using it, when cleaning it and during all maintenance operations.

Clean the filter after each cycle

The filter is an important part of your dryer:

it accumulates lint and fluff that is formed while drying. When finished drying, clean the filter by rinsing it under running water or with your vacuum cleaner. Should the filter become clogged up, the airflow inside the dryer will be seriously compromised: drying times lengthen and you will consume more energy. It may also damage your dryer.

The filter is found in front of the dryer trim (see diagram).

Cleaning the condenser unit

Periodically (every month) remove the condenser unit and clean any build up of fluff from between the plates by rinsing it under the tap with cold water.

This should be done with cold water from the rear of the condenser.

Removing the condenser:

1.Unplug the dryer and open the door.

2.Pull open the condenser cover (see diagram). Release the three catches by turning 90˚ counterclockwise then pull on the grip and remove from the dryer.

3.Clean the surface of the seals and replace, making sure that the catches have been secured.

Removing the filter:

1.Pull the plastic grip of the filter upwards (see diagram).

2.Clean the filter and replace it correctly.

Ensure the filter is fully located flush into the tumble dryer trim.

! Do not use the dryer without replacing the filter.

Empty the water container after each cycle

Pull the container out of the dryer and empty it into a sink or other suitable drain. Replace the water container securely.

Always check and empty the container before you start a new drying programme.

Check the drum after each cycle

Turn the drum manually in order to remove small items (handkerchiefs) that could have been left behind.

Cleaning the dryer

External parts in metal or plastic and rubber parts can be cleaned with a damp cloth.

Periodically clean the surface of the stainless steel sensor inside the drum with vinegar to remove water contaminates. Apply carefully with a cloth, this will maintain the drying performance of the dryer. The sensor is located on the plastic vane inside the drum towards the front of the dryer. Rotate the drum if necessary to locate it.

Periodically (every 6 months) vacuum the front air intake grille and vents at the rear of the dryer, to remove any build up of fluff, lint or dust. Also to remove accumulation of fluff from the front of the condenser and filter areas, clean occassionally with a vacuum cleaner.

!Do not use solvents or abrasives.

!Your dryer uses special bearing components which do not need lubrication.

!Have your dryer checked regularly by authorised technicians to ensure electrical and mechanical safety (see Service).

Water container

Filter

Tap

Rear

Front

Condenser cover

Air intake

Condenser unit

Catches Handle

GB

Installation







Description







Programmes

and Start





Laundry







Suggestions

and Warnings

Care

Maintenance



and





Troubleshooting







Service







9

Troubleshooting

One day your dryer seems not to be working. Before you call your Service Centre (see Service), go through the

GB

following troubleshooting suggestions:





Problem:

Possible causes / Solution:



The tumble dryer won’t start.

The plug is not plugged into the socket, or not making contact.





There has been a power failure.





The fuse has blown. Try to plug another appliance into the socket.





You are using an extension cord? Try to plug the dryer’s power cord







directly into the socket.





The door is not closed securely?





The PROGRAMMES knob has not been set properly (see Start and







Programmes).





The START button has not been pressed (see Start and Programmes).

It is taking a long time to dry. The filter has not been cleaned (see Maintenance).

The temperature setting is not ideal for the type of fabric you are drying (see Start and Programmes, and see Laundry).

The water container needs emptying? The empty water light is flashing? (see Maintenance).

The condenser needs cleaning? (see Maintenance).

The correct drying time has not been selected for the load (see Laundry).

The air intake grille or rear vents are obstructed (see Installation, and see Maintenance).

The items were too wet (see Laundry).

The dryer was overloaded (see Laundry).

Empty water light is on and the water container is not full.

Programme finishes and clothes are damper than expected.

This is normal, the light flashes when the container is full. If the light is on but not flashing it is just a reminder to empty the container (see Start and Programmes).

! For safety the dryer has a maximum programme time of 4 hours. If an automatic programme has not sensed the required final moisture in this time the dryer will complete the programme and stop. Check the above points and run the programme again, if the results are still damp, contact the Service Centre

(see Service).

10

Service

Before calling the Service Centre:

Use the troubleshooting guide to see if you can solve the problem yourself (see Troubleshooting).

If not, turn off the dryer and call the Service Centre closest to you.

What to tell the Service Centre:

name, address and post code.

telephone number.

the type of problem.

the date of purchase.

the appliance model (Mod.).

the serial number (S/N).

This information can be found on the data label inside the door of the machine.

Spare Parts

This dryer is a complex machine. Repairing it yourself or having a non-authorisedperson try to repair it could cause harm to one or more persons, could damage the machine and could invalidate the spare parts warranty.

Call an authorised technician if you experience problems while using the machine.

The spare parts have been designed exclusively for this appliance and not for other uses.

GB

Installation







Description







Programmes

and Start





Laundry







Suggestions

and Warnings





Care

Maintenance



and





Troubleshooting







Service







11

Key Contacts

After Sales Service

Over 1100 trained specialists, directly employed by us, ensure that you can have complete confidence in both the appliances and services we offer.

Repair Service and Information Help Desk

UK: 08709 066 066 Monday to Friday, 8am to 7.30pm

Saturday, 8.30am to 5.30pm Sunday, 9.30am to 3.30pm www.credaservice.co.uk

Republic of Ireland: 1850 302 200

Note: Our operators will require the following information: Model number

Serial number

Extended Warranties

UK: 08709 088 088 Monday to Sunday, 8am to 8pm

www.credaservice.co.uk

Republic of Ireland: 1850 502 200

Genuine Parts and Accessories

UK: 08709 077 077 Monday to Friday, 8.30am to 5pm

Saturday, 8.30am to 12noon www.credaservice.co.uk

Republic of Ireland: (01) 842 6836

www.creda.co.uk

Indesit Company UK Limited, Morley Way, Peterborough, PE2 9JB

PRINTED BY SIMLEX . FOUR ASHES, WOLVERHAMPTON.

01/2005 195042652.01
