Overview

At A Glance

AlphaServer™/AlphaStation ™

ES40 Systems include:

•

Alpha 21264 68/833-MHz CPU with 8-MB L2 Dual Data Rate Cache

•

6-10 64-bit PCI I/O expansion slots

•

512-MB, 1-GB, 2-GB, or 4-GB memory options (AlphaServers)

•

512-MB memory option (AlphaStations)

•

1.44-MB diskette drive

•

600-MB 48X IDE CD-ROM drive

•

Two 9-pin serial ports

•

One 25-pin parallel port

•

RMC dedicated serial port, 6-pin MMJ connector

•

Dual USB ports

•

Keyboard and mouse port

•

Knockouts for two 68-pin SCSI connections

•

Auto-sensing power supply

•

Integral remote system management console

•

Customer documentation

•

Tru64™ UNIX™ or OpenVMS™

Factory Installed Software

•

90-day software warranty

•

Protected by HP Services, including three-year hardware warranty, on-site with 5 x 9 next business day response

Compaq AlphaServer ES40

Compaq AlphaStation ES40

DA-10392 North America — Version 57 — March 18, 2003

QuickSpecs

Standard Features

Compaq AlphaServer ES40

Compaq AlphaStation ES40

Processor

Cache Memory

Upgradability Supports additional processors and upgrades of memory and hard drives

Memory

Network Controller

Expansion

Storage

Interfaces

Graphics

Form Factor Tower, Pedestal, Rackmount (M-Series Cabinet)

Power Supply

Manageability

OS Support

Service and Support

Alpha 21264 68/833-MHz CPU

8-MB L2 Dual Data Rate Backup Cache (68/833-MHz CPU)

Minimum

Maximum

Choice of Ethernet controllers

PCI I/O slots

Diskette Drive CD-ROM Hard Drives

Parallel Serial USB Keyboard Mouse Remote systems management SCSI connections

Optional

Auto sensing power supply, hot swappable, N+1 (see Step 4)

Compaq Insight Manager™

AlphaServer ES40 Tru64 UNIX systems include pre-installed software, Base license, Unlimited User license, Server Extension license, Internet Express, and Secure Web Server

AlphaStation ES40 Tru64 UNIX systems include pre-installed software, 2-user Base license and Compaq Open3D traditional license

AlphaServer ES40 OpenVMS systems include pre-installed software, Base license with System Manager license and Enterprise Integration Server License Package for OpenVMS V3.1

AlphaStation ES40 OpenVMS systems include pre-installed software, Base license, Concurrent Use 1-user license, NAS 150 Client license, Compaq MMS RT license and Compaq Open3D traditional license

Minimum OS support − Tru64 UNIX V4.0F, OpenVMS V7.2-2, Linux RedHat V6.2, Linux SuSE V6.3 or greater

Protected by HP Services including a three-year on-site hardware warranty with next business day response. Software warranty is a 90-day telephone advisory. Training, consulting, network integration, software support, comprehensive system maintenance and guaranteed uptime services are also available for customers requiring higher levels of service and support.

512 MB – AlphaServer ES40 Model 1 512 MB – AlphaStation ES40 1 GB – AlphaServer ES40 Model 2 16 GB (16 DIMM slots) Model 1; 32 GB (32 DIMM slots) Model 2 (see Step 3)

6 slots Model 1; 10 slots Model 2

1.44-MB diskette drive in dedicated slot 600-MB 48X IDE CD-ROM Choice of 18.2-GB, 36.4-GB, 72.8-GB, or 146-GB drives

1 25-pin parallel port 2 9-pin serial ports Dual USB ports 1 port 1 port 1 dedicated remote systems management port Two 68-pin SCSI connections knockouts

DA-10392 North America — Version 57 — March 18, 2003

QuickSpecs

Systems/Options

Step 1 −−−− Select system AlphaServer ES40 systems require the mandatory selection of the following items:

• Disk drive cage or StorageWorks™ shelf (Step 5)

• System disk drive (Step 5)

• System enclosures: Tower, Pedestal, or Rack Kit (Step 6)

• Ethernet adapter (Step 8)

• Storage adapter (Step 10)

• Software media and documentation for first system onsite

NOTES: ES40 Model 1 to Model 2 Upgrade Kit available − see Step 16.

Only 2-5-2 part numbers are factory integrated.

AlphaServer ES40 Systems

ES40 OS CPU PCI I/O Slots Memory/Cache Order Number

Model 1 Tru64 UNIX 833 MHz 6 512 MB/8 MB DA-62CAA-CA

Model 1 Tru64 UNIX 833 MHz 6 1 GB/8 MB DA-62CAA-DA

Model 1 Tru64 UNIX 833 MHz 6 2 GB/8 MB DA-62CAA-EA

Model 2 Tru64 UNIX 833 MHz 10 512 MB/8 MB DA-64CAA-CA

Model 2 Tru64 UNIX 833 MHz 10 1 GB/8 MB DA-64CAA-DA

Model 2 Tru64 UNIX 833 MHz 10 2 GB/8 MB DA-64CAA-EA

Model 2 Tru64 UNIX 833 MHz 10 4 GB/8 MB DA-64CAA-FA

Model 1 OpenVMS 833 MHz 6 512 MB/8 MB DY-62CAA-CA

Model 1 OpenVMS 833 MHz 6 1 GB/8 MB DY-62CAA-DA

Model 1 OpenVMS 833 MHz 6 2 GB/8 MB DY-62CAA-EA

Model 2 OpenVMS 833 MHz 10 512 MB/8 MB DY-64CAA-CA

Model 2 OpenVMS 833 MHz 10 1 GB/8 MB DY-64CAA-DA

Model 2 OpenVMS 833 MHz 10 2 GB/8 MB DY-64CAA-EA

Model 2 OpenVMS 833 MHz 10 4 GB/8 MB DY-64CAA-FA

AlphaStation ES40 Systems

Model 2 Tru64 UNIX 833 MHz 10 512 MB/8 MB DA-64CAA-CW

Model 2 OpenVMS 833 MHz 10 512 MB/8 MB DY-64CAA-CW

Compaq AlphaServer ES40

Compaq AlphaStation ES40

DA-10392 North America — Version 57 — March 18, 2003

QuickSpecs

Systems/Options

Step 2 −−−− Additional CPU Modules −−−− Optional

• One CPU included, three additional CPUs are supported

From: To: EV67 667-MHz CPU EV68 833-MHz CPU Upgrade console firmware to V5.9-24 as minimum revision Upgrade system hardware with EV68 CPUs Ensure all system firmware matches console version V5.9-24 EV6 500-MHz CPU EV68 833-MHz CPU

Step 3 −−−− Memory −−−− Optional

• Systems include one memory option

• Model 1 systems supports four memory options (total of 16 DIMMs)

• Model 2 systems support eight memory options (total of 32 DIMMs − see Note below)

• Memory performance considerations: Interleaved operations reduce the average latency and increase the memory throughput over non-

interleaved operations. With one memory option (4 DIMMs) installed, memory interleaving will not occur. With two identical memory options (8 DIMMs) installed, memory read-write operations are two-way interleaved. With four identical memory options (16 DIMMs) installed, memory read-write operations are four-way interleaved, maximizing memory through-put

SMP upgrade, includes one 67/667-MHz CPU with 8-MB cache and Tru64 UNIX SMP license

SMP upgrade, includes one 67/667-MHz CPU with 8-MB cache and OpenVMS SMP license

SMP upgrade, includes one 68/833-MHz CPU with 8-MB cache and Tru64 UNIX SMP license

SMP upgrade, includes one 68/833-MHz CPU with 8-MB cache and OpenVMS SMP license

Upgrade console firmware to V5.9-24 as minimum revision Upgrade system hardware with EV68 CPUs Re-install V5.9-24 console firmware Ensure all system firmware matches console version V5.9-24

512-MB memory option (4 x 128-MB DIMMs)

1-GB memory option (4 x 256-MB DIMMs)

2-GB memory option (4 x 512-MB DIMMs)

4-GB memory option (4 x 1024-MB DIMMs)

NOTE: ES40 configurations that require maximum N+1 power (three power supplies)

are restricted to a maximum of 24-GB of mixed memory (sixteen 1-GB DIMMs and sixteen 512-MB DIMMs). If N+1 maximum power is not required, 32-GB of memory is supported.

Compaq AlphaServer ES40

Compaq AlphaStation ES40

KN610-BB

KN610-BC

KN610-CB

KN610-CC

MS610-CA

MS610-DA

MS610-EA

MS610-FA

DA-10392 North America — Version 57 — March 18, 2003

QuickSpecs

Options

Step 3 −−−− Memory −−−− Optional (continued)

Step 4 −−−− Additional Power Supplies −−−− Required for third and fourth CPUs and/or second Disk Drive Cage

NOTE:

Linux configurations with large memory require the installation of a patch. The patch to support greater than 2 GB of memory per system is located at:

http://www.kernel.org/pub/linux/kernel/people/andrea/patches/v2.2/2.2.17

name: bigmem-2.2.18pre2-18.bz2) The following minimum operating system versions require the patch:

− Linux RedHat V6.2

− Linux SuSE V6.3 (Kernel V2.2.17)

The following operating system minimum versions support greater than 2 GB of memory:

− Linux RedHat V7.0 (installs Kernel V2.2.17)

− Linux SuSE V7.0 (installs Kernel V2.2.16)

When installing Linux SuSE V7.0 on a system with more than 2 GB of memory, user will be prompted for a (ramdisk) floppy. To create a floppy:

− Mount the SuSE V7.0 installation CD-ROM #1 on the system.

− Mount a blank formatted floppy (if not formatted, execute the following

command: fdformat/dev/fd0H1440).

− Change directory, to the ″disks″ directory on the install CD-ROM.

− Execute the following command to create the floppy contents:

dd if=install of=/dev/fd0.

Use this floppy when prompted by the install procedure for a floppy.

• One power supply supports two CPUs, up to 12 memory DIMMs, and one disk card cage; order second power supply if N+1 power is

required.

• Two power supplies support third and fourth CPU, 13 to 32 memory DIMMs (up to 24-GB of memory), and/or two disk card cages; order

third power supply if N+1 power is required for third and fourth CPUs, 24-GB of memory, and/or two disk card cages.

• Three power supplies support 32 GB of memory without N+1 power.

• Three power supplies support a maximum of 24 GB of memory with full N+1 power.

• Each additional power supply ordered with a tower system requires an additional country-specific power cord.

• Pedestal system and Rack kit include three internal power cords regardless of the number of power supplies ordered; Pedestal systems

support 120 V and 240 V power cords.

ES40 720W power supply

Compaq AlphaServer ES40

Compaq AlphaStation ES40

(patch

H7906-A9

DA-10392 North America — Version 57 — March 18, 2003

Compaq AlphaServer ES40

QuickSpecs

Options

Step 5 −−−− Disk Drive Cage or StorageWorks Shelf −−−− Mandatory

Step 5a −−−− Disk Drive Cage −−−− Requires selection of system disk drive Disk Drive Cages

System Disk Drives

(Supported in Disk Drive Cage and

Universal StorageWorks Shelves)

Step 5b −−−− StorageWorks BA36R Shelf − Requires selection of UltraSCSI adapter and SCSI cable (Step 10) and system disk drive

System Disk Drive

(Supported in StorageWorks

BA36R Shelf)

• Tower enclosure supports one system and two disk drive cages

• Pedestal enclosure supports one system and two disk drive cages, two Universal 42xx/43xx StorageWorks shelves or three BA36R

StorageWorks shelves

• M-Series cabinets support five systems each with two disk drive cages and up to six StorageWorks shelves

6-bay disk drive cage with cable for use with 1-inch Universal drives – requires mandatory selection of UltraSCSI adapter and SCSI cable (Step 10) per disk drive cage

6-bay disk drive cage with embedded Ultra2 LVD adapter; supports internal SCSI

niversal drives or tapes only

1-inch U OpenVMS V7.2-2 requires OpenVMS Tima Kit located at:

- http://ftp.support.compaq.com/patches/.new/openvms.shtml Tru64 UNIX V4.0F requires Patch Kit 2 (BL13):

- DUV40FAS0002-19991116.tar

NOTE: See AlphaServer ES40 Configuration Chart for Storage Adapters in Step 10.

18.2-GB Ultra320 SCSI 15,000 rpm 1-inch Universal disk drive

36.4-GB Ultra320 SCSI 10,000 rpm 1-inch Universal disk drive

36.4-GB Ultra320 SCSI 15,000 rpm 1-inch Universal disk drive

72.8-GB Ultra320 SCSI 10,000 rpm 1-inch Universal disk drive

72.8-GB Ultra320 SCSI 15,000 rpm 1-inch Universal disk drive

146-GB Ultra320 SCSI 10,000 rpm 1-inch Universal disk drive

• StorageWorks Shelf supports seven 3.5-inch x 1.6-inch hard disk drives; with addition of redundant power supply, only six drives are

supported

• StorageWorks shelf kits are mounted back-to-back in pedestals and cabinets

StorageWorks UltraSCSI single-bus shelf kit

StorageWorks UltraSCSI split-bus shelf kit;

NOTE: When ordering a split-bus shelf that will be mounted in a Pedestal Enclosure,

order one BN37A-03 cable for KZPCM-DA adapter, BN37A-03 cable for 3X-DEPVZ-AA combo adapter, or one BN38C-03 for 3X-KZPCA-AA or

KZPBA-CA adapter.

3-meter SCSI cable

36.4-GB Wide UltraSCSI 10,000 rpm disk drive

Compaq AlphaStation ES40

BA610-6D

BA610-6E

3R-A3848-AA

3R-A3838-AA

3R-A3849-AA

3R-A3839-AA

3R-A3851-AA

3R-A3841-AA

BA36R-RC

BA36R-RD

BN37A-03

DS-RZ1FC-VW

DA-10392 North America — Version 57 — March 18, 2003

QuickSpecs

Options

Step 5 −−−− Disk Drive Cage or StorageWorks Shelf −−−− Mandatory (continued) Step 5c −−−− StorageWorks Model 4314R and Model 4354R Universal Drive Shelves

StorageWorks Model 4314T Standalone Enclosure for Universal Drives

• StorageWorks Model 4314R and 4354R Ultra2 SCSI (LVD) single-bus and split-

bus Universal drive shelves; refer to StorageWorks Enclosure 4300 Family QuickSpecs when configuring shelves. When selecting a DS-SL13R-xx split-bus shelf, order two UltraSCSI adapters. Model 43xx shelves are compatible with Wide Ultra2 (LVD) adapters only.

• BN38C-05 cable is required per channel if the connection is not VHDCI/VHDCI.

DS-SL13R shelves include one 12-foot VHDCI/VHDCI SCSI cable.

• Note that the depth of a DS-SL13R-xx shelf does not allow front and rear

mounting.

StorageWorks Model 4314R Ultra3 SCSI (LVD) single-bus Universal drive rackmount shelf, includes one power supply, U.S. (190209-0011)

StorageWorks Model 4314R Ultra3 SCSI (LVD) single-bus Universal drive rackmount shelf, includes one power supply, Japan (190209-291)

StorageWorks Model 4354R Ultra3 SCSI (LVD) split-bus Universal drive rackmount shelf, includes two redundant power supplies, U.S. (190211-0011)

StorageWorks Model 4354R Ultra3 SCSI (LVD) split-bus Universal drive rackmount shelf, includes two redundant power supplies, Japan (190211-291)

To add additional power supply for single-bus Universal shelf, U.S. (212980-B21) DS-SE2UP-AA To add additional power supply for single-bus Universal shelf, International

(119826-B31)

Model 4314T Ultra3 SCSI, single-bus tower enclosure, U.S. (190210-001)

Model 4314T Ultra3 SCSI, single-bus tower enclosure, International (190210-B31)

Compaq AlphaServer ES40

Compaq AlphaStation ES40

DS-SL13R-AA

DS-SL13R-AJ

DS-SL13R-BA

DS-SL13R-BJ

DS-SE2UP-AI

DS-SL13T-AA

DS-SL13T-AB

Model 4314T Ultra3 SCSI, single-bus tower enclosure, Japan (190210-291)

DS-SL13T-AJ

DA-10392 North America — Version 57 — March 18, 2003

Compaq AlphaServer ES40

QuickSpecs

Compaq AlphaStation ES40

Options

Step 6 −−−− System Enclosures −−−− Mandatory selection of Tower, Pedestal, or Rack Kit Step 6a −−−− Tower Enclosure

• Tower enclosure supports one system

• Tower enclosure ordered in North America includes 120V power cord; country-specific power cord mandatory for all non-North American

systems; additional power cord mandatory for each power supply ordered with a system installed in a tower enclosure

Step 6b −−−− Pedestal Enclosure

• Pedestal enclosure supports one system, two Universal 43xx StorageWorks shelves or three UltraSCSI BA36R StorageWorks shelves

• Pedestal enclosures (BA61P-PA, 120V/BA61P-PB, 240V) support Universal shelves

• 120V pedestal enclosure includes two external 120V power cords; 240V pedestal enclosure requires two country-specific power cords

• Pedestal enclosure includes two factory-configured power strips that provide five available outlets; if the number of BA356-RC/RD power

supplies requires a sixth outlet, this can be accommodated only if the system chassis is limited to two H7906-A9 power supplies

120V Pedestal Enclosure, includes two external power cords 240V Pedestal Enclosure, requires two country-specific power cords

Step 6c −−−− Rack Kit for M-Series Cabinet

• Rack Kit required for each AlphaServer ES40 system installed in a new or existing M-Series Cabinet

• Rack Kit supports one system

Rack kit for AlphaServer ES40, includes dress bezel, slides, three internal power cords,

NOTE: Factory integration of an ES40 system drawer in a 9000 rackmount cabinet using rack kit, 3X-BA61R-RC, is not supported. Contact

Custom Systems or Compaq Certified Integration Partner.

Step 7 −−−− M-Series Cabinets

M-Series cabinet enclosures support up to four systems, up to six StorageWorks shelves, and/or two BA370 enclosures; M-Series Enclosures require selection of the following items:

• H9A10 or H9A15 cabinet, 120V or 240V

• Rack kit for each system

• H9A10 or H9A15 rear cabinet extender

• Cabinet front door based on cabinet height

• Factory integration

• Ballast kit if only one system is ordered for the H9A15 cabinet

NOTE: For configurations beyond those listed in the following charts, contact CustomSystems.

Tower Enclosure

all bracketry and hardware for mounting in M-Series cabinets

BA61M-MT

BA61P-PA

BA61P-PB

BA61R-RM

DA-10392 North America — Version 57 — March 18, 2003

Compaq AlphaServer ES40

QuickSpecs

Options

Step 7 −−−− M-Series Cabinets (continued) Cabinet Configuration Chart for AlphaServer ES40 (8U) with StorageWorks Shelves (4U)

Cabinet Rack Kit Cabinet

H9A10-MC/MD1

H9A15-MC/MD4

M-Series Cabinets

79-inch cabinet with 71.7-inch or 41U of usable vertical space, 240V dual-16A

Cabinet

Extender

BA61R-RM H9C10-TE 67-inches/34U 1 6 8 6 4

NOTES:

1. Contact CustomSystems for cabinet configurations with four AlphaServer ES40 systems installed in H9C10-MC/MD cabinet.

2. Japan only – 240V cabinet required when using universal shelves

3. When using a combination of BA356 and DS-SL13R shelves in the same cabinet, do not remove the top fan (only remove fan when

4. Installation of one AlphaServer ES40 system in an H9A15 cabinet requires the mandatory selection of a ballast kit.

5. When adding the 5th system drawer, replace H7600-AA or -DB power controller with H7602-EA or -DB power controller. When replacing

2 6 5 6 1

3 2 2 4 0

BA61R-RM H9C15-TE 79-inches/41U 1 6 8 6 5

using DS-SL13R shelves exclusively)

H7600 controllers, replace all associated power cords; order BN35S-4E power cords for H7602-EA and H7602–DB power controllers.

• Required selection of one cabinet

• Two H7600-xx power distribution units are standard in the M-Series cabinet

• For cabinet configurations that require a third power distribution unit (H7600-xx),

67-inch cabinet with 59.5-inch or 34U of usable vertical space, 120V dual-24A controller, each with 10 NEMA 5-15R outlets, input power plug NEMA L5-30P, Americas, Asia Pacific; includes rear door and top fan tray

67-inch cabinet with 59.5-inch or 34U of usable vertical space, 240V dual-16A controller, each with 12 IEC C13 outlets, input power plug IEC 309, 16A, Europe; includes rear door and top fan tray

79-inch cabinet with 71.7-inch or 41U of usable vertical space, 120V dual-24A controller, each with 10 NEMA 5-15R outlets, input power plug NEMA L5-30P, Americas, Asia Pacific; includes rear door and top fan tray

controller, each with 12 IEC C13 outlets, input power plug IEC 309, 16A, Europe; includes rear door and top fan tray

Height/Space

contact CustomSystems at 1-800-282-6672.

Systems BA356 Shelves DS-SL13R 120V

0 0 0 0

2 6 5 6 2

3 6 2 6 0

4 2 0 2 0

0 0 0 0

Compaq AlphaStation ES40

Shelves

BA356/

DS-SL13R3

BA356 DS-SL13R

H9A10-MC

H9A10-MD

H9A15-MC

H9A15-MD

DA-10392 North America — Version 57 — March 18, 2003

QuickSpecs

Options

Step 7 −−−− M-Series Cabinets (continued) Rear Cabinet Extender

Cabinet Front Door

Factory Integration

Ballast Kit

Shelves Supported in M-Series Cabinets

Compaq AlphaServer ES40

Compaq AlphaStation ES40

• Required selection of one cabinet extender for each H9A10 or H9A15 cabinet

Rear cabinet extender, top gun blue, for H9A10-MC/MD cabinets

Rear cabinet extender, top gun blue, for H9A15-MC/MD cabinets

• Required selection of door based on cabinet height

Front door, top gun blue, for H9A10-MC/MD cabinet enclosure

Front door, top gun blue, for H9A15-MC/MD cabinet enclosure

• Required

Factory Integration of systems and storage devices assembled and configured in cabinet enclosure in predefined locations

• Required only if one system is ordered for the H9A15 cabinet

• Ballast is added to a cabinet at particular locations for specific configurations to

meet safety regulations for installation, operation, and service; see Cabinet Configuration Charts.

Two 35 to 40 lb steel plates

• Optional

UltraSCSI single-ended RETMA rack, single-bus personality module, 180W power supply

UltraSCSI single-ended RETMA rack, split-bus personality module, 180W power supply

H9C10-TE

H9C15-TE

H9C10-TF

H9C15-TF

YS-ASCAA-AA

H9C10-MC

BA36R-RC

BA36R-RD

DA-10392 North America — Version 57 — March 18, 2003

Compaq AlphaServer ES40

QuickSpecs

Options

Step 8 −−−− Networking Adapters/C ontrollers Step 8a −−−− Networking Adapters/C ontrollers −−−− Mandatory

Maximum # Supported

Ethernet 10/100 PCI (32-/64-bit, 33-/66-MHz) dual-port 10/100 Ethernet (UTP/RJ45s) NIC and

• Select mandatory Ethernet adapter

• Adapters require a minimum of Tru64 UNIX V4.0F or OpenVMS V7.2-2

• Each adapter uses one PCI slot

NOTE: Ethernet adapter is not required if 3X-DEPVZ-AA or KZPCM is selected as SCSI adapter for StorageWorks shelf.

Base Module. (One 3X-DE602-TA or 3X-DE602-FA optional add-on daughter

card can be combined with this module.)

Use BN25G, BN26M, BN24Q, or BN28Q twisted pair RJ45 cables.

Compaq AlphaStation ES40

Tru64 UNIX OpenVMS Linux

4 4 -

3X-DE602-BB

Multi-function Module 10/100

3X-DEPVZ-AA specific-use 3-meter LVD2 SCSI cable

Step 8b – Networking Adapters/Controllers -- Optional

Maximum # Supported

Ethernet 10/100

PCI (32-bit, 33-MHz) multi-function (single-port 10/100 Ethernet UTP/RJ45, Ultra2 LVD SCSI, and 2D graphics) adapter

NOTE: No support for multi-head graphics.

OpenVMS V7.2-2 requires OpenVMS Tima Kit located at:

- http://ftp.support.compaq.com/patches/.new/openvms.shtml Tru64 UNIX V5.1 requires Patch Kit 3:

- T64V51AS0003-20010413.tar

Tru64 UNIX V4.0F with NHD2 − TruCluster V5.1 support restricted to non-

shared buses Use BN25G, BN26M, BN24Q, or BN28Q twisted pair RJ45 cables.

PCI (32-/64-bit, 33-/66-MHz) single-port 1000 Mbps (MMF/SC) NIC; no onboard Boot-ROM support.

Use BN34A or BN34B cables. PCI (32-/64-bit, 33-/66-MHz) single-port 10/100/1000 (UTP/RJ45)

Gigabit NIC, copper; no on-board Boot-ROM support.

NOTE: Requires minimum version of Tru64 UNIX V5.0A, Patch kit 2:

- T64V50AAS0002-20001004.tar Requires minimum version of OpenVMS V7.2-2; OpenVMS V7.3 Requires Patch kit:

- DEC-AXPVMS-VMS73_LAN-V0100—4.PCSI Use BN25G, BN26M, BN24Q, or BN28Q twisted pair RJ45 cables.

Dual-port 10/100 Ethernet (UTP/RJ45) add-on daughter card for use with the 3X-DE602-BB only. The combined 3X-DE602-BB and 3X-DE602-TA modules provide four 10/100 (UTP/RJ45s) ports in a single PCI slot option; allows for a maximum of 16 ports per system.

NOTE: The 3X-DE602-TA cannot be used as standalone.

OpenVMS V7.3 requires Tima Kit:

- DEC-AXPVMS-VMS73_LAN-V0100—4.PCSI OpenVMS V7.2-2H1 requires OpenVMS Tima Kit located at:

http://ftp.support.compaq.com/patches/.new/openvms.shtml

Use BN25G, BN26M, BN24Q, or BN28Q twisted pair RJ45 cables.

1 1

Requires

Slot 0

Tru64 UNIX OpenVMS Linux

4 4 -

4 4 4

4 4 -

3X-DEPVZ-AA

BN37A-03

DEGPA-SA

DEGPA-TA

3X-DE602-TA

DA-10392 North America — Version 57 — March 18, 2003

Compaq AlphaServer ES40

QuickSpecs

Options

Step 8 −−−− Networking Adapters/C ontrollers (continued) Step 8b – Networking Adapters/Controllers – Optional (continued)

Maximum # Supported

FDDI

Single-port 100Mbps (MMF/duplex-SC) add-on daughter card for use with 3X-DE602-BB. The combined 3X-DE602-BB 3X-DE602-FA provides two 10/100 (UTP/RJ45s) and one 100Mbps (MMF/SC) ports in a single PCI slot option.

NOTE: The 3X-DE602-TA cannot be used standalone.

Use BN34A or BN34B cables.

PCI (32-bit, 33-MHz) to FDDI SAS (MMF/duplex-SC) NIC. Use BN34A, BN34B, or BN34D cables.

PCI (32-bit, 33-MHz) to FDDI DAS (MMF/duplex-SC) NIC. Use BN34A, BN34B, or BN34D cables.

PCI (32-bit, 33-MHz) to FDDI DAS (UTP/RJ45s) NIC. Use BN25G, BN26M, BN24Q, or BN28Q twisted pair RJ45 cables.

PCI (32-bit, 33-MHz) to FDDI SAS (UTP/RJ45) NIC. Use BN25G, BN26M, BN24Q, or BN28Q twisted pair RJ45 cables.

FDDI - specific cable - Multimode fiber optic (MMF) 62.5/125um duplex cable with SC-to-MIC connectors.

-xx = available lengths: (01, 03, 10) for 1, 3, 10 meters

Compaq AlphaStation ES40

Tru64 UNIX OpenVMS Linux

4 per system

1 per adapter

4 4 -

3X-DE602-FA

3X-DEFPA-AC

3X-DEFPA-DC

3X-DEFPA-MC

3X-DEFPA-UC

BN34D-xx

ATM

Synchronous Communications (SYNC)

Asynchronous Communications

(ASYNC)

PCI (32-bit, 33-MHz) to 155 Mbps ATM, copper NIC with RJ45 connector. Use BN25G-xx, or BN26M-xx cables. PCI (32-bit, 33-MHz) to 155 Mbps ATM fiber NIC with SC connector. Use BN34B-xx cable. PCI (32-bit, 33-MHz) to 622 Mbps ATM fiber NIC with SC connector. Use BN34B-xx cable.

PCI (32-bit, 33-MHz) to dual-port intelligent synchronous communications NIC. Requires at least one (maximum two) 3X-BC34x synchronous cable listed below. PCI (32-bit, 33-MHz) to quad-port intelligent synchronous communications NIC. Requires at least one (max four) 3X-BCN34x synchronous cable listed below.

Synchronous-Specific Cables

EIA-530 single-port cable V.24/EIA-232 single-port cable

V.11/x.21 single-port cable

V.35 single-port cable

PCI (32-bit, 33-MHz) to quad-port Async Communications NIC with DB-25

octopus cable

PCI (32-bit, 33-MHz) to 8-port Async Communications NIC with DB-25

octopus cables

PCI (32-bit, 33-MHz) to 16-port Async Communications Controller and tabletop16-port distribution box with RJ45 connectors

PBXDA-AC A synchronous Connector Adapters

RJ45 to DB-25 converter cable RJ45 to DEC MJ11 converter cable (8 pack)

6 6 -

4 - -

4 4 -

2 2 -

3X-DAPBA-UA

3X-DAPBA-FA

3X-DAPCA-FA

3X-PBXDD-AA

3X-PBXDD-AB

3X-BC34G-06

3X-BC34S-06

3X-BC34T-06

3X-BC34L-06

PBXDA-BA

PBXDA-BB

PBXDA-AC

CXI01-AC

CXI01-AF

DA-10392 North America — Version 57 — March 18, 2003

Compaq AlphaServer ES40

QuickSpecs

Compaq AlphaStation ES40

Options

Step 8 −−−−Networking Adapters/C ontrollers (continued) Step 8c −−−− Multi-use Cables

Maximum # Supported

Ethernet, FDDI, ATM

Step 9 −−−− MEMORY CHANNEL −−−− Optional

NOTE: When using MEMORY CHANNEL, refer to the TruCluster QuickSpecs for configuration guidelines and restrictions:

http://www.compaq.com/products/quickspecs/Division/10657.html

The MEMORY CHANNEL controller, CCMAB-AA, must be revision C1 or later.

Tru64 UNIX Systems (V5.0A and later)

Tru64 UNIX Systems (V4.0F)

OpenVMS Systems

Configuring Information • Up to two PCI-to-System Area Network adapters (CCMAB-AA) are supported in a single

• CCMHB-AA includes four CCMLB-AA line cards and supports up to four nodes; expansion

Multimode fiber optic (MMF) 62.5/125um duplex cable, with SC-to-ST connectors. –xx = available lengths: (2E, 4E, 01, 03, 10, 20, 30) for 2.4, 4.5, 1, 3, 10, 20, 30 meters

Multimode fiber optic (MMF) 62.5/125um duplex cable, with SC-to-SC connectors.

-xx = available lengths: (2E, 4E, 01, 03, 10, 20, 30) for 2.4, 4.5, 1, 3, 10, 20, 0 meters

Category 5e (4-Unshielded Twisted Pairs / UTP) straight-through cable with RJ45-to-RJ45 connectors for system to switch, repeater, or hub connectivity.

-xx = available lengths: (0B, 0E, 01, 03, 04, 07) for 0.2, 0.5, 1, 3, 4, 7 meters Category 5e (4-Twisted Pairs, Screened/ ScTP) straight-through cable with

RJ45-to-RJ45 connectors for system to switch, repeater, or hub connectivity.

-xx = available lengths: (0E, 01, 03, 04, 07) for 0.5, 1, 3, 4, 7 meters Category 5e (4-Unshielded Twisted Pairs / UTP) Xover cable with RJ45-to-

RJ45 connectors for system to switch, repeater, or hub connectivity.

-xx = available lengths: (0E, 01, 03, 04, 07) for 0.5, 1, 3, 4, 7 meters Category 5e (4-Twisted Pairs, Screened / ScTP) Xover cable with RJ45-to-

RJ45 connectors for system to switch, repeater, or hub connectivity.

-xx = available lengths: (0E, 01, 03, 04, 07) for 0.5, 1, 3, 4, 7 meters

• Each system node in the cluster requires a TruCluster software license

(QL-6BRAE-AA)

• Requires a minimum of Tru64 UNIX V4.0F with TruCluster V1.6 or later

• Each system node in the cluster requires a TruCluster Production Server

(QB-3RLAE-AA) or TruCluster MEMORY CHANNEL software license (QB-4ZCAE-AA)

• TruCluster MEMORY CHANNEL license (QB-4ZCAG-AA), normally used for high

performance technical computing applications, not required if systems include a TruCluster Production Server license (QB-3RLAE-AA)

• OpenVMS V7.2-2 or later and OpenVMS Cluster license (QL-MUZAE-AA) are required

system.

• Two-node clusters can be configured by ordering a CCMAB-AA for each node and one

BN39B-04 or BN39B-10 cable; cable connects directly to CCMAB-AA in each node

• For a two-node cluster that will not be rebooted when adding additional members, order

one CCMAB-AA adapter and one BN39B-04 or BN39B-10 cable for each node and one CCMHB-AA hub for the cluster

• Two-node clusters can also be configured by ordering two CCMAB-AA adapters for each

node and two BN39B-04 or BN39B-10 cables; cables connect directly to CCMAB-AA in each node.

• For three or four node clusters, order one CCMAB-AA adapter and one BN39B-04 or

BN39B-10 cable for each node, and one CCMHB-AA hub for the cluster If two CCMABAAs are configured in each system, a second CCMHB-AA is required.

up to eight system nodes can be achieved by adding up to four CCMLB-AA line cards.

Tru64 UNIX OpenVMS Linux

BN34A-xx

BN34B-xx

BN25G-xx

BN26M-xx

BN24Q-xx

BN28Q-xx

DA-10392 North America — Version 57 — March 18, 2003

QuickSpecs

Options

Step 9 −−−− MEMORY CHANNEL −−−− Optional (continued) Configuring Information (continued)

• If nodes must be separated by a distance longer than standard copper cables allow the

CCMFB option converts the output of the standard CCMAB controller or CCMLB line card to single-mode fiber optic cable. The fiber optic connection may be up to 2,000 meters long between two CCMAB controllers connected in virtual hub mode, or 3,000 meters between a CCMAB controller and a CCMHB hub. (The connection from the CCMHB hub to a second system may also be 3,000 meters.) The CCMFB option requires a second PCI slot in the system from which it draws power only. It is normally connected to the corresponding CCMAB controller with the short BN39B-01 cable. The CCMFB is also used in the CCMHB hub where it occupies a slot normally used by the CCMLB line card, limiting expansion to four radial fiber optic connections.

• CCMHB-BA hub expansion box provides additional slots for up to eight fiber optic

connections. Two standard length single-mode fiber optic cables are available (BN34R-10 and BN34R-31); however, users normally provide this fiber optic connection. Fiber optic connectivity is completely transparent to the systems using it and has no performance impact.

Compaq AlphaServer ES40

Compaq AlphaStation ES40

MEMORY CHANNEL Controller/System Area Network Hub

MEMORY CHANNEL Power Cords

PCI-to-System Area Network Controller, maximum two

System Area Network Hub with four line cards; includes BN19P-2E power cord for Canada,

Japan, and U.S. −for other regions, order appropriate power cord from the following list:

Hub expansion box with no line cards Expansion line card for CCMHB hub 1-meter cable for CCMAB and CCMHB 4-meter cable for CCMAB and CCMHB 10-meter cable for CCMAB and CCMHB Copper-to-single mode fiber optic converter Rackmount kit (3U) for CCMHB (MEMORY CHANNEL Hub II); required for mounting in

H9A1x cabinets.

Power cord for rackmount CCMHB hub

Australia, New Zealand (103541-011)

Central Europe

Denmark (103541-481)

Egypt, India (103541-AR1)

Ireland, United Kingdom

Israel

Italy (103541-461)

Japan, 2.5-meter, Dentori approved

Switzerland (103541-511)

CCMAB-AA

CCMHB-AA

CCMHB-BA

CCMLB-AA

BN39B-01 BN39B-04 BN39B-10

CCMFB-AA

3X-BA61R-MC

BN35S-02

BN19H-2E

BN19C-2E

BN19K-2E

BN19S-2E

BN19A-2E

BN18L-2E

BN35M-02

3X-BN46F-02

BN19E-2E

DA-10392 North America — Version 57 — March 18, 2003

Compaq AlphaServer ES40

QuickSpecs

Options

Step 10 −−−− Storage Adapters/Controllers

NOTE: Refer to the following chart when configuring adapters, shelves, and disks.

AlphaServer ES40 Configuration Chart for Storage Adapters Storage Adapters Shelf Disk Drives Tru64 UNIX OpenVMS Linux

3X-KZPCA-AA BA610-6D

3X-KZPEA-DB BA610-6D

DS-KGPSA-DA External HSG80 3R-A0xxx-AA 1-inch Universal

3X-DEPVZ-AA DS-SL13R-xx 3R-A1xxx-AA 1-inch Universal V4.0F with NHD2 or

KZPCM-DA BA36R-xx DS-RZ1ED-VW

3X-KZPBA-CC BA36R-xx DS-RZ1ED-VW

DS-SSL14-Rx DS-SL13R-xx

DS-SSL14-Rx

3R-A0xxx-AA 1-inch Universal 3R-A1xxx-AA 1-inch Universal 3R-A3xxx-AA 1-inch Universal

3R-A0xxx-AA 1-inch Universal 3R-A1xxx-AA 1-inch Universal

3R-A3xxx-AA 1-inch Universal

3R-A1xxx-AA 1-inch Universal 3R-A3xxx-AA 1-inch Universal

DS-RZ1FC-VW

V4.0F or higher V7.2-2 or higher RedHat V6.2

V5.1A only V7.2-2 or higher -

V5.1 V7.2-2 or higher -

higher

V4.0F or higher V7.2-2 or higher -

V4.0F or higher V7.2-2 or higher RedHat V6.2

Compaq AlphaStation ES40

SuSE V6.3

(Requires BA610)

V7.2-2 or higher -

SuSE V6.3

DS-SWLA4-PD BA36R-xx DS-RZ1ED-VW

NOTE: Ethernet adapter is not required if 3X-DEPVZ-AA or KZPCM-DA is selected as SCSI adapter for StorageWorks shelf.

External RAID Controllers Controllers Shelf Disk Drives Tru64 UNIX OpenVMS Linux

3X-KZPDC-BE/DF DS-SL13R-xx 3R-A0xxx-AA 1-inch Universal

DS-KZPCC-AC/CE BA36R-xx* DS-RZ1ED-VW

KZPAC-AA/CA/CB BA36R-xx* DS-RZ1DD-VW V4.0F or higher V7.2-2 or higher

FR-PCTAR-IB BA36R-xx* DS-RZ1ED-VW

FR-PCTAR-IC BA36R-xx* DS-RZ1ED-VW

SN-KZPBC-AA BA36R-xx* DS-RZ1ED-VW

DS-SWLA4-PD BA36R-xx* DS-RZ1ED-VW

NOTE: * = BA36R-xx shelves require DOC2 I/O module, DS-BA35X-FC; order DS-BA35X-FC as an independent option (will not be factory installed).

Internal RAID Controllers Controllers Shelf Disk Drives Tru64 UNIX OpenVMS

3X-KZPDC-BE/DF BA610-6D 3R-A0xxx-AA 1-inch Universal

DS-KZPCC-AC/CE (see NOTES)

NOTES:

(1) DS-KZPCC-AC/CE RAID controllers can be used with Universal shelves and drives in ES40 Pedestal and Rackmount configurations.

(2) EV67 systems (54-30362-01) on V5.1 must be at Revision C01 or Revision D01

(3) Only BA610-6D cages (with Nile Cards Rev –0B) shipped after 1 October 2001 support internal RAID. Contact Customer Services to

BA610-6D

Configuration rules are restricted to specific CPU speeds and OS versions:

- Tru64 UNIX V4.0F requires NHD3 and Patch Kit 4 (BL15) or later (for EV6, EV67, EV68 systems)

- Tru64 UNIX V5.1 requires Patch Kit 3 (BL17) and Early Release Patch C462.02 (for EV68 and specific EV67 systems)

- Patch Kit 3 (BL17) is located at: T64V5117-C0046202-11060-Manual-ER-20010615.tar

- Patch C462.02 is located at: http://ftp1.support.compaq.com/public/unix/v5.1/

DS-KZPCC-AC/CE RAID controllers support standalone and cluster configurations

- No support as boot device in cluster configurations

- TruCluster V5.1 (restricted to non-shared buses only)

replace Nile Cards shipped in BA610-6D disk card cages prior to 1 October 2001 where internal RAID is required.

(3)

DS-RZ1FC-VW

3R-A1xxx-AA 1-inch Universal

3R-A3xxx-AA 1-inch Universal

DS-RZ1FC-VW

3R-A1xxx-AA 1-inch Universal

3R-A3xxx-AA 1-inch Universal

3R-A0xxx-AA 1-inch Universal 3R-A1xxx-AA 1-inch Universal 3R-A3xxx-AA 1-inch Universal

- - RedHat V6.2

V5.1B/V5.1A

EV68 only

V4.0F or higher Not supported -

- - RedHat V6.2

V5.1B/V5.1A

EV68 only

EV6 V4.0F

EV67 V5.1

EV68

(2)

(1)

V7.3-1

SuSE V6.3

SuSE V6.3 SuSE V6.3 SuSE V6.3 SuSE V6.3

V7.3-1

Not supported

DA-10392 North America — Version 57 — March 18, 2003

Compaq AlphaServer ES40

QuickSpecs

Options

Step 10 −−−− Storage Adapters/Controllers

Maximum # Supported

SCSI PCI 2-port PCI to Ultra3, 64-bit LVD SCSI adapter, uses one PCI slot;

PCI 1-port Ultra2 (LVD) SCSI adapter, 32-bit, single-channel (uses one

68-pin HD male-to-VHDCI male UltraSCSI cable;

PCI 1-port UltraSCSI differential adapter (uses one PCI slot); includes

68-pin HD male-to-VHDCI male UltraSCSI cable;

Fibre Channel

See Fibre Channel cables – Step 11 PCI-to-Fibre Channel adapter, 64-bit single channel (uses one PCI

includes internal 68-pin and external 68-pin VHDCI connectors; requires 3X-BC56J-xx cable to connect adapter to Universal shelf; supports internal SDLT tape drives and external SDLT tape libraries; no shared SCSI support; support restricted to EV68 833-MHz systems only and Tru64 UNIX V5.1A as a minimum. See Step 12 for graphics restrictions.

RequiresTru64 UNIX V5.1A as minimum revision.

OpenVMS V7.2-2 requires Tima kit:

- DEC-AXPVMS-V722_FIBRE_SCSI-V0100-4.PCSI OpenVMS V7.3 requires Tima kit:

- DEC-AXPVMS-V73_FIBRE_SCSI-V0100-4.PCSI

PCI slot); includes internal 68-pin and external 68-pin HD connectors; order BN38C-xx cable to connect adapter to Ultra3 shelf, or order VHDCI converter (BN38E-0B) for use with included cable; HSZxx RAID controllers not supported. OpenVMS V7.2-2 requires OpenVMS Tima Kit located at:

http://ftp.support.compaq.com/patches/.new/openvms.shtml

Tru64 UNIX V4.0F requires Patch Kit2 BL13:

- DUV40FAS0002-19991116.tar

-xx = 02, 03, 05, 10, 20 meters

external 68-pin HD connector, requires BN38C-xx cable (2 to 220 meters) to connect adapter to differential UltraSCSI shelf or RAID controller

-xx = 02, 03, 05, 10, 20 meters PCI to 2-Gbit Fibre Channel adapter, 64-bit, single-channel (uses one

PCI slot) (261329-B21)

NOTE: When used in standalone or TruCluster environment (with Fibre

Channel Switches, Step 11), a maximum of six adapters is supported. Arbitrated loop is not supported. Tru64 UNIX V5.1 requires Patch Kit:

- T64V51B18AS0004-20011114.tar OpenVMS V7.2-2 requires Tima Kit:

- DEC-AXPVMS-VMS722_FIBRE_SCSI-V0100 OpenVMS V7.3 requires Tima Kit:

- DEC-AXPVMS-VMS73_FIBRE-SCSI-V0200

PCI to 1-Gbit Fibre Channel adapter, 64-bit, single-channel (uses one PCI slot); direct attach supports a maximum of four adapters; TruCluster supports a maximum of two adapters

slot); includes cable to HSG80 controller; requires Linux RedHat V6.2 and Linux SuSE V6.3; for details, refer to:

http://www.compaq.com/products/storageworks/adapters/fchbalinux.html

Tru64 UNIX OpenVMS Linux

See Note See Note -

Compaq AlphaStation ES40

4 4 -

6 6 6

5 5 5

4 4 -

- - 3

BN38C-xx

3X-KZPEA-DB

3X-KZPCA-AA

BN38C-xx

3X-KZPBA-CC

DS-KGPSA-DA

DS-KGPSA-CA

DS-SWLA4-PD

DA-10392 North America — Version 57 — March 18, 2003

Compaq AlphaServer ES40

QuickSpecs

Compaq AlphaStation ES40

Options

Step 10 −−−− Storage Adapters/Controllers −−−− Required if StorageWorks shelf is selected in Step 5 (continued)

Maximum # Supported

Multi-function Module PCI 2-port UltraSCSI single-ended adapter and 10/100 Mb Ethernet

VHDCI male-to-VHDCI male UltraSCSI cable,

PCI (32-bit, 33-MHz) multi-function (single-port 10/100 Ethernet UTP/RJ45, Ultra2 LVD SCSI, and 2D graphics) adapter. See Step 8.

combo adapter (uses one PCI slot); includes internal 68-pin and 50-pin HD connectors and two external 68-pin VHDCI SCSI connectors, requires BN37A-xx cable to connect to single-ended UltraSCSI shelf

xx = 02, 2E [2.5], 03, 05, 10, 20 meters

Tru64 UNIX OpenVMS Linux

1 1 -

4 4 -

3X-DEPVZ-AA

KZPCM-DA

BN37A-xx

RAID PCI 3-port PCI to Ultra2, 64-bit, LVD backplane RAID controller with

64-MB cache (uses one PCI slot); requires connection to DS-SSL14-Rx (maximum seven disks supported per channel) or to DS-SL13R-xx (maximum 14 disks with single channel); requires graphics adapter to run console utilities (SMOR).

PCI 1-port PCI to Ultra2, 64-bit, LVD backplane RAID controller with

16-MB cache (uses one PCI slot); requires connection to DS-SSL14-Rx (maximum seven disks supported per channel) or to DS-SL13R-xx (maximum 14 disks with single channel); requires graphics adapter to run console utilities (SMOR).

PCI 2-port PCI to Ultra3, 64-bit, 66 MHz, LVD backplane RAID

controller with 128-MB cache (uses one PCI slot); requires connection to DS-SL13R-xx shelves or BA610-6D card cage.

NOTE: Tru64 UNIX requires V5.1B and TruCluster V5.1B (non-shared

buses only) with Initial Patch Kit: T64V51BV1AS0001-20021229.tar Tru64 UNIX requires V5.1A with Initial Patch Kit: T64V51AV21AS0004-20030206.tar

NOTE: Supports EV68 systems only; no host-based volume shadowing

or shared bus support under OpenVMS

PCI 4-port PCI to Ultra3, 64-bit, 66 MHz, LVD backplane RAID

controller with 256-MB cache (uses one PCI slot); requires connection to DS-SL13R-xx shelves or BA610-6D card cage.

NOTE: Tru64 UNIX requires V5.1B and TruCluster V5.1B (non-shared

buses only) with Initial Patch Kit: T64V51BV1AS0001-20021229.tar Tru64 UNIX requires V5.1A with Initial Patch Kit: T64V51AV21AS0004-20030206.tar

NOTE: Supports EV68 systems only; no host-based volume shadowing

or shared bus support under OpenVMS

PCI 1-port UltraSCSI RAID controller with 4-MB cache memory (uses

one PCI slot), includes RAID Array 230/Plus Subsystem software and documentation kit; includes VHDCI female connector; tape drives not supported; only 9.1-GB disk drives supported, requires BN37A-xx cable (0.3 to 20 meters) to connect to single-ended UltraSCSI shelf

PCI 3-port UltraSCSI RAID controller with 4-MB cache memory (uses

one PCI slot), includes RAID Array 230/Plus Subsystem Software and documentation kit; tape drives not supported; only 9.1-GB disk drives supported; SCSI cable required for each active port; requires BN37X-xx cable (0.3 to 20 meters) to connect to single-ended UltraSCSI shelf, and BN31K-0E for external third port connection

Same as KZPAC-CA with 8-MB cache memory 4 4 -

Cache battery backup for KZPAC controller

8 - -

6 per system 3 - PCI bus 0 4 - PCI bus 1

4 4 -

6 per system 3 - PCI bus 0 4 - PCI bus 1

DS-KZPCC-CE

DS-KZPCC-AC

3X-KZPDC-BE

3X-KZPDC-DF

KZPAC-AA

KZPAC-CA

KZPAC-CB

KZPSC-UB

DA-10392 North America — Version 57 — March 18, 2003

Compaq AlphaServer ES40

QuickSpecs

Options

Step 10 −−−− Storage Adapters/Controllers −−−− Required if StorageWorks shelf is selected in Step 5 (continued)

Maximum # Supported

RAID (continued) VHDCI male-to-VHDCI male UltraSCSI cable;

SCSI cable/bulkhead assembly kit, supports one third-port connection

SCSI cable/bulkhead assembly kit, supports two third-port connections

RAID (Linux) PCI 1-port Ultra SCSI RAID controller with 4-MB cache; supports disk

PCI 3-port Ultra SCSI RAID controller with 32-MB cache; supports disk

PCI 3-port Ultra SCSI RAID controller with 64-MB cache; supports disk

Tru64 UNIX OpenVMS Linux

-xx = 02, 2E [2.5], 03, 05, 10, 20, 25 meters

NOTE: Manufacturing may substitute BN37A-02 cable for specific

cabinet configurations.

from KZPAC-CA/CB, allows external connection of one third port

from KZPAC-CA/CB, allows external connection of two third ports

drives only and external support only in BA356 StorageWorks shelves; requires RedHat V6.2, SuSE V6.3

Compaq AlphaStation ES40

- - 4

- 4 SN-KZPBC-AA

- 4 FR-PCTAR-IB

BN37A-xx

BN31K-0E

KZPAC-SB

FR-PCTAR-IC

CI PCI CI adapter for OpenVMS systems only; requires two PCI slots and

CI cable for each adapter

CI cable

DSSI PCI DSSI controller for OpenVMS systems only; requires HSDxx

controller to connect directly to StorageWorks shelf; requires BC29S-xx cable

6-foot DSSI cable for connection to HSD10 installed in BA36R pedestal

shelf

9-foot DSSI cable for connection to HSD10 installed in BA36R cabinet

shelf

- 2 -

- 4 -

CIPCA-BA

BNCIA-xx

KFPSA-AA

BC29S-06

BC29S-09

DA-10392 North America — Version 57 — March 18, 2003

Compaq AlphaServer ES40

QuickSpecs

Compaq AlphaStation ES40

Options

Step 11 −−−− Storage Devices −−−− Optional Step 11a −−−− Tape Devices

Tape Drives

AIT Tape Drives (Internal)

AIT Tabletop Tape Drives AIT 35/70-GB 8-mm LVD tabletop tape drive, carbon black, North America Same as above, International Same as above, Japan AIT 50/100-GB 8-mm SCSI tabletop tape drive with 120V North American power cord Same as above, International Same as above, Japan AIT 100/200-GB 8-mm Ultra3 SCSI tabletop tape drive; supported with 3X-KZPEA-DB,

Same as above, International

AIT Hot-plug Tape Drives The following AIT hot-plug tape drives use two Universal (BA610) slots: AIT 35/70-GB hot-plug LVD Universal tape drive, uses two slots in BA610-6D or 43xxx

AIT 50/100-GB hot-plug LVD Universal tape drive, uses two slots in BA610-6D or 43xxx

AIT 100/200-GB hot-plug LVD Universal tape drive, uses two slots in BA610-6D or

AIT Autoloaders AIT 35-GB tabletop autoloader, 8 cartridge, U.S. Same as above, International AIT 35-GB rackmount autoloader, 8 cartridge, U.S. Same as above, International AIT Rail kit for autoloader

• System includes embedded 1.44-MB diskette drive

• System includes embedded 5.25-inch half-height 600-MB 16X IDE CD-ROM drive

• Removable media slots provide support for up to two 5.25-inch half-height devices, or one 5.25-inch

full-height removable media device; select up to two AIT or DAT devices or one DLT/SDLT tape device

• For maximum performance, tape libraries must be configured with Fast Wide Differential (FWD) controllers

for tape backup

• For more information on tape drives, see

http://www.compaq.com/products/StorageWorks/sitemap.html#tapedrives

NOTE: This website is available in English only.

• The following AIT tape drives are supported with 3X-KZPCA-AA and

3X-KZPEA-DB adapters.

AIT 5.25-inch half-height 35/70-GB 8-mm Wide UltraSCSI tape drive, top gun blue; requires SCSI cable (3X-BN46M-01)

AIT 5.25-inch half-height 35/70-GB 8-mm LVD UltraSCSI tape drive, carbon black; requires SCSI cable (3X-BN46M-01)

AIT 5.25-inch half-height 50/100-GB 8-mm Ultra2 (LVD) SCSI tape drive, top gun blue;

requires SCSI cable (3X-BN46M-01) AIT 5.25-inch half-height 50/100-GB 8-mm Ultra2 (LVD) SCSI tape drive; carbon black;

requires SCSI cable (3X-BN46M-01) (157766-B22)

AIT 5.25-inch half-height 100/200-GB 8-mm Ultra3 SCSI tape drive; supported with 3X-KZPEA-DB, 3X-KZPCA-AA, or 3X-DEPVZ-AA LVD adapters, carbon black, requires SCSI cable (3X-BN46M-01)

1-meter Ultra2 68-pin LVD cable with two connectors, multimode terminator and two wide-to-narrow adapters (for connection of 50-pin narrow devices)

3X-KZPCA-AA, or 3X-DEPVZ-AA LVD adapters, North America, carbon black

shelves

43xxx shelves; supported with 3X-KZPEA-DB, 3X-KZPCA-AA, or 3X-DEPVZ-AA LVD adapters

3X-SZ35X-LB

3R-A2392-AA

3X-SZ50X-LB

3R-A3753-AA

3R-A3623-AA

3X-BN46M-01

216885-001

216885-B31

216885-291 157767-002

157767-B32

157767-292 249160-001

249160-B31

3R-A2396-AA

3R-A2779-AA

3R-A3621-AA

292355-001

292355-B31

280349-001

280349-B31

284930-001

DA-10392 North America — Version 57 — March 18, 2003

QuickSpecs

Options

Step 11 −−−− Storage Devices −−−− Optional (continued) Step 11a −−−− Tape Devices (continued)

AIT Tape Libraries

DAT Tape Drives (Internal)

DAT Tabletop Tape Drives

DAT Hot-plug Tape Drive

DAT Autoloaders

SDLT Tape Drives (Internal)

SDLT Tabletop Tape Drives

SSL2020 AIT tabletop library with one AIT 50-GB drive and 20 slots, LVD

SSL2020 AIT tabletop library with two AIT 50-GB drive and 20 slots, LVD

SSL2020 AIT rackmount library with one AIT 50-GB drive and 20 slots, LVD (Universal shelves)

SSL2020 AIT rackmount library with two AIT 50-GB drives and 20 slots, LVD (Universal shelves)

• Select up to two DAT devices

• The following DAT tape drives are supported with 3X-KZPCA-AA and

DAT 12/24-GB 4-mm 5.25-inch half-height SCSI tape drive, top gun blue; requires SCSI

cable (3X-BN46M-01) (Linux-supported option) DAT 20/40-GB 4-mm 5.25-inch half-height Ultra2 (LVD) SCSI tape drive, top gun blue;

requires SCSI cable (3X-BN46M-01) DAT 20/40-GB 4-mm 5.25-inch half-height Ultra2 (LVD) SCSI tape drive, carbon black;

requires SCSI cable (3X-BN46M-01) (157769-B22)

1-meter Ultra2 68-pin LVD cable with two connectors, multimode terminator and two wide-to-narrow adapters (for connection of 50-pin narrow devices)

DAT 12/24-GB 4-mm narrow SCSI tape drive in StorageWorks carrier

DAT 20/40-GB 4-mm Wide Ultra2 (LVD) tabletop SCSI tape drive with 120V North American power cord, carbon black

Same as above, International Same as above, Japan

DAT 20/40-GB DDS4 hot-plug LVD Universal tape drive, uses two slots in BA610-6D or

43xxx shelves (Linux-s upported option)

DAT 20/40-GB auto loader external; requires VHDCI BN38A-0B adapter and BN23G-xx SCSI cable, North America

Same as above, International Same as above, Japan

• Select one SDLT tape device

• The following SDLT tape drives are supported with 3X-KZPCA-AA and

SDLT 110/220-GB 3U/5U tape drive (Linux-supported option)

SDLT 160/320-GB 3U/5U tape drive, carbon black

SDLT tabletop 110/220-GB external tape drive, carbon black − TruCluster support restricted to non-shared buses only − U.S.

Same as above – International Same as above – Japan

SDLT tabletop 160/320-GB external tape drive, carbon black− U.S.

Same as above – International Same as above – Japan

Compaq AlphaServer ES40

Compaq AlphaStation ES40

175195-B21

175195-B22

175196-B21

175196-B22

3X-KZPEA-DB adapters.

TLZ10-LB

3X-SD20X-LB

3R-A3752-AA

3X-BN46M-01

DS-TLZ10-VA

157770-002

157770-B32

157770-292

3R-A2780-AA

166505-001

166505-B31

166505-291

3X-KZPEA-DB adapters.

192106-B25 257319-B21

192103-002

192103-B32

192103-292 257319-001

257319-B31

257319-291

DA-10392 North America — Version 57 — March 18, 2003

QuickSpecs

Options

Step 11 −−−− Storage Devices −−−− Optional (continued) Step 11a −−−− Tape Devices (continued)

DLT/SDLT Tape Libraries

Rackmount kit for H9Axx M-Series cabinets – required for mounting MSL5000 series in M-Series cabinets

MSL5026DLX, DLT tabletop library with one 40/80-GB DLT tape drive, LVD

MSL5026DLX, DLT tabletop library with two 40/80-GB DLT tape drives, LVD

MSL5026DLX or MSL5026SL, DLT/SDLT rackmount library, 0 drives – requires rackmount kit (254795-001)

MSL5026DLX, DLT rackmount library with one 40/80-GB DLT tape drive, LVD – requires rackmount kit (254795-001)

MSL5026DLX, DLT rackmount library with two 40/80-GB DLT tape drives, LVD – requires rackmount kit (254795-001)

MSL5026S2, SDLT2 tabletop library with one 160/320-GB SDLT tape drive, LVD 293-473-B21 MSL5026S2, SDLT2 tabletop library with two 160/320-GB SDLT tape drives, LVD 293473-B22 MSL5026S2 SDLT rackmount library, 0 drives, LVD – requires rackmount kit

(254795-001) MSL5026S2, SDLT2 rackmount library with one 160/320-GB SDLT tape drive, LVD 293472-B22

MSL5026S2, SDLT2 rackmount library with two 160/320-GB SDLT tape drive, LVD 293472-B23 MSL5026S2, SDLT2 rackmount library with one 160/320-GB SDLT tape drive with Fibre

Channel, LVD MSL5026S2, SDLT2 rackmount library with two 160/320-GB SDLT tape drive with Fibre Channel, LVD

MSL5052SL SDLT tabletop library with two 110/220-GB drives, LVD

MSL5052SL SDLT rackmount library, 0 drives, LVD – requires rackmount kit (254795-001)

MSL5052SL SDLT rackmount library with two 110/220-GB drives, LVD – requires rackmount kit (254795-001)

MSL5052SL SDLT 110/220-GB drive field upgrade, LVD

MSL5052S2, SDLT2 tabletop library with two 160/320-GB SDLT tape drives, LVD, graphite MSL5052S2, SDLT2 rackmount library with two 160/320-GB SDLT tape drive, LVD 293474-B21

MSL5052S2, SDLT2 rackmount library with two 160/320-GB SDLT tape drive with Fibre Channel, LVD

ESL9198SL SDLT tape library with four 110/220-GB SDLT tape drives, 198 slots ESL9198SL SDLT tape library with eight 110/220-GB SDLT tape drives, 198 slots

ESL9322S2 SDLT2 tape library, two 160/320GB SDLT tape drives, 222 slots 293409-B22 ESL9322S2 SDLT2 tape library, eight 160/320GB SDLT tape drives, 222 slots 293409-B28 ESL9322S2 SDLT2 tape library, two 160/320GB SDLT tape drives, 322 slots 2934010-B22 ESL9322S2 SDLT2 tape library, eight 160/320GB SDLT tape drives, 322 slots 2934010-B28

Compaq AlphaServer ES40

Compaq AlphaStation ES40

254795-001

231821-B21

231821-B22

231979-B21

231891-B21

231891-B22

293472-B21

293472-B24

293472-B25

249490-B21

255102-B21

249491-B21

231823-B22

293476-B21

293474-B24

234618-B21 234618-B22

DA-10392 North America — Version 57 — March 18, 2003

Compaq AlphaServer ES40

QuickSpecs

Options

Step 11 −−−− Storage Devices −−−− Optional (continued) Step 11a −−−− Tape Devices (continued)

DLT/SDLT Tape Libraries (continued)

ESL9595SL SDLT tape library, 0 drives, 400 slots 274672-B21 ESL9595SL SDLT tape library, 2 drives, 400 slots 274672-B22 ESL9595SL SDLT tape library, 16 drives, 400 slots 274672-B28 ESL9595SL SDLT tape library, 0 drives, 500 slots 281627-B21 ESL9595SL SDLT tape library, 2 drives, 500 slots 281627-B22 ESL9595SL SDLT tape library, 16 drives, 500 slots 281627-B28 ESL9595SL SDLT tape library, 0 drives, 595 slots 281628-B21 ESL9595SL SDLT tape library, 2 drives, 595 slots 281628-B22 ESL9595SL SDLT tape library, 16 drives, 595 slots

ESL9326SL SDLT tape library with six 110/220-GB SDLT tape drives, LVD 234615-B21

ESL9326SL SDLT tape library with eight 110/220-GB SDLT tape drives, LVD 234615-B22

ESL9326SL SDLT tape library with 16 110/220-GB SDLT tape drives, LVD 234615-B26

ESL9595S2 SDLT2 tape library, two 160/320-GB SDLT tape drives, 400 slots 293411-B22

ESL9595S2 SDLT2 tape library, 16 160/320-GB SDLT tape drives, 400 slots 293411-B28

ESL9595S2 SDLT2 tape library, two 160/320-GB SDLT tape drives, 500 slots 293412-B22

ESL9595S2 SDLT2 tape library, 16 160/320-GB SDLT tape drives, 500 slots 293412-B28

ESL9595S2 SDLT2 tape library, two 160/320-GB SDLT tape drives, 595 slots 293413-B22

ESL9595S2 SDLT2 tape library, 16 160/320-GB SDLT tape drives, 595 slots 293413-B28

Compaq AlphaStation ES40

281628-B28

3U Rackmount Tape Drive Enclosure

NOTE: The following options are supported with 3X-KZPCA-AA or 3X-KZPEA-DB LVD adapters.

3U LVD Rackmount Tape Drive Enclosure for use in H9Axx M-Series Cabinets, carbon black, 0 drives

Rackmount Kit for H9Axx M-Series Cabinets, carbon black – required for mounting 3U Rackmount Tape Drive Enclosure in M-Series cabinet

NOTE: The 3U Rackmount Tape Enclosure supports up to four internal half-height

removable devices, or up to two full-height devices; select up to four AIT or DAT devices or two DLT/SDLT devices with 3U Rackmount Tape Enclosure

(274338-B21) or choose one of the preconfigured configurations listed below.

AIT 35/70-GB 3U tape drive, carbon black AIT 50/100-GB 3U tape drive, carbon black (157766-B22) DAT 20/40-GB 3U tape drive, carbon black (157769-B22) DLT8000 40/80-GB tape drive SDLT 110/220-GB tape drive SDLT 160/320-GB tape drive, carbon black

Preconfigured Configurations

AIT 50-GB 3U rackmount kit, carbon black DLT 40/80-GB, 3U rackmount kit, carbon black DLT 40/80-GB, dual-drive, 3U rackmount kit, carbon black SDLT 110/220-GB, 3U rackmount kit, carbon black SDLT 110/220-GB, dual-drive, 3U rackmount kit, carbon black

274338-B21

3R-A3804-AA

216884-B21 3R-A3753-AA 3R-A3752-AA

146196-B22

192106-B25

257319-B21

274333-B21

274332-B21

274335-B21

274331-B21

274334-B21

DA-10392 North America — Version 57 — March 18, 2003

QuickSpecs

Options

Step 11 −−−− Storage Devices −−−− Optional (continued) Step 11a −−−− Tape Devices (continued)

5U Rackmount Tape Drive Enclosure

Step 11b – Network Storage Routers Network Storage Routers

5U LVD Rackmount Tape Drive Enclosure for use in H9Axx M-Series Cabinets, 0 drives, carbon black

Rackmount Kit for H9Axx M-Series Cabinets, carbon black − required for mounting 5U

Rackmount Tape Drive Enclosure in M-Series Cabinet

NOTE: The 5U Rackmount Tape Enclosure supports four full-height removable devices;

DLT8000 40/80-GB tape drive SDLT 110/220-GB tape drive SDLT 160/320-GB tape drive, carbon black

Preconfigured configurations

NOTE: The following Network Storage Routers (Tru64 UNIX) are supported with MSL5000 and ESL9000 tape

NSR M2402 Two Fibre Channel x 4 HVD FC to SCSI Data Router, Tru64 UNIX and OpenVMS (262654-B21)

NSR M2402 Two Fibre Channel x 4 LVD FC to SCSI Data Router, Tru64 UNIX and OpenVMS (262653-B21)

NSR e1200 One Fibre Channel x 2 LVD FC to SCSI Data Router, Tru64 UNIX and OpenVMS, carbon black (262672-B21)

NSR e2400 Two Fibre Channel x 4 LVD FC to SCSI Data Router with card cage, Tru64 UNIX and OpenVMS, carbon black (262665-B21)

NSR e2400 Two Fibre Channel x 4 LVD FC to SCSI Data Router without card cage, Tru64 UNIX and OpenVMS, carbon black (262664-B21)

NSR N1200 One Fibre Channel x 2 LVD FC to SCSI Data Router, Tru64 UNIX and OpenVMS, supports tape drives and tape libraries (280823-B21)

Compaq AlphaServer ES40

Compaq AlphaStation ES40

select up to four DLT or SDLT devices with 5U Rackmount Tape Enclosure

(274339-B21) or choose one of the preconfigured configurations listed below.

SDLT 110/220-GB Tape Array III, 5U rackmount kit, carbon black DLT 40/80-GB Tape Array III, 5U rackmount kit, carbon black DLT Tape Array III Model 0 enclosure, U.S. Same as above, International Same as above, Japan

libraries

274339-B21

254795-001

146196-B22

192106-B25

257319-B21

274336-B21

274337-B21

168047-001

168047-B31

168047-291

3R-A3741-AA

3R-A3740-AA

3R-A3746-AA

3R-A3935-AA

3R-A3745-AA

3R-A3747-AA

DA-10392 North America — Version 57 — March 18, 2003

QuickSpecs

Options

Step 11 −−−− Storage Devices −−−− Optional (continued) Step 11c – External Storage Solutions/Controllers

External Storage Solutions/Controllers

SAN Solutions Kits

Enterprise Virtual Array Model 2C6D-B 60-Hz, includes 41U graphite storage cabinet, M3220 controller assembly with dual HSV110 controllers, six M5214 dual-redundant FC loop 14-bay drive enclosures, four 12-port FC loop switches; requires DS-KGPSA-xx (283198-B21)

Enterprise Virtual Array Model 2C6D-B 50-Hz, includes 41U graphite storage cabinet, M3220 controller assembly with dual HSV110 controllers, six M5214 dual-redundant FC loop 14-bay drive enclosures, four 12-port FC loop switches; requires DS-KGPSA-xx (283198-B22)

Enterprise Virtual Array Model 2C12D-B 60-Hz, includes 41U graphite storage cabinet, M3220 controller assembly with dual HSV110 controllers, twelve M5214 dual-redundant FC loop 14-bay drive enclosures, four 12-port FC loop switches; requires DS-KGPSA-xx (283199-B21)

Enterprise Virtual Array Model 2C12D-B 50-Hz, includes 41U graphite storage cabinet, M3220 controller assembly with dual HSV110 controllers, twelve M5214 dual-redundant FC loop 14-bay drive enclosures, four 12-port FC loop switches; requires DS-KGPSA-xx (283199-B22)

Enterprise Virtual Array Model 8C8D 60-Hz, includes 41U graphite storage cabinet, four M3220 controller assembly with eight HSV110 controllers, eight M5214 dual FC loop 14-bay drive enclosures; requires DS-KGPSA-xx (283263-B21)

Enterprise Virtual Array Model 8C8D 50-Hz, includes 41U graphite storage cabinet, four M3220 controller assembly, with eight HSV110 controllers, eight M5214 dual FC loop 14-bay drive enclosures; requires DS-KGPSA-xx (283263-B22)

Enterprise Virtual Array Model 0C6D-B 60-Hz, includes 41U graphite storage cabinet, six M5214 dual-redundant FC loop 14-bay drive enclosures, twelve 16.4-feet/5-meter interconnect cables (to 2C12D-B); requires DS-KGPSA-xx (283264-B21)

Enterprise Virtual Array Model 0C6D-B 50-Hz, includes 41U graphite storage cabinet, six M5214 dual-redundant FC loop 14-bay drive enclosures, twelve 16.4-feet/5-meter interconnect cables (to 2C12D-B); requires DS-KGPSA-xx (283264-B22)

Enterprise Virtual Array Model 0C12D-B 60-Hz, includes 41U graphite storage cabinet, 12 M5214 dual-redundant FC loop 14-bay drive enclosures, 24 16.4-feet/5-meter interconnect cables (to two 2C12D-Bs); requires DS-KGPSA-xx (283265-B21)

Enterprise Virtual Array Model 0C12D-B 50-Hz, includes 41U graphite storage cabinet, 12 M5214 dual-redundant FC loop 14-bay drive enclosures, 24 16.4-feet/5-meter interconnect cables (to two 2C12D-Bs); requires DS-KGPSA-xx (283265-B22)

Tru64 UNIX SAN Solutions Kit for Enterprise Virtual Array V2.0 (250193-B22)

NOTE: V5.1 requires Patch Kit 3: T64V51B19AS0005-20020411.tar

V5.1A requires Patch Kit 3: T64V51AB03AS0003-20020827.tar

OpenVMS SAN Solutions Kit for Enterprise Virtual Array V2.0 (250194-B22)

NOTE: V7.2-2 requires Tima Kit:DEC-AXPVMS-VMS722_FIBRE_SCSI-V0200

V7.3 requires Tima Kit:DEC-AXPVMS-VMS73_FIBRE_scsi-V0300

Compaq AlphaServer ES40

Compaq AlphaStation ES40

DS-SV110-JA

DS-SV110-JB

DS-SV110-KA

DS-SV110-KB

DS-SV110-LA

DS-SV110-LB

DS-SV110-MA

DS-SV110-MB

DS-SV110-NA

DS-SV110-NB

QB-6RPAB-SB

QB-6RPAC-SB

DA-10392 North America — Version 57 — March 18, 2003

Compaq AlphaServer ES40

QuickSpecs

Options

Step 11 −−−− Storage Devices −−−− Optional (continued) Step 11c – External Storage Solutions/Controllers (continued)

Fibre Channel Controll er Fibre Channel Controller (HSG80), includes 256-MB cache; requires following firmware:

Additional 256-MB cache for HSG80 (380674-B21) DS-HSDIM-AC Single cache battery, one per HSG80 controller (135823-B21) DS-SE2CS-CB Model 2200 controller shelf for HSG80 controller (135820-B21) DS-SE2ZS-C8

StorageWorks Disk Array Family NOTE: The HP StorageWorks Disk Array Family, specifically the XP128 and XP1024,

3R-A4417-AA A7876A XP128 Disk Array Control Frame 3R-A4418-AA A7906A XP1024 Disk Array Control Frame

RA3000 RAID Array

Step 11d – Fibre Channel Options

Fibre Channel Disk Drives

Fibre Channel Hubs

Fibre Channel Data Routers

Fibre Channel Switches Fibre Channel 2-Gb 8-port SAN switch (258707-B21)

Fibre Channel 2-Gb 16-port SAN switch (283056-B21)

Fibre Channel SAN 2-Gb switch – 16-port (287055-B2)

Fibre Channel 2-Gb 64-port Core Switch (254508-B21)

8.6-4F ACS FW (222318-B22, QB-6BUAA-SD), one per controller

8.6-4S ACS FW (222364-B22 QB-6ENAA-SC), one per controller

8.6-4P ACS FW (222316-B22, QB-6CAAA-SD), one per controller Requires Tru64 UNIX software: 222320-B23, QB-65RAB-SE, one per controller Requires OpenVMS software: 222321-B22, QB-65RAC-SD, one per controller

are supported on AlphaServer ES40 systems. For product and ordering information, refer to the following Web pages:

http://www.hp.com/products1/storage/products/disk_arrays/highend/xp1024/ index.html

http://www.hp.com/products1/storage/products/disk_arrays/highend/xp128/

index.html

The following part numbers have been assigned for reference purposes only:

RAID Array 3000 (HSZ22) storage array is supported on AlphaServer ES40 systems (Tru64 UNIX V4.0F, V5.0A or higher and OpenVMS V7.x); supports KZPBA-CB adapter, minimum console V5.8

• For ordering information see:

http://www.compaq.com/products/StorageWorks/raidstorage/RA3000ped_config.html

NOTE: This website is available in English only.

The following hubs, data routers, switches, and cables are used in Fibre Channel configurations using the DS-KGPSA-xx adapter. 36-GB 10K rpm dual-port 2-Gb/sec FC-AL 1-inch (25.4 mm) drive (238590-B21) 3R-A3239-AA 72-GB 10K rpm dual-port 2-Gb/sec FC-AL 1-inch (25.4 mm) drive (238921-B21) 3R-A3260-AA 36-GB 15K rpm dual-port 2-Gb/sec FC-AL 1-inch (25.4 mm) drive (236205-B21) 3R-A3210-AA

Fibre Channel 7-port Storage Hub, International (Tru64 UNIX only) (234453-B31) DS-SWXHB-17 Fibre Channel 7-port Storage Hub, Japan (Tru64 UNIX only) (234453-291) DS-SWXHB-J7

1 Fibre Channel x 2 HVD data router (163082-B21) 3R-A2673-AA 1 Fibre Channel x 2 LVD data router (163083-B21) 3R-A2774-AA 2 x 4 LVD Fiber Channel to SCSI Network Storage Router (262653-B21) 3R-A3740-AA 2 x 4 HVD Fiber Channel to SCSI Network Storage Router (262654-B21) 3R-A3741-AA

- Requires Tru64 UNIX V5.1A Patch Kit: T64V51AB01AS0001-20020116.tar

- Requires Tru64 UNIX V5.1 Patch Kit: T64V51AS0003-20010521.tar

Compaq AlphaStation ES40

DS-HSG80-BK

DS-DSGGD-AC DS-DSGGD-AD

DS-DSGGD-BA

DS-DSGGE-AB

DA-10392 North America — Version 57 — March 18, 2003

Compaq AlphaServer ES40

QuickSpecs

Options

Step 11 −−−− Storage Devices −−−− Optional (continued) Step 11d – Fibre Channel Options (continued)

McData 64-port Fibre Channel SAN Director Class Switches

SAN Edge Switch 2 Gb, 32 ports (286810-B21) SAN Edge Switch 2-Gb, 16 ports (286811-B21) NOTE: Connection for, or between, 1-Gb and/or 2-Gb SAN switches requires different

Fibre Channel Cables NOTE: The following LC-SC connector cables support connectivity between 1-Gb and

2-meter LC-SC multi-mode Fibre Channel cable (221691-B21) 5-meter LC-SC multi-mode Fibre Channel cable (221691-B22) 15-meter LC-SC multi-mode Fibre Channel cable (221691-B23) 30-meter LC-SC multi-mode Fibre Channel cable (221691-B26) 50-meter LC-SC multi-mode Fibre Channel cable (221691-B27) NOTE: The following LC-LC connector cables support connectivity between 2-Gb and

2-meter LC-LC multi-mode Fibre Channel cable (221692-B21)

Step 12 −−−− Graphics Adapters −−−− Optional

Maximum # Supported

2D Graphics 3Dlabs Oxygen VX1 32-MB PCI 2D graphics accelerator

PCI (32-bit, 33-MHz) multi-function (single-port 10/100 Ethernet

3D Graphics PowerStorm 300 3D multi-head graphics accelerator with 15-MB

PowerStorm 350 3D multi-head graphics accelerator with 30-MB

NOTE: PowerStorm 300 and PowerStorm 350 adapters require the following:

Tru64 UNIX V4.0F (minimum version required) requires Patch Kit 1 with Environmental Patch PowerStorm 300 and PowerStorm 350 adapters can be combined, provided the system maximum is not exceeded.

SAN Director 64 (1 GB) 32 ports, base model SAN Director 2 Gb, 64 ports (286809-B21)

cables. Refer to the Switches, Hubs, and Interconnects QuickSpecs at:

http://www.compaq.com/products/quickspecs/North_America/10490.html

2-Gb devices.

• RAID Configuration Utility is accessible via console port; optional graphics capability is available

• Select graphics adapter, monitor, and country-specific keyboard for Tru64 UNIX and OpenVMS systems if

required

Tru64 UNIX OpenVMS Linux

NOTE: Only one 3X-KZPEA-DB adapter is allowed with

SN-PBXGF-AB adapter.

UTP/RJ45, Ultra2 LVD SCSI, and 2D graphics) adapter

NOTE: No support for multi-head graphics.

OpenVMS V7.2-2 requires OpenVMS Tima Kit located at:

- http://ftp.support.compaq.com/patches/.new/openvms.shtml Tru64 UNIX V5.1 requires Patch Kit 3:

- T64V51AS0003-20010413.tar

Tru64 UNIX V4.0F with NHD2 − TruCluster V5.1 support restricted to

non-shared buses Use BN25G, BN26M, BN24Q, or BN28Q twisted pair RJ45 cables.

frame buffer memory and 16-MB texture memory

NOTE: Graphics controllers must be the same type (PowerStorm); no mixing. NOTE: If using SN-PBXGD-AD graphics adapter on the same PCI

bus with the 3X-KZPEA-DB adapter, the SN-PBXGD-AD must be at minimum revision C06.

frame buffer memory and 32-MB texture memory

NOTE: If using SN-PBXGD-AE graphics adapter on the same PCI

bus with the 3X-KZPEA-DB adapter, the SN-PBXGD-AE must be at minimum revision B05 or A03.

OpenVMS V7.2-2 (minimum version required) requires OpenVMS Tima Kits located at:

http://ftp.support.compaq.com/patches/.new/openvms.shtml

Compaq AlphaStation ES40

1 1 1

1 1

Requires

Slot 0

8 4 -

DS-DMGGD-AA DS-DMGGD-BA DS-DMGGE-BC DS-DMGGE-BB

3R-A2976-AA 3R-A2977-AA 3R-A2978-AA 3R-A3458-AA 3R-A3459-AA

3R-A2979-AA

SN-PBXGF-AB

3X-DEPVZ-AA

SN-PBXGD-AD

SN-PBXGD-AE

DA-10392 North America — Version 57 — March 18, 2003

QuickSpecs

Options

Step 13 −−−− Monitors − Optional

• Graphics monitors other than those listed can be used if compatible with SVGA graphics ordered with system

• A video cable, 6-foot/1.8-meter length, is included with all variants of monitors.

• Video extension cable required if monitor is located more than 1 meter from server

• Monitors will ship with, but not be integrated with systems.

Compaq AlphaServer ES40

Compaq AlphaStation ES40

Carbon/Silver Monitors

Carbon/Silver Fla t Panel Monitors

Video Extension Cable 6-foot/1.8-meter video extension cable − optional

Monitor Power Cords

V7550 17-inch (16-inch viewable image size) flat-faced shadow mask color monitor, two-tone (carbon/silver), 0.25mm dot pitch, VGA to 1024 x 768 @85 Hz, MPRII/TCO 99/Energy Star Compliant, Northern Hemisphere with NA power cord, VGA cable

Same as above, with Euro power cord 3R-A4201-AA

Same as above, APD, no power cord 3R-A4202-AA

Same as above, with PRC power cord, CCIB 3R-A4446-AA

Same as above, Southern Hemisphere, with Australia/New Zealand power cord 3R-A4203-AA

P930 19-inch (18-inch viewable image size) auto-scanning color monitor, Diamondtron NF, 0.24-mm aperture grille pitch, VGA to 1600 x 1200 @85 Hz, MPRII/TCO 99/Energy Star Compliant, Northern Hemisphere with NA power cord, VGA cable, Same as above, with Euro power cord

Same as above, Taiwan, with NA power cord

Same as above, with PRC power cord, CCIB

Same as above, Southern Hemisphere, 0.25 to 0.27 mm aperture grille pitch, with Australia/New Zealand power cord

P1130 21-inch (19.8-inch viewable image size) FD Trinitron auto-scanning color monitor, Diamondtron NF, 0.24-mm aperture grille pitch, VGA to 1792 x 1344 @85Hz, dual video input, USB Hub, MPRII/TCO 99/Energy Star Compliant, Northern Hemisphere with NA power cord, VGA cable

Same as above, with Euro power cord

Same as above, Taiwan, no power cord

Same as above, with PRC power cord, CCIB

Same as above, Southern Hemisphere, with Australia/New Zealand power cord

TFT1825, 18-inch (18-inch viewable image size) TFT flat panel monitor, 0.28mm pixel pitch, 1600 x 1200 @60Hz, multi-mode support, MPRII/TCO99/Energy Star compliant,

one VGA, one DVI-I input connector. NA power cord, VGA and DVI-I cables

TFT1520, 15-inch (15-inch viewable image size) TFT flat panel monitor, 0.297 mm pixel pitch, 1024 x 768 @75 Hz, multi-mode support, MPRII/TCO99/Energy Star compliant, two video input connectors (one VGA and one DVI-I), NA power cord, VGA and DVI-I cables

North America, 120V, 75-inch BN26J-1K

Australia, New Zealand, 2.5-meter (103541-011) BN19H-2E

Central Europe, 2.5-meter BN19C-2E

Denmark, 2.5-meter (103541-481) BN19K-2E

Egypt, India, South Africa, 2.5-meter (103541-AR1) BN19S-2E

Israel, 2.5-meter BN18L-2E

Italy, 2.5-meter (103541-461) BN35M-02

Japan, 2.5-meter, Dentori approved 3X-BN46F-02

Switzerland, 2.5-meter (103541-511) BN19E-2E

UK, Ireland, 2.5-meter BN19A-2E

3R-A4002-AA

3R-A4215-AA

3R-A4391-AA

3R-A4392-AA

3R-A4394-AA

3R-A4393-AA

3R-A4216-AA

3R-A4396-AA

3R-A4397-AA

3R-A4400-AA

3R-A4398-AA

3R-A4292-AA

3R-A4249-AA

BN39C-02

DA-10392 North America — Version 57 — March 18, 2003

Compaq AlphaServer ES40

QuickSpecs

Options

Step 14 −−−− Keyboards, Mouse, Power Cords, Documentation Step 14a −−−− Keyboards −−−− Optional

Opal Carbon Keyboard/Language OpenVMS Tru64 UNIX and Linux OpenVMS

U.S. keyboard LK461-A2 3R-LKQ48-BA 3X-LK462-A2 Arabic keyboard - 3R-LKQ48-BR Belgian keyboard LK461-AB 3R-LKQ48-AB 3X-LK462-AB BHCSY keyboard - 3R-LKQ48-AX Canadian/English keyboard LK461-AQ - 3X-LK462-AQ Canadian/French keyboard LK461-AC 3R-LKQ48-AC 3X-LK462-AC Cyrillic keyboard (Russian) LK461-BT 3R-LKQ48-BT 3X-LK462-BT Czech keyboard LK461-BV 3R-LKQ48-BV 3X-LK462-BV Danish keyboard LK461-AD 3R-LKQ48-AD 3X-LK462-AD Dutch keyboard LK461-AH 3R-LKQ48-AH 3X-LK462-AH Finnish keyboard LK461-AF 3R-LKQ48-AF 3X-LK462-AF French keyboard LK461-AP 3R-LKQ48-AP 3X-LK462-AP German keyboard LK461-AG 3R-LKQ48-AG 3X-LK462-AG Greek keyboard LK461-BH 3R-LKQ48-BH 3X-LK462-BH Hebrew keyboard LK461-AT 3R-LKQ48-AT 3X-LK462-AT Hungarian keyboard LK461-BQ 3R-LKQ48-BQ 3X-LK462-BQ

International keyboard - 3R-LKQ48-BA Italian keyboard LK461-AI 3R-LKQ48-AI 3X-LK462-AI Japanese keyboard - 3R-LKQ48-AJ Korean keyboard - 3R-LKQ48-BK Latin-American keyboard - 3R-LKQ48-AR Norwegian keyboard LK461-AN 3R-LKQ48-AN 3X-LK462-AN Polish keyboard LK461-BP 3R-LKQ48-BP 3X-LK462-BP Portuguese keyboard LK461-AV 3R-LKQ48-AV 3X-LK462-AV Romanian keyboard LK461-BL - 3X-LK462-BL Simplified Chinese keyboard - 3R-LKQ48-CV Slovak keyboard LK461-CZ 3R-LKQ48-CZ 3X-LK462-CZ Spanish keyboard LK461-AS 3R-LKQ48-AS 3X-LK462-AS Swedish keyboard LK461-AM 3R-LKQ48-AM 3X-LK462-AM Swiss/French keyboard LK461-AK 3R-LKQ48-AK 3X-LK462-AK Swiss/German keyboard LK461-AL - 3X-LK462-AL Traditional Chinese keyboard - 3R-LKQ48-BI Thai keyboard - 3R-LKQ48-CB Turkish Q keyboard LK461-BU 3R-LKQ48-BU 3X-LK462-BU Turkish/F keyboard LK461-BW - 3X-LK462-BW UK keyboard - 3R-LKQ48-AE Yugoslavian keyboard LK461-BY - 3X-LK462-BY

• Select country-specific keyboard and mouse only if required.

• All keyboards listed may not be available in all geographies.

• Select an opal OpenVMS keyboard for use with VT5xx text terminals.

Compaq AlphaStation ES40

DA-10392 North America — Version 57 — March 18, 2003

Compaq AlphaServer ES40

QuickSpecs

Options

Step 14 −−−− Keyboards, Mouse, Power Cords, Documentation (continued) Step 14b − Mouse − Optional

Keyboard or Mouse Extension Cable 6-foot/1.8-meter keyboard or mouse extension cable; to extend both keyboard and Mouse 3-button mouse – carbon

Step 14c −−−− Power Cords Tower Power Cords

Tower and Pedestal Power Cords

North America 120V, 75-inch Australia, New Zealand, 2.5-meter (103541-011) Central Europe, 2.5-meter Denmark, 2.5-meter (103541-481) Egypt, India, South Africa, 2.5-meter (103541-AR1) Israel, 2.5-meter Italy, 2.5-meter (103541-461) Japan, 2.5-meter Switzerland, 2.5-meter (103541-511) UK, Ireland, 2.5-meter

Step 14d −−−− Documentation Additional AlphaServer ES40 System Information Kit (print and CD), Owners Guide,

mouse order two cables

• Tower enclosure ordered in North America includes 120V power cord; selection of

country-specific power cord is mandatory for all non-North American systems.

• Each additional power supply ordered with a system installed in tower enclosure

requires additional power cord

• Pedestal systems ordered in North America include two 120V power cords;

selection of two country-specific power cords is mandatory for all non-North American systems.

User Interface Guide, and Release Notes

Compaq AlphaStation ES40

3X-BC34A-06

3R-A3480-AA

BN26J-1K BN19H-2E BN19C-2E BN19K-2E BN19S-2E

BN18L-2E BN35M-02

3X-BN46F-02

BN19E-2E BN19A-2E

QA-6E88A-G8

DA-10392 North America — Version 57 — March 18, 2003

Compaq AlphaServer ES40

QuickSpecs

Options

Step 15−−−− Console Terminal − Optional

VT510 video terminal; requires keyboard, H8575-x adapter, and BC16E-x cable Console cable, female connector (25-pin passive adapter) Console cable, male connector (adapter with EOS, ESD, 25 POS D-SUB)

Step 16 −−−− Upgrade Kit −−−− Optional Upgrades ES40 Model 1 with six I/O slots and support for four memory options to ES40

Step 17 −−−− Software −−−− Required selection of media and documentation for first system on site

• Software Processor Code = E

Tru64 UNIX

When using Tru64 UNIX V5 .0A or later

When using Tru64 UNIX V4.0F

• Any terminal can be used as a console device

• Third-party console devices require an EIA-232 25-pin DSUB connector

Model 2 with 10 I/O slots and support for eight memory options

• AlphaServer ES40 Tru64 UNIX systems include Unlimited User license, Server

Extension license, Internet Express, and Secure Web Server

• AlphaStation ES40 Tru64 UNIX systems include preinstalled software, 2-user

Base license and Open3D traditional license

Tru64 UNIX media and online documentation on CD-ROM Tru64 UNIX full hard copy documentation StorageWorks Software Package, with licenses for Logical Storage Manager and

AdvFS Utilities TruCluster Server License Advanced Server for Tru64 UNIX, 25 client concurrent use license Advanced Server for Tru64 UNIX, 50 client concurrent use license Advanced Server for Tru64 UNIX, 100 client concurrent use license

Advanced Server for Tru64 UNIX, 250 client concurrent use license

Advanced Server for Tru64 UNIX, 500 client concurrent use license

Layered products media and documentation for Tru64 UNIX on CD-ROM

DECnet/OSI extended function license for Tru64 UNIX

DECnet/OSI end-system license for Tru64 UNIX

Open3D for Tru64 UNIX on CD-ROM, includes graphics drivers

Tru64 UNIX media and online documentation on CD-ROM

Tru64 UNIX full hard copy documentation

StorageWorks Software Package, with licenses for Logical Storage Manager and AdvFS Utilities

TruCluster Available Server License

TruCluster Production Server License

Tru64 UNIX Driver for MEMORY CHANNEL license

Advanced Server for Tru64 UNIX, 25 client concurrent use license

Advanced Server for Tru64 UNIX, 50 client concurrent use license

Advanced Server for Tru64 UNIX, 100 client concurrent use license

Advanced Server for Tru64 UNIX, 250 client concurrent use license

Advanced Server for Tru64 UNIX, 500 client concurrent use license

Layered products media and documentation for Tru64 UNIX on CD-ROM

DECnet/OSI end-system license for Tru64 UNIX

DECnet/OSI extended function license for Tru64 UNIX

Open3D for Tru64 UNIX on CD-ROM, includes graphics drivers

Compaq AlphaStation ES40

VT510-xx

H8575-A H8575-D

3X-KFPPA-AA

QA-6ADAA-H8 QA-6ADAA-GZ QB-5RXAE-AA

QL-6BRAE-AA QL-5U29M-3D

QL-5U29M-3

QL-5U29M-3F

QL-5U29M-3G

QL-5U29M-3H

QA-054AA-H8

QL-MTKAE-AA

QL-MTJAE-AA

QA-OAFAA-H8

QA-MT4AA-H8

QA-MT4AA-GZ

QB-5RXAE-AA

QL-05SAE-AA

QB-3RLAE-AA

QB-4ZCAE-AA

QL-5U29M-3D

QL-5U29M-3

QL-5U29M-3F

QL-5U29M-3G

QL-5U29M-3H

QA-054AA-H8

QL-MTJAE-AA

QL-MTKAE-AA

QA-OAFAA-H8

DA-10392 North America — Version 57 — March 18, 2003

QuickSpecs

Options

Step 17 −−−− Software −−−− Required selection of media and documentation for first system on site (continued) OpenVMS

• AlphaServer ES40 OpenVMS systems include Base license with System Manager

license and Enterprise Integration Server License Package for OpenVMS Revision V3.1

• AlphaStation ES40 OpenVMS systems include pre-installed software, Base

license, Concurrent Use 1-user license, NAS 150 Client license, MMS RT license and Open3D traditional license

• Enterprise Integration Package includes licenses for TCP/IP Services for

OpenVMS, DECwindows Motif for OpenVMS Alpha, DECprint Supervisor for OpenVMS Alpha Plus, DECprint Supervisor for OpenVMS Open, DECnet-Plus for OpenVMS Alpha End System, Archive/Backup System for OpenVMS

Management Tools, Archive/Backup Agent for Windows NT™, OpenVMS Disk

Services for Windows NT, Office Server for OpenVMS, PATHWORKS 32, PATHWORKS V6 for OpenVMS – Advanced Server, and DIGITAL Office Server Client Access License

• OpenVMS Concurrent Use licenses provide the right to interactively use the

operating system by the specified number of concurrent users on a designated OpenVMS system. OpenVMS Concurrent Use licenses can be moved from one system to another at user discretion and can be shared in a mixed OpenVMS VAX and OpenVMS Alpha cluster.

• OpenVMS Traditional Unlimited Use license is system specific and can only be

used on one system at a time. It cannot be shared between systems or in an

OpenVMS VAX or OpenVMS Alpha Cluster. Concurrent Use 1-user license

Concurrent Use 2-user license

Concurrent Use 4-user license

Concurrent Use 8-user license

Concurrent Use 16-user license

Concurrent Use 32-user license

Concurrent Use 64-user license

Concurrent Use 128-user license

Concurrent Use 256-user license

Traditional unlimited user license

OpenVMS V7.2-2 media and online documentation on CD-ROM

OpenVMS V7.3 media and online documentation on CD-ROM

OpenVMS media and documentation on CD-ROM

OpenVMS full hard copy documentation

Layered products media and documentation for OpenVMS on CD-ROM, includes Enterprise Integration Server for OpenVMS media and documentation.

DECnet extended function license for OpenVMS

DECnet end-system to extended function upgrade license for OpenVMS

OpenVMS Cluster license for Alpha systems

OpenVMS Volume Shadowing license

Compaq AlphaServer ES40

Compaq AlphaStation ES40

QL-MT3AA-3B

QL-MT3AA-3C

QL-MT3AA-3D

QL-MT3AA-3E

QL-MT3AA-3F

QL-MT3AA-3G

QL-MT3AA-3H

QL-MT3AA-3J

QL-MT3AA-3K

QL-MT2AE-AA

QA-MT1AR-H8

QA-MT1AT-H8

QA-MT1AA-H8

QA-001AA-GZ

QA-03XAA-H8

QL-MTGAE-AA

QL-MTHAE-AA

QL-MUZAE-AA

QL-2A1AE-AA

DA-10392 North America — Version 57 — March 18, 2003

Compaq AlphaServer ES40

QuickSpecs

Options

Step 18 −−−− Hardware and Software Support Services for Tru64 UNIX and OpenVMS

• Select one of the optional CarePaq™ Priority Service Packages described below that best support the customer’s operational

requirements for system availability.

CarePaq Priority Services

Program Features – Principal Server Priority •

•

• License Subscription for HP O/S software and embedded L/P (i.e., EIS for

• Consolidated Software Media Update Distribution for OpenVMS or Tru64 UNIX

Priority 24 •

•

• License Subscription for HP O/S software and embedded L/P (i.e., EIS for

• Consolidated Software Media Update Distribution for OpenVMS or Tru64 UNIX

Priority Silver •

• 24 x 7 Silver SW Support – Named Account Rep, 1-hour response Monday –

• License Subscription for HP O/S software and embedded L/P (i.e., EIS for

• Consolidated Software Media Update Distribution for OpenVMS or Tru64 UNIX

•

Priority Gold

•

• License Subscription for HP O/S software and embedded L/P (i.e., EIS for

• Consolidated Software Media Update Distribution for OpenVMS or Tru64 UNIX

•

• CarePaq Priority Services are available for AlphaServer systems running Tru64

UNIX or OpenVMS operating systems. Priority Services are designed for the

growing number of customers who need support beyond the basic warranty. It

offers five services packages − Priority, Priority 24, Priority Silver, Priority Gold,

and Priority Executive with coverage for both principal server systems and SSPs

(Subsequent System Packages) – that meet a full range of customer support

requirements.

9 x 5 HW/SW support

4-hour response on-site hardware support

2-hour response for Bronze software support

OpenVMS, unlimited users, and server extensions for Tru64 UNIX

and their layered products. (Some Layered products are not included on

Consolidated Software Media Update Distribution and can be ordered separately.)

24 x 7 HW/SW support

Named HW engineer

4-hour response on-site hardware support

2-hour response for Bronze software support

•

OpenVMS, unlimited users and server extensions for Tru64 UNIX

and their layered products. (Some Layered products are not included on

Consolidated Software Media Update Distribution and can be ordered separately.)

24 x 7 HW Support. Named Engineer, 4-hour response

Friday, 8AM-5PM local time; 2-hour response remaining hours

OpenVMS, unlimited users, and server extensions for Tru64 UNIX

and their layered products. (Some Layered products are not included on

Consolidated Software Media Update Distribution and can be ordered separately.)

Technical newsletter and SW activity review

Proactive Patch Notification

One System Healthcheck per year

•

24 x 7 HW support with Named Engineer, 4-hour response for on-site support

•

24 x 7 Gold SW support – Named Account Rep

30-minute callback (critical); 1-hour callback (non-critical)

OpenVMS, unlimited users, and server extensions for Tru64 UNIX

and their layered products. (Some Layered products are not included on

Consolidated Software Media Update Distribution and can be ordered separately.)

Technical newsletter, SW activity review and 10 hrs Upgrade impact planning

Proactive Revision Management

Two System Healthchecks per year

Mandatory pre-qualification required

Compaq AlphaStation ES40

DA-10392 North America — Version 57 — March 18, 2003

Compaq AlphaServer ES40

QuickSpecs

Options

Step 18−−−− Hardware and Software Support Services for Tru64 UNIX and OpenVMS (continued) Program Features – Principal Server (continued)

Priority Gold Executive • 24 x 7 HW support with Named Engineer, 2-hour response for on-site support

• 24 x 7 Gold SW support – Named Account Rep

• 30-minute callback (critical); 1-hour callback (non-critical)

• License Subscription for HP O/S software and embedded L/P (i.e., EIS for

• Consolidated Software Media Update Distribution for OpenVMS or Tru64 UNIX

• Technical newsletter, SW activity review and 10 hrs Upgrade impact planning

• Proactive Revision Management

• Two System Healthchecks per year

• Customer site must be within 25 miles of a HP service location

• Mandatory pre-qualification required

Program Features – Additional Services SSPs (Subsequent System Packages) • For Priority, Priority 24, Priority Silver, Priority Gold, and Priority Gold Executive

• HW Support at same level as corresponding package for Principal server

• License Subscription: HP O/S (where applicable)

• Telephone support through Principal server covered by full support package

Installation • Preinstallation review

• Unpacking of equipment

• Assemble and test

• Basic product usage info

• No software installation added

Installation & Startup HP O/S

• Assemble and test

• Basic product usage info

• Install operating systems

• Product configuration

• Print & network access

• Orientation

OpenVMS, unlimited users, and server extensions for Tru64 UNIX.

and their layered products. (Some Layered products are not included on

Consolidated Software Media Update Distribution and can be ordered separately.)

• Preinstallation review

• Unpacking of equipment

Compaq AlphaStation ES40

DA-10392 North America — Version 57 — March 18, 2003

Compaq AlphaServer ES40

QuickSpecs

Options

Step 18 −−−− Hardware and Software Support Services for Tru64 UNIX and OpenVMS (continued) Model/CarePaq

Priority Service AlphaServer ES40 Model 1 Pedestal

Priority FP-F01AA-12 FP-F01AA-36 FP-F21AA-12 FP-F21AA-36 Priority 24 FP-F02AA-12 FP-F02AA-36 FP-F22AA-12 FP-F22AA-36 Priority Silver FP-F04AA-12 FP-F04AA-36 FP-F24AA-12 FP-F24AA-36 Priority Gold FP-F08AA-12 FP-F08AA-36 FP-F28AA-12 FP-F28AA-36 Priority Gold Exec. FP-F09AA-12 FP-F09AA-36 FP-F29AA-12 FP-F29AA-36 Installation FP-FINST-AA FP-FINST-AA FP-FINST-AA FP-FINST-AA Installation & Startup FP-FSTAR-AA FP-FSTAR-AA FP-FSTAR-AA FP-FSTAR-AA

AlphaServer ES40 Model 2 Pedestal

Priority FP-F01BA-12 FP-F01BA-36 FP-F21BA-12 FP-F21BA-36 Priority 24 FP-F02BA-12 FP-F02BA-36 FP-F22BA-12 FP-F22BA-36 Priority Silver FP-F04BA-12 FP-F04BA-36 FP-F24BA-12 FP-F24BA-36 Priority Gold FP-F08BA-12 FP-F08BA-36 FP-F28BA-12 FP-F28BA-36 Priority Gold Exec. FP-F09BA-12 FP-F09BA-36 FP-F29BA-12 FP-F29BA-36 Installation FP-FINST-BA FP-FINST-BA FP-FINST-BA FP-FINST-BA Installation & Startup FP-FSTAR-BA FP-FSTAR-BA FP-FSTAR-BA FP-FSTAR-BA

AlphaServer ES40 Model 1 Tower/Drawer

Priority FP-F01CA-12 FP-F01CA-36 FP-F21CA-12 FP-F21CA-36 Priority 24 FP-F02CA-12 FP-F02CA-36 FP-F22CA-12 FP-F22CA-36 Priority Silver FP-F04CA-12 FP-F04CA-36 FP-F24CA-12 FP-F24CA-36 Priority Gold FP-F08CA-12 FP-F08CA-36 FP-F28CA-12 FP-F28CA-36 Priority Gold Exec. FP-F09CA-12 FP-F09CA-36 FP-F29CA-12 FP-F29CA-36 Installation FP-FINST-CA FP-FINST-CA FP-FINST-CA FP-FINST-CA Installation & Startup FP-FSTAR-CA FP-FSTAR-CA FP-FSTAR-CA FP-FSTAR-CA

AlphaServer ES40 Model 2 Tower/Drawer

Priority FP-F01DA-12 FP-F01DA-36 FP-F21DA-12 FP-F21DA-36 Priority 24 FP-F02DA-12 FP-F02DA-36 FP-F22DA-12 FP-F22DA-36 Priority Silver FP-F04DA-12 FP-F04DA-36 FP-F24DA-12 FP-F24DA-36 Priority Gold FP-F08DA-12 FP-F08DA-36 FP-F28DA-12 FP-F28DA-36 Priority Gold Exec. FP-F09DA-12 FP-F09DA-36 FP-F29DA-12 FP-F29DA-36 Installation FP-FINST-DA FP-FINST-DA FP-FINST-DA FP-FINST-DA Installation & Startup FP-FSTAR-DA FP-FSTAR-DA FP-FSTAR-DA FP-FSTAR-DA

Principal Server

1 year

Principal Server

3 years

Compaq AlphaStation ES40

Subsequent Systems

1 year

Subsequent Systems

3 years

NOTES:

• AlphaServer ES40 systems include three years hardware warranty with 5 x 9, on-site Next Business Day response.

• New HP hardware options internal to the AlphaServer enclosure receive the same warranty or service level as purchased with the server.

• External storage devices/cabinets carry their own level of warranty and should be quoted separately for uplifted warranty services (CarePaq

Priority Service).

• In addition to the CarePaq Priority Services, uplifted warranty Supplemental Services are available for separate hardware and software support.

For more information on Hardware and Software Supplemental Services and other HP service options available for AlphaServers, consult a Sales Account Manager or visit http://www.compaq.com/services/

NOTE: This website is available in English only.

DA-10392 North America — Version 57 — March 18, 2003

Compaq AlphaServer ES40

QuickSpecs

Compaq AlphaStation ES40

Options

Step 19 −−−− Hardware Supplemental Support Services for Linux −−−− Optional Hardware - Americas and Asia Pacific

Only

Add-on memory installation for ES40 FM-64MEM-IN Add-on SMP CPU installation for ES40 FM-64CPU-IN NOTE: Add-on installation part numbers should be used when options are added to

Hardware - Europe Only Europe does not offer specific part numbers for Hardware Supplemental Support

• Systems include three-year hardware warranty, onsite with 5 x 9, 24-hour

response time

• Options ordered as part of initial system sale take on warranty of the enclosure

• Options added after initial system sale take on warranty of the enclosure until

enclosure warranty ends

• All unique ES40 options have a minimum of one-year Return to Hewlett-Packard

Warranty

• Select optional Hardware Supplemental Support Services if required

Supplemental Service for ES40 Tower System

3-year, 5 x 9, 4-hour response time FM-4T4HR-36 FM-4Q4HR-36

5-year, 5 x 9, 4-hour response time FM-4T4HR-60 FM-4Q4HR-60

3-year, 7 x 24, 4-hour response time FM-4T724-36 FM-4Q724-36

5-year, 7 x 24, 4-hour response time FM-4T724-60 FM-4Q724-60

5-year, 5 x 9, next day, on-site FM-4TXHW-60 FM-4QXHW-60

Supplemental Service for ES40 Pedestal System

3-year, 5 x 9, 4-hour response time FM-4F4HR-36 FM-4G4HR-36

5-year, 5 x 9, 4-hour response time FM-4F4HR-60 FM-4G4HR-60

3-year, 7 x 24, 4-hour response time FM-4F724-36 FM-4G724-36

5-year, 7 x 24, 4-hour response time FM-4F724-60 FM-4G724-60

5-year, 5 X 9, next day, on-site FM-4FXHW-60 FM-4GXHW-60

Installation Services

Hardware product installation for ES40 Tower System FM-4TINS-IN FM-4QINS-IN

Hardware product installation for ES40 Pedestal System FM-4FINS-IN FM-4GINS-IN

existing systems.

Services. Prices are quoted based on worldwide service reference pricing. Contact MCS Sales in your country for information on Hardware Supplemental Support

Services.

Model 1 Model 2

DA-10392 North America — Version 57 — March 18, 2003

QuickSpecs

Technical Specifications

Compaq AlphaServer ES40

Compaq AlphaStation ES40

Tower Configuration

Pedestal Configuration

Rackmount System

Dimensions (H x W x D) Shipping Dimensions Weight

Shipping Weight

Clearances

Front

Rear

Left Side

Right Side

Dimensions (H x W x D) Shipping Dimensions Weight

Shipping Weight

Clearances

Front

Rear

Left Side

Right Side

Dimensions (H x W x D)

Shipping Dimensions Weight

Shipping Weight

Clearances

20 x 15.25 x 31 in/50.8 x 38.7 x 78.7 cm

32.2 x 24 x 40 in/82.48 x 60.2 x 101.6 cm

Typical Configuration 144.3 lb/65.6 kg

Maximum Configuration 212.8 lb/96.7 kg

Typical Configuration 172 lb/78 kg

Maximum Configuration 242 lb/110 kg

Operating Service

29.5 in/75 cm 29.5 in/75 cm

6 in/15 cm 29.5 in/75 cm

None 29.5 in/75 cm

None None

30.8 x 20 x 31.75 in/78.2 x 50.8 x 80.6 cm

42.4 x 39.5 x 23.9 in/107.7 x 100.3 x 60.7 cm

Typical Configuration 280 lb/127 kg

Maximum Configuration 350 lb/159 kg

Typical Configuration 328 lb/149 kg

Maximum Configuration 407 lb/185 kg

Operating Service

29.5 in/75 cm 29.5 in/75 cm

6 in/15 cm 29.5 in/75 cm

None None

None 29.5 in/75 cm

13.87 x 17.6 x 30.1 in/35.2 x 44.7 x 76.5 cm (fits 14 in [8U] standard RETMA cabinet)

28.8 x 24 x 40 in/73.2 x 60.7 x 101.6 cm

When lifting:

Nominal 110 lb/50 kg

Maximum 167.2 lb/76 kg

Total added to cabinet (brackets, slides, cables):

Nominal 130 lb/59 kg

Maximum 202.4 lb/92 kg

Nominal 158 lb/72 kg

Maximum 233 lb/106 kg

Operating Service

See specific cabinet requirements

Minimum 4 ft/121.9 cm, 30 in/76.3 cm withdrawal on rails

DA-10392 North America — Version 57 — March 18, 2003

QuickSpecs

Technical Specifications

Compaq AlphaServer ES40

Compaq AlphaStation ES40

Cabinet Configuration

System Unit

H9A10 M-Series H9A15 M-Series Dimensions (H x W x D)

(Depth includes rear door

extender)

Shipping Dimensions

Weight Shipping Weight

ENVIRONMENTAL

Temperature

Humidity

Maximum Wet Bulb Temperature

Maximum Dew Point Temperature

Heat Dissipation

Tower and Rack

Pedestal

H9A10/H9A15 Cabinets

Air Flow and Quality

Altitude (unpressurized)

67 x 23.6 x 41.5 in/ 170 x 60 x 105.4 cm

73 x 36 x 48 in/

185.5 x 91.5 x 122 cm

Configuration dependent Configuration dependent

Nominal: 946 lb/430 kg Nominal: 1,056 lb/550 kg

Maximum: 1,375 lb/625 kg Maximum: 1,408 lb/640 kg)

Operating (Tower, Pedestal, Rackmount)

Non-operating

Storage (60 days)

Rate of change

NOTE: Maximum operating temperature at sea level; reduce by 1.8°F (1°C) for

each 2,000 ft (600 m) above sea level.

Operating 20% to 80%

Non-operating 20% to 80%

Storage (60 days) 10% to 95%

Rate of change 20% hr

Operating 82° F/28° C Storage (60 days) 115° F/46° C Operating 36° F/2° C

Nominal Maximum

Intake location Front

Exhaust location Rear Tower, Pedestal, Rack; Rear/top

Particle size N/A

Concentration N/A

Operating 10,000 ft/3,048 m

Non-operating 40,000 ft/12,192 m

NOTE: Higher altitudes are possible if maximum operating temperature is

reduced (see Temperature); other restrictions may apply such as maximum permissible altitude for hard drives.

79 x 23.6 x 41.5 in/ 200 x 60 x 105.4 cm

85 x 36 x 48 in/ 216 x 91.5 x 122 cm

50° to 95° F/10° to 35° C

–40° to 151° F/–40° to 66° C –40° to 151° F/–40° to 66° C 20° F/hr/11° C/hr

900 W, 3,074 BTU/hr 1300 W, 4,440 BTU/hr

1480 W, 5,054 BTU/hr

Configuration dependent

H9A10/H9A15

2400 W. 8,196 BTU/hr

4800 W, 16,392 BTU/hr

DA-10392 North America — Version 57 — March 18, 2003

QuickSpecs

Technical Specifications

Compaq AlphaServer ES40

Compaq AlphaStation ES40

System Unit (continued)

ACOUSTICS

Acoustics

ELECTRICAL

Nominal Voltage (VAC) Voltage Range (VAC)

(temporary condition)

Power Source Phase Nominal Frequency (Hz) Frequency Range (Hz) RMS Current

Power Cords

(Declared values per ISO 9296 and ISO 7779)

(Power supplies are universal, PFC, auto ranging, 100/240 VAC)

Idle 6.6 48

Operating 6.6 48

NOTE: Current values for specific configurations are available, 1 B = 10 dBA.

100 120 200 to 240

90 to 100 110 to 128 180 to 250

Single Single Single

50/60 50/60 50/60

49 to 51/59 to 61 49 to 51/59 to 61 49 to 51/59 to 61

Tower and Rackmount Single power cord 11.0 A 8.5 A 5.0 A

Multiple power cords 6.5 A 5.3 A 3.0 A

Maximum VA 1,300 1,270 1,250

Pedestal Each power cord 12.0 A 10.5 A 6.0 A

Maximum VA 1,960 1,900 1,880

M-Series Cabinet (configuration dependent)

Each power cord 24 A 24 A 16 A

Tower Up to 3 (75 in/190

Pedestal 2 (75 in/190 cm) 120V non-removable NEMA

Rackmount 3 (14 ft 10 in/52 cm) IEC 320 C13 to NEMA 5-15

Cabinet 2 (10 ft 10 in/30 cm) 120V non-removable NEMA

B L

WAd3

Nominal voltage (VAC)

cm)

dBA

nAm5

(bystander position)

100 120 220 to 240

IEC 320 C13 to NEMA 5-15 (North America) or IEC 320 C13 to country-specific

5-15 (N. America) or 200-240V IEC 320 C13 to country-specific

(North America) or IEC 320 C13 to IEC 320 C14 (other countries)

L5-30P or 200-240V nonremovable IEC 309

DA-10392 North America — Version 57 — March 18, 2003

QuickSpecs

Technical Specifications

Compaq AlphaServer ES40

Compaq AlphaStation ES40

System Unit (continued)

Hewlett-Packard, the Hewlett-Packard logo, AlphaServer, AlphaStation, OpenVMS, StorageWorks, CarePaq, Tru64, and TruCluster are trademarks of Hewlett-Packard Company in the U.S. and/or other countries. UNIX is a registered trademark or trademark of The Open Group in the U.S. and/or other countries. All other product names mentioned herein may be trademarks of their respective companies.

Hewlett-Packard shall not be liable for technical or editorial errors or omissions contained herein. The information is provided ″as is″ without warranty of any

kind and is subject to change without notice. The warranties for Hewlett-Packard products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty.

ELECTRICAL

Regulatory

(Power supplies are universal, PFC, auto ranging, 100/240 VAC) (continued)

Agency Approvals UL: Listed to UL1950 (third edition)

CSA: Certified to CAN/CSA-C22.2

No. 950-M95

TUV: EN 60950/A4: 1997 VDE 0805 GS

marked

FCC: Part 15.B Class A

CE: EN55022, EN50082

VCCI Class II ITE

BCIQ: CISPR22, CNS13438

C-Tick: CISPR22, AS/NZS 3548

Reviewed to AS/NZ 3260:1993 Australian/New Zealand

Standard

EN 60950/A4: 1997 European Norm IEC 950 (second edition, third amend)

DA-10392 North America — Version 57 — March 18, 2003

Compaq DA-64CAA-DA - AlphaServer - ES40 Model 2, AlphaServer ES40, AlphaStation ES40 Specification

Specifications and Main Features

Frequently Asked Questions

User Manual
