Commander SK

Options for Commander SK

Michael Nakulski

September 2004

INDEX

Page 3 - Options for Commander SK

Page 4 - LED Remote Mounting Keypad

Page 5 - LCD Remote Mounting Keypad

Page 6 - Parameter Memory Stick

Page 7 - Fieldbus Option Modules

Page 8 - Extended I/O

Page 9 - Extended I/O with Real-time-clock

Commander SK

Page 10 - Commissioning Software

Page 11 - PLC Function Programming Software

Page 12 - PLC Function Stick

Page 13 - Connecting Cable for PC

Page 14 - Additional EMC Filters

Page 15 - Top NEMA 1 Cover

Page 16 - Bottom Glanding Metal Cover

Options for Commander SK

Commander SK has many option possibilities

which compliment the standard features and

functions making it the most flexible general

purpose AC drive.

All the options described on the following pages are

supported by all three frame sizes of Commander SK.

The exception is the SM range of option modules

which is only supported by sizes B & C.

Commander SK

Size C

Size A

Size

200 to 240V +/-10%

380 to 480 V +/-10%

Size B

CBA

2.2 kW1.1 to 1.5 kW0.25 to 0.75 kW

2.2 to 4.0 kW0.37 to 1.5 kW-

LED Remote Mounting Keypad

Ordering Code: SK-Keypad Remote

Description:

Remote panel mounting LED keypad display to IP54 (NEMA12) with additional function key.

•Selectable function key with LED to indicate function selected.

– Hand-Off-Auto, Jog, Reverse, etc.

•Connects to the RS485 Modbus RTU port on the drive via a standard RJ45 connector

•Connecting cable (up to 30m)

Commander SK

•Simple panel cut-out - 21mm hole

•Fixed keypad on drive remains active.

Compatibility:

• Commander SK only –

all sizes

LCD Remote Mounting Keypad

Ordering Code: SM-Keypad Plus

Description:

Remote panel mounting LCD multilingual

text keypad display to IP54 (NEMA12) with

the additional “Help” key.

•For remote panel mounting only

•Multi-lingual – 3 lines of text

(English, French, Spanish, German & Italian)

•Help function key

•Connects to the RS485 Modbus RTU port on

the drive via standard RJ45 connector

Commander SK

•Simple panel cut-out - 21mm hole

•Fixed keypad on drive remains active

•A PC software tool enables you to set up your

own text lines.

•Exactly the same LCD keypad as used by

Unidrive SP

Compatibility:

• Commander SK – all sizes

• Unidrive SP

• Commander SX (IP66)

Parameter Memory Stick

Ordering Code: SmartStick

Description:

Upload drive parameters to the

SmartStick for storage or for easy setup

of identical drives or for downloading to

replacement drives.

•SmartStick

- 1 parameter configures as:

•Read - program the drive with contents

Commander SK

•Program - Drive parameter set loaded

onto SmartStick

•Boot - Loads parameters at power up

(and can then be removed) - Read only

and can’t be changed!

Compatibility:

• Commander SK – all sizes

Fieldbus Option Modules

Ordering Code: SM-PROFIBUS DP

SM-DeviceNet

SM-CANopen

SM-INTERBUS

SM-Ethernet (end 2004)

Description:

The most popular industrial fieldbus

protocols are available in the SM range of

option modules.

One option slot in sizes B & C allows an SM

fieldbus option and other specified SM option

Commander SK

modules to be fitted.

Use fieldbus firmware version 3.0 or higher for

complete compatibility for the entire range of AC

drives.

Compatibility:

• Commander SK sizes B & C

• Unidrive SP

• Commander SX (IP66)

ETHERNET

(TCP/IP)

Extended I/O

Ordering Code: SM-I/O Lite

Description:

Additional I/O option with the following

connections:

• 0V

• ±10V bi-polar or 4-20mA Analogue input

• 0-10V or 4-20mA Analogue output

• +24V

• Digital input

• Encoder B or Digital input

• Encoder B\

• Encoder A

• Encoder A\

• 0V

• Encoder +5V

This "Encoder Speed Reference" input is not a

true quadrature counter - therefore applications

which require accuracy when operating close to

zero speed will not be possible. Therefore,

generally this option cannot be used for position

applications but is more suited to applications

Commander SK

• Relay

Compatibility:

• Commander SK sizes B & C

• Unidrive SP

that require accurate speed holding and speed

following.

Extended I/O with Real-time-clock

Commander SK

Ordering Code: SM-I/O Timer

Description:

Real-time-clock for scheduling drive

running as well as the following additional I/O connections:

• 0V

• ±10V bi-polar or 4-20mA Analogue input

• 0-10V or 4-20mA Analogue output

• +24V

• Digital input

• Encoder B or Digital input

• Encoder B\

• Encoder A

• Encoder A\

• 0V

• Encoder +5V

This "Encoder Speed Reference" input is not a

true quadrature counter - therefore applications

which require accuracy when operating close to

zero speed will not be possible. Therefore,

generally this option cannot be used for position

applications but is more suited to applications that

require accurate speed holding and speed

Size B

• Relay

Real Time Clock

(Year, Month, Date, Week day, Hour, Minute, Second)

Compatibility:

• Commander SK sizes B & C

• Unidrive SP

following.

Size C

Commissioning Software

Ordering Code: CTSoft

(comes free-of-charge with product CD ROM)

Description:

Software for your PC or laptop which allows you to commission and store parameter settings.

Use with CT Comms Cable.

•Drive Set up & Monitoring Software Tool this one software package handles all key CT drive products

•Upload / download / store parameter setups

Commander SK

•Easy set up Wizards

Compatibility:

• Commander SK – all sizes

• Unidrive SP

PLC Function Programming Software

Ordering Code: SyPTLite

(comes free-of-charge with product CD ROM)

Description:

Software for your PC or laptop which allows you to program PLC functions within the Drive.

Use with LogicStick and CT Comms Cable.

•SyPTLite: A ladder diagram editor allowing the development of application programs (30-50

rungs typical)

•IEC 61131-3 environment - same as leading PLC programmers

Commander SK

•Library of Standard Function Blocks

•Self Documenting

•Fully Compatible with Unidrive SP

Compatibility:

• Commander SK – all sizes

• Unidrive SP

PLC Function Stick

Ordering Code: LogicStick

Description:

The LogicStick plugs into the front of the

drive and enables you to program PLC

functions within the drive.

Use with SyPTLite software and the CT

Comms Cable.

•Nano and micro PLCs can be easily replaced by LogicStick

Commander SK

•Memory storage for application or customer specific functionality

• Application Programming using SyPT Lite IEC61131-3 (Industry Standard Ladder)

Compatibility:

• Commander SK – all sizes

Connecting Cable for PC

Ordering Code: CT Comms Cable

Description:

Cable with isolated RS232 to RS485

converter. For connecting your PC / laptop

to the drive when using CTSoft or

SyPTLite.

Use with SyPTLite PLC Function software or

CTSoft commissioning software.

SELV isolation rated for safety and reliability.

Commander SK

Compatibility:

• Commander SK – all sizes

• Unidrive SP

• Commander SX (IP66)

Additional EMC Filters

Ordering Code:

EMC Footprint Filters:

•Size A - 1 Phase EMC Filter

•Size B - 1 Phase EMC Filter

•Size B - 3 Phase EMC Filter

•Size C - 1 Phase EMC Filter

•Size C - 3 Phase EMC Filter

Low Earth Leakage EMC Filters:

•Size A - 1 Phase Low Earth Leakage EMC Filter

•Size B - 1 Phase Low Earth Leakage EMC Filter

Description:

The EMC footprint filters are designed to

Commander SK

operate together with the drive’s own internal

EMC filter in areas of sensitive equipment.

In areas where EMC filtering is required and

earth leakage current interferes with the

protection equipment (i.e. RCD circuit

breakers) the range of low earth leakage

EMC filters can be used.

The drive’s integral EMC filter must be

disconnected when using the low earth

leakage EMC filters.

Compatibility:

• Commander SK – all sizes

Top NEMA 1 Cover

Ordering Code:

EMC Footprint Filters:

•Size A – NEMA 1 Top Cover

•Size B – NEMA 1 Top Cover

•Size C - NEMA 1 Top Cover

Description:

These plastic top covers give the drives

a NEMA 1 rating when fitted. They are

designed to simply clip on to the top of

the drive giving additional protection for

falling dust or falling water droplets.

Commander SK

Compatibility:

• Commander SK – all sizes

Bottom Glanding Metal Cover

Ordering Code:

EMC Footprint Filters:

•Size A – Gland Cover

•Size B – Gland Cover

•Size C - Gland Cover

Description:

These metal bottom glanding covers are

ideal for Commander SK installations

using cable conduit entry or for

terminating incoming cables using gland

fittings.

Commander SK

Compatibility:

• Commander SK – all sizes
