DATA SHEET

COD.

3072B

SIMPLEBUS DIGITAL DIRECTORY MODULE, VANDALCOM
SERIES

Made using a double 2.5 mm stainless steel plate, complete with 4 backlit stainless steel
buttons and 32-character alphanumeric display. Stores up to 1000 usernames. 2 search
buttons are used to scroll though the names. Once the desired name is displayed, simply
press the call button. User programming is easy, thanks to programmer art. 1230 or PC
software art. 1231/6D. Dimensions: 106x106x56 mm. From IR10 it is compatible with all
SBTOP products and functions. It can be used for the call addressing of up to 120000
users.

Main specifications

Backlighting color: Green led

Software/firmware specifications

No. user codes: 1500
No. of storable users: 1500

Functions

Key button function: No

Hardware specifications

Vandal Resistant IK: Yes
Customisable housing: No
Visual signalling: No
Acoustic signalling: No
Total buttons: 4
Sensitive Touch technology: No

General info

Product height (mm): 106
Product width (mm): 106
Product depth (mm): 56
Product colour: Grey
Operating temperature (°C): -25 ÷ 55

Compatibility

Simplebus Top system: Yes

The technical specifications are subject to variations without warning

DATA SHEET

Simplebus Color system: Yes
Simplebus 2 system: Yes

Mounting/Installation

Flush-mounted: Yes
Wall-mounted: Yes

Audio/video specifications

Display resolution (H x V): 16x2 characters
Audio system: Yes
Audio/video system: Yes
Type of display: Alphanumeric

Connectivity

Type of connections/ports: RS232, RS485, Infrared
Infrared port: Yes
RS232 ports: 1
RS485 ports: 1

Electrical specifications

Maximum current absorption (mA): 100

The technical specifications are subject to variations without warning
