Cobra Electronics 9907 Users manual

Action-Sports Camera

Part # 9907

User Manual

Please read through this user manual before using the product and keep the
manual for future reference. Product appearance and/or specifications are

subject to change without notification.

WASPcam is a division of 636 Distributing Inc.

Ariss, ON

519-822-8400

TABLE OF CONTENTS

Safety Precautions 3
System Requirements / Features 4
Accessories 5
Camera Function Quick Guide Diagram 6-7
Button Functions 7
Installing SD Card 8
Using the LED Lights 8
Charging the Battery 8
Turning the Camera On/Off 8
LCD Screen 8
Maintaining Waterproof Seal 9
Recording Functions 9-10
Image Rotation 10
Photos 10-12
Zoom / Playback Mode 11
Deleting / Protecting Files / Slide Show 12
Menu Interface Introduction 12
Video Menu Settings 12-13
System Menu Settings 13
Photo Menu Settings 13-14
Using the Camera’s Wi-Fi 14-16
Installing the WASPcam App 14
WASPcam App Interface 16-17
Remote Control (Functions & Indicators) 18
Connecting to External Devices 19
Technical Specifications 20
Copyright Notice 20

2

Safety Precautions

• Read the following guidelines before using this camera

• Refer to the manual instructions to operate the camera properly. Improper

operation may cause damage to camera internal components

• Do not store the product in dusty, dirty, or sandy areas, as its components
may be damaged

• Do not leave the camera in places exposed to extremely high temperatures, such
as direct sunlight for extended periods of time. High temperatures can shorten
the life of electronic devices, damage batteries and warp or melt certain plastics

• Do not store the product in cold areas. When the product warms up to its
normal temperature, moisture can form inside, which may damage the
electronic circuits

• Do not attempt to open the casing or attempt your own repairs. High-voltage
internal components create the risk of electric shock when exposed

• Do not drop or knock the product. Rough handling may damage the
internal components

• Do not use harsh chemicals, cleaning solvents or strong detergents to
clean the product. Wipe the product with a slightly damp soft cloth

• Do not open the battery cover while an image is being recorded. Doing so will
not only make storage of the current image impossible, it can also corrupt
other image data already stored on file

• If the product or any of its accessories are not working properly, please con
636 Distributing Inc. and our tech team will assist you and if necessary, arrange
for the product to be repaired or replaced

• It is recommend to use the camera in temperatures between 0°C to 40°C

• Turn off the camera before removing the memory card, to avoid damaging the

card or storage data

• It is normal for the camera to be warm after long periods of use

• Do not touch the lens while using the camera or it can affect video/picture

quality

• Please use the air blower (special lens blowing equipment) to clean lens or use
special lens-cleaning cloth to clean fingerprint or dust on the surface

• Always test for proper operation before using the camera

• 636 Distributing Inc. is not responsible for any damage or personal injuries

resulting from the use of the WASPcam or for replacing it if lost or stolen

• 636 Distributing is not responsible for any legal repercussions from the use
of the WASPcam or from the sharing of footage

3

System Requirements

The camera requires a PC with the following specifications for full HD 1080p
30fps and 720p 60fps playback



Windows® 8 /Windows® 7 /Vista / XP (SP2) / MAC OS X 10.5 and later



Intel® / AMD Dual-Core CPU and later



At least 1 GB of RAM or higher



At least DirectX 9 video card, DirectX 10 is recommended



Standard USB 1.1 port and later



At least 2GB or greater available hard disk space

Features

The camera offers a variety of features and functions including



4K 2440P 24FPS, 2K 1440P (30fps), Full HD 1080p (60fps.)



H.264 Video Clip



170° Wide Angle Lens



WLAN 802.11 b/g/n



20 Megapixel Photos



Li-ion Rechargeable Battery



Smartphone App Supported – WASPcam App

4

ACCESSORIES

The following items should be in your the package. If any items are missing or
damaged, con your dealer immediately.

8Pin 2.0 USB cable

Micro USB Cable

Bar Mount

Helmet Mount

Tripod Mount Adapter

User Manual

Li-Ion Battery

Straight Joint Mount

3M Stickers

Wrist Remote

J-Hook Buckle

Wall Charger

Flat Mount w/3M Tape

Curved Mount w/3M Tape

5

Camera Function Quick Guide Diagram

Refer to the following illustrations to familiarize yourself with the buttons and
controls of this camera

6

BUTTON FUNCTIONS

Button Function

Power Button (Top Left)

Mode Button

M

Record Button (Top Right)

Menu Button

OK Button

OK

Left Button

Right Button To choose the next menu or file,

LED Light On/Off Button

To turn the camera on & off
To capture pictures when recording

To switch to picture mode, video mode and playback
mode

Start and stop taking photos/videos,
Returns to the photo/video mode when you are in
the menu

To enter / exit menu settings

To browse photos and videos, to enter and confirm
settings under setting mode, short press clear screen
character
To choose the last menu or file,
To zoom in image.
To Reverse playback under playback mode.

To zoom out image.
To fast forward playback under playback mode.
To open and close Wifi

7
