Code 3 920-06 Flashers User Manual
INSTALLATION MANUAL
920-06 Headlight Flasher for 2006 Chevy920-06 Headlight Flasher for 2006 Chevy
920-06 Headlight Flasher for 2006 Chevy
920-06 Headlight Flasher for 2006 Chevy920-06 Headlight Flasher for 2006 Chevy
Impala Police Package VehicleImpala Police Package Vehicle
Impala Police Package Vehicle
Impala Police Package VehicleImpala Police Package Vehicle
900 Series Plug In Flasher
Read all instructions and warnings before installing and using.
IMPORTANT:
INSTALLER: This manual must be delivered
to the end user of this equipment.
W ARNING!
Larger wires and tight connections will provide longer service life
for components. For high current wires it is highly recommended
!
WARNING!
that terminal blocks or soldered connections be used with shrink
tubing to protect the connections. Do not use insulation displacement connectors (e.g. 3M®) Scotchlock type connectors. Route
wiring using grommets and sealant when passing through
compartment walls. Minimize the number of splices to reduce
voltage drop. High ambient temperatures (e.g. underhood) will
significantly reduce the current carrying capacity of wires, fuses,
and circuit breakers. Use "SXL" type wire in engine compartment.
All wiring should conform to the minimum wire size and other
recommendations of the manufacturer and be protected from
moving parts and hot surfaces. Looms, grommets, cable ties,
and similiar installation hardware should be used to anchor and
protect all wiring.
Fuses or circuit breakers should be located as close to the power
takeoff points as possible ad properly sized to protect the wiring
and devices. Particular attention should be paid to the location
and method of making electrical connections and splices to
protect these points from corrosion and loss of conductivity.
Ground (Earth) termination should only be made to substantioal
chassis components, preferably directly to the vehicle battery.
The user should install a circuit breaker sized to approximately
125% of the anticipated maximum current requirements to
protect against short circuits. For example, a 30 Amp circuit
breaker should carry a maximum of 24 amps.
This Product contains high intensity LED
devices. To prevent eye damage, DO NOT
stare into light beam at close range.
DO NOT USE 1/4" DIAMETER GLASS FUSES AS THEY ARE NOT
SUITABLE FOR CONTINUOUS DUTY IN SIZES ABOVE 15 AMPS.
Circuit breakers are very sensitive to high temperatures and will
"false trip" when mounted in hot environments or operated close
to their capacity.
2
IMPORTANT NOTES:
••
• The use of a flashing headlight system may be regulated by state,
••
county, or municipal authorities. It is the responsibility of the end user
to comply with these regulations.
••
• Before attempting the installation of the 920 headlight flasher, thoroughly
••
read and understand instructions and steps shown below.
••
• Disconnect the battery from the electrical system
••
before attempting any part of this installation.
••
• Have your “Impala Police Package Owner’s Manual Supplement”
••
available for reference.
Installation:
1. Locate and remove the three, plastic fasteners that secure the cowl
panel covering the area between the top of the radiator support and
the top of the grille. Remove this panel from the vehicle.
NOTE: Each fastener must be returned to its original location when re-
installing this panel.
2. Locate and remove the two, passenger-side headlight pillar bolts
(see fig. 1).
3
