Corsair A500 User Manual
Corsair A500 Tower Air Cooler
Embargo Date
6-Jan-20
First Customer Ship Date
Product Etail Title
Product Title
Corsair A500 Tower Air Cooler
Pre-Order Option
None
Product Imagery
Photography
Bring your CPU temperatures down with the CORSAIR A500 High Performance Dual Fan CPU Cooler, equipped with four direct-contact copper heat
Intel LGA 1150/1151/1155/1156
AMD AM4/AM3/FM2/FM1
1
18-Nov-19
A500 Dual Fan CPU Cooler
Product Name CORSAIR A500 High Performance Dual Fan CPU Cooler
Compatibility List
Overview
25 Word Product Description
Intel 2011/2011-3/2066
pipes and two CORSAIR ML120 fans.
Overview
50 Word Product Description
Bring your CPU temperatures down with the CORSAIR A500 High Performance Dual Fan CPU Cooler, taking advantage of four direct-contact copper
heat pipes to cool CPUs up to 250W TDP. Two CORSAIR ML120 PWM magnetic levitation bearing fans run between 400 RPM for ultra-quiet operation
or 2,400 RPM for extreme cooling performance.
Overview
100 Word Product Description
Bring your CPU temperatures down with the CORSAIR A500 High Performance Dual Fan CPU Cooler, taking advantage of four direct-contact copper
heat pipes to cool CPUs up to 250W TDP. Two CORSAIR ML120 PWM magnetic levitation bearing fans run between 400 RPM for ultra-quiet operation
or 2,400 RPM for extreme cooling performance. An intuitive slide-and-lock fan mounting system accommodates most RAM designs, while the easy-toinstall CORSAIR HoldFast retention system ensures a secure and reliable fit on almost all modern AMD & Intel CPUs. With pre-applied CORSAIR XTM50
High Performance Thermal Paste and a five-year warranty for peace of mind, the A500 will help unlock your CPU’s potential.
Corsair A500 Tower Air Cooler
Style 1
●
●
●
●
●
●
Style 2
●
●
●●●
●
Intuitive slide-and-lock fan mount system allows for variable mounting height, for wide DRAM compatibility and easy installation.
Equipped with two CORSAIR ML120 magnetic levitation bearing fans with PWM control, allowing you to adjust speed anywhere
CORSAIR HoldFast retention system is easy to install and ensures consistent thermal performance with a secure and reliable fit on
almost all modern AMD & Intel CPUs.*
Comes with pre-applied CORSAIR XTM50 High Performance Thermal Paste in an optimized pattern for even spreading.
Five-year warranty for complete peace of mind.
•Coldplate Material:
Quad Direct-Contact Copper Heat Pipe Design: Cools your CPU up to 250W TDP, unlocking higher performance by dropping CPU
temperatures.
Intuitive Slide-and-Lock Fan Mount System: Variable mounting height for wide DRAM compatibility and easy installation.
Two CORSAIR ML120 Fans: Magnetic levitation bearing fans with PWM control allow you to adjust between 400 RPM for ultra-quiet
CORSAIR HoldFast Retention System
Pre-Applied Thermal Material
Five-Year Warranty
*Supports: AM4, AM3, FM2, LGA115x, LGA20xx
•Dimensions (mm):
173mm x 143.5mm x 168.7mm / 6.81" x 5.65" x 6.64"
• Heatsink Material:
•Fans included:
2x ML120 Magnetic Levitation PWM Fans
•Fan Max Speed:
• Fan Dimensions:
120x120x25mm / 4.72" x 4.72" x 0.98"
•Tubing Material:
•Lighting:
•Warranty:
5 Years
•Fan Airflow:
75 CFM
•Fan Static Pressure:
4.2 mm-H2O
•Fan Noise Level:
37 dBa
Tech Specs
Features and Benefits
Search Terms
2
Four direct-contact copper heat pipes cool your CPU up to 250W TDP, unlocking higher performance by dropping CPU temperatures.
between 400 RPM for ultra-quiet operation or 2,400 RPM for extreme cooling performance.
*Supports: AM4, AM3, FM2, LGA115x, LGA20xx
operation or 2,400 RPM for extreme cooling performance.
almost all modern AMD & Intel CPUs.*
: Easy to install and ensures consistent thermal performance with a secure and reliable fit on
: CORSAIR XTM50 High Performance Thermal Paste applied in an optimized pattern for even spreading.
: For complete peace of mind.
CPU air cooler, CPU air cooling, CORSAIR Air cooler, PC tower cooler, Air CPU cooler, CPU fan cooler, CPU heatsink fan, Fan CPU cooler, PC air cooling
Black Nickel-Plated Copper
Black Nickel-Plated Aluminum
2400 RPM
N/A
None
