Page 1
Vandalcom
Vandalcom is Comelit’s vandalproof stainless steel entrance panel,
specially studied to resist even the most violent attacks. It is available
in the audio, audio-video and digital versions.
Vandalcom can fit in with any type of building. Its frame is available
in 2 different colours – steel grey and dark grey - to show that the
entrance panel is not only sturdy but also has a pleasant design.
The technology used for Vandalcom is the first and major guarantee
of reliability: galvanised sheet steel boxes 1.5 mm thick, vandalproof
modules made with 2 thick stainless steel plates, stainless steel
pushbuttons with short run, and security screws.
The entrance panel is rated to IP54.
20
Page 2
VANDALCOM
Vandalcom
21
21
Page 3
Simplebus Color | Vandalcom Entrance panel
3159 Stainless steel surface-mounted housing
No. Modules Article Dimensions
1 3159/1 142x142x58 mm
2 3159/2 142x254x58 mm
3 3159/3 142x366x58 mm
3160 Flush-mounted box
Made of 1.5 mm thick galvanized sheet, complete with special
spacers for joining and templating several boxes.
No. Modules Article Dimensions
1 3160/1 130x130x58 mm
2 3160/2 130x242x58 mm
3 3160/3 130x354x58 mm
3161 Module Holder Frame
Made of die-cast aluminium and painted using special powder
paints resistant to external environments. Dark grey colour.
No. Modules Article Dimensions
1 3161/1 143x143x18 mm
2 3161/2 143x255x18 mm
3 3161/3 143x367x18 mm
3161/A Module Holder Frame
Made of die-cast aluminium and painted using special powder
paints resistant to external environments.
Steel grey colour.
No. Modules Article Dimensions
1 3161/1A 143x143x18 mm
2 3161/2A 143x255x18 mm
3 3161/3A 143x367x18 mm
3262 Module preset for audio speaker unit
Made of double 2.5 mm stainless steel plate.
To be fitted with the relative audio speaker unit art. 1602 or art.
1602VC.
No. Pushbuttons Article Dimensions
0 3262/0 106x106x5.6 mm
1 3262/1 106x106x5.6 mm
2 3262/2 106x106x5.6 mm
3268 Vandalcom Module preset for audio/video unit
Module made of double 2.5 mm stainless steel plate.
To be fitted with audio/video unit art. 4660C.
n. Pushbuttons Article Dimensions
0 3268/0 106x106x5.6 mm
1 3268/1 106x106x5.6 mm
2 3268/2 106x106x5.6 mm
22
Page 4
3064/A 4-pushbutton module
Module made of double 2.5 mm stainless steel plate, complete
with 4 traditional pushbuttons for the Simplebus digital system.
Has an EEPROM memory on board to memorize the call code.
Dimensions: 106x106x56 mm
3070/A Stainless Steel electronic call module for
Simplebus system
Made of double 2.5 mm stainless steel plate, complete with 12
stainless steel pushbutton keypad illuminated from the rear, 16character alphanumerical display for showing the call codes and
interactive messages with the user (engaged, etc.). Also carries
out the electronic coded key function with 300 possible different
codes with 6 digits. The device controls the relay on board Art.
3262 and 3268. It is compatible with Art. 3062. With the PC
software Art. 1249, it is possible to download codes (up to 6 digits)
for calls with indirect addressing. Dimensions: 106x106x56 mm
3072/A Stainless Steel electronic name directory module
for Simplebus system
Made of double 2.5 mm stainless steel plate, complete with 4
stainless steel pushbuttons illuminated from the rear and 32character alphanumerical display. Memorises 400 user names.
Name scrolling is carried out using 2 search pushbuttons. Once
the name is displayed, simply press the call button. User
programming is simple by means of programmer Art. 1230 or
using dedicated software for P.C. Art. 1249.
Also compatible with Art. 3062. Dimensions: 106x106x56 mm
VANDALCOM
3176 Plain stainless steel module for Vandalcom
entrance panels
Made of double 2.5 mm stainless steel plate.
Dimensions: 106x106x9 mm
3178 Traditional stainless steel PTT module for
Vandalcom entrance panels
Made of double 2.5 mm stainless steel plate, preset for PTT key.
Dimensions: 106x106x9 mm
3182 Stainless steel module without label for Vandalcom
entrance panels
Made of double 2.5 mm stainless steel plate without nameplate
label, to be etched by the user with 4, 8 or 12 pushbuttons.
No. Pushbuttons Article Dimensions
4 3182/4 106x106x56 mm
8 3182/8 106x106x56 mm
12 3182/12 106x106x56 mm
Product Catalogue
23
23
Page 5
Simplebus Color | Vandalcom Entrance panel
3183 Vandalcom series module for signalling system engaged for
Comelbus and Simplebus digital systems
Made of double 2.5 mm stainless steel plate, it is used to indicate the engaged
state of systems with traditional entrance panels. Complete with flashing LED for
visual indication of the system state. The white translucent card is supplied blank
for writing any instructions. Dimensions: 106x106x56 mm
3186 Stainless steel information / nameplate module
Module made of double 2.5 mm stainless steel plate, complete with white label for
general information (house n°, etc.) and pre-printed label with space for writing
the names of 12 users. Dimensions: 106x106x9 mm
3188 Stainless steel Vandalcode access control module for
Vandalcom entrance panels
Made of double 2.5 mm stainless steel plate, complete with keypad illuminated
from the rear. Has 300 different 8 digit codes available which can be programmed
from the keypad to control two relays (10A), operation confirmation buzzer tones
and relay actuation LED. Relay closing time can be programmed from the keypad.
Power supply: 12V AC/DC. Dimensions: 106x106x56 mm
3195 Vandalock electronic key module
Proximity reader module able to recognise special "electronic keys" (credit card
or key ring type) with a relay. Readout is done without any contact between the
key and the reader. Up to a maximum of 660 keys. Power supply 12V AC/DC.
Dimensions: 106x106x56 mm
3198 Anti-tampering element
Anti-tampering element to be inserted in the flush-mounted box, useful for
indicating any tampering with the entrance panel.
Dimensions: 51x18x13 mm
1172 Spare bulb
24V/3W festoon bulb for nameplate label lighting. Pack of 10 pieces.
1602 Audio speaker unit for Simplebus system
Audio speaker unit for Simplebus system with terminal board and double amplifier,
watertight loudspeaker and electret microphone, both microphone and
loudspeaker volumes can be adjusted from the front. Complete with microprocessor
and DIP SWITCH with 8 positions for programming the calls to the users. 12 V AC
power supply (use Art. 1395). Electronic door-opening function on board (3A). To be
inserted in modules Art. 3262/0, 3262/1 and 3262/2. Dimensions: 102x55x35 mm
1602VC
Module for remote camera
Module which allows modulation and transmission of the video signal on the riser.
On input it has the composite video signal of a colour camera.
Power supply: 12V AC. Dimensions: 102x55x35 mm.
24
Page 6
4660C Audio video unit with colour camera
Simplebus system audio-video unit with terminal board complete with 1/4" pinhole CCD colour camera adjustable from the front, and LED camera illumination.
Complete with audio speaker unit with double amplifier, watertight loudspeaker
and electret microphone; both microphone and loudspeaker volumes can be
adjusted from the front. To be inserted in modules arts. 3321/0, 3321/1 e 3321/2.
Dimensions: 102x55x35 mm
1026 Electronic card key for art. 3195
Electronic proximity key in credit card format. 5 cm reading distance. To be used
with art. 3195
1027 Electronic Key fob for art. 3195
Electronic proximity key. Fob type format and dimensions. 5 cm reading
distance. To be used with Key art. 3195.
1028 Programmer for art. 3195
Optional programmer for enabling / disabling the electronic keys for Art. 3195.
Supplied by batteries not provided. Only needed if you want to have the
“disabling” function of the keys in the case of not possessing the keys
themselves, or to change the time of the door opener.
Can only be used with art. 3195.
VANDALCOM
Product Catalogue
25
25
