Comelit 3183SV Specsheet

DATA SHEET

COD.

3183SV

VANDALCOM VISUAL/ACOUSTIC SIGNALLING UNIT

The Vandalcom Unit Art. 3183SV is used to visually and acoustically signal the system
operating status by playing voice messages and through 4 colored LEDs: 1 red LED: call
on hold, waiting for a reply, 2 yellow LED: conversation in progress, 3 green LED:
doorrelease active and 4 blue LED: line busy. This unit can be mounted on Simplebus 2
and Simplebus Color systems.

Main specifications

Vandal Resistant IK: Yes

Compatibility

Simplebus Top system: Yes
Simplebus Color system: Yes
Simplebus 2 system: Yes
Comtel system: Yes

Mounting/Installation

Flush-mounted: Yes
Wall-mounted: Yes
Surface-mounted: Yes

Audio/video specifications

Audio system: Yes
Audio/video system: Yes

Hardware specifications

Customisable housing: No
DDE function: Yes

Technical properties

Temperature range (°C): -25/55

Electrical specifications

Maximum current absorption (mA): 100

The technical specifications are subject to variations without warning

DATA SHEET

General info

EAN product code: 8023903194661
Intrastat code: 85176920
Product height (mm): 106
Product width (mm): 106
Product depth (mm): 30
Product colour: GREY

Packaging

Single pack height (mm): 126
Single pack width (mm): 126
Single pack weight (g): 530
Single pack depth (mm): 38
Single pack volume (dm3): 0,603

The technical specifications are subject to variations without warning
