The Compaq HB1004 10Base-T Ethernet Hub is a stand-alone, intelligent, 4
port hub. If offers an SNMP V1-compliant firmware agent. The HB1004 can
be monitored and controlled through a network management station. In
addition, you can also cascade the hub to additional 10Mb/s hubs or
10/100Mb/s switches.
The hub supports both in-band and out-of-band management. For in-band
management you can use SNMP compliant network management software to
monitor and control the system. For out-of-band management, you can connect
the hub’s RS232 port to a PC running the Compaq HB1004 System
Configuration Program.
Features
Four RJ-45 10Base-T ports
Q
IEEE 802.3 compliant
Q
Provides one DB9 connector RS232 port for out-of-band network
Q
management using the Compaq HB1004 System Configu ration Program
One port is selectable to provide either MDI or MDI-X support
Q
Supports automatic polarity detection and correction, permitting
Q
automatic recovery due to wiring errors
Automatically auto-partitions bad ports to protect normal network
Q
operation
Automatically adapts to a wide range of power sources
Q
Can be mounted on a desktop or in a standard 19” rack
Q
Includes a comprehensive LED indicator panel for reporting network
Q
activity, unit configuration, and problem diagnosis
SNMP support including MIB-II, repeater MIB, and Compaq private
Q
MIB
Supports FlashROM on board for easily updating the microcode using
Q
TFTP or the Compaq HB1004 System Configuration Program running
on a PC
Compaq HB1004 10Base-T Hub User Guide
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overview
1-2
Package Contents
Before you start to install the hub, verify that this package contains the
following items:
Compaq HB1004 10Base-T Ethernet hub
Q
Communication cable
Q
Adapter connectors
Q
Power cord
Q
Rack-mounting kit (two mounting brackets, eight 3/8-inch bracket
Q
screws, and four ½-inch rack-mount screws)
Four adhesive-backed rubber feet
Q
Compaq HB1004 System Configuration Program diskette
Q
Compaq HB1004 10Base-T Ethernet Hub User Guide
Q
Warranty guide
Q
Figure 1-1 Package Contents
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-3
Hub Components
This section provides an overview of the Compaq HB1004 hub’s components
including the LED indicators, RJ-45 ports, and the serial COM port. Figure 1-1
shows the hub’s front panel.
Figure 1-1 Compaq HB1004 10Base-T Ethernet Hub Front Panel
RJ-45 Ports
The hub’s four RJ-45 ports allow connections to workstations and servers in a
10Base-T network via UTP cabling. When the MDI/MDI-X slide switch on the
front panel of the hub is set to MDI, Port 4 uses the MDI pinout and can be
used for a 10Base-T uplink. When the switch is set to MDI-X, Port 4 uses the
MDI-X pinout and can be connected directly to a network interface card (NIC).
Serial COM Port
The HB1004 hub contains a serial COM port that uses a male DB9 connector
with a standard AT pinout. You can use this port to connect to a workstation
for out-of-band communication using the Compaq HB1004 System
Configuration Program.
LED Indicators
The LED panel of the hub helps you monitor the hub’s operation. When you
power on the hub, it performs a power-on self test (POST) which lasts a few
seconds. After the POST, all LEDs reflect the current operational modes
described in Table 1-1.
Compaq HB1004 10Base-T Hub User Guide
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overview
1-4
Unit LEDs
The unit-level LEDs on the HB1004 indicate the status of the power supply and
the percentage of use and collisions on the hub.
Table 1-1
Hub LED Conditions and Descriptions
LED Status Description
Power On Power supply is operational
Off Power supply is off
Utilization Indicates percentage of network utilization
1 Green lit 1% to 5%
2 Green lit 5% to 15%
3 Green lit 15% to 30%
3 Green, 1 Amber lit 30% to 65%
3 Green, 2 Amber lit Above 65%
Collision Indicates percentage of network collision count variation
1 Green lit 1% to 3%
2 Green lit 3% to 5%
3 Green lit 5% to 10%
3 Green, 1 Amber lit 10% to 15%
3 Green, 2 Amber lit Above 15%
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-5
Port LEDs
There are two LEDs for each port to indicate link/activity and partition/disable
on the ports.
Table 1-2
Port LED Conditions and Descriptions
LED Status Description
Link/Activity Solid green A network device has established a link with the hub
Partition/Disable Solid Amber Indicates the port is partitioned
MDI/MDI-X Slide Switch
The MDI/MDI-X slide switch is located on the front panel of the hub. This
switch allows you to use Port 4 as an uplink port to connect the hub to another
hub or switch. When the switch is in the MDI position, Port 4 us es the MDI
pinout for an uplink port. When the switch is in the MDI-X position, Port 4
uses the MDI-X pinout to connect to a workstation or server NIC.
Flashing green
Flashing Amber Indicates the port has been disabled by management
Off The port is operating normally
Data is passing through the port, flashes in proportion to
rate of traffic passing through the port
Compaq HB1004 10Base-T Hub User Guide
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-1
Chapter 2
Installation
This chapter provides information to help you prepare for and install the hub
and connect the hub to the network.
Mounting the Hub
You can place this hub directly on a desktop or mount it in a rack. Before you
start installing the hub, make sure you can provide the right operating
environment, including power requirements, sufficient physical space, and
proximity to other network devices you want to connect. Verify the following
installation requirements:
Power requirements: 100 to 240 VAC (+/- 10%) at 50 to 60 Hz (+/- 3
Q
Hz). The hub’s power supply automatically adjusts to the input voltage.
The hub should be located in a cool, dry place with at least 10 cm (4 in.)
Q
of space at the front and back for ventilation.
Place the hub out of direct sunlight and away from heat sources or areas
Q
with a high amount of electromagnetic interference.
If you intend to mount the hub in a rack, make sure you have all the
Q
necessary mounting screws, brackets, and tools.
Check if network cables and connectors needed for installation are
Q
available.
Mounting the Hub on a Flat Surface
This hub can be placed anywhere there is enough flat space, such as on a table
or desktop.
1. Stick the self-adhesive rubber foot pads (that come with this package) on
each of the four concave spaces located on the bottom of the hub
2. Place the hub on a firm, flat surface.
3. Be sure you allow at least 2 inches (5 cm) on each side and 4 inches (10
cm) at the back of the hub for proper airflow.
Compaq HB1004 10Base-T Hub User Guide
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation
2-2
Mounting the Hub in a Rack
To mount the hub in a rack, follow these steps:
1. Use a standard EIA 19 inch rack
2. Use the brackets and screws supplied in the rack mounting kit
3. Use a cross-head screwdriver to attach the brackets to the side of the hub
Figure 2-1 Attaching the Mounting Brackets
4. Position the hub in the rack by lining up the holes in the brackets with
the appropriate holes on the rack, and then use the supplied screws to
mount the hub in the rack
Figure 2-2 Positioning the Hub in a Rack
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-3
Connecting the Hub System
The Compaq HB1004 hub has four RJ-45 ports, one of which serves as an
MDI/MDI-X port.
Making a Connection via an MDI-X Port
You can connect any RJ-45 (MDI-X) station port on the hub to any device that
uses a standard network interface such as a PC or server. You can also connect
to an MDI-X port of a network interconnection device such as a bridge or router
by using a cross-over cable.
1. Prepare the network devices you wish to network. Make sure you have
installed 10Base-T network interface cards for connecting to the hub’s
RJ-45 (MDI-X) station ports. You also need to prepare straight-through
shielded or unshielded twisted-pair cables with RJ-45 plugs at both ends.
Use 100Ω Category 3, 4, or 5 cable for all RJ-45 connections.
2. Connect one end of the cable to the RJ-45 port of the network interface
card, and the other end to any available (MDI-X) station port on the hub.
When inserting an RJ-45 plug, be sure the tab on the plug clicks into
position to ensure that it is properly seated. Using the hub in a standalone configuration, you can network up to four end nodes.
RJ-45
Connector
Figure 2-3 Inserting an RJ-45 Connector
Compaq HB1004 10Base-T Hub User Guide
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation
2-4
WARNING: Do not plug a phone jack connector into any RJ-45 port.
This may damage the hub. Instead, use only twisted-pair cables with
RJ-45 connectors
.
NOTES:
1. Make sure each twisted-pair cable does not exceed 100 meters (328 feet)
2. When using Port 4 as an MDI-X port, set the port selection switch to MDI-X
Making a Connection via the MDI/MDI-X Port
(Port 4)
1. To make a direct connection to a compatible hub or switch, use the
MDI/MDI-X port (Port 4). When connecting to this port, remember to
set the port selection switch to MDI. You can also connect any RJ-45
(MDI-X) port on the hub to an MDI/MDI-X port on the other device
when the other device’s port is set to MDI.
2. Prepare straight-through shielded or unshielded twisted-pair cables with
RJ-45 plugs at both ends. Use 100Ω Category 3, 4, or 5 cable for all RJ-
45 connections. When inserting an RJ-45 plug, be sure the tab on the
plug clicks into position to ensure that it is properly seated.
NOTES:
1. To connect to another hub or switch, you may also attach to (MDI-X)
station ports at both ends if you use a crossover cable.
2. When using Port 4 as an MDI port, set the port selection switch to
MDI.
3. When connecting to another 10Mb/s hub, you can cascade up to four
hubs, and use up to 100 meters (328 feet) of cable between each
inter-hub link.
Powering On the Hub
1. Plug the power cord into the power socket at the rear of the hub, and the
other end into a power outlet (see Figure 2-4).
2. Turn on the power switch on the back of the hub ( I = on; 0 = off).
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-5
I
O
Figure 2-4 Connecting the Power Cord
3. Check the LED marked PWR on the front panel to see if it is on. The
unit will automatically select the setting that matches the connected
input voltage. Therefore, no additional adjustments are necessary when
connecting it to any input voltage within the specified range. See
Appendix A for power requirement s .
4. The hub performs a self-diagnostic test upon power-on.
Compaq HB1004 10Base-T Hub User Guide
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation
2-6
Diagnostic Tests
After power on, the hub automatically performs a diagnostic self-test. During
this test, port status LEDs indicate the success or failure of each test.
The system tests each component one at a time. At the completion of the test, if
no diagnostic LEDs are lit, then all components passed the test. If a component
fails the test, the corresponding LED will continue blinking. The following
table identifies the component that corresponds to each diagnostic test LED.
Figure 2-5 Power On Self Test Diagnostic LEDs
Table 2-1
LED Diagnostic Test Functions
LED Series LED Number Test Function/Component
Partition/Disable 1 CPU
2 Flash ROM 1
3SRAM
4 LAN Controller
Link/Activity 1 HUB Controller
2 Serial Port RS232 Controller
3 EEPROM
4 Flash ROM 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-7
Verifying Hub and Port Status
After the hub completes the POST, you can check hub activity and each
connection by comparing the indicators with Table 2-2.
Figure 2-6 HB1004 Hub and Port LEDs
Table 2-2
Hub and Port LED Indicators
LED State Indication
Power On Hub receiving power, CPU running
Utilization% On Number of LEDs lit indicates percentage of LAN bandwidth used
Collision% On Two or more devices attempted to transmit data at the same time,
number of LEDs lit indicates percentage of collisions
Link/Activity On Port has established a valid network connection
Flashing Port is receiving packets; blinking proportional to traffic
Partition/Disable On Port partitioned due to an abnormal network condition
Flashing Port has been disabled by management
Off Port is operating normally
Table 1-1 in Chapter 1 explains the LED system for indicating percentages for
Utilization and Collisions.
Compaq HB1004 10Base-T Hub User Guide
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation
2-8
Applications
This hub is not only designed to provide network access for 10Mb/s
connections, but also to provide options in setting up network connections. It
can be used as a simple stand-alone hub or can be cascaded to any compatible
hub or switch. A sample configuration diagram is shown in Figure 2-7.
Figure 2-7 A Sample Application Using the HB1004 10Base-T Ethernet Hub
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-1
Chapter 3
Setup and Configuration
Preparing for Configuration
Management
There are two methods for configuring the Compaq HB1004 - u sing the out-ofband program or using in-band network management software (not supplied).
The diskette included with the Compaq HB1004 contains the menu-driven
Compaq HB1004 System Configuration Program. To use this program, make a
direct PC or modem connection to the serial port on the front of the hub.
Out-of-Band Connection
Out-of-band configuration requires a computer as your workstation. There are
two valid connection types to the hub:
Out-of-band onsite connection - The workstation, normally within the
Q
vicinity of the hub, is directly connected to the serial port on the hub.
Out-of-band modem connection - The workstation is connected to the
Q
remote hub via a modem.
Onsite Connection
Attach a PC to the serial port on the hub. Use the communication cable (and
DB9 to RJ-45 converters) provided with this package. Configure the PC’s
serial port for 9600 baud, 8 bits, no parity, and one stop bit (9600, 8, N, 1). See
Figure 3-1.
: Some PCs may have a 25 pin serial port. For these PCs use the DB25 to
NOTE
RJ-45 converter supplied with the hub instead of the DB9 to RJ-45 converter
mentioned above to connect the PC.
Compaq HB1004 10Base-T Hub User Guide
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setup and Configuration
3-2
Figure 3-1. Out-of-Band Connection Using an Onsite PC
Modem Connection
Connect the COM port on the hub to the serial port on the modem. Use the
communications cable provided with the hub and DB9/25 to RJ-45 converters
as needed. At the remote site, connect the PC’s COM port to the remote
modem. Configure the PC’s COM port and the modems for 9600 baud, 8 bits,
no parity, and one stop bit (9600, 8, N, 1). See Figure 3-2.
Figure 3-2. Out-of-Band Connection Using a Remote PC and Modem
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-3
In-Band Connection
You can configure and manage the hub through the network (in-band) by using
a network management application (not supplied). However, before you can
access the hub with an in-band connection you must use an out-of-band
connection and the Compaq HB1004 System Configuration Program to
configure the hub’s IP address, subnet mask, and default gateway.
Starting the Configuration Program
To open the Compaq HB1004 System Configuration Program, do the
following:
1. Determine which operating system you are using and follow the proper
instructions to start the HB1004 System Configuration Program.
To start the Compaq HB1004 System
Configuration Program from MS-DOS:
1. Insert the Compaq HB1004 Configuration Program diskette into the
floppy disk drive
2. At the command prompt, type A:\HB1004CP for Drive A or
B:\HB1004CP for Drive B
3. Press ENTER and the program will start by opening the
communication dialog box shown in Figure 3-3.
The Compaq HB1004 System Configuration Program allows selection of
NOTE:
COM Ports 1, 2, 3 or 4 and assumes the normal default IRQ for the appropriate
port (i.e. COM1 is IRQ4, COM2 is IRQ3, COM3 is IRQ4 and COM4 is IRQ3). If
your communication port is configured differently, it is necessary to specify the
correct IRQ for that port. If this is the case, type:
A:\HB1004CP /i[irq#] or B:\HB1004CP /i[irq#]
at the command prompt.
Compaq HB1004 10Base-T Hub User Guide
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setup and Configuration
3-4
To start the Compaq HB1004 System
Configuration Program from
Windows:
1. Insert the Compaq HB1004 Configuration Program diskette into the
floppy disk drive
2. In File Manager or Program Manager, click File, then click Run
3. Type A:\HB1004CP for Drive A or B:\HB1004CP for Drive B
in the Command Line box
4. Click the OK button to open the program and display the
communication dialog box shown in Figure 3-3.
: The Compaq HB1004 System Configuration Program allows selection of
NOTE
COM Ports 1, 2, 3 or 4 and assumes the normal default IRQ for the appropriate
port (i.e. COM1 is IRQ4, COM2 is IRQ3, COM3 is IRQ4 and COM4 is IRQ3). If
your communication port is configured differently, it is necessary to specify the
correct IRQ for that port. If this is the case, type:
A:\HB1004CP /i[irq#] or B:\HB1004CP /i[irq#]
In the Command Line box.
To start the Compaq HB1004 System
Configuration Program from
Windows 95 or Windows 98:
1. Insert the Compaq HB1004 Configuration Program diskette into the
floppy disk drive
2. Click the Start button in the lower left corner of the screen
3. Click Run...
4. Type A:\HB1004CP for Drive A or B:\HB1004CP for Drive B
in the Open box
5. Click the OK button to open the program and display the
communication dialog box shown in Figure 3-3.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-5
The Compaq HB1004 System Configuration Program allows selection of
NOTE:
COM Ports 1, 2, 3 or 4 and assumes the normal default IRQ for the appropriate
port (i.e. COM1 is IRQ4, COM2 is IRQ3, COM3 is IRQ4 and COM4 is IRQ3). If
your communication port is configured differently, it is necessary to specify the
correct IRQ for that port. If this is the case, type:
A:\HB1004CP /i[irq#] or B:\HB1004CP /i[irq#]
in the
Figure 3-3 Communication Port Dialog Box
2. Using arrow keys, select the workstation’s communication port
connected to the hub and press <Enter>. The DCE/DTE dialog box
appears as shown in Figure 3-4.
Open
box.
Compaq HB1004 10Base-T Hub User Guide
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setup and Configuration
3-6
Figure 3-4 DCE/DTE Dialog Box
3. Select the appropriate option in the DCE/DTE dialog box:
Terminal Channel for local hookup, opens the Main Menu as
Q
shown in Figure 3-6.
Modem Channel for remote connection via modems.
Q
If you are using a modem connection, select Modem Channel to open
the Phone List menu as shown in Figure 3-5. Enter the phone number
and press <Enter>to start the dialing mechanism
Figure 3-5 Phone List Menu
.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-7
Once the connection is established, the Main Menu for out-of-band
configuration appears as shown in Figure 3-6.
Figure 3-6 Main Menu
4. Select any of the displayed menu items as described in the following
section. Table 3-1 describes each of the Main Menu items.
Compaq HB1004 System
Configuration
The Compaq HB1004 provides a proprietary, user-friendly, menu driven outof-band program (Compaq HB1004 System Configuration Program). This
program allows you to configure the hub using a PC directly attached to the
RS232 port on the front of the hub,
RS232 port. With this program you can define system parameters, manage and
control the hub and associated ports, and monitor network conditions. Table 3-1
briefly describes the menu selections available for this program.
or remotely via a modem connected to the
Compaq HB1004 10Base-T Hub User Guide
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setup and Configuration
3-8
Table 3-1
Main Menu
Menu Item Description
Information Defines description for the system
Configuration Sets system parameters
Trap Managers Configures Communities and IP trap managers
Port Control Includes port description and command to
enable/disable selected ports
Network Status Displays port statistics
Download Downloads new version of firmware to update your
system
Restart Restarts your system
Factory Setting Reverts all configuration selections to factor y default
settings
Save Configuration Saves configuration changes made during current
session
Reset Configuration Restores the last saved configuration settings
Help Tells what each menu option does
Exit Exits the configuration program
Common Menu Functions
Many of the HB1004 System Configuration Program sub menus have common
keys for navigating through the menus and setting menu options. Table 3-2
describes the common key functions. Not all functions are available to all sub
menus. The bottom of each sub menu identifies the functions available to that
sub menu.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-9
Table 3-2
Common Menu Key Functions
Key Function
F1 Help – Displays help for the current menu
F2 Modify – Changes the value in a modifiable field
F3 Set – Sets the menu field selections as the current
settings (see System Configuration Settings)
F6 Refresh – Refreshes the display in the menu
ESC Exit – Exits the current menu and returns to the
previous menu. Exits the program from the Main Menu
TAB Move the cursor to the next field
System Configuration Settings
The HB1004 hub maintains three sets of configuration settings:
Current configuration settings
Q
Last Saved configuration settings
Q
Factory Default configuration settings
Q
The hub always operates using the Current configuration settings. Any changes
you make to the hub’s configuration are kept as the Current configuration
settings. When you exit from the configuration program those changes are not
lost, even if you do not save them. Current configuration settings will remain in
place until you change them again.
Once you save a configuration it is loaded into the Last Saved configuration
settings. You can return to these settings at any time by selecting Reset
Configuration from the Main Menu. At that time the Last Saved configuration
becomes the Current configuration.
Compaq HB1004 10Base-T Hub User Guide
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setup and Configuration
3-10
The Factory Default configuration settings never change and are always
available to apply to the hub. When you select Factory Setting from the Main
Menu the Factory Default configuration is loaded into the Current
configuration. See Table B-3 in Appendix B for a list of all factory default
settings.
Displaying System Information
Use the Information command to display and modify system information about
the hub, or for quick system identification. View a description of the system:
Figure 3-7. System Information Screen
System Description – Identifies the hub
Q
System Uptime - Length of time the management agent has been running
Q
System Name – User-defined name for the hub
Q
Contact - Contact person for the system
Q
Location - Specifies the area or location where the system resides
Q
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing System Configuration
Parameter Description
Use the Configuration command from the Main Menu to modify current values
for the following parameters:
Figure 3-8. System Configuration Screen
IP Address - IP address of the HB1004 agent. The agent runs the SNMP
Q
protocol over the UDP/IP transport protocol. In this environment, all
systems on the Internet, such as network interconnection devices are
assigned an IP address.
3-11
MAC Address - Hardware address of the agent. The MAC address can
Q
also be found on a sticker on the front panel of the hub above the COM
port.
Subnet Mask - Subnet mask of the agent you’ve selected. This mask
Q
identifies the host address bits used for routing to specific subnets.
Default Gateway - Default gateway used in passing trap messages from
Q
the hub agent to the management station.
TFTP Server IP – Sets the TFTP server IP address.
Q
TFTP-Download File – Specifies the download file name.
Q
Compaq HB1004 10Base-T Hub User Guide
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setup and Configuration
3-12
Assigning Trap Managers
Use the Trap Managers command from the Main Menu to modify current
values for the following parameters:
Figure 3-9. Trap Managers Screen
SNMP Community Names - The community strings authorized for trap
Q
management access. All community strings used for IP Trap Managers
must be listed in this table.
Community Name - A community entry authorized for trap
management access.
Access Management - access is restricted to read-only (RO) or
read/write (RW).
Status - The status of the current entry can be set to VALID or
INVALID.
IP Trap Managers - IP management stations selected to receive trap
Q
messages from the HB1004 agent.
IP Address - IP address of the management station.
Community Name - The community string required for trap
management access.
Status - The status of the current entry can be set to VALID or
INVALID.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Configuring Port Parameters
Parameter Description
Use the Port Control command to configure the ports. This menu provides a
brief description of the hub, and also allows you to enable/disab le any port on
the hub.
Figure 3-10. Port Control Screen
Port Identifier - Numeric identifier 1 to 4.
Q
Name - User-defined name for selected port.
Q
Type - Connection type is 10BASE-T (RJ-45)
Q
Status - Any port may be ENABLED or DISABLED.
Q
3-13
Network Performance
Variable Description 1
Part - Indicates if the port is partitioned.
Q
Link State - Indicates if the port has a valid connection to an external
Q
device.
The Network Status screen displays statistics for each of the hub ports. The last
line shows total statistics for the hub and is the sum of all of the port statistics.
Figure 3-11. Network Status Screen
Compaq HB1004 10Base-T Hub User Guide
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setup and Configuration
3-14
Frames - Number of frames passing through this port or hub.
Q
Bytes - Number of bytes passing through this port or hub.
Q
Collisions - Number of simultaneous node transmissions detected by this
Q
port or hub.
Alignment Errors - Number of mis-synchronized data packets detected
Q
by this port or hub.
CRC Errors - Number of Ethernet Cyclic Redundancy Code errors
Q
detected by this port or hub.
Total Errors - Total number of errors, including CRC, alignment,
Q
FramesTooLong, ShortEvents, LateEvents, Jabber, and
DataRateMismatches detected on this port or hub.
: The values displayed have been accumulated since the last system reboot
NOTE
or counter reset.
Downloading System Software
Parameter Description
Use the Download command from the Main Menu to load available software
updates into the agent’s flash ROM. The download file should be a .bin file;
otherwise the agent will not accept it. Also, the Timeout and Retry fields must
have a non-zero entry.
Figure 3-12. Download Screen
Invoking this command brings up the Download dialog box. When all entries
are confirmed, the display will change to show the progress of the download
process. After downloading the new software, the agent will automatically
restart. The following describes each entry in the dialog box:
Timeout - Time to wait for a response.
Q
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-15
Retry - Number of attempts to make contact.
Q
Filename - The *.bin file to download.
Q
Transferred Block - Current number of data block being transferred.
Q
Total Blocks - Total number of blocks to transfer.
Q
Restarting the Agent
Use the Restart command from the Main Menu to reset the agent. LEDs on the
agent will light up sequentially as it executes the initialization test. This will
also reset the statistics counter to 0 (zero).
Reverting Configuration to Factory Settings
Use the Factory Settings command from the Main Menu to change all
configuration settings back to the factory defaults. See Table B-3 in Appendix
B for a list of all factory default settings.
Saving a New Configuration
The Save Configuration option saves any changes you have made to the hub’s
configuration. The hub will use the new configuration each time it boots up
until you change it again.
Resetting the Configuration
The Reset Configuration option returns the hub to the last saved configuration.
See Page 3-7 for an explanation of the different system configuration settings.
Help
Use the Help option to get a brief description of each of the Main Menu
options.
Compaq HB1004 10Base-T Hub User Guide
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A-1
Appendix A
Specifications
HB1004 10Base-T Ethernet Hub
Access Method - CSMA/CD, 10 Mbps
Q
Standards Conformance - IEEE 802.3 10BASE-T
Q
Communication Rate - 10 Mbps
Q
Media Supported - 100Ω Category 3, 4, or 5 UTP/STP
Q
Number of Ports - 4 RJ-45 ports
Q
Indicator Panel LEDs for monitoring power, utilization, collisions,
Q
partition/disable, link/activity
Dimensions - 440 x 171 x 43 mm (17.32 x 6.73 x 1.69 in)
Q
Weight - 2.42 kg (5.34 lb)
Q
Input Power - 100~240 VAC, 50/60 Hz (built-in full-range power
Q
module)
Power Consumption – (typical) 13 Watts @ 240VAC
Q
Heat Dissipation – (typical) 44.4 BTU/hr @ 240VAC
Q
Environmental
Q
Temperature – Operating: 0°C to 40°C (32 to 104°F)
Storage: 0°C to 60°C (32 to 140°F)
Humidity – Operating/Storage: 5% to 95% (non-condensing)
Altitude – Operating: 0 to 3 km (0 to 10,000 ft)
Storage: 0 to 9 km (0 to 30,000 ft)
Certification CE Mark
Q
Emissions CISPR 22 Class A
Q
Immunity IEC 1000-4-2/3/4
Q
Safety TÜV/GS
Q
Compaq HB1004 10Base-T Ethernet Hub
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications
A-2
Network Criteria
Hub-to-Workstation Distance 100 meters maximum using twisted-pair
Q
cable.
Inter-hub Distance (MDI Port) 100 meters using twisted-pair cable (4
Q
hub cascade).
Total Network Span
Q
Single Hub 200 meters of twisted-pair cable (100 meters to each
attached node).
4-hub Chain (MDI Port) 500 meters of twisted-pair cable (100
meters to each attached node and between hubs).
Management Support
System Configuration
Q
Out-of-band configuration via PC or modem connection to serial
COM port.
In-band full-featured SNMP management using network
management software (not provided) over a LAN connection.
Management Agent – SNMP support including MIB II (RFC1213),
Q
repeater MIB (RFC1516), and Compaq private MIB.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B-1
Appendix B
Troubleshooting
Diagnosing Hub Indicators
The hub can be easily monitored through panel LED indicators to assist the
network manager in identifying problems. This section describes common
problems you may encounter and possible solutions.
Table B-1
Diagnosing Hub Indicators
Symptom Cause Solution
Power indicator does not light
up (green) after power on
Defective power outlet, power
cord, or internal power supply
Check the power outlet by plugging in another
device that is functioning properly. Check the
power cord with another device. If these
measures fail to resolve the problem, contact
Compaq Technical Support at 1678-23143
Link indicator does not light
up (green) after making a
connection
Network interface (e.g., a network
adapter card on the attached
device), network cable, or hub
port is defective
Verify that the hub and attached device are
powered on. Be sure the cable is plugged into
both the hub and attached device. Check the
adapter on the attached device and cable
connections for possible defects. See if your
cable is functioning properly by using it for
another port and attached device that displays
valid indications when connected to the
network. Replace the defective adapter or
cable if necessary. Also verify that you have
not exceeded specified limits for any attached
media.
Compaq HB1004 10Base-T Ethernet Hub
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting
B-2
Power and Cooling Problems
If the power indicator does not turn on when the power cord is plugged in, you
may have a problem with the power outlet, power cord, or internal power
supply as explained in the previous section. However, if the unit powers off
after running for a while, check for loose power connections, power losses or
surges at the power outlet, and verify that the fan on back of the unit was
unobstructed and running prior to shutdown. If you still cannot isolate the
problem, then the internal power supply may be defective. In this case, contact
Compaq Technical Support at 1678-23143.
Installation
Verify that all system components have been properly installed. If one or more
components appear to be malfunctioning (e.g., the power cord or network
cabling), test them in an alternate environment where you are sure that all the
other components are functioning properly.
Port and Cable Assignments
RJ-45 hub ports (MDI-X) can be attached to any device that uses a standard
network interface (e.g., a workstation or server). Similar networking devices
(e.g., another hub or switch) can be cascaded by connecting any of the RJ-45
ports (MDI-X) on the HB1004 hub to an MDI port on the other device. You
can also set Port 4 on the HB1004 hub to MDI and connect to an MDI-X port
on the other device. Use 100Ω Category 3, 4, or 5 twisted-pair cable,
unshielded or shielded (UTP/STP), for all RJ-45 connections. Also be sure that
the length of any twisted-pair connection does not exceed 100 meters (328
feet).
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B-3
Table B-2
RJ-45 Port Pin Assignments
Pin Assignment
1 Input Receive Data + Output Transmit Data +
2 Input Receive Data - Output Transmit Data 3 Output Transmit Data + Input Receive Data +
6 Output Transmit Data - Input Receive Data -
4, 5, 7, 8 Not Used Not Used
Twisted Pair Cable
Figure B-1 shows the wiring for Straight-Through and Crossover twisted-pair
cable.
(Hub)
1 IRD+
2 IRD3 O TD +
6 O TD -
(Hub Ports 1 – 4)
Straight-Through
(Adapter)
1 O TD +
2 O TD 3 IRD+
6 IRD-
(Hub)
1 IRD+
2 IRD3 O TD +
6 O TD -
Assignment
(MDI/MDI-X Port, other Device)
Crossover
(Hub)
1 IRD+
2 IRD3 O TD +
6 O TD -
Figure B-1 Straight-through and Crossover UTP cables
Compaq HB1004 10Base-T Ethernet Hub
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting
B-4
Using Diagnostic Mode
When you power up the HB1004 hub, the unit executes a self-test. If the
management agent fails the self-test the unit will not become active and the
diagnostic LED will remain lit. Run the Compaq HB1004 System
Configuration Program to open the Diagnostic Mode Main Menu. The
Diagnostic Mode provides a limited set of tools to assist you in resolving the
problem and getting the unit operational. Figure B-2 shows the Diagnostic
Mode Main Menu screen.
Configuration
Select Configuration to view and modify the hub configuration parameters. See
Chapter 3 “Changing System Configuration” for an explanation of the entries in
this screen shown in Figure B-3.
Figure B-2. Diagnostic Mode Main Menu
Figure B-3. Diagnostic Mode Configuration Screen
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B-5
Download
The Download option allows you to download softwa re to the agent’s flash
ROM. The Diagnostic Mode Download operation and screen is the same as for
normal mode. See Chapter 3 “Downloading System Software” for information.
Factory Settings
This option allows you to reset all hub settings to the default factory
configuration. The Diagnostic Mode Factory Settings operation and screen is
the same as for normal mode.
Table B-3
Factory Default Settings
Description MIB Object Factory Setting
Contact Name sysContact
Unit Name sysName/usUnitName Blank
Compaq Computer Corporation,
1-800-652-6672
Location sysLocation Blank
SNMP Access Traps snmpEnableAuthenTraps enabled
Port Enable Status rptrPortAdminStatus All Ports Enabled
Access Community String usCommunityString public in first entry
Access Mode usCommunityAccessMode All R/W
Community Status usCommunityStatus Only First Valid
Trap Receiver IP Address usTrapRcvrIPAddress All are set to 0.0.0.0
Trap Receiver Status usTrapRcvrStatus All Invalid
Download Server IP Address usDownloadServerIP Set to 0.0.0.0
Agent IP Address usAgentIP Set to 0.0.0.0
Agent Network Mask usAgentNetMask Set to 0.0.0.0
IP Gateway usAgentGateway Set to 0.0.0.0
Port Names usPortName All entries Blank
Compaq HB1004 10Base-T Ethernet Hub
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting
B-6
Help
The Help option provides a brief description of the Diagnostic Mode Maim
Menu options.
Exit
Exits the Diagnostic Mode and returns to DOS.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
C-1
Appendix C
Certification and Compliance
European Union (EU) Notice
Products with the CE Marking comply with both the EMC Directive (89/336/EEC) and the Low Voltage
Directive (73/23/EEC) issued by the Commission of the European Community.
Compliance with these directives implies conformity to the following European Norms (in brackets are
the equivalent international standards):
EN55022 (CISPR 22) - Electromagnetic Interference
■
EN50082-1 (IEC801-2, IEC801-3, IEC801-4) - Electromagnetic Immunity
■
EN60950 (IEC950) - Product Safety
■
CAUTION:
this device. Les raccordeurs ne sont pas utilisé pour le système téléphonique!
Do not plug a phone jack connector in the RJ-45 port. This may damage
Safety Compliance
Wichtige Sicherheitshinweise (Germany)
1. Bitte lesen Sie diese Hinweise sorgfältig durch.
2. Heben Sie diese Anleitung für den späteren Gebrauch auf.
3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen.
Verwenden Sie keine Flüssigoder Aerosolreiniger. Am besten eignet
sich ein angefeuchtetes Tuch zur Reinigung.
4. Die Netzanschluß steckdose soll nähe dem Gerät angebracht und leicht
zugänglich sein.
5. Das Gerät ist vor Feuchtigkeit zu schützen.
6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten. Ein
Kippen oder Fallen könnte Beschädigungen hervorrufen.
Compaq HB1004 10Base-T Ethernet Hub
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Certification and Compliance
C-2
7. Die Belüftungsöffnungen dienen der Luftzirkulation, die das Gerät vor
Überhitzung schützt. Sorgen Sie dafür, daß diese Öffnungen nicht
abgedeckt werden.
8. Beachten Sie beim Anschluß an das Stromnetz die Anschlußwerte.
9. Verlegen Sie die Netzanschlußleitung so, daß niemand darüber fallen
kann. Es sollte auch nichts auf der Leitung abgestellt werden.
10. Alle Hinweise und Warnungen, die sich am Gerät befinden, sind zu
beachten.
11. Wird das Gerät über einen längeren Zeitraum nicht benutzt, sollten Sie
es vom Stromnetz trennen. Somit wird im Falle einer Überspannung
eine Beschädigung vermieden.
12. Durch die Lüftungsöffnungen dürfen niemals Geg e nstände oder
Flüssigkeiten in das Gerät gelangen. Dies könnte einen Brand bzw.
elektrischen Schlag auslösen.
13. Öffnen sie niemals das Gerät. Das Gerät darf aus Gründen der
elektrischen Sicherheit nur von authorisiertem Servicepersonal geöffnet
werden.
14. Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz zu
trennen und von einer qualifizierten Servicestelle zu überprüfen:
a. Netzkabel oder Netzstecker sind beschädigt.
b. Flüssigkeit ist in das Gerät eingedrungen.
c. Das Gerät war Feuchtigkeit ausgesetzt.
d. Wenn das Gerät nicht der Bedienungsanleitung entsprechend
funktioniert oder Sie mit Hilfe dieser Anleitung keine Verbesserung
erzielen.
e. Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt.
f. Wenn das Gerät deutliche Anzeichen eines Defektes aufweist.
15. Zum Netzanschluß dieses Gerätes ist eine geprüfte Leitung zu
verwenden. Für einen Nennstrom bis 6A und einem Gerätegewicht
größer 3kg ist eine Leitung nicht leichter als H05VV-F, 3G, 0.75mm2
einzusetzen.
Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt
70dB(A) oder weniger.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
I-1
Index
A
Access Management 3-12
Alignment Errors 3-14
C
Category 3 2-3, 2-4
Check LED marked PWR 2-5
COM Ports 1 3-3, 3-4, 3-5, 3-11
Command Line box 3-4
Communication
cable 1-2, 3-1, 3-2
dialog box 3-3, 3-4
port 3-3, 3-4, 3-5
Port Dialog Box 3-5
Community Name 3-12
Compaq private MIB 1-1
Connection type 3-13
CPU 2-6, 2-7
CRC 3-14
D
DB9 connector 1-3
DCE/DTE dialog box 3-5, 3-6
Default gateway 3-11
Diagnostic self-test 2-6
E
EIA 19 inch rack 2-2
Electromagnetic interference 2-1
F
Factory default settings 3-9, 3-10,
3-15
File Manager 3-4
Firmware 3-8
H
Hardware address 3-11
I
IEEE 802.3 1-1
In-Band Connection 3-3
Initialization test 3-15
Internet 3-11
IP
address 3-11, 3-12
trap managers 3-12
IRQ 3-3, 3-4, 3-5
J
Jack connector 2-4
L
LAN 2-6
LAN bandwidth 2-7
Last saved configuration 3-9
LED
indicators 1-3
system 2-7
Link state 3-13
M
MAC Address 3-11
Main Menu 3-6, 3-7, 3-9, 3-10, 3-11,
3-12, 3-14, 3-15
Management
software 3-1
station 1-1, 3-11, 3-12
MDI
port 2-4
position 1-5
MDI/MDI-X
port 2-3, 2-4
slide switch 1-3, 1-5
Compaq HB1004 10Base-T Hub User Guide
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Index
I-2
MDI-X
port 2-3, 2-4
position 1-5
support 1-1
Modem Channel 3-6
N
Network Status screen 3-13
Numeric identifier 1 3-13
O
Open box 3-4, 3-5
Operational modes 1-3
Out-of-Band connection 3-1, 3-2
P
Phone List menu 3-6
Pin serial port 3-1
Pinout 1-3
MDI 1-3, 1-5
MDI-X 1-3, 1-5
Port Identifier 3-13
Port RS232 2-6
Program Manager 3-4
SNMP
Community Names 3-12
compliant network management
software 1-1
protocol 3-11
support 1-1
V1-compliant firmware 1-1
Software updates 3-14
SRAM 2-6
Sub menu 3-8
Subnet mask 3-11
System
Description 3-10
Name 3-10
Uptime 3-10
T
Terminal Channel 3-6
TFTP
download file 3-11
server IP address 3-11
Trap management access 3-12
Trap managers 3-8
Trap messages 3-11, 3-12
U
R
RJ-45
10Base-T ports 1-1
connections 2-3, 2-4
converter 3-1, 3-2
plug 2-3, 2-4
port 1-3, 2-3, 2-4
Rubber feet 1-2
S
Save Configuration option 3-15
Self-diagnostic test 2-5
UDP/IP transport protocol 3-11
UTP cabling 1-3
V
Ventilation 2-1
W
Warranty guide 1-2
Windows 95 3-4
Windows 98 3-4
Loading...
