User Manual
Audio Phone AP-2R
• Thank you for purchasing COMMAX products.
• Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow
instructions to use a product exactly.
• The company is not responsible for any safety accidents caused by abnormal operation of the product.
AG
1. W arnings and Caution
To prevent fire or shock hazard, do not expose
the unit to rain or moisture.
This symbol is intended to alert the use to the
presence of uninsulated
within the product’s enclose that
may be of sufficient magnitude to constitute a risk of
electric shock to persons.
This symbol is intended to alert the use to the
presence of important operating and maintemance
(servicing) instructions in the literature
accompanying the appliance
CAUTION : To reduce the risk of electric shock, do not
remove cover(or back) no user-serviceable
part inside refer servicing to qualified service
personnel.
* Caution
Do not place the handset close to your ear and
operate the hook switch.
You may damage your hearing because of the sound
produced during product operation.
“
“
dangerous Voltage
caution
Risk of electric shock
do not open
”
”
2. Overview
3. Wiring
Non polarity
Installation
4. Operation
Call from a lobby phone
• When the lobby phone pages, you can hear the ring tone.
• When you pick up the handset, you can talk to a visitor at the lobby phone.
• You can open the door if you press the door release button or hook switch while you are
talking to a visitor at the lobby phone.
• When you finish the call, please hang up.
Call from a guard station
•
When the guard station pages, you can hear the melody.
•
When you pick up the handset, you can talk to guard.
• When you finish the call, please hang up.
Call a guard station
•
When you pick up the handset, it pages the guard station automatically.
At that time, you can hear the recall sound from the handset.
•
When the guard station answers your call, you can talk to guard.
•
If you want to talk to other household units, the guard station can transfer
your call during the call with guard.
• When you finish the call, please hang up.
Power source
Transmission 2 wires with non-polarity
Paging sound Lobby : Electric chime bell, Guard : Melody
Distance
Operation Temp. 0°C ~ +40°C
Dimension(mm)
From floor distributor
100m( 0.65
With handset : 60(W) x 210(H) x 48(D)
Ø)
513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea
Int’l Business Dept. : Tel.; +82-31-7393-540~550 Fax.; +82-31-745-2133
Web site : www.commax.com
Edited 2019.05.23
