Creative S750 User Manual
MWorks THX S750 CLA.book Page i Friday, November 14, 2003 4:37 PM
Safety & Regulatory Information
The following sections contain notices for various countries:
Notice for the USA
FCC Part 15: This equipment has been tested and
found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, this notice is not a guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to
radio or television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try one or more of the following
measures:
❒
Reorient or relocate the receiving antenna.
❒
Increase the distance between the equipment
and receiver.
❒
Connect the equipment to an outlet on a circuit
different from that to which the receiver is
connected.
❒
Consult the dealer or an experienced radio/ TV
technician.
CAUTION: To comply with the limits for the Class B
digital device, pursuant to Part 15 of the FCC Rules,
The lightning flash arrowhead within an equilateral triangle is intended to alert the user to
the presence of uninsulated, “dangerous voltage” within the product’s enclosure, that may
be of sufficient magnitude to constitute risk of
electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying this product.
this device must be installed with computer equipment
certified to comply with the Class B limits.
All cables used to connect the computer and
peripherals must be shielded and grounded.
Operation with non-certified computers or nonshielded cables may result in interference to radio or
television reception.
Modifications
Any changes or modifications not expressly approved
by the grantee of this device could void the user’s
authority to operate the device.
Notice for Canada
This apparatus complies with the Class B limits for
radio interference as specified in the Canadian
Department of Communications Radio Interference
Regulations.
Cet appareil est conforme aux normes de CLASSE
“B” d’interference radio tel que spe’cifie’ par le
Ministère Canadien des Communications dans les
règlements d’interfèrence radio.
Important Notice
The serial number for the GigaWorks S750/S700/
S700 is located on the subwoofer. Please write this
Safety Warnings
WARNING
DO NOT OPEN
TO PREVENT THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE SPEAKER
COVERS (OR BACKS). NO USER-
SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
number down and keep it in a secure area. This is for
your security.
CAUTION
Take care to prevent accidental operation of your new
loudspeaker system at excessive sound pressure
levels!
In a typical personal computer installation, the
GigaWorks S750/S700 satellite speakers are less
than a meter from the listener.
If you do not hear sound from your new speaker, keep
the GigaWorks S750/S700's volume control at a low
level (two Level Indicators lit on the wired remote
control) while trying to restore sound to your system.
This will prevent accidental operation at
uncomfortably loud levels.
Compliance
This product conforms to the following Council
Directive:
EMC Directive 89/ 336/ EEC amended by Directive
92/ 31/ EEC and 93/68/EEC LVD 73/ 23/ EEC
amended by Directive 93/68/EEC.
CAUTION:
TO PREVENT THE RISK OF ELECTRIC
SHOCK, MATCH WIDE BLADE OF PLUG
TO WIDE SLOT. INSERT CAREFULLY.
ATTENTION:
POUR EVITER LES CHOCS ELECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE
DE LA FICHE DANS LA BORNE
CORRESPONDANTE DE LA PRISE ET
POUSSER JUSQU AU FOND.
CAUTION:
This symbol indicates that the marked item may
be Hot and should not be touched without
proper care.
❒
To minimize the risk of burns and other injuries to
children, position the device such that hot surfaces are
out of their reach.
❒
To minimize the risk of fire, keep flammable materials like
paper and cloth (for example, curtains) away from the hot
surface.
WAR NI NG:
Do not expose this apparatus to dripping or
splashing fluids, and ensure that no objects filled
with liquids — such as vases — are placed on
the apparatus.
AVISQUE
POUR EVITER TOUT RISQUE DE
CHOC ELECTRIQUE, NE PAS
DEMONTER LE COUVERCLE DU
HAUT PARLEUR. AUCUN ENTRETIEN
DES PIECES INTERIEURES N EST
REQUIS. TOUT SERVICE D
ENTRETIEN NE DOIT ETRE EFFECTUE
QUE PAR DU PERSONNEL D
ENTRETIEN QUALIFIE.
IMPORTANT NOTICE:
THE SERIAL NUMBER FOR THE
SPEAKER IS LOCATED ON THE
SUBWOOFER. PLEASE WRITE THIS
NUMBER DOWN AND KEEP IT IN A
SECURE AREA. THIS IS FOR YOUR
SECURITY.
READ AND HEED IMPORTANT SAFETY WARNING ON REAR OF SPEAKER ENCLOSURE
i
MWorks THX S750 CLA.book Page ii Friday, November 14, 2003 4:37 PM
IMPORTANT SAFETY INSTRUCTIONS
READ INSTRUCTIONS - All safety and operating
instructions should be read before the GigaWorks S750/
S700 amplified subwoofer/satellite system is operated.
RETAIN INSTRUCTIONS - The safety and operating
instructions should be retained for future reference .
HEED WARNINGS - All warnings on the subwoofer and
in the operating instructions should be adhered to.
FOLLOW INSTRUCTIONS - All operating and usage
instructions should be followed.
CLEANING - Unplug the subwoofer from the wall outlet or
other power source before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp cloth for cleaning.
AT TAC H ME N T S - Do not use attachments not
recommended by Creative Technology as they may
cause hazards.
WATER AND MOISTURE - Do not use the subwoofer
near water—for example, near a bath tub, wash bowl,
kitchen sink, or laundry tub; in a wet basement; or near
a swimming pool; and the like.
ACCESSORIES - Do not place the GigaWorks S750/S700
system on an unstable cart, stand, tripod, bracket, or
table. The subwoofer or satellites may fall, causing
serious injury to a child or adult, and serious damage to
the product. Use only with a cart, stand, tripod,
bracket, or table recommended by Creative
Technology, or sold with the product. Any mounting of
the satellites or subwoofer should follow the
manufacturer’s instructions, and should use a mounting
accessory recommended by Creative Technology.
VENTILATION - Slots and openings in the cabinet are
provided for ventilation, to ensure reliable operation of
the subwoofer and to prevent it from overheating; and
these openings must not be blocked or covered. The
openings should never be blocked by placing the
product on a bed, sofa, rug, or other similar surface.
The subwoofer should not be placed in a built-in
installation such as a bookcase or rack unless proper
ventilation is provided or Creative Technology’s
instructions have been adhered to.
HEAT - The subwoofer should be situated away from
heat sources such as radiators, heat registers, stoves,
and other products (including amplifiers) that
produce heat.
POWER SOURCES - The subwoofer should be
operated only from the type of power source indicated
on the marking label. If you are not sure of the type of
power supply to your home, consult your product
dealer or local power company. For products intended
to operate from battery power or other sources, refer
to the operating instructions.
POLARIZATION - The subwoofer may be equipped
with a polarized alternating-current line plug (a plug
having one blade wider than the other). This plug will fit
into the power outlet only one way. This is a safety
feature. If you are unable to insert the plug fully into the
outlet, try reversing the plug. If the plug should still fail
to fit, contact your electrician to replace your obsolete
outlet. Do not defeat the safety purpose of the
polarized plug.
POWER-CORD PROTECTION - Power-supply cords
should be routed so that they are not likely to be
walked on or pinched by items placed upon or against
them, paying particular attention to cords at plugs,
convenience receptacles, and the point where they exit
from the subwoofer.
LIGHTNING - For added protection for the GigaWorks
S750/S700 system during a lightning storm, or when it
is left unattended and unused for long periods of time,
unplug it from the wall outlet. This will prevent damage
to the subwoofer due to lightning and power-line
surges.
OVE RLOA DIN G - Do not overload wall outlets,
extension cords, or integral convenience receptacles as
this can result in a risk of fire or electric shock.
OBJECT AND LIQUID ENTRY - Never push objects
of any kind into the subwoofer through openings as
they may touch dangerous voltage points or short out
parts that could result in a fire or electric shock. Never
spill liquid of any kind on the subwoofer.
SERVICING - Do not attempt to service the subwoofer
yourself as opening or removing covers may expose you
to dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
DAMAGE REQUIRING SERVICE - Unplug the
subwoofer from the wall outlet or other power source
and refer servicing to qualified service personnel under
the following conditions:
a)When the power-supply cord or plug is damaged.
b)If liquid has been spilled, or object have fallen into the
subwoofer.
c)If the subwoofer has been exposed to rain or water.
d)If the subwoofer does not operate normally by
following the operating instructions; or exhibits a
distinct change in performance.
e)If the product has been dropped or damaged in any
way.
REPLACEMENT PARTS - When replacement parts are
required, be sure the service technician has used
replacement parts specified by Creative Technology, or
have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric
shock, or other hazards.
SAFETY CHECK - Upon completion of any service or
repairs to the GigaWorks S750/S700 system, ask the
service technician to perform safety checks to
determine that the GigaWorks S750/S700 system is in
proper operating condition.
WALL OR CEILING MOUNTING - The GigaWorks
S750/S700 satellites should be mounted to a wall or
ceiling only as recommended by Creative Technology.
ii
MWorks THX S750 CLA.book Page 3 Friday, November 14, 2003 4:37 PM
Contents
GigaWorks S750 / GigaWorks S700
Safety and Regulatory Information and Warnings ...1
Important Safety Instructions ....................................2
Contents and copyright notice ..................................3
Introduction ............................................................... 4
Speaker Connection ................................................ 5
GigaWorks S750
Speaker Placement Options / Stand Attachment......6
Audio Control Pod and Remote Control....................7
Connecting Input Devices........................................ 9
Understanding Upmixing.........................................11
Controlling Noise and Distortion .............................12
Specifications and Upgrade option .........................12
GigaWorks S700
Information in this document is subject to change without notice and does not represent a commitment on the part of
Creative Technology Ltd. No part of this manual may be reproduced or transmitted in any form or by any means, electronic
or mechanical, including photocopying and recording, for any purpose without the written permission of Creative
Technology Ltd.
Version 1.0
November 2003
© 2003 Creative Technology Ltd. All rights reserved. GigaWorks is a trademark of Creative Technology Ltd. The Creative
logo, EAX, Audigy and Sound Blaster are registered trademarks, and Extigy and Live! are trademarks of Creative
Technology Ltd. in the USA and/or other countries. THX and the THX logo are trademarks or registered trademarks of THX
Ltd. Lucasfilm is a trademark of Lucasfilm Ltd. Used under authorization. All other logos, brand and product names are
trademarks or registered trademarks of their respective holders. All specifications are subject to change without prior
notice. Actual contents may differ slightly from those pictured.
3
MWorks THX S750 CLA.book Page 4 Friday, November 14, 2003 4:37 PM
Introduction
Four steps to enjoying your GigaWorks speakers ...
Connect your
Place the speakers
speakers
Page 5 contains
the set up instructions for Creative
GigaWorks S750
or GigaWorks
S700.
Thank you for purchasing the
GigaWorks S750 or S700 speakers
by Creative Technology.
The GigaWorks S750 features a
powerful 7.1 channel amplifier,
driving 7 satellite speakers and a
subwoofer. The GigaWorks S700 is
similar in all aspects, except that
only 5 satellites are supplied. When
you are ready to upgrade to 7.1channel audio, just purchase two
additional satellites speakers to
make full use of the GigaWorks
S700 system’s built-in 7.1 amplifier.
As such, unless otherwise stated,
all references to the hardware from
this point onwards, apply to both
products.
Both speaker systems feature
precision super tweeters suitable
for DVD-Audio playback.
Additionally, this series of highquality amplified multimedia
speaker systems features the finest
drivers, precision internal crossover
and amplifier circuitry in an elegant
enclosure design.
The GigaWorks S750 and S700
support the very latest in audio
technology today. This includes:
EAX™, DirectSound
Audio and multichannel gaming.
The powerful speakers also support
the 5.1, 6.1 or 7.1 analog output
from the the latest Sound Blaster
Live!™ and Audigy
cards. To experience the full
®
3D, DVD-
®
series audio
Page 6 contains
placement tips
that maximize the
surround-sound
effects of your
speaker system.
®
Learn to operate
correctly
the system
Pages 7 and 8
show you what
you can do with
the Audio Control
Pod and Remote
Control.
potential of your GigaWorks
system, we recommend that you
take a few minutes to read through
this User’s Guide in the order
shown above.
Remember to ensure that all
plugs are securely fastened to their
respective sockets before operating
your speaker system.
GigaWorks S750
With its seven powerful satellite
speakers and a separate subwoofer
with 8-channel amplification, the
Creative GigaWorks S750 is an
incredible 7.1 speaker system for
use with Creative’s EAX-enabled
products. This high power speaker
system delivers a thrilling, high
quality PC home theater audio
experience that meets the
prestigious THX multimedia
certification standard. Combine this
speaker system with the 24-bit
Sound Blaster Audigy
sound cards and you will
experience the ultimate in highpowered, high definition playback of
your Dolby Digital Surround EX
titles on your PC.
GigaWorks S700
With its five powerful satellite
speakers and a separate
®
2 series
Connect and upmix
audio sources
Pages 9 –11 help
you to connect
audio devices to
your speakers,
and “upmix” audio
for better sound.
subwoofer, the Creative GigaWorks
S700 is an excellent speaker
system for use with Creative’s EAXenabled products. Combine it with
the Sound Blaster Audigy
sound cards, you will experience a
thrilling, high quality 5.1 PC home
theater audio experience that
meets the prestigious THX
multimedia certification standard.
THX Certification
Lucasfilm-THX Certified
multimedia products carry the THX
mark of excellence in consumer
home entertainment. When you
purchase a THX Certified
multimedia product you will be
confident knowing that it has been
developed, evaluated and tested to
meet rigorous performance
requirements established by THX
certification specifications. These
specifications include power
handling, frequency response and
dispersion characteristics. The THX
logo on your product is your
guarantee of performance,
promising many years of crisp and
clear sound.
®
series
4
Loading...
